Shuttle X27D User manual

Product Specification
www.shuttle.com
Shuttle Computer Handels GmbH
Fritz-Strassmann-Str. 5
25337 Elmshorn | Germany
Tel. [phone]
Fax [phone]
[email protected]
Pa
g
e 1
|
10
D
ecember 2008
©2008 by Shuttle Computer Handels GmbH (Germany).All information subject to changewithout notice. Pictures for illustration purposes only.
Shuttle Barebone X27D –
Stylish Simplicity
The ultra-compact Shuttle Barebone X27D comes with an
integrated Dual Core Intel Atom processor. Its visual appearance
shines with coated surfaces and mirrored plates. The optical drive
and front panel connectors are elegantly concealed behind drive
doors to provide maximum protection. This tiny tot with barely 7cm
in height and a volume of 3 litres comes up with DVI, support for
DDR2 memory and SATA2 as well as a vast array of interfaces and
connectors. Ideal for use with internet and office applications.
Feature Highlight
X chassis
• Slim X-series chassis, black color
• Dimensions: 25 x 18.5 x 7 cm (L/W/H)
• Bays: 1x 2.5”, 1x for slim optical drive
CPU • Intel ATOM 330 Dual Core, 2x 1.6GHz
Chipset • Intel 945GC + ICH7
Graphics
• Integrated GMA950 graphics
• 224MB Shared Memory
• Digital DVI and analog VGA output
Memory • 1x 240 pin DIMM socket
• Supports max. 2GB DDR2-533/667
Drive
connectors
• 2x SATA II (3 Gbit/s)
• 1x IDE ATA 100
• Preinstalled Serial ATA cables
Other
connectors
• 5.1 HD audio
• USB 2.0 (4x rear, 2x front, 4x onb.))
• Gigabit LAN
• Serial port, PS/2 ports
Power supply • External 60W fanless power supply
Application • Basic
Shuttle
X
-Series Barebone
X27D
Images for illustration purposes only.
The optical drive is not included.
Dual
Core

Product Specification
www.shuttle.com
Shuttle Computer Handels GmbH
Fritz-Strassmann-Str. 5
25337 Elmshorn | Germany
Tel. [phone]
Fax [phone]
[email protected]
Pa
g
e 2
|
10
D
ecember 2008
©2008 by Shuttle Computer Handels GmbH (Germany).All information subject to changewithout notice. Pictures for illustration purposes only.
Shuttle X-Series Barebone X27D – Special Product Features
Built-in Intel® Atom™ Processor
The Shuttle Barebone X27D comes with embedded Intel® Atom™ 330
dual core processor which is based on an entirely new x86-design
which consumes only a few watts of power, but powerful enough to
connect to business, enjoy entertainment and enable a big Internet
experience.
Intel® Graphics Media Accelerator 950
The Intel GMA 950 is an intelligent and responsive 256-bit graphics
engine built into the chipset that is on the mainboard. It supports 224
MB maximum shared memory and 2048x1536 at 75 Hz maximum
resolution.
Dual View Technology with DVI and VGA
Dual View technology offers multiple display support on up to two
separate monitors. This allows more users to see the desktop image at
the same time. The integrated graphics supports clone mode.
DVI output
The Digital Visual Interface (DVI) allows the signal to stay the way it was
intended to be all the way to the end display and this results in a far
more compelling image that is razor sharp and wonderfully vibrant.
Gigabit LAN Network
Today’s media-rich communications across the Internet and within
organizations are creating new demands on clients in Local Area
Networks. For that reason Shuttle introduces the Gigabit LAN perfor-
mance even in the business and entry level segment of their Mini-PC
line.
High speed USB 2.0 interface
The back panel provides 4 USB 2.0 ports which support up to 480 Mb/s
data transfer rate for data intensive external devices.
SATA 3Gb/s storage interface for 2.5” HDD
High speed storage improves transfer rate for improved data access.
The SATA II specification doubles bus bandwidth from 1.5Gb/s to 3Gb/s.
The Shuttle Barebone X27D supports one 2.5” hard disk drive.
Great connectivity
Behind the front panel door you will find two USB’s for USB stick, external
drives, MP3 players etc. and 1/8 inch (3.5 mm) jacks for headphone
and microphone, which can be used for a head-set. At the back
panel you can connect your input devices by PS/2 or USB. The audio
jack can be configured as Mic/Line-in/Line-out or 6-ch audio.
Images for illustration purposes only.

Product Specification
www.shuttle.com
Shuttle Computer Handels GmbH
Fritz-Strassmann-Str. 5
25337 Elmshorn | Germany
Tel. [phone]
Fax [phone]
[email protected]
Pa
g
e 3
|
10
D
ecember 2008
©2008 by Shuttle Computer Handels GmbH (Germany).All information subject to changewithout notice. Pictures for illustration purposes only.
Shuttle X-Series Barebone X27D Specifications
Chassis
Slim X-type chassis, silver black
Dimensions: 250 x 185 x 70 mm (LWH) = 3.2 litres
Front doors for optical drive and front panel connectors
Mini-iTX Mainboard: 17 x 17 cm
Storage
bays
1x 2,5" (internal) for hard disk
1x for optical drive in slimline format
With pre-installed SATA cables
Power
Supply
External 60W power adapter (fanless)
Input: 100~240V AC, max. 2A
Output: 12V DC, 50/60 Hz, max. 5A
Internal DC-DC daughter board
Chipset Intel® 945GC+ICH7 Express Chipset
Embedded
Processor
Intel ATOM 330 processor (Codename: Diamondville)
2x 1.6 GHz core clock, 533 MHz FSB
2x 512kB L2 cache
Supports Hyper-Threading (4 threads total)
TDP = 8 watts
Passive CPU cooling
Memory
Support
1x 240 pin DIMM slots
supports DDR2-533/667 DDR SDRAM memory
supports max. 2GB capacity
Expansion
Slots not available
Integrated
Graphics
Intel Graphics Media Accelerator 950 (GMA950)
with PCI-E x1 improved bandwidth, features 333MHz graphics core
DX8/DX9 support and enhanced 3D performance
Dynamic Video Memory Technology (DVMT) 3.0, shared Memory max. 224MB
Video out: Digital DVI-D and Analog 15pin D-Sub VGA
Supports Dual Monitor operation in clone mode.
6-channel
Audio
Audio Realtek® ALC 662 6-channel High-Definition Audio
Three analog audio connectors (3.5mm) at the Back-Panel:
1) Front Line out (head phone)
2) Rear Surround line-out (shared with microphone input)
3) Center line-out (shared with Line in)
Gigabit LAN
Controller
Realtek 8111C Ethernet network controller (Gigabit)
Supports 100 / 1.000 MBit/s operation
Supports Wake-on-LAN (WOL)

Product Specification
www.shuttle.com
Shuttle Computer Handels GmbH
Fritz-Strassmann-Str. 5
25337 Elmshorn | Germany
Tel. [phone]
Fax [phone]
[email protected]
Pa
g
e 4
|
10
D
ecember 2008
©2008 by Shuttle Computer Handels GmbH (Germany).All information subject to changewithout notice. Pictures for illustration purposes only.
Drive
connectors
2x Serial-ATA II, 3 Gb/s (300 MB/s) bandwidth,
1x IDE ATA 100 drives
Note: This barebone system comes with pre-installed SATA cables for a 2.5" hard disk and for
an optical slim drive. If you want to use an optical drive with IDE connector (PATA) then an
additional Slim IDE Adapter with IDE ribbon cable is required, which is not included in the
package.
Front panel
Microphone input
Audio Line-out (headphone)
2x USB 2.0
Power button
Power LED
HDD LED
Back panel
connectors
DVI connector (digital)
VGA connector (D-Sub 15 pol., analog)
4x USB 2.0
GigaBit LAN (RJ45)
PS/2 for mouse and keyboard
Serial port (COM)
Audio Line-in
Audio Line-out
Audio Mic-in
Other
onboard
connectors
4x USB (two 2x5 pin headers)
Audio-in for CDROM (4-pin)
20-pin ATX power supply connector
2x fan connectors (4 pin, one for north bridge fan)
Accessories
Multi-language user guide,
32-bit / 64-bit Driver CDROM,
2x cable for SATA (preinstalled)
Power cord
Screws

Product Specification
www.shuttle.com
Shuttle Computer Handels GmbH
Fritz-Strassmann-Str. 5
25337 Elmshorn | Germany
Tel. [phone]
Fax [phone]
[email protected]
Pa
g
e 5
|
10
D
ecember 2008
©2008 by Shuttle Computer Handels GmbH (Germany).All information subject to changewithout notice. Pictures for illustration purposes only.
Shuttle X-Series Barebone X27D – Connectors
Front Panel Back Panel
9
10
11 12 15 16 17 18
19
1 2 3 4
13
7
5 6
14
8
1 USB 2.0 9 PS/2 mouse
2 Microphone input 10 PS/2 keyboard
3 Head phone output 11 Serial port
4 USB 2.0 12 Digital DVI video output
5 HDD LED 13 Analog VGA video output
6 Power LED 14 Gigabit LAN (RJ45)
7 Slim format optical drive 15 4x USB 2.0
(drive not included) 16 Microphone input
Pre-installed SATA cables 17 Audio Line-out (head phone)
8 Power button 18 Audio Line-in
19 Input for power supply voltage
Mainboard Overview
Processor:
Intel Atom 330
(embedded)
Backpanel connectors
Fan connector
ITE 8718F
I/O controller
Fan connector
Intel 945GC
Northbridge
240 pins DDR2
DIMM socket
ATX Power
Connector
Audio codec
CD-in header
Front Panel header
2x2 USB headers
Clear CMOS
Jumper
Battery
Intel ICH7
Southbridge
BIOS chip
IDE (PATA)
2x Serial ATA
Power button header
Gigabit LAN chip
DVI physical chip
Daughterboard with
DC-DC-Converter

Product Specification
www.shuttle.com
Shuttle Computer Handels GmbH
Fritz-Strassmann-Str. 5
25337 Elmshorn | Germany
Tel. [phone]
Fax [phone]
[email protected]
Pa
g
e 6
|
10
D
ecember 2008
©2008 by Shuttle Computer Handels GmbH (Germany).All information subject to changewithout notice. Pictures for illustration purposes only.
Shuttle X-Series Barebone X27D – Required components
Just add a few components and you will get a fully configured Mini-PC system:
Slim SATA
DVD drive
2.5” SATA-hard disk
DDR2-533/667/800
Memory module max. 2GB
Windows / Linux
Operating System
Note:
This barebone system comes with pre-
installed SATA cables for a 2.5" hard
disk and for an optical slim drive. If you
want to use an optical drive with IDE
connector (PATA) then an additional
Slim IDE Adapter with IDE ribbon cable
is required, which is not included in the
package.
