SICK CLV63 Series User manual

OPERATING INSTRUCTIONS
CLV63x, CLV64x, CLV65x
Bar code scanner

Described product
CLV63x
CLV64x
CLV65x
Manufacturer
SICK AG
Erwin-Sick-Str. 1
79183 Waldkirch
Germany
Legal information
This work is protected by copyright. Any rights derived from the copyright shall be
reserved for SICK AG. Reproduction of this document or parts of this document is only
permissible within the limits of the legal determination of Copyright Law. Any modifica‐
tion, abridgment or translation of this document is prohibited without the express writ‐
ten permission of SICK AG.
The trademarks stated in this document are the property of their respective owner.
© SICK AG. All rights reserved.
Original document
This document is an original document of SICK AG.
25
2O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 8019588/129Z/2019-02-07 | SICK
Subject to change without notice

Contents
1 About this document........................................................................ 5
1.1 Information on the operating instructions.............................................. 5
1.2 Scope......................................................................................................... 5
1.3 Explanation of symbols............................................................................ 5
1.4 Further information................................................................................... 6
1.5 SICK service.............................................................................................. 6
2 Safety information............................................................................ 7
2.1 Intended use............................................................................................. 7
2.2 Incorrect use............................................................................................. 7
2.3 Internet protocol (IP) technology.............................................................. 7
2.4 Limitation of liability................................................................................. 7
2.5 Modifications and conversions................................................................ 8
2.6 Requirements for skilled persons and operating personnel.................. 8
2.7 Hazard warnings and operational safety................................................. 9
2.8 Switching off the device........................................................................... 12
2.9 Protection of the environment................................................................. 12
2.10 Repairs...................................................................................................... 12
3 Product description........................................................................... 13
3.1 Product ID.................................................................................................. 13
3.2 Product characteristics............................................................................ 15
4 Transport and storage....................................................................... 26
4.1 Transport................................................................................................... 26
4.2 Transport inspection................................................................................. 26
4.3 Storage...................................................................................................... 26
5 Mounting............................................................................................. 27
5.1 Overview of mounting procedure............................................................. 27
5.2 Scope of delivery....................................................................................... 27
5.3 Preparation for mounting......................................................................... 28
5.4 Mounting location..................................................................................... 31
5.5 Mounting the device................................................................................. 34
5.6 Mounting with shock mounts (optional).................................................. 34
5.7 Mounting external components............................................................... 37
6 Electrical installation........................................................................ 39
6.1 Safety......................................................................................................... 39
6.2 Prerequisites for safe operation of the device........................................ 40
6.3 Wiring notes.............................................................................................. 43
6.4 Pin allocation of the connections............................................................ 43
6.5 Connection diagrams............................................................................... 46
6.6 Wiring interfaces....................................................................................... 51
CONTENTS
8019588/129Z/2019-02-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 3
Subject to change without notice

7 Commissioning.................................................................................. 55
7.1 Overview of the commissioning steps..................................................... 55
7.2 SOPAS ET configuration software............................................................ 55
7.3 Initial commissioning................................................................................ 56
7.4 Adjust the device...................................................................................... 57
7.5 Fine adjustment and further configuration............................................. 58
8 Operation............................................................................................ 60
8.1 Operating and status indicators.............................................................. 60
8.2 Operating options..................................................................................... 61
9 Maintenance...................................................................................... 63
9.1 Maintenance............................................................................................. 63
9.2 Cleaning..................................................................................................... 63
10 Troubleshooting................................................................................. 66
10.1 Overview of possible errors and faults.................................................... 66
10.2 Detailed fault analysis.............................................................................. 66
10.3 Status log.................................................................................................. 66
10.4 SICK Support............................................................................................. 67
11 Decommissioning............................................................................. 68
11.1 Disassembly and disposal....................................................................... 68
11.2 Returning devices..................................................................................... 68
12 Technical data.................................................................................... 70
12.1 Optics......................................................................................................... 70
12.2 Performance............................................................................................. 71
12.3 Interfaces.................................................................................................. 71
12.4 Mechanics/electronics............................................................................. 73
12.5 Ambient data............................................................................................. 74
12.6 Reading field diagrams............................................................................ 74
13 Accessories........................................................................................ 96
13.1 Additional accessories............................................................................. 96
14 Annex.................................................................................................. 97
14.1 Notes on PROFINET.................................................................................. 97
14.2 EU declaration of conformity / Certificates............................................. 98
14.3 Certification in accordance with UL60950............................................. 98
14.4 Dimensional drawings.............................................................................. 99
14.5 Abbreviations used................................................................................... 99
CONTENTS
4O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 8019588/129Z/2019-02-07 | SICK
Subject to change without notice

1 About this document
1.1 Information on the operating instructions
These operating instructions provide important information on how to use devices from
SICK AG.
Prerequisites for safe work are:
•Compliance with all safety notes and handling instructions supplied.
•Compliance with local work safety regulations and general safety regulations for
device applications
The operating instructions are intended to be used by qualified personnel and electrical
specialists.
NOTE
Read these operating instructions carefully before starting any work on the device, in
order to familiarize yourself with the device and its functions.
The instructions constitute an integral part of the product and are to be stored in the
immediate vicinity of the device so they remain accessible to staff at all times. Should
the device be passed on to a third party, these operating instructions should be handed
over with it.
These operating instructions do not provide information on operating the machine in
which the device is integrated. For information about this, refer to the operating instruc‐
tions of the specific machine.
1.2 Scope
These operating instructions serve to incorporate the device into a customer system.
Instructions are given by stages for all actions required.
These instructions apply to all available device variants of the device. More detailed
information for the identification of the available device type see "Type code",
page 13.
Available device variants are listed on the online product page.
•www.sick.com/CLV63x
•www.sick.com/CLV64x
•www.sick.com/CLV65x
Various device variants are used as examples for commissioning, based on the default
parameter settings for the relevant device.
1.3 Explanation of symbols
Warnings and important information in this document are labeled with symbols. The
warnings are introduced by signal words that indicate the extent of the danger. These
warnings must be observed at all times and care must be taken to avoid accidents, per‐
sonal injury, and material damage.
DANGER
… indicates a situation of imminent danger, which will lead to a fatality or serious
injuries if not prevented.
ABOUT THIS DOCUMENT 1
8019588/129Z/2019-02-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 5
Subject to change without notice

WARNING
… indicates a potentially dangerous situation, which may lead to a fatality or serious
injuries if not prevented.
CAUTION
… indicates a potentially dangerous situation, which may lead to minor/slight injuries if
not prevented.
NOTICE
… indicates a potentially harmful situation, which may lead to material damage if not
prevented.
NOTE
… highlights useful tips and recommendations as well as information for efficient and
trouble-free operation.
1.4 Further information
NOTE
All the documentation available for the device can be found on the online product page
at:
•www.sick.com/CLV63x
•www.sick.com/CLV64x
•www.sick.com/CLV65x
The following information is available for download there:
•Model-specific online data sheets for device variants, containing technical data,
dimensional drawings, and reading field diagrams
•EU declaration of conformity for the product family
•Dimensional drawings and 3D CAD dimension models in various electronic
formats
•Reading field diagrams
•These operating instructions are available in German and other languages.
•Other publications related to the devices described here
•Publications dealing with accessories
1.4.1 Supplementary documents
Information about configuration of the device can be found in the online help function
of the SOPAS ET configuration software.
1.4.2 Documents on request
Overview of command strings for the device.
1.5 SICK service
If you require any technical information, our SICK Service will be happy to help. To find
your agency, see the final page of this document.
NOTE
Before calling, make a note of all type label data such as type code, serial number, etc.,
to ensure faster processing.
1 ABOUT THIS DOCUMENT
6O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 8019588/129Z/2019-02-07 | SICK
Subject to change without notice

2 Safety information
2.1 Intended use
The device is an intelligent, opto-electronic SICK ID sensor and is used for automatic,
fixed identification and decoding of bar codes on moving or stationary objects. The data
content of the decoded bar codes is sent by the device to a higher-level control (PLC) for
further coordinating processing.
NOTE
The bar codes being read must conform to at least quality level C in accordance with
ISO/IEC 15416.
SICK AG assumes no liability for losses or damage arising from the use of the product,
either directly or indirectly. This applies in particular to use of the product that does not
conform to its intended purpose and is not described in this documentation.
2.2 Incorrect use
•The device does not constitute a safety-relevant device according to the EU
Machinery Directive (2006/42/EC).
•The device must not be used in explosion-hazardous areas.
•The device must not be used in forklift applications in low temperature conditions.
•Any other use that is not described as intended use is prohibited.
•Any use of accessories not specifically approved by SICK AG is at your own risk.
WARNING
Danger due to improper use!
Any improper use can result in dangerous situations.
Therefore, observe the following information:
■Device should be used only in accordance with its intended use.
■All information in these operating instructions must be strictly observed.
2.3 Internet protocol (IP) technology
NOTE
SICK uses standard IP technology in its products. The emphasis is placed on availability
of products and services.
SICK always assumes the following prerequisites:
•The customer ensures the integrity and confidentiality of the data and rights
affected by its own use of the aforementioned products.
•In all cases, the customer implements the appropriate security measures, such as
network separation, firewalls, virus protection, and patch management.
2.4 Limitation of liability
Relevant standards and regulations, the latest technological developments, and our
many years of knowledge and experience have all been taken into account when com‐
piling the data and information contained in these operating instructions. The manufac‐
turer accepts no liability for damage caused by:
■Non-adherence to the product documentation (e.g., operating instructions)
■Incorrect use
SAFETY INFORMATION 2
8019588/129Z/2019-02-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 7
Subject to change without notice

■Use of untrained staff
■Unauthorized conversions
■Technical modifications
■Use of unauthorized spare parts, consumables, and accessories
With special variants, where optional extras have been ordered, or owing to the latest
technical changes, the actual scope of delivery may vary from the features and illustra‐
tions shown here.
2.5 Modifications and conversions
NOTICE
Modifications and conversions to the device may result in unforeseeable dangers.
Interrupting or modifying the device or SICK software will invalidate any warranty claims
against SICK AG. This applies in particular to opening the housing, even as part of
mounting and electrical installation.
2.6 Requirements for skilled persons and operating personnel
WARNING
Risk of injury due to insufficient training.
Improper handling of the device may result in considerable personal injury and material
damage.
■All work must only ever be carried out by the stipulated persons.
This product documentation refers to the following qualification requirements for the
various activities associated with the device:
■Instructed personnel have been briefed by the operator about the tasks assigned
to them and about potential dangers arising from improper action.
■Skilled personnel have the specialist training, skills, and experience, as well as
knowledge of the relevant regulations, to be able to perform tasks delegated to
them and to detect and avoid any potential dangers independently.
■Electricians have the specialist training, skills, and experience, as well as knowl‐
edge of the relevant standards and provisions to be able to carry out work on elec‐
trical systems and to detect and avoid any potential dangers independently. In Ger‐
many, electricians must meet the specifications of the BGV A3 Work Safety Regu‐
lations (e.g. Master Electrician). Other relevant regulations applicable in other
countries must be observed.
The following qualifications are required for various activities:
Table 1: Activities and technical requirements
Activities Qualification
Mounting, maintenance ■Basic practical technical training
■Knowledge of the current safety regulations in the workplace
Electrical installation,
device replacement
■Practical electrical training
■Knowledge of current electrical safety regulations
■Knowledge of the operation and control of the devices in their
particular application
2 SAFETY INFORMATION
8O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 8019588/129Z/2019-02-07 | SICK
Subject to change without notice

Activities Qualification
Commissioning, configura‐
tion
■Basic knowledge of the WindowsTM operating system in use
■Basic knowledge of the design and setup of the described con‐
nections and interfaces
■Basic knowledge of data transmission
■Basic knowledge of bar code technology
Operation of the device for
the particular application
■Knowledge of the operation and control of the devices in their
particular application
■Knowledge of the software and hardware environment for the
particular application
2.7 Hazard warnings and operational safety
To reduce health risks and to avoid dangerous situations, observe the safety notes and
warnings set out in the following chapters of these operating instructions.
2.7.1 Laser radiation
The device works with a red light laser diode in the wavelength range between 655 nm
(CLV63x-64x) and 658 nm (CLV65x).
CAUTION
Optical radiation: Laser class 2
The human eye is not at risk when briefly exposed to the radiation for up to 0.25 sec‐
onds. Exposure to the laser beam for longer periods of time may cause damage to the
retina. The laser radiation is harmless to human skin.
■Do not look into the laser beam intentionally.
■Never point the laser beam at people's eyes.
■If it is not possible to avoid looking directly into the laser beam, e.g., during com‐
missioning and maintenance work, suitable eye protection must be worn.
■Avoid laser beam reflections caused by reflective surfaces. Be particularly careful
during mounting and alignment work.
■Do not open the housing. Opening the housing may increase the level of risk.
■Current national regulations regarding laser protection must be observed.
It is not possible to entirely rule out temporary disorienting optical effects, particularly
in conditions of dim lighting. Disorienting optical effects may come in the form of daz‐
zle, flash blindness, afterimages, photosensitive epilepsy, or impairment of color vision,
for example.
SAFETY INFORMATION 2
8019588/129Z/2019-02-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 9
Subject to change without notice

Laser class
Figure 1: Laser output aperture of the different designs
The device complies with laser class 2. The entire reading window is a laser output
aperture.
NOTE
No maintenance is required to ensure compliance with Laser Class 2.
Warning symbol on the device
The colored laser warning label is fitted in combination with the type label on the rear of
the device.
In addition to other information, the type label of the device in use also contains the
laser output data. This consists of: Laser output power (maximum/average), wave‐
length or wavelength range, and pulse time duration. The data is located on the lower
section of the type label, see "Type label", page 13.
2 SAFETY INFORMATION
10 O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 8019588/129Z/2019-02-07 | SICK
Subject to change without notice

Figure 2: Example of a laser warning sign on the device
What the laser warning label means: Laser radiation – Never look into the light beam –
Laser class 2
NOTE
Additional laser warning label
If the laser warning label applied to the device is concealed when the device is installed
into a machine or paneling, the laser beam outlet opening must be suitably labeled. For
this purpose, an additional warning label of the same type must be applied next to the
outlet opening.
Controlling the laser diode
When operating properly, the device only switches the laser diode on if there is an
object in the reading area, or if a reading is required (cyclic reading operation).
A laser timeout can switch off the laser diode automatically in this type of object trigger
control if the pulse has stopped for too long (e.g. the conveyor system has stopped). In
this case, the current internal reading interval of the device remains open.
Depending on the selected parameterization type, the laser timeout can be set as fol‐
lows:
•Using the SOPAS ET configuration software, on the Illumination Control device page
•During GSD configuration with the “10_Object Trigger Ctrl” module (Profinet/
Profibus)
In the default setting, laser timeout is deactivated.
The laser diode is permanently or repeatedly switched on in the following device sta‐
tuses:
■In the “Percentage Evaluation” and “Auto Setup” operating modes (only used tem‐
porarily for configuration/diagnosis)
■In reading operation in the PSDI types “Auto pulse” (adjustable duty cycle) or
“free.”
If the timeout is activated, it will have no effect in this case.
SAFETY INFORMATION 2
8019588/129Z/2019-02-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 11
Subject to change without notice

2.8 Switching off the device
When switching off the device, at the most, the following data will be lost:
■Application-specific parameter sets that were only temporarily stored in the device
■Last reading result
■Daily operating hours counter
2.9 Protection of the environment
During construction of the device, attention was paid to achieving the smallest environ‐
mental impact possible. Apart from the housing, the device contains no materials using
silicon.
2.10 Repairs
Repair work on the device may only be performed by qualified and authorized person‐
nel from SICK AG. Interruptions or modifications to the device by the customer will inval‐
idate any warranty claims against SICK AG.
2 SAFETY INFORMATION
12 O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 8019588/129Z/2019-02-07 | SICK
Subject to change without notice

3 Product description
3.1 Product ID
3.1.1 Type label
The type label gives information for identification of the device. An existing UL certifica‐
tion can be found on the type label.
1443 0297
S/N:
DC 10...30V 5.0W
1
2
3
4
5
Manufactured:
D-79276 Reute
Made in Germany
λ = 655nm
Pmax=1.5mW P<1.0mW average
Pulse duration <300µs
Imax=700mA
P/N: 1068608
CLV610-C000
MAC
6
Figure 3: Type label design for the device, illustration may differ from actual type label
1Type designation
2Part number
3Serial number
4Laser output data
5MAC address
6Date of manufacture
25
3.1.2 Type code
The devices of the CLV63x, CLV64x, and CLV65x product families are arranged accord‐
ing to the following type code:
CLVxyz-abcde
CLV x y z - a b c d e
1 2 3 4 5 6 7 8 9
Table 2: Type code
Position Description Characteristic
1 Code reader V-principle
2 - 3 Product family 63: CLV63x
64: CLV64x
65: CLV65x
PRODUCT DESCRIPTION 3
8019588/129Z/2019-02-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 13
Subject to change without notice

Position Description Characteristic
4 CLV63x: Working range
CLV64x: Resolution
CLV65x: Resolution
CLV63x:
0: Long range
1: Mid range
2: Short range
CLV64x:
0: Standard density
2: High density
CLV65x:
0: Standard density
1: Depth of field optimized for 0.5 mm
5 Scanning method, reading window
orientation 1)
0: Line scanner, reading window on front
1: Raster scanner, reading window on
front
2: Line scanner, reading window on side
3: Raster scanner, reading window on side
6: Line scanner with oscillating mirror,
reading window on side
6 Electrical connections (design) 0: Cable 0.9 m with male connector, D-
Sub-HD, 15-pin
1: Swivel connector, 12-pin (2 x M12 plug
connector)
3: Cable 2 m with male connector, D-Sub-
HD, 15-pin
8: Swivel connector, 17-pin (2 x M12 plug
connector)
7 Interfaces 0: RS-232, RS422/485, CAN, digital IOs
2: Ethernet, RS-232, RS422/485, CAN,
digital input
3: Ethernet, RS-232, RS422/485, CAN,
digital IOs
8 Front screen material 0: Glass
1: Plastic
9 Application (environment) Without label: Ambient temperature
0 °C ... +40 °C
F0: With mounted external heating
(Ambient temperature ‒35 °C … + 35 °C)
Without label: Protection class IP 65
S01: IP 69k in the special housing
1) Refers to the longitudinal axis of the device.
NOTE
Additional information on electrical connections and interfaces can be found in the
Technical data chapter of this product documentation.
NOTE
Not all combinations are possible according to the type code. The available device vari‐
ants can be found online at:
•www.sick.com/CLV63x
•www.sick.com/CLV64x
•www.sick.com/CLV65x
3 PRODUCT DESCRIPTION
14 O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 8019588/129Z/2019-02-07 | SICK
Subject to change without notice

3.2 Product characteristics
3.2.1 Device view
CLV63x, CLV64x, CLV65x
Figure 4: Device variants (from top to bottom) - reading window on front, oscillating mirror (read‐
ing window on side)
PRODUCT DESCRIPTION 3
8019588/129Z/2019-02-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 15
Subject to change without notice

3
3
1
6
7
5
4
2
8
ß á
9
Figure 5: Device view of the CLV63x, CLV64x and CLV65x
1Blind hole thread M5 (5 mm deep) for mounting (4x)
2Laser warning label
3Cover for micro SD card slot
4Type label
5Buttons for function selection/activation
6Bar graph display
7LEDs for indicating the status
8Swivel connector
9Central position of the deflected laser beam in the V-shaped aperture angle
ßMale connector, M12, 12-pin or 17-pin, A-coded
àFemale connector, M12, 4-pin, D-coded (Ethernet)
áCable with male connector, D-Sub-HD, 15-pin
3 PRODUCT DESCRIPTION
16 O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 8019588/129Z/2019-02-07 | SICK
Subject to change without notice

3.2.2 Product features and functions (overview)
Table 3: Overview of product features and functions of the device
Product feature/func‐
tion
Characteristic
Safety and ease of
use
•Rugged, compact metal housing, CE marking
•Laser Class 2, laser switches off if the output power is exceeded
•Automatic self-test on system start
•Diagnostic tools for system setup and (remote) system monitoring
•Configurable output of reading diagnostic data in two reading
results formats
•Operating data polling, in case of error, issue of error code if
required
•Test string function (heartbeat) can be activated to signal that the
device is ready for operation
•Password-protected configuration mode via SOPAS ET
•Future-oriented by firmware update (FLASH PROM) via data inter‐
face
•Future-oriented SOPAS ET configuration software
•Low power consumption
•Additional supply voltage range
•Optional parameter cloning with external CMC600 parameter mem‐
ory module in the CDB/CDM connection module
Convenient operation/
configuration
•Configuration via configuration software SOPAS ET (online/offline)
or commands
•Configuration depending on the model via GSD configuration (via
CDF600-2xx or with Ethernet version device)
•Status displays via LEDs
•Auto setup of the optical reading properties
•Profile programming with bar codes, generated and printed via
SOPAS ET
•Two pushbuttons on the device to call up preset functions without
connecting a computer
•Buzzer, which can be switched off, to confirm the device function
Read operation modes •Start/stop operation (one bar code bearing object per read pulse)
•Tracking operation (CLV65x-x8300A)
Read cycle •Pulse sources for start: switching inputs, data interface (command),
auto pulse, free, CAN
•Pulse sources for stop: read pulse source, switching inputs, data
interface (command), timer, condition
Bar code evaluation •All current 1D bar code types
•Max. number of bar codes: 50 per reading interval
•Separation of identical codes of the same code type using the read
angle
Data processing •Influencing the output of the reading data by event-dependent eval‐
uation conditions
•Influencing the output string by filtering and output sorting
Data communication •Host interface: two data output formats can be configured, can be
switched to various physical interfaces, parallel operation possible
•Aux interface: fixed data output format, can be switched to various
physical interfaces
3.2.3 Operating principle
The device consists of a laser scanner (laser diode and optics), an electronics unit with
integrated decoder and various data interfaces (type-dependent) to industrial bus sys‐
tems. The use of various focusing settings, resolutions, scan processes, bus systems,
mounting options and optics enables use in most industrial applications. Interfaces to
PRODUCT DESCRIPTION 3
8019588/129Z/2019-02-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 17
Subject to change without notice

external timers, such as photoelectric sensors or incremental encoders, enable reading
pulses independent of the control. The reading results are provided for further process‐
ing by the data interfaces.
In principle, the codes can be recorded on any side on still or moving objects in a con‐
veyor system (single-side reading).
By combining several devices, it is possible to record several sides in one passage
(multi-side reading).
To record the codes, the device generates a scan line (line scanner).
When designed as a raster scanner, the device generates eight scan lines which are
offset parallel to each other.
Line scanner with oscillating mirror
The oscillating mirror also moves the scan line vertically to the scan direction from the
resting position to both sides with a low oscillation frequency. This means that the
device can also scan larger areas for bar codes.
NOTE
When starting up the device, the oscillating mirror may cause increased volume devel‐
opment.
The length of the scan line which can be used for evaluation (reading field height)
depends on the reading distance as a result of the V-shaped light emission.
The light pattern reflected from the bar code is recorded, processed, and decoded.
External sensors deliver information about the read cycle and conveyor speed (incre‐
ment) to control this process. The read results are output to the device data interfaces
and forwarded to a host/PC.
Detailed wiring of the device and the connections to the host/PC and the external sen‐
sors are described in chapter Electrical installation.
NOTE
The CDB620 connection module with additional circuit board ( see "Connecting connec‐
tion modules to devices with heating", page 48) or the CDM420 connection module
with additional terminal ( see "Connecting the supply voltage", page 51) is to be used
for devices with heating.
Block diagrams
Input 2 à
Input 1
Output 1 ß
Output 2 9
Device 3
"Serial RS-232/RS-422/485" (Host)
Connection module 2
SerialSerial
Configuration
Diagnostics 5
SOPASSOPAS
"Power/SerialData/CAN/I/O"
(Aux, Host)
...
...
12
VS
GND
Host
PC
“Serial RS-232” (Aux 1)
VS 1
Further data
processing 6
Reading result 7
Cable 4
Cable 8
Figure 6: CLV63x to CLV65x facilities for connecting, serial variant
1Supply voltage VS (VS = UV)
3 PRODUCT DESCRIPTION
18 O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 8019588/129Z/2019-02-07 | SICK
Subject to change without notice

2Connection module (optional, CDB620 here as example)
3Device
4Null modem cable (female connector, D-Sub, 9-pin/female connector, D-Sub, 9-pin),
crossed TxD and RxD
5Configuration or diagnostics
6Data further processing
7Read result
8Serial variant: Device cable with male connector, D-Sub-HD, 15-pin
9Digital switching output 2, e.g. for connecting an LED
ßDigital switching output 1, e.g. for connecting an LED
àDigital switching input 2, e.g., for connecting an incremental encoder
áDigital switching input 1, e.g., for connecting a read cycle sensor
"Ethernet" (Host 2)
Input 1 â
Device 3
"Serial RS-232/RS-422/485" (Host 1) ß
Connection module 2
SerialSerial
Configuration
Diagnostics 7
SOPASSOPAS
"Power/SerialData/I/O"
(Aux, Host)
...
...
12
VS
GND
Host
PC
"Serial RS-232" (Aux 1) 5
"Ethernet" (Aux 2) 6
VS1
"Ethernet"
Reading result 8
EthernetEthernet
Further data
processing 9
Cable 4
CableCable á
Figure 7: CLV63x to CLV65x facilities for connecting, Ethernet variant, M12, 12-pin, A-coded
1Supply voltage VS (VS = UV)
2Connection module (optional, CDB620 here as example)
3Device
4Null modem cable (female connector, D-Sub, 9-pin/female connector, D-Sub, 9-pin),
crossed TxD and RxD
5Alternative to Ethernet AUX port
6Alternative to serial AUX
7Configuration or diagnostics
8Read result
9Data further processing
ßAlternative to Ethernet host port
àAdapter cable (male connector, M12, 4-pin, D-coded/male connector, RJ-45, 8-pin)
áAdapter cable (female connector, M12, 12-pin, A-coded/male connector, D-Sub-HD, 15-
pin)
âDigital switching input 1, e.g., for connecting a read cycle sensor
PRODUCT DESCRIPTION 3
8019588/129Z/2019-02-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 19
Subject to change without notice

"Ethernet" (Host 2)
Input 2 ä
Input 1
Output 1 ã
Output 2 â
Device 3
"Serial RS-232/RS-422/485" (Host 1) ß
Connection module 2
SerialSerial
Configuration
Diagnostics 7
SOPASSOPAS
"Power/SerialData/I/O"
(Aux, Host)
...
...
12
VS
GND
Host
PC
"Serial RS-232" (Aux 1) 5
"Ethernet" (Aux 2) 6
VS1
"Ethernet"
Reading result 8
EthernetEthernet
Further data
processing 9
Cable 4
Cable àCable á
Figure 8: CLV63x to CLV65x facilities for connecting (all without heating), Ethernet variant, M12,
17-pin, A-coded
1Supply voltage VS (VS = UV)
2Connection module (optional, CDB650-204 required here)
3Device
4Null modem cable (female connector, D-Sub, 9-pin/female connector, D-Sub, 9-pin),
crossed TxD and RxD
5Alternative to Ethernet AUX port
6Alternative to serial AUX
7Configuration or diagnostics
8Read result
9Data further processing
ßAlternative to Ethernet host port
àAdapter cable (male connector, M12, 4-pin, D-coded/male connector, RJ-45, 8-pin)
áConnection cable 1:1 (female connector, M12, 17-pin, A-coded/male connector, M12, 17-
pin, A-coded)
âDigital switching output 2, e.g. for connecting an LED
ãDigital switching output 1, e.g. for connecting an LED
äDigital switching input 2, e.g., for connecting an incremental encoder
åDigital switching input 1, e.g., for connecting a read cycle sensor
3.2.3.1 Object trigger control
The device needs a suitable external signal (trigger source) as notification of an object
being in the reading field to start an object-related read process. As standard, the start
signal is issued via an external read cycle sensor (e.g. photoelectric sensor). As soon as
an object has passed the reading cycle sensor, a time window (“reading interval”) is
opened in the device for the reading process.
Alternatively, a command triggers the read process via a data interface or the
SICK SENSOR network. In auto pulse mode, the device internally generates the reading
gate itself with an adjustable clock ratio.
The read cycle can be terminated in various ways. In the event of external triggering,
this is carried out via the read cycle source or a command, or internally via a timer or an
evaluation condition that needs to be met.
NOTE
The SOPAS-ET configuration software can be used to configure the trigger source.
3 PRODUCT DESCRIPTION
20 O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 8019588/129Z/2019-02-07 | SICK
