Shure Microflex MX200 Series User manual

General Description
Shure Microflex®MX200 Series microphones are miniature electret condenser
microphones designed for miking choirs and performance groups. They are
typically suspended over the heads of the performers. Their high sensitivity
and wide frequency range make them suitable for recording, as well as sound
reinforcement applications. An attached 101 mm (4 in.) gooseneck allows
them to be easily aimed at the sound source.
• Wide dynamic range and frequency response for accurate sound repro-
duction
•Interchangeable cartridges that provide a choice of polar pattern for each
application
• White or black finish that blends unobtrusively with most surroundings
• RF filtering
Model Variations
Microflex MX202 microphones are available in black or white with a choice
of in-line preamplifier or plate-mount preamplifier.
The polar pattern of the included cartridge is indicated by a model number
suffix:
/C Cardioid
/S Supercardioid
/N Cartridge not included
Interchangeable Cartridges
Microflex microphones use interchangeable cartridges that allow you to choose the polar pattern for different installations.
Omnidirectional Supercardioid Cardioid
R183 R184 R185
Cartridge Polar Patterns
Snap-Fit Windscreen
• Snap into the groove below the cartridge.
• To remove, spread the gap with a screwdriver or thumbnail.
• Provides 30 dB of "pop" protection.
1/5©2017 Shure Incorporated
MX200 Series
Overhead Microphones

Preamp Gain
If necessary, the preamplifier gain can be reduced by 12 dB. Contact an authorized Shure service center for information.
R6 and R4
R13 and R16
Q8
Q9
Q2
Q6
Q1
Q5
Q3
D1
Q4
Q7
C10
C11
C6
C9
C3
C11
RFI Filtering
Important: Microphones must be used with the RK100PK and RK202PK
plate-mounted preamp to optimize RF immunity.
Microphone Placement
The microphone is most stable when the gooseneck is bent into a "lazy S"
shape. Use the supplied hanging clip and heavy thread or monofilament
fishing line to suspend the microphone at a specific location.
• For choir installations, hang a microphone 0.6 to 0.9m (2 to 3 ft.) in front
of the first row, and 0.6 to 0.9m (2 to 3 ft.) over the heads of the singers
in the last row. Aim the microphone at the back row.
• When miking groups that move or vary in size, use a boom stand and
the supplied stand adapter.
• If four or more microphones will be open at once, an automatic mixer,
such as the Shure SCM810 or SCM410, is recommended. Set up the
automatic mixer so that all overhead microphones gate on simultaneously.
.6 – 1 m
(2 – 3 ft.)
.6 – 1 m
(2 – 3 ft.)
1.8 – 3m
(6 – 9 ft.)
0.6 – 1m
(2-3 ft.)
Permanent Installation
Installing the In-Line Preamp
Shure IncorporatedMX200 Series Overhead Microphones
2017/11/012/5

Use the two supplied mounting clamps to hold the preamp in place on a wall or ceiling.
Ceiling Tile Installation
1. Drill a 1/2 in. hole into the ceiling tile. CAUTION: To avoid tile damage, use a 1/2 in. augur bit and drill very slowly.
2. Unplug the mini 4-pin connector from the preamp and feed the cable through the hole.
3. Place the rubber grommet, tip down, over the cable and position it to suspend the microphone at the appropriate height.
4. Fit the grommet securely into the hole. For 5/8 in. ceiling tile, use the suppled washer.
5. Reconnect the preamp.
1/2"
Plate Mount Preamp Installation
The plate-mounted preamp allows you to mount the preamp in an electical box and use conduit to run cable through ceilings and walls.
1. Remove preamp housing by removing two phillips head screws.
2. Remove knock-out from the hole in the center of the cover plate (if present).
3. Cut cable to desired hanging length, allowing for a 76 to 101 mm (3 to 4 in.) service loop.
4. Clamp strain relief around cable and insert strain relief into hole in plate.
5. Connect cable leads to input terminal block (B = Black, R = Red, S = Shield).
6. Using professional-quality, two-conductor, shielded microphone cable, thread output cable from outside of preamp through hole with black bushing.
7. Connect cable to output terminal block (Pin 2 = +, Pin 3 = –, Shield = S).
8. Reattach the preamplifier housing.
Shure IncorporatedMX200 Series Overhead Microphones
3/52017/11/01

INPUT OUTPUT
Specifications
Note:Yellowing of any plastic material can be caused from cigarette smoke,
ultra violet rays, and other chemical interactions. Once plastic has yellowed,
there typically is no cleaning method that will restore the whiteness.
Accessories
Furnished Accessories
RK183WSBlack Snap-Fit Foam Windscreens (4) for BETA98,
BETA98A, BETA98/S, BETA98D/S, BETA98H/C,
MX183, MX184, MX185, MX202, WH30, WL183,
WL184 and WL185Black Snap-Fit Foam Windscreens
(4) for Beta 98, Beta 98A, Beta 98/S, Beta 98D/S, Beta
98H/C, MX183, MX184, MX185, MX202, WH30,
WL183, WL184 and WL185
95B2064White Snap-Fit Windscreen
RK202PKPreamplifier Kit, Plate Mounted, White (MX202BP and
MX202WP)
65B1752Stand Adaptor (MX202B and MX202W)
Optional Accessories
A202BBSmall Black Desk/Table Stand for MX202 Microphones
Replacement Parts
RK100PKRFI Resistant, Inline Preamp for all MX Models (Black)
RK100PKWRFI Resistant, Inline Preamp for all MX Models (White)
R183BBlack or White Omnidirectional Cartridge for all MX-
(Microflex®) Models and WL183
R183WWhite Omnidirectional Cartridge for MX- (Microflex®)
Models
R184BBlack or White Supercardioid Cartridge for all MX-
(Microflex®) and WL183, WL184 and WL185 Models
R184WWhite Supercardioid Cartridge for MX- (Microflex®)
Models
R185BBlack or White Cardioid Cartridge for WL185 and all
MX- (Microflex®) Models
R185WWhite Cardioid Cartridge for MX- (Microflex®) Models
80A479Strain Relief (MX202BP and MX202WP)
80A476Clamp (MX202B and MX202WP)
80B489Hang Clip
Shure IncorporatedMX200 Series Overhead Microphones
2017/11/014/5

氏
NERO
RED
SCHWARZ NEGRO
(30.0 ft.)
9.1 m
(5.69 in.)
144.5 mm
(1.39 in.)
35.4 mm
(0.23 in.)
5.8 mm
(0.46 in.)
11.7 mm
(.33 in.)
(0.75 in.)
19.0 mm
(4.00 in.)
101.6 mm
Certifications
Meets essential requirements of all applicable European Directives.
Eligible for CE marking.
The CE Declaration of Conformity can be obtained from:
www.shure.com/europe/compliance
Authorized European representative:
Shure Europe GmbH
Headquarters Europe, Middle East & Africa
Department: EMEA Approval
Jakob-Dieffenbacher-Str. 12
75031 Eppingen, Germany
Phone: [phone]
Fax: [phone]
Email: [email protected]
Shure IncorporatedMX200 Series Overhead Microphones
5/5
