GST DC-M9416 Series Assembly instructions

© 2017 United Technologies Corporation 1 / 3 P/N 30310841-EN • REV 001 • ISS 27MAR17
DC-M9416 Series Ceiling
Mount Sounder Strobe
Installation Sheet
Description
The DC-M9416 Series Ceiling Mount Sounder Strobe is a fire alarm
notification appliance that is designed for mounting on indoor ceilings
and walls. See Table 1 for a list of model numbers.
Table 1: Models
Description
Model number
Sounder strobe,
15 to 95 multi-
cd, white, with FIRE marking
DC-M9416W
Sounder strobe,15 to 95 multi
-
cd, red,
with FIRE marking DC-M9416W
Field-configurable jumper options are available for selecting the
desired dB output, temporal or steady sound output, and strobe signal
output.
The sounder strobe includes a field-configurable switch for selecting
the desired candela output. The candela output setting is locked in
place and remains visible after final installation.
This strobe features an enhanced synchronization circuit to comply
with the latest requirements of UL 1971 Signaling Devices for the
Hearing Impaired.
Synchronized operation requires that you connect the DC-M9416
Series Ceiling Mount Sounder Strobe to a NAC output set for Synch
Mode, or to a separate DC-M9410 Signal Synchronization Module.
Installation
Install and wire this device in accordance with applicable national and
local codes, ordinances, and regulations.
WARNING: Electrocution hazard. To avoid personal injury or death
from electrocution, remove all sources of power and allow 10 minutes
for stored energy to discharge before installing or removing equipment.
Caution: Electrical supervision requires the wire run to be broken at
each terminal. Do not loop the signaling circuit field wires around the
terminals.
To install the sounder strobe:
1. Remove the cover by depressing the tab on the side of the unit
with a small screwdriver. Turn the cover counterclockwise to
release.
2. Set the sounder signal, sound output level, and strobe signal to the
desired settings. See Figure 1.
3. Connect the strobe terminals to the signal circuit field wiring. You
must observe polarity for the unit to function properly. See
Figure 3.
4. Slide the candela switch to the desired candela output (95, 115,
150, or 177 cd) by aligning it with the indicator below the switch.
See Figure 2.
5. Mount the unit onto a compatible electrical box. See Figure 4.
6. Replace the cover by positioning the alignment arrows together
and rotating the cover clockwise.
7. Test the unit for proper operation.
Figure 1: Sounder and strobe settings
(1) JP1: Sounder signal jumper: Cut to change from temporal to
steady
(2) JP2: Strobe signal output: Cut to change from 1 flash per second
(public mode) to temporal (private mode)
(3) JP3: Sounder sound output: Cut to change from high dB to low dB
Note: If the strobe is set to temporal (private mode), this device is no
longer UL 1971 but is still UL 1638 Listed.
Figure 2: Candela switch
(1)
Candela switch (2) Indicator
JP3
JP1
JP2
(1) (2) (3)

2 / 3 P/N 30310841-EN • REV 001 • ISS 27MAR17
Wiring
Figure 3: Wiring Diagram
(1) From NAC output
(2) To next appliance, EOLR, or return to source
Note: Signal polarity is shown in the alarm condition.
Figure 4: Mounting diagram
Figure 5: UL 1971 minimum light output (% of rating vs. angle)
(1) Angle
(2) Percentage of rated output
Note: Horizontal and vertical outputs have the same pattern
Table 2: Strobe operating current in RMS (A)
15 cd 30 cd 75 cd 95 cd
VDC
0.147 0.190 0.316 0.372
VFWR
0.189 0.253 0.417 0.451
VDC = Volts direct current, regulated and filtered
VFWR = Volts full wave rectified
Note: Operating currents shown above were measured by UL at
16 VDC and 16 VFWR.
Table 3: Sound level output (dBA)
Signal
VDC High db Low db
Temporal
16 79.8 75.0
24 83.3 78.0
33 85.0 80.9
Steady
16 83.2 79.3
24 85.4 83.0
33 87.8 85.9
UL464: Sound level output at 10 ft. (3.05 m) measured in a reverberant
room
Table 4: Audible directional characteristics (horizontal pattern)
Angle (°) [1]
Sound output (dBA) [2]
90 (Ref)
0 (Ref)
75
and 115 −3
70 and 120
−6
[1] Angles are measured from a perpendicular axis; positive angles to
the right.
[2] Peak output at regulated 24 VDC, set for temporal tone.
Table 5: Audible directional characteristics (vertical pattern)
Angle (°) [1]
Sound output (dBA) [2]
90 (Ref)
0 (Ref)
65 and 135
−3
55 and 140
−6
[1] Angles are measured from a perpendicular axis; positive angles are
up.
[2] Peak output at regulated 24 VDC, set for temporal tone.
(1) (2)
100
95 90 85 80 75 70 65
60 55 50 45 40 35
30 25 20 15 10
5 0 5
10 15
20 25 30 35 40 45
50 55 60 65 70 75 80
85 90 95
100
0510 15 20 25 30 35 40 45505560
65
70
75
80
85
90
-5
-10
-15
-20
-25
-30
-35
-40
-45
-50
-55
-60
-65
-70
-75
-80
-85
-90
1
2

P/N 30310841-EN • REV 001 • ISS 27MAR17 3 / 3
Figure 6: Light output profile
Maintenance
Caution: To maintain the required agency listings, do not change
factory applied finishes.
This unit is not serviceable or repairable. Should the unit fail to
operate, contact the supplier for replacement.
Perform a visual inspection and an operational test twice a year or as
directed by the local authority having jurisdiction.
Specifications
Voltage
Regulated 24 VDC, 24 VFWR
Strobe operating
current
See Table 2
Light output
Selectable at 15, 30, 75, and 95 cd
Synchronization
Meets UL 1971 requirements. Maximum
allowed resistance between any two devices
is 20 Ω. Refer to specifications for the
synchronization control module, this strobe,
and the control panel to determine allowed
wire resistance.
Sound level output
See Table 3
Default settings
Signal
Sound level output
Strobe signal
rate
Temporal
High dB
1 flash per second (fps)
Wire size
12 to 18 AWG (0.75 TO 2.50 mm²)
Compatible electrical
boxes
4 in. square electrical box, 2-1/8 in. deep
(no extension ring)
Operating environment
Temperature
Relative humidity
32 to 120°F (0 to 49°C)
0 to 93% noncondensing
Regulatory information
UL rating
Regulated 24 DC and 24 FWR [1]
Environmental
class
UL: Indoor, Dry
N
orth American
standards
UL 464, UL 1638, and UL 1971
[1] This device was tested to the regulated 24 DC/FWR operating
voltage limits of 16 V and 33 V. Do not apply 80% and 110% of these
values for system operation.
Contact information
For information or questions, please contact:
Gulf Security Technology Co., Ltd.
No. 80, Changjiang East Road,
QETDZ, Qinhuangdao, Hebei, P. R. China 066004
Tel [phone]
Fax [phone]
[email protected]
www.gst.com.cn
