Shenzhen Jumper Medical Equipment JPD-FR400 User manual
1
JPD-FR400
Infrared Thermometer
Instruction Manual
Shenzhen Jumper Medical Equipment Co., Ltd
Manual Ver.: 1.0
Issuing Date: 2016/09/12
0482
2
Introduction
Thank you for choosing the Dual-mode Digital Infrared Thermometer of
Jumper Medical, Infrared thermometer for short.
The infrared thermometer JPD-FR400 can be used to read the body
temperature by measure the ear and forehead temperature, which is
suitable for adult and children(ear test mode only for the child above 3
months).
Please read the instructions carefully before using the product, and put it
in a safe and secure place for reference.
Contents
1. The advantages of infrared thermometer JPD-FR400 ............1
2. Necessary safety instructions...................................2
3.Instructions for product designs..................................3
4.How to measure the forehead temperature........................ 4
5.How to measure the ear temperature.............................4
6.Instructions for display and operation.............................6
7.Cleaning and Disinfection.......................................9
8.Maintenance ..................................................9
9. Replace the battery. ..........................................10
10.Troubleshooting ............................................. 10
11. Technical specifications......................................11
12. After-sale service ...........................................12
13. Security type ............................................... 13
14. Authorized European Representative: .........................13
15. Symbols ................................................... 13
16.Declaration ................................................. 13
17. Appendix A: EMC Information-Guidance and Manufacture‟s
Declaration ....................................................14
1
1. The advantages of infrared thermometer JPD-FR400
Multiple use (measurement of forehead temperature and ear
temperature)
Dual-mode design, you are free to take body temperature by detecting
the infrared heat given off by the forehead or eardrum,The Measuring
range of the thermometer in forehead /ear mode is between 32.0°F -
212.0°F (0 °C- 100 °C) .
The product consists of ABS plastics, temperature sensor, Infrared
temperature measuring element, microcomputer controlled circuit, LCD ,
backlight and buzzer.
Convenient for use
●Special ergonomic design to facilitate operation.
●No inconvenience would be caused to your daily life. It‟s available for
measurement when your children‟s sleeping.
●It provides comfortable user experience compared with anus
thermometer for children, rapid reading and simple operation compared
with mouth thermometer.
Memory recall
A maximum of 20 previous readings is available to help you track the
changes of your body temperature.
Safe and hygienic
●Compared to mercury thermometer, there is no danger of breaking the
glass or swallowing mercury.
●It is totally safe for children to use.
Fever warning
When the reading exceeds 37.5℃/99.5℉, this product shall warn the
user that he/she may have a fever by 7 rapid and short rings with LCD
flicker.(For normal forehead temperature, the signal is long ring with LCD
no flicker)
Extensive clinical data of hospital
The cooperation with designated hospitals is subjected to precise clinical
verification, with the support of extensive clinical data and professional
medical experts.
Application scope
The thermometer takes human body temperature for clinical or
household use. It applies to all age groups and those who are suffering
from a fever.
2
Operating principle
The infrared temperature sensor detects infrared energy emitted by the
eardrum. A built-in lens focuses the collected energy, which is then
converted into a temperature reading by the thermopiles and
measurement circuits.
2. Necessary safety instructions
●The device is not used for newborn baby.
●The device is not continuous monitoring device.
●JPD-FR400 is not waterproof. Please do not douse it into water or other
liquids. Cleaning and disinfection procedure shall be in comply with the
instructions specified in [cleaning and storage]
●Please do not use the product if the temperature sensor or the
Dual-mode infrared thermometer shows any sign of damage. Do not try
to repair the product if it is damaged. Please contact the nearest Jumper
Customer Service.
●JPD-FR400 consists of precision parts with high quality. Please prevent
the product from falling off. Protection shall be provided for no intense
shock and vibration. Do not twist the Dual-mode infrared thermometer
and the temperature sensor.
●Operating Conditions:
Temperature: 10C to 40C
Humidity: 15-95% RH, non-condensing
Atmospheric pressure: 86kPa to 106kPa
●Storage and Shipping Conditions:
Temperature: -20C to 55C
Humidity: 0-95% RH, non-condensing
Atmospheric pressure: 50kPa to 106kPa
