Sharp CD-MPX850 User manual

03/12/17 CD-MPX850 FRONT.fm
Thank you for purchasing this SHARP product.
To obtain the best performance from this product, please read this
manual carefully. It will guide you in operating your SHARP product.
MINI COMPONENT SYSTEM
CD-MPX850 Mini Component System consisting of CD-MPX850 (main
unit), CP-MPX850 (speaker system).
Accessories
Please confirm that the following accessories are included.
MODEL
OPERATION MANUAL
CD-MPX850
Note:
Only the above accessories are included.
Remote control 1
(RRMCGA122AWSA)
AM loop antenna 1
(QANTL0010AWZZ)
FM antenna 1
(92LFANT1535A)

03/12/17 CD-MPX850 02-42.fm
2
CD-MPX850
Important Instruction
SPECIAL NOTES
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER SERVIC-
ING TO QUALIFIED SERVICE PERSONNEL.
Explanation of Graphical Symbols:
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s en-
closure that may be of sufficient magnitude
to constitute a risk of electric shock to per-
sons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and main-
tenance (servicing) instructions in the lit-
erature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
Caution - use of any controls, adjustments or procedures
This product is classified as a CLASS 1 LASER PRODUCT
other than those specified herein may result in hazardous
radiation exposure.
Note to CATV system installer:
This reminder is provided to call the CATV system installer's
attention to Article 820-40 of the National Electrical Code that
provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of
cable entry as practical.
NOTE
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful in-
terference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to ra-
dio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
WARNING
FCC Regulations state that any unauthorized changes or modifications
to this equipment not expressly approved by the manufacturer could void
the user's authority to operate this equipment.
NOTES
It is the intent of Sharp that this product be used in full compliance
with the copyright laws of the United States and that prior permission
be obtained from copyright owners whenever necessary.
Licensed under one or more of U.S. Pat. 4,972,484, 5,214,678,
5,323,396, 5,530,655, 5,539,829, 5,544,247, 5,606,618, 5,610,985,
5,740,317, 5,777,992, 5,878,080 or 5,960,037. 0303
FOR YOUR RECORDS
For your assistance in reporting this unit in case of loss or theft,
please record below the model number and serial number which
are located on the rear of the unit.
Please retain this information.
Model number .......................................................
Serial number .......................................................
Date of purchase .......................................................
Place of purchase .......................................................
0202

03/12/17 CD-MPX850 02-42.fm
3
CD-MPX850
Important Instruction
IMPORTANT SAFETY INSTRUCTIONS
Electricity is used to perform many useful functions, but it can also
cause personal injuries and property damage if improperly handled.
This product has been engineered and manufactured with the
highest priority on safety. However, improper use can result in
electric shock and/or fire. In order to prevent potential danger, please
observe the following instructions when installing, operating and
cleaning the product. To ensure your safety and prolong the service
life of this product, please read the following precautions carefully
before use.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult an electrician
for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from
the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for
long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
Additional Safety Information
15) Power Sources - This product should be operated only from the
type of power source indicated on the marking label. If you are
not sure of the type of power supply to your home, consult your
product dealer or local power company. For product intended
to operate from battery power, or other sources, refer to the
operating instructions.
16) Overloading - Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in a risk of
fire or electric shock.
17) Object and Liquid Entry - Never push objects of any kind into
this product through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product.

03/12/17 CD-MPX850 02-42.fm
4
CD-MPX850
Important Instruction
IMPORTANT SAFETY INSTRUCTIONS
(continued)
18) Damage Requiring Service - Unplug this product from the wall
outlet and refer servicing to qualified service personnel under
the following conditions :
a) When the AC cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the
product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following
the operating instructions. Adjust only those controls
that are covered by the operating instructions as an
improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the product to its normal
operation,
e) If the product has been dropped or damaged in
any way, and
f) When the product exhibits a distinct change in
performance - this indicates a need for service.
19) Replacement Parts - When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer or have the same characteristics
as the original part. Unauthorized substitutions may result in
fire, electric shock, or other hazards.
20) Safety Check - Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
21) Wall or ceiling mounting - When mounting the product on a wall
or ceiling, be sure to install the product according to the method
recommended by the manufacturer.
22) Power Lines - An outside antenna system should not be located
in the vicinity of overhead power lines or other electric light or
power circuits,or where it can fall into such power lines or circuits.
When installing an outside antenna system, extreme care should
be taken to keep from touching such power lines or circuits as
contact with them might be fatal.
23) Outdoor Antenna Grounding - If an outside antenna or cable system
is connected to the product, be sure the antenna or cable system is
grounded so as to provide some protection against voltage surges
and built-up static charges. Article810 of the National Electrical Code,
ANSI/NFPA 70, provides information with regards to proper grounding
of the mast and supporting structure, grounding of the lead-in wire to
an antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
24) Protective Attachment Plug - The product is equipped with an attachment
plug having overload protection. This is a safety feature. See Instruction
Manual for replacement or resetting of protective device. If replacement
of the plug is required, be sure the service technician has used a replace-
ment plug specified by the manufacturer that has the same overload
protection as the original plug.
25) Stand - Do not place the product on an unstable cart, stand, tripod or
table. Placing the product on an unstable base can cause the product to
fall, resulting in serious personal injuries as well as damage to the product.
Use only a cart, stand, tripod, bracket or table recommended by the
manufacturer or sold with the product. When mounting the product on a
wall, be sure to follow the manufacturer's intructions. Use only the mounting
hardware recommended by the manufacturer.
ANTENNA LEAD IN WIRE
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
NEC - NATIONAL ELECTRICAL CODE
S2898A
ELECTRIC
SERVICE
EQUIPMENT
GROUND
CLAMP
Example of antenna grounding as per
National Electrical Code, ANSI/NFPA 70
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)

03/12/17 CD-MPX850 02-42.fm
5
CD-MPX850
General Information
Special Note
Supply of this product does not convey a license nor imply any right
to distribute content created with this product in revenue-generating
broadcast systems (terrestrial, satellite, cable and/or other distribu-
tion channels), revenue-generating streaming applications (via Inter-
net, intranets and/or other networks), other revenue-generating
content distribution systems (pay-audio or audio-on-demand appli-
cations and the like) or on revenue-generating physical media (com-
pact discs, digital versatile discs, semiconductor chips, hard drives,
memory cards and the like). An independent license for such use is
required. For details, please visit http://mp3licensing.com
MPEG Layer-3 audio coding technology licensed from Fraunhofer
IIS and Thomson.
Contents
Page
 General Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 9
 Preparation for Use
System connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 - 12
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
 Basic Operation
General control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Setting the clock (Remote control only). . . . . . . . . . . . . . . . . . 15
 CD or MP3/WMA disc Playback
Listening to a CD or MP3/WMA disc . . . . . . . . . . . . . . . . .16 - 19
Advanced CD or MP3/WMA disc playback . . . . . . . . . . . .20 - 22
MP3/WMA navigation (only for MP3/WMA files) . . . . . . . .23 - 26
 Radio
Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 - 28
 Tape Playback
Listening to a cassette tape (TAPE 1 or TAPE 2) . . . . . . .29 - 30
 Tape Recording
Recording on a cassette tape . . . . . . . . . . . . . . . . . . . . . . .30 - 32
 Advanced Features
Timer and sleep operation (Remote control only). . . . . . .33 - 36
Enhancing your system . . . . . . . . . . . . . . . . . . . . . . . . . . .37 - 38
 References
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38 - 40
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41 - 42
CONSUMER LIMITED WARRANTY . . . . . . . . . . . . . .Back cover
ENERGY STAR®Program Information
Products that have earned
the ENERGY STAR®are
designed to protect the
environment through
superior energy efficiency.
To comply with the ENERGY STAR®standards mentioned above,
please cancel the demonstration mode, as described on page 12.
ENERGY STAR®is a U.S. registered mark.

03/12/17 CD-MPX850 02-42.fm
6
CD-MPX850
General Information
Precautions
 General
 Please ensure that the equipment is positioned in a well ventilated
area and ensure that there is at least 4" (10 cm) of free space
along the sides, top and back of the equipment.
 Do not place anything on top of the unit.
 Do not expose the unit to moisture, to temperatures higher than
140 ˚
F (60
˚
C) or to extremely low temperatures.
 If your system does not work properly, disconnect the AC power
cord from the AC outlet. Plug the AC power cord back in, and then
turn on your system.
 This unit should only be used within the range of 41 ˚ F - 95 ˚ F
(5 ˚ C - 35 ˚ C).
Warning:
The voltage used must be the same as that specified on this unit.
Using this product with a higher voltage other than that which is
specified is dangerous and may result in a fire or other type of
accident causing damage. SHARP will not be held responsible for
any damage resulting from use of this unit with a voltage other than
that which is specified.
 Volume control
The sound level at a given volume setting depends on speaker
efficiency, location, and various other factors. It is advisable to avoid
exposure to high volume levels, which occurs while turning the unit
on with the volume control setting up high, or while continually
listening at high volumes.
 Use the unit on a firm, level surface free from
vibration.
 Keep the unit away from direct sunlight,
strong magnetic fields, excessive dust,
humidity and electronic/electrical equip-
ment (home computers, facsimiles, etc.)
which generate electrical noise.
 In case of an electrical storm, unplug the
unit for safety.
4" (10 cm)
Table
4" (10 cm) 4" (10 cm)
4" (10 cm)
 Hold the AC power plug by the head when
removing it from the AC outlet, as pulling
the cord can damage internal wires.
 The AC power plug is used as disconnect
device and shall always remain readily
operable.
 Do not remove the outer cover, as this
may result in electric shock. Refer
internal service to your local SHARP
service facility.
ACINPUT

03/12/17 CD-MPX850 02-42.fm
7
CD-MPX850
General Information
Controls and indicators
 Front panel
Reference page
1. Disc Trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2. Timer Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4. CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5. Power On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . 14
6. Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
7. Game/Video Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
8. Tape 1 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . 29
9. Headphone Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
10. Game/Video Input Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
11. Disc Tray Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . 17
12. Disc Number Select Buttons . . . . . . . . . . . . . . . . . . . . . . . . 17
13. Volume Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
14. CD or Tape Stop Button . . . . . . . . . . . . . . . . . . . . . . . . 18, 30
15. CD Play or Repeat, Tape Play Button . . . . . . . . . . . 17, 21, 29
16. CD Track Up or Fast Forward, Tape 2 Fast Forward,
Tuner Preset Up, Time Up Button . . . . . . . . . . 15, 18, 28, 30
17. CD Track Down or Fast Reverse, Tape 2 Rewind,
Tuner Preset Down, Time Down Button . . . . . . 15, 18, 28, 30
18. Tape 2 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . 29
19. Remote Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

03/12/17 CD-MPX850 02-42.fm
8
CD-MPX850
General Information
Controls and indicators (continued)
 Display
Reference page
1. Disc Number Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2. MP3/WMA Folder Indicator . . . . . . . . . . . . . . . . . . . . . . . . . 23
3. MP3/WMA Title Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4. MP3 Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5. WMA Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6. Sleep Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
7. Timer Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
8. Timer Recording Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 34
9. Tape 2 Record Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
10. MP3/WMA Total Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 24
11. Daily Timer Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
12. FM Stereo Mode Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 27
13. FM Stereo Receiving Indicator . . . . . . . . . . . . . . . . . . . . . . 27
14. Tape Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
15. Memory Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22, 28
16. Extra Bass Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
17. Disc Repeat Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . 21
18. Disc Pause Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
19. Disc Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
 Rear panel
Reference page
1. Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2. AC Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3. FM 75 Ohms Antenna Jack . . . . . . . . . . . . . . . . . . . . . . . . . 11
4. AM Antenna Ground Terminal . . . . . . . . . . . . . . . . . . . . . . 11
5. AM Loop Antenna Terminal . . . . . . . . . . . . . . . . . . . . . . . . . 11
6. Speaker Light-up Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7. Video out Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
8. Front Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
 Speaker system
AC INPUT
3
6
7
4
5
8
2
1
12 3 45 6789
11 12 13
10 14
15
16 17
18 19
1. Tweeter
2. Super Tweeter
3. Woofer
4. Bass Reflex Duct
5. Speaker Wire
6. Speaker Light-Up Wire
1
2
3
4
56

03/12/17 CD-MPX850 02-42.fm
9
CD-MPX850
General Information
 Remote control
Reference page
1. Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . 13
2. Disc Number Select Buttons . . . . . . . . . . . . . . . . . . . . . . . . 17
3. Clock/Timer Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 33
4. Character Input/Disc Direct Search Buttons . . . . . . . . 20, 25
5. Equalizer Mode Select Button . . . . . . . . . . . . . . . . . . . . . . 14
6. Extra Bass/Demo Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7. Power On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . 14
8. CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
9. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
10. Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
11. Game/Video Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
12. Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . 14
13. Disc Clear/Dimmer Button . . . . . . . . . . . . . . . . . . . . . . 14, 22
14. Disc Random Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
15. Disc Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
16. Tape Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
17. Memory Button . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 22, 28, 33
18. Disc Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
19. Disc Play or Repeat Button . . . . . . . . . . . . . . . . . . . . . . 17, 21
20. Tape Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
21. Tape 2 Record Pause Button . . . . . . . . . . . . . . . . . . . . . . . 31
22. Tuning Up, Cursor Up Button . . . . . . . . . . . . . . . . . . . . . . . 23
23. Disc Track Up or Fast Forward, Tape Fast Forward,
Tuner Preset Up, Time Up, Cursor Right Button . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 18, 28, 30
24. Disc Track Down or Fast Reverse, Tape Rewind,
Tuner Preset Down, Time Down, Cursor Left Button . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 18, 28, 30
25. Tuning Down, Cursor Down Button . . . . . . . . . . . . . . . . . . 23
26. MP3/WMA Navigation Mode Select Button . . . . . . . . . . . . 23
27. Character Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
28. MP3/WMA Display Button . . . . . . . . . . . . . . . . . . . . . . . . . . 19
29. Enter Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
1
2
3
5
6
12
4
8
9
7
10
11
17
19
18
13
15
14
21
20
16
25
24
22 23
26 27 2829

03/12/17 CD-MPX850 02-42.fm
10
CD-MPX850
Preparation for Use
System connections
AC INPUT
Left speaker
Right speaker
Speaker connection
(see page 11)
Antenna connection (see page 11)
Make sure to unplug the AC power cord before any connections.
FM antenna AM loop antenna
AC outlet
(AC 120 V, 60 Hz)
AC power connection (see page 12)
Speaker light-up wire Speaker light-up wire

03/12/17 CD-MPX850 02-42.fm
11
CD-MPX850
Preparation for Use
 Antenna connection
Note:
Placing the antenna on the unit or near the AC power cord may
cause noise pickup. Place the antenna away from the unit for better
reception.
Installing the AM loop antenna:
 Speaker connection
Connect the black wire to the FRONT SPEAKERS minus (-) terminal,
and the red wire to the FRONT SPEAKERS plus (+) terminal.
 Speaker Light-Up connection
1. Connect the speaker light-up wires to the SPEAKERS LIGHT-UP
jacks for speaker illumination. To turn off the speaker light-up
feature, press the CLEAR/DIMMER button on the remote control
for 2 seconds or more.
Note:
Placing the right speaker light-up wire to the RIGHT jack and the left
speaker light-up wire to the LEFT jack.
Caution:
Supplied FM antenna:
Connect the FM antenna wire to the
FM 75 OHMS jack and position the FM
antenna wire in the direction where the
strongest signal can be received.
Supplied AM loop antenna:
Connect the AM loop antenna to the
AM and GND terminals. Position the
AM loop antenna for optimum
reception. Place the AM loop antenna
on
a shelf, etc., or attach it to a stand
or a wall with screws (not supplied).
< Assembling > < Attaching to the wall >
Wall Screws (not supplied)
AM loop
antenna
FM
antenna
AC INPUT
Black
Red
 Use speakers with an impedance of 6 ohms or more, as lower
impedance speakers can damage the unit.
 Do not mistake the right and the left
channels. The right speaker is the one on the
right side when you face the unit.
 Do not let the bare speaker wires touch
each other.
 Do not stand or sit on the speakers. You may
be injured.
 Do not allow any objects to fall into or to be
placed in the bass reflex duct.
Incorrect
AC INPUT
LEFT SPEAKER RIGHT SPEAKER

03/12/17 CD-MPX850 02-42.fm
12
CD-MPX850
Preparation for Use
System connections (continued)
 AC power connection
After checking all the connections have been made correctly, plug
the AC power cord of this unit into the AC outlet. If you plug in the unit
first, the unit will enter the demonstration mode.
Notes:
 The unit will start the tape initialization when plugged in to the AC
outlet. During this process, initializing sound will be heard and the
unit cannot be turned on. Wait until the process is finished.
 Unplug the AC power cord from the AC outlet if the unit will not be
in use for a prolonged period of time.
 Demonstration mode
 Outdoor FM antenna
Use an outdoor FM antenna if you require better reception. Consult
your dealer.
Note:
When an outdoor FM antenna is used, disconnect the supplied FM
antenna wire.
Cooling fan:
The main unit is built with a cooling fan at the rear of the unit for
improved cooling. Please do not cover the opening of the fan with
any obstacles, as this will block proper ventilation.
AC INPUT
AC outlet
(AC 120 V, 60 Hz)
AC INPUT
The first time the unit is plugged in, the
unit will enter the demonstration mode.
You will see words scroll and the speaker
will light up in flashing mode.
To cancel the demonstration mode:
When the unit is in the power
stand-by mode (demonstration
mode), press the X-BASS/DEMO
button. The unit will enter the low
power consumption mode and the
speaker light up will be off.
To return to the demonstration mode:
When the unit is in the power stand-by mode, press the
X-BASS/DEMO button again.
Note:
When the power is on, the X-BASS/DEMO button can be used to
select the extra bass mode.
Outdoor
FM antenna
75 ohms
coaxial cable

03/12/17 CD-MPX850 02-42.fm
13
CD-MPX850
Preparation for Use
Remote control
Battery installation
Precautions for battery use:
Replace all old batteries with new ones at the same time.
Do not mix old and new batteries.
Remove the batteries if the unit will not be used for long periods
of time. This will prevent potential damage due to battery leakage.
Caution:
Do not use rechargeable batteries (nickel-cadmium battery, etc.).
Installing the batteries incorrectly may cause the unit to
malfunction.
Battery removal:
Open the battery cover and pull up the battery to take out.
Notes concerning use:
Replace the batteries if the operating distance is reduced or if the
operation becomes erratic.
Periodically clean the transmitter on the remote control and the
sensor on the unit with a soft cloth.
Exposing the sensor on the unit to strong light may interfere with
operation. Change the lighting or the direction of the unit.
Keep the remote control away from moisture, heat, shock, and
vibrations.
Test of the remote control
Check the remote control after checking all the connections (see
pages 10 - 12).
Point the remote control directly at the remote sensor on the unit.
The remote control can be used within the range shown below:
Press the ON/STAND-BY button. Does the power turn on? Now, you
can enjoy music.
Use 2 “AA” size batteries (UM/SUM-3, R6, HP-7 or similar).
Batteries are not included.
1 Open the battery cover.
2 Insert the batteries according to the direction indicated in
the battery compartment.
When inserting or removing the batteries, push them toward the
battery terminals.
3 Close the battery cover.
Remote sensor

03/12/17 CD-MPX850 02-42.fm
14
CD-MPX850
Basic Operation
General control
To turn the power on
Press the ON/STAND-BY button to turn the power on.
Illumination light control
When the power is turned on, light illuminates around the display.
To turn on/off the light, hold down the CLEAR/DIMMER button on
the remote control for 2 seconds or more.
Speaker light up control
The speaker will light up according to the level of the music source
played back. To turn on/off the light, hold down the CLEAR/DIMMER
button on the remote control for 2 seconds or more.
Volume auto fade-in
If you turn off and on the main unit with the volume set to 27 or
higher, the volume starts at 16 and fades in to the last set level.
Volume control
Equalizer
When the power is first turned on, the unit will enter FLAT mode.
When the EQUALIZER MODE button is pressed, the current mode
setting will be displayed. To change to a different mode, press the
EQUALIZER MODE button repeatedly until the desired sound mode
appears.
Note:
If the EQUALIZER MODE button is pressed in the surround mode, it
will be canceled automatically.
After use:
Press the ON/STAND-BY button to enter the power stand-by mode.
Main unit operation:
When the VOLUME control is turned
clockwise, the volume will increase.
When it is turned counterclockwise, the
volume will decrease.
Remote control operation:
Press the VOLUME (+ or –) button to in-
crease or decrease the volume.
In CD/TUNER/TAPE mode In GAME/VIDEO mode
30 MAXIMUM0.....
POPS
VOCALS
JAZZ
FLAT
ROCK
CLASSIC
For rock music.
For pop music.
No equalization.
For classical music.
For jazz.
Vocals are enhanced.
ACTION
SPORTS
RACING
FLAT
ROCK
CLASSIC
For rock music.
For action games.
No equalization.
For classical music.
For car racing games.
For sports games.

03/12/17 CD-MPX850 02-42.fm
15
CD-MPX850
Basic Operation
Setting the clock (Remote control only)
In this example, the clock is set for the 12-hour (AM 12:00) display.
To confirm the time display:
[When the unit is in the stand-by mode]
Press the CLOCK/TIMER button.
The time display will appear for about 10 seconds.
[When the power is on]
Press the CLOCK/TIMER button.
Within 10 seconds, press the or button to display the
time.
The time display will appear for about 10 seconds.
Note:
The “CLOCK” will appear or time will flash to confirm the time
display when the AC power supply is restored after a power failure
or unplugging the unit. If incorrect, readjust the clock as follows.
To readjust the clock:
Perform “Setting the clock” from step 1. If the “CLOCK” does not
appear in step 3, step 4 (for selecting the 12-hour or 24-hour
display) will be skipped.
To change the 12-hour or 24-hour display:
1Press the ON/STAND-BY button to turn the power on.
2Press the CLOCK/TIMER button.
3Within 10 seconds, press the or button to
select “CLOCK”, and press the MEMORY button.
4Press the or button to select 12-hour or 24-
hour display and then press the MEMORY button.
“AM 12:00” The 12-hour display will appear.
(AM 12:00 - PM 11:59)
“AM 0:00” The 12-hour display will appear.
(AM 0:00 - PM 11:59)
“0:00” The 24-hour display will appear.
(0:00 - 23:59)
5Press the or button to adjust the hour and
then press the MEMORY button.
Press the or button once to advance the time by
1 hour. Hold it down to advance continuously.
6Press the or button to adjust the minutes and
then press the MEMORY button.
Press the or button once to advance the time by
1 minute. Hold it down to change the time in 5-minutes inter-
vals.
1 Clear all the programmed contents. [Refer to “Clearing all the
memory (reset)” on page 40 for details.]
2 Perform “Setting the clock” from step 1.

03/12/17 CD-MPX850 02-42.fm
16
CD-MPX850
CD or MP3/WMA disc Playback
Listening to a CD or MP3/WMA disc
This system can play back a standard CD, CD-R/RW in the CD format
and CD-R/RW with MP3 or WMA files, but cannot record on them.
Some audio CD-R and CD-RW discs may not be playable due to the
state of the disc or the device that was used for recording.
MP3:
MP3 is a form of compression. It is an acronym which stands
for MPEG Audio Layer 3.
MP3 is a type of audio code which is processed by significant
compression from the original audio source with very little loss
in sound quality.
This system supports MPEG 1 Layer 3, MPEG 2 Layer 3, and
VBR files.
During VBR file playback, time counter in the display may differ
from its actual playback time.
WMA:
WMA files are Advanced System Format files that include audio
files which are compressed with Windows Media Audio codec.
WMA is developed by Microsoft as an audio format file for Win-
dows Media Player.
“MP3” or “WMA” indicator will light up after the unit reads infor-
mation on an MP3 or WMA disc.
Auto power on function:
When you press any of the following buttons, the unit turns on.
CD button (main unit and remote control): The unit turns on and
the “CD” function is activated.
CD / button on the remote control: The unit turns on and CD
playback starts (regardless of the last function).
/ button on the main unit: The unit turns on and playback of
the last function starts (CD,TAPE,TUNER,GAME/VIDEO).
Auto power off function:
In the stop mode of CD, MP3 or WMA operation, the main unit enters
the stand-by mode after 15 minutes of inactivity.

03/12/17 CD-MPX850 02-42.fm
17
CD-MPX850
CD or MP3/WMA disc Playback
1Press the ON/STAND-BY button to turn the power on.
2Press the CD button.
3Press the 1 button and within 5 seconds, press the
button to open the disc tray 1.
4Place the disc on the disc tray 1, label side up.
Be sure to place 3" (8 cm) disc in the middle of the disc trays.
5Press //
// button to close the disc tray 1.
Due to the structure of the disc information, it takes longer to
read an MP3/WMA disc than a normal CD (approximately 20
to 90 seconds).
6You can place discs on the trays 2 - 5 by following steps
3 - 5.
7Press the / button to start playback.
5" (12 cm) 3" (8 cm)
[CD]
Total number of
tracks on the disc
Total playing
time of the disc
Total number
of folders
Total number
of files
MP3 indicator
[MP3/WMA] WMA indicator
Disc play indicator

03/12/17 CD-MPX850 02-42.fm
18
CD-MPX850
CD or MP3/WMA disc Playback
Listening to a CD or MP3/WMA disc (continued)
Playback will begin from track 1 on disc 1. After that disc finishes
playing, the next disc will automatically play.
After the last track on the fifth disc is played, the unit will stop
automatically.
When there is no disc in one of the disc trays (1 - 5), the empty
tray will be skipped to the next tray with a disc.
To exchange other discs while playing a disc:
Press one of the 1 - 5 buttons for the stopped disc and within 5
seconds, press the button and exchange discs.
To remove the discs:
In the stop mode, press the 1 - 5 buttons and within 5 seconds,
press the button.
Caution:
Do not place two discs in a same tray.
Do not play discs of special shapes (heart, octagon, etc.) as it
may cause malfunctions.
Do not push the disc tray while it is moving.
If the power fails while the tray is open, wait until the power is
restored.
If the disc tray is stopped with force, “ER-CD20” will appear on the
display for 3 seconds and the unit will not function. If this occurs,
press the ON/STAND-BY button to enter the power stand-by
mode and then turn the power on again.
If TV or radio interference occurs during CD operation, move the
unit away from the TV or radio.
If a disc is damaged, dirty, or loaded upside down, the disc will
skip or not play.
Various disc functions
Function Main unit Remote
control
Operation
Play Press in the stop
mode.
Stop Press in the playback
mode.
Pause Press in the playback
mode. Press the /
button to resume play-
back from the paused
point.
Track up/
Track down
Press in the playback
or stop mode.
If you press the button
in the stop mode,
press the / button
to start the desired
track.
Fast for-
ward/Fast
reverse
Press and hold down
in the playback mode.
Release the button to
resume playback.

03/12/17 CD-MPX850 02-42.fm
19
CD-MPX850
CD or MP3/WMA disc Playback
Notes for CD:
Notes for MP3/WMA discs:
Track up/track down is possible only within individual discs.
The sound is heard during fast forward/fast reverse with a CD, but
not with an MP3/WMA disc. For fast forward or fast reverse of an
MP3/WMA disc, refer to playback time on the display.
Fast forward/fast reverse is possible only within individual tracks.
When the end of the track is reached during fast forward, the next
track will be played. Playback of the track will begin when its be-
ginning is reached during fast reverse.
To change the display (MP3/WMA discs only)
Track up/track down is possible only within individual discs.
Fast forward/fast reverse is possible only within individual discs.
When the end of the last track is reached during fast forward,
“END” will appear on the display and CD operation will be paused.
When the beginning of the first track is reached during fast
reverse, the unit will enter the playback mode.
While a disc is playing, press the DISPLAY
button.
Each time the button is pressed, the display
will change as follows.
Folder name
File name
Track number Elapsed
playback time

03/12/17 CD-MPX850 02-42.fm
20
CD-MPX850
CD or MP3/WMA disc Playback
Advanced CD or MP3/WMA disc playback
To specify a disc to play
You can play a disc by specifying the disc number.
Playback will begin from track 1 on the chosen disc.
After the last track on the last disc is played, the unit stops auto-
matically.
Note:
If a disc tray with no disc is selected, playback will not start and the
disc indicator will disappear.
To stop playback:
Press the (CD ) button.
Direct track search
By using the direct search buttons, the desired tracks on the current
disc can be played.
If the direct search buttons are pressed while the disc is stopped,
press the / button to start the desired track on the current disc.
Notes:
A track number higher than the number of tracks on the disc
cannot be selected.
During random play, direct search is not possible.
1Press one of the 1 - 5 buttons to select the desired disc.
Selected disc number
2Within 5 seconds, press the / button on the main unit.
Use the direct search buttons on
the remote control to select the
desired track while playing the
selected disc.
Selected track number
The direct search buttons allow you to select up to number 9.
When selecting number 10 or higher, use the “+10” button.
A. For example, to choose 13
1 Press the “+10” button once.
2 Press the “3” button.
B. For example, to choose 30
1 Press the “+10” button three times.
2 Press the “0” button.
