Event Lighting F100WWMZ User manual

F100/F200/F300WWMZ
100/200/300 W Warm White Fresnel
USER MANUAL
For your safety, please read this user manual carefully before initial use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications
within this manual are subject to change without notice. Event Lighting assumes no liability or
responsibility for any errors or omissions. Please consult Event Lighting for any clarification or
information regarding this item.
Version: A109.1

www.event-lighting.com.au
2
Safety Instructions
Warning
• Do not open this device, there are no user serviceable parts inside. Risk of electric
shock.
• Do not look at the light source when the device is on.
• CAUTION: This unit’s housing may become hot during and after operation.
• Install this device in a location with adequate ventilation, at least 20 inches (50 cm) from
adjacent surfaces.
• Do not leave any flammable material within 20 inches (50 cm) of this unit while operating
or connected to power.
• Use a safety chain when mounting the device overhead.
• Do not operate this device outdoors or in any location where dust, excessive heat, water
or humidity may affect it.
• Do not operate this device if the housing, lenses, or cables appear damaged.
• Do not connect this device to a dimmer or rheostat.
• Only connect this device to a grounded and protected circuit.
• Only use the hanging bracket to carry this device.
• In case of a serious problem, stop using this device immediately.
• Do not operate this device at ambient temperatures higher than 40° C (104° F).
Power Input and Power Linking
This device has an auto-switching power supply that works with 100-240 V AC, 50/60 Hz input.
Link up to the maximum of 8A. DO NOT exceed this.
Fuse Replacement
If the fine wire fuse of the device fuses, replace it with one of the same type and rating. Before
replacing the fuse, disconnect from mains power.
Procedure:
1. Unscrew the fuse holder on the rear panel from the housing with a fitting screwdriver.
2. Remove the old fuse from the fuse holder.
3. Install the new fuse in the fuse holder
4. Replace the fuse holder in the housing and secure it.
Product Installation
This device can be mounted in many orientations provided each individual device is secured by
the use of the correct mounting bracket. Use a safety chain when mounting this device overhead.

www.event-lighting.com.au
3
Dimensions
Lux Chart
Control Panel Operation
Menu – Move up one level.
Up – Move up one item.
Down – Move down one item.
Enter – Move down one level / confirm selection.

www.event-lighting.com.au
4
Menu
Level 1
Level 2
Value
Information
DMX
DMX address
1-512
Set DMX address
CHAN
CH01
Use 1 channel mode
CH02
Use 2 channel mode
CH03
Use 3 channel mode
Manual
DIM
0-255
Manual control of Dimmer
D_F
0-255
Manual control of Dimmer-Fine
STO
0-255
Manual control of Strobe
CURVE
Linear
Linear dimming curve
Log
Logarithmic dimming curve
S
S dimming curve
Reset
YES/NO
Reset to factory default
TEMP
C.000
Current fixture temperature
FAN
Max
Fastest fan speed
Auto
Variable fan speed, based on thermal sensor
Silent
Theatre mode, meets the Nr25 standard
FADE
ON/OFF
Enable/disable fade time on dimming
VERSION
A109.01
Software version
Press Up and Down to select the desired operation, press Enter to select.
Set DMX Address
Select “DMX” then press Enter.
Use Up and Down to set the desired DMX address from 1 to 512.
Press Enter to confirm and save.
Set DMX Channel Mode
Select “Chan” then press Enter.
Use Up and Down to set the desired DMX channel mode.
Press Enter to confirm and save.
Refer to the DMX Chart below for more information on each mode.
Set Dimmer Curve
Select “Curve” then press Enter.
Use Up and Down to set the desired dimmer curve.
Press Enter to confirm and save.
Set Manual Control
Set the Dimmer, Dimmer Fine and Strobe values through the control panel.
• Strobe speed 0 is always on, 1-100, strobe slow to fast.
Factory Reset
Select reset and press Enter twice to reset the device to factory default settings.

www.event-lighting.com.au
5
DMX Chart
• This fixture is controlled by the universal DMX 512 protocol. The DMX address is the first
channel used to receive instructions from the external controller. For independent control,
each fixture must be assigned a unique address for each of its control channels. For
example, this device has three channel modes: 1/2/3, if it’s set to 3 channel mode, and
there are several fixtures need to be independently controlled, we just simply address
first fixture at 1, and second fixture at 4, third one at 7, etc.
• If multiple fixtures have the same DMX address, they will behave synchronically.
• Display will flash when no DMX signal is received.
Mode/Channel
Min.
DMX
Max.
DMX
Function
1 Ch
2 Ch
3 Ch
1
1
1
0
255
Dimmer
2
2
0
255
Dimmer-Fine
3
0
255
Strobe, slow to fast

www.event-lighting.com.au
6
Technical Specifications
F100WWMZ
Photometrics
• Light Source: 100 W 3,000K COB LED
• CRI: 90
• Beam Angle: 12°~25°
• Field Angle: 30°~65°
• Output: 4928 lux @ 2.5 m @ 12°, 2005 lux @ 2.5 m @ 25°
• Lens: 150 mm Fresnel
• PWM: 8,000 Hz
• LED Lifespan: 50,000 hours
Effects
• Dimming: 0~100% 8 / 16-bit
• Strobe: 1~25 Hz
• Zoom: Manual Zoom 12°~25°
• Barn Door: Included
• Gel Frame: Included
Power
• Power Supply: 100~240 V AC, 50/60 Hz, 100 W
• Power Connection: Neutrik® PowerCON in / out
Control
• Operational Modes: DMX, Manual, Master / Slave
• Display: 4-button LCD control panel
• Control Protocol: DMX512
• DMX Channels: 1 / 2 / 3
• Control Interface: 3-pin XLR
Housing
• Housing Materials: Aluminium and ABS, matte black finish
• Cooling: Sensor Thermostat Controlled Variable Speed Fan
• Net Weight: 5 kg

www.event-lighting.com.au
7
F200WWMZ
Photometrics
• Light Source: 200 W 3,200K COB LED
• CRI: 90
• Beam Angle: 16°~25°
• Field Angle: 30°~65°
• Output: 7524 lux @ 2.5 m at 12°, 3505 lux @ 2.5 m at 25°
• Lens: 150 mm Fresnel
• PWM: 8,000 Hz
• LED Lifespan: 50,000 hours
Effects
• Dimming: 0~100% 8 / 16-bit
• Dimming Curves: 3
• Strobe: 1~25 Hz
• Zoom: Manual 12°~25°
• Barn Door: Included
• Gel Frame: Included
Power
• Power Supply: 100~240 V AC, 50/60 Hz, 200 W
• Power Connection: Neutrik® PowerCON in / out
Control
• Operational Modes: DMX, Manual, Master / Slave
• Display: 4-button LCD control panel
• Control Protocol: DMX512
• DMX Channels: 1 / 2 / 3
• Control Interface: 3-pin XLR
Housing
• Housing Materials: Aluminium and ABS, matte black finish
• Housing Finishing: Matte Black
• Cooling: Sensor Thermostat Controlled Variable Speed Fan
• Net Weight: 5 kg

www.event-lighting.com.au
8
F300WWMZ
Photometrics
• Light Source: 300 W 3,200 K COB LED
• CRI: 90
• Beam Angle: 12°~35°
• Field Angle: 35°~65°.
• Output: 14,223 lux @ 2.5 m at 12°, 4,990 lux @ 2.5 m at 35°
• Lens: 150 mm Fresnel
• PWM: 8,000 Hz
• LED Lifespan: 50,000 hours
Effects
• Dimming: 0~100% 8 / 16-bit
• Dimming Curves: 3
• Strobe: 1~25 Hz
• Zoom: Manual 14°~55°
• Barn Door: Included
• Gel Frame: Included
Power
• Power Supply: 100~240 V AC, 50/60 Hz, 300 W
• Power Connection: Neutrik® PowerCON in / out
Control
• Operational Modes: DMX, Manual, Master / Slave
• Display: 4-button LCD control panel
• Control Protocol: DMX512
• DMX Channel Mode: 1 / 2 / 3
• Control Interface: 3-pin XLR
Housing
• Housing Materials: Aluminium and ABS, matte black finish
• Cooling: Sensor Thermostat Controlled Variable Speed Fan
• Net Weight: 5 kg
Warranty
Please refer to your local dealer or contact Event Lighting.
