Shehds 7X40W User manual

1
-Maintenance
1.Please keep the light in dryness and avoiding use in wet place.
2.Using intermittenlly can be extended the life.
3.Attention to clean the fan and lens usually in order to get the ventilating effects and lighting effects
better.
4.Please do not wipe the crust using organic menstruum for avoid to damaged the product.
-Statement
The product has well capability and intact packing when leave factory,All of the user should comply
with above warning item and manual ,any misuse cause of the damages are not included in our
guarantee,and also can’t be responsible for any malfunction & problem owing to ignore the manual.
Please forgive that we will not be notice for technical change
-Attention Item
1.For guarantee the life of product,please do not put it on the wet place and not use it the place over
40 degree.
2.Please don’t lay the product on the un-fixable or shakable place.
3.Ask for the professional to maintain the product in order to avoid the danger of get an electric
shock.
4.Power supply should not be changed over +&-10% while the light is using,it will be decreased the
life of lamp if the power is too high,but it will be influenced the luminosity if the power is too low.
7X40W LED BEAM WASH MOVING HEAD

2
5.After power off,if it is need used again,please cool down over 20 minuter.
6.Please look round the manual for ensure the product can be used normally.
-Display Control Instruction
Welcome to use our light.The light uses energy-saving LED,long Product life,shockproof,dustproof,
DMX receiver and self-running feature, which can produce a variety of vivid lighting effects,easy to
operate, suitable for all types of entertainment decoration,architectural lighting industry.
Instructions:Press the function key A cycled out the eight different function effects,digital tube first
two digits on behalf of which the current function(see menu).The last two digits represent the
functions in which the address code or speed parameters.Press the B or C key to modify the
parameter values.Press the D key to confirm.
-Product Introduction
* Power Supply:AC90--275V,50--60HZ
* Power consumption:350W
* Fixing lamp:LED 7*40W OSRAM RGBW4IN1
* DMX-Control-channels:15 CH
* Shuttle:Flash rate:0--25HZ & random
* Control mode: DMX,M/S,Sound active
* Dimmer:0-100% mechanic dimmer
* Long Lifespan LEDs(more than 60,000 hours)
* N.W.:30kg
* Page size:38*31*46cm

3
Display Control Instruction
1. Add (DMX512 address setting page menu)
(1) DMX address this option is used to set the DMX communication address. Press the "up" key to
increase the address number, and the "down" key to decrease the address number. After selecting the
address, press "enter" to save and exit.
2. Set (this option enters system setting)
(1) Run mode this option is used to set the working mode of the lamp body. Press "enter" to enter the
setting, press "up" or "down" to select the working mode. The working mode successively includes "DMX" /
DMX512 mode, "autol1" / self running mode 1, "autol2" / self running mode 2, "sound" / s voice control mode.
After selecting the working mode, press "enter" to save and exit.
(2) Channel mode this option is channel setting. Press "enter" to enter the setting, press "up" or
"down" to select channel mode.
(3) Invert LCD this option is to set the LCD font reverse direction of the display panel. Press "enter" to enter
the setting, press "up" or "down" to select the switch.
(4) Invert pan \ invert tilt this option is to set the X / Y axis in the reverse direction. Press enter to
enter the setting, up or down to select whether the X / Y axis is in the reverse direction. Select on to indicate
that the X / Y axis is in the reverse direction, off to indicate that the X / Y axis is not in the reverse direction.
Press enter to save the exit.
(5) Pan tilt swap this option is the X / Y vertical switch setting, press "enter" to enter the setting, press
"up" or "down" to select the X / Y axis vertically, select "on" to indicate the X / y vertical opening, select "off"
to indicate the X / Y axis vertical closing, press "enter" to save and exit after selecting the direction.
(6) Encoder this option is the X / y error correction switch. Press "enter" to enter the setting, press "up"
or "down" to select, select "on" to indicate that the X / y error correction function is on, select "off" to
indicate that the X / y error correction function is off, and press "enter" to save and exit.
(7) No signal this option is whether to keep the previous working state when the lamp has no signal.
Press "enter" key to enter the setting, press "up" key or "down" key to select the lamp state. Select "clean"
to clear the previous working state when the lamp has no signal input, and automatically restore the initial
state when the power on reset is completed. Select "keep" to indicate that the lamp has no signal No. will
remember the previous working state when entering, keep the previous working state unchanged, and press

4
"enter" to save and exit.
(8) Screen saver this option is the LCD backlight long light switch. Press "enter" to enter the setting,
press "up" or "down" to select the LCD backlight status. Select "on" to indicate that the LCD backlight is off
15 seconds after the LCD screen protection takes effect, select "off" to indicate that the LCD screen protection
is off, and the LCD backlight will always be on. Press "enter" to save and back Out.
(9) Language this option is to display Chinese \ English switch. Press enter to enter the setting, press up
or down to select, select en for English display, Chinese for Chinese display, and press enter to save and exit.
(10) Load default this option is the lamp reset switch. Press "enter" to enter the setting, press "up" or
"down" to select, select "OK" to press "enter" to enter the reset state, select "Cancel" to press "enter" to
exit the page.
3. Check (lamp enters manual mode)
(1) This option is to set the scene parameters of the lamp body. Press "enter" key to enter into saving. After
power failure, the next power on can restore the previous power on state.
4. Calib (system calibration)
(1) Motor calibration system internal setting XY fine adjustment and initial
password of light bead white balance parameter 0000 press "enter" to
enter the setting.
Change code change password (press "enter" to enter the setting, press
"up" or "down" to select password value, press "enter" to save and exit,
and the system calibration password change is completed)
5.Test (lamp test mode)
6. Note (system information)
System info
M. Firm: v0.00 motor board
D. Firm: v1.01 display board
Error: USART reset failed: XY communication
7. Reset
After the user chooses to reset, wait for 3 seconds, and the lamp body will
reset.

5
DMX Channel Summary-15 Channels Mode
Channel
Function
Value
Function
CH1
Pan
0-255
Pan 0-540°
CH2
P fine
0-255
Pan Fine tuning 16bit
CH3
Tilt
0-255
Tilt 0-270°
CH4
T fine
0-255
Tilt Fine tuning 16bit
CH5
P/T Speed
0-255
Pan Tilt Speed
CH6
Zoom
0-255
Light spot from large to small
CH7
Total dimming
0-255
Gobo&Wash LED dimming
CH8
Strobe
4-99
Synchronization Strobe
100-149
Divide equally Strobe
150-199
Flash
200-249
Random strobe
CH9
Red
0-255
Red dimming
CH10
Green
0-255
Green dimming
CH11
Blue
0-255
Blue dimming
CH12
White
0-255
White dimming
CH13
Micro
0-255
Micro Color
CH14
Color
temperature
10-255
From high to low
CH15
Reset
201-205
Reset
