Sharp CD-XP160W User manual

MINI COMPONENT SYSTEM
MODEL
CD-XP160W
OPERATION MANUAL
Thank you for purchasing this SHARP product.
To obtain the best performance from this product, please read
this manual carefully. It will guide you in operating your SHARP
product.
CD-XP160W Mini Component System consisting of CD-XP160W
(main unit) and CP-XP160 (speaker system).
*CDXP160WSCA_FRONT 02.12.20, 4:09 PM1

1
02/5/27 CD-XP160W(SCA)E1.fm
CD-XP160W
Important Instruction
- Introduction / Special notes -
Introduction
Thank you for purchasing this SHARP product. To obtain the best
performance from this product, please read this manual carefully. It
will guide you in operating your SHARP product.
Special notes
Warning:
z When the ON/STAND-BY button is set at STAND-BY position,
mains voltage is still present inside the unit. When the ON/
STAND-BY button is set at STAND-BY position, the unit may be
brought into operation by the timer mode or remote control.
z This unit contains no user serviceable parts. Never remove cov-
ers unless qualified to do so. This unit contains dangerous volt-
ages, always remove mains plug from the socket before any
service operation and when not in use for a long period.
z To prevent fire or shock hazard, do not expose this appliance to
dripping or splashing. No objects filled with liquids, such as
vases, should be placed on the apparatus.
CAUTION
z This product is classified as a CLASS 1 LASER product.
z Use of controls, adjustments or performance of procedures other
than those specified herein may result in hazardous radiation ex-
posure.
As the laser beam used in this compact disc player is harmful to
the eyes, do not attempt to disassemble the cabinet. Refer servic-
ing to qualified personnel only.
Laser Diode Properties
Material: GaAIAs
Wavelength: 780 nm
Emission Duration: continuous
Laser Output: max. 0.6 mW
Note for users in Australia:
Copyright may exist in material you wish to record. Copying or
broadcasting such material without permission of the relevant lic-
ensees or owners of the copyright is prohibited by law. SHARP is not
in a position to authorise the copying or broadcasting of copyright
materials and nothing in this OPERATION MANUAL should be
implied as giving that authority.
For other countries:
Audio-visual material may consist of copyrighted works which must
not be recorded without the authority of the owner of the copyright.
Please refer tothe relevant laws in your country.

02/5/27 CD-XP160W(SCA)E1.fm
2
CD-XP160W
General Information
- Accessories / Contents -
Accessories
Please confirm that the following accessories are included.
Note:
Only the above accessories are included.
Contents
Page
T General Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 6
T Preparation for Use
System connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 10
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
T Basic Operation
Sound control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
T CD Playback
Listening to a CD (CDs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14, 15
Advanced CD playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16, 17
T Radio
Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18,19
Page
T Tape Playback
Listening to a cassette tape . . . . . . . . . . . . . . . . . . . . . . . . 19, 20
T Karaoke
Playing karaoke . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
T Tape Recording
Recording to a cassette tape . . . . . . . . . . . . . . . . . . . . . . . 22, 23
T Advanced Features
Timer and sleep operation . . . . . . . . . . . . . . . . . . . . . . . . . 24, 25
T References
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26, 27
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . End of the manual
Remote control 1 "AA" size battery
(UM/SUM-3, R6,
HP-7 or similar) 2
AM loop aerial 1 AA FM aerial 1 AA AC power lead 1

02/5/27 CD-XP160W(SCA)E1.fm
3
CD-XP160W
General Information
- Precautions -
Precautions
 General
z Please ensure that the equipment is positioned in a well venti-
lated area and ensure that there is at least 10 cm (4") of free
space along the sides, top and back of the equipment.
z Use the unit on a firm, level surface free from vibration.
z Keep the unit away from direct sunlight, strong magnetic fields,
excessive dust, humidity and electronic/electrical equipment
(home computers, facsimiles, etc.) which generate electrical
noise.
z Do not place anything on top of the unit.
z Do not expose the unit to moisture, to temperatures higher than
60°C (140°F) or to extremely low temperatures.
z If your system does not work properly, disconnect the AC power
lead from the wall socket. Plug the AC power lead back in, and
then turn on your system.
z In case of an electrical storm, unplug the unit for safety.
z Hold the AC power plug by the head when removing it from the
wall socket, as pulling the lead can damage internal wires.
z Do not remove the outer cover, as this may result in electric
shock. Refer internal service to your local SHARP service
facility.
z The ventilation should not be impeded by covering the ventilation
openings with items, such as newspapers, tablecloths, curtains,
etc.
z No naked flame sources, such as lighted candles, should be
placed on the apparatus.
z Attention should be drawn to the environmental aspects of bat-
tery disposal.
z This unit should only be used within the range of 5°C - 35°C
(41°F - 95°F).
Warning:
The voltage used must be the same as that specified on this unit.
Using this product with a higher voltage other than that which is
specified is dangerous and may result in a fire or other typeof acci-
dent causing damage. SHARP will not be held responsible for any
damage resulting from use of this unit with a voltage other than that
which is specified.
 Volume control
The sound level at a given volume setting depends on speaker effi-
ciency, location, and various other factors. It is advisable to avoid
exposure to high volume levels. Do not turn the volume on to full at
switch on and listen to music at moderate levels.

02/5/27 CD-XP160W(SCA)E1.fm
4
CD-XP160W
General Information
- Controls and indicators -
Controls and indicators
 Front panel Reference page
1.Disc Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.Timer Set Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14, 22
6.CD Track Down or Fast Reverse,
Tuner Preset Down Button . . . . . . . . . . . . . . . . . . . . . . 15, 19
7.Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
8.CD Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
9.CD Play or Repeat Button . . . . . . . . . . . . . . . . . . . . . . . 14, 16
10. Microphone Level Control . . . . . . . . . . . . . . . . . . . . . . . . . . 21
11. Microphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
12. Tape 1 Cassette Compartment . . . . . . . . . . . . . . . . . . . 20, 23
13.Tape Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20, 23
14. CD Track Up or Fast Forward,
Tuner Preset Up Button . . . . . . . . . . . . . . . . . . . . . . . . . 15, 19
15. Equaliser Mode Select/Extra Bass/
Demo Mode Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10, 12
16. Disc Tray Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . 14
17. Disc Skip Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
18. Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . 12
19. Tuning Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
20. Tuning Down Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
21. Tape 2 Cassette Compartment . . . . . . . . . . . . . . . . . . . 20, 23
22.Tape 1 Record Button . . . . . . . . . . . . . . . . . . . . . . . . . . 22, 23
23. Tape 1 Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
24. Tape 1 Rewind Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
25. Tape 1 Fast Forward Button . . . . . . . . . . . . . . . . . . . . . . . . 20
26. Tape 1 Stop/Eject Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
27. Tape 1 Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
28. Tape 2 Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
29. Tape 2 Rewind Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
30. Tape 2 Fast Forward Button . . . . . . . . . . . . . . . . . . . . . . . . 20
31. Tape 2 Stop/Eject Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

02/5/27 CD-XP160W(SCA)E1.fm
5
CD-XP160W
General Information
- Controls and indicators -
Controls and indicators (continued)
T Display
1.CD Play Indicator
2.CD Repeat Play Indicator
3. FM Station Indicator
4.AM Station Indicator
5.Disc Number Indicators
6.Clock Indicator
7.Sleep Indicator
8.Timer Play Indicator
9.Tape 1 Record Indicator
10. CD Pause Indicator
11. FM Stereo Mode Indicator
12. FM Stereo Receiving Indicator
13. Memory Indicator
14. CD Random Play Indicator
15. Extra Bass Indicator
T Rear panel Reference page
1.AC Voltage Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2. AC Power Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.FM 75 Ohms Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . .7, 8
4.FM Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . .7, 8
5. AM Loop Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8
6. Span Selector Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
7. Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8
T Speaker system
1.Woofers
2.Bass Reflex Ducts
3.Speaker Wire

02/5/27 CD-XP160W(SCA)E1.fm
6
CD-XP160W
General Information
- Controls and indicators -
 Remote control Reference page
1.Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14, 22
4.Tape Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20, 23
5.Memory Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 17, 19
6.CD Track Down orFast Reverse,
Tuner Preset Down Button . . . . . . . . . . . . . . . . . . . . . . . . 15, 19
7.CD Play or Repeat Button . . . . . . . . . . . . . . . . . . . . . . . . 14, 16
8.CD Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
9.Equaliser Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . . 12
10.Clock Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 24
11. Timer Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
12. Disc Number Select Buttons . . . . . . . . . . . . . . . . . . 14, 17, 22
13. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
14. Programme Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
15.CD Random Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
16. CD Track Up or Fast Forward,
Tuner Preset Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 19
17. CD Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
18. Extra Bass Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
19. Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . 12
20. Sleep Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
1
2
3
4
5
6
7
8
9
11
10
15
18
14
13
12
16
17
19
20
Buttons with " " mark in the illustration or highlighted in bold on the
right can be operated on the remote control only.

02/5/27 CD-XP160W(SCA)E1.fm
7
CD-XP160W
Preparation for Use
- System connections -
System connections

02/5/27 CD-XP160W(SCA)E1.fm
8
CD-XP160W
Preparation for Use
- System connections -
T Aerial connection
Supplied FM aerial:
Connect the FM aerial wire to the FM 75 OHMS terminal and posi-
tion the FM aerial wire in the direction where the strongest signal
can be received.
Supplied AM loop aerial:
Connect the AM loop aerial to the AM LOOP socket. Position the
AM loop aerial for optimum reception. Place the AM loop aerial on a
shelf, etc., or attach it to a stand or a wall with screws (not supplied).
Note:
Placing the aerial on the unit or near theAC power lead may cause noise
pickup. Place the aerial away from the unit for better reception.
Installing the AM loop aerial:
External FM aerial:
Use an external FM aerial if you require better reception. Consult your
dealer.
Note:
When an external FM aerial is used, disconnect the supplied FM aerial
wire.
T Speaker connection
Connect the black wire to the minus (-) terminal and the red to the
plus (+) terminal.
Caution:
Notes:
z The speaker grilles are not removable.
z There is no physical distinction between the right and left speak-
ers.
< Assembling > < Attaching to the wall >
Wall Screws (not supplied)
External
FM aerial
75 ohm
coaxial
cable
z Use speakers with an impedance of 6 ohms or
more, as lower impedance speakers can damage
the unit.
z Do not mistake the right and the left channels. The
right speaker is the one on the right side when you
face the unit.
z Do not let the bare speaker wires touch each
other.
z Do not allow any objects to fall into or to be placed
in the bass reflex ducts.
z Do not stand or sit on the speakers. You may be in-
jured. Incorrect
Right speaker Left speaker

02/5/27 CD-XP160W(SCA)E1.fm
9
CD-XP160W
Preparation for Use
- System connections -
System connections (continued)
T Setting the AC voltage selector
Check the setting of the AC voltage selector located on the rear
panel before plugging the unit into a wall socket. If necessary, adjust
the selector to correspond to the AC power voltage used in your
area.
Turn the selector with a screwdriver until the appropriate volt-
age number appears in the window (110 V, 127 V, 220 V or 230 V
- 240 V AC).
T Connecting the AC power lead
After checking all the connections have been made correctly, con-
nect the AC power lead to the AC power inputsocket, then plug the
AC power lead of this unit into the wall socket. If you plug in the unit
first, the unit will enter the demonstration mode (see page 10).
Notes:
z Unplug the AC power lead from the wall socket if the unit will not
be in use for a prolonged period of time.
z Never use a power lead other than the one supplied. Otherwise, a
malfunction or an accident may occur.
AC Plug Adaptor
In areas (or countries) where a wall socket as shown in illustration
is used, connect the unit using the AC plug adaptor supplied with
the unit, as illustrated. The AC plug adaptor is notincluded in areas
where the wall socket and AC power plug can be directly connected
(see illustration ).

02/5/27 CD-XP160W(SCA)E1.fm
10
CD-XP160W
Preparation for Use
- System connections -
 Setting the FM/AM span selector
The International Telecommunication Union (ITU) has established
that member countries should maintain either a 100 kHz or a 50 kHz
interval between broadcasting frequencies of FM stations and 10
kHz or 9 kHz for AM station. The illustration shows the 50/9 kHz
zones (regions 1 and 3),and the 100/10 kHz zone (region 2).
Before using the unit, set the
SPAN SELECTOR switch (on the rear
panel) to the interval (span) of your area.
To change the tuning zone:
Caution:
This operation will erase all data stored in memory including clock,
timer settings, tuner preset, and CD programme.
 Demonstration mode
To cancel the demonstration mode:
When the unit is in the power stand-by mode (demonstration mode),
press the EQUALIZER/X-BASS/DEMO button. The demonstration
modewill be cancelled and the display
will disappear .
To return to the demonstration mode:
When the unit is in the power stand-by mode, press the EQUAL-
IZER/X-BASS/DEMO button again.
Note:
When the power is on, the EQUALIZER/X-BASS/DEMO button can
be used to select the pre-programmed equaliser and extra bass
modes.
 To turn the power on
Press the ON/STAND-BY button to turn the power on.
1 Press the ON/STAND-BY button to enter the stand-by mode.
2 Set the SPAN SELECTOR switch (on the rear panel) as follows.
z For 100 kHz FM interval (10 kHz in AM) 100/10
z For 50 kHz FM interval (9 kHz in AM) 50/9
3 Whilst pressing down the TUNER (BAND) button and the DISC
SKIP button, press the ON/STAND-BY button until "CLEAR" ap-
pears.
The first time the unit is plugged in, the
unit will enter the demonstration mode.
You will see words scroll.
After use:
Press the ON/STAND-BY button to enter the power stand-by
mode.

02/5/27 CD-XP160W(SCA)E2..fm
11
CD-XP160W
Preparation for Use
- Remote control -
Remote control
T Battery installation
Precautions for battery use:
z Replace all old batteries with new ones at the same time.
z Do not mix old and new batteries.
z Remove the batteries if the unit is not to be used for long periods
of time. This will prevent potential damage due to battery leak-
age.
Caution:
z Do not use rechargeable batteries (nickel-cadmium battery, etc.).
z Installing the batteries incorrectly may cause the unit to malfunc-
tion.
Notes concerning use:
z Replace the batteries if the operating distance is reduced or if the
operation becomes erratic. Purchase 2 "AA" size batteries (UM/
SUM-3, R6, HP-7 or similar).
z Periodically clean the transmitter on the remote control and the
sensor on the unit with a soft cloth.
z Exposing the sensor on the unit to strong light may interfere with
operation. Change the lighting or the direction of the unit.
z Keep the remote control away from moisture, heat, shock, and
vibrations.
T Test of the remote control
Check the remote control after checking all the connections (see
pages 7 - 9).
Point the remote control directly at the remote sensor on the unit.
The remote control can be used within the range shown below:
Press the ON/STAND-BY button. Does the power turn on? Now, you
can enjoy music.
1 Remove the battery cover.
2 Insert the batteries according to the direction indicated in
the battery compartment.
When inserting or removing thebatteries, push them towards the
battery terminals.
3 Replace the cover.
0.2 m - 6 m
(8" - 20')
Remote sensor

02/5/27 CD-XP160W(SCA)E2..fm
12
CD-XP160W
Basic Operation
- Sound control -
Sound control
T Volume control
Main unit operation:
Press
the or button
to increase or decrease the volume.
Remote control operation:
Press the VOLUME (+ or -) button to increase or decrease the vol-
ume.
T Pre-programmed equaliser/Extra bass
(X-BASS)
When the power is first turned on, the unit enters the X-BASS mode,
“X-BASS” is lit and the equaliser is set to FLAT.
Changing the mode:
Press the EQUALIZER/X-BASS/DEMO (EQUALIZER MODE) but-
ton repeatedly until the desired sound mode appears.
To enter or cancel the extra bass mode by the remote control:
Press the X-BASS button to light up “X-BASS”. The unit enters the
extra bass mode. Turn off “X-BASS” to cancel the extra bass mode.
12 29 30 VOLMAXVOLMIN .....
ROCK (X-BASS off)
FLAT (X-BASS on)
FLAT (X-BASS off)
CLASSIC (X-BASS off)
The sound is not modified.
Bass frequencies are emphasised.
Bass and treble are emphasised.
POPS (X-BASS off)
Bass and treble are slightly emphasised.
JAZZ (X-BASS off) Treble is cut a little.
Treble is reduced a lot.
VOCAL (X-BASS off)
Vocals (midrange tones) are emphasised.

02/5/27 CD-XP160W(SCA)E2..fm
13
CD-XP160W
Basic Operation
- Setting the clock -
Setting the clock
This may be operated only with the remote control.
In this example, the clock is set for the 24-hour (0:00) display.
To confirm the time display:
Press the CLOCK button.
The time display will appear for about 8 seconds.
Note:
The time will flash at the push of the CLOCK button when the AC
power supply is restored after a power failure or unplugging the unit.
Readjust the clock as follows.
To readjust the clock:
Perform "Setting the clock" from the beginning. If the "0:00" is not
flashing in step 2, step 3 (for selecting the 24-hour or 12-hour dis-
play) will be skipped.
To change the 24-hour or 12-hour display:
1 Press the ON/STAND-BY button to turn the power on.
2 Press the CLOCK button and within 8 seconds, press the
MEMORY button.
3 Within 30 seconds, press the PRESET ( or ) button to
select 24-hour or 12-hour display and then press the MEM-
ORY button.
"0:00" The 24-hour display will appear.
(0:00 - 23:59)
"AM 12:00" The 12-hour display will appear.
(AM 12:00 - PM 11:59)
Note that this can only be setwhen the unit is first installed or it
has been reset. [Refer to "Clearing all the memory (reset)" on
page 27 for details.]
4 Within 30 seconds, press the PRESET ( or ) button to
adjust the hour and thenpress the MEMORY button.
z Press the PRESET ( or ) button once to advance the time
by 1 hour. Hold it down to advance continuously.
z When the 12-hour display is selected, "AM" will change au-
tomatically to "PM".
5
Within 30 seconds, press the PRESET ( or ) button to ad-
just the minutes and then press the MEMORY button.
z Press the PRESET ( or ) button once to advance the time
by 1 minute. Hold it down to advance continuously.
z Thehour will not advance even if minutes advancefrom "59"
to "00".
1 Clear all the programmed contents. [Refer to "Clearing all the
memory (reset)" on page 27 for details.]
2 Perform "Setting the clock" from the beginning.

02/5/27 CD-XP160W(SCA)E2..fm
14
CD-XP160W
CD Playback
- Listening to a CD (CDs) -
Listening to a CD (CDs)
This system can also play audio CD-R and CD-RW discs, but can-
not record.
Some audio CD-R and CD-RW discs may not be playable due to the
state of disc or the device that was used for recording.
T CD playback
1Press the ON/STAND-BY button to turn the power on.
2Press the CD button.
3Press the OPEN/CLOSE button to open the disc tray.
4Place the CD(s) on the disc tray, label side up.
When loading a third disc, press the DISC SKIP button to
turn the disc tray, then place the CD in the open position.
z CDs can be placed on any open position on the disc tray.
z Be sure to place 8 cm(3") CD(s) in the middleof the disc po-
sitions.
5Press the OPEN/CLOSE button to close the disc tray.
Total number of tracks on
the CD whose number is
flashing
Total playing time of the CD
whose number is flashing
6To select the CD you want to listen to first, press one of
1 - 3 buttons on the remote control.
7Press the / button to start playback.
z Playback will begin from track 1 on the disc you have select-
ed to play. After that disc finishes playing, the next disc will
automatically start playback.
z When the last track on the third disc hasfinished playing, the
CD player will automatically stop.
z When there is no CD in one of the disc 1 - 3 positions, that
position will be skipped and the next CD will begin to play.
12 cm (5") 8 cm (3")

02/5/27 CD-XP160W(SCA)E2..fm
15
CD-XP160W
CD Playback
- Listening to a CD (CDs) -
Listening to a CD (CDs) (continued)
To interrupt playback:
Press the CD button on the remote control.
To resume playback from the same point, press
the button .
To stop playback:
Press the button.
To remove the CDs:
Whilst in the stop mode, press the OPEN/CLOSE button.
The disc tray will open. Remove the two discs. Then, press the DISC
SKIP button to rotate the disc tray and remove the remaining disc.
Caution:
z If you tilt the unit forward in the power stand-by mode, the disc
tray will open. The unit or CD may be damaged.
z Do notplace two CDs in one disc tray.
z Do not play discs with special shapes (heart- or octagon-
shaped). It may cause malfunctions.
z Do not push the disc tray whilst it is moving.
z Do not turn the disc tray by hand. This may cause malfunctions.
z If the power fails whilst the tray is open, wait until the power is
restored.
z If the disc tray is stopped with force, "OPEN" will appear in the
display. If this occurs, press the OPEN/CLOSE button.
z If TV or radio interference occurs during CD operation, move the
unit away from the TV or radio.
z If a disc is damaged, dirty, or loaded upside down, the disc will
skip or not playback.
T To locate the beginning of a track
Notes:
z You can locate the beginning of a track on a single disc
only .
z
You can skip to any track by pressing the or button
repeatedly until the desired track number appears.
T To locate the desired portion
Notes:
z Normal playback will resume when the or button is
released.
z You can locate the desired portion on a single disconly.
z When the end of the last track is reached during fast forward, the
unit will enter the stop mode. When the beginning of the first track
is reached during fast reverse, playback will start when you
release the
button.
To move to the beginning of the next track:
Press the button for less than 0.5 seconds during playback.
To restart the track being played:
Press the button for less than 0.5 seconds during playback.
For audible fast forward:
Press and hold down the button during playback.
For audible fast reverse:
Press and hold down the button during playback.

02/5/27 CD-XP160W(SCA)E2..fm
16
CD-XP160W
CD Playback
- Advanced CD playback -
Advanced CD playback
T Starting playback with a desired track
You can play a disc starting with the desired track.
Notes:
z When the DISC SKIP button is pressed during playback, thenext
disc will begin automatically.
z
When one of the 1 - 3 buttons on the remote control is
pressed during playback, the selected disc will begin automat-
ically.
z If you select a disc with the 1 - 3 buttons and a track with
the or button, a track number exceeding the total track
number on the disc may be displayed (maximum 99). In this
case, the last track on the selected disc is played back.
T Repeat play
All tracks on up to 3 discs, or a programmed sequence can be con-
tinuously repeated.
To cancel repeat play:
Press the / button again. " " will go out.
T Random play
The tracks on the disc(s) can be played in random order automati-
cally .
To cancel random play:
Press the RANDOM button.
Notes:
z If you press the button during random play, you can move to
the track selected next by the random operation. On the other
hand, the button does not allow you to move to the previous
track. The beginning of the track being played will be located.
z In random play, the CD player will select and play tracksautomat-
ically. (You cannot select the order of the tracks.)
Caution:
After performing repeat or random play, be sure to press the but-
ton. Otherwise, the disc(s) will play continuously.
1 Whilst in the stop mode, press one of
the 1 - 3 buttons
on the remote control or DISC SKIP button to select the de-
sired disc.
2 Press the or button to select the desired track.
Selected disc number
Selected track number
3 Press the / button to start playback.
Playback of the selected track is started. When the end of last
track of the disc selected is reached, the next disc will be auto-
matically started.
To repeat all tracks on up to 3 discs:
Press the / button twice.
To repeat a desired track:
Perform steps 1 - 4 in the "Programmed play" section on page 17
and then press the / button twice.
Press the RANDOM button on the remote control to begin ran-
dom play.

02/5/27 CD-XP160W(SCA)E2..fm
17
CD-XP160W
CD Playback
- Advanced CD playback -
Advanced CD playback (continued)
T Programmed play
This may be operated only with the remote control.
You can choose up to 20 selections for playback in the order you
like.
Adding tracks to the programme:
If a programme has been previously stored, the "MEMORY" indica-
tor will be displayed. Then follow steps 1 - 3 to add tracks. The new
tracks willbe stored after the last track ofthe original programme.
Notes:
z If you open the disc
tray , change to another function or enter the
stand-by mode, the programmed sequence is automatically can-
celled.
z During programme operation, random play is not possible.
T Care of compact discs
Compact discs are fairly resistant to damage, however mistracking
can occur due to an accumulation of dirt on the disc surface. Follow
the guidelines below for maximum enjoyment from your CD collec-
tion and player.
z Do not write on either side of the disc, particularly the non-label
side from which signals are read. Do not mark this surface.
z Keep your discs away from direct sunlight, heat, and excessive
moisture.
z Always hold the CDs by the edges. Fingerprints, dirt, or water on
the CDs can cause noise or mistracking. If a CD is dirty or does
not play properly, clean it with a soft, dry cloth, wiping straight out
from the centre, along the radius.
1 Whilst in the stop mode, press
one of the 1 - 3 buttons to
select the desired disc.
2 Press the or button to
select the desired track.
If you select and memorise a track whose number exceeds the
last track number on the disc, it will not be played back.
3 Press the MEMORY button to save the track number.
When the track is memorised, "MEMORY" will appear.
4 Repeat steps 1 - 3 for other tracks. Up to 20 tracks can be
programmed.
If you make a mistake, the programmed tracks can be cleared
by pressing the CLEAR button.
5 Press the / button to start playback.
To clear the programmed selections:
Whilst the "MEMORY" indicator is lit, set the
CD to the stop mode and then press the
CLEAR button.
Each time the button is pressed, one track
will be cleared, beginning with the last track
programmed. When all the tracks are
cleared, "MEMORY" will disappear.
NO YES
Correct
Selected disc number
Selected track number
Playback order

02/5/27 CD-XP160W(SCA)E2..fm
18
CD-XP160W
Radio
- Listening to the radio -
Listening to the radio
T Tuning
To receive an FM stereo transmission:
Press the TUNER (BAND) button to display the "ST"indicator.
z " " will appear when an FM broadcast is in stereo.
z If the FM reception is weak, press the TUNER (BAND) button to
extinguish the "ST" indicator. The reception changes to monau-
ral, and the sound becomes clearer.
Note:
This productcan receive FM stereo/FM monaural and AM monaural
broadcasts. AM stereo broadcasts will not be played in stereo.
1Press the ON/STAND-BY button to turn the power on.
2Press the TUNER (BAND) button repeatedly to select
the desired frequency band (FM orAM).
3Press the TUNING ( or ) button to tune in to the de-
sired station.
Manual tuning:
Press the TUNING button as many times as required to tune in
to the desired station.
Auto tuning:
When the TUNING button is pressed for more than 0.5 sec-
onds, scanning will start automatically and the tuner will stop at
the first receivable broadcast station.
Notes:
z When radio interference occurs, auto scan tuning may stop
automatically at that point.
z Auto scan tuning will skip weak signal stations.
z To stop the auto tuning, press the TUNING button again.
FM stereo mode indicator
FM stereo receiving indicator

02/5/27 CD-XP160W(SCA)E2..fm
19
CD-XP160W
Radio / Tape Playback
- Listening to the radio / Listening to a cassette tape -
Listening to the radio (continued)
T Memorising a station
This may be operated only with the remote control.
You can store 30 AM and FM stations in memory and recall them at
the push of a button. (Preset tuning)
Note:
The backup function protects the memorised stations for a few
hours should there be a power failure or if the AC power lead dis-
connected.
T To recall a memorised station
Listening to a cassette tape
Before playback:
1 Perform steps 1 - 3 in
"Tuning" on page 18.
2 Press the MEMORY button to
enter the preset tuning sav-
ing mode.
3Within 5 seconds, press the PRESET ( or ) button to
select the preset channel number.
Store the stations in memory, in order, starting with preset
channel 1.
4 Within 5 seconds, press the
MEMORY button to store that
station in memory.
If the preset number indicators go out before the station is
memorised, repeat the operation from step 2.
5 Repeat steps 1 - 4 to set other stations, or to change a pre-
set station.
When a new station is stored in memory, the station previously
memorised will be erased.
Press the PRESET ( or ) button to select the desired sta-
tion.
z For playback, use normal or low-noise tapes for
the best sound. (Metal or CrO tapes are not rec-
ommended.)
z Do not use C-120 tapes or poor-quality tapes, as
they may cause malfunctions.
z Before loading a tape into the cassette compart-
ment, tighten the slack with a pen ora pencil.
