Event Lighting lite BAR224FXL User manual

BAR224FXL
24x 4W RGBW Bar with Segment Control
USER MANUAL
For safety, please read this user manual carefully before initial use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications
within this manual are subject to change without notice. Event Lighting assumes no liability or
responsibility for any errors or omissions. Please consult Event Lighting for any clarification or
information regarding this item.
Version: 1 (30 October 2023)

www.event-lighting.com.au
Safety Instructions
Warning
•Do not open this fixture, there is no user-serviceable parts inside. Risk of electric shock.
•Do not look at the light source when the device is on.
Caution: This unit’s housing may become hot during and after operation.
•Install this fixture in a location with adequate ventilation, at least 50 cm from adjacent
surfaces.
•Do not leave any flammable material within 50 cm of this unit while operating or connected
to power.
•Use a safety chain when mounting this fixture overhead.
•Do not operate this device in any location where excessive dust, heat, water or humidity may
affect it.
•Do not operate this fixture if the housing, lenses, or cables appear damaged.
•Do not connect this fixture to a dimmer or rheostat.
•ONLY connect this fixture to a grounded and protected circuit.
•ONLY use the hanging bracket to carry this fixture.
•In case of a serious operating problem, stop using immediately.
•The maximum ambient temperature is 40° C. Do not operate this fixture at higher
temperatures.
Power Input and Power Linking
This fixture has an auto switching power supply that works with an input voltage range of 110-240V
AC, 50/60 Hz.
Link up to a maximum of 8A. Do NOT exceed this.
Product Installation
•This fixture can be mounted in many orientations provided each individual fixture is secured
by a suitable mounting bracket.
•Use a safety chain when mounting this fixture overhead.
Menu
2

www.event-lighting.com.au
3
Table 1
Mode
Programming
Description
Auto mode
Auto
Mode Auto-run mode
DMX Mode
Addr
3CH
A001-A510
The selected channel
mode will limit the
available DMX addresses.
The fixture will
automatically enter DMX
mode when a controller is
connected.
5CH
A001-A508
8CH
A001-A505
24CH
A001-A489
48CH
A001-A465
53CH
A001-A460
Show
Shou
Sh1-54
Program Show 1-54
Sp1-10
Program Speed 1-10 (slow-fast)
St0-9
Program Flash 0-9 (slow-fast)
Sound
Mode
Soud
Sou1
Sen1-9
Mic Sensitivity
Sou2
Sou3
Edit color
Colo
R000-255
Red(0-100%)Red Dimming
G000-255
Green(0-100%)Green Dimming
B000-255
Bule(0-100%)Bule Dimming
St0-St9
LED Strobe (slow-fast)
Static
colors
Stat
CL00-CL26
RGB static color
Slave
Slav
Slave
Slav(Slave,automatically identify the host)
Information
Info
Ver
VVxx
Soft version
Product
Set
Set
dis
10s
Set the backlight of the
display, from 10 seconds
to always on. Default is 10
seconds.
20s
30s
60s
on
dir
Setting direction right
Setting direction left

www.event-lighting.com.au
DMX Chart
This fixture is controlled by the universal DMX 512 protocol. The DMX address is the first
channel used to receive instructions from the external controller. For independent control, each
fixture must be assigned a unique address for each of its control channels. For example, this
device has five channel modes: 3/5/8/24/48/53, if it’s set to 3 channel mode, and there are
several fixtures need to be independently controlled, we just simply address first fixture at 1,
and second fixture at 4, third one at 7, etc. !
•If multiple fixtures have the same DMX address, they will behave synchronically. !
•Display will flash when no DMX signal is received. !
Table 1-1
Mode/Channel
Min
DMX
Max
DMX
Function
3 ch
5 ch
8 ch
24
ch
48
ch
53
ch
1
1
1
1
0
255
Dimmer, 0-100%
2
0
9
No function
10
255
Strobe, slow to fast
1
3
2
2
0
255
Red, 0-100%
2
4
3
3
0
255
Green, 0-100%
3
5
4
4
0
255
Blue, 0-100%
5 (a)
5 (a)
0
9
No function (Ch 2-4 applies)
10
13
Static colour (Ch 7 selection)
14
17
Internal effect 1
18
21
Internal effect 2
22
25
Internal effect 3
26
29
Internal effect 4
30
33
Internal effect 5
34
37
Internal effect 6
38
41
Internal effect 7
42
45
Internal effect 8
46
49
Internal effect 9
50
53
Internal effect 10
54
57
Internal effect 11
58
61
Internal effect 12
62
65
Internal effect 13
66
69
Internal effect 14
4

www.event-lighting.com.au
70
73
Internal effect 15
74
77
Internal effect 16
78
81
Internal effect 17
82
85
Internal effect 18
86
89
Internal effect 19
90
93
Internal effect 20
94
97
Internal effect 21
98
101
Internal effect 22
102
105
Internal effect 23
106
109
Internal effect 24
110
113
Internal effect 25
114
117
Internal effect 26
118
121
Internal effect 27
122
125
Internal effect 28
126
129
Internal effect 29
130
133
Internal effect 30
134
137
Internal effect 31
138
141
Internal effect 32
142
145
Internal effect 33
146
149
Internal effect 34
150
153
Internal effect 35
154
157
Internal effect 36
158
161
Internal effect 37
162
165
Internal effect 38
166
169
Internal effect 39
170
173
Internal effect 40
174
177
Internal effect 41
178
181
Internal effect 42
182
185
Internal effect 43
186
189
Internal effect 44
190
193
Internal effect 45
194
197
Internal effect 46
198
201
Internal effect 47
202
205
Internal effect 48
5

www.event-lighting.com.au
206
209
Internal effect 49
210
213
Internal effect 50
214
217
Internal effect 51
218
221
Internal effect 52
222
225
Internal effect 53
226
229
Internal effect 54
230
233
Auto run (cycle effects 1-54)
234
237
DMX sound mode 1
238
241
DMX sound mode 2
242
255
DMX sound mode 3
6 (b)
0
9
No function (Ch 5 applies)
10
15
1st LED segment on, Ch 2-4 controls
colour. Remaining segments are offwhen
Ch 7 > 100
16
21
2nd LED segment on, Ch 2-4 controls
colour. Remaining segments are offwhen
Ch 7 > 100
22
27
3rd LED segment on, Ch 2-4 controls
colour. Remaining segments are offwhen
Ch 7 > 100
28
33
4th LED segment on, Ch 2-4 controls
colour. Remaining segments are offwhen
Ch 7 > 100
34
39
5th LED segment on, Ch 2-4 controls
colour. Remaining segments are offwhen
Ch 7 > 100
40
45
6th LED segment on, Ch 2-4 controls
colour. Remaining segments are offwhen
Ch 7 > 100
46
51
7th LED segment on, Ch 2-4 controls
colour. Remaining segments are offwhen
Ch 7 > 100
52
57
8th LED segment on, Ch 2-4 controls
colour. Remaining segments are offwhen
Ch 7 > 100
58
63
9th LED segment on, Ch 2-4 controls
colour. Remaining segments are offwhen
Ch 7 > 100
64
69
10th LED segment on, Ch 2-4 controls
colour. Remaining segments are offwhen
Ch 7 > 100
6

www.event-lighting.com.au
70
75
11th LED segment on, Ch 2-4 controls
colour. Remaining segments are offwhen
Ch 7 > 100
76
81
12th LED segment on, Ch 2-4 controls
colour. Remaining segments are offwhen
Ch 7 > 100
82
87
13th LED segment on, Ch 2-4 controls
colour. Remaining segments are offwhen
Ch 7 > 100
88
93
14th LED segment on, Ch 2-4 controls
colour. Remaining segments are offwhen
Ch 7 > 100
94
99
15th LED segment on, Ch 2-4 controls
colour. Remaining segments are offwhen
Ch 7 > 100
100
105
16th LED segment on, Ch 2-4 controls
colour. Remaining segments are offwhen
Ch 7 > 100
106
111
Patten effect 1 (Ch 2-4 control colour)
112
117
Patten effect 2 (Ch 2-4 control colour)
118
123
Patten effect 3 (Ch 2-4 control colour)
124
129
Patten effect 4 (Ch 2-4 control colour)
130
135
Patten effect 5 (Ch 2-4 control colour)
136
141
Patten effect 6 (Ch 2-4 control colour)
142
147
Patten effect 7 (Ch 2-4 control colour)
148
153
Patten effect 8 (Ch 2-4 control colour)
154
159
Patten effect 9 (Ch 2-4 control colour)
160
165
Patten effect 10 (Ch 2-4 control colour)
166
171
Patten effect 11 (Ch 2-4 control colour)
172
177
Patten effect 12 (Ch 2-4 control colour)
178
183
Patten effect 13 (Ch 2-4 control colour)
184
189
Patten effect 14 (Ch 2-4 control colour)
190
195
Patten effect 15 (Ch 2-4 control colour)
196
201
Patten effect 16 (Ch 2-4 control colour)
202
207
Patten effect 17 (Ch 2-4 control colour)
208
213
Patten effect 18 (Ch 2-4 control colour)
214
219
Patten effect 19 (Ch 2-4 control colour)
220
225
Patten effect 20 (Ch 2-4 control colour)
226
231
Patten effect 21 (Ch 2-4 control colour)
7

www.event-lighting.com.au
232
237
Patten effect 22 (Ch 2-4 control colour)
238
243
Patten effect 23 (Ch 2-4 control colour)
244
255
Patten effect 24 (Ch 2-4 control colour)
6
0
9
No function (Ch 5 applies)
10
19
Patten effect 1 (Ch 2-4 control colour)
20
29
Patten effect 2 (Ch 2-4 control colour)
30
39
Patten effect 3 (Ch 2-4 control colour)
40
49
Patten effect 4 (Ch 2-4 control colour)
50
59
Patten effect 5 (Ch 2-4 control colour)
60
69
Patten effect 6 (Ch 2-4 control colour)
70
79
Patten effect 7 (Ch 2-4 control colour)
80
89
Patten effect 8 (Ch 2-4 control colour)
90
99
Patten effect 9 (Ch 2-4 control colour)
100
109
Patten effect 10 (Ch 2-4 control colour)
110
119
Patten effect 11 (Ch 2-4 control colour)
120
129
Patten effect 12 (Ch 2-4 control colour)
130
139
Patten effect 13 (Ch 2-4 control colour)
140
149
Patten effect 14 (Ch 2-4 control colour)
150
159
Patten effect 15 (Ch 2-4 control colour)
160
169
Patten effect 16 (Ch 2-4 control colour)
170
179
Patten effect 17 (Ch 2-4 control colour)
180
189
Patten effect 18 (Ch 2-4 control colour)
190
199
Patten effect 19 (Ch 2-4 control colour)
200
209
Patten effect 20 (Ch 2-4 control colour)
210
219
Patten effect 21 (Ch 2-4 control colour)
220
229
Patten effect 22 (Ch 2-4 control colour)
230
239
Patten effect 23 (Ch 2-4 control colour)
240
255
Patten effect 24 (Ch 2-4 control colour)
1
2
Segment 1 Red, 0-100%
2
3
Segment 1 Green, 0-100%
3
4
Segment 1 Blue, 0-100%
4
5
Segment 2 Red, 0-100%
5
6
Segment 2 Green, 0-100%
6
7
Segment 2 Blue, 0-100%
8

www.event-lighting.com.au
...
...
46
47
Segment 16 Red, 0-100%
47
48
Segment 16 Green, 0-100%
48
49
Segment 16 Blue, 0-100%
50 (c)
0
9
No function (Ch 2-49 applies)
10
13
Static colour (Ch 52 selection)
14
17
Internal effect 1
18
21
Internal effect 2
22
25
Internal effect 3
26
29
Internal effect 4
30
33
Internal effect 5
34
37
Internal effect 6
38
41
Internal effect 7
42
45
Internal effect 8
46
49
Internal effect 9
50
53
Internal effect 10
54
57
Internal effect 11
58
61
Internal effect 12
62
65
Internal effect 13
66
69
Internal effect 14
70
73
Internal effect 15
74
77
Internal effect 16
78
81
Internal effect 17
82
85
Internal effect 18
86
89
Internal effect 19
90
93
Internal effect 20
94
97
Internal effect 21
98
101
Internal effect 22
102
105
Internal effect 23
106
109
Internal effect 24
110
113
Internal effect 25
114
117
Internal effect 26
118
121
Internal effect 27
122
125
Internal effect 28
9

www.event-lighting.com.au
126
129
Internal effect 29
130
133
Internal effect 30
134
137
Internal effect 31
138
141
Internal effect 32
142
145
Internal effect 33
146
149
Internal effect 34
150
153
Internal effect 35
154
157
Internal effect 36
158
161
Internal effect 37
162
165
Internal effect 38
166
169
Internal effect 39
170
173
Internal effect 40
174
177
Internal effect 41
178
181
Internal effect 42
182
185
Internal effect 43
186
189
Internal effect 44
190
193
Internal effect 45
194
197
Internal effect 46
198
201
Internal effect 47
202
205
Internal effect 48
206
209
Internal effect 49
210
213
Internal effect 50
214
217
Internal effect 51
218
221
Internal effect 52
222
225
Internal effect 53
226
229
Internal effect 54
230
233
Auto run (cycle effects 1-54)
234
237
DMX sound mode 1
238
241
DMX sound mode 2
242
255
DMX sound mode 3
51
(d)
0
9
No function (Ch 50 applies)
10
19
Patten effect 1 (Ch 2-4 control colour)
20
29
Patten effect 2 (Ch 2-4 control colour)
30
39
Patten effect 3 (Ch 2-4 control colour)
10

www.event-lighting.com.au
40
49
Patten effect 4 (Ch 2-4 control colour)
50
59
Patten effect 5 (Ch 2-4 control colour)
60
69
Patten effect 6 (Ch 2-4 control colour)
70
79
Patten effect 7 (Ch 2-4 control colour)
80
89
Patten effect 8 (Ch 2-4 control colour)
90
99
Patten effect 9 (Ch 2-4 control colour)
100
109
Patten effect 10 (Ch 2-4 control colour)
110
119
Patten effect 11 (Ch 2-4 control colour)
120
129
Patten effect 12 (Ch 2-4 control colour)
130
139
Patten effect 13 (Ch 2-4 control colour)
140
149
Patten effect 14 (Ch 2-4 control colour)
150
159
Patten effect 15 (Ch 2-4 control colour)
160
169
Patten effect 16 (Ch 2-4 control colour)
170
179
Patten effect 17 (Ch 2-4 control colour)
180
189
Patten effect 18 (Ch 2-4 control colour)
190
199
Patten effect 19 (Ch 2-4 control colour)
200
209
Patten effect 20 (Ch 2-4 control colour)
210
219
Patten effect 21 (Ch 2-4 control colour)
220
229
Patten effect 22 (Ch 2-4 control colour)
230
239
Patten effect 23 (Ch 2-4 control colour)
240
255
Patten effect 24 (Ch 2-4 control colour)
7 (e)
7 (e)
52 (e)
0
9
No function
10
19
Static colour 1
20
29
Static colour 2
30
39
Static colour 3
40
49
Static colour 4
50
59
Static colour 5
60
69
Static colour 6
70
79
Static colour 7
80
89
Static colour 8
90
99
Static colour 9
100
109
Static colour 10
110
119
Static colour 11
120
129
Static colour 12
11

www.event-lighting.com.au
(a) Channel 5 is valid when the value of channel 6 is 0-9.
(b) Channel 5 is applied first.
(c) Channel 50 is valid when the value of channel 6 is 0-9.
(d) Channel 50 is applied first.
(e) (8/24 channel mode) This channel applies when channel 5 is 10-13. (53 channel mode) This
channel applies when channel 50 is 10-13.
(f) This channel applies when channel 5 is 0-9 and channel 6 is 0-9.
130
139
Static colour 13
140
149
Static colour 14
150
159
Static colour 15
160
169
Static colour 16
170
179
Static colour 17
180
189
Static colour 18
190
199
Static colour 19
200
209
Static colour 20
210
219
Static colour 21
220
229
Static colour 22
230
239
Static colour 23
240
249
Static colour 24
250
255
Static colour 25
8
8
0
9
No function
10
255
Strobe, slow to fast
9 (f)
0
255
1st LED segment dimmer, 0-100%, colour
controlled by Ch 2-4
10 (f)
2nd LED segment dimmer, 0-100%,
colour controlled by Ch 2-4
...
23 (f)
15th LED segment dimmer, 0-100%,
colour controlled by Ch 2-4
24 (f)
16th LED segment dimmer, 0-100%,
colour controlled by Ch 2-4
12

www.event-lighting.com.au
Technical Specifications
•Light Source: 224x SMD5050 RGB LEDs
•Beam Angle: 90°
•PWM: 10,000 Hz
•Operation Modes: DMX, auto, manual, sound active, master/slave
•Control Interface: 3-pin XLR in/out
•DMX Channels: 3/5/8/24/4/53
•Input Voltage: 110-240V AC, 50/60 Hz
•Dimensions: 1100x60x60 mm
•Weight: 3.5 kg
Optional Accessories
XSTANDM8 - Vertical Mount Stand
Warranty
Please contact your local dealer or contact Event Lighting.
www.event-lighting.com.au
13
