Shimano HP-NX10 Operating instructions

If the handlebar still moves after the
ring has been turned
counterclockwise, turn the ring again
while moving the handlebar slightly
until it locks.
Ring
STOP
1
Center of frame
METHOD OF USE
Moving the ring to “STOP” when parking the bicycle
Before riding the bicycle, check that the ring is turned to the
“FREE” side (in the clockwise direction) as far as it will go and
that the red “ ” mark is aligned with the center of the frame.
When the ring is in this position, the handlebar should turn
smoothly.
If you try to ride the bicycle while the ring is turned to the
“STOP” position, it will not be possible to turn the handlebar in
the normal way, and a serious accident may result.
The handlebar will also not turn in the normal way while the
ring is set to somewhere between the “FREE” and “STOP”
positions. If you try to ride the bicycle with the ring in this
condition, a serious accident may result.
Never turn the ring to the “STOP”. position while riding, as this
will stop the handlebar from turning normally, which could
cause a serious accident.
Do not hang any luggage in the area of the handlebar while
riding, as there is the danger that the luggage might touch the
ring and move it away from the “FREE” position and toward
the “STOP” position.
Avoid putting a child’s seat forward of the bicycle seat, as the
child might accidentally touch the ring while sitting in this seat.
Do not leave the bicycle alone while a child is sitting in the
child’s seat‚ otherwise the bicycle may fall over and serious
injury to the child may result.
Make sure you fully understand how the ring operates before
you ride the bicycle. If you have any questions regarding
operation, please contact your nearest bicycle shop.
WARNING
The handlebar stopper is activated by turning the ring to the “STOP”
position (counterclockwise). In this condition, the handlebar will turn if you
force it to turn, but it will make a cracking sound. Never ride the bicycle in
this condition, as it is extremely dangerous.
HP-NX10 Handlebar stopper
SERVICE INSTRUCTIONS
Before use‚ read these instructions carefully‚ and follow them for correct use.
SI-9470A
The handlebar can be unlocked by turning the ring to the “FREE” position
(clockwise). Check that the red “ ” mark is aligned with the center of the
frame and that the handlebar turns smoothly before riding the bicycle.
Turn the ring clockwise
as far as it will go.
2
Check that the
handlebar turns
smoothly.
Red “ ” mark on ring
FREE
Moving the ring to “FREE” before riding the bicycle
t

These service instructions are
printed on recycled paper and
can be recycled again.
Jun.1998 by Shimano Inc. PIT. SZK. Printed in Japan
C
These service instructions explain how to use and maintain the Shimano
bicycle parts which have been used on your new bicycle. For any questions
regarding your bicycle or other matters which are not related to Shimano parts‚
please contact the place of purchase or the bicycle manufacturer.
Please note: Specifications are subject to change for improvement without notice. (English)
