Siemens SIMATIC RF640T Gen 2 User manual

SIMATIC RF640T Gen 2 1
SIMATIC Sensors
RFID systems
SIMATIC RF640T Gen 2
Operating Instructions
05/2009
J31069-D0197-U001-A2-7618
TAGnology RFID GmbH | Grazer Vorstadt 142 | 8570 Voitsberg | AUSTRIA
phone: [phone] | fax: [phone] | of[e-mail] | www.tagnology.com

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
with a safety alert symbol, indicates that minor personal injury can result if proper precautions are not taken.
CAUTION
without a safety alert symbol, indicates that property damage can result if proper precautions are not taken.
NOTICE
indicates that an unintended result or situation can occur if the corresponding information is not taken into
account.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The device/system may only be set up and used in conjunction with this documentation. Commissioning and
operation of a device/system may only be performed by qualified personnel. Within the context of the safety notes
in this documentation qualified persons are defined as persons who are authorized to commission, ground and
label devices, systems and circuits in accordance with established safety practices and standards.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be adhered to. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of the
owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
J31069-D0197-U001-A1-7618
Ⓟ 05/2009
Copyright © Siemens AG 2006,
2007, 2008, 2009.
Technical data subject to change

SIMATIC RF640T Gen 2
Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618 3
Table of contents
1 SIMATIC RF640T Gen 2 ........................................................................................................................... 5
1.1 Characteristics ...............................................................................................................................5
1.2 Ordering data .................................................................................................................................6
1.3 Planning the use ............................................................................................................................6
1.3.1 Optimum antenna/transponder positioning with plane mounting of the transponder on
metal ..............................................................................................................................................6
1.3.2 Reading range on flat metallic carrier plates .................................................................................7
1.3.3 Reading range when mounted on non-metallic carriers ................................................................8
1.3.4 Influence of conducting walls on the reading range.......................................................................9
1.3.5 Directional radiation pattern of the transponder...........................................................................10
1.3.6 Use of the transponder in hazardous areas.................................................................................11
1.3.7 Use of the transponder in hazardous areas for gases.................................................................12
1.3.8 Use of the transponder in hazardous areas for dusts..................................................................13
1.4 Mounting instructions ...................................................................................................................14
1.5 Memory configuration ..................................................................................................................15
1.6 Technical Specifications ..............................................................................................................18
1.6.1 Mechanical data...........................................................................................................................18
1.6.2 Electrical data...............................................................................................................................18
1.6.3 Memory specifications .................................................................................................................19
1.6.4 Environmental conditions.............................................................................................................19
1.6.5 Chemical resistance of the RF640T Gen 2 transponder .............................................................20
1.7 Certificates and approvals ...........................................................................................................22
1.7.1 Certificates and approvals ...........................................................................................................22
1.7.2 Manufacturer's declaration RF640T Gen 2 UHF Tool Tag Version 1..........................................22
1.8 Dimension drawing ......................................................................................................................23

Table of contents
SIMATIC RF640T Gen 2
4 Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618

SIMATIC RF640T Gen 2
Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618 5
SIMATIC RF640T Gen 2 1
1.1 Characteristics
The SIMATIC RF640T Gen 2 transponder is a passive (i.e. battery-free) and maintenance-
free, round-shaped data carrier. It functions based on the UHF Class 1 Gen 2 technology
and is used for saving the electronic product code (EPC) of 96 bits/240 bits. The transponder
also has a 512-bit user memory.
Fields of application are industrial asset management, RF identification of tools, containers
and metallic equipment.
The tool tag is small, smart, and rugged, suitable for industrial applications with degree of
protection IP68. It is resistant to mineral oils, lubricants and detergents.
Preferably the SIMATIC RF640T is to be mounted direct on a flat metal surface of at least
150 mm diameter where it achieves a typical sensing distance of 4 m.
SIMATIC RF640T Gen 2 transponder Characteristics
Application Identification tasks in rugged industrial
environments
Europe USA / Canada Frequency versions
868 MHz 915 MHz
Air interface according to ISO 18000-6C
Polarization Linear
Memory EPC 96 bit/240 bit
Add-on-memory 64 bytes
Typically 4.0 m in connection with:
•RF660R readers and
•RF660A antennas
Typically 2.0 m in connection with:
•RF630R readers and
•RF660A antennas
Read/write range
Typically 2.0 m in connection with:
•RF620R with integrated antenna
Installation Suitable for direct mounting on conductive
materials (preferably metal)

SIMATIC RF640T Gen 2
1.2 Ordering data
SIMATIC RF640T Gen 2
6 Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618
1.2 Ordering data
Ordering data Order no.
SIMATIC RF640T Gen 2 (Europe)
•Frequency 865 MHz to 868 MHz
•EPC 96 bits/240 bits
•64-byte user memory
•-25 °C to +85 °C operating temperature
•Dimensions (D x H) 50 mm x 8 mm
6GT2810-2DC00
SIMATIC RF640T Gen 2 (USA/Canada)
•Frequency 902 MHz to 928 MHz
•EPC 96 bits/240 bits
•64-byte user memory
•-25 °C to +85 °C operating temperature
•Dimensions (D x H) 50 mm x 8 mm
6GT2810-2DC10
1.3 Planning the use
1.3.1 Optimum antenna/transponder positioning with plane mounting of the transponder
on metal
5)7
WUDQVSRQGHU
0HWDOVXSSRUW
5HFHLYHILHOG
5HFHLYH
7[DQWHQQD
5[DQWHQQD
7UDQVPLWILHOG
'LVWDQFHFP
5HDGLQJGLVWDQFHP
6HQG
Figure 1-1 Example of optimum antenna/transponder positioning

SIMATIC RF640T Gen 2
1.3 Planning the use
SIMATIC RF640T Gen 2
Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618 7
1.3.2 Reading range on flat metallic carrier plates
The transponder generally has linear polarization. The polarization axis runs as shown in the
diagram below. If the tag is centrically mounted on a flat metal plate, which may either be
almost square or circular, it can be aligned in any direction since the transmitting and
receiving RF660A antennas operate with circular polarization.
3RODUL]DWLRQD[LV
6TXDUH
PHWDOFDUULHUSODWH
&LUFXODUPHWDO
FDUULHUSODWH
r
Figure 1-2 Optimum positioning of the transponder on a (square or circular) metal plate
Table 1- 1 Reading range on flat metallic carrier plates
Carrier plate material Reading range
Metal plate of at least Ø 150 mm 100%
Metal plate Ø 120 mm Approx. 80%
Metal plate Ø 85 mm Approx. 55%
Metal plate Ø 65 mm Approx. 40%
On rectangular carrier plates, the reading distance depends on the mounting orientation of
the transponder

SIMATIC RF640T Gen 2
1.3 Planning the use
SIMATIC RF640T Gen 2
8 Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618
1.3.3 Reading range when mounted on non-metallic carriers
The transponder is generally designed for mounting on metallic objects which provide the
conditions for the maximum reading ranges
Table 1- 2 Reading range on non-metallic carriers
Carrier plate material Reading range
Transponder on wooden carrier Approx. 40%
Transponder on plastic carrier Approx. 35%
Transponder on plastic mineral water bottle Approx. 55%
Transponder without base Approx. 30%
100% reading distance refers to a metal plate of at least 150 mm diameter.

SIMATIC RF640T Gen 2
1.3 Planning the use
SIMATIC RF640T Gen 2
Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618 9
1.3.4 Influence of conducting walls on the reading range
If there are conducting walls or restrictions in the vicinity that could shade the radio field, a
distance of approx. 10 cm is recommended between the transponder and the wall In
principle, walls have least influence if the polarization axis is orthogonal to the conducting
wall.
Reading range: One conducting wall
Influence on reading range when positioned against one conducting wall
G
&RQGXFWLQJZDOO
3RODUL]DWLRQD[LV
Top view
Distance d 20 mm 50 mm 100 mm
Approx. 90 % Approx. 90 % Approx. 95 % Wall height 20 mm
Approx. 80 % Approx. 90 % Approx. 90 % Wall height 50 mm
Reading range
Approx. 70 % Approx. 75 % Approx. 90 % Wall height 100 mm
Reading range: Two conducting walls
Influence on reading range when positioned against two conducting walls
G
G
&RQGXFWLQJZDOO
&RQGXFWLQJZDOO
3RODUL]DWLRQD[LV
0HWDOFDUULHU
Top view
G
0HWDOFDUULHU
&RQGXFWLQJZDOO
:DOOKHLJKW
&RQGXFWLQJ
ZDOO
Side view
Distance d 20 mm 50 mm 100 mm
Approx. 75 % Approx. 90 % Approx. 90 % Wall height 20 mm
Approx. 50 % Approx. 45 % Approx. 80 % Wall height 50 mm
Reading range
Approx. 40 % Approx. 45 % Approx. 75 % Wall height 100 mm
The values specified in the tables above must be complied with.

SIMATIC RF640T Gen 2
1.3 Planning the use
SIMATIC RF640T Gen 2
10 Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618
1.3.5 Directional radiation pattern of the transponder
Preferably, align the tag parallel to the transmitting antenna. If, however, the tag including
the metallic carrier plate is tilted, the reading range will be reduced.
Rotation about the polarization axis
-25
-20
-15
-10
-5
0
-90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 30 40 50 60 70 80 90
$QJOHGHJUHHV
*DLQG%U
Figure 1-3 Transponder characteristics when rotated about the polarization axis

SIMATIC RF640T Gen 2
1.3 Planning the use
SIMATIC RF640T Gen 2
Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618 11
Rotation orthogonal to the polarization axis
-25
-20
-15
-10
-5
0
-90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 30 40 50 60 70 80 90
$QJOHGHJUHHV
*DLQG%U
Figure 1-4 Transponder characteristics when rotated orthogonally to the polarization axis (within the tag plane)
1.3.6 Use of the transponder in hazardous areas
TÜV NORD CERT GmbH, appointed center no. 0044 as per Article 9 of the Directive
94/9/EC of the European Council of 23 March 1994, has confirmed the compliance with the
essential health and safety requirements relating to the design and construction of
equipment and protective systems intended for use in hazardous areas as per Annex II of
the Directive.
The essential health and safety requirements are satisfied in accordance with standards
EN 60079-0:2004, EN 50020:2002, IEC 61241-0:2004 and IEC 61241-11:2005.
Identification
The identification is as follows:
II 2 G Ex ib IIC T6 to T3 or II 2 D Ex ibD 21 T140°C, -25 °C < Ta°< +85 °C

SIMATIC RF640T Gen 2
1.3 Planning the use
SIMATIC RF640T Gen 2
12 Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618
1.3.7 Use of the transponder in hazardous areas for gases
Temperature class delineation for gases
The temperature class of the transponder for hazardous areas depends on the ambient
temperature range:
Ambient temperature range Temperature class
-25 °C to +85 °C T3
-25 °C to +60 °C T4
-25 °C to +40 °C T5
-25 °C to +30 °C T6
WARNING
Ignitions of gas-air mixtures
When using the RF640T transponder, check to ensure that the temperature class is
observed in respect of the requirements of the area of application
Non-compliance with the permitted temperature ranges while using the transponder can
lead to ignitions of gas-air mixtures.
WARNING
Ignitions of gas-air mixtures
The maximum transmitting power of the transmitter used to operate the transponder must
not exceed 2 W.
Non-compliance with the permissible transmitting power can lead to ignitions of gas-air
mixtures.

SIMATIC RF640T Gen 2
1.3 Planning the use
SIMATIC RF640T Gen 2
Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618 13
1.3.8 Use of the transponder in hazardous areas for dusts
The equipment is suitable for dusts whose ignition temperatures for a dust layer of 5 mm are
higher than 210 °C (smoldering temperature). With the ignition temperature specified
according to IEC 61241-0 and IEC 61241-11 according to the type of ignition protection iD,
the smoldering temperature of the dust layer is referenced in this case.
Temperature class delineation for dusts
Ambient temperature range Temperature value
-25 °C < Ta < +85 °C T140 °C
WARNING
Ignitions of dust-air mixtures
When using the RF640T transponder, check to ensure that the temperature values are
complied with in connection with the requirements of the application area.
Non-compliance with the permitted temperature ranges while using the transponder can
lead to ignitions of dust-air mixtures.

SIMATIC RF640T Gen 2
1.4 Mounting instructions
SIMATIC RF640T Gen 2
14 Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618
1.4 Mounting instructions
Properties Description
Type of installation Screw mounting ①, (M4 screws)
(two DIN 433 washers and two M4 hexagon socket head cap screws
DIN 6912)
Tightening torque (at room temperature) < 1.2 Nm


Figure 1-5 Screw mounting
Note
Make sure that the mounting surface is even when mounting the transponder.
7KHPRXQWLQJVXUIDFH
PXVWEHHYHQ

SIMATIC RF640T Gen 2
1.5 Memory configuration
SIMATIC RF640T Gen 2
Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618 15
1.5 Memory configuration
SIMATIC memory configuration
The following graphic shows the structure of the virtual SIMATIC memory for the
RF620R/RF630R reader and explains the function of the individual memory areas. The
SIMATIC memory configuration is based on the 4 memory banks, as they are defined in
EPC Global.
7KH86(5PHPRU\DUHDDOZD\VEHJLQVDWDGGUHVV
DQGHQGVZLWKWKHKLJKHVWDGGUHVVZKLFKWKHWDJ
FDQXVH7KHPD[LPXPVL]HRIWKH86(5PHPRU\
DUHDLVE\WHV
7KH(3&PHPRU\DUHDDOZD\VEHJLQVDWDGGUHVV))
7KHPD[LPXPVL]HRIWKH(3&PHPRU\DUHDLVE\WHV
7KH(3&PHPRU\DUHDDOZD\VFRQWDLQVWKH(3&,'WKH
SURWRFRODQGWKH&5&RIDWDJ
))(OHQJWKE\WHV 3&3URWRFRO&RQWURO:RUG
2SWLRQDOPHPRU\DUHD
3DVVZRUGVRIWKHWUDQVSRQGHU
ವ ))  .,// SDVVZRUG ORFNHG
ವ ))  $&&(66 SDVVZRUG
2SWLRQDOPHPRU\DUHD
7KH7,'PHPRU\DUHDFRQWDLQVYHQGRUVSHFLILFGDWD
5HDGDFFHVVRQO\VL]HFDQYDU\GHSHQGLQJRQWKH
PDQXIDFWXUHU
63(&,$/PHPRU\DUHD
7KH63(&,$/PHPRU\DUHDFRQWDLQVVSHFLDOWDJ
DQGUHDGHUIXQFWLRQV
ವ )))'  $&&(66 SDVVZRUG WUDQVIHUUHG WR WKH UHD
G
ವ )))(  /2&. 81/2&. 3(50$ /2&. IXQFWLRQ
ವ ))))  .,// SDVVZRUG WUDQVIHUUHG WR WKH UHDGHU
63(&,$/
7,'
5(6(59('
(3&
86(5
0HP%DQN
0HP%DQN
KH[
)())KH[
))KH[
)))KH[
))KH[
))%)KH[
))&KH[
)))KH[
)))KH[
))))KH[
0HP%DQN
0HP%DQN
Figure 1-6 SIMATIC memory configuration

SIMATIC RF640T Gen 2
1.5 Memory configuration
SIMATIC RF640T Gen 2
16 Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618
Memory representation for RF640T Gen 2
Tags User
[hex]
EPC TID RESERVED
(passwords)
special
Range Access KILL-PW Lock
function
RF640T
Gen 2
00 - 3F FF00-FF0B
(240 Bit =
FF00-FF1D)
read/
write
FFC0-FFC7 FF80-FF87 LOCKED yes
Memory representation according to EPC
The memory of the ISO 18000-6C EPC Class 1 Gen 2 chip is logically divided into four
different memory banks:
Memory bank (decimal) Memory type Description
MemBank 112 USER User-writable USER memory area
MemBank 102 TID Is defined by the manufacturer, contains the class identifier and
serial number of a tag
MemBank 012 EPC Contains the EPC UID, the protocol and the CRC of a tag
You can write to the EPC memory area. In the delivery condition,
the memory contents can have the following states:
•empty
•containing the same data
•containing different data
MemBank 002 RESERVED Contains the access and kill password.

SIMATIC RF640T Gen 2
1.5 Memory configuration
SIMATIC RF640T Gen 2
Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618 17
The graphic below illustrates the exact memory utilization: Each box in the right part of the
graphic represents one word (16 bit) in the memory.
0HP%DQN

0HP%DQN

0HP%DQN

0HP%DQN

7,'
86(5
(3&
5(6(59('
06% /6%
7,'>@
6HULDOQXPEHU>@
7,'>@

K

K

K

K

K

K

K

K

K

K
06% /6%



(3&>@
3URWRFRO&RQWURO>@
&5&>@
(3&>@
)
K

K
)
K
)
K
)
K
)
K
)
K

K
06% /6%



86(5>@
86(5>@ ))
K
)
K
)
K
)
K
06% /6%
)
K
)
K
)
K
)
K
$FFHVV3DVVZ>@
$FFHVV3DVVZ>@
.LOO3DVVZ>@
.LOO3DVVZ>@
Color Access by SIMATIC RF660R / SIMATIC RF610M
Read
Write / read
Figure 1-7 Representation of the memory configuration RF640T Gen 2 according to EPC (logical
memory map)

SIMATIC RF640T Gen 2
1.6 Technical Specifications
SIMATIC RF640T Gen 2
18 Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618
1.6 Technical Specifications
1.6.1 Mechanical data
Property Description
Dimensions (D x H) 50 mm x 8 mm (+1 mm)
Construction PCB with integrated antenna
Design Plastic housing (PA12)
Weight approx. 13 g
Mounting on metal directly on metal without spacing
1.6.2 Electrical data
Description
Property
Europe USA / Canada
Air interface According to ISO 18 000-6 C According to ISO 18 000-6 C
Frequency range 865 … 868 MHz 902 MHz ... 928 MHz 1)
Necessary transmit power 2 W (ERP) 4 W (EIRP)
Reading range
Mounting on metal 2)
at least 3 m
typically 4.0 m
at least 3 m
typically 4.0 m
Writing range
Mounting on metal 2)
at least 2 m
typically 3 m
at least 2 m
typically 3 m
Polarization type Linear Linear
Minimum distance to transmit
antenna
Approx. 0.2 m Approx. 0.2 m
Energy source Magnetic energy via antenna, without
battery
Magnetic energy via antenna, without
battery
Multi-tag capability Yes, minimum distance between data
carriers ≥ 50 mm 3)
Yes, minimum distance between data
carriers ≥ 50 mm 3)
1) Reduction of range to about 70% at the band limits 902 MHz or 928 MHz; recording is
guaranteed at 915 MHz due to frequency hopping procedure.
2) Mounting on a flat surface with a diameter of at least 150 mm
3) When the minimum distances are not reached, there is a reduction in the maximum read
and write distances of the transponder.
See also
Reading range on flat metallic carrier plates (Page 7)
Directional radiation pattern of the transponder (Page 10)

SIMATIC RF640T Gen 2
1.6 Technical Specifications
SIMATIC RF640T Gen 2
Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618 19
1.6.3 Memory specifications
Property Description
Type EPC Class 1 Gen 2
EPC code 96 bits/240 bits
User memory 64 bytes
TID 64 bits
Memory organization
Reserved (passwords) 64 bits
Protocol ISO 18000-6C
Data retention time 10 years
Read cycles Unlimited
Write cycles Minimum at +22 °C 100 000
1.6.4 Environmental conditions
Property Description
Temperature range when operating in non-
hazardous areas
-25 °C … 85 °C1)
Temperature range when operating in areas at risk
of a gas explosion with temperature class T3-T6
See alsoUse of the transponder in hazardous
areas for gases (Page 12) 2)
Temperature range when operating in areas at risk
of dust explosions with T140 °C
See alsoUse of the transponder in hazardous
areas for dusts (Page 13) 2)
Temperature range during storage -40 °C … 125 °C1)
Shock
Vibration
compliant with EN 60721-3-7 Class 7 M3
100 g, 3)
20 g, 3)
Torsion and bending load Not permissible
IP 68 according to EN 60529:
(45 minutes. immersion in water; water depth
1 m from
top edge of housing at +20 °C)
Degree of protection
IP x9K according to EN 60529:
•Steam blaster nozzle distance 150 mm
•10 to 15 l of water per minute
•Pressure 100 bar
•Temperature 75 °C
•Test time 30 seconds
MTBF 1,54 x 107 h
1) At temperatures above 70 °C the casing may distort slightly; this does not however cause
any impairment of function (mechanical or electrical).
2) Directive 94/9/EC of the European Council of 23 March 1994 must be complied with, see
also Chapter "Using the transponder in hazardous areas".

SIMATIC RF640T Gen 2
1.6 Technical Specifications
SIMATIC RF640T Gen 2
20 Operating Instructions, 05/2009, J31069-D0197-U001-A2-7618
3) The values for shock and vibration are maximum values and must not be applied
continuously.
WARNING
Ignitions of gas-air or dust-air mixtures
When using the RF640T transponder, check to ensure that the temperature values are
observed in respect of the requirements of the hazardous area of application.
Non-compliance with the permitted temperature ranges while using the transponder can
lead to ignitions of gas-air or dust-air mixtures.
NOTICE
Damage to the surface of the housing
The values specified for the IP x9K test are maximum values and must not be applied
continuously.
Protracted loading of the transponder can lead to damage to the surface of the housing due
to high pressures.
1.6.5 Chemical resistance of the RF640T Gen 2 transponder
The following table gives an overview of the chemical composition of the data memory made
from polyamide 12. The plastic housing has a notably high resistance to chemicals used in
automobiles (e.g.: oil, grease, diesel fuel, gasoline) which are not listed separately.
Concentration 20 °C 60 °C
Acetic acid, w. 50 ￚ ￚ
Ammonia gas ￮￮￮￮ ￮￮￮￮
Ammonia, w. conc. ￮￮￮￮ ￮￮￮￮
10 ￮￮￮￮ ￮￮￮￮
Battery acid 30 ￮￮ ￚ
Benzol ￮￮￮￮ ￮￮￮
Bleach solution (12.5 % effective chlorine) ￮￮ ￚ
Butane, gas, liquid ￮￮￮￮ ￮￮￮￮
Butyl acetate (acetic acid butyl ester) ￮￮￮￮ ￮￮￮￮
Calcium chloride, w. ￮￮￮￮ ￮￮￮
Calcium nitrate, w. k. g. ￮￮￮￮ ￮￮￮
Carbon tetrachloride ￮￮￮￮ ￮￮￮￮
Chlorine ￚ ￚ
Chrome baths, tech. ￚ ￚ
Detergent High ￮￮￮￮ ￮￮￮￮
Ethyl alcohol, w., undenaturated 96 ￮￮￮￮ ￮￮￮
50 ￮￮￮￮ ￮￮￮￮
Formaldehyde, w. 30 ￮￮￮ ￚ
