Sharp XL-DV484W User manual

XL-DV484W(Z)
TINSZA032AWZZ
DVD MICRO SYSTEM
MICRO-CHAÎNE DVD
CADENA MICRO CON DVD
MODEL
MODÈLE
MODELO
XL-DV484W
XL-DV555W
OPERATION MANUAL
MODE D’EMPLOI
MANUAL DE MANEJO
NTSC/PAL
SHARP CORPORATION
XL-DV484W
XL-DV555W
Please refer to pages i and E-1 to E-72.
Se reporter aux pages i et F-1 à F-72.
Consulte las páginas ii y S-1 a S-72.
ENGLISH
FRANÇAIS
ESPAÑOL
*DV484W(EN)_FRONT 04.2.23, 10:551
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
i
XL-DV484W(Z)
TINSZA032AWZZ
Copyright Information:
IUnauthorized copying, broadcast, public display, transmission,
public performance and rental (regardless of whether or not such
activities are for profit) of disc contents are prohibited by law.
IThis system is equipped with copy protection technology that
causes substantial degradation of images when the contents of a
disc are copied to a video tape.
Copy Protection:
This unit supports Macrovision copy protection.
On DVD discs that include a copy protection code, if the contents of the
DVD disc are copied using a VCR, the copy protection code prevents
the videotape copy from playing normally.
Apparatus Claims of U.S. Patent Nos.
4,631,603, 4,577,216, 4,819,098, and
4,907,093, licensed for limited viewing
uses only.
This product incorporates copyright protection technology that is
protected by method claims of certain U.S. patents and other
intellectual property rights owned by Macrovision Corporation and
other rights owners.
Use of this copyright protection technology must be authorized by
Macrovision Corporation, and is intended for home and other limited
viewing uses only unless otherwise authorized by Macrovision
Corporation.
Reverse engineering or disassembly is prohibited.
“DTS” and “DTS Digital Out” are trademarks of Digital Theater
Systems, Inc.
Manufactured under license from Dolby Laboratories. “Dolby” and the
double-D symbol are trademarks of Dolby Laboratories.
Renseignements sur les droits d’auteur:
ILa copie, la diffusion, l’affichage public, la transmission, la
représentation publique ou la location non autorisés (que ces
activités soient à but lucratif ou non) du contenu d’un disque sont
interdits par la loi.
ICe système est équipé d’une technologie de protection contre les
copies qui cause une importante dégradation de l’image quand le
contenu d’un disque est copié sur une vidéocassette.
Protection contre la copie:
Cet appareil supporte la protection de copie Macrovision.
Sur les disques DVD qui comportent un code de protection contre la
copie,silecontenududisqueDVDestcopiéàl’aided’unmagnétoscope,
le code de protection contre la copie empêche la lecture normale de la
cassette vidéo.
Brevets U.S. N 4 631 603, 4 577 216,
4 819 098 et 4 907 093 sous licence
uniquement pour des visualisations à
usage limité.
Ce produit utilise une technologie de protection des droits d’auteur
protégée par les revendications de méthode de certains brevets U.S.
etd’autresdroitsintellectuelsappartenantàlaMacrovisionCorporation
et à d’autres propriétaires des droits.
L’utilisation de cette technologie de protection des droits d’auteur doit
être autorisée par la Macrovision Corporation, et est seulement
destinée à l’usage domestique et d’autres visionnements limités
seulement à moins d’une autorisation spéciale de la Macrovision
Corporation.
Les applications techniques inversées ou le démontage sont
strictement interdits.
“DTS” et “DTS Digital Out” sont des marques de commerce de Digital
Theater Systems, Inc.
Fabriqué sous licence de Dolby Laboratories. “Dolby” et le symbole
double D sont des marques de commerce de Dolby Laboratories.
*DV484W(EN)_XP01-02 04.2.20, 17:201
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
ii
XL-DV484W(Z)
TINSZA032AWZZ
1
2
3
4
5
6
7
8
9
SHARP TINSZA032AWZZ (Z)
10
Información sobre los derechos de autor:
I La copia, difusión, exposición pública,
transmisión, interpretación pública y el alquiler
(independientemente de si estas actividades
tienen o no fines lucrativos) del contenido de los
discos sin autorización están prohibidos por la ley.
I Este sistema está provisto de tecnología para
proteccióncontra copias que degrada de manera
substancial las imágenes cuando se copia el
contenido de un disco a una cinta de vídeo.
Protección contra copias:
Este aparato es compatible con la protección
contra copias Macrovision.
Endiscos DVD que incluyen un código de protección
contra copias, si se copia el contenido del disco DVD
empleando una videograbadora, el código de
protección contra copias evita que la copia de la
videocinta puedan reproducirse con normalidad.
Derechos sobre aparatos de los N.°de
patente de EE.UU. 4.631.603, 4.577.216,
4.819.098,y 4.907.093, con licencia otorgada
sólo para usuarios de visión limitada.
Este producto incorpora tecnología de
protección de los derechos de autor que se
protege con derechos de métodos de ciertas
patentes de EE.UU. y otros derechos de
propiedad intelectual propiedad de Macrovision
Corporation y otros propietarios de derechos.
El empleo de esta tecnología de protección contra
copias debe estar autorizado por Macrovision
Corporation, y el propósito de su aplicación sólo es
para usuarios de visión en el hogar y visión adicional
limitada a menos que Macrovision Corporation lo
haya autorizado para otras aplicaciones.
Se prohíben la manipulación indebida y el
desmontaje.
“DTS” y “DTS Digital Out” son marcas
registradas de Digital Theater Systems, Inc.
Fabricado bajo licencia de Dolby Laboratories.
“Dolby”y elsímbolo conuna dobleD sonmarcas
registradas de Dolby Laboratories.
*DV484W(EN)_XP01-02 04.2.20, 18:042
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
E-1
ENGLISH
Important Instruction
XL-DV484W(Z)
TINSZA032AWZZ
WARNINGS
IWhen the ON/STAND-BY button is set at STAND-BY position, mains
voltage is still present inside the unit. When the ON/STAND-BY button is
set at STAND-BY position, the unit may be brought into operation by the
timer mode or remote control.
IThis unit contains no user serviceable parts. Never remove covers unless
qualified to do so. This unit contains dangerous voltages, always remove
mains plug from the socket before any service operation and when not in
use for a long period.
ITo prevent fire or shock hazard, do not expose this appliance to dripping
or splashing. No objects filled with liquids, such as vases, shall be placed
on the apparatus.
CAUTION
IThis product is classified as a CLASS 1 LASER product.
IThisproduct contains a low powerlaser device.Toensure continued safety
do not remove any cover or attempt to gain access to the inside of the
product. Refer all servicing to qualified personnel.
Note for users in Australia:
Copyright may exist in material you wish to record. Copying or broadcasting
such material without permission of the relevant licensees or owners of the
copyright is prohibited by law. SHARP is not in a position to authorise the
copyingor broadcasting of copyright materials and nothing in this OPERATION
MANUAL should be implied as giving that authority.
For other countries:
Audio-visual material may consist of copyrighted works which must not be
recorded without the authority of the owner of the copyright.
Please refer to the relevant laws in your country.
Note:
The illustrations of the speaker system in this operation manual are for the
model XL-DV484W.
Special notes
ENGLISH
Remote control × 1“AA”size battery (UM/SUM-3,
R6, HP-7 or similar) × 2
AM loop aerial × 1FM aerial × 1
Accessories
Please confirm that the following accessories are included.
Subwoofer cable × 1
(Black)
Note:
Only the above accessories are included.
Video cable × 1
(Yellow)
Thank you for purchasing this SHARP product.
To obtain the best performance from this product, please read
this manual carefully. It will guide you in operating your SHARP
product.
XL-DV484W DVD Micro System consisting of XL-DV484W (main unit), CP-
DV484 (front speaker) and CP-SW800V (active subwoofer).
XL-DV555W DVD Micro System consisting of XL-DV555W (main unit), CP-
DV555 (front speaker) and CP-SW800V (active subwoofer).
Introduction
*DV484W_EP01 04.2.20, 17:201
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
E-2
ENGLISH
General Information
XL-DV484W(Z)
TINSZA032AWZZ
4
Contents
HVideo CD/CD Playback Page
Video CD......................................................................................43
Preparation for video CD playback ........................................... 43
Video CD playback ...............................................................44, 45
CD playback ........................................................................ 46 - 49
MP3/WMA disc ......................................................................50, 51
HKaraoke
Playing karaoke ....................................................................52, 53
HRadio
Listening to the radio ...........................................................54, 55
HTape Playback
Listening to a cassette tape ................................................56, 57
HTape Recording
Recording to a cassette tape............................................. 57 - 61
HAdvanced Features
Timer and sleep operation ................................................. 62 - 65
Enhancing your system .......................................................66, 67
HReferences
Troubleshooting chart........................................................ 67 - 69
Maintenance ................................................................................ 70
Specifications ..................................................................... 70 - 72
HGeneral Information Page
Precautions ...................................................................................3
Controls and indicators ......................................................... 4 - 9
HPreparation for Use
System connections........................................................... 10 - 15
Remote control ...........................................................................16
HBasic Operation
General control ...........................................................................17
Setting the clock ......................................................................... 18
HDVD Explanation
Types of playable discs .......................................................19, 20
Preparing to watch a DVD (DVDs).............................................21
HDVD Setting
Setting up for playback of an NTSC disc .................................22
TV mode setup ............................................................................ 23
Parental setting.....................................................................24, 25
Audio setting.........................................................................26, 27
Disc language setting ........................................................ 27 - 29
Changing the display mode.......................................................30
HDVD Playback
Playing a DVD (DVDs) ................................................................31
Other disc play features.......................................................32, 33
HAdvanced DVD Features
Using the function control ................................................. 34 - 39
Repeat play .................................................................................40
Programmed play .......................................................................41
Selecting titles from the menu ..................................................42
Setting parameters using the disc menu .................................42
*DV484W_EP02-05 04.2.20, 17:202
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
E-3
ENGLISH
General Information
XL-DV484W(Z)
TINSZA032AWZZ
Precautions
HGeneral
IPlease ensure that the equipment is positioned in a well ventilated area
and ensure that there is at least 10 cm (4") of free space along the sides,
top and back of the equipment.
IDo not place active subwoofer system on the same surface as main
unit to prevent sound interruption during playback.
IUse the unit on a firm, level surface free from vibration.
IKeep the unit away from direct sunlight, strong magnetic fields, excessive
dust, humidity and electronic/electrical equipment (home computers,
facsimiles, etc.) which generate electrical noise.
IDo not place anything on top of the unit.
IDonotexpose the unittomoisture, to temperatureshigherthan 60°C (140°F)
or to extremely low temperatures.
IIf your system does not work properly, disconnect the AC power lead from
the wall socket. Plug the AC power lead back in, and then turn on your
system.
IIn case of an electrical storm, unplug the unit for safety.
IHold theAC power plug by the head when removing it from the wall socket,
as pulling the lead can damage internal wires.
IDo not remove the outer cover, as this may result in electric shock.
Refer internal service to your local SHARP service facility.
IThe ventilation should not be impeded by covering the ventilation openings
with items, such as newspapers, tablecloths, curtains, etc.
INo naked flame sources, such as lighted candles, should be placed on the
apparatus.
IAttentionshould bedrawn tothe environmental aspects of battery disposal.
IThis unit should only be used within the range of 5°C - 35°C (41°F- 95°F).
10 cm (4") 10 cm (4") 10 cm (4")
10 cm (4")
Warning:
The voltage used must be the same as that specified on this unit.
Using this product with a higher voltage other than that which is specified is
dangerous and may result in a fire or other type of accident causing damage.
SHARP will not be held responsible for any damage resulting from use of this
unit with a voltage other than that which is specified.
HVolume control
The sound level at a given volume setting depends on speaker efficiency,
location and various other factors. It is advisable to avoid exposure to high
volume levels. Do not turn the volume on to full at switch on and listen to music
at moderate levels.
HCare of DVD/Video CD/CD discs
DVD/Video CD/CD discs are fairly resistant to damage, however mistracking
can occur due to an accumulation of dirt on the disc surface. Follow the
guidelines below for maximum enjoyment from your DVD/Video CD/CD
collection and player.
IDo not write on either side of the disc, particularly the non-label side from
which signals are read. Do not mark this surface.
IKeep your discs away from direct sunlight, heat, and excessive moisture.
IAlways hold the DVD/Video CD/CDs by the edges. Fingerprints, dirt, or
wateron theDVD/Video CD/CDs can cause noise or mistracking. If a DVD/
Video CD/CD is dirty or does not play properly, clean it with a soft, dry
cloth, wiping straight out from the centre, along the radius.
YES
Correct
NO
Floor Table
*DV484W_EP02-05 04.2.20, 17:203
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
E-4
ENGLISH
General Information
XL-DV484W(Z)
TINSZA032AWZZ
4
Controls and indicators
HFront panel
Reference page
1. Disc Trays............................................................................................ 21
2. Illumination Light ................................................................................ 17
3. Timer Set Indicator ............................................................................. 63
4. On/Stand-by Button ...................................................................... 17, 21
5. Clock/Timer Button........................................................... 18, 62, 64, 65
6. DVD/Video CD/CD/MP3/WMA Track Down or Fast Reverse, Tape
Fast Wind, Tuner Preset Down, Time Down Button .......... 32, 33, 47, 55
7. Tape Reverse Play Button.................................................................. 56
8. Tape Reverse Mode Select Button .................................................... 56
9. Cassette Compartment ...................................................................... 56
10. Headphone Socket ............................................................................. 66
11. Disc Tray Open/Close Button ............................................................ 21
12. Disc Number Select Buttons .......................................................21, 31
13. DVD/Video CD/CD/MP3/WMA Direct Play Button............................. 31
14. Volume Control ................................................................................... 17
15. DVD/Video CD/CD/MP3/WMA Track Up or Fast Forward, Tape
Fast Wind, Tuner Preset Up, Time Up Button .......... 32, 33, 45, 47, 55
16. Memory/Set Button ............................................... 18, 41, 49, 55, 62, 65
17. Equaliser Mode Select Button ........................................................... 17
18. Extra Bass/Demo Mode Button ......................................................... 17
19.
DVD/Video CD/CD/MP3/WMA Play, Tape Forward Play Button ..... 31, 56
20. DVD/Video CD/CD/MP3/WMA or Tape Stop Button ................... 31, 56
21. DVD/Video CD/CD/MP3/WMA Button .......................................... 21, 31
22. Tuner (Band) Button ...........................................................................54
23. Tape Button ......................................................................................... 56
24. Video/Auxiliary Button ....................................................................... 66
25. Tape Record Pause Button ........................................ 53, 58, 59, 60, 61
26. Tuning Up Button................................................................................ 54
27. Tuning Down Button........................................................................... 54
28.
Mic Level ............................................................................................... 52
29.
Mic 1 Socket ........................................................................................ 52
30.
Mic 2 Socket ........................................................................................ 52
*DV484W_EP02-05 04.2.20, 17:204
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
E-5
ENGLISH
General Information
XL-DV484W(Z)
TINSZA032AWZZ
HDisplay
1. Disc Number Indicators
2. DVD/Video CD/CD/MP3/WMA Play Indicator
3. DVD/Video CD/CD/MP3/WMA Pause Indicator
4. DVD/Video CD/CD/MP3/WMA Repeat Indicator
5. DVD Indicator
6. VCD Indicator
7. CD Indicator
8. MP3 Indicator
9. Extra Bass Indicator
10. Memory Indicator
11. DVD Angle Indicator
12. DVD Chapter Indicator
13. DVD Title Indicator
14. WMA Indicator
15. Virtual Surround Indicator
16. Tape Record Indicator
17. Timer Recording Indicator
18. Timer Play Indicator
19. Sleep Indicator
20. Tape Reverse Play Indicator
21. Tape Forward Play Indicator
22. Tape Reverse Mode Indicator
23. FM Stereo Mode Indicator
24. FM Stereo Receiving Indicator
25. Daily Timer Indicator
26. Tuner Receiving Frequency Indicators
27. Karaoke Mode Indicator
Controls and indicators (continued)
*DV484W_EP02-05 04.2.20, 17:205
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
E-6
ENGLISH
General Information
4
XL-DV484W(Z)
TINSZA032AWZZ
HRear panel
Reference page
1. Video Output Socket .................................................................... 12, 21
2. S-Video Output Socket ....................................................................... 21
3. Cooling Fan
4. AC Voltage Selector............................................................................ 13
5. Speaker Terminals ........................................................................ 10, 11
6. AC Power Lead ............................................................................. 10, 13
7. Audio Digital Output Socket .............................................................. 67
8. FM 75 Ohms Aerial Terminal........................................................ 10, 11
9. FM Aerial Earth Terminal.............................................................. 10, 11
10. AM Loop Aerial Socket................................................................. 10, 11
11. Video/Auxiliary (Audio Signal) Input Sockets .................................. 66
12. Span Selector Switch ......................................................................... 15
13. Subwoofer Pre-output Socket ........................................................... 10
Cooling fan:
This product is equipped with a cooling fan inside, which begins to run at
a specified volume level for better heat radiation.
*DV484W_EP06-09 04.2.20, 17:216
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
E-7
ENGLISH
General Information
XL-DV484W(Z)
TINSZA032AWZZ
1
2
3
8
6
7
9
10
5
4
13
4
2
HActive subwoofer
Reference page
1. Bass Reflex Port
2. Power Indicator ................................................................................... 14
3. Subwoofer Unit
4. Cooling Fan
5. Subwoofer Input Socket............................................................... 10, 14
6. AC Voltage Selector............................................................................ 14
7. Power Switch ...................................................................................... 14
8. AC Power Lead ............................................................................. 10, 14
9. Volume Control ................................................................................... 14
10. Crossover Frequency Control ........................................................... 14
HSpeaker system
1. Tweeter
2. Woofer
3. Bass Reflex Duct
4. Speaker Wire
Controls and indicators (continued)
Cooling fan:
This product is equipped with a cooling fan
inside, which begins to run once the power is
on for better heat radiation.
*DV484W_EP06-09 04.2.20, 17:217
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
E-8
ENGLISH
General Information
4
XL-DV484W(Z)
TINSZA032AWZZ
1
2
20
21
22
23
24
25
26
27
28
3
4
5
6
7
8
9
10
18
19
11
15 33 34 35 36
37 38 39 40
29 30 31 32
16 17
12 13 14
HRemote control Reference page
1. Remote Control Transmitter .............................................................. 16
2. Disc Number Select Buttons ................................................. 21, 31, 44
3. DVD Top Menu Button ........................................................................42
4. Clock/Timer Button........................................................... 18, 62, 64, 65
5. Direct Search Buttons .................................................................. 49, 50
6. Clear/Display Button .......................................................................... 41
7. Enter Button .................................................................................. 22, 26
8. Cursor Left Button ........................................................................ 25, 49
9. Memory/Dimmer Button ................................. 17, 18, 41, 49, 55, 62, 65
10. Cursor Down Button............................................................... 22, 26, 49
11. Tape Record Pause Button .................................................... 59, 60, 66
12.
DVD Chapter Skip/DVD/Video CD/MP3/WMA Fast Reverse/Video CD/
CD/MP3/WMA Track Down/Tape Fast Wind and Tuner Preset Down,
Time Down Button ..............................................................
32, 33, 47, 55
13. DVD/Video CD/CD/MP3/WMA Pause Button..................................... 33
14.
DVD Chapter Skip/DVD/Video CD/MP3/WMA Fast Forward/Video CD/
CD/MP3/WMA Track Up/Tape Fast Wind and Tuner Preset Up,
Time Up Button ........................................................... 32, 33, 45, 47, 55
15. Tape Reverse Play Button.................................... 56, 57, 58, 59, 60, 61
16. DVD/Video CD/CD/MP3/WMA/Tape Stop Button ........................ 31, 56
17. DVD/Video CD/CD/MP3/WMA/Tape Play Button ........................ 31, 56
18. Shift Button ................................................................................... 22, 53
19. Volume Up/Down Buttons .................................................................. 17
20. On/Stand-by Button ...................................................................... 16, 21
21. Echo Level Up/Down Buttons............................................................ 52
22. DVD Direct Button ..............................................................................35
23. DVD Menu Button ............................................................................... 42
24. Return Button...................................................................................... 25
25. CD Random Button............................................................................. 48
26. Cursor Up Button.................................................................... 22, 26, 49
27. Cursor Right Button ..................................................................... 25, 49
28. DVD/Video CD Slow Button ............................................................... 32
29. DVD/Video CD/CD/MP3/WMA Repeat Button ................................... 40
30. DVD Subtitle Button ...........................................................................36
31. DVD Angle Button ............................................................................... 36
32. DVD Zoom Button ............................................................................... 39
33. DVD/Video CD/CD/MP3/WMA Button .......................................... 21, 31
34. Tuner (Band) Button ...........................................................................54
35. Tape Button ......................................................................................... 56
36. Video Button ....................................................................................... 66
37. Equaliser Mode Select Button ........................................................... 17
38. Extra Bass Button .............................................................................. 17
39. DVD 3-D Virtual Surround Button ..................................................... 37
40. DVD On Screen Button....................................................................... 30
*DV484W_EP06-09 04.2.20, 17:218
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
E-9
ENGLISH
General Information
XL-DV484W(Z)
TINSZA032AWZZ
1
2
3
4
5
6
HRemote control with shift button Reference page
1. Karaoke/Audio Mode Button .............................................................53
2. DVD Setup Button......................................................................... 22, 26
3. DVD Sound Button .............................................................................37
4. DVD Super Picture Button ................................................................. 39
5. DVD/Video CD/CD A-B Repeat Button .............................................. 40
6. DVD Digital Gamma Button ............................................................... 38
Controls and indicators (continued)
*DV484W_EP06-09 04.2.20, 17:219
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
E-10
ENGLISH
Preparation for Use
4
XL-DV484W(Z)
TINSZA032AWZZ
System connections
Right speaker
FM aerial AM loop aerial
Left speaker
To a wall socket
(See page 13)
Active subwoofer
To a wall socket
(See page 14)
Subwoofer cable
(Black)
Red Black
*DV484W_EP10-16 04.2.20, 17:2110
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
E-11
ENGLISH
Preparation for Use
XL-DV484W(Z)
TINSZA032AWZZ
HAerial connection
Supplied FM aerial:
Connect the FM aerial wire to the FM 75 OHMS terminal and position the FM
aerial wire in the direction where the strongest signal can be received.
Supplied AM loop aerial:
Connect the AM loop aerial to the AM LOOP socket. Position the AM loop
aerial for optimum reception. Place theAM loop aerial on a shelf, etc., or attach
it to a stand or a wall with screws (not supplied).
Note:
Placing the aerial on the unit or near the AC power lead may cause noise
pickup. Place the aerial away from the unit for better reception.
Installing the AM loop aerial:
< Assembling > < Attaching to the wall >
External FM aerial:
Use an external FM aerial if you require better reception. Consult your dealer.
ANTENNA
GND
FM
75 OHMS
AM
LOOP
External
FM aerial
75 ohm
coaxial
cable
Screws (not supplied)
Wall
System connections (continued)
HSpeaker connection
Connect the black wire to the minus (-) terminal, and the red wire to the plus (+)
terminal.
Caution:
IUse speakers with an impedance of 6 ohms or more, as lower impedance
speakers can damage the unit.
IDo not mistake the right and the left channels. The right speaker is the one
on the right side when you face the unit.
IDo not let the bare speaker wires touch each other.
IDo not allow any objects to fall into or to be placed in the bass reflex ducts.
IDo not stand or sit on the speakers. You may be injured.
HSpeaker grilles are removable
Make sure nothing comes into contact with the
speakerdiaphragmswhen you removethe speaker
grilles.
Incorrect
Note:
When an external FM aerial is used, disconnect the supplied FM aerial wire.
*DV484W_EP10-16 04.2.20, 17:2111
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
E-12
ENGLISH
Preparation for Use
4
XL-DV484W(Z)
TINSZA032AWZZ
HPlacing the speaker system
There is no distinction between the right and the left speakers
.
Caution:
IDo not place active subwoofer system on the same surface as main unit to
prevent sound interruption during playback.
Notes:
IThe speakers are magnetically shielded.
Therefore, they do not affect the display even if you use them near the TV.
However, some colour variation may occur, depending on the type of TV
used.
If colour variation occurs...
Turn off the TV (from the power switch).
After 15 - 30 minutes, turn the TV on again.
If the colour variation is still present...
Move the speakers further away from the TV.
IIf any kind of magnet or an electromagnet is placed too close to the TV and
the system, irregular colours may appear on the TV screen.
Floor Table
Active subwoofer Left speaker Main unit Right speaker
HTV/monitor connection
If the TV/monitor has a video input, connect it to the VIDEO OUTsocket on the
rear of the unit.
TV
To video
input socket
Video cable
(Yellow)
*DV484W_EP10-16 04.2.20, 17:2112
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
E-13
ENGLISH
Preparation for Use
XL-DV484W(Z)
TINSZA032AWZZ
System connections (continued)
Main Unit
HSetting the AC voltage selector
Check the setting of the AC voltage selector located on the rear panel before
pluggingtheunitinto a wall socket.Ifnecessary, adjusttheselectorto correspond
to the AC power voltage used in your area.
Turn the selector with a screwdriver until the appropriate voltage number
appears in the window (110 V, 127 V, 220 V or 230 V - 240 V AC).
HAC power connection
Afterchecking all theconnections havebeen made correctly, plug theAC power
lead of this unit into the wall socket. If you plug the unit first, the unit will enter
the demonstration mode (see page 15).
Notes:
IThe unit will start the tape initialisation when plugged in to the AC socket.
During this process, initialising sound will be heard and the unit cannot be
turned on. Wait until the process is finished.
IUnplug the AC power lead from the wall socket if the unit will not be in use
for a prolonged period of time.
AC plug adaptor
In areas (or countries) where a wall socket as shown in illustration 2 is used,
connect the unit using theAC plug adaptor supplied with the unit, as illustrated.
The AC plug adaptor is not included in areas where the wall socket and AC
power plug can be directly connected (see illustration 1 ).
Note for users in Australia and New Zealand:
AnAC plug adaptor is not supplied if the lead has an Australian standard plug.
*DV484W_EP10-16 04.2.20, 17:2113
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
E-14
ENGLISH
Preparation for Use
4
XL-DV484W(Z)
TINSZA032AWZZ
HSetting the AC voltage selector
Check the setting of theAC voltage selector located on the rear panel before
plugging the unit into a wall socket. If necessary, adjust the selector to
correspond to the AC power voltage used in your area.
Turn the selector with a screwdriver until the appropriate voltage num-
ber appears in the window (110 V, 127 V, 220 V or 230 V - 240 V AC).
HConnecting the AC power lead
After checking all the connections have been made correctly, plug the AC
power lead of this unit into the wall socket.
Note:
Unplug theAC power lead from the wall socket if the unit will not be in use for
a prolonged period of time.
AC plug adaptor
In areas (or countries) where a wall socket as shown in illustration 2 is
used, connect the unit using the AC plug adaptor supplied with the unit, as
illustrated. TheAC plug adaptor is not included in areas where the wall socket
and AC power plug can be directly connected (see illustration 1 ).
Note for users in Australia and New Zealand:
AnAC plug adaptor is not supplied if the lead has an Australian Standard plug.
HPower switch
The POWER indicator lights up when you press the POWER switch to
ON.
HVolume control
Turn the VOLUME control clockwise to increase the volume, and turn it anti-
clockwise to decrease the volume.
HCrossover frequency control
Adjust the high frequency cut-off point. Frequencies higher than the set
frequency are removed.
Toemphasise the bass, turn this control towards 35 Hz and increase the volume.
Notes:
Observe the following to avoid malfunction and sound distortion.
I
Donot set the volume too high on the main unit.The subwoofermay be damaged.
I Before you switch on/off on the main unit, minimise the volume on the main unit.
Active Subwoofer
Make sure to unplug the AC power lead of the main unit before any
connections.
HConnecting the subwoofer
Use the subwoofer cable to connect the SUBWOOFER PRE-OUT socket on
the main unit and the SUBWOOFER IN socket on the active subwoofer.
*DV484W_EP10-16 04.2.20, 17:2114
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
E-15
ENGLISH
Preparation for Use
XL-DV484W(Z)
TINSZA032AWZZ
System connections (continued)
HSetting the FM/AM span selector
TheInternationalTelecommunicationUnion (ITU)has established that member
countries should maintain either a 100 kHz or a 50 kHz interval between
broadcasting frequencies of FM stations and 10 kHz or 9 kHz for AM station.
The illustration shows the 50/9 kHz zones (regions 1 and 3), and the 100/10
kHz zone (region 2).
Before using the unit, set the SPAN SELECTOR switch (on the rear panel) to
the interval (span) of your area.
To change the tuning zone:
1. Press the ON/STAND-BY button to enter the stand-by mode.
2. Set the SPAN SELECTOR switch (on the rear panel) as follows.
IFor 50 kHz FM interval (9 kHz in AM) →50/9
IFor 100 kHz FM interval (10 kHz in AM) →100/10
3. Whilst pressing down the I6 button and the X-BASS/DEMO button, press
the 5 3 PRESET Xbutton until “CLEAR AL” appears.
Caution:
Thisoperationwill erase alldatastored in memoryincludingclock, timer settings,
tuner preset, and CD programmes.
HDemonstration mode
The first time the unit is plugged in, the unit
will enter the demonstration mode.
You will see words scroll.
To cancel the demonstration mode:
When the unit is in the power stand-by mode (demonstration mode), press the
X-BASS/DEMO button. The demonstration mode will be cancelled and the
display will disappear.
To return to the demonstration mode:
Whenthe unitis inthe powerstand-by mode,press theX-BASS/DEMO button.
Note:
When the power is on, the X-BASS/DEMO button can be used to select the
extra bass mode.
1
2
3
4
5
6
7
8
9
SHARP TINSZA032AWZZ (Z)
10
*DV484W_EP10-16 04.2.20, 17:2115
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
E-16
ENGLISH
Preparation for Use
4
XL-DV484W(Z)
TINSZA032AWZZ
Remote control
HBattery installation
1 Open the battery cover.
2 Insert the batteries according to the direction indicated in the battery
compartment.
Wheninserting or removing the batteries, push them towards the –battery
terminal.
3 Close the cover.
Precautions for battery use:
IReplace all old batteries with new ones at the same time.
IDo not mix old and new batteries.
IRemove the batteries if the unit is not to be used for long periods of time.
This will prevent potential damage due to battery leakage.
Caution:
IDo not use rechargeable batteries (nickel-cadmium battery, etc.).
IInstalling the batteries incorrectly may cause the unit to malfunction.
Notes concerning use:
IReplace the batteries if the operating distance is reduced or if the operation
becomes erratic. Purchase 2 “AA” size batteries (UM/SUM-3, R6, HP-7 or
similar).
IPeriodically clean the transmitter on the remote control and the sensor on
the unit with a soft cloth.
IExposing the sensor on the unit to strong light may interfere with operation.
Change the lighting or the direction of the unit.
IKeep the remote control away from moisture, heat, shock and vibrations.
HTest of the remote control
Check the remote control after checking all the connections have been made
correctly. (See pages 10 - 14.)
Point the remote control directly at the remote sensor on the unit.
The remote control can be used within the range shown below:
Press the ON/STAND-BY button. Does the power turn on? Now, you can enjoy
music.
0.2 m - 6 m
(8” - 20’)
Remote sensor
1
2
3
4
5
6
7
8
9
SHARP TINSZA032AWZZ (Z)
10
*DV484W_EP10-16 04.2.20, 17:2116
Downloaded from: http://www.usersmanualguide.com/

XL-DV484W
XL-DV555W
E-17
ENGLISH
Basic Operation
XL-DV484W(Z)
TINSZA032AWZZ
HVolume control
Main unit operation:
Whenthe VOLUME control is turned clockwise, thevolume will increase. When
it is turned anti-clockwise, the volume will decrease.
Remote control operation:
Press the VOLUME (+ or -) button to increase or decrease the volume.
HBass control (X-BASS)
When the power is first turned on, the unit will enter the extra bass mode which
emphasises the bass frequencies, and “X-BASS” will appear. To cancel the
extra bass mode, press the X-BASS/DEMO (X-BASS) button.
HEqualiser
When the EQUALIZER button is pressed, the current mode setting will be
displayed. To change to a different mode, press the EQUALIZER button
repeatedly until the desired sound mode appears.
General control
HTo turn the power on
Press the ON/STAND-BY button to turn the power on.
HIllumination light control
When the power is turned on, the entire display and
ring around the volume control light up. To turn on/off
the light, hold down the MEMORY/DIMMER button on
the remote control for more than 2 seconds.
After Use:
Press the ON/STAND-BY button to enter the power stand-by mode.
For tuner, tape, and video other than DVD/VCD disc For DVD/VCD disc only
The sound is not modified.
Bass and treble are emphasised.
Treble is cut a little.
Bass and treble are slightly emphasised.
Vocals (midrange tones) are emphasised.
Treble is slightly emphasised.
FLAT
MODE-1
MODE-2
MODE-3
MODE-4
MODE-5
30 MAXIMUM0 .....
*DV484W_EP17-18 04.2.20, 17:2117
Downloaded from: http://www.usersmanualguide.com/
