Installation Instructions
Document No. 129-262
September 30, 2009
ASK76.1U Conduit Adapter
Item Number 129-262, Rev. BAPage 1 of 2
Product Description
This kit provides an adapter that allows for a conduit
connection to the OpenAir™ GDE/GLB models.
Contents
This kit contains one conduit adapter and a flat head
screw.
Product Numbers
ASK76.1U
Required Tools
•Flat head screw driver
•4 mm hex wrench
Expected Installation Time
10 minutes
Installation Conventions
WARNING
Personal injury/loss of life may
occur if you do not follow a
procedure as specified.
CAUTION
Equipment damage or loss of
data may occur if you do not
follow a procedure as specified.
Prerequisites
Provide a conduit connector.
Installation
Loosen and remove the stop set screw and nut from the
actuator. See Figure 1
Figure 1.
Attach the desired conduit connector to the base of the
conduit adapter.
NOTE: A second opening in the base of the
adapter is available by removing the
knock-out.
Figure 2.
Thread the cable through the opening(s) in the conduit
adapter.
Set the actuator in the adapter so that the actuator
fits into the guide on the adapter.

Document No. 129-262
Installations Instructions
September 30, 2009
Information in this publication is based on current specifications. The company reserves the right to make changes in specifications and
models as design improvements are introduced. OpenAir is a registered trademark of Siemens Industry, Inc. Other product or company
names mentioned herein may be the trademarks of their respective owners. © 2009 Siemens Industry, Inc.
Siemens Industry, Inc.
Building Technologies Division
1000 Deerfield Parkway
Buffalo Grove, IL 60089
+ 1 847-215-1000
Your feedback is important to us. If you have
comments about this document, please send
them to sbt_technical.edi[email protected]
Document No. 129-262
Printed in the USA
Page 2 of 2
Figure 3.
Fasten the actuator to the adapter with the screw
provided. See Figure 3.
Mount the actuator and adapter following the
installation instructions that come with the actuator.
NOTE: The actuator mounting bracket fits between
the guides in the lower back of the conduit
adapter.
Figure 4.
Reference
Installation Instruction
OpenAir GDE/GLB Rotary Non-spring Return Electronic
Damper Actuator 129-240
