KAM InfinityBeam User manual

XY Laser
MANUAL VERSION 1.0
01-07-15
For the latest instruction manual updates and information on the entire Kam range visit:
www.kam.co.uk
Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ
Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: [email protected] • Web: www.lambaplc.com
If this product is ever no longer functional please take it to a recycling plant for environmentally friendly disposal.
Due to continuous product development, specifications and appearance are subject to change.
© Copyright Lamba plc. E&OE.
InfinityBeam
Multi-colour wide angle beam effects

Thank you for purchasing this Kam product, we are sure that it will serve you for many years to come.
To optimise it’s performance, please read these instructions carefully to familiarise yourself with the basic operations of the unit.
Please retain them for future reference.This unit has been tested at the factory before being shipped to you. To prevent or reduce
the risk of electrical shock or fire, do not expose the unit to rain or moisture. To prevent a fire hazard, do not expose the unit to
any naked flame sources. Unplug this apparatus during lightning storms or if it is unlikely to be used for long periods of time.
When installing the unit, please ensure you leave enough space around the unit for ventilation. Slots and openings in the unit are
provided for ventilation to ensure reliable operation of the product and to protect it from overheating. To prevent fire hazard, the
openings should never be blocked or covered.
The unit is powered by the mains, always handle the power cable by the plug. Never pull out the plug by pulling on the cable.
Never touch the power cable when your hands are wet as this could cause an electric shock. Do not tie a knot in the cable. The
power cable should be placed such that it is not likely to be stepped on. A damaged power cable can cause a fire or give you an
electrical shock. Check the power cord periodicaly, if you ever find that it is damaged, replace it before using the unit again.
Contact your retailer for a replacement.
The voltage of the available power supply differs according to country or region. Be sure that the power supply voltage of the area
where this unit is to be used meets the requirements of the unit.
The lightning flash symbol inside a triangle is to alert the user to the presence high voltage within the unit’s enclosure
that may be of sufficient power to constitute a risk of electrical shock to persons. Caution: to prevent the risk of electric
shock, do not attempt to open the unit. No user-serviceable parts inside. Refer all servicing to qualified service
personnel. The exclamation mark inside a triangle is intended to alert the user to the presence of important operating
and maintenance instructions in the literature accompanying the appliance. Please read and pay attention to all laser
safety warning sticker labels on the unit.
Select the installation location of your unit carefully. Avoid placing it in direct sunlight or locations subject to vibration and
excessive dust. Do not use the unit where there are extremes in temperature (below 41ºF / 5ºC or exceeding 95ºF / 35ºC).
Unpacking and safety Please unpack your new product carefully. Your new product should reach you in perfect condition.
Please check that no damage has occurred during transit. If any damage is found, do not operate your unit. Please contact the
retailer you purchased it from immediately. If there is any damage to the mains cable do not use the device. Always disconnect
the unit from the mains supply when carrying out any cleaning of the unit.
Manufacturer declarations
In compliance with the following requirements: RoHS Directive (2002/95/EU) and WEEE Directive (2002/96/EU).
If this product is ever no longer functional please take it to a recycling plant for environmentally friendly disposal.
CE declaration of conformity
R&TTE Directive (1999/5/EU), EMC Directive (2004/108/EU), Low Voltage Directive (2006/95/EU).
The declarations are available on application from certificati[email protected]
Before putting the devices into operation, please observe the respective country-specific regulations.
AC power
The unit is supplied with a power plug appropriate to its voltage. Should any other connections be required they must be carried
out with the following configuration:
Cable (EU)
Cable (US)
Pin
International
Brown
Black
Live
L
Light blue
White
Neutral
N
Yellow/green
Green
Earth

DMX-512 connection
If you are using a standard DMX controller, you can connect the DMX output of the controller directly to the DMX input of the first
unit in a DMX chain. If you wish to connect a DMX controller with other XLR outputs you will need to use adapter cables.
1 = ground 2 = minus signal (-) 3 = plus signal (+)
Connect the DMX output of the first unit in a DMX chain with the DMX input of the next unit in the chain. Always connect the the
output of one unit with the input of the next unit until all units are connected. If you use a controller with 5 pin DMX connection you
will need to use a 5 pin to 3 pin adapter.
Overhead rigging
Important - the installation must be carried out by qualified service personal only. Improper installation can result in serious
injuries and /or damage to property. Overhead rigging required extensive experience. Working load limits should be respected,
certified installation materials should be used, the installed unit should be inspected regularly for safety.
!Make sure the area below the installation place is free from unwanted persons during rigging, de-rigging and servicing.
!Locate the unit in a well ventilated spot, far away from any flammable materials and/or liquids. The fixture must be fixed at
least 50cm from surrounding walls
!The device should be installed out of reach of people and outside of areas where persons may walk by or be seated.
!Before rigging make sure that the installation area can hold minimum point load of 10 times the device’s weight.
!The device should be well fixed; a free swinging mounting is dangerous.
!Do not cover any ventilation opening as this may result in overheating
Before first time use, the unit should be inspected for safety. Inspect the unit regularly every year.
Key to rear panel diagram
1. Mains power output/link socket. Insert an IEC cable between this socket and a connected unit’s power input socket.
2. Mains power input IEC socket. Connect the supplied IEC cable to the input and the mains power.
3. Position of adjustable bracket
4. Menu button – see below table for function setting
5. Enter button – see below table for function setting
6. Function setting LED display panel and LED indicators for power and sound input
7. Down button – see below table for function setting
8. Up button – see below table for function setting
9. Microphone - used to monitor the music input during Sound-to-Light mode
10. Sensitivity - used to adjust the mic’s input sensitivity during Sound-to-Light mode.
11. DMX input - 3 pin male XLR socket for DMX communication
12. DMX output - 3 pin female XLR socket for DMX communication
Rear panel Function Setting LED display
Use a combination of the four function buttons to set the unit to your desired working mode.
To select any of the menu options, press the MENU button to select the mode required.
Once you have made a selection then press ENTER to confirm.
Use the UP and DOWN buttons to choose the desired menu option.
The menu structure is shown on the following page.

Menu function and operation
AUT
AUTP
AP**
Auto programs
AP01~AP** - selects the auto shows
Press the Enter button to confirm
your choice
S.01~S.99 - selects the show speed
01 is the slowest / 99 is the fastest
Press the Enter button to confirm
your choice and return to AP** menu
AUTF
AF**
Auto flashing programs
AF01~AF** - selects the auto flashing shows
Press the Enter button to confirm
your choice
S.01~S.99 - selects the show speed
01 is the slowest / 99 is the fastest
Press the Enter button to confirm
your choice and return to AF** menu
AUTM
AM**
Auto mixed programs
AM01-AM02 - selects the auto mixed shows
Press the Enter button to confirm
your choice
S.01~S.99 - selects the show speed
01 is the slowest / 99 is the fastest
Press the Enter button to confirm
your choice and return to AM** menu
SOU
SOUP
SP**
Sound-to-Light programs
SP01~SP** - selects auto sound shows
Press the Enter button to confirm
your choice and return to SP** menu
SOUF
SF**
Sound-to-Light flashing programs
SF01~SF** - selects flashing sound shows
Press the Enter button to confirm
your choice and return to SF** menu
SOUM
SM**
Sound-to-Light mixed programs
SM01-SM02 - select the sound mixed show
Press the Enter button to confirm
your choice and return to SM** menu
DMX
03CH (d001-d510)
09CH (d001-d504)
14CH (d001-d499)
Select the DMX channel mode then
press Enter button for the next menu
dXXX
d 001-dxxx
Select DMX value then press the
Enter button to confirm your choice
SLA
SLAV
Sets the unit to slave mode
Press the Enter button to confirm
your choice
SYS
LEDS
Turns the LED display on or off
Press the Enter button to confirm
your choice
TEST
Self tests the unit
REST
Resets the unit to factory defaults
Press the Enter button to confirm and
restart the unit

3 channel DMX mode
Channel
Value
Description
1
000-009
Black out
010-050
Auto
051-090
Auto flash
091-130
Auto mix
131-170
Sound
171-210
Sound flash
211-255
Sound mix
2
000-255
Auto - AP** (based on channel 1, value 010-050) see below table
000-255
Auto flash - AF** (based on channel 1, value 051-090) see below table
000-255
Auto mix - AM** (based on channel 1, value 091-130) see below table
000-255
Sound - SP** (based on channel 1, value 131-170) see below table
000-255
Sound flash - SF** (based on channel 1, value 171-210) see below table
000-255
Sound mix - SM** (based on channel 1, value 211-255) see below table
3
0-255
Program speed
3 channel DMX mode / channel 2 details
Value
Auto program
Value
Sound program
000-010
AP01
000-010
SP01
011-021
AP02
011-021
SP02
022-032
AP03
022-032
SP03
033-043
AP04
033-043
SP04
044-054
AP05
044-054
SP05
055-065
AP06
055-065
SP06
066-076
AP07
066-076
SP07
077-087
AP08
077-087
SP08
088-098
AP09
088-098
SP09
099-109
AP10
099-109
SP10
110-120
AP11
110-120
SP11
121-131
AP12
121-131
SP12
132-142
AP13
132-142
SP13
143-153
AP14
143-153
SP14
154-164
AP15
154-164
SP15
165-175
AP16
165-175
SP16
176-186
AP17
176-186
SP17
187-197
AP18
187-197
SP18
198-208
AP19
198-208
SP19
209-219
AP20
209-219
SP20
220-230
AP21
220-230
SP21
231-241
AP22
231-241
SP22
242-255
AP23
242-255
SP23
000-024
AF01
000-024
SF01
025-049
AF02
025-049
SF02
050-074
AF03
050-074
SF03
075-099
AF04
075-099
SF04
100-124
AF05
100-124
SF05
125-149
AF06
125-149
SF06
150-174
AF07
150-174
SF07
175-199
AF08
175-199
SF08
200-224
AF09
200-224
SF09
225-255
AF10
225-255
SF10
000-085
AM01
000-085
SM01
086-171
AM02
086-171
SM02
172-255
AM03
172-255
SM03

9 channel DMX mode
Channel
Value
Description
1
000-085
Red 0 - 100% (head 1)
086-170
Green 0 - 100% (head 1)
171-255
Blue 0 - 100% (head 1)
2
000-085
Red 0 - 100% (head 2)
086-170
Green 0 - 100% (head 2)
171-255
Blue 0 - 100% (head 2)
3
000-085
Red 0 - 100% (head 3)
086-170
Green 0 - 100% (head 3)
171-255
Blue 0 - 100% (head 3)
4
000-085
Red 0 - 100% (head 4)
086-170
Green 0 - 100% (head 4)
171-255
Blue 0 - 100% (head 4)
5
000-085
Red 0 - 100% (head 5)
086-170
Green 0 - 100% (head 5)
171-255
Blue 0 - 100% (head 5)
6
000-085
Red 0 - 100% (head 6)
086-170
Green 0 - 100% (head 6)
171-255
Blue 0 - 100% (head 6)
7
000-085
Red 0 - 100% (head 7)
086-170
Green 0 - 100% (head 7)
171-255
Blue 0 - 100% (head 7)
8
000-085
Red 0 - 100% (head 8)
086-170
Green 0 - 100% (head 8)
171-255
Blue 0 - 100% (head 8)
9
000-255
strobe speed (strobe LEDs)

14 channel DMX mode
Channel
Value
Description
1
000-085
Red 0 - 100% (head 1)
086-170
Green 0 - 100% (head 1)
171-255
Blue 0 - 100% (head 1)
2
000-085
Red 0 - 100% (head 2)
086-170
Green 0 - 100% (head 2)
171-255
Blue 0 - 100% (head 2)
3
000-085
Red 0 - 100% (head 3)
086-170
Green 0 - 100% (head 3)
171-255
Blue 0 - 100% (head 3)
4
000-085
Red 0 - 100% (head 4)
086-170
Green 0 - 100% (head 4)
171-255
Blue 0 - 100% (head 4)
5
000-085
Red 0 - 100% (head 5)
086-170
Green 0 - 100% (head 5)
171-255
Blue 0 - 100% (head 5)
6
000-085
Red 0 - 100% (head 6)
086-170
Green 0 - 100% (head 6)
171-255
Blue 0 - 100% (head 6)
7
000-085
Red 0 - 100% (head 7)
086-170
Green 0 - 100% (head 7)
171-255
Blue 0 - 100% (head 7)
8
000-085
Red 0 - 100% (head 8)
086-170
Green 0 - 100% (head 8)
171-255
Blue 0 - 100% (head 8)
9
000-255
General brightness
10
000-080
Dimmer 0 - 100% for the 8 heads)
081-160
Dimmer 100% - 0 (for the 8 heads)
161-240
Strobe speed, slow to fast (for the 8 heads)
241-255
Sound to strobe
11
000-255
White strobe speed (strobe 1)
12
000-255
White strobe speed (strobe 2)
13
000-255
White strobe speed (strobe 3)
14
000-255
White strobe speed (strobe 4)

Kam InfinityBeam features & specification
Multi-colour wide angle beam effects
Classic disco lighting effects updated with LED
Room-filling beams from 8 multi-colour heads
Each head has a powerful 9 watt RGB multi-colour tri-LED
Position each head exactly where you want it
Strobing white effects from 4 static LEDs
Fill the dance floor with multi-colour beams of light
Stunning built-in programs
Easy-to-use 4 button control panel
Auto, Sound-to-Light, Master/Slave and DMX modes
Adjustable bracket for stands, rigs and ceilings
Controller has a robust metal chassis
Linkable IEC mains input and output
Mains input voltage: AC100~240v 50/60Hz
Dimensions: 600 x 220 x 260mm
Weight: 3.5kg
