Shuttle XS35V5 Series User manual

For the : XS35V5 Series
XPC BIOS User Guide

Shuttle®
XPC Installation Guide
Copyright
©2015 by Shuttle® Inc. All Rights Reserved.
No part of this publication may be reproduced, transcribed, stored in a retrieval system,
translated into any language, or transmitted in any form or by any means such as electronic,
mechanical, magnetic, optical, chemical, photocopy, manual, or otherwise, without prior
written permission from Shuttle® Inc.
Other brands and product names used herein are for identification purposes only and may
be trademarks of their respective owners.
Disclaimer
Shuttle® Inc. shall not be liable for any incidental or consequential damages resulting from
the performance or use of this product.
Shuttle® Inc. makes no representation or warranty regarding the contents of this ma-
nual. Information in this manual had been carefully checked for accuracy;however, no
guarantee is given as to the correctness of the contents. For continuing product improve-
ment, Shuttle® Inc. reserves the right to revise the manual or make changes to the speci-
fications of this product at any time without notice and obligation to any person or entity
regarding such change. The information contained in this manual is provided for general
use by customers.
This device complies to Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful interference.
2. This device must withstand any background interference including those that may
cause undesired operation.
Trademarks
Shuttle is a registered trademark of Shuttle Inc.
Intel and Pentium are registered trademarks of Intel Corporation.
PS/2 is a registered trademark of IBM Corporation.
AWARD is a registered trademark of Award Software Inc.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
General Notice
Other brand and product names used herein are for identification purposes only and
may be trademarks of their respective owners.

Safety Information
Read the following precautions before setting up a Shuttle XPC.
Installation Notices
Do not place this device underneath heavy loads or in an
unstable position.
Do not expose this device to high levels of direct sunlight,
high-humidity or wet conditions.
Do not use or expose this device around magnetic elds
as magnetic interference may affect the performance of
the device.
Do not block the air vents to this device or impede the
airow in any way.
Laser compliance statement
The optical disc drive in this server is a laser product. The drive's classication
label is lacated on the drive.
CLASS 1 LASER PRODUCT
CAUTION： INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
CAUTION
Incorrectly replacing the battery may damage this computer. Replace
only with the same or equivalent as recommended by Shuttle. Dispose
of used batteries according to the manufacturer's instructions.

TABLE OF CONTENTS
Driver and Software Installation........................................................1
Motherboard Driver CD..............................................................1
User Manuals.............................................................................2
Appendix...........................................................................................3
Starting BIOS .............................................................................3
BIOS Setup Menu ......................................................................3
Main Setup ..........................................................................5
Advanced ............................................................................6
Power Management Con󰘰guration ..............................7
Hardware Health Con󰘰guration ....................................8
OnBoard Device Con󰘰guration ....................................9
CPU Con󰘰guration .....................................................10
SATA Con󰘰guration ...................................................12
USB Con󰘰guration .....................................................12
Boot...................................................................................13
Security .............................................................................15
Save & Exit .......................................................................17

1
English
Driver and Software Installation
The Motherboard Driver DVD contains all the motherboard drivers necessary to
optimize the performance of this Shuttle Xvision in a Windows®OS. Install these
drivers after installing Microsoft®Windows®.
Insert the attached DVD into your DVD-ROM drive. The DVD AutoRun screen
should appear. If the AutoRun screen does not appear, double click on Autorun
icon in My Computer to bring up Shuttle Mainboard Software Setup screen.
Navigation Bar Description :

Auto Install Driver/Utility

Install Intel Chipset Driver

User Manuals - Motherboard Manual, Quick Guide.
Link to Shuttle Website - Link to shuttle website homepage.
Browse this DVD - Allows you to see contents of this DVD.
The DVD contents attached in XS35V5 Series motherboard are subject to
change without notice.
Motherboard Driver CD

2
English
User Manuals
Install Adobe Reader 9.5
Motherboard Manual
Quick Guide

3
English
Appendix
AMIBIOS has been integrated into many motherboards for over a decade. In the past,
people often referred to the AMIBIOS setup menu as BIOS, BIOS setup, or CMOS
setup.
American Megatrends refers to this setup as BIOS. Specically, it is the name of the
BIOS setup utility. This chapter describes the basic navigation of the BIOS setup
screens.
Enter the BIOS
To enter the BIOS setup screens, follow the steps below:
Step1. Power on the motherboard.
Step2. Press the <Delete> key on your keyboard when you see the following
text prompt: Press DEL to run Setup.
Step3. After you press the <Delete> key, the main BIOS setup menu displays.
You can access the other setup screens from the main BIOS setup menu,
such as the Chipset and Power menus.
The main BIOS setup menu is the rst screen that you can navigate. Each main
BIOS setup menu option is described in this user’s guide.
The Main BIOS setup menu screen has two main frames. The left frame displays all
the options that can be congured. “Grayed-out” options cannot be congured.
Options is blue can be.
The right frame displays the key legend. Above the key legend is an area reserved for
a text message. When an option is selected in the left frame, it is highlighted in white.
Often a text message will accompany it.
This manual describes the standard look of the BIOS setup screen.
The motherboard manufacturer has the ability to change any and all of the
settings described in this manual. This means that some of the options
described in this manual do not exist in your motherboard's AMIBIOS.
In most cases, the <Delete> key is used to invoke the BIOS setup screen.
There are a few cases that other keys are used, such as <F1>,<F2>, and
so on.
Starting BIOS
BIOS Setup Menu

4
English
The BIOS setup/utility uses a key-based navigation system called hot keys. Most of
the BIOS setup utility hot keys can be used at any time during the setup navigation
process. These keys include <F1>, <F2>, <F3>,<F4>,<Enter>, <ESC>, <Arrow>
keys, and so on.
Hot Key Description
→ Left
← Right
The Left and Right <Arrow> keys allow you to select a BIOS setup screen.
For example: Main screen, Advanced screen, Chipset screen, and so on.
↑ Up
↓ Down
The Up and Down <Arrow> keys allow you to select an BIOS setup item or sub-
screen.
+- Plus/Minus The Plus and Minus <Arrow> keys allow you to change the field value of a
particular setup item. For example: Date and Time.
Tab The <Tab> key allows you to select BIOS setup elds.
F1 The <F1> key allows you to display the General Help screen.
Press the <F1> key to open the General Help screen.
F4
The <F4> key allows you to save any changes you have made and exit BIOS
Setup. Press the <F4> key to save your changes. Press the <Enter> key to save
the conguration and exit. You can also use the <Arrow> key to select Cancel and
then press the <Enter> key to abort this function and return to the previous screen.
ESC
The <Esc> key allows you to discard any changes you have made and exit the
BIOS Setup. Press the <Esc> key to exit the BIOS setup without saving your
changes. Press the <Enter> key to discard changes and exit. You can also use the
<Arrow> key to select Cancel and then press the <Enter> key to abort this function
and return to the previous screen.
Enter
The <Enter> key allows you to display or change the setup option listed for a
particular setup item. The <Enter> key can also allow you to display the setup sub-
screens.
Has default text messages built into it. The motherboard manufacture retains the
option to include, leave out, or change any of these text messages. They can also
add their own text messages. Because of this, many screen shots in this manual
are different from your BIOS setup screen.
There is a hot key legend located in the right frame on most BIOS setup screens.

5
English
When you rst enter the BIOS Setup Utility, you will enter the Main setup screen.
You can always return to the Main setup screen by selecting the Main tab. There are
two Main Setup options. They are described in this section. The Main BIOS Setup
screen is shown below.
System Date/System Time
Use this option to change the system time and date. Highlight System Time or Sys-
tem Date using the <Arrow> keys. Enter new values through the keyboard. Press the
<Tab> key or the <Arrow> keys to move between elds. The date must be entered in
MM/DD/YY format. The time is entered in HH:MM:SS format.
The time is in 24-hour format. For example, 5:30 A.M. appears as 05:30:00,
and 5:30 P.M. as 17:30:00.
Main Setup

6
English
Select the Advanced tab from the BIOS setup screen to enter the Advanced BIOS
Setup screen. You can select any of the items in the left frame of the screen, such as
CPU Conguration, to go to the sub menu for that item.
You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>
keys. All Advanced BIOS Setup options are described in this section.
The Advanced BIOS Setup screen is shown below. The sub menus are described on
the following pages.
Advanced

7
English
Wake Up by USB (S3)
Enable or disable system wake up by USB (S3).
The choice: Enabled , Disabled.
EuP Function
Enable or disable system EuP function in S4/S5.
The choice: Enabled , Disabled.
Power-On after Power-Fail
Enable or disable system power on automatically after AC power restored.
 The choice: Power Off, Power On, Former-Sts, Power On by LAN
and Power On by RTC.
Power Management Con󰘰guration

8
English
Wake Up by LAN
Enable or disable system wake on by onboard LAN chip.
The choice: Enabled , Disabled.
PowerOn by RTC Alarm
When enabled, System will wake on the hr::min::sec specied.
The choice: Enabled , Disabled.
Hardware Health Con󰘰guration

9
English
High Denition Audio
This item allows you to enable or disable the HD Audio.
The choice: Enabled , Disabled.
OnBoard LAN Function
This item allows you to enable or disable the onboard LAN function.
The choice: Enabled , Disabled.
Onboard LAN Boot ROM
This item allows you to enable or disable the onboard LAN boot ROM.
The choice: Enabled , Disabled.
IGD Memory Size Select
Onboard IGD Graphics Memory Size.
 The choice: 64MB,128MB,512MB.
OnBoard Device Con󰘰guration

10
English
You can use this screen to select options for the CPU Conguration Settings. Use the
up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to
change the value of the selected option. A description of the selected item appears
on the right side of the screen. The settings are described on the following pages. An
example of the CPU Conguration screen is shown below.
CPU Con󰘰guration
C State Support
This item allows you to enable or disable the CPU C state function.
The choice: Enabled , Disabled.
The CPU Conguration setup screen varies depending on the installed processor.

11
English
EIST
Enable or disable Enhanced lntel SpeedStep®Technology.
The choice: Enabled , Disabled.
Turbo Mode
Enable or disable lntel®Turbo Boost Technology.
The choice: Enabled , Disabled.
Intel® V. T.
When enable, a VMM can utilize the additional hardware capabilities provided
by vanderpool Technology.
The choice: Enabled , Disabled.

12
English
USB Con󰘰guration
SATA Con󰘰guration

13
English
Select the Boot tab from the BIOS setup screen to enter the Boot BIOS Setup screen.
You can select any of the items in the left frame of the screen, such as Boot Settings
Conguration, to go to the sub menu for that item.
You can display an Boot BIOS Setup option by highlighting it using the <Arrow> keys.
All Boot BIOS Setup options are described in this section.
The Boot BIOS Setup screen is shown below. The sub menus are described on the
following pages.
Boot
Bootup Num-Lock
Select NumLock state after system bootup.
The choice: Enabled , Disabled.
Fast Boot Function
This item allows you to enable or disable Fast Boot Function.
The choice: Enabled , Disabled.

14
English
Boot From USB device
This item allows you to enable or disable boot from USB device.
The choice: Enabled , Disabled.
Boot Mode Select
Select boot mode LEGACY/UEFI.
 The choice: LEGACY, UEFI.
OS Select
Select system.
 The choice: Default, Legacy System, Yocto Linux.
Boot Device Priority (Boot Option #1/2/3/....)
Species the boot sequence from the available devices. A device enclosed in
parenthesis has been disabled in the corresponding type menu.

15
English
Select the Security tab from the BIOS setup screen to enter the Security BIOS Setup
screen. You can display an Security BIOS Setup option by highlighting it using the
<Arrow> keys. All Security BIOS Setup options are described in this section.
The Security Setup screen is shown below. The sub menus are documented on the
following pages.
Enter New Password
Change Supervisor Password
When this item is selected, a message box shall appear on the
screen as below:
Security
Type a maximum of 6-digit password and press [Enter]. The password typed now will
replace any previously set password from CMOS memory. You may also press [ESC]
to abandon new password setting.
When the Supervisor Password is set, new items Change User Password and Pass-
word Check will be added in the menu.

16
English
Select Change User Password to give or to abandon password setting same as
Change Supervisor Password item above.
Note that Supervisor Password eld allows users to enter and change the settings of
the BIOS SETUP UTILITY, while User Password eld only allows users to enter the
BIOS SETUP UTILITY without having the authorization to make any change.
The Password Check item is used to specify the type of BIOS password protection
that is implemented. Password Settings are described below:
Setup The password is required only when users try to access to
BIOS SETUP UTILITY.
To clear a set Supervisor Password/ User Password, just press [Enter] under Change
Supervisor Password/ Change User Password eld when you are prompted to enter
the password. Please note that when Supervisor Password has been cleared, User
Password will be cleared as well. A message box will pop up conrming password will
be disabled. Once the password is disabled, the system will boot and user can enter
setup without entering password.
Boot The password is required every time when power on.
Both The password is required every time when power on.Also,
the password is required only when users try to access to
BIOS SETUP UTILITY.
Password Login control
Password Mode select.
The choice: Boot, Setup, Both
Flash Write Protection
Enabled/Disabled BIOS Write Protection control function.
The choice: Enabled , Disabled.
Secure Boot Control
Enabled/Disabled Secure Boot Control.
The choice: Enabled , Disabled.
