1. Brief introduction
This Microsound is a recording voice reminder with human body induction detection technology. When detecting
the human body passing it will give warm prompt, reminding and greetings at the first time. It has large induction
range, sensitive trigger and so on. There is no need to have manual operation for the intelligent triggering.
This product can be used for smart doorbell, welcome gate, daily reminder, family warm reminder and other
occasions.
2. Features
Small and exquisite, good sound recording quality.
Recording format: MP3, sample rate 48KHz, bit rate 32Kbps.
Human body induction, induction distance within 4 meters.
Two levels of volume for adjustment.
Standard 4Mbyte SPI-flash, available to replace capacity according to customer requirements.
Can record voice directly by microphone.
Using three AAA 1.5V batteries for power supply.
Built in 8 euro 1 watt speaker.
3. Electrical parameters
Working voltage
DC3.6-5V
Working Current
Standby state
≤90uA
Recording state
≤40mA
Playing state
≤200mA
Audio recording format
MP3
Bit rate: 32Kbps
Sample rate:48KHz
Speaker
8Ω/1W
Recording duration(for reference):
FLASH capacity(bit)
1M
2M
4M
8M
16M
32M
Recording duration(s)
25
50
105
210
430
900

Shenzhen Waytronic Electronics Co., Ltd. MicroSound V16.00
4. Panel introduction
1
4
2
5
3
6
7
Note: when recording, shall start to record what you need after hearing a “di” sound.During its recording, long
press the recording button all the time. To save the recorded voice completely, after finishing recording, wait a
moment,then release the recording button.
5. Installation and user guide
5.1 Installation Requirements
1) Shall be installed indoor, not recommended for outdoor applications.
2) Do not be installed near the high-power electrical appliances and switching devices.
3) Do not be installed under or next to the air conditioner.
4) Do not be installed in the environment with large temperature change. There shall be no heat source in front of
the detection direction. Otherwise, the machine will give false alarm.
No.
Function
Function introduction
1
Inductive probe
Human body inductive probe
2
Indicator light
Recording and playing indicator
3
Button A
Long press 3s, start to record when hearing a “di” sound; release
button and stop recording hearing a “di” sound.
4
Power/volume switch
To the bottom is switch off; to the middle is switch on and one
level volume; to the top is the 2nd level volume.
5
Recording hole
Microphone recording hole
6
Button B
Short press to play; press again to stop.
7
Speaker
Sound output

Shenzhen Waytronic Electronics Co., Ltd. MicroSound V16.00
5.2 Installation method
1) Can hung on the bracket or flat screw through a mounting hole on the back.
2) Can use binding tape to fix it on the column through the middle of hole at the back.
3) Can use double-sided adhesive tape or glue to stick on the wall or other flat surface.
6. Button function introduction
Button A: after switch on, short press is to trigger to play the recording voice. 3 seconds later after finishing the
recording voice play, only short press again and it can play again. It is invalid to long press.
Button B: after switch on, long press button A for 3 seconds, starting to record after a dropping sound. Then
short press button A again to stop recording, two dropping sounds. If there is distortion, please keep a little further
from the voice source or turn down the volume, recording again.
7. Induction triggering
After switch on and finishing recording, after initial power up, 10~25S later it can trigger to play. After playing for
3s, it will trigger again.
8. Product List
No.
Name
Quantity
Remark
1
Main body
1
Standard configuration
2
Packaging box
1
Standard configuration
3
Packaging bag
1
Standard configuration
4
AAA battery(1.5V)
3
Optional configuration
5
One shelf and one hanger for a set
1
Optional configuration
Product name
Version
Introduction
Remark
MicroSound
series of voice
prompters
(built-in 8ohm
0.5W speaker)
Light/ body induction
(WTV020-S)
Replace voice via USB downloader. Built-in SPI
FLASH can support 64Mbit (standard 8Mbit) at
most for voice memory. Voice length can not
exceed 2000s.
Small and
exquisite, easy
to carry and
install.
Light/ body induction
(OTP)
Can not replace voice. Two levels of volume can
be adjusted. Biggest voice length is 35s, 65s,
80s.
Light/ body induction
(WT5001)
Support SD card for voice replacement. Can
save even power off. Built-in SPI FLASH can
support 64Mbit(standard 16Mbit) at most for
voice memory. Built in 8ohm 1W speaker.
Body induction and
direction identification
Can identify the direction of movement. Can set
voice in different direction
Note:
1. WTV020-Sversion support WAV audio with 6-22Ksample rate.
2. WT5001 version support mp3 format. The bit rate is 16-320Kbps.
