Sharp CD-XP700 User manual

CD-XP700/CD-XP7700
No. S2212CDXP700/
CONTENTS Page
IMPORTANT SERVICE NOTES (FOR U.S.A. ONLY)....................................................................................................... 2
SPECIFICATIONS ............................................................................................................................................................. 3
NAMES OF PARTS ........................................................................................................................................................... 4
OPERATION MANUAL ...................................................................................................................................................... 6
QUICK GUIDE (FOR U.S.A. ONLY) .................................................................................................................................. 8
DISASSEMBLY................................................................................................................................................................ 10
REMOVING AND REINSTALLING THE MAIN PARTS................................................................................................... 13
ADJUSTMENT ................................................................................................................................................................. 14
NOTES ON SCHEMATIC DIAGRAM .............................................................................................................................. 18
TYPES OF TRANSISTOR AND LED............................................................................................................................... 18
BLOCK DIAGRAM ........................................................................................................................................................... 19
SCHEMATIC DIAGRAM / WIRING SIDE OF P.W.BOARD............................................................................................. 22
VOLTAGE ........................................................................................................................................................................ 40
WAVEFORMS OF CD CIRCUIT...................................................................................................................................... 41
TROUBLESHOOTING ..................................................................................................................................................... 42
FUNCTION TABLE OF IC................................................................................................................................................ 46
FL DISPLAY..................................................................................................................................................................... 57
REPLACEMENT PARTS LIST/EXPLODED VIEW
PACKING OF THE SET (FOR U.S.A. ONLY)
SERVICE MANUAL
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
SHARP CORPORATION
• In the interests of user-safety the set should be restored to its
original condition and only parts identical to those specified be
used.
Illustration: CD-XP700
Illustration: CD-XP7700
MINI COMPONENT SYSTEM
MODEL CD-XP700
CD-XP700 Mini Component System consisting of CD-XP700
(main unit) and CP-XP700 (speaker system).
MINI COMPONENT SYSTEM
MODEL CD-XP7700
CD-XP7700 Mini Component System consisting of CD-XP7700
(main unit) and CP-XP7700 (speaker system).

CD-XP700/CD-XP7700
– 2 –
IMPORTANT SERVICE NOTES (FOR U.S.A. ONLY)
BEFORE RETURNING THE AUDIO PRODUCT
(Fire & Shock Hazard)
Before returning the audio product to the user, perform the
following safety checks.
1. Inspect all lead dress to make certain that leads are not
pinchedorthathardwareisnotlodgedbetweenthechassis
and other metal parts in the audio product.
2. Inspect all protective devices such as insulating materials,
cabinet,terminalboard,adjustmentandcompartmentcovers
or shields, mechanical insulators etc.
3. To be sure that no shock hazard exists, check for leakage
current in the following manner.
* Plug the AC line cord directly into a 120 volt AC outlet.
* Using two clip leads, connect a 1.5 kohm, 10 watt resistor
paralleled by a 0.15 µF capacitor in series with all exposed
metal cabinet parts and a known earth ground, such as
conduit or electrical ground connected to earth ground.
* Use a VTVM or VOM with 1000 ohm per volt, or higher,
sensitivity to measure the AC voltage drop across the
resistor (See diagram).
* Connect the resistor connection to all exposed metal parts
havingareturnpathtothechassis(antenna,metalcabinet,
screw heads, knobs and control shafts, escutcheon, etc.)
and measure the AC voltage drop across the resistor.
AllcheckmustberepeatedwiththeAClinecordplugconnection
reversed.
Anyreading of0.3 voltRMS (thiscorresponds to0.2 milliamp.
AC.) or more is excessive and indicates a potential shock
hazard which must be corrected before returning the audio
product to the owner.
TO EXPOSED
METAL PARTS
CONNECT TO
KNOWN EARTH
GROUND
TEST PROBE
0.15 µF
1.5 kohms
10 W
VTVM
AC SCALE

– 3 –
CD-XP700/CD-XP7700
General
Amplifier
CD player
Tuner
Cassette deck
Power source AC 120 V, 60 Hz
Power consumption 107 W
Dimensions Width: 270 mm (10-5/8")
Height: 330 mm (13")
Depth: 355 mm (13-15/16")
Weight 7.9 kg (17.4 lbs.)
Output power RMS: 200 W (100 W + 100 W) (10 % T.H.D.)
Output terminals Speakers: 6 ohms
Headphones: 16 - 50 ohms (recommended: 32 ohms)
Input terminals Video/Auxiliary (audio signal): 500 mV/47 kohms
Type 3-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser pickup
D/A converter 1-bit D/A converter
Frequency response 20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency range FM: 87.5 - 108 MHz
AM: 530 - 1,720 kHz
Frequency response 50 - 14,000 Hz (Normal tape)
Signal/noise ratio 55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
Wow and flutter 0.3 % (WRMS)
Type 2-way type speaker system
5 cm (2") Tweeter
16 cm (6-1/2") Woofer
Maximum input power 200 W
Rated input power 100 W
Impedance 6 ohms
Dimensions Width: 220 mm (8-11/16")
Height: 330 mm (13")
Depth: 232 mm (9-1/8")
Weight 3.3 kg (7.3 lbs.)/each
General
Amplifier
CD player
Tuner
Cassette deck
Power source AC 120 V, 60 Hz
Power consumption 107 W
Dimensions Width: 10-5/8" (270 mm)
Height: 13" (330 mm)
Depth: 13-15/16" (355 mm)
Weight 17.4 lbs. (7.9 kg)
Output power 100 watts minimum RMS per channel into 6 ohms from
60 Hz to 20 kHz, 10% total harmonic distortion
Output terminals Speakers: 6 ohms
Headphones: 16 - 50 ohms (recommended: 32 ohms)
Input terminals Video/Auxiliary (audio signal): 500 mV/47 kohms
Type 3-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser pickup
D/A converter 1-bit D/A converter
Frequency response 20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency range FM: 87.5 - 108 MHz
AM: 530 - 1,720 kHz
Frequency response 50 - 14,000 Hz (Normal tape)
Signal/noise ratio 55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
Wow and flutter 0.3 % (WRMS)
Type 2-way type speaker system
2" (5 cm) Tweeter
6-1/2" (16 cm) Woofer
Maximum input power 200 W
Rated input power 100 W
Impedance 6 ohms
Dimensions Width: 8-11/16" (220 mm)
Height: 13" (330 mm)
Depth: 9-1/8" (232 mm)
Weight 7.3 lbs. (3.3 kg)/each
Type 2-way type speaker system
2" (5 cm) Tweeter
6-1/2" (16 cm) Woofer
Maximum input power 200 W
Rated input power 100 W
Impedance 6 ohms
Dimensions Width: 8-11/16" (220 mm)
Height: 13" (330 mm)
Depth: 9-3/8" (238 mm)
Weight 7.0 lbs. (3.2 kg)/each
SPECIFICATIONS
CD-XP700/CD-XP7700 (Except for Canada)
CP-XP700 (Except for Canada)
Specifications for this model are subject to change without
prior notice.
CP-XP7700 (Except for Canada)
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
CD-XP700 (For Canada)
CP-XP700 (For Canada)

CD-XP700/CD-XP7700
– 4 –
NAMES OF PARTS
CD-XP700/CD-XP7700
Display
1. Disc Pause Indicator
2. Extra Bass Indicator
3. MP3 Disc Indicator
4. Disc Number Indicators
5. Tape 2 Record Indicator
6. FM Stereo Mode Indicator
7. FM Stereo Receiving Indicator
8. Timer Play Indicator
9. Sleep Indicator
10. Timer Recording Indicator
11. Disc Play Indicator
12. Disc Repeat Play Indicator
13. Tape Play Indicator
14. Memory Indicator
Front panel
1. Disc Tray
2. Timer Set Indicator
3. Power On/Stand-by Button
4. Tuner (Band) Button
5. CD/MP3 Disc Button
6. Headphone Jack
7. Tape (1 2) Button
8. Video/Auxiliary Button
9. Equalizer Mode Select/Extra Bass/
Demo Mode Button
10. Disc Tray Open/Close Button
11. Disc Skip Button
12. Volume Up and Down Buttons
13. Tape 1 Cassette Compartment
14. Tape 2 Cassette Compartment
15. CD/MP3 Disc Track Down or Fast Reverse,
Tape 2 Rewind, Tuner Preset Down Button
16. CD/MP3 Disc Track Up or Fast Forward,
Tape 2 Fast Forward, Tuner Preset Up Button
17. Clock Button
18. Timer/Sleep Button
19. CD/MP3 Disc Play or Repeat, Tape Play Button
20. CD/MP3 Disc or Tape Stop Button
21. Tuning and Time Down Button
22. Memory/Set Button
23. Tape 2 Record Pause Button
24. Tuning and Time Up Button
3
2
1
47
14
8
9
10
11
12
14
5
6
13
2567810134 9
13
11
12
15
19 20 21 242322
1716 18
Rear panel
1. Cooling Fan
2. AC Power Cord
3. Transport Screw
4. FM/AM Loop Antenna Jack
5. Video/Auxiliary (Audio Signal) Input Jacks
6. Speaker Terminals
4
1
2
5
6
3

– 5 –
CD-XP700/CD-XP7700
1. Tweeter
2. Woofer
3. Bass Reflex Duct
4. Speaker Wire
1
2
334
1
3
2
3
4
Remote control
1. Remote Control Transmitter
2. Disc Number Select Buttons
3. Disc Direct Search Buttons
4. Tape 2 Record Pause Button
5. CD/MP3 Disc Track Down or Fast Reverse,
Tape 2 Rewind Button
6. Equalizer Mode Select Button
7. Tuner (Band) Button
8. CD/MP3 Disc Button
9. Power On/Stand-by Button
10. Extra Bass Button
11. MP3 Disc Display Button
12. Disc Random Button
13. Disc Memory Button
14. Disc Clear Button
15. Tuner Preset Up and Down Buttons
16. Disc Pause Button
17. CD/MP3 Disc Track Up or Fast Forward,
Tape 2 Fast Forward Button
18. CD/MP3 Disc or Tape Stop Button
19. CD/MP3 Disc Play or Repeat, Tape Play Button
20. Video/Auxiliary Button
21. Tape (1 2) Button
22. Volume Up and Down Buttons
1
2
3
4
5
6
7
8
9
10
11
12
15
16
17
18
19
13
14
20
21
22
Buttons with " " mark in the illustration can be operated on the remote control
only.
Other buttons can be operated both on the main unit and the remote control.
CD-XP700/CD-XP7700
CP-XP700/CP-XP7700
CP-XP7700
CP-XP700

CD-XP700/CD-XP7700
– 6 –
OPERATION MANUAL
Setting the clock
In this example, the clock is set for the 12-hour (AM 12:00) display.
Note:
The "CLOCK" or time will flash at the push of the CLOCK button when the AC power
supply is restored after a power failure or unplugging the unit.
Readjust the clock as follows.
To readjust the clock:
Perform "Setting the clock" from step 1. If the time display is flashing, step 3 (for
selecting the 12-hour or 24-hour display) will be skipped.
To change the 12-hour or 24-hour display:
1
Press the ON/STAND-BY button to turn the power on.
2
Press the CLOCK button and within 5 seconds, press the MEMO-
RY/SET button.
3
Press the TUNING/TIME ( or ) button to select 12-hour or 24-
hour display and then press the MEMORY/SET button.
"AM 12:00" The 12-hour display will appear.
(AM 12:00 - PM 11:59)
"AM 0:00" The 12-hour display will appear.
(AM 0:00 - PM 11:59)
"0:00" The 24-hour display will appear.
(0:00 - 23:59)
Note that this can only be set when the unit is first installed or it has been reset.
[Refer to "Clearing all the memory (reset)".]
4
Press the TUNING/TIME ( or ) button to adjust the hour and then
press the MEMORY/SET button.
Press the TUNING/TIME ( or ) button once to advance the time by 1 hour.
Hold it down to advance continuously.
When the 12-hour display is selected, "AM" will change automatically to "PM".
5
Press the TUNING/TIME ( or ) button to adjust the minutes and
then press the MEMORY/SET button.
Press the TUNING/TIME ( or ) button once to advance the time by 1
minute. Hold it down to change the time in 5-minute intervals.
The hour will not advance even if minutes advance from "59" to "00".
The clock begins counting from "0" seconds. (Seconds are not displayed.)
The time display will disappear after a few seconds.
To confirm the time display:
Press the CLOCK button.
The time display will appear for about 5 seconds.
1 Clear all the programmed contents. [Refer to "Clearing all the memory (reset)".]
2 Perform "Setting the clock" from step 1.
Troubleshooting chart
Many potential problems can be resolved by the owner without calling a service tech-
nician.
If something is wrong with this product, check the following before calling your autho-
rized SHARP dealer or service center.
General
CD player
Tuner
Cassette deck
Remote control
Condensation
Symptom Possible cause
The clock is not on time. Did a power failure occur? Reset the
clock.
When a button is pressed, the unit
does not respond. Set this unit to the power stand-by mode and then turn it back on.
Iftheunit stillmalfunctions, reset it.
No sound is heard. Is the volume level set to "0"?
Are the headphones connected?
Are the speaker wires disconnected?
Symptom Possible cause
Playback does not start. Is the disc loaded upside down?
Playback stops in the middle or is
not performed properly. Does the disc satisfy the standards?
Is the disc distorted or scratched?
Playback sounds are skipped, or
stopped in the middle of a track. Is the unit located near excessive vibra- tions?
Is the disc very dirty?
Has condensation formed inside the unit?
Symptom Possible cause
Radio makes unusual noise con-
secutively. Is the unit placed near the TV or comput- er?
Is the FM/AM loop antenna placed proper-
ly? Move the AC power cord away from
the antenna if located near.
Symptom Possible cause
Cannot record. Is the erase-prevention tab removed?
Cannot record tracks with proper
sound quality. Is it a normal tape? (You cannot record on a metal or CrO tape.)
Cannot erase completely.
Sound skipping. Is there any slack?
Is the tape stretched?
Cannot hear treble. Are the capstans, pinch rollers, or heads
dirty?
Sound fluctuation.
Cannot remove the tape. If a power failure occurs during playback,
the heads remain engaged with the tape.
Do not open the compartment forcibly.
Wait until electricity resumes.
Symptom Possible cause
The remote control does not oper-
ate. Is the AC power cord of the unit plugged in?
Is the battery polarity respected?
Are the batteries dead?
Is the distance or angle incorrect?
Does the remote control sensor receive
strong light?
Sudden temperature changes, storage or opera-
tion in an extremely humid environment may
cause condensation inside the cabinet (CD pick-
up, tape heads, etc.) or on the transmitter on the
remote control.
Condensation can cause the unit to malfunction.
If this happens, leave the power on with no disc
(or cassette) in the unit until normal playback is
possible (about 1 hour). Wipe off any condensa-
tion on the transmitter with a soft cloth before op-
erating the unit.

– 7 –
CD-XP700/CD-XP7700
If trouble occurs
When this product is subjected to strong external interference (mechanical shock,
excessive static electricity, abnormal supply voltage due to lightning, etc.) or if it is
operated incorrectly, it may malfunction.
If such a problem occurs, do the following:
1 Set the unit to the stand-by mode and turn the power on again.
2 If the unit is not restored in the previous operation, unplug and plug in the unit,
and then turn the power on.
Note:
If neither operation above restores the unit, clear all the memory by resetting it.
Clearing all the memory (reset)
1 Press the ON/STAND-BY button to enter the power stand-by mode.
2 While pressing down the CLOCK button and the EQUALIZER/X-BASS/DEMO
button, press the ON/STAND-BY button until "CLEAR AL" appears.
Caution:
This operation will erase all data stored in memory including clock, timer settings,
tuner preset, and CD program.
Before transporting the unit
On the back of this unit is equipped with a transport screw in order to prevent damage
during transportation.
1 Press the ON/STAND-BY button to turn the
power on.
2 Press the CD button.
3 Press the OPEN/CLOSE button to open
the disc tray.
Remove all CDs inserted in the unit.
4 Press the OPEN/CLOSE button to close
the disc tray.
Make sure that "NO DISC" is displayed.
5 Press the ON/STAND-BY button to enter the
stand-by mode, and then unplug the AC
power cord from the AC outlet.
6 Insert the transport screw into the back of
the unit and tighten it with a flat head screw-
driver or a coin.
Troubleshooting chart
Remote control
Test of the remote control
Point the remote control directly at the remote sensor on the unit.
The remote control can be used within the range shown:
Press the ON/STAND-BY button. Does the power turn on? Now, you can enjoy the
music.
8" - 20'
(0.2 m - 6 m)
Remote sensor

CD-XP700/CD-XP7700
– 8 –
QUICK GUIDE (FOR U.S.A ONLY)
Accessories Accesorios
FM/AM loop antenna × 1
Antena de cuadro de FM/AM
×
1
Remote control × 1
Controlador remoto
×
1
1
1
123
Remote control battery installation
Instalación de las pilas del controlador remoto
Use 2 “AA” size batteries (UM/SUM-3, R6, HP-7 or similar). Batteries are not included. Use dos pilas del tamaño “AA” (UM/SUM-3, R6, HP-7 o equivalentes). Las pilas no están incluidas.
Remove the
Insert the batteries
Replace the cover.
battery cover.
as shown.
Extraiga la cubierta Inserte las pilas Vuelva a colocar la
de las pilas. como se muestra. cubierta.
2
2
System connections Conexiones del sistema
3
3
AM loop antenna Antena de cuadro de AM
FM antenna Antena de FM
Red Rojo
Black Negro
Right speaker Altavoz derecho
Left speaker Altavoz izquierdo
AC outlet (AC 120 V, 60 Hz) A un tomacorriente de
CA (120 V de CA, 60 Hz)
Right speaker
Altavoz derecho
Left speaker
Altavoz izquierdo
RCA cord (not supplied) Cable RCA
(no suministrado)
To the line output jacks A las tomas de
salida de línea
VCR, DVD, etc.
Videograbadora,
DVD, etc.
TV TV
Before turning the power on, be sure to remove this transport screw on the back of the unit using a flat head screwdriver or a coin. Antes de conectar la alimentación, asegúrese de extraer este tornillo para
eltransportede la parteposteriordel aparato empleandoun destornillador
de punta plana o una moneda.
●The illustrations are for the model CD-XP700. ●
Las ilustraciones son para el modelo CD-XP700.

– 9 –
CD-XP700/CD-XP7700
Turn on your system Conexión de la alimentación de su sistema
4
4
The first time the unit is plugged in, the unit will enter the demon- stration mode. You will see words scroll. Cuando se enchufe por primera vez
el aparato, se establecerá en el
modo de demostración. Verá un
desplazamiento de palabras.
12
Listening to a CD (CDs) Audición de un disco CD (discos CD)
63
5
2, 4
1
5” (12 cm) 12 cm
3” (8 cm) 8 cm
Press the EQUALIZER/ X-BASS/DEMO button to cancel the demon- stration mode.
Pulse el botón
EQUALIZER/X-BASS/
DEMO para cancelar el
modo de demostración.
Press the ON/STAND-BY button to turn the power on. Pulse el botón
ON/STAND-BY
para
conectar la alimentación.
1
Press the CD button.
Pulse el botón CD.
2
Press the OPEN/CLOSE button to open the disc tray. Pulse el botón OPEN/CLOSE
para abrir
la bandeja de discos.
3
Place the CD(s) on the disc tray, label side up. When loading a third disc, press the DISC SKIP button to turn the disc tray, then place the CD in the open position. Coloque el disco compacto en la bandeja
de discos, con el lado de la etiqueta hacia
arriba.
Cuando ponga un tercer disco, pulse el
botón DISC SKIP para girar la bandeja de
discos, y coloque el disco compacto en la
posición abierta.
4
Press the OPEN/CLOSE button to close the disc tray. Pulseelbotón OPEN/CLOSEpara cerrar
la bandeja de discos.
5
To select the CD you want to listen to first, press one of 1 - 3 buttons on the remote control. Para seleccionar el disco CD que desee
escucharprimero,pulseunode los botones
1 - 3 del controlador remoto.
6
Press the button to start playback. Pulse el botón para iniciar la
reproducción.
Listening to a cassette tape (TAPE 1 or TAPE 2)
Audición de una cinta de cassette (TAPE 1 o TAPE 2)
Listening to the radio Audición de la radio
FM stereo mode indicator Indicador del modo de FM en estéreo
FM stereo receiving indicator Indicador de recepción de FM en estéreo
1 2
TAPE 1 TAPE 2
1, 2
3 4
1
Press the TUNER (BAND) button repeat- edly to select the desired frequency band (FM or AM).
Pulse repetidamente el botón TUNER
(BAND) para seleccionar la banda de
frecuencias deseada (FM o AM).
2
Press the TUNING/TIME ( or ) but- ton to tune in to the desired station. When the TUNING/TIME button is pressedformore than0.5 seconds,scan- ningwillstart automaticallyand thetuner will stop at the first receivable broadcast station.
PulseelbotónTUNING/TIME( o ) para
sintonizar la emisora deseada.
Cuando se pulse el botón
TUNING/TIME
durante más de 0,5 segundos, la
exploración se iniciará automáticamente y
el sintonizador se parará en la primera
emisora difusora que pueda recibirse.
To receive an FM stereo transmission: Press the TUNER (BAND) button to display the “ST” indicator. ●“ ” will appear when an FM broadcast is in ste-
reo.
Para recibir una transmisión de FM en estéreo:
Pulse el botón TUNER (BAND) para que se visualice
el indicador “ST”.
●
“ ” aparecerá cuando una difusión de FM sea en
estéreo.
1
Open the cassette door by pushing the area marked “ PUSH EJECT”. Abra la puerta del cassette pulsando la
parte marcada “ PUSH EJECT”.
2
Load a cassette into the TAPE 1 or TAPE 2 cassette compartment with the side to be played facing toward you. Cargue un cassette en el compartimiento
de cassette de TAPE 1 o de TAPE 2 con la
cara a reproducirse encarada hacia usted.
3
Press the TAPE (1 2) button to select the cassette you want to listen to.
Pulse el botón TAPE (1 2) para
seleccìonar el cassette que desee
escuchar.
4
Press the button to start playback. Pulse el botón para iniciar la
reproducción.

CD-XP700/CD-XP7700
– 10 –
1 Top Cabinet 1. Screw ...................... (A1) x4 10-1
2 Side Panel 1. Screw ...................... (B1) x8 10-1
(Left/Right)
3 CD Tray Cover/ 1. Turn on the power supply,.. 10-2
CD Player Unit open the disc tray, take out
the CD tray cover, and close.
(Note 1)
2. Screw ...................... (C1) x1
3. Hook........................ (C2) x3
4. Hook........................ (C3) x2
5. Socket ..................... (C4) x2
4 Rear Panel with 1. Screw ...................... (D1) x7 10-2
Fan Motor 2. Socket ..................... (D2) x1
5 Main PWB 1. Screw ...................... (E1) x4 10-2, 11-1
2. Socket ..................... (E2) x3 11-1
3. Flat Cable ............... (E3) x1
4. Flat Wire.................. (E4) x1
6 Front Panel 1. Screw .......................(F1) x2 11-1
2. Hook.........................(F2) x2
3. Socket ......................(F3) x1
7 Display PWB 1. Screw ....................(G1) x16 11-2
2. Flat Cable ............... (G2) x1
8 Tape Mechanism 1. Open the cassette holder. .. 11-2
2. Screw...................... (H1) x5
9 Headphones PWB 1. Screw ....................... (J1) x1 11-2
10 Turntable 1. Hook........................ (K1) x2 11-3
2. Cover ...................... (K2) x1
11 Loading Tray 1. Turn fully the lock lever in the 10-3
arrow direction .
2. Push the loading tray backward 11-4
to engage the claw with the
groove and remove it in the
direction of the arrow ... (L1) x6
12 CD Servo PWB 1. Screw ......................(M1) x2 11-5
(Note 2) 2. Hook........................(M2) x1
3. Socket ..................... (M3) x4
13 CD Mechanism 1. Hook........................ (N1) x2 11-6
2. Hook........................ (N2) x2
DISASSEMBLY
Caution on Disassembly
Follow the below-mentioned notes when disassembling
the unit and reassembling it, to keep it safe and ensure
excellent performance:
1. Take cassette tape and compact disc out of the unit.
2. Be sure to remove the power supply plug from the wall
outlet before starting to disassemble the unit.
3.Takeoffnylon bands orwireholderswhere they need to
beremovedwhendisassemblingtheunit.Afterservicing
theunit,besure to rearrange theleadswherethey were
before disassembling.
4. Take sufficient care on static electricity of integrated
circuits and other circuits when servicing.
Figure 10-2
STEP REMOVAL PROCEDURE FIGURE
Figure 10-1
Note 1: How to open the changer manually. (Fig. 10-3)
1. In this state, turn fully the lock lever in the arrow direction through
the hole on the loading tray bottom.
2. After that, push forward the Loading tray.
Note 2:
1. After removing the connector for the optical pickup from the
connector,wraptheconductivealuminiumfoilaroundthefrontend
of the connector so as to protect the optical pickup from electro-
static damage.
Note 3:
1. Be careful not to break the claw of the CD mechanism.
2. When fining back the cam gear assembly, let it lock by front
movement.
CD-XP700/CD-XP7700
CD-XP700/CD-XP7700
(B1)x2
ø3x10mm
(A1)x2
ø3x12mm
(A1)x2
ø3x12mm
(B1)x2
ø3x10mm
(B1)x4
ø3x10mm
Rear
Panel
Side Panel
(Right)
Side Panel
(Left)
Top Cabinet Front
Panel
(C3)x1
CD Player
Unit
CD Tray Cover (C2)x3
1
1
2
(E1)x1
ø3x10mm
(C1)x1
ø3x10mm
(E1)x1
ø3x10mm
(D1)x1
ø3x10mm
Lug Wire
Main PWB
Rear
Panel
Pull
(C3)x1
(C4)x2
CD Servo
PWB
Main
PWB
(D2)x1
(D1)x6
ø3x10mm
Figure 10-3
Lock Lever
CD Player Unit
(Bottom View)

– 11 –
CD-XP700/CD-XP7700
Figure 11-1
Figure 11-2
Figure 11-3
Figure 11-4
Figure 11-5
Figure 11-6
(F1)x2
ø3x10mm
Headphones
PWB
(E4)x1
Front
Panel
(E1)x2
ø3x10mm
(F2)x1
(F2)x1
(E2)x1
(F3)x1
(E3)x1
(E2)x2
Main PWB
Transformer
PWB
Power PWB
(G2)x1
(G1)x16
ø3x10mm
Display PWB
Headphones
PWB
Open
Cassette
Holder
Tape
Mechanism
(J1)x1
ø3x10mm
(H1)x5
ø3x10mm
Lug Wire
Front Panel
CD Player Unit
Loading
Tray
Turntable
(K2)x1
(K1)x2
(L1)x3
3
(L1)x3 Loading Tray
1
2
Loading
Tray
(M1)x2
ø3x10mm
(M3)x2 CD Servo
PWB
(M2)x1
(M3)x2
CD
Mechanism (N2)x2
(N1)x1
(N1)x1 Loading Tray

CD-XP700/CD-XP7700
– 12 –
Figure 12-1 Figure 12-2
1 Woofer 1. Front Panel ............. (A1) x1 12-1
2. Screw ...................... (A2) x4 12-2
2 Tweeter 1. Screw ...................... (B1) x2 12-2
STEP REMOVAL PROCEDURE FIGURE
CP-XP700
1 Woofer 1. Front Panel ............. (A1) x1 12-3
2. Screw ...................... (A2) x4 12-4
2 Tweeter 1. Screw ...................... (B1) x2 12-4
STEP REMOVAL PROCEDURE FIGURE
CP-XP7700
Screwdriver
Driver should
be pried away
from Speaker Box.
(A1)x1
Speaker Box
(A2)x4
ø4x12mm
(B1)x2
ø3x10mm
Speaker Box
Woofer
Tweeter
Figure 12-3 Figure 12-4
Screwdriver
Driver should
be pried away
from Speaker Box.
(A1)x1
Speaker Box
(A2)x4
ø4x12mm
(B1)x2
ø3x10mm
Speaker Box
Woofer
Tweeter

– 13 –
CD-XP700/CD-XP7700
REMOVING AND REINSTALLING THE MAIN PARTS
TAPE MECHANISM SECTION
Perform steps 1 to 6 and 8 of the disassembly method to
remove the tape mechanism.
How to remove the record/playback and erase
heads (TAPE 2) (See Fig. 13-1)
1. When you remove the screws (A1) x 2 pcs., the recording/
playback head and three-dimensional head of the erasing
head can be removed.
How to remove the playback head (TAPE 1)
(See Fig. 13-2)
1. When you remove the screws (B1) x 2 pcs., the playback
head can be removed.
How to remove the pinch roller (TAPE 1/2)
(See Fig. 13-3)
1. Carefully bend the pinch roller pawl in the direction of the
arrow <A>, and remove the pinch roller (C1) x 1 pc., in the
direction of the arrow <B>.
Note:
When installing the pinch roller, pay attention to the spring
mounting position.
How to remove the belt (TAPE 2)
(See Fig. 13-4)
1. Remove the main belt (D1) x 1 pc., from the motor side.
2. Remove the FF/REW belt (D2) x 1 pc.
How to remove the belt (TAPE 1)
(See Fig. 13-4)
1. Remove the main belt (E1) x 1 pc., from the motor side.
2. Remove the FF/REW belt (E2) x 1 pc.
How to remove the motor (See Fig. 13-5)
1. Remove the screws (F1) x 2 pcs., to remove the motor.
Figure 13-1
Figure 13-2
Figure 13-3
Figure 13-4Figure 13-5
(A1)x2
Ø2x9mm
TAPE 2
Record/Playback
Head
Erase Head
Clutch Ass'y
(B1)x2
Ø2x9mm
TAPE 1
Playback
Head
Clutch Ass'y
Pinch Roller
(C1)x1 <A>
<B>
Pinch
Roller
Pawl
Pull
TAPE 2 TAPE 1
Main Belt
(E1)x1
TAPE 2
Main Belt
(D1)x1
TAPE 1
Main Belt
(D1)x1 Main Belt
(E1)x1
FF/REW
Belt
(D2)x1
FF/REW
Belt
(E2)x1
Motor
Motor
(F1)x2
Ø 2.6x5mm
Motor
Clutch Ass'y

CD-XP700/CD-XP7700
– 14 –
How to remove the pickup (See Fig. 14-2)
1. Remove the stop washer (B1) x 1 pc., to remove the gear
(B2) x 1 pc.
2. Remove the screws (B3) x 2 pcs., to remove the shaft
(B4) x 1 pc.
3. Remove the pickup.
Note
After removing the connector for the optical pickup from the
connectorwraptheconductivealuminiumfoilaroundthefront
end of connector so as to protect the optical pickup from
electrostatic damage.
Figure 14-2
CD MECHANISM SECTION
Perform steps 1, 2, 3, 10, 11,12 and 13 of the disassembly
method to remove the CD mechanism.
How to remove the loading motor
(See Fig. 14-1)
1. Bend the hooks (A1) x 6 pcs., to remove the loading motor.
Figure 14-1
ADJUSTMENT
MECHANISM SECTION
•Driving Force Check
Torque Meter Specified Value
Play: TW-2111 Tape 1: Over 80 g
Tape 2: Over 80 g
•Torque Check
Torque Meter
Tape 2
Play: TW-2111 30 to 80 g.cm 30 to 80 g.cm
Fast forward: TW-2231 — 70 to 180 g.cm
Rewind: TW-2231 — 70 to 180 g.cm
Specified Value
Tape 1
Specified
Value
Adjusting
Point Instrument
Connection
Test Tape
Normal MTT-111 Variable 3,000 ±30 Hz Speaker
speed Resistor in Terminal
motor. (Load
resistance:
6 ohms)
•Tape Speed
Figure 14-3
(B3)x2
ø2.6x6mm
Shaft
(B4)x1
Stop Washer
(B1)x1
Gear
(B2)x1
CD Mechanism
Pickup
TAPE MECHANISM
Tape
Motor
Variable Resistor in motor
(A1)x6
Loading
Motor PWB
Loading
Motor
Loading
Tray

– 15 –
CD-XP700/CD-XP7700
Figure 15-2
CD ERROR CODE DESCRIPTION
Error Explanation
01 When Pickup set inner position, inner switch
cannot detect 'ON' level for 10 secs.
When tray moves to Open/Close, Open/Close switch
10* cannot detect 'ON' level for 7 secs.
When disc table rotate to target position.
Clamp switch cannot detect 'ON' level for 7 secs.
When disc table set to Disc1 position for 1 st time,
11* "CLAMP SW", "DISC NO SW" and "OPEN/CLOSE"
cannot detect 'ON' level for 14 secs.
31 When it changes to CD function, DSP cannot read
initial data.
T
T
EFBL
FDO
TE
Stopped
CH1=500 mV
DC 10:1 CH2=200 mV DC 10:1 CH3=1 V DC 10:1 500 ms/div
(500 ms/div)
NORM:20 kS/s
1
2
3
=Record Length=
Smoothing : ON CH1 : 0.000 V
CH2 : 0.000 V Main : 100K Zoom : 2k Mode : SINGLE Type : EDGE CH1
Delay : 0.0 ns
Hold off : 0.2 µs
CH3 : 0.00 V
CH4 : 0.00 V
BW : FULL
=Trigger==Filter= =Offset=
CH2
v/DIV
200 mV
1999/04/05 20:26:47
Test Stage Frequency Frequency
Display Setting/ Adjusting
Parts
Instrument
Connection
CD SECTION
• AM IF/RF
Signal generator: 400 Hz, 30%, AM modulated
*1. Input: Antenna Output: TP302
*2. Input: Antenna Output: TP301
TUNER SECTION
fL: Low-range frequency
fH: High-range frequency
AM IF 450 kHz 1,702 kHz T351 *1
AM Band — 530 kHz (fL): T306 *2
Coverage 1.1 ±0.1 V
AM Tracking 990 kHz 990 kHz (fL): T303 *1
*1. Input: Antenna Output: TP301
*2. Input: Antenna Output: Speaker terminal
•FM RF
Signal generator: 1 kHz, 40 kHz dev., FM modulated
FM Band — 87.50 MHz T301 (fL): *1
Coverage 1.3 V ±0.1 V
FM RF 98.00 MHz 98.00 MHz L312 *2
(10-30 dB)
Test Stage Instrument
Connection
Frequency Frequency
Display Setting/
Adjusting
Point
Figure 15-1 ADJUSTMENT POINTS
Items adjusted automatically
(1)Offsetadjustment(Theoffsetvoltagebetween the head
amplifier output and the VREF reference voltage is
compensated inside the IC.)
* Focus offset adjustment
* Tracking offset adjustment
(2) Tracking balance adjustment (waveform drawing
Fig.15-2 EFBL)
(3)Gainadjustment(ThegainiscompensatedinsidetheIC
sothattheloop gain at thegaincrossoverfrequency will
be 0 dB.)
* Focus gain adjustment
* Tracking gain adjustment
•Adjustment
Since this CD system incorporates the following automatic
adjustment functions, readjustment is not needed when
replacingthepickup.Therefore,differentPWBsandpickups
can be combined freely.
Each time a disc is changed, these adjustments are
performed automatically. Therefore, playback of each disc
can be performed under optimum conditions.
•FM IF
Signal generator: 10.7 MHz, FM modulated
IF 10.7 MHz 98 MHz T302 *1
(Turn the
core of trans-
former T302
fully counter-
clock wise)
Test Stage Instrument
Connection
Frequency Frequency
Display Setting/ Adjusting
Point
*1. Input: Antenna Output: TP301
AM IF
FM RF
TP301
TP302
FM IF
T301
T302
R316
R356
T303
T306
IC301
L312
T351
CNP301
AM/FM LOOP
ANTENNA
FM BAND
COVERAGE fL
AM BAND
COVERAGE fL
AM TRACKING
fL
MAIN PWB
1
* 'CHECKING'
IfErrorisdetected,'CHECKING'willbedisplayinsteadof'ER-
CD**' display. 'ER-CD**' display will only be display when
error had been detected for the 5 th times.

CD-XP700/CD-XP7700
– 16 –
TEST MODE
•Setting the test mode
Any one of test mode can be set by pressing several keys as follows.
<X-BASS> + <CD> + <POWER> TEST: CD operation test.
Function: -CD test mode.
-Enter test mode.
C D T E S T
OPEN/CLOSE operation is using manual.
<< >>,<< >>buttonsmakepick'sslidepossible.
Do TOC IL. Do normal play.
When these following key is input
into PLAY key, track number can
be appoint directly.
<<PLAY>> key input. <<MEMORY>> key input.
<< 1 >> key: Track 4
<< 2>> key: Track 9
<< 3>> key: Track 15
<<STOP>> key input.
STOP
Laser ON.
<<MEMORY>> key input.
Tracking OFF play at that
specific point.
<<MEMORY>> key input.
Tracking ON play from
that specific point.
<<STOP>> key input.
STOP
IL isn't done
VOL — Last memory
BAL — CENTER
P.GEQ — FLAT
X-BASS — OFF
To cancel : Power OFF
Sliding the PICKUP with
<< >>, << >> button
must only be in STOP mode.
<<MEMORY>>
key input.
Adjustment result
automatically will
display as below.
for each 2 sec :
a) "FOFF_XX"
b) "TOFF_XX"
c) "TBAL_XX"
d) "TGAN_XX"
f) "FGAN_XX"
g) "RFLS_XX"
explanation:
a) Focus off set = "FOFF_XX"
b) Tracking off set = "TOFF_XX"
c) Tracking balance = "TBAL_XX"
d) Tracking Gain = "TGAN_XX"
f) Focus Gain = "FGAN_XX"
g) RF level shift = "RFLS_XX"
Adjustmentresultautomaticallywill
display as below for each 2 sec :
a) "FOFF_XX"
b) "TOFF_XX"
c) "TBAL_XX"
d) "TGAN_XX"
f) "FGAN_XX"
g) "RFLS_XX"
<<MEMORY>> key input.

– 17 –
CD-XP700/CD-XP7700
Standard Specification of Stereo System Error Message Display Contents
Error Contents DISPLAY Notes
TAPE Mechanism Error. 'ER-TA**' 00: Tape Mechanism Error.
01: Initial Error.
02:
03:
CD Pickup Mechanism Error. 'ER-CD**' 01: PU-IN SW Detection NG.
02:
03:
04:
CD Changer Mechanism Error. 'ER-CD**' 10: Changer Error.
(*) 11: Initial Error.
12:
13:
CD DSP Communication Error 'ER-CD**' 31: DSP COMMUNICATION ERROR
Focus Not Match. 'NO DISC'
IL Time Over. 'NOT READ'
TUN PLL Unlock. 'ER-TU**' 00: TUN Error.
01: PLL Unlock.
02:
03:
(*) CHECKING:
IfCD changermechanism erroris detected,'CHECKING' willbe displayinstead of'ER-CD**' display'ER-CD**' willonly bedisplay
when CD changer mechanism error had been detected for the 5 th times.
Speaker abnormal detection and +B PROTECTION display
In case speaker abnormal detection or +B PROTECTION had occured, it can be check by pressing 'POWER', 'VIDEO' and 'X-
BASS' key twice. Display will show "S** B**". S is referring to speaker abnormal detection and B is referring to +B PROTECTION.
** is in hex valve.
+B PROTECTION is condition when irregular process occur on power supply line.

CD-XP700/CD-XP7700
– 18 –
•The indicated voltage in each section is the one measured
by Digital Multimeter between such a section and the chas-
sis with no signal given.
1. In the tuner section,
indicates AM
indicates FM stereo
2. In the main section, a tape is being played back.
3. In the deck section, a tape is being played back.
( ) indicates the record state.
4. In the power section, a tape is being played back.
5. In the CD section, the CD is stopped.
•Parts marked with “ 1” ( ) are important for
maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and
performance of the set.
NOTES ON SCHEMATIC DIAGRAM
•Resistor:
To differentiate the units of resistors, such symbol as K and
M are used: the symbol K means 1000 ohm and the symbol
M means 1000 kohm and the resistor without any symbol is
ohm-type resistor. Besides, the one with “Fusible” is a fuse
type.
•Capacitor:
To indicate the unit of capacitor, a symbol P is used: this
symbol P means pico-farad and the unit of the capacitor
without such a symbol is microfarad. As to electrolytic
capacitor, the expression “capacitance/withstand voltage”
is used.
(CH), (TH), (RH), (UJ): Temperature compensation
(ML): Mylar type
(P.P.): Polypropylene type
•Schematic diagram and Wiring Side of P.W.Board for this
model are subject to change for improvement without prior
notice.
REF. NO DESCRIPTION POSITION
SW714 VIDEO/AUX ON—OFF
SW715 TIMER/SLEEP ON—OFF
SW716 TUNING/TIME UP ON—OFF
SW717 REC PAUSE ON—OFF
SW718 MEMORY/SET ON—OFF
SW719 TUNING/TIME DOWN ON—OFF
SW720 CLOCK ON—OFF
SW721 VOLUME UP ON—OFF
SW722 VOLUME DOWN ON—OFF
SW723 DISC SKIP ON—OFF
SW724 OPEN/CLOSE ON—OFF
SW725 EQUALIZER/X-BASS/DEMO ON—OFF
SW1 OPEN/CLOSE ON—OFF
SW2 CLAMP ON—OFF
SW3 DISC NUMBER ON—OFF
SW4 PICKUP IN ON—OFF
SW701 POWER ON—OFF
SW702 FAST REWIND/PRESET DOWN ON—OFF
SW703 FAST FORWARD/PRESET UP ON—OFF
SW704 STOP ON—OFF
SW705 PLAY/REPEAT ON—OFF
SW711 CD ON—OFF
SW712 TUNER (BAND) ON—OFF
SW713 TAPE ON—OFF
TYPES OF TRANSISTOR AND LED
REF. NO DESCRIPTION POSITION
(1) (2) (3)
(S) (G) (D)
E C B
FRONT
VIEW FRONT
VIEW
2SC1845 F
KRC102 M
KRC104 M
KTA1266 GR
KTA1273 Y
SLR342VCJ
A503BC2E
2SD601 AR
UN2211
FRONT
VIEW
KTA1274 Y
KTA1504 GR
KTC3194 Y
KTC3199 GR
KTC3203 Y
B
(D)
(3)
E
(G)
(1)
C
(S)
(2)

– 19 –
CD-XP700/CD-XP7700
Figure 19 BLOCK DIAGRAM (1/3)
CNP7
CNP6
Q2
+3.3V
+5V
+5V
CONT5
MP3 CE
MP3 CL
DVDD1
DVDD2
DVDD3
DVDD4
DVDD5
DVDD6
X2
X1
LRSY
ADDATA
ADBCK
ADLRCK
C2FIN
CKIN(16M)
CKOUT
DATAIN DATACK
CONT3
CONT4
SLDO
SPDO
FDO TDO
+5V
+6.5V
TO DISPLAY SECTION
CLAMP SW
WRQ
CE
DO
CLK
DI
CD RES
OPEN/CLOSE
DISC NO.
SUB-CE
MPEG POWER
DRF
CNS4
BI4 CNP4
M2
SLED
MOTOR
M1
SPINDLE
MOTOR
MM
TRACKING COIL
FOCUS COIL
PICKUP UNIT
FIN1 A
FIN2 B
TIN1 E
TIN2 F
VVDD
ADAVDD
VDD
LVDD
RVDD
XVDD
VDD5V
LDS
LDD
Q1
LASER
DRIVER
VCC3 SYS-CE
SYS-CL SYS-DO SYS-DI
VCC2 VCC4
VCC VCC VCC DOEB DCASUB DCASLB
VCC1
IC2
M63001FP
FOCUS/TRACKING/
SPIN/SLED DRIVER
TO MAIN SECTION
R-CH
L-CH
AGND
DGND
DGND_DRIVER
+5V(DIG.) (+B7)
+5V(ANL) (+B8)
+6.5V (+B4)
RCHO
RVSS
LVSS
LCHO
IC1
LC78645NE
CD SERVO
-
+
M
SW1
OPEN/
CLOSE
XL1
33.8688 MHz
XL2
4.19 MHz
5
4
3
2
3
2
5
4
7
8
6
1
1
6
7
8
9
10
11
12
1
2
4
3
5
SW2
CLAMP
SW3
DISC
NUMBER
M3
T/T
UP/DOWN
LOADING
MOTOR
6
1
2
4
3
5
6
1
2
4
3
5
6
42
37
51
43
44
45
25
70
71
43
44
61 62 63 64 65 66 67
CE CL DI DO WRQ
RES
DEF
48 49
XOUT XIN
68
77
79
80
18
38
41
46
47
7
27
8
9
10
19
75
20
212223
26
60545250
14
5
6
7
15
16
26
27
2
17
25
4
3
2
1
79
80
80
9
7
5
51
31
21
11
68
61
OEB
CASUB
CASLB
45
43
44
41
42
38
39
35 29 22 21 14 8
40 18 24 23 28
SW4
PICKUP IN
+3.3V
+3.3V
+3.3V
+5V
+5V
~
~
23
1 6 22 29 30 31
30
~
~
~
IC5
IX0505AW
CD SIGNAL
CONTROL
IC3
LC78683E
MP3
DECODER
FSYNC
CMDOUT
INTB
FSYNC
CMDOUT
INTB
VDD
M+
M–
PS–
PS+
SL-
SL+
VDD
AVDD
73
77
66
73
77
66
73
77
66
15 16 18 19
IC4
LC32V4265B
4M DRAM
11 10
26
27
MP3 CE
MP3 CL
MDATA0
MDATA0 MDATA7
~
MDATA8 MDATA15 ADRS8 RASB WEB ADRS7 ADRS0
MDATA3
75 76
6
40
IC7
SI3033LUS
VOLTAGE
REGULATOR
IC6
SI3033LU
VOLTAGE
REGULATOR
Q3
Q4
Q5
,41 ,
33 40
~
53 60
~
~
,42 ,50 ,
25
~
~
MDATA4 MDATA7
DWEB
DRASB
~
MDATA8
MDATA11
~
MDATA12 MDATA15
~
ADRS0 ADRS3
~
ADRS4 ADRS8
~
,15 ,,
710
~
18 21
~
,24 28
~
,35 38
~
,40 43
~
16
,
+– +–
ZD1

CD-XP700/CD-XP7700
– 20 –
Figure 20 BLOCK DIAGRAM (2/3)
IC101
AN7345K
PLAYBACK AND RECORD
/PLAYBACK AMP.
AUX R
L
R
L
JK690
VIDEO/AUX
FM+B
+B5
CLK
+B6 +B6
+B6 +B5
AM IF
OSC BUFF
AM LOOP
ANTENNA
FM IF
FM
OSC
B.P.F
CNP301
BI601 –20dB
ATT
Q101~
Q104
Q107
Q108
Q601
Q602 Q603 Q604
10.7 MHz
450 kHz
FM
ANTENNA
REC/PLAY
CLK
CE
DI
DO DI CE
MO/ST
SWITCHING +B5
FM/AM
IC302
LC72131
PLL(TUNER)
FM/AM OUT
L
R
BIAS
T1/T2
MUTING
P.B. REC.
AC BIAS
L
L
R
R
R
L
TAPE
TUNER
CD
PB
CNP6
FROM CD SECTION
HEAD
ERASE
SWITCHING
SWITCHING
SWITCHING
BIAS
Q113
Q114
Q112
Q110
Q706
Q707
Q708
SWITCHING
Q109
BIAS
OSC
Q111
L103
Q105
Q106
REC./P.B.
HEAD
TAPE 2
P.B. HEAD
TAPE 1
R-CH
L-CH
R-CH
L-CH
IC601
LC75341
AUDIO PROCESSOR
+B5
R
L
REC
R
L
ALC
R REC
L REC
POP REDUCE
SWITCHING
L(T2)
R(T2)
R(T1)
L(T1)
R
L
FM/AM
MPXIN
STEREO
AM RF IN
AM OSC IN AM OSC OUT
FM
Q360
VT
OSC
X352
4.5 MHZ
AM BAND
COVERAGE
AM TRACKING
T303 T306
Q302
X351
456 kHz
ZD351
5.1V
MO/ST
VCO
FM
DET
FM+B
GND
AM IF
CF351
IC303
LA1832S
FM IF DET.
FM MPX./
AM IF MPX.
AM MIX
CF352
T351
FM RF
OSC
FM
L312 T301
CF303T302
IC301
TA7358AP
FM FRONT END
BF301
21
4
24
2
1
81817
3
910
18
11
16
3
15
10
9
7
23
14
12
13
1
2
19
7
18
10
13
21
4
2
24
23
6
9
16
12
11
15
1
5413
8
4
3
1
21
7
98517
6
21
21
20 22 11
17
1615
9
6
57 13
14
12
15
162324
4
7
H/N
P.B
REC
T1/T2
T1/T2
NOR/
HIGH
+B5
+B5
+B5
SYSTEM
MUTE
TAPE
MECHANISM
ASS'Y
MOTOR
DRIVER
SOLENOID
DRIVER
+B3
+B3
