Shinybow USA SB-8811 User manual

In st ru ction Manual
Part No.: ENCL008811R01A2
Thank you for purchasing the item of SB-8811 DVI Matrix Switcher. You will find this unit easy to install and highly
reliable but it is essential that you read this manual throughly before attempting to use 8x8 DVI Matrix switcher.
FULL HD DVI Matrix Switcher Series
8x8 DVI MATRIX SWITCHER
MODEL : SB-8811
M U LT I M E D I A A U D I O A N D V I S U A L
Version No.: 8811-20131101-003

SAFETY INFORMATION
THIS SAFETY INFORMATION IS OF A GENERAL NATURE AND MAY BE SUPERSEDED BY INSTRUCTIONS CONTAINED WITHIN THIS MANUAL
1. Save the carton and packing material even if the equipment has arrived in good condition. Should you ever need to ship the unit, use only the original
factory packing.
2. Read all documentation before operating your equipment. Retain all documentation for future reference.
3. Follow all instructions printed on unit chassis for proper operation.
4. Do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid.
5. Make sure power outlets conform to the power requirements listed on the back of the unit.
6. Do not use the unit if the electrical power cord is frayed or broken. The power supply cords should be routed so that they are not likely to be walked on
or pinched by items placed upon or against them, paying particular attention to cords and plugs, convenience receptacles, and the point where they exit
7. Always operate the unit with the AC ground wire connected to the electrical system ground. Precautions should be taken so that the means of grounding of
a piece of equipment is not defeated.
8. Mains voltage must be correct and the same as that printed on the rear of the unit. Damage caused by connection to improper AC voltage is not covered by
any warranty.
9. Power down & disconnect unit from mains voltage before making connections.
10. Never hold a power switch in the ＂ON＂ position.
11. Do not use the unit near stoves, heat registers, radiators, or other heat Producing devices.
12. Do not block fan intake or exhaust ports. Do not operate equipment on a surface or in an environment which may impede the normal flow of air around the unit,
13.
such as a bed, rug, carpet, or completely enclosed rack. If the unit is used in an extremely dusty or smoky environment, the unit should be
Periodically ＂blown free＂ of foreign matter.
14.
Do not remove the cover. Removing the cover will expose you to potentially dangerous voltages. There are no user serviceable parts inside.
15.
Do not drive the inputs with a signal level greater than that required to drive equipment to full output.
16.
Non-use periods. The power cord of equipment should be unplugged from the outlet when left unused for a long period of time.
Service Information Equipment should be serviced by qualifier service personnel when:
A. The power supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the equipment.
C. The equipment has been exposed to rain
D. The equipment does not appear to operate normally, or exhibits a marked change in performance
E. The equipment has been dropped, or the enclosure damaged.
from the appliance.
IMPORTANT SAFETY INSTRUCTIONS
To insure the best from this product, please read this manual carefully. Keep it in a safe place for future reference.
To reduce the risk of electric shock, do not remove the cover from the unit. No user serviceable parts inside. Refer servicing to qualified personnel.
To reduce the risk of fire, do not expose the unit to rain, water or excessive moisture.
Do not force switched or external connections.
When moving the unit disconnect the serial port connections first then the power cable and finally the interconnecting cables to other devices.
Do not attempt to clean the unit with chemical solvents or aerosol cleaners, as this may damage the unit. Use a clean dry cloth.
Installation of this unit should be in a cool dry place, away from sources of excessive heat, vibration, dust, moisture and cold.

PAGE 3SB-8811 INSTRUCTION & OPERATION MANUAL
TABLE OF CONTENTS
TABLE OF CONTENTS
INTRODUCTION AND PACKAGE CONTENTS
FEATURES
SPECIFICATIONS
EDID FUNCTION - EDID SETUP
EDID FUNCTION - EMBEDDED EDID
EDID FUNCTION - LEARNING EDID
EDID FUNCTION - LEARNING EDID
EDID FUNCTION - EDID SETUP
FRONT PANEL - 1
FRONT PANEL - 2
FRONT PANEL - 3
REAR PANEL
TYPICAL APPLICATION - HDMI IN/OUT
TYPICAL APPLICATION - HDBaseT TX/RX connection
IR REMOTE CONTROL
IR REMOTE CONTROL - IR DATA CODE
IR EXTERNAL INSTALL
ETHERNET SERIAL INTERFACE
RS232 PROTOCOL
LIMITED
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________

INTRODUCTION AND PACKAGE CONTENTS
PAGE 4 SB-8811 INSTRUCTION & OPERATION MANUAL
INTRODUCTION
The SB-8811 is high-performance 8x8 matrix routing switcher for DVI (Digital Visual Interface)
signals.This switcher supports data rates up to 6.75 Gbps, enabling 1920x1200 DVI formats and
UXGA/WUXGA/DVI resolution to any HD display. High Definition Digital signals can be selected
and distributed to any 8 outputs simultaneously. The Switcher is certified as being fully DVI and
HDCP compliant, with RoHS,CE,FCC certification. Support high resolution DVI sources routed to DVI
displays, monitors, projector or audio receivers. The EDID can be selected between four (4) different
modes. Control is provided via Front panel push buttons, IR remote, TCP/IP (not a web-browser)
or RS-232. An RS232 Windows GUI interface is provided for matrix routing control (Windows only).
PACKAGE CONTENTS
1. SB-8811 Matrix Switcher
2. Operating Instructions
3. RS-232 V2.0 Protocol Instructions
4. Ethernet V2.0 Protocol Instructions
5. Master wireless IR Remote Control (SW-8811)
6. 19 inch Ear mount bracket (Part # 1U-440L)
7. SB-100 IR Extender distance ~984 feet (300M) Receiver set.
8. SB-100C IR Extender distance 6ft (2M) Receiver Cable.
CD Contents : This manual, Windows GUI, ISP V1.0 Windows driver
RS232 Cable 6 feet (2M)
9. 16x DVI connector use ISO screw (L5mm/OD3mm)
10
11
12. Power Supply 12VDC, 5A Universal Type 50/60Hz, 100~240 VAC
SB-100 IR Receiver SB-100C IR Receiver #1U-440L
19-inch ear mountIR extender 2MIR extender 300M set
D-Sub 9P-9F (L=6ft)
RS-232 Cable (2M)

INTRODUCTION AND PACKAGE CONTENTS
PAGE 5SB-8811 INSTRUCTION & OPERATION MANUAL
FEATURES
1. 8x DVI signal device sources matrix switched to 8x DVI destination devices.
2. DVI digital video w/embedded, DVI format and HDCP 2.0 compliant
3. Seven (7) function key control and worldwide (4) EDID modes for HD-DVI resolutions.
4. Link speeds of up to 6.75 Gbps (link clock rate of 340Mb Hz), Support DVI 3D formats.
5. Wide range of HD DVI resolutions from PC XGA to WUXGA 1920x1200 and
HDTV/DTV resolutions 480i/480p, 576i/576p, 720p, 1080i & 1080p
6. Compatible with all DVI source devices, PC monitors, Plasma HD display, HDTV
and audio receivers/amplifiers.
7. Digital Video TMDS formats Resolution up to 1920x1200 with Deep color 36-bit.
8. Various User Interface control:
‧ Windows based GUI control via RS232 port
‧ Front Panel push button
‧ IR wireless remote control
‧ Ethernet series control
‧ Third party RS232 controller (via simple ASCII)
9. Support world wide control functions: ALL/OFF/RECALL/ENTER/MEMORY/EDID/LOCK
10. Support Embedded EDID modes :
Internal modes : FSS/1280x1024-60Hz/1920x1200-60Hz/Auto
External modes : Learning mode.
11. Automatic scanning input sources status via LED show on front panel.
12. Support ISP function to update the new F/W via RS-232 port.
13. Support IR Remote and IR Extender with distance up to ~ 984' (300M) Maximum.
14. Support Rack Mount 1RU High 19 ”Rack Mount with rack mount (1U-440L).
15. Support Power Supply 12VDC, 5A Universal Type 50/60Hz, 100~230 VAC
The Switcher will remember that last state during a power cycle.
When power is removed and resorted, the last configuration will be invoked.

SPECIFICATIONS
SPECIFICATIONS
As product improvement is continuous, specifications are subject to change and without notice or liability.
PAGE 6 SB-8811 INSTRUCTION & OPERATION MANUAL
Type of DVI Switcher 8x DVI inputs To 8x Outputs Matrix SwitcherDVI
DVI Support HD DVI 1920x1200, H36-bit Deep color, 3D (HDMI 1.4a) formats.
HDCP / CEC Support HDCP 2.0 Compliant, CEC Compliant.
Video Bandwidth Double Data Rates:340Mhz, Total 6.75Gbps bandwidth.
Digital Video Support Full HD DVI resolution: 1920x1200 & HDMI:480ip/720p/1080i/p
Switcher Controls IR Remote Controller
IR External port x 1 (OD 3.5mm Ear phone Jack)
Select & Function buttons on front panel
Ethernet Serial Interface and RS 232 series interface
Infrared Frequency 38 Khz
IR External Distance ~984 feet / 300 meters maximum.
DVI I/O Connector DVI-D - (24+5) pin Female DIP Type
Dimensions LxWxH=19 ”x 9.85 ” x 1.75 ”(482mm x 250mm x 44mm)
Rack Mount Rack Mount 1RU High 19 ”Rack Mount (with rack mount)
Power Supply DC12V / 5A, Universal world wide Type 50/60Hz, 100~230 VAC
Power Consumption 3880 mA Maximum
Temperature
Safety Approvals CE, FCC, RoHS, REACH.
Product Weight 2.45 Kgs / 4.10 lb
Preview output Support 1x preview output port via Output-#1simultaneously
Function Control Key ALL / OFF / RECALL / ENTER / MEMORY / LOCK / EDID
(0 C - 38 C)32 F - 100 F Operation
Source Status Automatically Scan Sources Inputs via (8) x LEDs show out

PAGE 7SB-8811 INSTRUCTION & OPERATION MANUAL
EDID FUNCTION
EDID function Setup
Press
6.1 Embedded EDID modes Total 4 EDID Modes
Operation will abort if no keys are pressed within 5 seconds.
EDID setup
Step 1 . Press the EDID button The display will show the currently selected EDID mode
Step 2 . Press SOURCE #1 or #2
button row
The button will flash blue and the display will show
the current Embedded EDID Status.
Step 3 . Press the ENTER button To set EDID mode.
The switcher will return to operation mode.
Select Embedded EDID :
Mode 1 : FSS
Mode 2 : 1280x1024-60Hz
Mode 3 : 1920x1200-60Hz
Mode 4 : AUTO
EDID
>
SOURCE
>
ENTER
Embedded EDID setup
To change the EDID setup
Repeatedly depressing the source 1 button will cycle up thru the options.
Repeatedly depressing the source 2 button will cycle down thru the options.
to select Embedded EDID mode or LEARNING mode.
SOURCE #1
or
SOURCE #2
Press EDID button : The LCM will show the current EDID status.
EDID
3.1920x1200-60HZ DVI-D

EDID FUNCTION
PAGE 8 SB-8811 INSTRUCTION & OPERATION MANUAL
EDID function : 4x Embedded EDID Modes
Mode 4 . AUTO <Default>
All Outputs will be set to the highest common
resolution of all connected display devices.
Mode 2 . 1280x1024-60Hz (DVI-D)
DVI Support :
DVI-D 1280x1024 - 60Hz
Mode 3 . 1920x1200-60Hz (DVI-D)
DVI Support :
DVI-D 1920 x 1200 - 60Hz
Mode 1 . FSS (Fast Speed Start)
R
EDID
1. FAST SPEED START
EDID
4. AUTO MODE
EDID
2.1280x1024-60HZ DVI-D
EDID
3.1920x1200-60HZ DVI-D
Fast Speed Start mode shortens the startup time of
the switcher. Selecting this mode does not force the
EDID setup to be cancelled. Users may first select one
EDID mode from mode 2 to 3, and then select mode 1
for fast speed start.

PAGE 9SB-8811 INSTRUCTION & OPERATION MANUAL
EDID FUNCTION
Switcher will LEARN destination EDID and
pass the selected source.
6.3 LEARNING EDID Learning EDID from Destination to Source
NOTE : The already learned EDID cannot be modified. You can only rebuild a new Learning EDID.
For example;
When the Source has "Learned" the EDID data from a destination, It will save that EDID
information into EPROM and the EDID data cannot change.
Please select new learning destination to sources or change to one of the embedded EDID modes
when you want to remove the learning EDID memory from EPROM.
Press
Learning EDID setup
EDID
>
SOURCE
>
ENTERDESTINATION
>
EDID function for DVI Matrix Switcher
Press EDID > DESTINATION Button:
EDID
LEARNING
The LCM will be show LEARNING.
Press
6.2 RESET EDID Return To Factory default
EDID
>
RECALL
>
ENTER
How to RESET EDID mode
EDID
RESET EDID
Press EDID button : The LCM will show the current EDID status.
Press RECALL button : The LCM will show the RESET EDID.
Press ENTER to confirm entries.
The EDID will return to FSS mode and resolution 1280x1024-60Hz.
RESET To the FACTORY DEFAULT (1280x1024).
EDID
3.1280x1024-60HZ DVI-D

EDID FUNCTION
PAGE 10 SB-8811 INSTRUCTION & OPERATION MANUAL
6.3.1
Step 1 . Press EDID button
Example : Learn Destination #8 EDID To Source #5.
The button will flash blue and the display will show
the current Embedded EDID Status.
Learning EDID Single to Single
Step 2 . Press the Destination #8 button row Copy the Destination #8 Display EDID.
Step 3 . Press the Source #5 button row Learning the Destination #8 EDID To Source # 5.
Step 4 .
Press ENTER button To confirm entries.
6.3.3
Step 3 .
Press EDID button
Learning destination EDID link to All Sources
The button will flash blue and the display will show
the current Embedded EDID Status.
Learning EDID Single to ALL
Step 1 .
Press destination button 1 thru 8 Learning anyone 1~8 Destination EDID to all sources.
Step 4 . Press ENTER button
To confirm entries.
Step 2 .
Press ALL button Learning selected destination EDID to all sources.
6.3.2
Step 3 .
Press EDID button
Learning destination EDID link to the majority Sources
The button will flash blue and the display will show
the current Embedded EDID Status.
Learning EDID Single to multiple
Step 1 .
Step 4 . Press ENTER button To confirm entries.
Step 2 . Press the Destinations #1~8 button row
Copy any 1~8 Destinations EDID.
Learning the Destination EDID link to source #1,#6,~#8 .
Press the Source #1, #6,~#8 button row
EDID Function : LEARNING
Step 4 .

EDID function for DVI Matrix Switcher
PAGE 11SB-8811 INSTRUCTION & OPERATION MANUAL
EDID FUNCTION
2. To set up learning between a single destination and single source:
Press EDID button > Press Destination 1 thru 8 > Press Source 1 thru 8 > Press ENTER to confirm.
Switcher will learn destination EDID to source device.
3. To set up learning between a single destination and Multiple sources:
Press EDID button > Press Destination 1 thru 8 > Press the majority Sources 1 thru 8 > Press ENTER.
Switcher will learn single destination EDID to many source devices.
4. How to Learning single destinations with all sources.
Press EDID button > Press ALL button > Press ENTER to confirm.
Example for single source
Destination > press #1 and then Source > press #1
Destination device #1 will set to the highest common resolution and Audio of source #1
Example for multiple sources
Destination device #1, #2, #3 will be set to the highest common resolution and Audio
available and source device #1 will output this same resolution.
6.7 Auto mode definition Common Resolution and Audio
Switcher will find highest common Resolution and Audio from all destination EDID
to link Source.
6.5
Step 2 . Press EDID button
Fast speed start
Select a optimum status of Embedded EDID mode.
How to setup FSS Function
Step 4 . Press EDID button To select the EDID FSS mode.
Step 5 . Press ENTER button To conform entries.
Step 1 . Press the Destination #1~8 button row To setup and Install all devices.
Then Press the Source #1~8 button row
R
R
Step 3 . Press ENTER button To conform entries.
R
6.4 EDID status
Step 1 . Press EDID button
Step 2 . Press EDID button
To view the current EDID status.
The button will flash blue and the display will show
the current Embedded EDID Status.
To exit.
1. Switcher will LEARN destination EDID and pass the selected source.
6.6 LEARNING EDID definition Learning EDID from Destination to Source

OUTPUT 1 2 3 4 5 6 7 8
FRONT PANEL
2
35
164
7
FRONT PANEL
PAGE 12 SB-8811 INSTRUCTION & OPERATION MANUAL
8x8 DVI MATRIX SWITCHER
POWER
1 2 3 5 6 7 8
SOURCE
DESTINATION
SOURCE
DESTINATION
4
AL L OF F ENTERRECALLLO CK MEMORYED ID
1 2 3 5 6 7 8 4
IR
1 2
SOURCE STATUS
3 4 5 6 7 8
SB-8811
POWER SWITCH
DESTINATION SELECT BUTTONS
1
4
The power switch turns the unit on and off. The LCM will illuminate red to indicate that the switcher is ON and
is receiving power.
The Switcher will remember that last state during a power cycle.
When power is removed and resorted, the last configuration will be evoked.
INPUT STATUS DISPLAY
2
Input sources 1 to 8 LCM illuminates blue to indicate that a video source is present on that input.
Separate outputs 1 thru 8 select buttons are provided for each destination assignment.
Routing can be Source to Destination or one source to multiple destinations.
Example : Press Destination 1,3,5 then press Source 2 will route Input 2 to Output 1,3,5 respectfully.
OUTPUT STATUS DISPLAY
3
Each Output (destination ) Channel shows which input (source) is assigned.
IR SENSOR
6
The IR sensor receives IR commands from the supplied remote controller or third party IR emitter.
EDID MODE SELECT BUTTONS
5
Used to select EDID mode using buttons #1 thru #2
SOURCE SELECT BUTTONS
7
Separate inputs 1 thru 8 select buttons are provided each source selection.
SOURCE 8 67 5 4 3 2 1

OUTPUT 1 2 3 4 5 6 7 8
SOURCE 5 4 3 2 1
8x8 DVI MATRIX SWITCHER
POWER
1 2 3 5 6 7 8
SOURCE
DESTINATION
SOURCE
DESTINATION
4
AL L OF F ENTERRECALLLO CK MEMORYED ID
1 2 3 5 6 7 8 4
IR
1 2
SOURCE STATUS
3 4 5 6 7 8
SB-8811
FRONT PANEL
FRONT PANEL
91110
PAGE 13SB-8811 INSTRUCTION & OPERATION MANUAL
FUNCTION KEY - OFF
9
Disables (mute) video to selected channels. Either destinations.
- Press OFF button followed by any Destination channel.
- Press 1 thru 8 output destination. The display will show " 0 " for the selected
channel indicating no video selected.
FUNCTION KEY - RECALL
The system will show previously stored presets, up to a total of 16.
Presets are stored in local memory using Source keys 1 thru 8 or Destination keys 1 thru 8
as the memory preset location.
- press RECALL button.
- press 1 thru 8 on either Source or Destination row.
- press ENTER The pre-set configuration will execute.
Operation completes.
Note: Operation will abort if no keys are dressed within 5 seconds.
10
FUNCTION KEY - ALL
Disables (mute) video on all destinations OR Selects the same source to all destinations.
Option 1
- Press ALL followed by OFF button. The display will show " 0 " indicating all destinations have no video
selected.
Option 2
- Press ALL followed by Source 1 thru 8. The display will show the Source selected.
- Press ENTER The pre-set source selection will be assigned all destinations.
8
8
FUNCTION KEY - ENTER
11
Press ENTER to confirm entries.
ALL
OUTPUT 1 2 3 4 5 6 7 8
1 1 1 1 1 1 1 1
OFF 1 0 3 0 5 0 7 0
OUTPUT 1 2 3 4 5 6 7 8
D-02
RECA LL
8 8 8 8 8 8 8 8
1 2 3 4 5 6 7 8
8 67
RECA LL
2 2 2 5 5 5 6 6
1 2 3 4 5 6 7 8
S-02

8x8 DVI MATRIX SWITCHER
POWER
1 2 3 5 6 7 8
SOURCE
DESTINATION
SOURCE
DESTINATION
4
AL L OF F ENTERRECALLLO CK MEMORYED ID
1 2 3 5 6 7 8 4
IR
1 2
SOURCE STATUS
3 4 5 6 7 8
SB-8811
FRONT PANEL
FRONT PANEL
15121314
PAGE 14 SB-8811 INSTRUCTION & OPERATION MANUAL
FUNCTION KEY - LOCK
- Press and hold LOCK button for two seconds lockout the front panel.
- Press and hold LOCK button for two seconds to enable the front panel.
13
FUNCTION KEY - EDID
14
19 INCH EAR MOUNT PAIR
Converts desktop to 19 inch rack mount. Bracket (part # 1U-440L) INCLUDED.
Image shows rack mount bracket attached.
15
FUNCTION KEY - MEMORY
12
The system will show store presets, up to a total of 16.
Presets are stored in local memory using Source keys 1 thru 8 or Destination keys 1 thru 8
as the memory preset location.
- Configure desired matrices..
- Press button.
- Press 1 thru 8 on either Source or Destination row.
- Press ENTER to ready memory location.
- or press MEMORY again to cancel operation.
Operation completes.
Note : Operation will abort if no keys are pressed within 5 seconds.
MEMORY
OUTPUT 1 2 3 4 5 6 7 8
8 67 5 4 3 2 1
- press EDID to select new EDID mode or select
source row #1 or #2 for LINK source EDID again.
EDID
LEARNING
EDID
3. 1920 X 1200 - 60 Hz
- press the DESTINATION # to learn EDID
The Destination EDID has been learned.
LOCK 1 2 3 4 5 6 7 8
OUTPUT 1 2 3 4 5 6 7 8
ME M ORY
2 2 2 2 2 2 2 2
1 2 3 4 5 6 7 8
S-05
MEMORY
2 2 5 5 8 8 1 1
1 2 3 4 5 6 7 8
SOURCE
D-02

REAR PANEL
PAGE 15SB-8811 INSTRUCTION & OPERATION MANUAL
1
REAR PANEL
23
1
3
2
INPUTS- 1,2,3,4,5,6,7, & 8 DVI-D
6
DVI-D
Input 1 ~ Input 8
Digital Video, Connector with fix screw
RS 232 CONNECTION
RS 232 control port to allow for interfacing to a PC
Such as a computer or touch panel control, to the switcher
via this DB-9pin Female connector for serial RS-232 control.
,
IR EXTENDER CONTROL
DC POWER INLET
The Switcher is fitted with a DC power plug input connector.
Ensure that the used is of an approved type and is of sufficient
current carrying connector capacity with the correct voltage and connector
polarity. 12Volt DC power supply 5A Max (Center pin positive).
7
6
OUTPUTS- 1,2,3,4,5,6,7 & 8 DVI-D
7
DVI-D
Output 1 ~ Output 8
Digital Video, Connector with fix screw
Remote port :
DB-9pin Female connector
DVI-D
DVI Female connector.
digital video/audio connector:
Connect a signal link of HDMI direct digital video/audio to
this Female DVI connector. This connector supports DVI-D
digital video/audio and DVI-D digital video sources. Note:
With the proper adapters, the switcher
can be used with DVI-D digital video signals
HDCP compliant. DVI does not support audio.
Connect a signal link of direct digital video/audio to
this Female DVI connector. This connector supports DVI-D
digital video/audio and DVI digital video sources.
DVI-D
DVI-D
DVI Female connector.
digital video/audio connector:
Note:
With the proper adapters, the switcher
can be used with DVI-D digital video signals
HDCP compliant.
Power Jack:
DC Jack - inner OD O 2.1mm (+ )
Outside OD O 5.5mm (GND)
Power input - 12VDC, 5A
IR Extender Jack:
Female Jack - inner OD O 3.5 mm
5
PREVIEW OUTPUT-01 DVI-D
5
DVI-D
DVI Female connector.
digital video/audio connector:
Connect a signal link of HDMI direct digital video/audio to this
Female DVI connector. This connector supports DVI-D digital
video/audio and DVI-D digital video sources. Note:
With the proper adapters, the switcher
can be used with DVI-D digital video signals
HDCP compliant. DVI does not support audio.
Preview port signal as the same as Output 1DVI-D
Support one of IR Ex tender (IR input)
Extend distance ma ximum 984 feet (300 me ters)
Note: DO NO T install or remote this connection with the power ON .
INPUT
PREVIEW OUTPUT-1
INPUTINPUT
2
2
OUTPUT
INPUT
3
3
OUTPUT
INPUT
4
4
OUTPUT
INPUTINPUT
5
5
OUTPUT
INPUT
6
6
OUTPUT
INPUT
8
8
OUTPUT
INPUT
1
1
OUTPUT
INPUT
7
7
OUTPUT
INPUT
SW IR In
DC 12V
Ethernet RS-232
Switch Control
8x8 DVI MATRIX SWITCHER
8811
4
4ETHERNET CONNECTION
ETHERNET control port to allow for TCP/IP interfacing to a PC
Such as a computer or touch panel control (not a web-browser),
to the switcher via this RJ-45 Female connector to control switcher.
,
Remote port : Control the switcher
RJ-45 Female connector
Ethernet
Ethernet Port:
Note: the Ethernet port and RS-232 port cannot be used
simultaneously. Any connection to the Ethernet port will
disable serial commands send to the RS-232 port.
Switch Control

TYPICAL APPLICATION
Support HDBaseT Extender by SB-6334T Transmitter and SB-6334R Receiver via CAT5e/6/7 cable
PAGE 16 SB-8811 INSTRUCTION & OPERATION MANUAL
INSTALLING DIAGRAM
PC RS232 Control
Blu-ray
SB-6334R
DVI DISPLAY
HDTV
DVI Extender-RX
DVI Projector
SB-100
IR-Receiver
IR Extender Cable
SB-101
IR-Transmitter
To Projector
IR Extender Cable
IR out
SB-8811 IR
SB-100
IR-Receiver
IR Extender Cable
Projector Remote Control
IR in
SB-6334T
CAT5 out
DVI in
Extender-Transmitter
PREVIEW output-1
CAT5e/6/7 Extension Cable Limited to 330 feet (100M)
DVI out
NOTE:
1. IR Control Projector Over HDBaseT Extender:
SB-6334T HDBaseT DVI Transmitter
SB-6334R HDBaseT DVI Receiver
2. Preview Output : Picture as same OUTPUT-1
3. RS-232 Control
4. External IR Remote.
5. IR Extender Transmitter :
SB-101 IR Extender Transmitter.
6. IR Extender Receiver :
SB-100 IR Extender Receiver.
Sample connection using HDBaseT Transmitter (SB-6334T DVI) and HDBaseT Receiver (SB-6334R DVI) extend
the signal via category CATx (6/6a/7) cable with distance 100M.
Use the IR Transmitters (SB-101) and IR Receiver (SB-100) to extend the IR signals to control a projector.
INPUT
PREVIEW OUTPUT-1
INPUTINPUT
2
2
OUTPUT
INPUT
3
3
OUTPUT
INPUT
4
4
OUTPUT
INPUTINPUT
5
5
OUTPUT
INPUT
6
6
OUTPUT
INPUT
8
8
OUTPUT
INPUT
1
1
OUTPUT
INPUT
7
7
OUTPUT
INPUT
SW IR In
DC 12V
Ethernet RS-232
Switch Control
8x8 DVI MATRIX SWITCHER
8811
PC Ethernet Control

TYPICAL APPLICATION
Support HDBaseT Extender by SB-6334T Transmitter and SB-6334R Receiver via CAT5e/6/7 cable
PAGE 17SB-8811 INSTRUCTION & OPERATION MANUAL
INSTALLING DIAGRAM 8x8 DVI MATRIX SWITCHER
SB-6334R
Extender-Receiver
IR Extender Cable
SB-101
IR Signal from Satellite
Receiver Remote Control
SB-100
IR-Receiver
IR Extender Cable
Satellite Receiver Remote Control
HD Satellite Receiver
SB-6334T
IR out
CAT5 out
DVI in
IR in
CAT5 in DVI out
Extender-Transmitter
NOTE :
1. IR Control Satellite Receiver Over HDBaseT
CAT5e/6/7 Extender from room:
SB-6334T HDBaseT DVI Transmitter
SB-6334R HDBaseT DVI Receiver
2. IR Extender Transmitter :
SB-101 IR Extender Transmitter.
3. IR Extender Receiver :
SB-100 IR Extender Receiver.
Sample connection using IR Transmitters (SB-101) and IR Receivers (SB-100) with SB-6334T and SB-6334R
to control a Satellite Receiver.
CAT5e/6/7 Extension Cable Limited to 330 feet (100M)
DVI DISPLAY
DVI
INPUT
PREVIEW OUTPUT-1
INPUTINPUT
2
2
OUTPUT
INPUT
3
3
OUTPUT
INPUT
4
4
OUTPUT
INPUTINPUT
5
5
OUTPUT
INPUT
6
6
OUTPUT
INPUT
8
8
OUTPUT
INPUT
1
1
OUTPUT
INPUT
7
7
OUTPUT
INPUT
SW IR In
DC 12V
Ethernet RS-232
Switch Control
8x8 DVI MATRIX SWITCHER
8811

Before making any connections to the switcher. Observe the following:
> Ensure the mains voltage supply matches the label on the supplied plug-
Pack (+/- 10%)
> Ensure that the power switch is OFF
> Ensure that all system grounds (earth) are connected to a common point.
> Avoid powering equipment within a system from multiple power sources
that may be separated by large distances
REMOTE CONTROL
REMOTE CONTROL
> Connect all audio video sources and destination equipment
> power up all source and destination audio-visual sources
> For each destination output select the appropriate input source by using
> Upon power up the switcher will return to its last used setting before
The front panel input 1~8 select buttons. The supplied IR remote control.
Or through the RS 232 serial communications port.
Powered down.
SWITCH POWER ON or OFF
1
Controller with a separate power ON and OFF
DESTINATION : 1 thru 8 OUTPUT SELECTION
Press the destination button to select the output
display channel.
2
3
FUNCTION KEY
ALL
OFF
EDID
RECALL
MEMORY
ENTER
LOCK
5
SOURCE : 1 thru 8 INPUT SOURCE SELECTION
Press input 1~8 sources with selection button
4
3
4
5
2
1
IR Remote: SW-8811
IR REMOTE CONTROL KEY :
PAGE 18 SB-8811 INSTRUCTION & OPERATION MANUAL
- function selection button
- function selection button
- function selection button
- function selection button
- function selection button
- function selection button
- function selection button
PO W ER
1 2 3 4
5 6 7 8
ON O F F
MEMORY
DESTINATION
SOURCES
RECALL
1 2 3 4
5 6 7 8
ENTER
LOCK
EDID
ALL OF F
8x8 DVI MATRIX SWITCHER
ENIRPA8811000A0
SW-8811
A15E A25D
10EF 20DF 30CF 40BF
50AF 609A 708F 807F
06F9
07F8
B04F
B34C
B44B
02FD01FE 03FC
05FA 08F7
B14E
B24DB54A
04FB
B748

IR REMOTE CUSTOM AND DATA CODES (NEC Standard)
REMOTE CONTROL
HOW TO SETUP IR CODES :
POWER ON : A15E
POWER OFF : 33CC A25D
33CC
CUSTOM CODE : 33CC
PAGE 19SB-8811 INSTRUCTION & OPERATION MANUAL
PRESS DESTINATION then PRESS SOURCE - #- #
DESTINATION #1 :
DESTINATION #2 :
DESTINATION #3 :
DESTINATION #4 :
DESTINATION #5 :
DESTINATION #6 :
DESTINATION #7 :
DESTINATION #8 :
SOURCE #1 :
SOURCE #2 :
SOURCE #3 :
SOURCE #4 :
SOURCE #5 :
SOURCE #6 :
SOURCE #7 :
SOURCE #8 :
01FE
02FD
03FC
04FB
05FA
06F9
07F8
08F7
33CC
33CC
33CC
33CC
33CC
33CC
33CC
33CC
10EF
20DF
30CF
40BF
50AF
609F
708F
807F
33CC
33CC
33CC
33CC
33CC
33CC
33CC
33CC
For example;
Select Destination # 1 to show Source #1~8,
The IR Data Code list :
Destination # 1 , Source #1
Destination # 1 , Source #2
Destination # 1 , Source #3
Destination # 1 , Source #4
Destination # 1 , Source #5
Destination # 1 , Source #6
Destination # 1 , Source #7
Destination # 1 , Source #8
33CC
33CC
33CC
33CC
33CC
33CC
33CC
33CC
10EF
10EF
10EF
10EF
10EF
10EF
10EF
10EF
33CC
33CC
33CC
33CC
33CC
33CC
33CC
33CC
01FE
02FD
03FC
04FB
05FA
06F9
07F8
08F7
ALL
OFF
EDID
LOCK
RECALL
MEMORY
ENTER
:
: 33CC
: 33CC
: 33CC
: 33CC
: 33CC
: 33CC
33CC B04F
B14E
B748
B54A
B24D
B44B
B34C

IR EXTENDER
PAGE 20 SB-8811 INSTRUCTION & OPERATION MANUAL
REAR PANEL IR EXTENDER PORT
Control Switcher SB-8811
SB-100 DISTANCE maximum ~ 984 feet (300 meters)
When you plug the External IR extender into the switcher, the front panel IR receiver remains active. Note:
IR EXTENDER PACKAGE :
HOW TO SETUP THE IR EXTENDER RECEIVER COMPONENTS
POWER
INPUT -1
1234
1234
1234
1234
HDMI MATRIX SWITCHER
ONOFF
INPUT -2
INPUT -3
INPUT -4
SW IR
Pin configuration for IR 984 feet (300 meters) Extender Receiver such as SB-100 compatible
VCC (Ring)
Signal (center)
GND (Sleeve)
Tip Ring
Sleeve
Tip: Signal
Ring :VCC
Sleeve: GND
Ring
Tip (center)
Sleeve
SB-100 IR Receiver set
IR Extender 300M Receiver
INPUT
DC 12V
Ro HS /9 5/ EC
IR EXT.
RS -232
Switcher IR EXT. In
IR Receiver (SB-100)
Cable(3C)
RS-232 IR EXT. in
SB-100 IR Receiver pack
1. SB-100 IR 300M Receiver
SB-100
IR Rx
Distance:Max.300M
SB-100C DISTANCE 2M (6feet)
SB-100C Receiver Cable
IR cable 6ft (2M)Receiver
2. SB-100C IR 2M Receiver
INPUT
DC 12V
Ro HS /9 5/ EC
IR EXT.
RS -232
Switcher IR EXT. In
IR Receiver (SB-100C)
Cable(2C)
RS-232 IR EXT. in
SB-100C
IR Rx
Distance: Max.(2M)
IR PN#: SW-8811
POWER
INPUT -1
1234
1234
1234
1234
HDMI MATRIX SWITCHER
ONOFF
INPUT -2
INPUT -3
INPUT -4
SW IR
SB-100C Receiver Cable
IR cable 6 feet (2M)Receiver
Pin configuration for IR Receiver 6 feet (2 meters) cable such as SB-100C compatible
Signal (center)
GND (Sleeve)
Tip Ring
Sleeve
Tip: Signal
Ring: NC
Sleeve: GND
Ring
Tip (center)
Sleeve
SB-100 Receiver and SB-101 Transmitter The DISTANCE maximum ~ 984 feet (300 meters)
SB-100C Receiver Cable and SB-101C Transmitter Cable The DISTANCE maximum 6 feet (2 meters)
IR PN#: SW-8811
Control Switcher SB-8811
Note:
The External IR jack has voltage on the “Ring” portion of a 3-conductor plug. Do not use a
2-conductor IR (aka:stereo plug) as this will short out the power supply.
