SICK Lector85 Flex Series User manual

OPERATING INSTRUCTIONS
Lector85x Flex
Image-based code reader

Described product
Lector85x Flex
Manufacturer
SICK AG
Erwin-Sick-Str. 1
79183 Waldkirch
Germany
Legal information
This work is protected by copyright. Any rights derived from the copyright shall be
reserved for SICK AG. Reproduction of this document or parts of this document is
only permissible within the limits of the legal determination of Copyright Law. Any modi‐
fication, abridgment or translation of this document is prohibited without the express
written permission of SICK AG.
The trademarks stated in this document are the property of their respective owner.
© SICK AG. All rights reserved.
Original document
This document is an original document of SICK AG.
2O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 8027859//2022-06-22 | SICK
Subject to change without notice

Contents
1 About this document........................................................................ 6
1.1 Information on the operating instructions.............................................. 6
1.2 Explanation of symbols............................................................................ 6
1.3 Related applicable documents................................................................ 7
1.4 Further information................................................................................... 7
2 Safety information............................................................................ 8
2.1 Intended use............................................................................................. 8
2.1.1 Operating restrictions.............................................................. 8
2.1.2 Conditions for specified enclosure rating.............................. 8
2.1.3 Cover on the device................................................................. 8
2.2 Improper use............................................................................................. 8
2.3 Cybersecurity............................................................................................ 9
2.4 Limitation of liability................................................................................. 9
2.5 Modifications and conversions................................................................ 9
2.6 Requirements for skilled persons and operating personnel.................. 10
2.7 Operational safety and specific hazards................................................. 10
2.8 LED warning label..................................................................................... 12
2.9 Applying the LED warning label................................................................ 13
3 Product description........................................................................... 14
3.1 Product variants........................................................................................ 14
3.2 Scope of delivery....................................................................................... 14
3.3 Product ID.................................................................................................. 14
3.3.1 Type label................................................................................. 14
3.3.2 Type code................................................................................. 15
3.4 Setup and dimensions............................................................................. 16
3.5 Integrated illumination unit...................................................................... 17
3.6 Display and control elements.................................................................. 17
4 Transport and storage....................................................................... 19
4.1 Transport................................................................................................... 19
4.2 Unpacking.................................................................................................. 19
4.3 Transport inspection................................................................................. 19
4.4 Storage...................................................................................................... 19
5 Mounting............................................................................................. 20
5.1 Mounting instructions............................................................................... 20
5.2 Preparation for mounting......................................................................... 20
5.2.1 Installation requirements........................................................ 20
5.2.2 Mounting systems.................................................................... 20
5.3 Mounting location..................................................................................... 21
5.3.1 Working range.......................................................................... 21
5.3.2 Mounting bracket and reflection prevention.......................... 21
CONTENTS
8027859//2022-06-22 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 3
Subject to change without notice

5.3.3 Field of view diagrams............................................................. 22
5.4 Mounting the lens and illumination......................................................... 23
5.5 Mounting the device................................................................................. 25
6 Electrical installation........................................................................ 26
6.1 Wiring instructions.................................................................................... 26
6.1.1 Data cables.............................................................................. 26
6.2 Prerequisites for safe operation of the device........................................ 27
6.3 Connections and pin assignment............................................................ 30
6.4 Connecting the device.............................................................................. 31
6.4.1 Electrically connecting the device.......................................... 31
6.4.2 Connecting the supply voltage................................................ 32
6.4.3 CAN interface........................................................................... 32
6.4.4 CAN connection principle........................................................ 33
7 Commissioning.................................................................................. 35
7.1 Starting SOPASair..................................................................................... 35
7.2 Starting SOPASET.................................................................................... 35
7.3 Saving the configuration data.................................................................. 36
7.4 Installing firmware updates...................................................................... 36
8 Maintenance...................................................................................... 37
8.1 Maintenance plan..................................................................................... 37
8.2 Cleaning..................................................................................................... 37
9 Troubleshooting................................................................................. 39
9.1 General faults, warnings, and errors....................................................... 39
9.2 Diagnostics using SOPASair..................................................................... 39
9.2.1 Error log.................................................................................... 39
9.2.2 Diagnostic file.......................................................................... 39
9.3 Repairs...................................................................................................... 39
9.4 Returns...................................................................................................... 39
9.5 Disassembling the device........................................................................ 40
9.6 Replacing the device................................................................................ 40
9.6.1 Transferring configuration data.............................................. 40
9.6.2 Putting the replacement device into operation..................... 40
9.7 Disposal..................................................................................................... 41
10 Technical data.................................................................................... 42
10.1 Features.................................................................................................... 42
10.2 Mechanics and electronics...................................................................... 43
10.3 Performance............................................................................................. 44
10.4 Interfaces.................................................................................................. 44
10.5 Ambient data............................................................................................. 45
11 Accessories........................................................................................ 46
CONTENTS
4O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 8027859//2022-06-22 | SICK
Subject to change without notice

12 Annex.................................................................................................. 47
12.1 Declarations of conformity and certificates............................................ 47
12.2 Licenses.................................................................................................... 47
CONTENTS
8027859//2022-06-22 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 5
Subject to change without notice

1 About this document
1.1 Information on the operating instructions
These operating instructions provide important information on how to use devices from
SICK AG.
Prerequisites for safe work are:
•Compliance with all safety notes and handling instructions supplied.
•Compliance with local work safety regulations and general safety regulations for
device applications
The operating instructions are intended to be used by qualified personnel and electrical
specialists.
NOTE
Read these operating instructions carefully to familiarize yourself with the device and its
functions before commencing any work.
The operating instructions are an integral part of the product. Store the instructions
in the immediate vicinity of the device so they remain accessible to staff at all times.
Should the device be passed on to a third party, these operating instructions should be
handed over with it.
These operating instructions do not provide information on the handling and safe
operation of the machine or system in which the device is integrated. Information on
this can be found in the operating instructions for the machine or system.
1.2 Explanation of symbols
Warnings and important information in this document are labeled with symbols. Sig‐
nal words introduce the instructions and indicate the extent of the hazard. To avoid
accidents, damage, and personal injury, always comply with the instructions and act
carefully.
DANGER
…indicates a situation of imminent danger, which will lead to a fatality or serious
injuries if not prevented.
WARNING
…indicates a potentially dangerous situation, which may lead to a fatality or serious
injuries if not prevented.
CAUTION
…indicates a potentially dangerous situation, which may lead to minor/slight injuries if
not prevented.
NOTICE
…indicates a potentially harmful situation, which may lead to material damage if not
prevented.
NOTE
…highlights useful tips and recommendations as well as information for efficient and
trouble-free operation.
1 ABOUT THIS DOCUMENT
6O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 8027859//2022-06-22 | SICK
Subject to change without notice

1.3 Related applicable documents
Related applicable documents from SICK
Document Title Part number Source
Technical
information
VI83I-xxxxxxHx illumination
unit
8027770 www.sick.com/8027770
1.4 Further information
NOTE
Further documentation for the device can be found on the online product page at:
•www.sick.com/Lector85x
There, additional information has been provided depending on the product, such as:
•Model-specific online data sheets for device types, containing technical data,
dimensional drawing, and specification diagrams
•Declarations of conformity and certificates of the product family
•Dimensional drawings and 3D CAD dimension models of the device types in
various electronic formats
•Other publications related to the devices described here
•Publications dealing with accessories
ABOUT THIS DOCUMENT 1
8027859//2022-06-22 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 7
Subject to change without notice

2 Safety information
2.1 Intended use
The Lector85x image-based code reader is a SICK 4Dpro sensor. It is used for auto‐
matic, stationary identification and decoding of codes on moving or stationary objects.
The device reads 1D codes (bar codes, stacked codes) and 2D codes (matrix codes). In
read mode, the device transmits the read results via the host interface to a higher-level
computer (e.g., PLC) for further centralized processing.
The device is designed for use in industrial and logistics areas, and meets the require‐
ments for industrial ruggedness, interfaces and data processing.
SICK AG assumes no liability for losses or damage arising from the use of the product,
either directly or indirectly. This applies in particular to use of the product that does not
conform to its intended purpose and is not described in this documentation.
2.1.1 Operating restrictions
NOTE
Radio interference may occur when the device is used in residential areas!
■Only use the device in industrial environments (EN 61000-6-4).
2.1.2 Conditions for specified enclosure rating
To ensure compliance with the specified IP65 enclosure rating of the device during
operation, the following requirements must be met: If these requirements are not met,
the device does not fulfill any specified enclosure rating.
•The cables plugged into the electrical connections must be screwed tight.
•Any electrical connections that are not being used must be sealed with a tightly-
fastened protective cap (as in the delivery condition).
•The cover on the top of the device is closed.
•The optics protection hood must be screwed tightly onto the device.
2.1.3 Cover on the device
NOTICE
Risk of product damage if cover is open!
In open state, the device does not conform to a specified enclosure rating.
If necessary, only operate the device for a short time with an open cover for the
activities listed in the following: During this time, protect the device against moisture
and dust.
Briefly open the cover for the following activities:
•Inserting or removing the optional memory card
•Temporary use of the USB interface as a service interface
For further warranty provisions, see the General Terms and Conditions of SICK AG, e.g.,
on the delivery note of the device.
2.2 Improper use
Any use outside of the stated areas, in particular use outside of the technical specifica‐
tions and the requirements for intended use, will be deemed to be incorrect use.
2 SAFETY INFORMATION
8O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 8027859//2022-06-22 | SICK
Subject to change without notice

•The device does not constitute a safety component in accordance with the respec‐
tive applicable safety standards for machines.
•The device must not be used in explosion-hazardous areas, in corrosive environ‐
ments or under extreme environmental conditions.
•The device must not be operated in the temperature range below 0°C.
•Any use of accessories not specifically approved by SICK AG is at your own risk.
WARNING
Danger due to improper use!
Any improper use can result in dangerous situations.
Therefore, observe the following information:
■Product should be used only in accordance with its intended use.
■All information in the documentation must be strictly observed.
■Shut down the product immediately in case of damage.
2.3 Cybersecurity
Overview
To protect against cybersecurity threats, it is necessary to continuously monitor and
maintain a comprehensive cybersecurity concept. A suitable concept consists of organi‐
zational, technical, procedural, electronic, and physical levels of defense and considers
suitable measures for different types of risks. The measures implemented in this
product can only support protection against cybersecurity threats if the product is used
as part of such a concept.
You will find further information at www.sick.com/psirt, e.g.:
•General information on cybersecurity
•Contact option for reporting vulnerabilities
•Information on known vulnerabilities (security advisories)
2.4 Limitation of liability
Relevant standards and regulations, the latest technological developments, and our
many years of knowledge and experience have all been taken into account when
compiling the data and information contained in these operating instructions. The
manufacturer accepts no liability for damage caused by:
■Non-adherence to the product documentation (e.g., operating instructions)
■Incorrect use
■Use of untrained staff
■Unauthorized conversions or repair
■Technical modifications
■Use of unauthorized spare parts, consumables, and accessories
2.5 Modifications and conversions
NOTICE
Modifications and conversions to the device may result in unforeseeable dangers.
Interrupting or modifying the device or SICK software will invalidate any warranty claims
against SICK AG. This applies in particular to opening the housing, even as part of
mounting and electrical installation.
SAFETY INFORMATION 2
8027859//2022-06-22 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 9
Subject to change without notice

2.6 Requirements for skilled persons and operating personnel
WARNING
Risk of injury due to insufficient training.
Improper handling of the device may result in considerable personal injury and material
damage.
■All work must only ever be carried out by the stipulated persons.
The following qualifications are required for various activities:
Table 1: Activities and technical requirements
Activities Qualification
Mounting, maintenance ■Basic practical technical training
■Knowledge of the current safety regulations in the workplace
Electrical installation,
device replacement
■Practical electrical training
■Knowledge of current electrical safety regulations
■Knowledge of the operation and control of the devices in their
particular application
Commissioning, configura‐
tion
■Basic knowledge of the computer operating system used
■Basic knowledge of the design and setup of the described
connections and interfaces
■Basic knowledge of data transmission
■Basic knowledge of 1D technology (bar code) or 2D technology
(matrix code)
Operation of the device for
the particular application
■Knowledge of the operation and control of the devices in their
particular application
■Knowledge of the software and hardware environment for the
particular application
2.7 Operational safety and specific hazards
Please observe the safety notes and the warnings listed here and in other sections
of this product documentation to reduce the possibility of risks to health and avoid
dangerous situations.
LED radiation of the integrated illumination unit
NOTICE
Only the VI83I illumination units from SICK intended for integration in this application
can be used as an integrated illumination unit.
Risk group 2
•Color of the illumination: visible white light (aperture angle: wide, medium)
2 SAFETY INFORMATION
10 O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 8027859//2022-06-22 | SICK
Subject to change without notice

CAUTION
Warning! Optical radiation: LED risk group 2, visible radiation, 400nm to 780nm
Potentially dangerous optical radiation. Can be damaging to the eyes.
■Do not look into the light source for extended periods of time.
■Never point the light source at people.
■Avoid any reflections on people from reflective surfaces. Be particularly careful
during mounting and alignment work.
■Do not open the housing. Opening the housing will not switch off the light source.
Opening the housing may increase the level of risk.
■Comply with the current national regulations on photobiological security of lamps
and lamp systems.
If looking directly into the light source for more than 0.25seconds cannot be ruled out
when handling the illumination unit (e.g., commissioning, adjustment, cleaning), wear
suitable eye protection.
If the product is operated in conjunction with external illumination systems, the risks
described here may be exceeded. This must be taken into consideration by users on a
case-by-case basis.
Laser alignment aid
CAUTION
Optical radiation: Class 1 Laser Product
The accessible radiation does not pose a danger when viewed directly for up to 100
seconds. It may pose a danger to the eyes and skin in the event of incorrect use.
■Do not open the housing. Opening the housing may increase the level of risk.
■Current national regulations regarding laser protection must be observed.
Caution – Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
For both radiation types:
It is not possible to entirely rule out temporary disorienting optical effects, particularly
in conditions of dim lighting. Disorienting optical effects may come in the form of 
dazzle, flash blindness, afterimages, photosensitive epilepsy, or impairment of color
vision, for example.
CAUTION
Risk of injury due to hot device surface.
The surface of the device can become hot.
•Before performing work on the device (e.g. mounting, cleaning, disassembly),
switch off the device and allow it to cool down.
•Ensure good dissipation of excess heat from the device to the surroundings.
SAFETY INFORMATION 2
8027859//2022-06-22 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 11
Subject to change without notice

WARNING
Electric shock!
Non-insulated electrical conductors are located in the housing. Electrical voltage can
cause severe injury or death.
■Do not open the housing.
■Protect the housing from damage.
■If the housing is damaged, disconnect the device from the voltage supply and do
not put it into operation.
WARNING
Electrical voltage!
Electrical voltage can cause severe injury or death.
■Work on electrical systems must only be performed by qualified electricians.
■The power supply must be disconnected when attaching and detaching electrical
connections.
■The product must only be connected to a voltage supply as set out in the require‐
ments in the operating instructions.
■National and regional regulations must be complied with.
■Safety requirements relating to work on electrical systems must be complied with.
WARNING
Risk of injury and damage caused by potential equalization currents!
Improper grounding can lead to dangerous equipotential bonding currents, which may
in turn lead to dangerous voltages on metallic surfaces, such as the housing. Electrical
voltage can cause severe injury or death.
■Work on electrical systems must only be performed by qualified electricians.
■Follow the notes in the operating instructions.
■Install the grounding for the product and the system in accordance with national
and regional regulations.
2.8 LED warning label
Illumination unit
Illumination units with LEDs in risk group RG2 are provided with a warning label.
Figure 1: Risk Group RG2: CAUTION – Possibly hazardous optical radiation emitted from
this product. Do not look into the lamp during operation. This could damage your eyes. IEC
62471:2006-07; EN 62471:2008-09.
Protective cover for optics
The mounted optics protection hood covers the warning label on the illumination unit.
The illumination unit types in risk group RG2 therefore contain an additional warning
label for risk group RG2.
When the illumination unit and optics protection hood are mounted, apply the addi‐
tional warning label to the outside of the optics protection hood in a well visible location
near the light outlet. If the device itself is, for example, integrated into a machine in
such a way that the attached warning label is obscured, attach further clearly visible
labels to the machine close to where the light is emitted.
2 SAFETY INFORMATION
12 O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 8027859//2022-06-22 | SICK
Subject to change without notice

Figure 2: CAUTION – Possibly hazardous optical radiation emitted from this product. Do not
look into the lamp during operation. This could damage your eyes. IEC62471:2006-07;
EN62471:2008-09.
2.9 Applying the LED warning label
Overview
The mounted optics protection hood covers the warning label on the illumination unit.
The integrated illumination unit types in risk group RG2 therefore contain an additional
warning label for risk group RG2. Apply the additional warning label to the outside of
the optics protection hood of the device in a well visible location.
Approach
1. Attach the illumination unit to the housing of the device.
2. Manually adjust the sharpness and aperture of the lens unit. Check the adjust‐
ment using SOPASair.
3. Attach the optics protection hood and screw it tight.
4. Apply the warning label to the optics protection hood in a well visible location near
the light outlet.
5. If the device itself is, for example, integrated into a machine in such a way that
the attached warning label is obscured, attach further clearly visible labels to the
machine close to where the light is emitted.
SAFETY INFORMATION 2
8027859//2022-06-22 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 13
Subject to change without notice

3 Product description
3.1 Product variants
Flex product variant
The Flex product variant is a camera housing with a C-mount thread. The product
can be assembled from individual components to suit the particular application. The
individual components can be ordered separately as accessories. Use only products
from SICK as components.
3.2 Scope of delivery
No. of
units
Component Note
1 Device in the version ordered •Camera housing with C-mount threaded connec‐
tion
•Order individual components separately as
accessories and mount them independently.
•Light inlet is sealed with a protective cap.
•Electrical connections are sealed with protective
caps.
•Without holders and connecting cables
2 Sliding nut, 5.5mm deep, with
M5 threaded fixing hole
•Alternative mounting option for the device
instead of the threaded mounting hole
•Use in pairs.
1 Hexagon key WAF2 For mounting the integrated VI83I illumination unit
1 LED warning label RG2 (self-
adhesive)
The LED warning label is included in the scope of
delivery of the separately-ordered RG2 illumination
unit.
1 Printed safety notes, multilin‐
gual
Brief information and general safety notes
With special variants, where optional extras have been ordered, or owing to the latest
technical changes, the actual scope of delivery may vary from the features and illustra‐
tions shown here.
3.3 Product ID
3.3.1 Type label
The type label contains information for identifying the product.
3 PRODUCT DESCRIPTION
14 O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 8027859//2022-06-22 | SICK
Subject to change without notice

Lector85x
V2D8512R-1MCXXXALOS
Product ID: pid.sick.com/1123615/22011234
MAC P1:
Scan Me!
D-79276 Reute
Made in Germany
Manufactured:
Janurary 2022
00:11:22:33:44:55
00:11:22:33:44:56MAC P2:
DC 24 V ±20% P max. 20 W
P/N S/N
Adjustable
F o c u s
MP12
25
1
2
6
3
7
ß
8
9
4
5
Connectivity
LA
FL 12mm
f/1.8-16.0
Figure 3: Lector85x type label (example)
1Product and type designation
2Product characteristics
3Product ID
4MAC address
5Supply voltage and maximum power consumption
6Conformity mark and certification mark
7Production date
8Production site
9Scan me!
ßQR code with a link to the product and more information
3.3.2 Type code
The devices of the product family are arranged according to the following type code:
V2D 8 5 aa b - c d e f g h i j w l
1-3 4 5 6-7 8 9 10 11 12 13 14 15 16 17 18 19
Position Description Characteristic
1-3 Device name type V2D: Vision 2D matrix
4 Product family 8: 8xx series
5 Platform / housing 5: Advanced Line
6-7 Image sensor resolution 12: 12megapixels
8 Function R: Lector - Reading
9 Separator "-"
10 Generation 1: First generation
11 Image sensor type/color M: Monochrome
12 Optical/focusing system C: C-mount
13 Lighting X: Without
PRODUCT DESCRIPTION 3
8027859//2022-06-22 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 15
Subject to change without notice

Position Description Characteristic
14 Focal length X: Without
15 Filter X: Without
16 CPU A: Advanced
17 Connection modules L: LA version (logistics automation)
18 IP protection class and front screen 0: Without
19 Temperature range S: 0°C…50°C (standard)
3.4 Setup and dimensions
P2
P1
P3
X2
X1
P2
P1
P3
X2
X1
P2
P1
P3
X2
X1
1
24
5
6
78
3Lector 850
40.3
(1.59)
0.9
(0.04)
46
(1.81)
90
(3.54)
21.4
(0.84)
75.6
(2.98)
7.2
(0.28)
102
(4.02)
22.2
(0.87)
13.6
(0.54)
97.8
(3.85)
15.9
(0.55)
143.4
(5.65)
min. 8 (0.31) - max. 87 (3.43)
Figure 4: structure and device dimensions, unit: mm (inch), decimal separator: period
1Optics protection hood (accessory)
2USB
3MicroSD memory card
44 tapped blind holes, M2.5, 5.5 mm deep, for mounting the spacer
5C-mount thread
6Cover (service)
7Two M5 sliding nuts; 5.5mm deep; pivoting; as an alternative method of mounting the
device
8Four M5 tapped blind holes, 5.5mm deep; for mounting the device
3 PRODUCT DESCRIPTION
16 O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 8027859//2022-06-22 | SICK
Subject to change without notice

3.5 Integrated illumination unit
Overview
1
2
4
3
Figure 5: VI83I illumination unit
1Illumination = 32 LEDs
21 Feedback LED, color: visible green light, e.g., for Good Read (not available)
31 Feedback LED, color: visible red light, e.g., for No Read (not available)
3Laser alignment aid, color: visible red light (not available)
Feedback LED (not available)
The function of the feedback LED can be set using the configuration software. With the
default device settings, for example, the green feedback LED briefly produces a green
light spot within the field of view of the device after a successful read.
Laser alignment aid (not available)
The laser alignment aid produces a red cross in the field of view of the object. The
alignment aid can be switched off.
3.6 Display and control elements
Overview
1
1Status LEDs
Status LEDs
Display LED Color Status
Ready OBlue Device is switched on
PRODUCT DESCRIPTION 3
8027859//2022-06-22 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 17
Subject to change without notice

Display LED Color Status
L/A P3
GbE
o- No Ethernet connection
OGreen Connected to network (10/100MB/s)
ÖGreen Data transmission over the network (10/100MB/s)
OBlue Connected to network (1GB/s)
ÖBlue Data transmission over the network (1GB/s)
o = off; O = illuminated; Ö = flashing
3 PRODUCT DESCRIPTION
18 O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 8027859//2022-06-22 | SICK
Subject to change without notice

4 Transport and storage
4.1 Transport
NOTICE
Damage due to improper transport!
■The product must be packaged with protection against shock and damp.
■Recommendation: Use the original packaging.
■Note the symbols on the packaging.
■Do not remove packaging until immediately before you start mounting.
4.2 Unpacking
•To protect the device against condensation, allow it to equilibrate with the ambient
temperature before unpacking if necessary.
•Handle the device with care and protect it from mechanical damage.
•To avoid ingress of dust and water, only remove the protective elements, e.g.
protective caps of the electrical connections just before attaching the connecting
cable.
4.3 Transport inspection
Immediately upon receipt in Goods-in, check the delivery for completeness and for any
damage that may have occurred in transit. In the case of transit damage that is visible
externally, proceed as follows:
•Do not accept the delivery or only do so conditionally.
•Note the scope of damage on the transport documents or on the transport compa‐
ny's delivery note.
•File a complaint.
NOTE
Complaints regarding defects should be filed as soon as these are detected. Damage
claims are only valid before the applicable complaint deadlines.
4.4 Storage
Store the device under the following conditions:
•Recommendation: Use the original packaging.
•Electrical connections are provided with a protective cap (as in the delivery condi‐
tion).
•Do not store outdoors.
•Store in a dry area that is protected from dust.
•To allow any residual dampness to evaporate, do not package in airtight contain‐
ers.
•Do not expose to any aggressive substances.
•Protect from sunlight.
•Avoid mechanical shocks.
•Storage temperature: see "Technical data", page 42.
•Relative humidity: see "Technical data", page 42.
•For storage periods of longer than 3 months, check the general condition of all
components and packaging on a regular basis.
TRANSPORT AND STORAGE 4
8027859//2022-06-22 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 19
Subject to change without notice

5 Mounting
5.1 Mounting instructions
•Observe the technical data.
•Protect the sensor from direct and indirect sunlight.
•To prevent condensation, avoid exposing the device to rapid changes in tempera‐
ture.
•The mounting site has to be designed for the weight of the device.
•Do not subject the device to excessive shock or vibrations. In systems subjected to
heavy vibrations, secure the screws used to mount the lens and illumination unit
using threadlocking adhesive.
•Observe the permitted ambient operating temperature, see "Technical data",
page 42. If the ambient operating temperature will be ≥45°C, ensure adequate
heat dissipation when mounting the device. For example, mount the device using a
mounting bracket on a suitable heat sink made of aluminum profile. Mounting
brackets are available as accessories. Use a heat sink with the dimensions
40mm x 80mm x 665mm. To ensure air circulation, mount the device, for
example, at an adequate distance from walls, ceilings and other devices.
•If the ambient temperature is above 35°C, do not adjust the mounted lens when
the device is switched on.
•If the device was previously switched on, wait for temperature equalization before
you touch the mounted lens (e.g., for removal) of a device that is not switched on
and where the ambient temperature is above 35°C.
5.2 Preparation for mounting
5.2.1 Installation requirements
Mounting requirements
•Typical space requirement: see type-specific dimensional drawing
•Comply with the technical data, such as the permitted ambient conditions for
operation, see "Technical data", page 42.
•Only mount the device using the threaded mounting holes provided or the movable
sliding nuts.
•Mount the device in a shock and vibration insulated manner.
•Make sure the device has a clear view of the codes.
Auxiliary equipment required
■Mounting system with sufficient load-bearing capacity and suitable dimensions
■4 or 2 M5 screws for mounting the device on a mounting system supplied by the
customer
■Tool and tape measure
The screw length depends on the mounting base (wall thickness of the bracket). When
using an optional SICK mounting system, the screws for mounting the device are
included with delivery.
5.2.2 Mounting systems
Mount the device to the mounting systems using at least 2 threaded mounting holes
(M5) or sliding nuts.
The threaded mounting holes are located on the rear side of the device.
The sliding nuts can each be inserted into a slot on the side of the housing.
5 MOUNTING
20 O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex 8027859//2022-06-22 | SICK
Subject to change without notice
