SB-5688Kp
8x8 HDMI Matrix Routing Switch w/ Full EDID Management/Learning
UHD 4K2K Capable
INSTRUCTION MANUAL
IMPORTANT WARRANTY INFORMATION.
If you remove the HDMI screw posts, you must use the provided HDMI Locking Post replacement
screws to keep the internal HDMI jack secure. Removing the HDMI screws without installing
the HDMI Locking Post replacement screws will void your warranty.

SAFETY INFORMATION
1. To ensure the best results from this product, please read this manual and all other documentation before operating your equipment.
Retain all documentation for future reference.
2. Follow all instructions printed on unit chassis for proper operation.
3. To reduce the risk of re, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid.
4. Make sure power outlets conform to the power requirements listed on the back of the unit. Keep unit protected from rain, water and
excessive moisture.
5. Do not attempt to clean the unit with chemical solvents or aerosol cleaners, as this may damage the unit. Dust with a clean dry cloth.
6. Do not use the unit if the electrical power cord is frayed or broken. The power supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords and plugs, convenience
receptacles, and the point where they exit from the appliance.
7. Do not force switched or external connections in any way. They should all connect easily, without needing to be forced.
8. Always operate the unit with the AC ground wire connected to the electrical system ground. Precautions should be taken so that the
means of grounding of a piece of equipment is not defeated.
9. AC voltage must be correct and the same as that printed on the rear of the unit. Damage caused by connection to improper AC
voltage is not covered by any warranty.
10. Turn power o󰀨 and disconnect unit from AC current before making connections.
11. Never hold a power switch in the “ON” position.
12. This unit should be installed in a cool dry place, away from sources of excessive heat, vibration, dust, moisture and cold. Do not use
the unit near stoves, heat registers, radiators, or other heat producing devices.
13. Do not block fan intake or exhaust ports. Do not operate equipment on a surface or in an environment which may impede the normal
ow of air around the unit, such as a bed, rug, carpet, or completely enclosed rack. If the unit is used in an extremely dusty or smoky
environment, the unit should be periodically “blown free” of foreign dust and matter.
14. To reduce the risk of electric shock, do not remove the cover. There are no user serviceable parts inside. Refer all servicing to
qualied service personnel. There are no user serviceable parts inside.
15. When moving the unit, disconnect input ports rst, then remove the power cable; nally, disconnect the interconnecting cables to
other devices.
16. Do not drive the inputs with a signal level greater than that required to drive equipment to full output.
17. The equipment power cord should be unplugged from the outlet when left unused for a long period of time.
18. Save the carton and packing material even if the equipment has arrived in good condition. Should you ever need to ship the unit,
use only the original factory packing.
19. Service Information Equipment should be serviced by qualied service personnel when:
A. The power supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the equipment.
C. The equipment has been exposed to rain.
D. The equipment does not appear to operate normally, or exhibits a marked change in performance.
E. The equipment has been dropped, or the enclosure damaged.
THIS SAFETY INFORMATION IS OF A GENERAL NATURE AND MAY BE SUPERSEDED BY INSTRUCTIONS CONTAINED WITHIN THIS MANUAL.

CONTENTS
INTRODUCTION & CONTENTS ...................................1
FEATURES.......................................................................2
SPECIFICATIONS............................................................3
FRONT PANEL ............................................................... 4
BACK PANEL .................................................................. 8
REMOTE CONTROL ..................................................... 9
EDID FUNCTIONS ........................................................ 11
TYPICAL APPLICATION .............................................. 14
IR EXTENDER .............................................................. 15
ETHERNET ................................................................... 16
RS-232 PROTOCOL .................................................... 17
INTRODUCTION
The SB-5688Kp is based on HDMI standards and supports full
resolution HDMI video with (7) embedded EDID. High Denition
Digital signals can be selected and distributed to any of the (8)
Inputs to the (8)+(1) preview outputs. The switcher is certied
as being fully CEC and HDCP 1.3 compliant with HDMI 1.4a,
4K2K@30Hz, DVI 1.0, 3D formats and a wide frequency range
of 25MHz ~ 340 MHz so there is no signal degradation. Full HD
supports UXGA/WUXGA/DVI 1920x1200 resolutions to any HD
display. The EDID management can be selected between (7)
di󰀨erent modes. Control is provided via front panel push buttons,
IR remote, RS- 232 or TCP/IP (not a web-browser). A RS-232
Windows GUI interface is provided for matrix routing control
(Windows only).
PACKAGE CONTENTS
Check that you have the following components;
• SB-5688Kp Matrix Switcher
• RS-232 V2.0 / Ethernet V1.0 Protocol Instructions
• IR Remote Control (SW-5688K)
• 19 inch Ear mount bracket (Part # 2U-440L)
• SB-100 IR Extender Receiver Set
• CD Contents: Manual, Windows GUI, ISP V1.0 Windows driver
• RS-232 Cable 6.5 feet (2M)
• HDMI Locking Post Replacement Screws
• Users Guide
• Power Supply: Worldwide Universal 100~240 VAC, AC 50/60Hz
• Optional: SB-100C IR Extender Receiver Cable (6.5ft (2M))
1
4K2K HDMI MATRIX SWITCHER SERIES
Thank you for purchasing the SB-5688Kp 4K2K HDMI Matrix Routing Switch. You will nd this unit easy to install and highly
reliable but it is essential that you read this manual thoroughly before attempting to use 8x8 4K2K HDMI Matrix switcher.
TABLE OF CONTENTS
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the
PSU if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
su󰀩cient space for air to circulate around the unit.
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. We assume no responsibility for any
infringements of patents or other rights of third parties which may
result from its use.
We assume no responsibility for any inaccuracies that may be
contained in this document. We make no commitment to update
or to keep current the information contained in this document.
We reserve the right to make improvements to this document
and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means
— electronic, mechanical, magnetic, optical, chemical, manual,
or otherwise — without express written permission and consent
© Copyright 2021. All Rights Reserved.
Version 1.2 JUNE 2021
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may
be trademarks of the companies with which they are associated.

FEATURES
• (8) HDMI source devices matrix switched to (8) HDMI+ (1) preview output destinations
• HDMI digital video w/ embedded HDCP and DVI formats and CEC/HDCP 1.3 compliant
• Worldwide control EDID modes for HDMI full 4K2K (24/30Hz) HD video resolutions
• Wide frequency range of 25MHz ~ 340MHz, Support HDMI 4K2K, 1.4a 3D formats
• Wide range of HD resolutions from PC XGA to WUXGA 1920x1200 and HDTV/DTV HDMI resolutions 480i/480p, 576i/576p, 720p,
1080i/p & 4K2K (24/30Hz)
• Compatible with all HDMI source devices, PC monitors, Plasma HD displayd, HDTV and audio receivers or audio ampliers
• Digital video TMDS formats resolutions up to 4K2K with Deep color 36-bit
• Using the build-in booster, each HDMI Output port is capable of driving cable lengths for 1080p up to 98 feet (30M) & 4K2K up to 66
feet (20M)
• Digital Audio Support: Dolby TrueHD, Dolby Digital, Dolby Digital Plug/ex, DTS, DTS-HD, DTS-HD Master, DTS-EX PCM, PCM2,
LPCM2
• Various User Interface Controls:
• Windows based GUI control via RS-232 interface 2000/XP/WIN7-32/WIN7-64/WIN8
• Front panel push buttons
• IR wireless remote control
• Ethernet switch control
• Third party RS-232 control (via simple ASCII)
• Supports (7) world wide control function keys:
• Full function front panel controls: ALL / OFF / EDID / LOCK / RECALL / MEMORY / ENTER
• Supports EDID Modes:
• a. Embedded EDID Modes: FSS/ H24-3D/ H24-3D-M/ H36-3D/ H36-3D-M/ 4K2K-3D / DVI-D 1920x1200-60Hz
• b. External Modes: Learning mode-1 (Single Learning) & Learning mode-2 (Multiple Learning)
• Automatic scanning input & output status via LCM show on front panel
• Supports IR Remotes and IR Extenders for distances up to ~984 feet (300M) Maximum
• Supports Universal power adaptor AC100V~AC240V, 50/60Hz
The switcher will remember that last state during a power cycle. When power is removed and resorted, the last conguration will be invoked.
2
FEATURES

3
SPECIFICATIONS
• Type of HDMI Switcher: (8) Inputs to (8) + (1) Preview Outputs HDMI Matrix Switch
• HDMI Support: HDMI 4K2K, 1080p@60Hz, H36-bit Deep color, 3D of HDMI V1.4 formats
• HDCP / CEC Support: HDCP 1.3 Compliant, CEC Compliant
• Video Bandwidth: Wide frequency range 25MHz ~ 340MHz
• Digital Video Support: HD: 480i/ 480p/ 720p/ 1080i/p and 4K2K up to 36bit deep color
• Video Inputs: (8) HDMI (HDMI or DVI digital source)
• Video Outputs:
• HDMI: With Booster output 1080p up to ~98 ft (30M) & 4K2K up to ~66 ft (20M)
• Audio Support: Multi Audio Formats 5.1 / 7.1, MAT (MLP), Dolby Digital, Dolby TrueHD, Dolby Digital Plus, DTS, DTS-ES 6CH,
DTS-HD, DTS-HD-HRA, DTS-HD Master, (PCM-2CH)
• Preview Output: (1) Preview output (same output #1 picture)
• Switcher Controls:
• Select & Function buttons on front panel (Data status via LCM panel show out)
• IR Remote Control (switch control)
• IR External port (switch control via 3.5mm OD Jack)
• RS-232 series interface (switch control)
• Ethernet series interface (switch control)
• Source Status: Input status LEDs indicates presence of a live signal
• (23) Function Control Keys: 1. ALL, 2. OFF, 3. RECALL, 4. ENTER, 5. MEMORY, 6. LOCK, 7. EDID, 8. Destination button 1 thru
8, 9. Source button 1 thru 8
• (7) EDID Management Modes:
• Select Embedded EDID Modes: Mode1: FSS, Mode2: H24-3D, Mode3: H24-3D-M, Mode4: H36-3D, Mode5: H36-3D-M,
Mode6: 4K2K-3D, PCM-2CH, Mode7: DVI-D 1920x1200-60Hz
• Select LEARNING Mode: Learning Destination EDID to Link Source
• Infrared Frequency: 38Khz
• IR Extend Distance: ~984 feet / 300M maximum
• HDMI I/O Connector: HDMI Type A - SMD 19-pin female type
• Temperature: Operating Temperature 32°F - 100°F (0°C - 32°C)
• Dimensions (LxWxH): 17.5 x 9.875 x 1.75 in
• Rack Mount: 1RU High 19” Rack Mount #1U-440L (with rack mount)
• Power Supply: AC 100~240VAC 50/60Hz (120V/0.5A/60W; 220V/0.27A/60W)
• Safety Approvals: CE, FCC, RoHS, REACH
• Weight: 3.65 Kgs / 8.15 lb
As product improvements are continuous, specications are subject to change without notice.
SPECIFICATIONS

4
FRONT PANEL
1. POWER SWITCH: The power switch turns the unit on and o󰀨. The LCM will illuminate red to indicate that the switcher is ON and
is receiving power. The switcher will remember that last state during a power cycle. When power is removed and resorted, the last
conguration will be evoked.
2. STATUS DISPLAY: Front panel status display shows current matrix routing conguration. This same display also shows particular
conguration settings depending on your current function. In run mode (as shown above), the display shows each Output (destination)
channel to which input (source) it is assigned.
3. IR SENSOR: The IR sensor receives IR commands from the supplied remote control or third party IR emitter.
4. INPUT STATUS DISPLAY: Input sources 1 to 8 LED illuminates blue to indicate that a video source is present on that input.
5. SOURCE SELECT BUTTONS: Separate inputs 1 thru 8 select buttons are provided each source selection.
6. EDID MODE SELECT BUTTONS: Used to select EDID mode using Source button #1 or #2.
7. DESTINATION SELECT BUTTONS: Separate outputs 1 thru 8 select buttons are provided for each destination assignment. Routing can be
source to destination or one source to multiple destinations.
Example: Press Destination 1, 3, 5, then press Source 2. It will route Input 2 to Output 1, 3, 5 respectfully.
8. 19 INCH EAR MOUNT PAIR: Converts desktop to 19 inch rack mount. Bracket (part # 2U-440L) INCLUDED. Image shows rack mount
bracket attached.
FRONT PANEL

5
FRONT PANEL
9. FUNCTION KEY - EDID:
Used to display/change current EDID mode.
- Press EDID to select new EDID mode.
- Press SOURCE row #1 or #2 Select EDID modes.
- Press ENTER to ready memory location.
- Or press EDID again to cancel the operation.
Operation completes.
Note: Operation will abort if no keys are pressed within 5 seconds.
10. FUNCTION KEY - RECALL:
The system will show previously stored presets, up to a total of (16). Presets are stored in
local memory using Source keys 1 thru 8 or Destination keys 1 thru 8 as the memory preset
location.
- Press RECALL button.
- Press 1 THRU 8 on either Source or Destination row.
- Press ENTER The pre-set conguration will execute.
Operation completes.
Note: Operation will abort if no keys are pressed within 5 seconds.
- Or press RECALL again to cancel the operation.
11. FUNCTION KEY - MEMORY:
The system will show stored presets, up to a total of (16). Presets are stored in local memory
using Source keys 1 thru 8 or Destination keys 1 thru 8 as the memory preset location.
- Congure desired matrices.
- Press MEMORY button.
- Press 1 THRU 8 on either Source or Destination row.
- Press ENTER to ready memory location.
- Or press MEMORY again to cancel the operation.
Operation completes.
Note: Operation will abort if no keys are pressed within 5 seconds.
- Or press MEMORY again to cancel the operation.
FRONT PANEL

6
FRONT PANEL
12. FUNCTION KEY - ALL:
Disables (mutes) video on all destinations OR assign the same source to all destinations.
Option 1
- Press ALL followed by OFF button. The display will show ”0” to indicate none of the
destinations are assigned a video source.
Option 2
- Press ALL followed by Source 1 thru 8. The display will show the Source selected.
- Press ENTER. The pre-set source selection will be assigned all destinations.
13. FUNCTION KEY - OFF:
Disables (mutes) video on the selected destinations.
- Press OFF button followed by any Destination channel.
- Press 1 THRU 8 output destination. The display will show “0“ for the selected channel,
indicating no video selected.
14. FUNCTION KEY - LOCK:
- Press and hold LOCK button for two seconds lockout the front panel.
- Press and hold LOCK button for two seconds to enable the front panel.
15. FUNCTION KEY - ENTER: Press ENTER to conrm entries.
FRONT PANEL

1. DC POWER INLET: The Switcher is tted with an AC power plug
input connector. Ensure that the used is of an approved type
and is of su󰀩cient current carrying connector capacity with
the correct voltage and connector polarity. 100~240Volt AC,
50/60Hz power supply.
2. IR EXTENDER CONTROL: Supports (1) IR Extender. Extends
maximum distance of ~984 feet/300M. When you plug the
external IR extender into the switcher, the front panel IR receiver
remains active.
3. RS-232 CONNECTION: RS-232 control port allows for interfacing
to a PC, such as a computer or touch panel control, to the switcher
via the DB-9pin female connector for serial RS-232 control.
4. ETHERNET CONNECTION: ETHERNET control port allows for
TCP/IP interfacing to a PC, such as a computer or touch panel
control (not a web-browser), to the switcher via the RJ-45 female
connector to control switcher.
5. INPUTS- 1,2,3,4,5,6,7, & 8 HDMI: Connects a HDMI signal source
to an Input. This HDMI port supports HDMI with embedded
audio and DVI with AUX audio sources. If you remove the HDMI
screw posts, you must use the provided HDMI Locking Post
replacement screws to keep the internal HDMI jack secure.
Removing the HDMI screws without installing the HDMI Locking
Post replacement screws will void your warranty.
6. OUTPUTS-1,2,3,4,5,6,7 & 8 HDMI: Connects a HDMI signal
source to an Output. This HDMI port supports HDMI with
embedded audio and DVI with AUX audio. If you remove the
HDMI screw posts, you must use the provided HDMI Locking
Post replacement screws to keep the internal HDMI jack secure.
Removing the HDMI screws without installing the HDMI Locking
Post replacement screws will void your warranty.
7. PREVIEW OUTPUT-1 HDMI: Connects a HDMI direct digital video/
audio signal link to the HDMI female connector. This connector
supports HDMI digital video/audio and DVI digital video sources.
Preview port HDMI signal as the same as Output 1.
POWER SOCKET:
CONNECTOR TYPE: IEC 60320 C13
IR EXTENDER JACK: Female jack - inner OD Ø 3.5mm
REMOTE PORT: D-SUB-9pin female connector
REMOTE PORT: Control the switcher via the RJ-45
female connector
ETHERNET PORT: Note: The Ethernet port and RS-
232 port cannot be used simultaneously. Any
connection to the Ethernet port will disable serial
commands sent to the RS-232 port.
HDMI CONNECTOR: HDMI Type A SMD 19pin female
socket connector
Note: With the proper adapters, the switcher can
be used with DVI digital video signals as it is
HDCP compliant. DVI supports Audio input.
HDMI CONNECTOR: HDMI Type A SMD 19pin female
socket connector
Note: With the proper adapters, the switcher can
be used with DVI digital video signals as it is
HDCP compliant. DVI supports Audio input.
HDMI CONNECTOR: HDMI Type A SMD 19pin female
socket connector
Note: With the proper adapters, the switcher
can be used with DVI digital video signals and
is HDCP compliant. DVI does not support audio.
7
BACK PANEL
BACK PANEL

8
Before making any connections to the switcher, observe the following:
• Ensure the main voltage supply matches the label on the supplied plug-pack (+/-10%).
• Ensure that the power switch is OFF.
• Ensure that all system grounds (earth) are connected to a common point.
• Avoid powering equipment within a system from multiple power sources that may be separated by large distances.
• Connect all audio video sources and destination equipment.
• Power up all source and destination audio-visual sources.
• For each destination output select the appropriate input source by using the front panel input select buttons. The supplied IR remote
control. Or through the RS-232 serial communications port.
• Upon powering up the switcher, it will return to its last used setting before being powered down.
REMOTE CONTROL
IR REMOTE CONTROL KEY :
1. & 2. SWITCH POWER ON or OFF:
Power ON and OFF
3. DESTINATION: 1 thru 8 OUTPUT SELECTION:
Destination buttons to select the output display channel
4. SOURCE: 1 thru 8 INPUT SOURCE SELECTION:
Input 1~8 source selection buttons
5. FUNCTION KEY: Function selection buttons
ALL OFF EDID RECALL
MEMORY ENTER LOCK
REMOTE CONTROL

9
IR REMOTE CUSTOM AND DATA CODES (NEC Standard)
HOW TO SETUP IR CODES: CUSTOM CODE: 4DB2
POWER ON: 4DB2 A15E LOCK: 4DB2 B54A
POWER OFF: 4DB2 A25D RECALL: 4DB2 B24D
ALL: 4DB2 B04F MEMORY: 4DB2 B44B
OFF: 4DB2 B14E ENTER: 4DB2 B34C
EDID: 4DB2 B748
PRESS DESTINATION - # then PRESS SOURCE - #
DESTINATION #1 : 4DB2 10EF SOURCE #1 : 4DB2 01FE
DESTINATION #2 : 4DB2 20DF SOURCE #2 : 4DB2 02FD
DESTINATION #3 : 4DB2 30CF SOURCE #3 : 4DB2 03FC
DESTINATION #4 : 4DB2 40BF SOURCE #4 : 4DB2 04FB
DESTINATION #5 : 4DB2 50AF SOURCE #5 : 4DB2 05FA
DESTINATION #6 : 4DB2 609F SOURCE #6 : 4DB2 06F9
DESTINATION #7 : 4DB2 708F SOURCE #7 : 4DB2 07F8
DESTINATION #8 : 4DB2 807F SOURCE #8 : 4DB2 08F7
For Example:
Select Destination # 1 to show Source #1~8,
The IR Data Code list:
Destination # 1 , Source #1 4DB2 10EF 4DB2 01FE 01FE
Destination # 1 , Source #2 4DB2 10EF 4DB2 01FE 02FD
Destination # 1 , Source #3 4DB2 10EF 4DB2 01FE 03FC
Destination # 1 , Source #4 4DB2 10EF 4DB2 01FE 04FB
Destination # 1 , Source #5 4DB2 10EF 4DB2 01FE 05FA
Destination # 1 , Source #6 4DB2 10EF 4DB2 01FE 06F9
Destination # 1 , Source #7 4DB2 10EF 4DB2 01FE 07F8
Destination # 1 , Source #8 4DB2 10EF 4DB2 01FE 08F7
REMOTE PROTOCOL COMMANDS

10
EDID FUNCTION - SYSTEM RESET/FACTORY RESET
SYSTEM RESET
SYSTEM RESET RETURN SWITCH TO FACTORY DEFAULTS
Press RECALL > OFF > ENTER RESET to Factory Default
1. Press RECALL button: The LCM will show the current stored presets status.
2. Press OFF button: The LCM will show “SYSTEM RESET”
3. Press ENTER button: To conrm entries.
The switch will reset all customizable values back to factory defaults.
You must POWER CYCLE the switch for the new values to take e󰀨ect.
NOTE: Factory Reset Defaults to:
1. Source Destination will be set to 1-1, 2-2, 3-3, etc.
2. Switch matrices stored in memory will be cleared.
3. Lock function will return to Un-Locked.
4. AUX function will disable and return to UN-AUX (On Select Models).
5. ARC function will disable and return to SPDIF as the Output (On Select Models).
6. EDID will return to FSS®(1080p-2ch Mode).
7. Ethernet port will return to DHCP=ENABLED.
RESET EDID
EDID RESET PROCEDURE
From the Front Panel:
Press EDID > RECALL > OFF > ENTER
RESET EDID
Press EDID.
Press RECALL.
Press OFF. The display should show Reset EDID.
Press ENTER.
LEARNING MODE 2 SETTING EDID TO LEARNING MODE 2
Press EDID > OFF > DESTINATIONS > ENTER
The EDID for HDMI has been passed from the
Destination port to the Source port.
1. Press EDID button: The LCM will show the current EDID status.
2. Press OFF button: Does the OFF button stay illuminated?*
*If Yes: Press ALL the Destination buttons individually so they illuminate blue.
The switcher will LEARN the destination HDMI EDID and pass to the selected
source. The switcher will Enable or Disable HDMI EDID for the selected source.
3. Press ENTER to conrm changes. The LCM will return to the default screen
showing selected matrix routing status. This puts you in Learning Mode 2.
*If No: You might need a f/w update.

EDID FUNCTION FOR HDMI MATRIX SWITCHER
EDID SETUP To Change The EDID Setup
Step 1. Press the EDID button The display will show the currently selected EDID mode.
Step 2. Press SOURCE #1 OR #2 button row The button will ash blue and the display will show the current Embedded EDID Status.
Step 3. Press the ENTER button To set EDID mode. The switcher will return to operation mode.
Operation will abort if no keys are pressed within 5 seconds.
EMBEDDED EDID MODES Total 7 EDID Modes
Embedded EDID Setup
Press EDID > SOURCE > ENTER
SOURCE #1 or SOURCE #2
To select Embedded EDID mode or LEARNING mode.
Repeatedly pressing the SOURCE 1 button will cycle up thru the options.
Repeatedly pressing the SOURCE 2 button will cycle down thru the options.
Embedded EDID:
Mode 1 : FSS® Mode 5 : H36-3D-M
Mode 2 : H24-3D Mode 6 : 4K2K
Mode 3 : H24-3D-M Mode 7 : DVI-D 1920x1200-60Hz
Mode 4 : H36-3D
EDID FUNCTION FOR HDMI MATRIX SWITCHER
RESET EDID Return To Factory Default
How to RESET EDID mode
Press EDID > RECALL > ENTER
To RESET to FACTORY DEFAULT (1080p-2CH).
Press EDID button: The LCM will show the current EDID status.
Press RECALL button: The LCM will show the RESET EDID.
Press ENTER to conrm entries.
The EDID will return to FSS®mode and resolution 1080p-2CH.
EDID STATUS To View The Current EDID Status
Step 1. Press EDID button The button will ash blue and the display will show the current Embedded EDID Status.
Step 2. Press EDID button To exit.
HOW TO SETUP FSS®FUNCTION Fast Speed Start®
Step 1. Press the DESTINATION #1~8 button row
Then Press the SOURCE #1~8 button row
To setup and Install all devices.
Step 2. Press EDID button Select a optimum status of Embedded EDID mode.
Step 3. Press ENTER button To conrm entries.
Step 4. Press EDID button To select the EDID FSS®mode.
Step 5. Press ENTER button To conrm entries.
11
EDID FUNCTION

EDID FUNCTION FOR HDMI MATRIX SWITCHER
EDID FUNCTION: (8) EMBEDDED EDID MODES
Mode 1. FSS®(Fast Speed Start®)Fast Speed Start®mode shortens the startup time of the switcher. Selecting this
mode does not force the EDID setup to be cancelled. Users may rst select one
EDID mode from mode 2 to 3, and then select mode 1 for fast speed start®.
Mode 2. H24-3D (1080p-24 bits) Audio Support: PCM 2CH
Mode 3. H24-3D-M (1080p-24 bits) Audio Support: MAT(MLP) 7.1CH, PCM-2CH, One Bit Audio 2CH, AC-3 5.1CH, DTS
5.1CH, PCM 7.1CH, Dolby Digital + 7.1CH, DTS-HD 7.1CH
Mode 4. H36-3D (1080p-36 bits) Audio Support: PCM 2CH
Mode 5. H36-3D-M (1080p-36 bits) Audio Support: MAT(MLP) 7.1CH, PCM 2CH, One Bit Audio 2CH, AC-3 5.1CH, DTS
5.1CH, PCM 7.1CH, Dolby Digital + 7.1CH, DTS-HD 7.1CH
Mode 6. 4K2K (24/30Hz) HDMI Support: 4K2K-3D, PCM 2CH (3860x2160-24/30Hz)
Audio Support: PCM 2CH
Mode 7. 1920x1200-60Hz (DVI-D) DVI Support: DVI-D 1920 x 1200 60Hz
12
EDID FUNCTION

LEARNING EDID SINGLE TO SINGLE Learning Destination #2 EDID To Source #3
Step 1. Press EDID button The button will ash blue and the display will show the current Embedded EDID Status.
Step 2. Press the DESTINATION #2 button row Copy the Destination #2 Display EDID.
Step 3. Press the SOURCE #3 button row Learning the Destination #2 EDID To Source # 3.
Step 4. Press ENTER button To conrm entries.
LEARNING EDID SINGLE TO MULTIPLE Learning Destination EDID Link To The Majority Sources
Step 1. Press EDID button The button will ash blue and the display will show the current Embedded EDID Status.
Step 2. Press the DESTINATION 1-8 button row Copy any 1~8 Destinations EDID.
Step 3. Press the SOURCE 1-8 button row Learning the Destination EDID link to source #1-8.
Step 4. Press ENTER button To conrm entries.
LEARNING EDID SINGLE TO ALL Learning Destination EDID Link To All Sources
Step 1. Press EDID button The button will ash blue and the display will show the current Embedded EDID Status.
Step 2. Press destination button 1 THRU 8 Learning anyone 1~8 Destination EDID to all sources.
Step 3. Press ALL button Learning selected destination EDID to all sources.
Step 4. Press ENTER button To conrm entries.
SINGLE LEARNING #1 DEFINITION Single Learning EDID from Destination to Source
1. Switcher will LEARN destination EDID and pass the selected source.
2. To set up learning between a single destination and single source: Press EDID button > Press DESTINATION 1 THRU 8 > Press SOURCE 1
THRU 8 > Press ENTER to conrm. Switcher will learn destination EDID to source device.
3. To set up learning between a single destination and Multiple sources: Press EDID button > Press DESTINATION 1 THRU 8 > Press the
majority SOURCES 1 THRU 8 > Press ENTER. Switcher will learn single destination EDID to many source devices.
4. How to Learning single destinations with all sources. Press EDID button > Press ALL button > Press ENTER to conrm.
MULTIPLE LEARNING #2 DEFINITION Multiple Learning EDID from Destination to Source
1. Switcher will multiple LEARN destination EDID and pass the selected source.
2. To set up multiple learning between a single destination and single source: Press EDID button > Press OFF button > Press DESTINATION
1 THRU 8 > Press ENTER to conrm. Switcher will learn destination EDID to source device.
3. When the Source has “Learned” the EDID data from a destination, it will save that EDID information into EPROM and the EDID data
will not change. To change a saved HDMI EDID information, you have to select a new LEARNING destination to source or Disable the
LEARNING.
13
EDID FUNCTION

LEARNING EDID MODE-#1 Learning EDID from Destination to Source
Single Learning Mode#1 EDID setup
Press
EDID > DESTINATION > SOURCE > ENTER
Key Press Sequence: EDID > DESTINATION # > SOURCE # > ENTER
The EDID for HDMI has been learned from the Destination port to the Source port.
1. Press EDID button. The LCM will show the current EDID status.
2. Press DESTINATION (1 -8) button.The LCM will show the LEARNING HDMI.
Switcher will LEARN destination HDMI EDID.
3. Press SOURCE (1 -8) button. Switcher will Learning destination HDMI EDID and
pass to the selected source.
4. Press ENTER to conrm changes. The LCM will return to the default screen
showing selected matrix routing status.
NOTE : The already learned EDID cannot be modied. You can only rebuild a new Learning EDID.
For Example: When the Source has “Learned” the EDID data from a destination, It will save that EDID information into EPROM and
the EDID data cannot change. Please select new learning destination to sources or change to one of the embedded EDID modes when
you want to remove the learning EDID memory from EPROM.
14
EDID FUNCTION

LEARNING EDID #2 Passing EDID From Destination To Source
Multiple Learning mode #2 EDID setup
Press
EDID > OFF > DESTINATION #1 THRU #8 > ENTER
The EDID for HDMI has been Learned from the Destination port to the Source port.
1. Press EDID button. The LCM will show the current EDID status.
2. Press OFF button. The LCM will show the current EDID LEARN status.
3. Press DESTINATION (1-8) button. The switcher will LEARN the destination HDMI
EDID and pass to the selected source. Switcher will Enable or Disable HDMI EDID
for the selected source.
4. Press ENTER to conrm changes. The LCM will return to the default screen
showing selected matrix routing status.
NOTE: When the Source has “Learned” the EDID data from a destination, it will save that EDID information into EPROM and
the EDID data will not change. To change a saved HDMI EDID information, you have to select a new LEARNING destination
to source or Disable the LEARNING
15
EDID FUNCTION

INSTALLING DIAGRAM
Sample Connection:
Using External IR, RS-232 or Ethernet commands to control the SB-5688Kp via PC or SB-100 IR receiver to transmit the SB-5688Kp’s
IR signal.
NOTE:
1. Switcher IR External Port: Use SB-100 IR signal Receiver
2. 4K2K Source: Use 4K2K Blu-ray HD Source
3. Control Switch via a PC RS-232
4. Control Switch via a PC Ethernet
Application RS-232, IR and Ethernet to control the switcher.
16
TYPICAL APPLICATION

ETHERNET / RS-232 SERIAL INTERFACE CONNECTS A PC OR CONTROL SYSTEM
VERSION COMPATIBLE V2.0
For a complete list of commands, please reference external document extended Ethernet Protocol Instruction Manual.
Example of the commanded string to select Inputs:
Function Command Variables
Set channel status OUTPUTxx yy; xx = Output Channel
yy = Input Channel
Command Example Response Description
OUTPUT02 04; HD-88 00; Set output 2 to input 4
HD-88 01; UN-KNOW Command
ETHERNET SERIAL INTERFACE
Pin Ethernet Reference
1 TXOP TX +
2 TXON TX -
3 RXIP RX +
4 NC
5 NC
6 RXIN RX -
7 NC
8 GND
ETHERNET TCP/IP PROTOCOL COMMANDS ( Ethernet / RS-232 Control driver V2.0 )
*** The Ethernet port and RS-232 port cannot be used simultaneously. Any connection to the Ethernet Control port will disable serial
commands sent to the RS-232 port.***
17
ETHERNET
Note: Control the switcher
SPD: Speed
LINK: Ethernet link
RJ-45 Female 8P-8C Connector
TCP, Port 5000

RS-232 Conguration
RS-232 cable is a straight thru cable and not null-modem
Denition Pin Pin Denition
1 1 DCD
TX 2 2 RX
RX 3 3 TX
4 4 DTR
GND 5 5 GND
6 6 DSR
7 7 RTS
8 8 CTS
9 9 RI
RS-232 SERIAL INTERFACE PROTOCOL COMMANDS ( Ethernet / RS-232 Control driver V2.0 )
The HD-88Kp switcher can be controlled via the RS-232 serial control port to allow for interfacing to a PC, or similar third party control
system. The serial communication parameters are 9600 baud, 8 bit, No Parity and 1 stop bit - this is often referred to as 9600 8N1. When
the unit recognizes a complete command it will perform the requested action - there is no delimiter character required.
18
RS-232 SERIAL INTERFACE
SB-5688Kp
Device PC
