Siemens QNA2 D Series Guide

QNA2..D
Indoor air quality multi-sensor
Mounting
A6V13562246_en--_c Smart Infrastructure
2023-05-16

2 | 16 A6V13562246_en--_c
Table of Contents
1Mounting and installation......................................................................................................................3
1.1 Drywall mounting .....................................................................................................................................6
1.2 Conduit box mounting ..............................................................................................................................9
1.3 Surface mounting...................................................................................................................................12
2Notes ....................................................................................................................................................14
2.1 Safety ....................................................................................................................................................14
2.2 Disposal.................................................................................................................................................14
3Dimensions ..........................................................................................................................................15

Mounting and installation
Drywall mounting
1
A6V13562246_en--_c 3 | 16
1 Mounting and installation
For technical data, see Data sheet.
For configuration, see Commissioning.
Note
Check the package to ensure that it includes all inbox items
Product Package item Name
QNA2700D.BA2
BACnet MSTP
●Sensor module
●Surface mount BACnet MSTP version
●In-wall mount
– Backpack with terminals
– Conduit box cover, mounting plate
– Set of screws and plastic insert
QNA2700D.BA1
BACnet IP
●Sensor module
●Surface mount BACnet IP version
●In-wall mount
– Backpack POE only
– Conduit box cover, mounting plate
– Set of screws and plastic insert
QNA2820D.xx
LoRaWAN
●Sensor module
●Surface mount, antenna
●In-wall mount
– Backpack with terminals (optional)
– Conduit box cover, mounting plate
– Set of screws and plastic insert

Mounting and installation
Drywall mounting
1
4 | 16 A6V13562246_en--_c
NOTICE
●Commission and setup the device prior to mounting.
●To power on the sensor module, connect it to a surface mount powered by
USB type C, PoE, or AC/DC 12...24 V.
Mounting location
●The devices are suitable for drywall mounting, conduit box mounting and surface mounting.
●Recommended height: 1.5 m (4 feet) above the floor. If the recommended height cannot be met, it should
not be lower than 0.9 m (3 feet).
●Do not mount the devices in recesses, shelves, behind curtains or doors, or above or near heat sources.
●Avoid direct solar radiation and drafts.
●Avoid unheated (uncooled) building area such as outside walls.
●Seal the conduit box or the installation tube if any, as air currents can affect sensor readings.
●Adhere to allowed ambient conditions.
●Devices should be mounted at least 5 m (16 feet) away from operable windows, air filters, and fresh air
diffusers.
●In areas where this is impossible, center your device between windows and place your monitor closer to air
return than air diffusers.

Mounting and installation
Drywall mounting
1
A6V13562246_en--_c 5 | 16
Select data mode
●With the inside (concave surface) facing you ensure that the mode selection switch points to 1 (LoRaWAN).
For configuration of BACnet, see Commissioning.
Preparing data connection
Set up your LoRaWAN gateway router prior to installation and on-boarding if LoRaWAN is used
●Unpack the contents of your surface mount kit and In-wall mount kit. If you plan to use LoRaWAN for data
connectivity, locate the LoRa gateway antenna provided in the surface mount kit and screw it onto the top of
the surface mount.

Mounting and installation
Drywall mounting
1
6 | 16 A6V13562246_en--_c
1.1 Drywall mounting

Mounting and installation
Drywall mounting
1
A6V13562246_en--_c 7 | 16

Mounting and installation
Drywall mounting
1
8 | 16 A6V13562246_en--_c

Mounting and installation
Conduit box mounting
1
A6V13562246_en--_c 9 | 16
1.2 Conduit box mounting

Mounting and installation
Conduit box mounting
1
10 | 16 A6V13562246_en--_c

Mounting and installation
Conduit box mounting
1
A6V13562246_en--_c 11 | 16

Mounting and installation
Surface mounting
1
12 | 16 A6V13562246_en--_c
1.3 Surface mounting

Mounting and installation
Surface mounting
1
A6V13562246_en--_c 13 | 16

Notes
Safety
2
14 | 16 A6V13562246_en--_c
2 Notes
2.1 Safety
CAUTION
National safety regulations
Failure to comply with national safety regulations may result in personal injury and
property damage.
●Observe national provisions and comply with the appropriate safety
regulations.
NOTICE
Radio frequency energy
Interference to radio communications
●Install and use equipment in accordance with installation guide.
●Read all regulatory compliance information.
2.2 Disposal
This symbol or any other national label indicate that the product, its packaging, and, where
applicable, any batteries may not be disposed of as domestic waste. Delete all personal
data and dispose of the item(s) at separate collection and recycling facilities in accordance
with local and national legislation.
For additional details, refer to Siemens information on disposal.

Dimensions 3
A6V13562246_en--_c 15 | 16
3 Dimensions
Dimensions in mm

A6V13562246_en--_c
Issued by
Siemens Switzerland Ltd
Smart Infrastructure
Global Headquarters
Theilerstrasse 1a
CH-6300 Zug
[phone]
www.siemens.com/buildingtechnologies
© Siemens Switzerland Ltd, 2022
Technical specifications and availability subject to change without notice.
