DIALighting IW7-10
USER MANUAL
PLEASE KEEP THIS FOR FUTURE USE

9. Maintenance and Cleaning
The following points have to be considered during the inspection:
1. All screws for installing the devices or parts of the device have to be tightly connected
and must not be corroded.
2. There must not be any deformations on the housing, color lenses, fixations and
installation spots (ceiling, suspension, trussing).
3. Mechanically moved parts must not show any traces of wearing and must not rotate
with unbalances.
4. The electric power supply cables must not show any damage, material fatigue or
sediments.
Further instructions depending on the installation spot and usage have to be adhered by
a skilled installer and any safety problems have to be removed.
In order to make the lights in good condition and extend the life time, we suggest a
regular cleaning to the lights.
1) Clean the inside and outside lens each week to avoid the weakness of the lights due
to accumulation of dust.
2) Clean the fan each week.
3) A detailed electric check by approved electrical engineer each three month, make
sure that the circuit contacts are in good condition, prevent the poor contact of circuit
from overheating.
We recommend a frequent cleaning of the device. Please use a moist, lint- free cloth.
Never use alcohol or solvents.
There are no serviceable parts inside the device. Please refer to the instructions under
“Installation instructions”.
.10.
1. Unpacking
Thank you for choosing our products . For your own safety, please read this manual
before installing the device. This manual covers the important information on installation
and applications. Please install and operate the fixture with followinginstructions.
Meanwhile, please keep this manual well for future needs.
Super beam light is made of a new type of high temperature strength of engineering
plastics and cast aluminum casing with nice outlook. The fixture is designed and
manufactured strictly following CE standards, complying with international standard
DMX512 protocol. It’s available independently controlled and linkable with each other for
operation. And it is applicable for large-scale live performances, theater, studio,
nightclubs and discos.
The adopt 7pcs 10W LEDs which features high brightness and stability. Please
carefully unpack it when you receive the fixture and check whether it is damaged during
the transportation. And please check whether the following items are included inside the
box:
Moving Head---------One Signal Cable----One
Hanging Bracket-------One Power Cable----One
User Manual----One
.1.

2. Safety Instructions
This device has left the factory in perfect condition. In order to maintain this condition
and to ensure a safe operation, it is absolutely necessary for the user to follow the
safety instructions and warning notes written in this user manual.
If the device has been exposed to temperature changes dueto environmental
changes, do not switch it on immediately. The arising condensation could damage the
device. Leave the device switched off until it has reached room temperature.
This device falls under protection-class I. Therefore it is essential that the device be
earthed.
The electric connection must carry out by qualified person.
The device shall only be used with rate voltage and frequency.
Make sure that the available voltage is not higher than stated at the end of this
manual.
Make sure the power cord is never crimped or damaged by sharp edges. If this would
be the case, replacement of the cable must be done by an authorized dealer.
Always disconnect from the mains, when the device is not in use or before cleaning it.
Only handle the power cord by the plug. Never pull out the plug by tugging the power
cord.
During initial start-up some smoke or smell may arise. This is a normal process and
does not necessarily mean that the device is defective, it should decrease gradually.
Please don't project the beam onto combustible substances.
Fixtures cannot be installed on combustible substances, keep more than 50cm
distance with wall for smooth air flow, so there should be no shelter for fans and
ventilation for heat radiation.
If the external flexible cable or cord of the luminaire was damaged, it shall
be exclusively replaced by the manufacturer or his service agent or a similar qualified
person in order to avoid a hazard.
.2.
19 ch annel s mode
Channel
Function
DMX
Value
Description
1
Pan
0-255
0~540 degree
2
Pan fine adjustment
0-255
16bit
3
Tilt
0-255
0~270 degree
4
Tilt fine adjustment
0-255
16bit
5
Pan/Tilt speed
0-255
Pan/Tilt speed from fast to slow
6
Lens rotation(Beam)
0-127
The distance between beams from
near to far(Angle from small to big)
128-190
Rotate Clockwise –unlimited from
fast to slow
191-255
Counter-clockwise –unlimited from
slow to fast
7
Color wheel
0-255
Color wheel rotation
8
Macro dimming
0-255
Linear dimming from dark to bright
9
Strobe
0-255
Strobe from slow to fast
10
Led 1 dimming
0-255
Linear dimming from dark to bright
11
Led 2 dimming
0-255
Linear dimming from dark to bright
12
Led 3 dimming
0-255
Linear dimming from dark to bright
13
Led 4 dimming
0-255
Linear dimming from dark to bright
14
Led 5 dimming
0-255
Linear dimming from dark to bright
15
Led 6 dimming
0-255
Linear dimming from dark to bright
16
Led 7 dimming
0-255
Linear dimming from dark to bright
17
Light effects show
0-4
Black out
5-7
Static effect 1
8-10
Dynamic effect 1
11-13
Static effect 2
14-16
Dynamic effect 2
…….
……………
…………
……………….
233-235
Static effect 39
236-238
Dynamic effect 39
239-242
Static effect 40
18
Speed of effects show
0-255
From fast to slow
19
Reset
0-249
No function
250-255
Reset within 6 seconds
.9.

3. Operation Instructions
-The moving head is for beam light and effect use.
-Don’t turn on the fixture if it’s been through severe temperature difference like after
transportation because it might damage thelight due to the environment changes.
So make sure to operate the fixture until it is in normal temperature.
-This light should be keep away from strong shaking during any transportation or
movement.
-Don’t pull up the light by only the head, or it might cause damages to the
mechanical parts.
-Don’t expose the fixture in overheat, moisture or environment with too much dust
when installing it. And don’t lay any power cables on the floor. Or it might cause
electronic shock to the people.
-Make sure the installation place is in good safety condition before installing the
fixture.
-Make sure to put the safety chain and check whether the screws are screwed
properly when installing the fixture.
-Make sure the lens are in good condition. It’s recommended to replace the units if
there are any damages or severe scratch.
-Make sure the fixture is operated by qualified personnel who knows the fixture
before using.
-Keep the original packages if any second shipment is needed.
-Don’t try to change the fixtures without any instruction by the manufacturer or the
appointed repairing agencies.
-It is not in warranty range if there are any malfunctions from not following the user
manual to operate or any illegal operation, like shock short circuit, electronic shock,
lamp broke, etc.
.3.
8. DMX Channels details
12 channels mode
Channel
Function
DMX Value
Description
1
Pan
0-255
0~540 degree
2
Tilt
0-255
0~270 degree
3
Pan/Tilt speed
0-255
Pan/Tilt speed from fast to slow
4
Lens
rotation(Beam)
0-127
The distance between beams from
near to far(Angle from small to big)
201-255
Rotation without limitation from slow
to fast
5
Color wheel
0-255
Color wheel rotation
6
Macro dimming
0-255
Linear dimming from dark to bright
7
Strobe
0-255
Strobe from slow to fast
8
Led 7 dimming
0-255
Linear dimming from dark to bright
9
Led 1-LED 6
dimming
0-255
Linear dimming from dark to bright
10
Light effects
show
0-4
Black out
5-7
Static effect 1
8-10
Dynamic effect 1
11-13
Static effect 2
14-16
Dynamic effect 2
…….
……………
…………
……………….
233-235
Static effect 39
236-238
Dynamic effect 39
239-242
Static effect 40
243-255
Dynamic effect 40
11
Speed of effects
show
0-255
From fast to slow
12
Reset
0-249
No function
250-255
Reset within 6 seconds
.8.

4. Specifications:
Voltage: AC90-240V 50-60Hz
Power: 90W
Led source: 7pcs high brightness 10W CREE white LEDs
Beam angle: 5-40° Strobe: 1-25 Hz
Dimmer: 0-100% linear dimmer with 16 bit without strobe
Pan: 540°+ fine Tilt: 250°+ fine
Color: With a 6 colors wheel to create colorful effect.
Channel: 12/19 DMX double channels mode
Control: DMX512/Master-slave/Auto/Sound activated
Function:
1. Strong beam light effect, beam angle is optional, beam light with macro effect.
2. Each bulb is controllable, with racing light effect.
3. B-eye designed Lens can rotate without limitation to create dynamic and
amazing effect. Can separate to colorful beams or gather to one strong beam.
4. Perfect beam light and effect light for disco, club, show, etc.
5. Smaller size but excellent effect to make installation as easy as you can
imagine.
5. Installation instruction:
Cautions: For added protection mount the fixtures in areas outside walking paths,
seating areas, or in areas were the fixture might be reached by
unauthorized personnel.
Before mounting the fixture to any surface, make sure that the installation area can
hold a minimum point load of 10 times the device’s weight.
Fixture installation must always be secured with a secondary safety attachment, such
as an appropriate safety cable.
Never stand directly below the device when mounting, removing, or servicing the
fixture.
From a ceiling, or ser on a flat level surface (see illustration below). Be sure the fixture
is kept at least 0.5 m away from any flammable materials.
Always use and install the supplied safety cable as a safety measure to prevent
accidental damage caused by the clamp fails.
.4.
7. Control Panel Menu Instruction
Menu Panel
Function
d
Set the DMX address
To choose the channel mode
Pan auto Run
Tilt auto Run
LENS auto Run
Color wheel auto Run
Auto Run mode 5
Sound activated mode
Pan reverse movement
Pan forward movement
Tilt reverse movement
Tilt forward movement
Display reverse 180°
Display forward 180°
Pan movement by manual control
Tilt movement by manual control
LENS rotation by manual control
Color wheel rotation by manual control
Hall Real-time status
number
Pan sensor Real-time status
number
Tilt sensor Real-time status
number
Fixture working time
Software version
Reset on
Reset off
.7.

Mounting points: Overhead mounting requires extensive experience, including amongst
others calculating working load limits, a fine knowledge of the installation material being
used, and periodic safety inspection of all installation material and the fixture. If you lack
these qualifications, do not attempt the installation yourself. Improper installation can
result in bodily injury.
Be sure to complete all rigging and installation procedures before connecting the main
power cord to the appropriate wall outlet.
Clamp Mounting: The LED BEAM provides a unique mounting bracket assembly that
integrates the bottom of the base, the included “Omega Bracket,” and the safety cable
rigging point in one unit (see the illustration below). When mounting this fixture to truss
be sure to secure an appropriately rated clamp to the included omega bracket using a
M10 screw fitted through the center hole of the “omega bracket”. As an added safety
measure be sure to attached at least one properly rated safety cable to the fixture using
on of the safety cable rigging point integrated in the base assembly
Regardless of the rigging option you choose for your LED super beam, always be sure to
secure your fixture with a safety cable. The fixture provides a built-in rigging point for a
safety cable on the hanging bracket as illustrated above. Be sure to only use the
designated rigging point for the safety cable and never secure a safety cable to a
carrying handle.
.5.
6. DMX-512 control connections
Connect the provided XLR cable to the female 3-pin XLR output of your controller and
the other side to the male 3-pin XLR input of the moving head. You can chain multiple
Moving head together through serial linking. The cable needed should be two core,
screened cable with XLR input and output connectors. Please refer to the diagram
below.
DMX-512 connection with DMX terminator
Controller
For installations where the DMX cable hasto run a long distance or is in an electrically
noisy environment, such as in a discotheque, it is recommended to use a DMX
terminator. This helps in preventing corruption of the digital control signal by electrical
noise. The DMX terminator is simply an XLR plug with a 120 Ω resistor connected
between pins 2 and 3,which is then plugged into the output XLR socket of the last
fixture in the chain. Please see illustrations below.
1
2
3
PI N 3
PI N 2
120 Ω
.6.
