Showven uFlamer X1800 User manual

USER MANUAL
uFlamer X1800
V1.1
2022.09

Thanks for choosing SHOWVEN uFlamer X1800, we wish it will bring you lots of exciting
moments.
Please read the following manual carefully before operating this product.
ΔWarning
\This product is only suitable for qualified or skilled operators who has experience with the technology
of the device and is particularly informed about the types of fuel used by the device.
\Unauthorized repair are prohibited, it may cause serious incident.
\Make sure power supply in consistent with the rated voltage of the equipment, and the socket must
well grounded. Unplug and turn off the machine when not use.
\Before power on the machine, please check carefully the safety distance and make sure it meets the
requirements in this manual.
\Please connect DMX cable before turn on the power supply, make sure communication command stay
at non firing status, and safety switch of X1800 stay at TEST MODE.
\After turning on the device, no person allows to stay in the danger area. Ensure all persons that are
part of the show be informed about the safety distance, risks and functions of the device.
\Always have a CO2fire extinguisher and an extinguishing blanket in case of needed.
\If there be any doubt as to the safety operation of the device in any circumstances, the device should
be taken out of service immediately. Be sure the device is in good operating condition before use. If fail
to fire correctly, immediately shut down and check it accordingly. Any questions please always contact
SHOWVEN ([e-mail]) for help.
\Be sure to use high quality flame fluid according to below requirement, otherwise, it is easily leads to
failure or danger.
\The operator responsible for the control of uFlamer X1800 must always have a clear view of the device,
so that he/she can stop the show immediately when there is danger. The main AC power switch should
near operator. So that operator can turn off the power of all devices in case of abnormal.
\The device shall not be altered and applied to other use purpose.
ΔDisclaimers:
SHOWVEN technologies Co., Ltd excludes liability for unsafe situations, accidents and damages resulting
from:
1. Ignoring warnings or regulations as shown on uFlamer X1800 or this manual.
2. Use for other applications or circumstances other than those indicated herein.
3. Changes to the uFlamer X1800, including use of non-original spare parts, lack of maintenance etc.
4. Dismantling uFlamer X1800 without authorization from SHOWVEN.
5. Use this machine by unqualified or untrained personnel.
6. Use other type of fuel instead of ISOPAR as indicated in this manual.
7. Improper use of machine.
ΔFunctional Characteristics
\210° swivel angles
\Waterproof design, can be used in rain
\Dual solenoid valve for extra safety
\Dual igniter ensure successful ignition
\88 preset firing sequences, easy to operate
\Support 9-60V pyro signal

\Flames up to 10m
\Stainless steel housing
\Built-in accumulator
\DMX control, both 3-pin and 5-pin XLR
ΔTechnical Specifications
\Model: uFlamer X1800
\Dimension: 370× 380× 380mm
\Weight: 19 kg
\Input: 220V, 110V
\Quick Coupler: ISO7241B G1/4 male
\Work Power: 260W
\Usage in Rain: YES
\Work Pressure Range: 8-12Bar
\Installation Angles: Any direction, bottom plate need protective cover to achieve waterproof function
\Fuel: ISOPAR L
\Accumulator: YES
\Flame Height: 8-10m(Nozzle M)
\Ignition: Dual, high voltage electron ignition
\Fuel Consumption: 60ml/s (Nozzle M), 30ml/s (Nozzle L)
\Control: DMX , 9-60V pyro signal
\Min. Firing Duration: 0.1S
\Firing Angle.: 210° (± 105° )
ΔStructure
1. Flame chamber
2. Front Panel
3. Top Panel
4. Rear panel
5. Safety loop
6. Label

Diagram of bottom panel
Rear Panel
1. Display area
2. Pressure gauge
3. Fuel IN quick coupler (ISO7241B G1/4 male) (Fuel input pressure 8-12bar)
4. Pressure indicator light
5. 3-PIN DMX
6. Safety switch
7. 5-PIN DMX
8. 9-60V pyro signal port
9. Power IN / OUT

ΔOperation Panel
1. LED Display Area
RX : Radio receiving (reserved)
DMX : DMX signal. Flash means DMX signal available, otherwise no DMX signal
ERR : Light on when there is an error
PUMP : Indicate light (reserved)
2. Button Functions:
MENU : Switch interface to setup parameter;
+ : Parameter Up
-: Parameter Down
ENTER : Confirm and save parameters (screen will flash when parameters saved)
Note: screen display will switch to main interface if don't press button in10s.
3. Pressure Indicator Light Status Explanation
Status
Pressure
OFF
Current Pressure < P. Low Limit
ON
P. Low Limit ≤Current Pressure < P. Upper Limit
BLINK
P. Upper Limit ≤Current Pressure
4. Welcome Interface
First Line: Product model and software version
Second Line: Equipment series number
5. Main Interface
First Line: DMX address;
Second Line: Pressure100 (e.g. 100=10bar); V: 13.6 means internal voltage is 13.6V.
X1800-A220627
XXXXXXXXXXX
DMX Address:1
P:100 V:13.6

6. Alert Message
Alert Message
Why it appears
How to remove
E0 Invert On
Invert function ON
Set Invert to OFF
E0 Test Mode
Safety Switch at TEST MODE
Switch to USER MODE
E0 Factory Mode
Factory mode
Switch to Normal mode
E0 MotorDisable
Motor Disabled ON
Set Motor Disabled to OFF
E0 FireForbidden
Fire Forbidden ON
Set Fire Forbidden to OFF
E4 ExtIgnite ON
Ext Ignite ON
Set Ext Ignite to OFF
7. Error Message
Error Message
Why it appears
How to remove
E5 Voltage Err
DC input < 10V or > 15v
Make sure DC input between 10-15V
E6 Tip Err
Machine slant over 45° , it stops
running
Tip setting set to OFF, or horizontal install
machine.
8. Interface setup
Press “MENU” to switch through setup menu
Menu
Range
Default
Explanation
Set DMX Address
1~512
1
DMX address setup
Angle Limit
MAX NO.1 - NO.15
MAX NO. 15
Restrict nozzle rotate angles: Set by "+" and "-
" , and confirm by "ENTER"
MIN NO.1 - NO.15
MIN NO. 1
Steps setting the angle limit and install angle blocks.
a) Set the “Maxi. Angle” and “Mini. Angle”, press “ENTER” to save the changes.
b) Test the SEQUENCE 31 or push the CH1 DMX value from 0 to 255 on DMX console to drive flame
nozzle movement manually, confirm the nozzle is waving only in the preset limited angles instead of
from -105° to +105°. If not, please reset the ANGLE LIMIT and check. (SEQUENCE 31 of X-F3600 is
short flame step sequence from -105° to +105° , after set the angle limit, it can only waving between
the Mini. Angle and Maxi. Angle).
c) After confirm the software angle limit control works well, then install the angle block plate and put
angle limit rod at corresponding Mini. Angle and Maxi. Angle. Test sequence 31 again to reconfirm
the angle limit rod was correctly installed.
9. Advanced Interface
Press “MENU” 3s enter advanced interface, press “MENU” to switch interface, press “MENU” 3s can
back to main interface.

Items
Contents
Default
Description
Drive Test
OFF / Motor / Igniter / Jet Valve 1 / Jet Valve 2
1. Motor
Swiveling and stop at target angle.
2. Igniter
Ignite 1s
3. Jet Valve 1
Safety lock located at user mode, pressure release
valve on, then related jet valve will be on and off
for 3 times
4. Jet Valve 2
Ext Ignite
OFF / ON
OFF
Trigger through 9-60V pyro ignition signal
Set Ext Sequence
1~88
OFF
Preset sequence triggered by pyro signal
语言 (Language)
English / Chinese
English
Language switch
Mode Select
Normal Mode /
Factory Mode
Normal
Mode
Factory mode is for test in factory only
Tip Setting
OFF / ON
OFF
Turn ON/OFF tip over function
Head to middle
OFF / ON
OFF
Channel 1=0, Firing head will remain in middle
position (NO.8) after running a preset sequence.
Invert
OFF / ON
OFF
When turned on, all angles will be mirrored.
Motor Disabled
OFF / ON
OFF
When turned on, the position of the firing head
should be moved or set manually, and the motor
of firing head will be disabled.
(The flamer should be restarted before it takes
effect.)
DefaultParameter
OFF / ON
OFF
Reset default parameter settings
ΔFiring Angles
The firing angle for X1800 is ± 105° , from the Audience Side view, there are altogether 15 firing angles as
below.
ΔDrive time for Effects
Time needed for the motor drive from NO.8 to relevant angle.

No.
Angles
Drive time needed
NO.1
-105°
170ms
NO.2
-90°
150ms
NO.3
-75°
130ms
NO.4
-60°
110ms
NO.5
-45°
90ms
NO.6
-30°
70ms
NO.7
-15°
50ms
NO.8
0°
0ms
NO.9
15°
50ms
NO.10
30°
70ms
NO.11
45°
90ms
NO.12
60°
110ms
NO.13
75°
130ms
NO.14
90°
150ms
NO.15
105°
170ms
For example for the motor drive from 0° to 45° , it need 90ms, when operator design a show to
synchronize to music, this drive time must be calculated.
ΔuFlamer X1800 Firing Sequences
uFlamer X1800 has 88 preset sequences, operator use related channel DMX value or sequence No. to
access certain sequence. Below, you can find sequence list and single ignitions.
Single Ignition Sequence List
No.
Ignition angle
Description
Nozzle
Movement
Firing Duration
(For reference)
CH5 DMX
Reference Value
1
-105°
Single Ignition SHORT flame
Static
0.19s
3-5
2
-90°
Single Ignition SHORT flame
Static
0.19s
6-7
3
-75°
Single Ignition SHORT flame
Static
0.19s
8-10
4
-60°
Single Ignition SHORT flame
Static
0.19s
11-12
5
-45°
Single Ignition SHORT flame
Static
0.19s
13-15
6
-30°
Single Ignition SHORT flame
Static
0.19s
16-17
7
-15°
Single Ignition SHORT flame
Static
0.19s
18-20
8
0°
Single Ignition SHORT flame
Static
0.19s
21-22
9
15°
Single Ignition SHORT flame
Static
0.19s
23-25
10
30°
Single Ignition SHORT flame
Static
0.19s
26-28
11
45°
Single Ignition SHORT flame
Static
0.19s
29-30
12
60°
Single Ignition SHORT flame
Static
0.19s
31-33
13
75°
Single Ignition SHORT flame
Static
0.19s
34-35
14
90°
Single Ignition SHORT flame
Static
0.19s
36-38
15
105°
Single Ignition SHORT flame
Static
0.19s
39-40
16
-105°
Single Ignition LONG flame
Static
0.56s
41-43
17
-90°
Single Ignition LONG flame
Static
0.56s
44-45
18
-75°
Single Ignition LONG flame
Static
0.56s
46-48
19
-60°
Single Ignition LONG flame
Static
0.56s
49-50
20
-45°
Single Ignition LONG flame
Static
0.56s
51-53
21
-30°
Single Ignition LONG flame
Static
0.56s
54-56
22
-15°
Single Ignition LONG flame
Static
0.56s
57-58
23
0°
Single Ignition LONG flame
Static
0.56s
59-61
24
15°
Single Ignition LONG flame
Static
0.56s
62-63
25
30°
Single Ignition LONG flame
Static
0.56s
64-66
26
45°
Single Ignition LONG flame
Static
0.56s
67-68
27
60°
Single Ignition LONG flame
Static
0.56s
69-71
28
75°
Single Ignition LONG flame
Static
0.56s
72-73
29
90°
Single Ignition LONG flame
Static
0.56s
74-76

30
105°
Single Ignition LONG flame
Static
0.56s
77-79
Step Sequences List
No.
Ignition angle NO.
Description
Nozzle
movement
Firing Duration
(For reference)
CH5 DMX
Reference Value
31
Step from 1-15
SHORT flame Step sequence
L -> R
2.66s
80-81
32
Step from 15-1
SHORT flame Step sequence
R -> L
2.66s
82-84
33
Step 5>8>11
SHORT flame Step sequence
L -> R
0.92s
85-86
34
Step 11>8>5
SHORT flame Step sequence
R -> L
0.92s
87-89
35
Step 6>10
SHORT flame Step sequence
L -> R
0.75s
90-91
36
Step 10>6
SHORT flame Step sequence
R -> L
0.75s
92-94
37
Step 4>6>8>10>12
SHORT flame Step sequence
L -> R
1.27s
95-96
38
Step 12>10>8>6>4
SHORT flame Step sequence
R -> L
1.27s
97-99
39
Step 8>6>10>4>12
SHORT flame Step sequence
M>L>R>L>R
1.60s
100-101
40
Step 8>10>6>12>4
SHORT flame Step sequence
M>R>L>R>L
1.60s
102-104
41
Step from 1-15
LONG flame Step sequence
L -> R
7.78s
105-107
42
Step from 15-1
LONG flame Step sequence
R -> L
7.78s
108-109
43
Step 5>8>11
LONG flame Step sequence
L -> R
1.82s
110-112
44
Step 11>8>5
LONG flame Step sequence
R -> L
1.82s
113-114
45
Step 6>10
LONG flame Step sequence
L -> R
1.25s
115-117
46
Step 10>6
LONG flame Step sequence
R -> L
1.25s
118-119
47
Step 4>6>8>10>12
LONG flame Step sequence
L -> R
2.68s
120-122
48
Step 12>10>8>6>4
LONG flame Step sequence
R -> L
2.68s
123-124
49
Step 8>6>10>4>12
LONG flame Step sequence
M>L>R>L>R
2.88s
125-127
50
Step 8>10>6>12>4
LONG flame Step sequence
M>R>L>R>L
2.88s
128-130
Wave Sequence List
No.
Ignition angle NO.
Description
Nozzle
movement
Firing Duration
(For reference)
CH5 DMX
Reference Value
51
Wave 5 -->11
Middle wave sequence
L -> R
1.87s
131-132
52
Wave 11-->5
Middle wave sequence
R -> L
1.87s
133-135
53
Big wave 1--15
LONG wave sequence
L -> R
4.08s
136-137
54
Big wave 15--1
LONG wave sequence
R -> L
4.08s
138-140
55
Wave 8-->1
Middle wave sequence
M -> L
2.09s
141-142
56
Wave 8-->15
Middle wave sequence
M -> R
2.09s
143-145
57
Wave 1-->8
Middle wave sequence
L -> M
2.31s
146-147
58
Wave 15-->8
Middle wave sequence
R -> M
2.31s
148-150
59
Wave 8-->11
SHORT wave sequence
M -> R
0.99s
151-152
60
Wave 8-->5
SHORT wave sequence
M -> L
0.99s
153-155
61
Wave 5-->8
SHORT wave sequence
L -> M
1.08s
156-158
62
Wave 11-->8
SHORT wave sequence
R -> M
1.08s
159-160
Additional Sequences List
No.
Ignition angle NO.
Description
Nozzle
movement
Firing Duration
(For reference)
CH5 DMX
Reference Value
63
Step 3>13
SHORT flame Step sequence
L -> R
0.93s
161-163
64
Step 13>3
SHORT flame Step sequence
R -> L
0.93s
164-165
65
Step 3>13
LONG flame Step sequence
L -> R
1.63s
166-168
66
Step 13>3
LONG flame Step sequence
R -> L
1.63s
169-170
67
Step 8-13
SHORT flame Step sequence
M -> R
1.55s
171-173
68
Step 13-8
SHORT flame Step sequence
R -> M
1.55s
174-175
69
Step 8-13
LONG flame Step sequence
M -> R
3.24s
176-178
70
Step 13-8
LONG flame Step sequence
R -> M
3.24s
179-181
71
Step 8-3
SHORT flame Step sequence
M -> L
1.54s
182-183
72
Step 3-8
SHORT flame Step sequence
L -> M
1.54s
184-186

73
Step 8-3
LONG flame Step sequence
M -> L
3.24s
187-188
74
Step 3-8
LONG flame Step sequence
L -> M
3.24s
189-191
75
Step 3-13
SHORT flame Step sequence
L -> R
1.98s
192-193
76
Step 13-3
SHORT flame Step sequence
R -> L
1.98s
194-196
77
Step 2-14
SHORT flame Step sequence
L -> R
2.32s
197-198
78
Step 14-2
SHORT flame Step sequence
R -> L
2.32s
199-201
79
Step 8>5>11
SHORT flame Step sequence
M>L>R
0.93s
202-203
80
Step 8>11>5
SHORT flame Step sequence
M>R>L
0.93s
204-206
81
Step 5-11
SHORT flame Step sequence
L -> R
1.28s
207-209
82
Step 11-5
SHORT flame Step sequence
R -> L
1.28s
210-211
83
Wave 8-->13
Middle wave sequence
M -> R
1.70s
212-214
84
Wave 13-->8
Middle wave sequence
R -> M
1.70s
215-216
85
Wave 8-->3
Middle wave sequence
M -> L
1.60s
217-219
86
Wave 3-->8
Middle wave sequence
L -> M
1.60s
220-221
87
Wave 3-->13
LONG wave sequence
L -> R
3.06s
222-224
88
Wave 13-->3
LONG wave sequence
R -> L
3.06s
225-226
>89
8(0°)
Single Ignition LONG flame
Static
max. 8s
227-255
ΔDMX CONTROL
Channel
Function
Value
CH1
Manual Angle setup
0~255: angle change from -105° to 105°
128: straight upward (0° )
CH2
Manual Nozzle Waving
Speed setup
0 and 255: Max Speed
1~254: Speed increase
CH3
Ignition ON/OFF
0~253: Ignition OFF
254~255: Ignition ON
CH4
Firing Duration setup
0 and 255: permanent fire (10s is limit duration time)
1~254: 10~2540ms duration time
(Manual firing duration = DMX Value * 10ms)
CH5
Program sequence setup
0-2: no preset sequence
3-255: preset sequence
DMX value = 2 + Sequence No.*2.55 (ROUND OFF)
CH6
Mode setup
0~49: Firing OFF (Emergency Stop)
50~200: Firing ON
201~255: Firing OFF (Emergency Stop)
Channel 1 (CH1): Manual Angle Setup
Angle No.
Angle
DMX Value
1
-105°
0
2
-90°
18
3
-75°
36
4
-60°
54
5
-45°
73
6
-30°
91
7
-15°
109
8
0°
128
9
15°
146
10
30°
165
11
45°
183
12
60°
201
13
75°
219
14
90°
237
15
105°
255
1. The first channel controls the firing angle. It defines to which angle the nozzle of CIRCLE FLAMER move
to. The angle can be chosen anywhere between -105° to +105° (DMX value 0 to 255)

2. The DMX value for angle of 0° is 127.5 (round up 128). Use this value, following formula can be used
to calculate all other angles ∠in degree. Please always note the prefix of the angle
DMX Value = 127.5 + (∠*1.2145)
Channel 2 (CH2): Manual Nozzle Waving Speed Setup
CH2: Nozzle Waving Speed Setup
DMX Value
0
1-254
255
Speed
Max Speed
Incremental of Speed
Max Speed
The second channel defines the nozzle waving speed. It work together with Channel 1 for manual firing
Channel 3 (CH3): Ignition ON/OFF
CH3: Ignition
DMX Value
0-253
254-255
Ignition
Igniter disable (ignition OFF)
Igniter enable (ignition ON)
The third channel activates the actual ignition. If the DMX value of this channel higher than 253, the
CIRCLE FLAMER will ignite.
Channel 4 (CH4): Firing Duration setup
CH4: Manual Firing Duration setup
DMX Value
0
1
2
3
4
……
254
255
Firing Duration
Permanent
10ms
20ms
30ms
40ms
2540ms
Permanent
The fourth channel is the firing duration setup
Below formula can be used to calculate the firing duration (ms):
DMX Value = t/10
Channel 5 (CH5): Program Sequence setup
The fifth Channel allows to firing a preset sequence. Three DMX values can be used for one of the
programmed firing sequence from above sequence list (refer to above sequence list table).
Below formula can be used to calculate firing sequence:
DMX Value = 2 + Sequence No.*2.55
CH5: Sequence List
DMX Value
0~2
3~5
6~7
8~10
11~12
..........
225-226
Sequence No.
N/A
1
2
3
4
88
Channel 6 (CH6): Mode setup
The sixth channel is the working mode.
ΔOperation
1. Safety Distance
Definition and Instructions
Safety distance for uFlamer X1800 divided into two parts safety radius around machine (a) and safety
distance at firing direction (b). No person and flammable materials are allowed to stay inside the safety
zone when flamer was armed.
CH6: Mode setup
DMX Value
0-49
50-200
201-255
Mode
Firing OFF
Firing ON
Firing OFF

The safety radius around machine depends on the firing height (nozzle size), with a radius from 2.5m to
3m.
For safety distance at firing direction equals to maximum firing height * 1.5. uFlamer X1800 with
maximum 105 waving firing angles, when firing step sequence, wave sequence or additional
sequences the safety zone is a three-dimensional sector area.
Nozzle Type
Max. Flame Height
Safety Radius around
uFlamer X1800 (a)
Safety Distance at Firing
Direction (b)
SFSMA002 Nozzle M
10m
3m
15m
SFSMA003 Nozzle L
8m
2.5m
12m
The uFlamer X1800 safety zone is a three-dimensional space with a cross-section of 210° sector enclosed
by a and b (check below diagram). We can understand it as a safety area formed by a safety column with
diameter of a, height of b rotate of ± 105 degrees. Unauthorized persons and objects are strictly
prohibited from entering. Depending on the firing sequence / angles the sector area changes accordingly.
For angled installation, the safety distance both around machine and firing direction should shift
accordingly.
Safety distance in windy environment
The safety zone radius (a) and safety distance of firing direction (b) increase with wind direction and wind
speed (v, m/s). The safety distance in windy conditions can be calculated as below:
For Nozzle M: a = 3 + v; b = 15 + v
For Nozzle L: a = 2.5 + v; b = 12 + v
For example when the wind speed is 3m/s, we use the Nozzle M on uFlamer X1800, then the safety zone
radius should be 6m, safety distance of firing direction is 18m.
When the wind speed ≥8m/s (wind force ≥ 5), please use it with caution. When wind speed ≥17m/s
wind force ≥ 8 , please stop use uFlamer X1800.
Direction Explanation

There is direction explanation on top panel of uFlamer X1800 as show above picture.
1. 1 to 15 is the firing angle of X1800, Far Right is position 15, Middle is position 8, Far Left is position 1.
2. Audience side and control side are indicated in above picture.
Note: in order to indicate correct direction, please place the top panel correctly.
Fuels for uFlamer X1800
1. Water content in fuel should less than 0.5%
2. For maximum safety, please use fuel with flash point between 60-80 , ISOPAR L is highly
recommended.
SHOWVEN excludes liability for the losses, damages and accidents caused by not using qualified fuels in
accordance with this requirement.
Always have a dry powder fire extinguisher, a CO2fire extinguisher and an extinguishing blanket next to
the equipment in case of needed. And someone must be on duty during operation. In case accident
occurs, a dry powder fire extinguisher can be used when the fire is large, and a carbon dioxide fire
extinguisher can be used when the fire is small.
2. Install uFlamer X1800 and Pump Station
a) Choose the correct nozzle, ensure the installation position of uFlamer X1800 meet above safe
distance requirements. New uFlamer X1800 supplied with a nozzle M which generate up to 10m
flame.
b) Pump station can only be installed horizontally on a firm level surface. The installation place must be
well ventilated, do not install it in the open air or in a confined space. The equipment must be far
away from heat sources, fire sources, and objects that can cause fire. Always have a dry powder fire
extinguisher, a CO2fire extinguisher and an extinguishing blanket next to the equipment in case of
needed. In case accident occurs, a dry powder fire extinguisher can be used when the fire is large,
and a carbon dioxide fire extinguisher can be used when the fire is small.
c) uFlamer X1800 can be installed in any direction, be aware the bottom panel of uFlamer X1800 is not
waterproof if need installed in angles or upside down please install bottom panel waterproof shield
(RMSTE1062, optional part).

d) Make sure uFlamer X1800 is securely installed. For truss installations always connect with safety rope
to ensure extra safety. If there is any other national or regional guidelines please follow it accordingly.
e) Double confirm the machine are firmly installed.
3. Hose connection between flame head X1800 and pump station
According to the position of flame heads and pump station, various connection methods can be flexibly
adopted. Below are some examples.
a. Pump Station uPumper P20 –Main hose –Fuel dispenser –Branch hose –uFlamer X1800
b. Pump Station uPumper P20 –Main hose –T-shape dispenser –Branch hose –uFlamer X1800
c. Pump Station uPumper P4 –Main hose –T-shape dispenser –Branch hose –uFlamer X1800
4. Power and DMX cable Connection for flame head
Before power and/or DMX cable connection, make sure safety lock of uFlamer X1800 stay at TEST MODE.

If control by DMX, follow below steps:
a) Connect a power cable to the POWER IN socket of uFlamer X1800. Connect the other end of power
cable to the power source. Make sure power supply in consistent with the rated voltage of the
equipment, and the socket must well grounded.
b) Each unit of uFlamer X1800 can be connected to power supply directly. If connect machine in
sequence, please connect a power link cable to the POWER OUT of previous machine, connect the
other end of the power link cable to POWER IN of the next machine. Do not connect exceed units to
a single electrical circuit.
c) Power on all uFlamer X1800
d) Assign DMX address for each unit of X1800. If use SHOWVEN host controller or FXcommander to
control the machine please allocate a unique DMX address for each unit of machine.
e) Connect a DMX cable to the DMX IN socket of first unit of X1800, another head of this DMX cable
connect to pump station DMX OUT. If the pump station is controlled separately please connect the
other head of this DMX cable to DMX console (such as FXcommander).
f) Connect a DMX cable to the DMX OUT socket of previous X1800, and the other end to the DMX IN
of next machine. Connect all devices in series in this way.
g) Suggest to plug in a DMX terminator into the DMX OUT in last unit of machine to improve signal
reliability. Signal amplifier is required for long distance (>200m) DMX signal transmission.
If control by 9-60V pyro signal, follow below steps:
a) Connect a power cable to the POWER IN socket of uFlamer X1800. Connect the other end of power
cable to the power source. Make sure power supply in consistent with the rated voltage of the
equipment, and the socket must well grounded.
b) Each unit of uFlamer X1800 can be connected to power supply directly. If connect machine in
sequence, please connect a power link cable to the POWER OUT of previous machine, connect the
other end of the power link cable to POWER IN of the next machine. Do not connect exceed units to
a single electrical circuit.
c) Power on all uFlamer X1800
d) Set the Ext Ignite to ON status in advanced interface, set the firing sequence by choose a sequence
No. at Set Ext Sequence.
e) Connect the power control cables to the 9-60V pyro signal connector on uFlamer X1800.
f) Connect the other end of power control cables to the pyro controller (9-60V external trigger source).
Make sure the pyro controller is powered off.
5. Power and DMX connection for Pump Station
a) Connect a power cable to the POWER INPUT of Pump Station. Connect the other end of power
cable to the power source. Make sure power supply in consistent with the rated voltage of the
equipment, and the socket must well grounded.
b) Connect a DMX cable to the DMX IN socket of Pump Station, the other head of this DMX cable
connect to DMX console (such as FXcommander).
c) Power ON the Pump Station and DMX console
6. Programming
Program the uFlamer X1800 with DMX console.
7. Test the ignition function of Flame head uFlamer X1800
Test the ignition function of uFlamer X1800, we can check whether the igniters of each unit of X1800
is working fine. Due to the safety switch is stay at TEST MODE and pump station is under depressurize
status, there will be only ignition while no fuel spray out, so no flames generated.
8. Fill the Pump Station
Please fill the pump station with qualified fuel.
a) Water content in fuel should less than 0.5%

b) The fuels should meet the requirements of both flame head uFalmer X1800 and pump station.
c) uPumper P20 can only use fuel with flash point between 60-80℃, ISOPAR L is highly recommended.
ISOPROPANOL, Ethanol etc highly flammable fuels are forbidden to use on uPumper P20.
9. Pressurize
Pressurize the pump system through DMX console, we can check the pressure through pressure gauge
on both pump station and flame head uFlamer X1800. The working pressure range for uFlamer X1800
is 8-12bar. We can check whether pump station are work normally and hose connection are well
connected through this step.
Once confirmed very thing is fine, depressurize the whole system.
10. Firing
a) Double confirm the prescribed safety zone is clear, no person, animal or other property within in this
region.
b) Switch the safety switch of uFlamer X1800 to USER MODE.
c) Activate the pump station and pressurize for uFlamer X1800.
d) Firing, the operator should always have a clear view of the device, so that he/she can stop the show
immediately when there is danger.
11. Depressurize
Depressurize the system after use or if not use for a long time during the show we also suggest to
depressurize to ensure the safety.
12. Power OFF
a) Power OFF the pump station and DMX console after show
b) If need to disassemble the installation, please disconnect the fuel supply between pump station and
hose.
c) Switch safety switch of uFlamer X1800 to TEST MODE
d) Power OFF uFlamer X1800
e) Disconnect power cable, DMX cable and hose connections.
ΔNozzle Replacement
Use 14mm outer hexagon socket wrench to disassemble the nozzle, clean the nozzle and nozzle socket
with air gun (air compressor), change a different nozzle and install it.
Nozzle disassemble tool: SFMET944

ΔIgniter Position Adjustment
Whenever changed the nozzle or ignition is not good, please check igniter pole position according to
below parameters. The right position for each pair of pole should have a gap from tip to tip of 4± 0.5mm
and a gap between two igniter of 13± 1mm. Check the ignition success rate after adjustment by firing.
Note: Do unplug the power cable when service flamer.
ΔMaintenance
1. To maintain the system in good performance and running status, it is recommended to running the
device at least once per month.
2. Check the ignition probes both before and after each show, if there is any foreign objects on it please
clean it up.
3. Maintenance of the nozzle: Nozzle needs to be cleaned from time to time, and it is recommended that
once every six months (depending on the environment and frequency of use). In the process of using
the equipment, if the flame shape is seriously deformed or the fuel injection line is significantly
deformed or coarsened, the nozzle should be removed immediately for cleaning. If after clean, there
are still problems please replace new nozzle.
4. Maintenance of the O-ring: If it is found that the O-ring of the nozzle is damaged or ageing when
cleaning the nozzle, the O-ring should be replaced in time (material and size of O-ring: fluororubber O-
ring, the outermost diameter is 14 mm, and the line diameter is 2 mm).
5. Switchable power input design, switchable between 110V and 220V as show above picture (voltage
will show on it). The power supply is located on the side of the electric control, and you should remove
the cover before switch it.

ΔOptional Parts for uFlamer X1800
Part. No.
Description
pcs / unit
RMWAS025
O ring for nozzle
1
RMBOT036
Safety ring
1
RMMET045
Safety rope
1
RMEMD062
Wireless receiver ( for wireless control with
FXcommander)
1
SFSMA002
nozzle M
1
SFSMA003
nozzle L
1
SFMET944
Nozzle disassemble tool
1
RMSMA215
Angle block assembly
2
RMSTE472
1
RMSTE473
1
SFCAB065
Waterproof DMX cable, 6m
1
RMSTE1062
X1800 bottom plate waterproof cover
1

ΔWarranty Instructions
\Sincere thanks for your choosing our products, you will receive quality service from us
\The product warranty period is one year. If there are any quality problems within 7 days after shipping
out from our factory, we can exchange a brand new same model machine for you
\We will offer free of charge maintenance service for machines which with hardware malfunction
(except for the instrument damage caused by human factors) in warranty period. Please don't repair
machine without factory permission
Below situations NOT included in warranty service:
\Damage caused by use unqualified fuels;
\Damage caused by improper transportation, usage, management, and maintenance, or
damage caused by human factors;
\Disassemble, modify or repair products without permission;
\Damage caused by external reasons (lightning strike, power supply etc.)
\Damage caused by improper installation or use;
For product damage not included in warranty range, we can provide paid service.
Invoice is necessary when applying for maintenance service from SHOWVEN

PREMIUM FACTORY SAS - DISTRIBUTEUR OFFICIEL
1 Route Neuve, 71710 MONTCENIS – FRANCE Office
[phone] | [phone]
[email protected] | www.premiumfactory.eu
