Showven Sparkular User manual

USER MANUAL
SPARKULAR
V1.0
2021/05/27
Showven Technologies Co., Ltd

USER MANUAL
SPARKULAR
★Please read this manual carefully before operating this product.
★Warranty card attached in the manual, please keep it well.
▲SAFETY CONSIDERATIONS
\ Never touch the nozzle of SPARKULAR, danger of getting burnt
\ Never touch the sparks which shooting out from the nozzle
\ Cover of nozzle of SPARKULAR is prohibited
\ Keep audience, animals or flammable objects at a minimum distance of 3m from SPARKULAR.
Make sure sparks shoot out from SPARKULAR can NOT touch any objects in the air
\ Ensure that children, animals and unauthorized persons don’t have access to the SPARKULAR!
\ Unauthorized repair are prohibited, it may cause serious incident
\ Keep SPARKULAR dry and do NOT use in rain or snow
\ Make sure lid of feeding hopper are well covered when use SPARKULAR. Accidentally
burning of Composite Ti can only use sands to extinguish. Composite Ti should keep away from
moisture and stored in a dry sealed environment
\ please be noted that there may sparks or remains fall to the ground when use HC8200
MEDIUM and HC8200 LARGE
\ Clear material is necessary both before and after the show. Please check nozzle of
SPARKULAR after each show, if there are consumable agglomerated in the nozzle, please clear
it with screwdriver, otherwise it will affect the spark effects and even damage the machine
\ Maximum cascade of SPARKULAR is 6 units (3 units for 110V version SPARKULAR) with one
standard power cable. Otherwise it may damage the machine and even cause fire
\ For better heat dissipation, block the air intake and air outlet is prohibited
▲Description
SPARKULAR is original innovation products introduced by SHOWVEN, it is the first spark
fountain machine in special effects industry. SPARKULAR is designed for highly demanding
professional market with adjustable sparks height from 1.5 to 5m.

▲Technical Specifications
\ MODEL: BT01/BT02
\ DIMENSION: 200×218×305mm
\ WEIGHT: 8.5kg
\ VOLTAGE: 220V(BT01)/110V(BT02), 50/60Hz
\ WORK POWER: 500W
\ EFFECT HEIGHT: 1.5-5m adjustable
\ INTERFACE: 3-pin XLR, POWER IN/OUT
\ CONTROL: DMX 2 channels
▲Operation Panel
1. LED display area:
READY DMX FAU LT HEAT
READY: Flash means machine is preparing, LED keeps on means ready to operate
DMX: Flash means DMX signal is connected, light OFF means there is no DMX signal
FAULT: Light ON when error occurs
HEAT: Light ON when system is heating up
2. Control button area:
MENU DOWN UP ENTER
MENU: switch through setup menu
DOWN: parameter down
UP: parameter up
ENTER: confirm and save parameters
3. Interface and Plugging Area
T6.3A
250V
POWER IN: power in
POWER OUT: power out
DMX IN: DMX Communication Signal Input
DMX OUT: DMX Communication Signal Output

3. RFID area:
RFID card comes together with HC8200, it is a safety design, allow machines to identify the
parameter and types of consumable it adding to the hopper of machine. It is obligatory to
swiping the card before adding the consumable HC8200 to the hopper of machine.
Note: Please note that the card enables the unit for 10-20 minutes of operation (which is the
amount of time each bag of HC8200 last). The RFID card is disposable and it is disabled after it
has been swiped.
▲Interface
1. Main Interface:
DMX Address 1
580
Displays DMX Address
Display inner core temperature of machine
Display error information when error occurs
2. Error information:
Error information
Explanation
E0 System IC
Systematic error
E1 Motor Protect
Over current protection of the motor
E2 Temp. Sensor
Temperature sensor is not connected or
damaged
E3 P Temp. Over
The equipment stops due to the over
temperature of the chassis
E4 Time Remain
Activated time for the machine is not
enough, please swip RFID card
E5 K Temp. Over
The equipment stops due to over
temperature of the inner core
E6 Heat Fail
Heating fail, problem on heating PCB of
mainboard
E7 Tip Over
Tilt sensor activated when machine slant
more than 45 degree

3. Setting Menu:
Press “MENU” switch through setup menu.
4. DMX address setup for SPARKULAR:
Sparkular No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
DMX Address
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
Note: DMX address must set according to above rules.
If use together with HOST CONTROLLER ZK6200/6300, each unit of SPARKULAR must use
different DMX address, otherwise it may leads to signal interference.
5. Advanced Interface
Options
Range
Explanation
Set DMX Address
1-512
Set DMX Address.
Fountain Height
1-10
10 gears of fountain height, manually
adjust the height of sparks.
Manual Fountain
ON/OFF
Auto preheat function switch after turn on
machine. If it is ON, machine will heating up
automatically after turn on. If it is OFF,
operator need to start heating up on HOST
CONTROLLER or DMX console.
Manual Fountain
ON/OFF
Automatic clear material settings
Options
Range
Explanation
Set Temperature
500-610
Setup SPARKULAR inner core temperature
Wireless Control
ON/OFF
Wireless ON/OFF, for wireless version only
LCD Backlight
ON/OFF
LCD Backlight ON/OFF
Density@ Height 1
30-50
Adjusts the sparks density of Height gear 1*
Density@ Height 2
30-50
Adjusts the sparks density of Height gear 2*
Density@ Height 3
30-50
Adjusts the sparks density of Height gear 3*
Density@ Height 4
30-60
Adjusts the sparks density of Height gear 4*
Density@ Height 5
30-70
Adjusts the sparks density of Height gear 5*
Density@ Height 6
40-100
Adjusts the sparks density of Height gear 6*
Density@ Height 7
40-100
Adjusts the sparks density of Height gear 7*
Density@ Height 8
40-100
Adjusts the sparks density of Height gear 8*
Density@ Height 9
40-100
Adjusts the sparks density of Height gear 9*
Density@ Height 10
40-100
Adjusts the sparks density of Height gear 10*
Mode Selection
Factory Mode
User Mode
Factory mode is for engineer only. When in
Factory mode machine can’t controlled by
DMX console/host controller
Default Parameter
Press ENTER in this interface, all parameter
of machine restore to default value.

*For better performance of SPARKULAR, please don’t change the default value of density
without permission from SHOWVEN.
6. DMX Channel Mode:
The system occupies two channels.
Motor Protect
ON/OFF
Motor protect function, default setting is
OFF
Power Selection
220/110Vac
Select input power supply voltage
Default setting for BT01 is 220VAC. BT02 is
110VAC
First Channel
Function
0-15
Fountain Off
16-39
Fountain Height 1
40-63
Fountain Height 2
64-87
Fountain Height 3
88-111
Fountain Height 4
112-135
Fountain Height 5
136-159
Fountain Height 6
160-183
Fountain Height 7
184-207
Fountain Height 8
208-231
Fountain Height 9
232-255
Fountain Height 10
Second Channel
Function
60-80
Clear Material
20-40
EMERGENCY STOP
0-10
Pre-heat OFF
240-255
Pre-heat ON

HOST CONTROLLER
▲Description
The Host Controller is an intelligent system specially designed for the multi-effects and remote
control of SPARKULAR series products, so as to realize the simulation and demonstration of
multi dynamic effects. The Host Controller has multiple interface types and control mode
adapting to modern stage, except DMX communication, it can also be triggered by Audio and
MIDI time code to achieve music synchronization, and use LAN to achieve collaboration and
communication between multiple host controllers.
▲Technical Specifications
\ MODEL: ZK6200/ZK6300
\ DIMENSION: 390×300×110mm
\ WEIGHT: 3.5kg
\ VOLTAGE: 100-240V, 50/60Hz
\ POWER: 15W
\ MAX CASCADE OF SPARKULAR: 18units (ZK6200)/ 54units (ZK6300)
\ SUPPORT MACHINES: SPARKULAR series, CIRCLE FLAMER series, SONICBOOM series
▲Host Controller Introduction –Standard or Pro Version
1. Standard DMX512 signal output
2. Support 18 units Sparkular at the same time (ZK6300 54 units).
3. Five standard dynamic effect modes: Synchronization, Center to Ends, Ends to Center, Left to
right, Right To Left, Special Effects and one user-definable special effect mode (together with
SPARKULAR Edit 200 software from SHOWVEN), supports 8 files and each file supports 36000
lines at maximum (special effects last for 30 minutes)
4. There are multiple optional trigger sources. Hand, Music or Midi Inputs.
5. Support simulation function and LED display.
6. Monitoring function: Host controller with RDMX function, can feedback status information
such as Temp., error message etc. of each machine.
7. Emergency stop function: Pause or Stop Button.

▲Controller Operation Panel
1. Cable Connection Area:
AC Input: AC Power Input.
CAN: CAN Communication Input/Output Ports.
Tape In: Audio Signal Input Port of Main Channel
Aux: Audio Signal Socket of Side Channel.
Music: Displaying the Electrical Level of Audio Signal.
MIDI In: Time Synchronous Signal Input of MIDI thru output.
DMX 512: DMX Signal port
LAN: Network’s Cascade Socket among Multi-Chassis, so as to link the remote control feature.
Download: SparkularEdit200 software Port
2. Manual Operation Area:
No.1 to No.18 is Sparkular number.
Firing / Stop of each unit of Sparkular by press related key of 1 to18.
The Sparkular can be operated after the Pre-Heat warm up for 5 minutes. The indicator light
will switch from flash green to always-on when heating up was ready. When firing is activated
the indicator light will change to Red. Press “FIRING “to shoot/stop the SPARKULAR machine.

3. Mode Selection Area:
There are five standard dynamic modes and one special effects mode which can be initiated by
pressing the keys. These activate a pre-programmed page of functions that are displayed on
each selection.
4. LCD Area:
F1: Main Menu
F2: File Selection Menu
F3: Configuration Menu
F4: About Menu
5. Edit/Control Area:
Parameters can be programmed through number keys or up/down keys.
Test: For test/demonstration of edit effects. When press the Test, Sparkular file will be operated
and LED will display theeffect, but communication won’t be output. This is also for factory
testing.
Pause: Device can be forced to stop once any abnormality happens. Pre-heat also shuts off.
Forward: Under the special effect mode, the operating time can be put forward.
Rewind: Under the special effect mode, the operating time can be put backward.
Clear Material: Clear material of SPARKULAR before and after each show, to clean the
remaining consumable in the heating chamber, avoid blocking of the SPARKULAR.

Pre-heat: Press “Pre-heat” to heating up the SPARKULAR. It takes around 5min. For long time
not use the machine, suggest to turn off the “Pre-heat” function and allow SPARKULAR to
return to normal temperature.
Firing: Activate/stop SPARKULAR programming. Left and right keys can make the cursor move
on the different parameters.
Parameters can be edited through up/down keys and number keys and it will be saved
automatically. The confirm key can also be initiated to save.
▲Interface
1. Main Menu:
MODE: Effect Mode
GROUP: Total Quantity of Devices.
Battery logo shows battery capacity and when it decrease to one grid, please charge it.
F1 MAIN
MODE:Center ToEnds Group:12
F I L E
NO.
Terminal Monitor
FI RING
HEIGHT
9 1.2s
DURTN
F I R I N G TRIG
DELAY
0.3s 4.0s 2
REPEAT
COUNTS
REPEAT
DELAY
1
1
7
13
2
8
14
3
9
15
4
10
16
5
11
17
6
12
18
MAIN FILE SELECT CONFIG ABOUT
Note: Only “Pause or Stop, Forward”, “Rewind” button are available when “Firing” button
lighting. Please note the setting for “repeat counts”to avoid mutli repeat of effects.
Monitor: The working status of SPARKULAR will show on the LCD screen of host controller.
Normal ly it shows the core temperature of SPARKULAR, when there are error information it
will also show in this area.
2. Error Information
Please refer to the error information of the machine.
Option
Scope
Illustration
FILE NO.
1-8
File number
FIRING HEIGHT
1-10
Fountain Height gear. “.” button can
change height10 directly.
FIRING DURATION
0.1-30.0s
Duration of the Fountain
TRIGER DELAY
0.1-30.0s
Trigger delay between two machines
REPEAT PERIOD
0.1-30.0s
Time to start of next sequence/period
REPEAT COUNTS
1-5
Repeated times

3. File Select: F2
F2 displays the parameters list of 8 preset files.
F2 FILE SELECT
MODE: Synchronization
FILE
No.
1
2
3
4
5
6
7
8
3
9
3
9
9
9
9
9
5.0s 0.0s
0.8s
5.0s
0.4s
0.5s
1.0s
1.0s
1.0s
5.0s
0.0s
0.0s
0.0s
0.0s
0.0s
0.0s
0.0s
1.0s
7.0s
1.0s
5.0s
3.0s
2.0s
1.0s
1
1
2
1
2
3
2
1
NEIGHT
FURING FIR IN G
DURTN DELAY DELAY COUNTS
TRIG REPEAT REPEAT
4. Configuration Menu F3
F3 CONFIG
SPARKULAR End No. : 6
Trigger Source : HAND
Audio Level : 2
Audio Stop : Firing Stop
Audio Filter Delay : 20ms
Mode Selection : Factory Mode
LAN : OFF
Language : EngLish
Repeat Time Mode : Repeat Delay Mode
SPARKULAR Start No. : 1
Option
Scope
Description
SPARKULAR Start No.
1-18
Select range
SPARKULAR End No.
1-18
Select range
Trigger Source
HAND,AUDIO,MIDI
Trigger Sources options under special effect
mode
Audio Level
1,2,3,4
Voltage classes1-4 after choosing Audio
Trigger Mode
Audio Filter Delay
10-100ms
Time to The filtering time of trigger signals
after choosing Audio Trigger Mode start of
next sequence/period
Mode Selection
User Mode
Factory Mode
Factory Mode only used for the factory test
LANGUAGE
ENGLISH/CHINESE
Language switch
REPEAT TIME MODE
Repeat period
Repeat Delay
Repeat period: Cycle timing start when first
machines start to work. (chasing effects can
realize with this mode)
Repeat delay: Cycle timing start when the
first firing cycle terminate

5. The Use of the Special Effect Mode:
Special effects are edit on SparkularEdit200 software with computer, effects file can download
to host controller with USB cable. For more information please refer to SparkularEdit200
manual.
Trigger Source
HAND: When Trigger Source select HAND, press Firing to activate programming.
AUDIO: Audio Trigger interfered easily, and it can be triggered only one time, it activated
when audio signal appears. There are audio signal light on the Music window, and Audio Level
1-4 corresponding to bottom to top.
When Audio Level is 1 and Audio Filter Delay is 50ms, when audio signal appear, first light of
Music is on and lasts for 50ms, and the file was activated.
In order to prevent the mistake trigger, before use AUDIO trigger function, please set Trigger
Source at HAND, connect audio signal to normal audio signal source, and select AUDIO.
According to the level of audio signal select proper Audio Level, Audio Filter Delay.
MIDI: When Trigger Source is set as MIDI, the operation of the device can be started and
stopped synchronously by MIDI Time Code (MTC).
No matter which mode the Trigger Source selected, the operation of the device can be started
and stopped synchronously by SparkularEdit200 connected computer.
▲System Configuration and Connection
1. System Configuration:
2. System Connection:
DMX IN
ON/OFF
On: DMX in activated, when there is DMX in
signal, host controller will be locked, and
DMX signal will transfer to SPARKULAR.
OFF: DMX in disabled.
DMX Address
1-512
When use DMX IN function of Host
controller, the DMX address of host
controller.
LAN
Reserve for future use. Default value is OFF.

(1) Controller and Sparkular:
Host Controller (ZK6200)
DMX Communication Cable
T6.3A
250V
Sparkular
(2) Controller and Sparkular:
T6.3A
250V
Sparkular
Power Supply Cable
(3) Power Link Cable Connection between Sparkular:

T6.3A
250V
Sparkular
Power Link Cable
T6.3A
250V
Sparkular
(4) Communication Cable Connection between Sparkular:
T6.3A
250V
Sparkular
DMX Communication Cable
T6.3A
250V
Sparkular
▲System Prepare and Start

1. Fill the Sparkular consumable HC8200 to Sparkular:
Please fill in Sparkular Granules HC8200 into the hopper. Maximum volume for the hopper is
200g. There are three typesof HC8200 for SPARKULAR.
2. Open HC8200 pouch:
SMALL MEDIUM LARGE
3. Fill SPARKULAR hopper:
Warning: Please fill SPARKULAR by following above process. After adding the consumable,
please do remember to close the lid.
4. Turn On Host Controller:
Switch on host controller as below
5. Turn On Sparkular:
Model
HC8200 SMALL
HC8200 MEDIUM
HC8200 LARGE
Effect height
1.5-3m
1.5-3.5m
2-5m

Switch on Sparkular
T6.3A
250V
6. Parameters setup:
Programming SPARKULAR effects according to this manual.
7. Activate Sparkular machine:
Swip an RFID card after filling each bag of HC8200. Read the card as show below. SPARKULAR
shows time remain if read successfully. SPARKULAR report E4 when remaining time is less than
10 minutes.
CN. 00000001
8. Firing
Activate programming effects by press “FIRING” on the host controller.
9. Turn Off
After show, please power off Sparkular and host controller. Allow SPARKULAR to cool down
before packing. Never touch the nozzle of SPARKULAR. DANGER OF BURN!
10. Lear Material
Please running Clear Material both before and after each show. Before delivery or not use
machine in a long time, please pouring the HC8200 out of hopper, and store the remaining
HC8200 in a dry sealed bottle for next time use.
Warning: Please follow this process to clear material when necessary.

Warranty Instructions
▲Sincere thanks for your choosing our products, you will receive quality service from us
▲The product warranty period is one year. If there are any quality problems within 7
days after shipping out from our factory, we can exchange a brand new same model
machine for you
▲We will offer free of charge maintenance service for machines which with hardware
malfunction (except for the instrument damage caused by human factors)in warranty
period. Please don't repair machine without factory permission
Below situations NOT included in warranty service:
1. Damage caused by improper transportation, usage, management, and maintenance, or
damage caused by human factors;
2. Disassemble, modify or repair products without permission;
3. Damage caused by external reasons (lightning strike, power supply etc.)
4. Damage caused by improper installation or use;
For product damage not included in warranty range, we can provide paid service.
Invoice and warranty card are necessary when applying for maintenance service from
SHOWVEN.
Warranty Card
Product Name:
Serial No.
Purchase Date:
Tel:
Address:
Info. feedback
about the
problem:
Actual problem:
Maintenance
detail:
Service Engineer:
Service Date:

Showven Technologies Co., Ltd.
Tel: [phone]
Web: www.showven.cn E-mail: [e-mail]
Add: Liuyang Economic Development Zone, Changsha, 410300, Hunan Province,
P.R.China
