Show Tec COMPACT POWER LIGHTSET 4 RGBW User manual

Compact Power Lightset 4 RGBW V1
Highlit e I nt ernat ional B.V. –Vest ast raat 2 –6468 EX –K erkrade –t he Net herlands
Ordercode: 30277
MANUAL
ENGLISH

1
Ordercode: 30277
Compact Power Lightset 4 RGBW
Table of contents
Warning........................................................................................................................................................... 2
Safety Instructions........................................................................................................................................ 2
Operating Determinations ........................................................................................................................... 4
Rigging........................................................................................................................................................ 4
Connection with the mains.......................................................................................................................... 4
Return Procedure......................................................................................................................................... 5
Claims......................................................................................................................................................... 5
Description of the device................................................................................................................................. 6
Optional accessories ................................................................................................................................... 6
Backside...................................................................................................................................................... 7
Installation....................................................................................................................................................... 7
Set Up and Operation ...................................................................................................................................... 7
Control Modes............................................................................................................................................. 7
One Compact Power Lightset 4 RGBW (Sound-control)............................................................................. 8
One Compact Power Lightset 4 RGBW (Manual control) ........................................................................... 8
One Compact Power Lightset 4 RGBW (Auto Run, Built-in programs).......................................................... 8
Multiple Compact Power Lightsets 4 RGBW (Master/Slave control)............................................................. 8
Multiple Compact Power Lightsets 4 RGBW (DMX512 Mode)...................................................................... 9
Fixture Linking ............................................................................................................................................ 10
Data Cabling............................................................................................................................................. 10
Control Panel............................................................................................................................................. 11
DMX Control Mode.................................................................................................................................... 11
DMX Addressing ........................................................................................................................................ 11
Menu overview.............................................................................................................................................. 12
Main Menu Options ................................................................................................................................... 13
1. DMX Mode....................................................................................................................................... 13
2. Built-in Programs............................................................................................................................... 13
3. Auto Run Program ............................................................................................................................ 14
4. Info .................................................................................................................................................. 14
5. Settings ............................................................................................................................................ 14
6. Sound control Mode......................................................................................................................... 15
7. Manual Mode (Static color mode).................................................................................................... 16
8. Slave Mode...................................................................................................................................... 16
Footswitch................................................................................................................................................. 16
DMX Channels........................................................................................................................................... 17
4 channels.............................................................................................................................................. 17
5 channels.............................................................................................................................................. 17
6 channels.............................................................................................................................................. 19
8 channels.............................................................................................................................................. 20
10 channels ............................................................................................................................................ 21
16 channels ............................................................................................................................................ 23
19 channels ............................................................................................................................................ 25
Maintenance................................................................................................................................................. 27
Replacing a Fuse....................................................................................................................................... 27
Troubleshooting ............................................................................................................................................. 27
No Light..................................................................................................................................................... 27
No Response to DMX ................................................................................................................................. 28
Product Specifications ................................................................................................................................... 29
Dimensions.................................................................................................................................................... 30

2
Ordercode: 30277
Compact Power Lightset 4 RGBW
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear to be damaged from shipping or the carton
itself shows signs of mishandling. Save the carton and all packing materials. In the event that the fixture
must be returned to the factory, it is important that the fixture be returned in the original factory box and
packing.
Your shipment
includes:
Showtec Compact
Power Lightset 4
RGBW
•Stand, T-bar, carrying
bag and hard case
incl.
•IEC powercable 5,0m
•2 safety eyes
•User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
●be qualified
●follow the instructions of this manual

3
Ordercode: 30277
Compact Power Lightset 4 RGBW
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty. This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non -observance of
this manual or any unauthorized modification to the device.
Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Never use anything to cover the ground contact.
Never place any material over the lens.
Never look directly into the light source.
Never leave any cables lying around.
Do not insert objects into air vents.
Do not connect this device to a dimmerpack.
Do not switch the device on and off in short intervals, as this would reduce the device’s lifespan.
Do not touch the device’s housing bare-handed during its operation. Allow the fixture to cool for at
least 5 minutes before handling.
Do not shake the device. Avoid brute force when installing or operating the device.
Only use device indoor, avoid contact with water or other liquids.
Only operate the fixture after having checked that the housing is firmly closed and all screws are
tightly fastened.
Only operate the device after having familiarized with its functions.
Avoid flames and do not put close to flammable liquids or gases.
Always keep case closed while operating.
Always allow free air space of at least 50 cm around the unit for ventilation.
Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord by the plug. Never pull out the plug by tugging the power cord.
Make sure that the device is not exposed to extreme heat, moisture or dust.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
If the lens is obviously damaged, it has to be replaced to prevent its functions from being impaired,
due to cracks or deep scratches.
If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
For adult use only. Device must be installed out of reach of children. Never leave the unit running
unattended.
Never attempt to bypass the thermostatic switch or fuses.
For replacement, use fuses of same type and rating only.
The user is responsible for correct positioning and operating of the Compact Power Lightset 4 RGBW.
The manufacturer will not accept liability for damages caused by the misuse or incorrect installation
of this device.
This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
Repairs, servicing and electrical connection must be carried out by a qualified technician.
WARRANTY: Till one year after date of purchase.

4
Ordercode: 30277
Compact Power Lightset 4 RGBW
Operating Determinations
●This device is not designed for permanent operation. Regular operation breaks will ensure that the
device will serve you for a long time without defects.
●The minimum distance between light-output and the illuminated surface must be bigger than 1
meter.
●The maximum ambient temperature ta = 40°C must never be exceeded.
●The relative humidity must not exceed 50 % w ith an ambient temperature of 40° C.
●If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
●Any other operation may lead to dangers like short -circuit, burns, electric shock, crash etc.
You endanger your own safety and the safety of others!
Rigging
Please follow t he European and nat ional guidelines concerning rigging, trussing and all
ot her safetyissues.
Do not attempt the installation yourself!
Always let the installation be carried out by an aut horized dealer!
Procedure:
If the Compact Power Lightset 4 RGBW is lowered from the ceiling or high joists, professional
trussing systems have to be used.
Use a clamp to mount the Compact Power Lightset 4 RGBW, with the mounting-bracket, to the
trussing system.
The Compact Power Lightset 4 RGBW must never be fixed swinging freely in the room.
The installation must always be secured with a safety attachment, e.g. an appropriate safety net
or safety-cable.
When rigging, derigging or servicing the Compact Power Lightset 4 RGBW, always make sure, that
the area below the installation place is blocked and staying in the area is forbidden.
The Compact Power Lightset 4 RGBW can be placed on a flat stage floor or mounted to any kind of truss
by a clamp.
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure t hat the device is always connect ed properly t o t he earth!
Improper inst allation can cause serious damage t o people and propert y!

5
Ordercode: 30277
Compact Power Lightset 4 RGBW
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause of the
return. Be sure to properly pack fixture as any shipping damage resulting from inadequate packaging is
the customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name.
02) Your address.
03) Your phone number.
04) A brief description of the symptoms.
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short -
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that the fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period, complaints will not be handled anymore.
Complaints will only be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

6
Ordercode: 30277
Compact Power Lightset 4 RGBW
Description of the device
Features
The Showtec Compact Power Lightset 4 RGBW is a T-bar with 4 LED spots on a light stand, packed in a
hard case and a carrying bag for the stand. It is a plug and play set that offers internal chase programs
but also can be controlled by DMX or with the optional available footswitch.
•T-Bar with built-in controller
•4-in-1 RGBW LEDs
•Stand included
•Carrying bag included
•Power Supply: 100-240V AC, 50/60Hz
•Drive current: 330 mA
•Refresh rate: 7,8 Khz
•Control Mode: DMX512
•LED Source: 5x 4-in-1 RGBW LEDs 4W (per spot)
•Dimmer: 0-100%
•Strobe: 0-20Hz
•Beam angle: 25°
•Consumption Power: 90 Watt
•3 pin female XLR socket and 3 pin male XLR socket
•IEC Power In and Out (10a)
•Linkable via 3-pin XLR cable
•Built-in microphone
•Housing: Black Aluminum and Iron
•LCD display
•Fuse: 5S1.5A / 250V
•Cooling: Aluminum heat sink
•IP rating: IP-20
•Control mode: DMX512, Sound, Stand-alone, Master/slave, Optional footswitch
•Selectable 4, 5, 6, 8, 10, 16 and 19 DMX channel operation
•Dimensions T-bar + 4 parcans: 845 x 55 x 70 mm (LXWXH)
•Weight T-bar + 4 parcans: 7,3 kg
Note: Knowledge of DMX is required to fully utilize this unit.
Optional accessories
30267 Footswitch
D7026 Case for 4X compact lightsets

7
Ordercode: 30277
Compact Power Lightset 4 RGBW
Backside
Fig. 01
01) IEC Power Out (10a)
02) 5x 4-in-1 RGBW LEDs 4W (per spot)
03) Footswitch input
04) DMX signal connector (IN) 3-pin
05) DMX signal connector (OUT) 3-pin
06) Menu Buttons + LCD display
07) IEC Power In + Fuse: 5S1.5A / 250V
08) Ground/Earth connection
09) IEC Power Out (10a)
Installation
Remove all packing materials from the Compact Power Lightset 4 RGBW.
Check that all foam and plastic padding is removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.
Control Modes
There are 6 modes:
Sound-controlled
Manual mode (Static)
Auto Run
Built-in Programs
Master/Slave
DMX-512 (4, 5, 6, 8, 10, 16, 19CH)

8
Ordercode: 30277
Compact Power Lightset 4 RGBW
One Compact Power Lightset 4 RGBW (Sound-control)
01) Fasten the effect light onto firm trussing or place it on the floor. Leave at least 0,5 meter on all sides
for air circulation.
02) When the Compact Power Lighset is not connected by a DMX-cable, it functions as a stand-alone
device.
03) Turn on the music. If device is set to (Audio), then the fixture will react to the beat of the
music. Please see page 13 for more information about the Sound-controlled mode.
One Compact Power Lightset 4 RGBW (Manual control)
01) Fasten the effect light onto firm trussing or place it on the floor. Leave at least 0,5 meter on all sides
for air circulation.
02) When the Compact Power Lightset is not connected by a DMX-cable, it functions as a stand-alone
device.
03) If device is set to , then the fixture can be manually controlled.
04) Please see page 13 for more information about the Manual control mode.
One Compact Power Lightset 4 RGBW (Auto Run, Built-in programs)
01) Fasten the effect light onto firm trussing or place it on the floor. Leave at least 0,5 meter on all sides
for air circulation.
02) When the Compact Power Lightset is not connected by a DMX-cable, it functions as a stand-alone
device.
03) If device is set to or , then the fixture will play one of its built-in programs or show its
auto run mode. Please see pages 15-16 for more information about the built-in programs or auto run
mode.
Multiple Compact Power Lightsets 4 RGBW (Master/Slave control)
01) Fasten the effect light onto firm trussing or place it on the floor. Leave at least 0,5 meter on all sides
for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) Use a 3-p XLR cable to connect the Compact Power Lightsets and other devices.
The pins:
1. Earth
2. Signal (-)
3. Signal (+)
04) Link the units as shown in Fig. 02, connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second and third units. You can use the
same functions on the master device as described on pages 13-16 (Sound controlled, Manual
control, Auto run, Built-in Programs). This means you can set your desired operation mode on the
master device and all slave devices will react the same as the master device.
Multiple Compact Power Lightsets 4 RGBW (Master/Slave control)
Fig. 02

9
Ordercode: 30277
Compact Power Lightset 4 RGBW
Multiple Compact Power Lightsets 4 RGBW (DMX512 Mode)
01) Fasten the effect light onto firm trussing or place it on the floor. Leave at least 0,5 meter on all sides
for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) Use a 3-p XLR cable to connect the Compact Power Lightsets and other devices.
04) Link the units as shown in Fig. 03, Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second and third units.
05) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.
Multiple Compact Power Lightsets 4 RGBW DMX Set Up
Fig. 03
Note: Link all cables before connecting electric power!

10
Ordercode: 30277
Compact Power Lightset 4 RGBW
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX -512 controller or to
run synchronized shows on two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixt ures the
data link can support.
The Compact Power Lightsets 4 RGBW uses up to 19 channels.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin. Ordercode
FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
•DAP Audio DMX adapter: 3-pin/5-pin. Ordercode FLA30.

11
Ordercode: 30277
Compact Power Lightset 4 RGBW
Control Panel
A. LCD Display
B. Mode button
C. Setup Button
D. Up Button
E. Down Button
Fig. 04
DMX Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address the next time.)
DMX Addressing
The control panel on the backside of the device allows you to assign the DMX fixture address, which is
the first channel from which the Compact Power Lightset 4 RGBW will respond to the controller. Please
note when you use the controller, the unit has up to 19 channels. When using multiple Compact Power
Lightsets 4 RGBW, make sure you set the DMX addresses right. Therefore, the DMX address of the first
Compact Power Lightset 4 RGBW should be 1(001); the DMX address of the second Compact Power
Lightset 4 RGBW should be 1+19=20 (020); the DMX address of the third Compact Power Lightset 4 RGBW
should be 20+19=39 (039), etc. Please, be sure that you do not have any overlapping channels in order
to control each Compact Power Lightset 4 RGBW correctly. If two or more Compact Power Lightsets 4
RGBW are addressed similarly, they will work similarly.
Controlling:
After having addressed all Compact Power Lightsets 4 RGBW, you may now start operating these via
your lighting controller.
Note: After switching on, the Compact Power Lightset 4 RGBW will automatically detect whether DMX
512 data is received or not. The problem may be:
•The XLR cable from the controller is not connected with the input of the Compact Power Lightset 4
RGBW.
•The controller is switched off or defective, the cable or connector is defective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert a XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 10 seconds
It is possible to set a time for turning off the display. When no button is pressed for 10, 20, 30 or 60 seconds,
the display will turn off. To light up the display, you have to press the Mode, Setup, Up or Down buttons.
Once you have pressed the button, the display will light up.

12
Ordercode: 30277
Compact Power Lightset 4 RGBW
Menu overview

13
Ordercode: 30277
Compact Power Lightset 4 RGBW
Main Menu Options
1. DMX mode
2. Built in programs
3. Auto run
4. Info
5. Settings
6. Sound-controlled mode
7. Manual mode (Static color mode)
8. Slave mode
1. DMX Mode
With this menu you can set the DMX address and choose a DMX configuration.
01) Press the Mode button until the display shows .
02) You can choose 512 different DMX addresses.
03) Use the Up/Down buttons to select the required address between .
04) If you press the Setup button, you can choose a different DMX Mode. Select a DMX channel mode
between .
The display will blink.
2. Built-in Programs
With this menu you can choose a built-in program.
01) Press the Mode button, until the display shows .
02) You can choose between 24 built-in programs by using the Up and Down buttons.
03) If you choose and you press Setup you can choose between 33 colors with the Up/Down
buttons.
04) Press Setup again and you can set the strobe frequency ( ) by using the
Up/Down buttons.
05) Press the Mode button to go back one step.
06) With the Up/Down buttons you can choose between .
07) Press the Setup button to set the speed or strobe frequency from the program.

14
Ordercode: 30277
Compact Power Lightset 4 RGBW
08) Use the Up/Down buttons to set the speed between 001-100 and strobe frequency between 000-099.
3. Auto Run Program
With this menu you can activate the Auto run mode of the Compact Power Lightset 4 RGBW.
01) Press the Mode button on the device until the display shows .
02) The Compact Power Lightset 4 RGBW will start automatically with its built-in program.
4. Info
With this menu you can view 2 info’s about the device.
01) Press the Mode button until the display shows .
02) Press the Setup button to open the menu.
03) Press the Up/Down buttons to choose .
04) Press the Setup button to open the menu.
05) You can now see the current software version .
5. Settings
With this menu you can adjust the settings of the device.
01) Press the Mode button until the display shows .
02) Press the Setup button to open the menu.
03) Press the Up/Down buttons to choose between the 6 available options, , , ,
, and .
04) Press the Setup button to open one of the 6 options.
05) In the submenu you can select one of the 4 dimming curves, by pressing the Up/Down
buttons.

15
Ordercode: 30277
Compact Power Lightset 4 RGBW
06) With the menu option , you can set the dimmer speed, by pressing the Up/Down buttons.
You can choose between Smooth or Fast.
07) In the menu you can set how long the display will remain ON, when no button is pressed.
08) Press the Up/Down buttons to choose between 10, 20, 30 or 60 seconds. If you choose the option
“ON”, the display will remain continuously ON, when no button is pressed.
09) The menu option is for resetting the device to the factory settings.
10) Press the Setup button to open the menu and then press the Up/Down buttons to choose Yes or No.
11) Press the Setup button again to confirm your choice. If you have chosen Yes, the factory settings will
be restored. The fixture will start up in the Auto Run mode.
12) In the menu option you can set the device to Off or Hold.
13) If you choose Off the fixture will blackout when there is no DMX signal.
14) If you choose Hold the fixture will remember the last settings and will not go out when there is no DMX
signal.
15) In the menu option you can choose between ON or OFF.
16) If you choose ON, you activate the tool which helps to keep multiple fixtures synchronized when
using them in master slave mode, even after a certain amount of time.
6. Sound control Mode
With this menu you can set the sound sensitivity of the device.
01) Press the Mode button until the display shows .
02) Press the Setup button to open the menu.
03) Press the Up/Down buttons to set the sound sensitivity. The adjustment range is between
, from OFF to high sound sensitivity.

16
Ordercode: 30277
Compact Power Lightset 4 RGBW
7. Manual Mode (Static color mode)
With this menu you can create a static color.
01) Press the Mode button until the display shows .
02) Press the Setup button to open the menu.
03) With the Setup button you can scroll through the colors Red, Green, Blue and White.
04) With the Up/Down buttons you can set the intensity of the colors. The adjustment range is between
000-255 , from OFF to maximum intensity.
8. Slave Mode
With this menu you can set the device as a slave device.
01) Press the Mode button until the display shows .
02) If the device has not been set to slave, it is automatically classified as a master device. All slave
devices will follow the master movement. If the device has been set to slave, it will react the same as
its master device.
Footswitch
7. Footswitch Function (footswitch (30267) not included !)
01) Step on the Auto Run pedal to enter the auto running mode.
02) Step on the Music pedal to enter the sound active mode.
03) Step on the Freeze pedal to pause the function; Step on this pedal again to restart operation.
04) Step on the Blackout pedal to turn off all lights and then step on it again to enter the previ ous mode.
Foot pedal (30267) separately available

17
Ordercode: 30277
Compact Power Lightset 4 RGBW
DMX Channels
4 channels
Channel 1 –Red Dimmer intensity
0-255
Gradual adjustment Red from 0-100%
Channel 2 –Green Dimmer intensity
0-255
Gradual adjustment Green from 0-100%
Channel 3 –Blue Dimmer intensity
0-255
Gradual adjustment Blue from 0-100%
Channel 4 –White Dimmer intensity
0-255
Gradual adjustment White from 0-100%
5 channels
Channel 1 –Master Dimmer
0-255
Gradual adjustment, from dark to brightest 0-100%
Channel 2 –Linear Strobe (CH1 must be set between 001-255 )
0-10
Off
11-255
Linear strobe intensity, from low to high frequency
Channel 3 –Color presets (CH1 must be set between 001-255 )
0-7
No function
8-13
Color 1 (R255, G000, B000, W000)
14-20
Color 2 (R255, G000, B000, W100)
21-27
Color 3 (R255, G000, B000, W200)
28-34
Color 4 (R255, G050, B000, W000)
35-41
Color 5 (R255, G150, B000, W000)
42-48
Color 6 (R255, G255, B000, W000)
49-55
Color 7 (R255, G255, B000, W075)
56-62
Color 8 (R000, G255, B000, W255)
63-69
Color 9 (R000, G255, B000, W150)
70-76
Color 10 (R000, G255, B000, W050)
77-83
Color 11 (R000, G255, B000, W000)
84-90
Color 12 (R000, G255, B050, W000)
91-97
Color 13 (R000, G255, B150, W000)
98-104
Color 14 (R000, G255, B255, W000)
105-111
Color 15 (R000, G255, B255, W075)
112-118
Color 16 (R000, G255, B255, W150)
119-125
Color 17 (R000, G100, B255, W255)
126-132
Color 18 (R000, G000, B255, W100)
133-139
Color 19 (R000, G000, B255, W050)
140-146
Color 20 (R000, G000, B255, W000)
147-153
Color 21 (R075, G000, B255, W000)
154-160
Color 22 (R160, G000, B255, W000)
161-167
Color 23 (R255, G000, B255, W000)
168-174
Color 24 (R255, G000, B175, W000)
175-181
Color 25 (R255, G000, B100, W000)
182-188
Color 26 (R255, G000, B100, W050)
189-195
Color 27 (R255, G000, B025, W050)
196-202
Color 28 (R255, G000, B025, W025)
203-209
Color 29 (R255, G000, B025, W000)

18
Ordercode: 30277
Compact Power Lightset 4 RGBW
210-216
Color 30 (R000, G000, B000, W255)
217-223
Color 31 (R075, G075, B000, W255)
224-230
Color 32 (R000, G000, B100, W255)
231-255
Color 33 (R255, G255, B255, W255)
Channel 4 –Color running (CH1 must be set must between 001-255 )
0-5
No function
6-15
Program 01
16-25
Program 02
26-35
Program 03
36-45
Program 04
46-55
Program 05
56-65
Program 06
66-75
Program 07
76-85
Program 08
86-95
Program 09
96-105
Program 10
106-115
Program 11
116-125
Program 12
126-135
Program 13
136-145
Program 14
146-155
Program 15
156-165
Program 16
166-175
Program 17
176-185
Program 18
186-195
Program 19
196-205
Program 20
206-215
Program 21
216-225
Program 22
226-235
Program 23
236-255
Sound-controlled
Channel 5 –Program Speed (CH4 must be set between 006-235 )
0-255
Gradual speed adjustment, from slow to fast
Channel 5 –Sound Sensitivity (CH4 must be set between 236-255 )
0-255
Gradual sound sensitivity from low sensitivity to high sensitivity

19
Ordercode: 30277
Compact Power Lightset 4 RGBW
6 channels
Channel 1 –Master Dimmer
0-255
Gradual adjustment, from dark to brightest 0-100%
Channel 2 –Linear Strobe (CH1 must be set between 001-255 )
0-10
Off
11-255
Linear strobe intensity, from low to high frequency
Channel 3 –Red color intensity (CH1 must be set between 001-255 )
0-255
Gradual adjustment Red from 0 –100%
Channel 4 –Green color intensity (CH1 must be set between 001-255 )
0-255
Gradual adjustment Green from 0 –100%
Channel 5 –Blue color intensity (CH1 must be set between 001-255 )
0-255
Gradual adjustment Blue from 0 –100%
Channel 6 –White color intensity (CH1 must be set between 001-255 )
0-255
Gradual adjustment White from 0 –100%
