Sharp XL-MP110H User manual

SERVICE MANUAL
XL-MP110H/MP110E
No. S2513XLMP110H
SHARP CORPORATION
CONTENTS
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
PRECAUTIONS FOR USING LEAD-FREE SOLDER
CHAPTER 1. GENERAL DESCRIPTION
[1] SAFETY PRECAUTION FOR SERVICE
MANUAL ........................................................ 1-1
[2] SPECIFICATIONS ......................................... 1-1
[3] NAMES OF PARTS........................................ 1-3
CHAPTER 2. ADJUSTMENTS
[1] ADJUSTMENT ............................................... 2-1
[2] TEST MODE .................................................. 2-2
[3] Standard Specification of Stereo System
Error Message Display Contents ................... 2-4
CHAPTER 3. MECHANICAL DESCRIPTION
[1] REMOVING AND REINSTALLING THE
MAIN PARTS ................................................. 3-1
[2] DISASSEMBLY .............................................. 3-3
CHAPTER 4. DIAGRAMS
[1] BLOCK DIAGRAM ......................................... 4-1
CHAPTER 5. CIRCUIT DESCRIPTION
[1] WAVEFORMS OF CD CIRCUIT....................5-1
[2] VOLTAGE ......................................................5-2
CHAPTER 6. CIRCUIT SCHEMATICS AND PARTS
LAYOUT
[1] NOTES ON SCHEMATIC DIAGRAM ............6-1
[2] TYPES OF TRANSISTOR AND LED ............6-1
[3] WIRING SIDE OF PWB/SCHEMATIC DIA-
GRAM............................................................6-2
CHAPTER 7. FLOWCHART
[1] TROUBLESHOOTING ..................................7-1
CHAPTER 8. OTHERS
[1] FUNCTION TABLE OF IC .............................8-1
[2] FL DISPLAY ................................................8-10
Parts Guide
MICRO COMPONENT SYSTEM
XL-MP110H
MODEL
XL-MP110H Micro Component System consisting of XL-
MP110H (main unit) and CP-MP110H (speaker system).
• In the interests of user-safety the set should be restored to its origi-
nal condition and only parts identical to those specified be used.
XL-MP110E
MODEL
XL-MP110E Micro Component System consisting of XL-
MP110E (main unit) and CP-MP110E (speaker system).
Illustration XL-MP110H
Illustration XL-MP110E
(XL-MP110H Only) (XL-MP110H Only)

XL-MP110H/MP110E
i
AudioXL-MP110H/MP110EService ManualXLMP110H/EMarketE
PRECAUTIONS FOR USING LEAD-FREE SOLDER
1. Employing lead-free solder
Example:
Indicates lead-free solder of tin, silver and copper.
2. Using lead-free wire solder
When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with conventional lead wire solder
may cause damage or accident due to cracks.
As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40 C, we recommend you to use a
dedicated soldering bit, if you are not familiar with how to obtain lead-free wire solder or soldering bit, contact our service station
or service branch in your area.
3. Soldering
As the melting point of lead-free solder (Sn-Ag-Cu) is about 220 C which is higher than the conventional lead solder by 40 C,
and as it has poor solder wettability, you may be apt to keep the soldering bit in contact with the PWB for extended period of
time. However, Since the land may be peeled off or the maximum heat-resistance temperature of parts may be exceeded,
remove the bit from the PWB as soon as you confirm the steady soldering condition.
Lead-free solder contains more tin, and the end of the soldering bit may be easily corrected. Make sure to turn on and off the
power of the bit as required.
If a different type of solder stays on the tip of the soldering bit, it is alloyed with lead-free solder. Clean the bit after every use
of it.
When the tip of the soldering bit is blackened during use, file it with steel wool or fine sandpaper.
Be careful when replacing parts with polarity indication on the PWB silk.
Lead-free wire solder for servicing
Ref No. Description Parts No.
PWB-A 92LPWB6289MANS
92LPWB6289PWRS
92LPWB6230CDUS
PWB-B
PWB-B
PWB-D
MAIN (A1),DISPLAY (A2),TERMINAL (A3),SWITCH (A4) [XL-MP110H]
PWB-A 92LPWB6291MANS
92LPWB6291PWRS
MAIN (A1),DISPLAY (A2),TERMINAL (A3),SWITCH (A4) [XL-MP110E]
POWER (B1),JACK (B2) [XL-MP110H]
POWER (B1),JACK (B2) [XL-MP110E]
CD MP3
"MAIN,DISPLAY,TERMINAL,SWITCH,POWER,JACK,TUNER,CD MP3,CD MOTOR (PWB ONLY),
CD CHANGER MOTOR (PWB ONLY) PWB" of this model employs lead-free solder.
The LF symbol indicates lead-free solder, and is attached on the PWB and service manuals. The alphabetical character
following LF shows the type of lead-free solder.
92LPWB6289TUNSPWB-C
PWB-E
PWB-F
TUNER [XL-MP110H]
92LPWB6291TUNSPWB-C TUNER [XL-MP110E]
CD MOTOR (PWB ONLY)
CD CHANGER MOTOR (PWB ONLY)
QPWBF0027AWZZ
QPWBF1055AWZZ

XL-MP110H/MP110E
1 – 1
AudioXL-MP110H/MP110EService ManualXLMP110H/EMarketE
CHAPTER 1. GENERAL DESCRIPTION
[1] SAFETY PRECAUTION FOR SERVICE MANUAL
Precaution to be taken when replacing and servicing the Laser Pickup.
The AEL (Accessible Emission Level) of Laser Power Output for this model is specified to be lower than Class 1 Requirements. However, the follow-
ing precautions must be observed during servicing to protect your eyes against exposure to the Laser beam.
1) When the cabinet has been removed, the power is turned on without a compact disc, and the Pickup is on a position outer than the lead-in posi-
tion, the Laser will light for several seconds to detect a disc. Do not look into the Pickup Lens.
2) The Laser Power Output of the Pickup inside the unit and replacement service parts have already been adjusted prior to shipping.
3) No adjustment to the Laser Power should be attempted when replacing or servicing the Pickup.
4) Under no circumstances look directly into the Pickup Lens at any time.
5) CAUTION - Use of controls or adjustments, or performance of procedures other than those specified herein may result in hazardous radiation
exposure.
[2] SPECIFICATIONS
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER TO THE OPERATION MANUAL.
XL-MP110H
General
Amplifier
CD player
Tuner
Cassette deck
Speaker
Power source AC230V,50Hz
Power
consumption
Power on:100 W
Power stand-by: 0.6 W(*)
Dimensions Width: 185 mm (7-1/4")
Height: 260 mm (10-1/4")
Depth: 307 mm (12")
Weight 6.1 kg (13.4 lbs.)
( * )This power consumption value is obtained when the demonstra-
tion mode is cancelled in the power stand-by mode. Refer to
page 9 to cancel the demonstration mode.
Output power PMPO: 364 W (total)
MPO: 182 W (91 W + 91 W) (DIN 45 324)
RMS: 100 W (50W+50W)(DIN 45 324)
RMS: 68 W (38 W + 38 W) (DIN 45 500)
Output terminals Speakers: 6 ohms
Headphones: 16 - 50 ohms
(recommended: 32 ohms)
Subwoofer pre-out (audio signal):
200mV/10kohmsat70Hz
Input terminals Video/Auxiliary (audio signal):
500mV/47kohms
Type 5-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency range FM: 87.5 - 108 MHz
AM: 522 - 1,620 kHz
Frequency
response
50 - 14,000 Hz (normal tape)
Signal/noise ratio 50 dB (recording/playback)
Wow and flutter 0.35 % (DIN 45 511)
Type 2-way type speaker system
5cm(2")tweeter
13 cm (5-1/8") woofer
Maximum input
power
100 W
Rated input power 50 W
Impedance 6ohms
Dimensions Width: 185 mm (7-1/4")
Height: 260 mm (10-1/4")
Depth: 205 mm (8-1/16")
Weight 2.4 kg (5.3 lbs.)/each
■■
■
■
■
■

XL-MP110H/MP110E
1 – 2
XL-MP110E
General
Amplifier
Tuner
Cassette deck
Speaker
Power source AC 230 - 240 V, 50 Hz
Power
consumption
100 W
Dimensions Width: 185 mm (7-1/4")
Height: 260 mm (10-1/4")
Depth: 307 mm (12")
Weight 6.1 kg (13.4 lbs.)
Output power
MPO: 182 W (91 W + 91 W) (10 % T.H.D.)
RMS: 100 W (50 W + 50 W) (10 % T.H.D.)
RMS: 76 W (38 W + 38 W) (0.9 % T.H.D.)
Output terminals Speakers: 6 ohms
Headphones: 16 - 50 ohms
(recommended: 32 ohms)
Subwoofer pre-out (audio signal):
200mV/10kohmsat70Hz
Input terminals Video/Auxiliary (audio signal):
500mV/47kohms
Frequency range FM: 87.50 - 108.00 MHz
AM: 522 - 1,620 kHz
Frequency
response
50 - 14,000 Hz (normal tape)
Signal/noise ratio 50 dB (recording/playback)
Wow and flutter 0.3 % (WRMS)
Type 2-way type speaker system
5 cm (2") tweeter
13 cm (5-1/8") woofer
Maximum input
power
100 W
Rated input power 50 W
Impedance 6 ohms
Dimensions Width: 185 mm (7-1/4")
Height: 260 mm (10-1/4")
Depth: 205 mm (8-1/16")
Weight 2.4 kg (5.3 lbs.)/each
■■
■
■
■
■CD player
Type 5-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Specifications for this model are subject to change without prior
notice.

XL-MP110H/MP110E
1 – 3
[3] NAMES OF PARTS
■
Illustration XL-MP110H
Front panel
1. Disc Trays
2. Timer Indicator
3. On/Stand-by Button
4. Clock/Timer Button
5. Tape Record Pause Button
6. RDS ASPM (Auto Station Programme Memory) Button
7. RDS Programme Type/
Traffic Information Search Button
8. RDS Display Mode Select Button
9. Cassette Compartment
10. Headphone Socket
11. Disc Tray Open/Close Button
12. Disc Number Select Buttons
13. Disc Direct Play Button
14. Remote Sensor
15. Volume Control
16. Memory/Set Button
17. Equalizer Mode Select Button
18. Extra Bass/Demo Mode Button
19. CD Button
20. Tape Button
21. Disc Track Down or Fast Reverse, Tape Rewind,
Tuner Preset Down, Time Down Button
22. Disc Track Up or Fast Forward, Tape Fast Forward,
Tuner Preset Up, Time Up Button
23. Tuner (Band) Button
24. Video/Auxiliary Button
25. Disc Play or Repeat, Tape Play Button
26. Tuning Down Button
27. Tuning Up Button
28. Disc or Tape Stop Button
/
■
Illustration XL-MP110H
Display
1. Disc Number Indicators
2. Disc Play Indicator
3. Disc Pause Indicator
4. Memory Indicator
5. Disc Repeat Play Indicator
6. WMA Indicator
7. CD Indicator
8. MP3 Indicator
9. Extra Bass Indicator
10. RDS Indicator
11. Traffic Announcement Indicator
12. Dynamic PTY Indicator
13. Traffic Programme Indicator
14. Tape Record Indicator
15. Sleep Indicator
16. Timer Play Indicator
17. Timer Recording Indicator
18. Tape Play Indicator
19. FM Stereo Mode Indicator
20. Daily Timer Indicator
21. FM Stereo Receiving Indicator
976 8321 4 5
16
13
1110
2019 21
15
12
14
17
18

XL-MP110H/MP110E
1 – 4
Illustration XL-MP110E
Front panel
1. Disc Trays
2. Timer Indicator
3. On/Stand-by Button
4. Clock/Timer Button
5. Tape Record Pause Button
6. Cassette Compartment
7. Headphone Socket
8. Disc Tray Open/Close Button
9. Disc Number Select Buttons
10. CD Direct Play Button
11. Remote Sensor
12. Volume Control
13. Memory/Set Button
14. Equalizer Mode Select Button
15. Extra Bass/Demo Mode Button
16. CD Button
17. Tape Button
18. Disc Track Down or Fast Reverse, Tape Rewind,
Tuner Preset Down, Time Down Button
19. Disc Track Up or Fast Forward, Tape Fast Forward,
Tuner Preset Up, Time Up Button
20. Tuner (Band) Button
21. Video/Auxiliary Button
22. Disc Play or Repeat, Tape Play Button
23. Tuning Down Button
24. Tuning Up Button
25. Disc or Tape Stop Button
/
25
■
■
Illustration XL-MP110E
Display
1. Disc Number Indicators
2. Disc Play Indicator
3. Disc Pause Indicator
4. Memory Indicator
5. Disc Repeat Play Indicator
6. WMA Indicator
7. CD Indicator
8. MP3 Indicator
9. Extra Bass Indicator
10. Tape Record Indicator
11. Sleep Indicator
12. Timer Play Indicator
13. Timer Recording Indicator
14. Tape Play Indicator
15. FM Stereo Mode Indicator
16. Daily Timer Indicator
17. FM Stereo Receiving Indicator
976 8321 4 5
1615 17
14
1211
10
13

XL-MP110H/MP110E
1 – 5
■
■
Rear panel
1. Speaker Terminals
2. AC Power Lead
3. FM 75 Ohms Aerial Socket
4. AM Loop Aerial Socket
5. Video/Auxiliary (Audio Signal) Input Sockets
6. Cooling Fan
7. Subwoofer Pre-output Socket
Speaker system
1. Tweeter
2. Woofer
3. Bass Reflex Duct
4. Speaker Wire
7
3
4
5
6
1
2
3
4
1
2
■Remote control
1. Remote Control Transmitter
2. Disc Clear/Dimmer Button
3. Disc Number Select Buttons
4. Disc Random Button
5. Disc Stop Button
6. Tape Stop Button
7. Disc Track Down or Fast Reverse, Tape Rewind,
Tuner Preset Down, Time Down Button
8. Equalizer Mode Select Button
9. Extra Bass Button
10. Disc Direct Search Buttons
11. Memory Button
12. On/Stand-by Button
13. CD Button
14. Disc Pause Button
15. Tuner (Band) Button
16. Disc Play or Repeat Button
17. Tape Button
18. Tape Play Button
19. Video/Auxiliary Button
20. Tape Record Pause Button
21. Disc Track Up or Fast Forward, Tape Fast Forward,
Tuner Preset Up, Time Up Button
22. Volume Up and Down Buttons
23. Clock/Timer Button
24. MP3/WMA Display Button
21
22
23
24
6
5
414
16
18
20
2
3
8
10
7
17
19
13
15
12
9
111

XL-MP110H/MP110E
2 – 1
AudioXL-MP110H/MP110EService ManualXLMP110H/EMarketE
CHAPTER 2. ADJUSTMENTS
[1] ADJUSTMENT
1. MECHANISM SECTION
•Driving Force Check
•Torque Check
2. TUNER SECTION
fL: Low-range frequency
fH: High-range frequency
•AM IF/RF
Signal generator: 400 Hz, 30%, AM modulated
Notes:
1. Description of the "FM IF Adjustment" is not carried on this Manual.
It is because the IF coil in the FM front end section has been best
adjusted in the factory so that its further adjustment is not needed
at the field. When replacing the FM front end assembly, no adjust-
ment is needed either.
2. The parts in the FM front end section are prepared in a complete
unit, so you can't obtain each part individually.
•Tape Speed
3. CD SECTION
•Adjustment
Since this CD system incorporates the following automatic adjust-
ment functions, readjustment is not needed when replacing the
pickup. Therefore, different PWBs and pickups can be combined
freely.
Each time a disc is changed, these adjustments are performed
automatically. Therefore, playback of each disc can be performed
under optimum conditions.
Items adjusted automatically
1) Offset adjustment (The offset voltage between the head amplifier
output and the VREF reference voltage is compensated inside the
IC.)
* Focus offset adjustment
* Tracking offset adjustment
2) Tracking balance adjustment
3) Gain adjustment (The gain is compensated inside the IC so that the
loop gain at the gain crossover frequency will be 0 dB.)
* Focus gain adjustment
* Tracking gain adjustment
4. CD ERROR CODE DESCRIPTION
* 'CHECKING'
If Error is detected, 'CHECKING' will be displayed instead of 'ER-
CD**'. 'ER-CD**' display will only be displayed when error had been
detected for the 5th times.
Torque Meter Specified Value
Play: TW-2111 Over 80 g
Torque Meter Specified Value
Play: TW-2111 30 to 80 g.cm
Fast forward: TW-2231 70 to 180 g.cm
Rewind: TW-2231 70 to 180 g.cm
Test Stage Frequency Frequency
Display
Setting/
Adjusting
Parts
Instrument
Connection
AM IF 450 kHz 1,620 kHz T351 *1
AM Band
Coverage
— 522 kHz (fL): T306
1.1 ± 0.1 V
*2
AM Tracking 990 kHz 990 kHz (fL): T303 *1
*1. Input: Antenna Output: TP302
*2. Input: Antenna Output: TP301
Figure 2 ADJUSTMENT POINTS
AM
LOOP
ANTENNA
IC302
T351
IC303
L354
T303
T306
CNP302
SO301
FE301
TP302
TP301
AM TRACKING fL
AM BAND
COVERAGE fL
AM IF
ANTENNA
TERMINAL
TUNER PWB-C
20
R357
R356
C393
Test Tape Adjusting
Point
Specified
Value
Instrument
Connection
Normal
speed
MTT-111 Variable
Resistor in
motor.
3,000 ± 30 Hz Speaker Ter-
minal (Load
resistance: 6
ohms)
Figure 1
Error Explanation
01 When Pickup set inner position, inner switch cannot detect
'ON' level for 10 secs.
10* CAM error. Can't detect CAM switch when CAM is moving.
11* When it detect cam operation error during initialize process.
20* TRAY error. Can't detect TRAY switch when TRAY is mov-
ing.
21* When it detect TRAY operation error during initialize pro-
cess.
31 When it change to CD function, DSP cannot read initial data.
TAPE MECHANISM
Tape
Motor
Variable Resistor in motor

XL-MP110H/MP110E
2 – 2
[2] TEST MODE
•Setting the test mode
During stand-by mode, press ON/STAND-BY button while pressing
down the button and X-BASS/DEMO button. then, press the CD
button to enter the test mode.
IL isn’t done
OPEN/CLOSE operation is using manual. IL isn’t done
<< >>,<< >>buttons make pick's slide possible. IL isn’t done
to page 2-3
<<PLAY>> key input.
C D T E S T
A
Do TOC IL. Do normal play.
When these following key is input into PLAY key, track num-
ber can be appoint directly.
<<MEMORY>>
key input.
<< 1>> key: Track 4
<< 2>> key: Track 9
<< 3>> key: Track 15
Adjustment result automatically will
display as below for each 2 sec:
a) "FOF_XXXX"
b) "TOF_XXXX"
c) "TBAL_XX"
d) "TGAN_XX"
f) "FGAN_XX"
g) "RFLS_XX"
––––––––
<<STOP>> key input.
STOP
explanation:
a) Focus off set = "FOF_XXXX"
b)Tracking off set = "TOF_XXXX"
c)Tracking balance = "TBAL_XX"
d)Tracking Gain = "TGAN_XX"
f) Focus Gain = "FGAN_XX"
g) RF level shift = "RFLS_XX"
VOL — Last memory
P. G E Q — F L AT
X-BASS — OFF
To cancel: Power OFF

XL-MP110H/MP110E
2 – 3
Sliding the PICKUP with<< >>, << >> button must only be
in STOP mode.
<<MEMORY/SET>> key input.
Laser ON.
<<MEMORY/SET>> key input.
Tracking OFF play at that specific point.
<<MEMORY/SET>> key input.
Tracking ON play from that specific point.
<<MEMORY/SET>> key input.
Adjustment result automatically will display as below for each 2 sec:
a) "FOF_XXXX"
b) "TOF_XXXX"
c) "TBAL_XX"
d) "TGAN_XX"
f) "FGAN_XX"
g) "RFLS_XX"
<<STOP>> key input.
STOP
explanation:
a) Focus off set = "FOF_XXXX"
b)Tracking off set = "TOF_XXXX"
c)Tracking balance = "TBAL_XX"
d)Tracking Gain = "TGAN_XX"
f) Focus Gain = "FGAN_XX"
g) RF level shift = "RFLS_XX"
VOL — Last memory
P. G E Q — F L AT
X-BASS — OFF
To cancel: Power OFF
A

XL-MP110H/MP110E
2 – 4
[3] Standard Specification of Stereo System Error Message Display Contents
(*) CHECKING:
If CD changer mechanism error is detected, 'CHECKING' will be display instead of 'ER-CD**'. 'ER-CD**' display will only be display when error had
been detected for the 5 th times.
Speaker abnormal detection and +B PROTECTION display
In case speaker abnormal detection or +B PROTECTION had occurred, the unit will automatically enter to stand-by mode and Timer indicator will
flashing as below.
Example:In case of speaker abnormal
BEFORE TRANSPORTING THE UNIT
The following process need to be taken after set tapering/parts replacement.
1. Press the ON/STAND-BY button to enter stand-by mode.
2. While pressing down the button and the X-BASS/DEMO button, press the ON/STAND-BY button. The Micro Computer version number will
be displayed as "AM******".
3. Press OPEN/CLOSE button until "WAIT"--> "FINISHED" appears.
4. Unplug the AC cord and the unit is ready for transporting.
Error Contents DISPLAY Notes
CD Pickup Mechanism Error. 'ER-CD01' PU-IN SW Detection NG.
CD Changer Mechanism Error. 'ER-CD**' (*) 10: CAM SW Detection NG during normal operation
11: CAM SW Detection NG during initialize process
20:TRAY SW Detection NG during normal operation
21:TRAY SW Detection NG during initialize process
CD DSP Communication Error. 'ER-CD31' DSP COMMUNICATION ERROR.
Focus Not Match/IL Time Over. 'NO DISC'
TUNER PLL Unlock.
FM MHz
PLL Unlock.
87.50
TIMER
LED OFF OFF OFF OFF
1 FRAME (REPEAT)
FLASHINGFLASHING
NO. 2 NO. 2
ON ON
NO. 1 : +B PROTECTION
NO. 2 : Speaker abnormal
NO. 1NO. 1

XL-MP110H/MP110E
3 – 1
AudioXL-MP110H/MP110EService ManualXLMP110H/EMarketE
CHAPTER 3. MECHANICAL DESCRIPTION
[1] REMOVING AND REINSTALLING THE
MAIN PARTS
1. TAPE MECHANISM SECTION
Perform steps 1 to 5, 11 of the disassembly method to remove the tape
mechanism.(see page 3-3,3-4)
1.1. How to remove the Record/Playback Head (See Fig. 1)
1. When you remove the screws (A1) x 2 pcs., the record/playback
head can be removed.
1.2. How to remove the Pinch Roller (See Fig. 2)
1. Carefully bend the pinch roller pawl in the direction of the arrow
<A>, and remove the pinch roller (B1) x 1 pc., in the direction of the
arrow <B>.
NOTE: When installing the pinch roller, pay attention to the spring
mounting position.
1.3. How to remove the Belt (See Fig. 3)
1. Remove the main belt (C1) x 1 pc., from the motor side.
2. Remove the FF/REW belt (C2) x 1 pc.
1.4. How to remove the Motor (See Fig. 4)
1. Remove the screws (D1) x 2 pcs., to remove the motor.
Figure 1
Figure 2
Figure 3
Figure 4
(A1)x2
ø2x9mm
Record/Playback
Head
Erase Head
Clutch Ass'y
Pinch Roller
(B1)x1 <A>
<B>
Pinch
Roller
Pawl
Pull
Main Belt
(C1)x1
FF/REW
Belt
(C2)x1
FF/REW
Clutch
Motor
(D1)x2
ø2.6x5mm
Motor
Clutch Ass'y

XL-MP110H/MP110E
3 – 2
2. CD MECHANISM SECTION
Perform steps 1 to 3, 14 of the disassembly method to remove the CD
mechanism.(see page 3-3,3-4)
2.1. How to remove the Optical Pickup (See Fig. 1)
1. Remove the screws (A1) x 2 pcs and shaft (A2) x 1 pc.
2. Remove the stop washer (A3) x 1 pc and gear (A4) x 1 pc.
3. Remove the optical pickup.
NOTE: After pulling out the optical pickup connector, wrap the tip of it
with conductive aluminium foil or the like to protect the optical
pickup from the static electricity.
2.2. How to remove CD Disc (See Fig. 2~6)
1. When CD is at play position, rotate reduction gear C clock-wise as
shown in Figure 2 until disk tray is at ‘STOCK’ position, then rotate
the gear further to eject the disk tray (Figure 6) so that CD can be
removed from the tray.
2. In another case, if CD mechanism is at tray No. 1 play position and
to remove CD located in tray No. 3, the procedure is as follows:
If the gear up down board is located at tray No. 1 position, then
rotate Reduction gear C clock-wise until Disc tray is at ‘STOCK’
position. Rotate reduction gear D clock-wise (Figure 3) to move the
CD mechanism to tray No. 3 position. This is confirmed by check-
ing the gear up down board position base on the marking as indi-
cated on the main chassis as shown in Figure 4.
• Usually changer is covered with top plate. As for reference pur-
pose, we exclude the top plate for easy viewing. (Figure 5,6)
Figure 6
CD Disc
CD At 'PLAY' position.
Disc Tray
Guide Tray
CD Disc
CD At 'STOCK' position.
CD Disc
Tray eject
Remove CD from tray.
Figure 5
Figure 1
Figure 4
(A1) x2
ø2.6 x5mm
CD
Mechanism
Stop Washer
(A3) x1
Optical Pickup
Gear
(A4) x1
Shaft
(A2) x1
Reduction gear D
Figure 3
Up Down
Reduction gear C
Front
Figure 2
Rear
Mark 1
(DISC 1)
(DISC 2)
(DISC 3)
(DISC 4)
(DISC 5)
Gear up down board
Mark 3 Mark 5
Mark 2 Mark 4

XL-MP110H/MP110E
3 – 3
[2] DISASSEMBLY
Note 1:
After removing the connector for the optical pickup from the connector,
wrap the conductive aluminium foil around the front end of the connec-
tor so as to protect the optical pickup from electrostatic damage.
Caution on Disassembly
Follow the below-mentioned notes when disassembling the unit and
reassembling it, to keep it safe and ensure excellent performance:
1) Take cassette tape and compact disc out of the unit.
2) Be sure to remove the power supply plug from the wall outlet
before starting to disassemble the unit.
3) Take off nylon bands or wire holders where they need to be
removed when disassembling the unit. After servicing the unit,
be sure to rearrange the leads where they were before disas-
sembling.
4) Take sufficient care on static electricity of integrated circuits and
other circuits when servicing.
STEP REMOVAL PROCEDURE FIGURE
1 Top Cabinet 1. Screw.............................(A1) x5 1
2 Side Panel (Left/
Right)
1. Screw.............................(B1) x8 1
3 CD Changer unit 1. Screw.............................(C1) x2
2. Hook...............................(C2) x2
3. Socket............................(C3) x1
4. Flat Cable.......................(C4) x1
2
4 Rear Panel 1. Screw.............................(D1) x8 2
5 Front Panel 1. Screw.............................(E1) x3
2. Flat Cable.......................(E2) x2
3. Socket............................(E3) x1
4. Hook...............................(E4) x2
2,3
3
6 Tuner PWB 1. Screw..............................(F1) x1
2. Socket............................(F2) x1
2
3
7 Main PWB 1. Screw.............................(G1) x2
2. Socket............................(G2) x4
2,4
4
8 Power PWB 1. Screw.............................(H1) x4 4
9 Terminal PWB 1. Screw..............................(J1) x1 4
10 Display PWB 1. Knob...............................(K1) x1
2. Screw............................(K2) x 8
3. Flat Cable......................(K3) x 1
5
11 Tape Mechanism 1. Screw.............................(L1) x 4 5
12 Jack PWB 1. Screw............................(M1) x 1 5
13 CD MP3 PWB
(Note 1)
1. Screw.............................(N1) x2
2. Flat Cable......................(N2) x 2
3. Socket............................(N3) x1
6
14 CD Mechanism 1. Screw.............................(P1) x4
2. Screw.............................(P2) x4
6
7
Figure 1
Figure 2
Figure 3
(A1) x2
ø3x12mm
(A1) x2
ø3x12mm
(B1) x2
ø3x10mm
(B1) x2
ø3x8mm
(B1) x2
ø3x8mm
(B1) x2
ø3x8mm
(A1) x1
ø3x12mm
Front Panel
Top Cabinet
Rear
Panel
Side Panel
(Left)
Side Panel
(Right)
(D1) x8
ø3x8mm
(F1) x1
ø3x8mm
(G1) x1
ø3x10mm
(E1) x1
ø3x10mm
(E2) x1
(C3) x1
(C4) x1
Front Panel
Rear Panel
Hook
(C2)x1
Hook
(C2)x1
Pull
Pull
CD Changer
Unit
Main PWB
Headphones
PWB
CD Servo PWB
(C1) x1
ø3x10mm
(C1) x1
ø3x10mm
(F2) x1
(E1) x2
ø3x10mm
Front Panel
Tuner PWB
Main PWB
Pull
(E2) x1
(E3) x1
Pull
Hook
(E4)x1
Hook
(E4)x1

XL-MP110H/MP110E
3 – 4
Figure 4
Figure 5
Figure 6
(G1) x1
ø3x8mm
(H1) x4
ø4x6mm
(J1) x1
ø3x8mm
(G2) x2
(G2) x2
Terminal PWB
Main PWB
Power PWB
(K2) x8
ø2.6x8mm
(L1) x4
ø3x10mm
(M1) x1
Special
(K3) x1
(K1) x1
Front Panel
Jack PWB
Cassette
Holder
Display PWB
Tape
Mechanism
(N1) x2
ø3x10mm
(N2) x2
(N3) x1
(P1) x2
ø3x10mm
(P1) x2
ø3x10mm
CD Changer
Unit
CD MP3 PWB
Figure 7
STEP REMOVAL PROCEDURE FIGURE
1Woofer/
Tweeter
1. Net Frame.................(A1) x1
2. Front Panel...............(A2) x1
3. Screw........................(A3) x2
4. Screw........................(A4) x4
8
Figure 8
(P2) x4
Special
CD Changer
Unit
CD Mechanism
Screwdriver
Net Frame
(A1)x1
(A3)x2
ø3x10mm
(A4)x4
ø4x16mm Woofer
Front Panel
(A2)x1
Tweeter

XL-MP110H/MP110E
4 – 1
AudioXL-MP110H/MP110EService ManualXLMP110H/EMarketE
CHAPTER 4. DIAGRAMS
[1] BLOCK DIAGRAM
+B5
+B5 +B5 +B10
+B5
+B8(SW_+5V)
+B7(A_+5V)
VIDEO/AUX
R
L
R
L
Q108
REC/PLAY
CLK
CE
DI
L
R
BIAS
MUTING
AC BIAS
L
L
R
R
R
L
TAPE
TUNER
CD
PB
CNP3
FROM CD SECTION
HEAD
ERASE
SWITCHING
SWITCHING
SWITCHING
BIAS
Q113
Q114
Q112
SWITCHING
OSC
BIAS
Q105
Q106
REC /P.B. HEAD
TAPE R-CH
L-CH
AUDIO PROCESSOR
LC75341
R
L
REC
R
L
R REC
L REC
SWITCHING L(TA)
R(TA)
/PLAYBACK AMP.
PLAYBACK AND RECORD
AN7345K
Q107
+B5
U
-20dBATT
17
3
1
2
2
7
18
4
21
13
16
9
23
2
21
13
12
14
16
11
1
4
9
10
15
3
24
12
15
11
718 8 23
7
5
+B4
H/N
P.B
REC
LD_+8V
CNS3
TO CD/MP3 SECTION
M_+8V
FOUT
ST FM
R
L
IF OUT
AM IN
FM IN
COVERAGE
AM BAND
TRACKING
AM
TERMINAL
ANTENNA 5.1V
FM IF
L341
BALUN
ANTENNA
AM LOOP
FM
+B
+B5
CL
AM IF
456kHz
10.7MHz
450kHz
DO DI CE
MO/ST
SWITCHING
FM/AM
PLL(TUNER)
LC72131
FM/AM OUT
R
L
FM/AM MPXIN
STEREO
AM RF IN
AM OSC IN
VSM
FM
VT
OSC
4.5MHZ
MO/ST
VCO
FM
DET
FM+B
GND
AM IF
FM IF DET./
LA1832S
AM MIX
OUT
FM FRONT END
AM OSC OUT
FM MPX./AM IF
1516
10
1220
3762
8
5
1
34
217
16242120
15
23
51
910
18
89542
7
117
622 11
17
13
14
12
XL-MP110H
Q601
Q602
IC601
JK690
CNS3
Q104
Q101-
IC101
L103
Q111 Q110
Q109
SO301
FE301 CF301 Q301
IC303
CF352
T351
CF302
CF351
ZD351
X351
IC302
Q360
X352
XT21
Q607
ICT21
LC72723
RDS DECODER
16
15
14
13
910
2
3
11
74
MPX IN VDDA XOUT
XIN
QT21
RST RDDA RDCL RDS-ID/ READY
VSSD
4.332MHz
TEST VSSA
VDDD
8
LOW PASS
FILTER
L354
Figure 4-1 BLOCK DIAGRAM (1/8)

XL-MP110H/MP110E
4 – 2
0
+B10
+B3
KIA7812AP
REGULATOR
VOLTAGE
VOLTAGE
VOLTAGE
KIA7810AP
REGULATOR
KIA7805AP
REGULATOR T2A L 250V
T2A L 250V
T4A L 250V
D842-D845
POWER
TRANSFORMER
RELAY
DRIVER
AC_RLY
P_IN
+B7(A_5V)
+B8(SW_+5V)
+B_PROTECT
+VCC
-VCC
GND
SP_RLY
SP DET
-VF
TO DISPLAY SECTION
TRANSFORMER
POWER
REGULATOR
VOLTAGE
UNSW_5.6V KIA78L05
VOLTAGE
REGULATOR
DRIVER
T4A L 250V
R-OUT
L-OUT
STK432-070
POWER AMP.
L
R
-B2
+B2
VF1
VF2
M971
-20dBATT
+B3
FAN MOTOR
HEADPHONES
SUB WOOFER
OUT-PUT
SPEAKER TERMINAL
M
7
1015
1
13
9
8
+B5
(SUB)
(MAIN)
T.F
A_+10V
LD_+8V
CTION
M_+8V
+B1
+B1
M_+13V
2
3
4
6
9
5
7
8
1
SW_5V
UNSW5.6
M_+13V
REC/PLAY
SP_DET
-20dB
VF1
-VF
VF2
AC_RLYCON
P_IN
+B_PROTECT
+B_PROTECT
D_GND
SP_RLY
T_BIAS
CLK
DI
CE
DO
25
24
23
22
29
28
27
26
21
20
19
18
17
16
15
14
13
12
11
10
RDS_READY
TUN_SM
RDS_RDCL
RDS_RDDA
RDS_RST
AC 230V,50 Hz
SUPPLY CORD
AC POWER
Q906
Q904
Q901
IC901
F802
IC854
Q841
Q801
Q850
IC855
F804
F803
IC851
IC852
IC853
D802 F801 PT801
JK953
JK701
SO901
RL914
Q905
RL841
RELAY
PT841
RELAY
CNP701B
L841
AC LINE
FILTER
Figure 4-2 BLOCK DIAGRAM (2/8)

XL-MP110H/MP110E
4 – 3
+B5
+B5 +B5 +B10
+B5
+B8(SW_+5V)
+B7(A_+5V)
VIDEO/AUX
R
L
R
L
Q108
REC/PLAY
CLK
CE
DI
L
R
BIAS
MUTING
AC BIAS
L
L
R
R
R
L
TAPE
TUNER
CD
PB
CNP3
FROM CD SECTION
HEAD
ERASE
SWITCHING
SWITCHING
SWITCHING
BIAS
Q113
Q114
Q112
SWITCHING
OSC
BIAS
Q105
Q106
REC /P.B. HEAD
TAPE R-CH
L-CH
AUDIO PROCESSOR
LC75341
R
L
REC
R
L
RREC
LREC
SWITCHING L(TA)
R(TA)
/PLAYBACK AMP.
PLAYBACK AND RECORD
AN7345K
Q107
+B5
UN
S
-20dBATT
17
3
1
2
2
7
18
4
21
13
16
9
23
2
21
13
12
14
16
11
1
4
9
10
15
3
24
12
15
11
718 8 23
7
5
+B4
H/N
P.B
REC
LD_+8V
CNS3
TO CD/MP3 SECTION
M_+8V
+
+B
_
F OUT
ST FM
R
L
IF OUT
AM IN
FM IN
COVERAGE
AM BAND
TRACKING
AM
TERMINAL
ANTENNA 5.1V
FM IF
L341
BALUN
ANTENNA
AM LOOP
FM
+B
+B5
CL
AM IF
456kHz
10.7MHz
450kHz
DO DI CE
MO/ST
SWITCHING
FM/AM
PLL(TUNER)
LC72131
FM/AM OUT
R
L
FM/AM MPXIN
STEREO
AM RF IN
AM OSC IN
VSM
FM
VT
OSC
4.5MHZ
MO/ST
VCO
FM
DET
FM+B
GND
AM IF
FM IF DET./
LA1832S
AM MIX
OUT
FM FRONT END
AM OSC OUT
FM MPX./AM IF
1516
10
1220
3762
8
5
1
34
217
16242120
15
23
51
910
18
89542
7
117
622 11
17
13
14
12
XL-MP110E
Q601
Q607
Q602
IC601
JK690
CNS3
Q104
Q101-
IC101
L103
Q111 Q110
Q109
SO301
FE301 CF301 Q301
IC303
CF352
T351
CF302
CF351
ZD351
X351
IC302
Q360
X352
LOW PASS
FILTER
L354
Figure 4-3 BLOCK DIAGRAM (3/8)

XL-MP110H/MP110E
4 – 4
+B10
+B3
KIA7812AP
REGULATOR
VOLTAGE
VOLTAGE
VOLTAGE
KIA7810AP
REGULATOR
KIA7805AP
REGULATOR T2A L 250V
T2A L 250V
T4A L 250V
AC_RLY NC
P_IN
+B7(A_5V)
+B8(SW_+5V)
+B_PROTECT
+VCC
-VCC
GND
SP_RLY
SP DET
-VF
TO DISPLAY SECTION
TRANSFORMER
POWER
REGULATOR
VOLTAGE
UNSW_5.6V KIA78L05
VOLTAGE
REGULATOR
DRIVER
T4A L 250V
R-OUT
L-OUT
STK432-070
POWER AMP.
L
R
-B2
+B2
VF1
VF2
M971
-20dBATT
+B3
FAN MOTOR
HEADPHONES
SUB WOOFER
OUT-PUT
SPEAKER TERMINAL
M
7
1015
1
13
9
8
+B5
(MAIN)
T.F
A_+10V
_
+8V
ON
+8V
+B1
+B1
M_+13V
2
3
4
6
9
5
7
8
1
SW_5V
UNSW5.6
M_+13V
REC/PLAY
SP_DET
-20dB
VF1
-VF
VF2
AC_RLYCON
P_IN
+B_PROTECT
+B_PROTECT
D_GND
SP_RLY
T_BIAS
CLK
DI
CE
DO
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
AC 230-240V,50 Hz
SUPPLY CORD
AC POWER
Q906
Q904
Q901
IC901
F802
IC854
Q801
Q850
IC855
F804
F803
IC851
IC852
IC853
D802 F801 PT801
JK953
JK701
SO901
RL914
Q905 RELAY
CNP701B
L841
AC LINE
FILTER
Figure 4-4 BLOCK DIAGRAM (4/8)

XL-MP110H/MP110E
4 – 5
M_+13V
SYSTE
M
MICROCOM
P
TAPE MECHANISM Ass'y (212)
CNP701A
CNP702
Q702
Q712
Q701
Q714 Q715
Q713
IC701
FL701
IXA058A
W
38394041424344454647484950
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81 82 83 84 85 86 87 88 89 90 91 9
2
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
8
7
6
5
4
3
2
1
T_SOL_B
SMUTE
T_FPSW
T_RUN_PULS
T_MOTOR
FPA
T1RUN
T_SOL
T_MOTOR
GND
T_SOL
T SOL B
T_MOTOR T_SOL_A/VOLLED VSS RESET ILLU_LED VDD NS_SW2 NS_SW1 DIST
T_BIAS
T_REC/PLAY
-20dBATT
SP_RLY
AC_RLY
S30
S20(DIST1)
S19(DIST2)
S18(DIST3)
S17(DIST4)
S16
S15
S14
S13
S12
S11
VDD2
VLOAD
S10
S8 S9 S7 S6 S5 S4 S3 S2 S1
G11 G10
G9
7
1
4
5
2
3
6
CE
DO
CLK
DI
+B_PROTECT
H : 29PIN
H ONLY
H ONLY
E : 25PIN
D_GND
S_MUTE
REC/PLAY
T_BIAS
A+10V
M_+13V
SW_5V
SP_DET
SP_RLY
-20dB
VF2
VF2
-VF
-VF
P_IN
VF1
UNSW5.6 +B
+B
+B
+B
+B
+B
+B
+B
+B
+B
AC_RLY(H ONLY)
AC_RLY(H ONLY)
TO MAIN PWB
7
1
4
5
6
2
3
R. REC
F. REC
+MTR
-COM
M+
-
END SW
+SOL
N.C. (OP PACK)
SOLENOID
TAPE
MOTOR
46474849
RDS_RDCL RDS_RDDA RDS_READY RDS_RST
89 101112131415161718192021222324252627282930313233343536373839404142434445
F2 F2
NP NP NP NP NP NP NP NP
P20 P19 P18 P17 P16 P15 P14 P13 P12
P11 P10 P09 P08 P07 P06 P05 P04 P03 P02 P01
G11 G10 G09 G08 G07 G06 G05 G04
FL DISPLAY
RDS_RDCL
RDS_RDDA
RDS_READY
RDS_RST
Figure 4-5 BLOCK DIAGRAM (5/8)
