Show Tec Pixel Ber 4 COB User manual

Pixel Bar 4 COB V2
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands
Ordercode: 41268
MANUAL
ENGLISH

1
Ordercode: 41268
Pixel Bar 4 COB
Table of contents
Warning........................................................................................................................................................................... 2
Safety Instructions ..................................................................................................................................................... 2
Operating Determinations....................................................................................................................................... 4
Rigging........................................................................................................................................................................ 4
Mounting of Multiple Pixel Bars ............................................................................................................................... 5
Connection with the mains ..................................................................................................................................... 5
Return Procedure...................................................................................................................................................... 6
Claims ......................................................................................................................................................................... 6
Description of the device............................................................................................................................................. 7
Frontside ..................................................................................................................................................................... 7
Backside ..................................................................................................................................................................... 8
Installation ...................................................................................................................................................................... 8
Set Up and Operation................................................................................................................................................... 8
Control Modes........................................................................................................................................................... 9
One Pixel Bar (Manual Control) ........................................................................................................................... 9
One Pixel Bar (Built-in Programs, Auto run)......................................................................................................... 9
One Pixel Bar (Sound-controlled) ........................................................................................................................ 9
Multiple Pixel Bars (Master/Slave control) .......................................................................................................... 9
Multiple Pixel Bars (DMX Control).......................................................................................................................10
Fixture Linking ...........................................................................................................................................................11
Data Cabling ...........................................................................................................................................................11
Control Panel ...........................................................................................................................................................12
Control Mode ..........................................................................................................................................................12
DMX Addressing ...................................................................................................................................................... 12
Menu Overview.......................................................................................................................................................13
Main Menu Options .............................................................................................................................................14
1. DMX Addressing ...............................................................................................................................................14
2. Slave Mode.......................................................................................................................................................14
3. Manual Color....................................................................................................................................................14
4. Built-in Programs ...............................................................................................................................................15
5. Auto Run Mode ................................................................................................................................................15
6. Sound control Mode .......................................................................................................................................15
DMX Channels .........................................................................................................................................................16
2 Channels ............................................................................................................................................................16
3 Channels ............................................................................................................................................................17
5 Channels ............................................................................................................................................................17
6 Channels ............................................................................................................................................................17
12 Channels ..........................................................................................................................................................18
Maintenance................................................................................................................................................................19
Replacing the Fuse .................................................................................................................................................19
Troubleshooting ...........................................................................................................................................................19
Product Specification..................................................................................................................................................21
Dimensions ...................................................................................................................................................................22

2
Ordercode: 41268
Pixel Bar 4 COB
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
Showtec Pixel Bar 4 COB with IEC power cable (1,5 m)
User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving your lifespan expectancy is of a higher priority, place care in providing
for lower operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

3
Ordercode: 41268
Pixel Bar 4 COB
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Never use anything to cover the ground contact.
Never place any material over the lens.
Never look directly into the light source.
Never leave any cables lying around.
Do not insert objects into air vents.
Do not connect this device to a dimmer pack.
Do not switch the device on and off in short intervals, as this would reduce the device’s life.
Do not touch the device’s housing bare-handed during its operation. Allow the fixture to cool for at
least 5 minutes before handling.
Do not shake the device. Avoid brute force when installing or operating the device.
Only use device indoors, avoid contact with water or other liquids.
Only operate the fixture after having checked that the housing is firmly closed and all screws are
tightly fastened.
Only operate the device after having familiarized with its functions.
Avoid flames and do not put close to flammable liquids or gases.
Always keep case closed while operating.
Always allow free air space of at least 50 cm around the unit for ventilation.
Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord by the plug. Never pull out the plug by tugging the power cord.
Make sure that the device is not exposed to extreme heat, moisture or dust.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
If the lens is obviously damaged, it has to be replaced, so that its functions are not impaired, due to
cracks or deep scratches.
If device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
For adult use only. Device must be installed out of the reach of children. Never leave the unit running
unattended.
Never attempt to bypass the thermostatic switch or fuses.
For replacement use fuses of same type and rating only.
The user is responsible for correct positioning and operating of the Pixel Bar. The manufacturer will not
accept liability for damages caused by the misuse or incorrect installation of this device.
This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
Repairs, servicing and electric connection must be carried out by a qualified technician.
WARRANTY: Till one year after date of purchase.

4
Ordercode: 41268
Pixel Bar 4 COB
Operating Determinations
This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
The minimum distance between light-output and the illuminated surface must be more than 1 meter.
The maximum ambient temperature ta = 40°C must never be exceeded.
The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
If this device is operated in any other way, than the one described in this manual, the product may
suffer damages and the warranty becomes void.
Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
If the Pixel Bar is lowered from the ceiling or high joists, professional trussing systems have to be used.
Use a clamp to mount the Pixel Bar, with the mounting-bracket, to the trussing system.
The Pixel Bar must never be fixed swinging freely in the room.
The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety-cable.
When rigging, derigging or servicing the projector, always make sure, that the area below the
installation place is blocked and staying in the area is forbidden.
The Pixel Bar 4 COB can be placed on a flat stage floor or mounted to any kind of truss with a clamp.
Improper installation can cause serious injuries and/or damage of property !

5
Ordercode: 41268
Pixel Bar 4 COB
Mounting of Multiple Pixel Bars
01) Connect two Pixel Bars by means of the dedicated locks.
02) Using clamps, mount both Pixel Bars to any kind of truss.
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International EU Cable UK Cable US Cable Pin
L BROWN RED YELLOW/COPPER FASE
N BLUE BLACK SILVER NULL
YELLOW/GREEN GREEN GREEN EARTH
Make sure that the device is always connected properly to the earth!

6
Ordercode: 41268
Pixel Bar 4 COB
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

7
Ordercode: 41268
Pixel Bar 4 COB
Description of the device
Features
The Showtec Pixel Bar 8 COB is a light effect with high output and great effects.
LED quantity: 4 x 15W COB RGB
3-in-1 COB LED technology
Refresh rate: 7,8 kHz
DMX modes: 2, 3, 5, 6, 12 channels
Color range: 16,7 million additive colors
IP rating: IP-20
Specially designed housing ensures an optimum heat dissipation during operation
Input voltage: 100-240V AC, 50/60Hz
Drive current: 500mA/240V
Power consumption: 60W max @FO (full output)
DMX control via standard DMX controller
Onboard: Display for easy setup
Control: DMX-512, Built-in Programs, Auto, Manual, Master/Slave, Sound-controlled
Beam angle: 55°
Dimmer: 0-100%
Strobe: 0-20Hz
Housing: Die-cast aluminum powder coat finish
Cooling: Convection
Lens plate: Tempered Glass
Lux (@ 2 meter): Red: 180
Green: 205
Blue: 250
RGB: 635
Max. distance: 15 m
Fuse: 1,5A/250V
Dimensions: 425 x 160 x 85 mm (LxWxH)
Weight: 3,1 kg
Frontside
Fig. 01
01) Mounting bracket with inclination screw
02) 4 x 15W COB RGB

8
Ordercode: 41268
Pixel Bar 4 COB
Backside
Fig. 02
03) 100-240V AC, IEC power connector OUT
04) 100-240V AC, IEC power connector IN + Fuse 1,5A/250V
05) LED display + control buttons
06) DMX signal connector IN
07) DMX signal connector OUT
Installation
Remove all packing materials from the Pixel Bar 4 COB. Check that all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.

9
Ordercode: 41268
Pixel Bar 4 COB
Control Modes
There are 6 modes: Stand-alone (Manual Color control, Built-in Programs, Auto run)
Sound-controlled
Master/Slave
DMX512 (2CH, 3CH, 5CH, 6CH, 12CH)
One Pixel Bar (Manual Control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Pixel Bar is not connected with a DMX cable, it functions as a stand-alone device.
05) Please see page 14 for more information about the manual control functions.
One Pixel Bar (Built-in Programs, Auto run)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Pixel Bar is not connected with a DMX cable, it functions as a stand-alone device.
05) Please see page 15 for more information about the Built-in programs or the Auto Run functions.
One Pixel Bar (Sound-controlled)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Pixel Bar is not connected with a DMX cable, it functions as a stand-alone device.
05) Turn on the music. If the device is set to SU00, then the Pixel Bar will react to the beat of the music.
Please see page 15 for more information about the sound-control options
Multiple Pixel Bars (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-pin XLR cable to connect the Pixel Bar.
The pins:
1. Earth
2. Signal (-)
3. Signal (+)
05) Link the units as shown in (Fig. 03), Connect a DMX signal cable from the first unit's DMX "out" socket
to the second unit's "in" socket. Repeat this process to link the second, third, and fourth units. You can
use the same functions on the master device as described on pages 14-15 (Manual Control or Sound
control). This means that you can set your desired operation mode on your master device and all
slave devices will react the same as the master device.
Multiple Pixel Bars (Master/Slave control)
Fig. 03

10
Ordercode: 41268
Pixel Bar 4 COB
Multiple Pixel Bars (DMX Control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-pin XLR cable to connect the Pixel Bars and other devices.
05) Link the units as shown in (Fig. 04), Connect a DMX signal cable from the first unit's DMX "out" socket
to the second unit's "in" socket. Repeat this process to link the second, third, and fourth units.
06) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.
Multiple Pixel Bars DMX Set Up
Fig. 04
Note : Link all cables before connecting electric power

11
Ordercode: 41268
Pixel Bar 4 COB
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows on two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important: Fixtures on a serial data link must be daisy chained in one single line. To comply with the
EIA-485 standard no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of Pixel Bars on a DMX data link: 30 fixtures
Maximum recommended number of Pixel Bars on a Powercon link: 15 fixtures @110V
Maximum recommended number of Pixel Bars on a Powercon link: 30 fixtures @240V
Data Cabling
To link fixtures together you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).

12
Ordercode: 41268
Pixel Bar 4 COB
The Pixel Bar can be operated with a controller in control mode or without the controller in stand-alone
mode.
Control Panel
A)
B)
C)
D)
E)
LED Display
MODE button
SETUP button
UP button
DOWN button
Fig. 05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address the next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign the DMX fixture address, which is the
first channel from which the Pixel Bar will respond to the controller.
Please note when you use the controller, the unit has 12 channels.
When using multiple Pixel Bars, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Pixel Bars should be 1(d001); the DMX address of the second Pixel
Bar should be 1+12=13 (d013); the DMX address of the third Pixel Bar should be 13+12=25 (d025), etc.
Please, be sure that you don’t have any overlapping channels in order to control each Pixel Bar
correctly.
If two or more Pixel Bars are addressed similarly, they will work similarly.
Controlling:
After having addressed all Pixel Bar fixtures, you may now start operating these via your lighting controller.
Note: After switching on, the Pixel Bar will automatically detect whether DMX 512 data is received or not.
If there is no data received at the DMX-input, the “LED“ on the control panel will not flash.
The problem may be:
•The XLR cable from the controller is not connected with the input of the Pixel Bar.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It’s necessary to insert a XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 30 seconds
When no button is pressed for 30 seconds, the display will turn off.
To light up the display, you have to press the MODE button.
Once you have pressed the button, the display will light up.

13
Ordercode: 41268
Pixel Bar 4 COB
Menu Overview

14
Ordercode: 41268
Pixel Bar 4 COB
Main Menu Options
DMX address
Master-Slave
Manual Color
Built-in Programs
Auto run
1. DMX Addressing
With this menu you can set the DMX address.
01) Press the MODE button, until the display shows .
02) Press the SETUP button to open the menu. You can choose 512 different DMX addresses.
03) Press the UP/DOWN buttons to select the required address from .
04) Once you have set the desired DMX address, you can also choose the desired DMX channel mode.
05) Press the SETUP button to set 5 different DMX modes. Press the UP/DOWN buttons to choose between
2, 3, 5, 6, or 12 channels.
2. Slave Mode
With this menu you can set the device as a master or slave.
01) Press the MODE button, until the display shows .
02) If the device has not been set to slave, it is automatically classified as a master device. All slave
devices will follow the master’s movement.
03) If the device has been set to slave, it will react the same as its master device.
3. Manual Color
With this menu you can manually set a desired color.
01) Press the MODE button, until the display shows .
02) Press the SETUP button to open the menu.
03) Press the SETUP button to scroll through the 3 color options.
04) Press the UP/DOWN buttons to change the values.
Set the brightness of the red LEDs (0-255)
Set the brightness of the green LEDs (0-255)
Set the brightness of the blue LEDs (0-255)
05) You can combine Red, Green and Blue to create an infinite range of colors (0-255).

15
Ordercode: 41268
Pixel Bar 4 COB
4. Built-in Programs
With this menu you can you can set the built-in programs.
01) Press the MODE button, until the display shows .
02) Press the UP/DOWN buttons to scroll through the 24 built-in programs.
03) In menu , you can switch between the Program Running Speed and the Flash
frequency by pressing the SETUP button.
04) Press the UP/DOWN buttons to change the values.
5. Auto Run Mode
With this menu you can set Auto Run mode of the Pixel Bar.
01) Press the MODE button, until the display shows .
02) Press the SETUP button to scroll through the 3 options.
03) Press the UP/DOWN buttons to change the values.
Set the speed (01-99+Full)
Set the flash frequency (0-99+Full)
Set the number of loops (01-100)
6. Sound control Mode
With this menu you can set Sound control mode of the Pixel Bar.
01) Press the MODE button, until the display shows .
02) Press the UP/DOWN buttons to set the sound sensitivity. The adjustment range is between
, from OFF to high sound sensitivity.

16
Ordercode: 41268
Pixel Bar 4 COB
DMX Channels
2 Channels
Channel 1 – Static Colors (CH1 must be open )
0 Off
1-7 Red
8-15 Red + Green
16-23 Green
24-31 Green + Blue
32-39 Blue
40-47 Red + Blue
48-55 Red + Green + Blue
56-63 Program 1
64-71 Program 2
72-79 Program 3
80-87 Program 4
88-95 Program 5
96-103 Program 6
104-111 Program 7
112-119 Program 8
120-127 Program 9
128-135 Program 10
136-143 Program 11
144-151 Program 12
152-159 Program 13
160-167 Program 14
168-175 Program 15
176-183 Program 16
184-191 Program 17
192-199 Program 18
200-207 Program 19
208-215 Program 20
216-223 Program 21
224-231 Program 22
232-239 Program 23
240-247 Program 24
248-255 Sound-controlled Mode
Channel 2 – No Function (when CH1 is set between 0-55 )
Channel 2 – Speed (when CH1 is set between 56-247 )
0-255 Speed from slow to fast
Channel 2 – Audio Sensitivity (when CH1 is set between 248-255 )
0-255 Audio sensitivity from less sensitive to highly sensitive

17
Ordercode: 41268
Pixel Bar 4 COB
3 Channels
Channel 1 – Red Dimmer intensity
0-255 Red from 0 – 100%
Channel 2 – Green Dimmer intensity
0-255 Green from 0 – 100%
Channel 3 – Blue Dimmer intensity
0-255 Blue from 0 – 100%
5 Channels
Channel 1 – Red Dimmer intensity
0-255 Red from 0 – 100%
Channel 2 – Green Dimmer intensity
0-255 Green from 0 – 100%
Channel 3 – Blue Dimmer intensity
0-255 Blue from 0 – 100%
Channel 4 – Dimmer
0-255 From black to brightest
Channel 5 – Shutter / Strobe (CH1, CH2, CH3 or CH4 must be set between 1-255 )
0 Open
1-255 Strobe effect, from slow to fast (0-20 flashes/sec.)
6 Channels
Channel 1 – Red Dimmer intensity
0-255 Red from 0 – 100%
Channel 2 – Green Dimmer intensity
0-255 Green from 0 – 100%
Channel 3 – Blue Dimmer intensity
0-255 Blue from 0 – 100%
Channel 4 – Red Dimmer intensity
0-255 Red from 0 – 100%
Channel 5 – Green Dimmer intensity
0-255 Green from 0 – 100%
Channel 6 – Blue Dimmer intensity
0-255 Blue from 0 – 100%

18
Ordercode: 41268
Pixel Bar 4 COB
12 Channels
Channel 1 – Red Dimmer intensity
0-255 Red from 0 – 100%
Channel 2 – Green Dimmer intensity
0-255 Green from 0 – 100%
Channel 3 – Blue Dimmer intensity
0-255 Blue from 0 – 100%
Channel 4 – Red Dimmer intensity
0-255 Red from 0 – 100%
Channel 5 – Green Dimmer intensity
0-255 Green from 0 – 100%
Channel 6 – Blue Dimmer intensity
0-255 Blue from 0 – 100%
Channel 7 – Red Dimmer intensity
0-255 Red from 0 – 100%
Channel 8 – Green Dimmer intensity
0-255 Green from 0 – 100%
Channel 9 – Blue Dimmer intensity
0-255 Blue from 0 – 100%
Channel 10 – Red Dimmer intensity
0-255 Red from 0 – 100%
Channel 11 – Green Dimmer intensity
0-255 Green from 0 – 100%
Channel 12 – Blue Dimmer intensity
0-255 Blue from 0 – 100%

19
Ordercode: 41268
Pixel Bar 4 COB
Maintenance
The Showtec Pixel Bar requires almost no maintenance. However, you should keep the unit clean.
Otherwise, the fixture’s light output will be significantly reduced. Disconnect the mains power supply and
then wipe the cover with a damp cloth. Wipe the front glass panel clean with glass cleaner and a soft
cloth. Do not use alcohol or solvents. The front glass panel will require weekly cleaning, as smoke-fluid
tends to build up residues, reducing the light output very quickly. Do not immerse in liquid.
Keep connections clean. Disconnect electric power, and then wipe the DMX and audio connections
with a damp cloth. Make sure connections are thoroughly dry before linking equipment or supplying
electric power.
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by an expert after every year in the course of an acceptance test.
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by a skilled person once a year.
The following points have to be considered during the inspection:
01) All screws used for installing the device or parts of the device have to be tightly connected and must
not be corroded.
02) There may not be any deformations on housings, fixations and installation spots.
03) Mechanically moving parts like axles, eyes and others may not show any traces of wearing.
04) The electric power supply cables must not show any damages or material fatigue.
Replacing the Fuse
Power surges, short-circuit or inappropriate electrical power supply may cause a fuse to burn out. If the
fuse burns out, the product will not function whatsoever. If this happens, follow the directions below.
01) Unplug the unit from electric power source.
02) Insert a screwdriver into the slot in the fuse cover. Gently pry up the fuse cover. The fuse will come
out.
03) Remove the used fuse. If brown or unclear, it is burned out.
04) Insert the replacement fuse into the holder where the old fuse was. Reinsert the fuse cover. Be sure to
use a fuse of the same type and specification. See the product specification label for details.
Troubleshooting
No Light
This troubleshooting guide is meant to help solve simple problems.
If a problem occurs, carry out the steps below in sequence until a solution is found. Once the unit
operates properly, do not carry out following steps.
If the light effect does not operate properly, refer servicing to a technician.
Suspect three potential problem areas as: the power supply, the LEDs, the fuse.
01) Power supply. Check that the unit is plugged into an appropriate power supply.
02) The LEDs. Return the Pixel Bar to your Showtec dealer.
03) The fuse. Replace the fuse. See page 19 for more information.
04) If all of the above appears to be O.K., plug the unit in again.
05) If you are unable to determine the cause of the problem, do not open the Pixel Bar, as this may
damage the unit and the warranty will become void.
06) Return the device to your Showtec dealer.
No Response to DMX
Suspect the DMX cable or connectors, a controller malfunction, a light effect DMX card malfunction.
01) Check the DMX setting. Make sure that DMX addresses are correct.
02) Check the DMX cable: Unplug the unit; change the DMX cable; then reconnect to electrical power.
Try your DMX control again.
03) Determine whether the controller or light effect is at fault. Does the controller operate properly with
other DMX products ? If not, take the controller in for repair. If so, take the DMX cable and the light
effect to a qualified technician.
