Show Tec NanoQ 12 Q4 V1 User manual

NanoQ 12 Q4 V1
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands
Ordercode: 43710
MANUAL
ENGLISH

Ordercode: 43710
NanoQ 12 Q4
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions.........................................................................................................................................................2
Operating Determinations..........................................................................................................................................4
Rigging............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................5
Claims..............................................................................................................................................................................5
Description of the device.................................................................................................................................................6
Features ..........................................................................................................................................................................6
Frontside..........................................................................................................................................................................6
Backside .........................................................................................................................................................................7
Installation...........................................................................................................................................................................7
Set Up and Operation.......................................................................................................................................................7
Control Modes...............................................................................................................................................................8
One NanoQ 12 Q4 (Auto run program, Built-in programs and Sound-controlled mode) ..........................8
One NanoQ 12 Q4 (Manual Mode).......................................................................................................................8
Multiple NanoQ 12 Q4s (Master / Slave Control)................................................................................................8
Multiple NanoQ 12 Q4s (DMX Control)..................................................................................................................9
Fixture Linking...............................................................................................................................................................10
Data Cabling...............................................................................................................................................................10
Control Panel...............................................................................................................................................................11
Control Mode ..............................................................................................................................................................11
DMX Addressing..........................................................................................................................................................11
Menu Overview...........................................................................................................................................................12
Main Menu Options....................................................................................................................................................13
1. Auto run mode.....................................................................................................................................................13
2. Built-in programs ..................................................................................................................................................13
3. Manual mode ......................................................................................................................................................14
3.1. Dimmer settings.................................................................................................................................................14
3.2. Zoom settings ....................................................................................................................................................14
3.3. Backlight dimmer settings...............................................................................................................................14
4. Sound-controlled mode.....................................................................................................................................14
5. DMX-512 mode ....................................................................................................................................................15
6. Master/Slave mode.............................................................................................................................................15
7. Settings...................................................................................................................................................................15
7.1. Display settings..................................................................................................................................................15
7.2. Reset settings.....................................................................................................................................................15
7.3. Dimming curves................................................................................................................................................16
7.4. Dimming mode.................................................................................................................................................16
8. System information..............................................................................................................................................16
DMX Channels.............................................................................................................................................................17
6 Channels ................................................................................................................................................................17
10 Channels..............................................................................................................................................................17
14 Channels..............................................................................................................................................................18
Maintenance....................................................................................................................................................................21
Troubleshooting ...............................................................................................................................................................21
No Light.........................................................................................................................................................................21
No Response to DMX..................................................................................................................................................21
Product Specification .....................................................................................................................................................23
Dimensions........................................................................................................................................................................24
Notes..................................................................................................................................................................................25
1

Ordercode: 43710
NanoQ 12 Q4
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
•Showtec NanoQ 12 Q4
•Schuko to Pro power connector power cable (1,5 m)
•User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving your lifespan expectancy is of a higher priority, place care in providing
for lower operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
•be qualified
•follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
2

Ordercode: 43710
NanoQ 12 Q4
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Do not insert objects into air vents.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this would reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation. Allow the fixture to cool for at
least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use device indoor, avoid contact with water or other liquids.
•Only operate the fixture after having checked that the housing is firmly closed and all screws are
tightly fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep case closed while operating.
•Always allow free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the lens is obviously damaged, it has to be replaced. So that its functions are not impaired, due to
cracks or deep scratches.
•If device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. Device must be installed out of the reach of children. Never leave the unit running
unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.
•The user is responsible for correct positioning and operating of the NanoQ 12 Q4. The manufacturer
will not accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.
3

Ordercode: 43710
NanoQ 12 Q4
Operating Determinations
●This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
●The minimum distance between light-output and the illuminated surface must be more than 1 meter.
●The maximum ambient temperature ta = 40°C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
●If this device is operated in any other way, than the one described in this manual, the product may
suffer damages and the warranty becomes void.
●Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself!
Always let the installation be carried out by an authorized dealer!
Procedure:
●If the NanoQ 12 Q4 is lowered from the ceiling or high joists, professional trussing systems have to be
used.
●Use a clamp to mount the NanoQ 12 Q4, with the mounting-bracket, to the trussing system.
●The NanoQ 12 Q4 must never be fixed swinging freely in the room.
●The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety-cable.
●When rigging, derigging or servicing the projector, always make sure, that the area below the
installation place is blocked and staying in the area is forbidden.
Improper installation can cause serious damage to people and property!
4

Ordercode: 43710
NanoQ 12 Q4
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always connected properly to the earth!
Improper installation can cause serious damage to people and property!
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name.
02) Your address.
03) Your phone number.
04) A brief description of the symptoms.
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.
5

Ordercode: 43710
NanoQ 12 Q4
Description of the device
Features
The Showtec NanoQ 12 Q4 is a high power parcan with zoom function.
•Input Voltage: 100-240 VAC, 60/50Hz
•Power consumption: 150W
•Light output @ 2 m: 14300 lux
•LED Quantity: 12 x 4-in-1 10W RGBW LEDs
•Backlight: 21 x 3-in-1 RGB LEDs
•DMX modes: 6, 10, 14 channels
•Beam angle: 5-60°
•Color mixing: RGBW
•Color range: 16,7 million additive colors
•IP Rating: IP20
•DMX-control via standard DMX-controller
•Onboard: LCD display for easy setup
•Control mode: Auto run, Built-in programs, Manual mode, Sound-controlled, Master/Slave, DMX512
•Dimmer: 0-100%
•Strobe: 0-20Hz
•Housing: Die-cast aluminum powder coat finish
•Power connector: Pro power connector
•Data connectors: 3-pin/5-pin XLR IN, 3-pin/5-pin XLR OUT
•Cooling: Convection (no fans) which eliminates the use of fans and noise
•Dimensions: 215 x 185 x 290 mm (LxWxH)
•Weight: 4,4 kg
Optional accessories:
D7246 – Case for NanoQ 12 Q4
43711 – Top hat for NanoQ 12 Q4
Frontside
Fig. 01
01) 12 x 4-in-1 10W RGBW LEDs
02) Adjustment screw
03) Mounting bracket with inclination screw
6

Ordercode: 43710
NanoQ 12 Q4
Backside
Fig. 02
04) Mode button
05) Setup button
06) Up button
07) Down button
08) 5-pin DMX signal connector IN
09) 3-pin DMX signal connector IN
10) Pro power connector 100-240V IN
11) LCD display
12) 5-pin DMX signal connector OUT
13) 3-pin DMX signal connector OUT
14) Pro power connector 100-240V OUT
NOTE: Knowledge of DMX is required to fully utilize this unit.
Installation
Remove all packing materials from the NanoQ 12 Q4. Check that all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
7

Ordercode: 43710
NanoQ 12 Q4
Control Modes
There are 6 modes:
Auto run program
Built-in programs
Manual mode
Sound-controlled mode
Master / Slave
DMX-512 (6CH, 10CH or 14CH)
One NanoQ 12 Q4 (Auto run program, Built-in programs and Sound-controlled mode)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the NanoQ 12 Q4 is not connected with a DMX cable, it functions as a stand-alone device.
05) Please see page 13-14 for more information.
One NanoQ 12 Q4 (Manual Mode)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the NanoQ 12 Q4 is not connected with a DMX-cable, it functions as a stand-alone device.
05) Please see page 14 for more information about the manual mode functions.
Multiple NanoQ 12 Q4s (Master / Slave Control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-pin XLR cable to connect the NanoQ 12 Q4s.
The pins:
01) Earth
02) Signal (-)
03) Signal (+)
05) Link the units as shown in (fig.03). Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units. This means
that you can set your desired operation mode on the master device and all slave devices will react
the same as the master device.
Multiple NanoQ 12 Q4s (Master / Slave Set Up)
Fig. 03
8

Ordercode: 43710
NanoQ 12 Q4
Multiple NanoQ 12 Q4s (DMX Control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-pin/5-pin XLR cable to connect the NanoQ 12 Q4 and other devices.
05) Link the units as shown in (fig.04). Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units.
06) Supply electric power: Plug electric mains power cords into each unit's Pro power connector socket,
then plug the other end of the mains power cord into proper electric power supply sockets, starting
with the first unit. Do not supply power before the whole system is set up and connected properly.
Multiple NanoQ 12 Q4s (DMX Set Up)
Fig. 04
9

Ordercode: 43710
NanoQ 12 Q4
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows on two or more fixtures set to a master / slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy chained in one single line. To comply with the
EIA-485 standard no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of NanoQ 12 Q4s on a DMX data link: 30 fixtures
Maximum recommended number of NanoQ 12 Q4s on a power link: 4 fixtures @110V
Maximum recommended number of NanoQ 12 Q4s on a power link: 8 fixtures @240V
Data Cabling
To link fixtures together you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
10

Ordercode: 43710
NanoQ 12 Q4
The NanoQ 12 Q4 can be operated with a controller in control mode or without the controller in stand-
alone mode.
Control Panel
A)
B)
C)
D)
E)
LCD Display
MODE button
SETUP Button
UP Button
DOWN Button
Fig. 05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller.
DMX Addressing
The control panel on the front side of the base allows you to assign the DMX fixture address, which is the
first channel from which the NanoQ 12 Q4 will respond to the controller.
Please note when you use the controller, the unit has 14 channels.
When using multiple NanoQ 12 Q4s make sure you set the DMX addresses right.
Therefore, the DMX address of the first NanoQ 12 Q4 should be 1(001); the DMX address of the second
NanoQ 12 Q4 should be 1+14=15 (015); the DMX address of the third NanoQ 12 Q4 should be 15+14=29
(029), etc.
Please, be sure that you do not have any overlapping channels in order to control each NanoQ 12 Q4
correctly.
If two or more NanoQ 12 Q4s are addressed similarly, they will work similarly.
Controlling:
After having addressed all NanoQ 12 Q4 fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the NanoQ 12 Q4 will automatically detect whether DMX 512 data is received
or not. If there is no data received at the DMX-input, the display text on the control panel will not flash.
The problem may be:
•The XLR cable from the controller is not connected with the input of the NanoQ 12 Q4.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It’s necessary to insert a XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 30 seconds
When no button is pressed for 30 seconds, the display will turn off.
To light up the display, you have to press the MODE, SETUP, UP or DOWN button.
Once you have pressed the button, the display will light up.
11

Ordercode: 43710
NanoQ 12 Q4
Menu Overview
12

Ordercode: 43710
NanoQ 12 Q4
Main Menu Options
Auto run mode
Built-in programs
Manual mode
Sound-controlled mode
DMX-512 mode
Master/Slave mode
Settings
System information
1. Auto run mode
With this menu you can activate the auto run program.
01) Press the MODE button until the display shows .
02) The device will now run all the built-in programs in a sequence.
2. Built-in programs
With this menu you can you can set the built-in programs.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the menu.
03) Press the UP/DOWN buttons to select one of the 10 built-in programs: .
04) When the display shows , press the SETUP button to open the submenu.
05) Press the UP/DOWN buttons to choose one of the following 35 color presets:
06) Press the SETUP button again, to proceed to strobe flash frequency settings.
07) Press the UP/DOWN buttons to increase/decrease the strobe flash frequency. The adjustment range
is between , from OFF to high frequency.
13

Ordercode: 43710
NanoQ 12 Q4
3. Manual mode
With this menu you can set the device’s static colors.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the menu.
03) Press the UP/DOWN buttons to choose one of the 3 options:
Dimmer settings
Zoom settings
Backlight dimmer settings
3.1. Dimmer settings
01) When the display shows , press the SETUP button to open the menu.
02) Repeatedly press the SETUP button to toggle between the static colors (Red, Green, Blue, White) and
strobe.
03) Once you have chosen the desired color, press the UP/DOWN buttons to increase/decrease the LED
intensity. The adjustment range is between 0-255, from OFF to full ON.
04) You can combine Red, Green, Blue and White to create an infinite range of colors (0-255).
05) Press the SETUP button again to proceed to strobe flash frequency settings.
06) Press the UP/DOWN buttons to increase/decrease the strobe flash frequency. The adjustment range
is between , from OFF to high frequency.
3.2. Zoom settings
01) When the display shows , press the SETUP button to open the menu.
02) Press the UP/DOWN buttons to increase/decrease the zoom factor. The adjustment range is between
, from OFF to full zoom.
3.3. Backlight dimmer settings
01) When the display shows , press the SETUP button to open the menu.
02) Repeatedly press the SETUP button to toggle between the secondary colors (Red, Green, Blue) and
strobe.
03) Once you have chosen the desired color, press the UP/DOWN buttons to increase/decrease the LED
intensity. The adjustment range is between 0-255, from OFF to full ON.
04) You can combine Red, Green, Blue and White to create an infinite range of colors (0-255).
05) Press the SETUP button again to proceed to strobe flash frequency settings.
06) Press the UP/DOWN buttons to increase/decrease the strobe flash frequency. The adjustment range
is between , from OFF to high frequency.
4. Sound-controlled mode
With this menu you can set the sound-controlled mode.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the menu.
03) Press the UP/DOWN buttons to increase/decrease the sound sensitivity. The adjustment range is
between , from OFF to high sound sensitivity.
04) The device will now react to the beat of the background music.
14

Ordercode: 43710
NanoQ 12 Q4
5. DMX-512 mode
With this menu you can adjust the device’s DMX settings.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the menu.
03) Press the UP/DOWN buttons to set the device’s DMX starting address. The adjustment range is
between .
04) Press the SETUP button to proceed to DMX channel mode settings.
05) Press the UP/DOWN buttons to choose one of the 3 DMX channel modes:
.
6. Master/Slave mode
With this menu you can set the device as a slave.
01) Press the MODE button until the display shows .
02) The device is now set as a slave and will react the same as the master device.
7. Settings
With this menu you can adjust the device’s settings.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the menu.
03) Press the UP/DOWN buttons to choose one of the 3 options:
Display settings
Reset settings
Dimming curves
Dimming mode
7.1. Display settings
01) When the display shows , press the SETUP button to open the submenu.
02) Press the UP/DOWN buttons to toggle between the following 5 options:
•ON
•05 seconds
•10 seconds
•20 seconds
•30 seconds
03) This menu determines the time after which the display will turn OFF, if no button is pressed.
7.2. Reset settings
01) When the display shows , press the SETUP button to open the submenu. The display will show
.
02) Press the SETUP button (to reset the settings) or the MODE button (to return to the main menu).
15

Ordercode: 43710
NanoQ 12 Q4
7.3. Dimming curves
01) When the display shows , press the SETUP button to open the submenu.
02) Press the UP/DOWN buttons to choose one of the 4 dimming curves: Linear, Square, Inverted square
and S-curve:
7.4. Dimming mode
01) When the display shows , press the SETUP button to open the submenu.
02) Press the UP/DOWN buttons to choose either Fast or Smooth dimming mode.
8. System information
With this menu you can monitor the most important information on the device.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the submenu.
03) Press the UP/DOWN buttons to toggle between the 2 options:
Device’s software version
Motor temperature
04) Press the SETUP button to see either the current software version or the motor temperature.
16

Ordercode: 43710
NanoQ 12 Q4
DMX Channels
6 Channels
Channel 1 – Dimmer
0-255
From black to brightest
Channel 2 – Red Dimmer intensity Dimmer must be open
0-255
Red from 0 – 100%
Channel 3 – Green Dimmer intensity Dimmer must be open
0-255
Green from 0 – 100%
Channel 4 – Blue Dimmer intensity Dimmer must be open
0-255
Blue from 0 – 100%
Channel 5 – White Dimmer intensity Dimmer must be open
0-255
White from 0 – 100%
Channel 6 – Zoom
0-255
Zoom from 0 - 100%
10 Channels
Channel 1 – Dimmer
0-255
From black to brightest
Channel 2 – Red Dimmer intensity Dimmer must be open
0-255
Red from 0 – 100%
Channel 3 – Green Dimmer intensity Dimmer must be open
0-255
Green from 0 – 100%
Channel 4 – Blue Dimmer intensity Dimmer must be open
0-255
Blue from 0 – 100%
Channel 5 – White Dimmer intensity Dimmer must be open
0-255
White from 0 - 100%
Channel 6 – Strobe Dimmer and CH2-5 must be open
0-15
No function
16-255
Strobe effect, from slow to fast (0-20Hz)
Channel 7 – Zoom
0-255
Zoom from 0 - 100%
Channel 8 – Backlight Dimmer must be open
0-255
Red from 0 – 100%
17

Ordercode: 43710
NanoQ 12 Q4
Channel 9 – Backlight Dimmer must be open
0-255
Green from 0 – 100%
Channel 10 – Backlight Dimmer must be open
0-255
Blue from 0 – 100%
14 Channels
Channel 1 – Dimmer
0-255
From black to brightest
Channel 2 – LEE Colors Dimmer must be open
0-10
Dimming effect function
11-17
Red
18-24
Flame Red
25-31
Deep Gold Amber
32-38
Millenium Gold
39-45
Gold Amber
46-52
Orange
53-59
Chrome Orange
60-66
Deep Amber
67-73
Spring Yellow
74-80
Lime Green
81-87
JAS Green
88-94
Fern Green
95-101
Moss Green
102-108
Primary Green
109-115
Green
116-122
Medium Blue Green
123-129
Light Blue
130-136
Lighter Blue
137-143
Steel Blue
144-150
Half CT Blue
151-157
Full CT Blue
158-164
State Blue
165-171
Double CT Blue
172-178
Medium Blue
179-185
Just Blue
186-192
Blue
193-199
Congo Blue
200-206
Surprise Pink
207-213
Fuchsia Pink
214-220
Follies Pink
221-227
Special Rose Pink
228-234
Pink
235-241
Moroccan Pink
242-248
Cold White
249-255
Open White
Channel 3 – Red Dimmer intensity CH2 must be set between 0-10
0-255
Red from 0 – 100%
18

Ordercode: 43710
NanoQ 12 Q4
Channel 4 – Green Dimmer intensity CH2 must be set between 0-10
0-255
Green from 0 – 100%
Channel 5 – Blue Dimmer intensity CH2 must be set between 0-10
0-255
Blue from 0 – 100%
Channel 6 – White Dimmer intensity CH2 must be set between 0-10
0-255
White from 0 – 100%
Channel 7 – Strobe Dimmer and CH2-6 must be open
0-15
No function
16-255
Strobe effect, from slow to fast (0-20Hz)
Channel 8 – Zoom
0-255
Zoom from 0 - 100%
Channel 9 – Backlight Dimmer
0-255
From black to brightest
Channel 10 – LEE Colors CH9 must be open
0-10
Backlight dimming function
11-17
Red
18-24
Flame Red
25-31
Deep Golden Amber
32-38
Millenium Gold
39-45
Gold Amber
46-52
Orange
53-59
Chrome Orange
60-66
Deep Amber
67-73
Spring Yellow
74-80
Lime Green
81-87
JAS Green
88-94
Fern Green
95-101
Moss Green
102-108
Primary Green
109-115
Green
116-122
Medium Blue Green
123-129
Light Blue
130-136
Lighter Blue
137-143
Steel Blue
144-150
Half CT Blue
151-157
Full CT Blue
158-164
State Blue
165-171
Double CT Blue
172-178
Medium Blue
179-185
Just Blue
186-192
Blue
193-199
Congo Blue
200-206
Surprise Pink
207-213
Fuchsia Pink
214-220
Follies Pink
221-227
Special Rose Pink
228-234
Pink
235-241
Moroccan Pink
19
