Siemens SIMATIC ET 200SP User manual

___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
SIMATIC
ET 200SP
BusAdapter
Manual
03/2018
A5E41449003
-AA
Preface
1
Guide
2
Product overview
3
BusAdapter BA 2xRJ45
4
BusAdapter BA 2xFC
5
BusAdapter BA 2xSCRJ
6
BusAdapter BA SCRJ/RJ45
7
BusAdapter BA SCRJ/FC
8
BusAdapter BA 2xLC
9
BusAdapter BA LC/RJ45
10
BusAdapter BA LC/FC
11
Strain relief
12
Dimension drawings
A
Accessories
B

Siemens AG
Division Digital Factory
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E41449003-AA
Ⓟ
02/2018 Subject to change
Copyright © Siemens AG 2018.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

BusAdapter
Manual, 03/2018, A5E41449003-AA 3
Table of contents
1 Preface ................................................................................................................................................... 5
2 Guide...................................................................................................................................................... 8
2.1 BusAdapter guide .....................................................................................................................8
3 Product overview .................................................................................................................................. 11
4 BusAdapter BA 2xRJ45......................................................................................................................... 14
4.1 Product overview ....................................................................................................................14
4.2 Connecting..............................................................................................................................15
4.3 Diagnostics .............................................................................................................................18
4.4 Technical specifications ..........................................................................................................19
5 BusAdapter BA 2xFC ............................................................................................................................ 20
5.1 Product overview ....................................................................................................................20
5.2 Connecting..............................................................................................................................21
5.3 Diagnostics .............................................................................................................................25
5.4 Technical specifications ..........................................................................................................26
6 BusAdapter BA 2xSCRJ........................................................................................................................ 27
6.1 Product overview ....................................................................................................................27
6.2 Connecting..............................................................................................................................28
6.3 Diagnostics .............................................................................................................................32
6.4 Technical specifications ..........................................................................................................34
7 BusAdapter BA SCRJ/RJ45 .................................................................................................................. 35
7.1 Product overview ....................................................................................................................35
7.2 Connecting..............................................................................................................................36
7.3 Diagnostics .............................................................................................................................38
7.4 Technical specifications ..........................................................................................................40
8 BusAdapter BA SCRJ/FC...................................................................................................................... 41
8.1 Product overview ....................................................................................................................41
8.2 Connecting..............................................................................................................................42
8.3 Diagnostics .............................................................................................................................44
8.4 Technical specifications ..........................................................................................................46

Table of contents
BusAdapter
4Manual, 03/2018, A5E41449003-AA
9 BusAdapter BA 2xLC ............................................................................................................................ 47
9.1 Product overview.................................................................................................................... 47
9.2 Connecting ............................................................................................................................. 48
9.3 Diagnostics............................................................................................................................. 52
9.4 Technical specifications ......................................................................................................... 53
10 BusAdapter BA LC/RJ45....................................................................................................................... 54
10.1 Product overview.................................................................................................................... 54
10.2 Connecting ............................................................................................................................. 55
10.3 Diagnostics............................................................................................................................. 57
10.4 Technical specifications ......................................................................................................... 58
11 BusAdapter BA LC/FC .......................................................................................................................... 59
11.1 Product overview.................................................................................................................... 59
11.2 Connecting ............................................................................................................................. 60
11.3 Diagnostics............................................................................................................................. 62
11.4 Technical specifications ......................................................................................................... 63
12 Strain relief ........................................................................................................................................... 64
12.1 Product overview.................................................................................................................... 64
12.2 Installing ................................................................................................................................. 65
A Dimension drawings.............................................................................................................................. 67
A.1 BusAdapter dimension drawings ........................................................................................... 67
A.2 Strain relief dimension drawings ............................................................................................ 67
B Accessories .......................................................................................................................................... 68
B.1 Accessories............................................................................................................................ 68

BusAdapter
Manual, 03/2018, A5E41449003-AA 5
Preface
1
Purpose of the manual
This manual provides all the necessary information for configuring, installing, connecting and
commissioning the BusAdapter.
Basic knowledge required
The following knowledge is required in order to understand the manual:
●General knowledge in the field of automation technology
●Knowledge of the use of computers or PC -like tools (e.g. programming devices) under
the Windows operating system.
●Knowledge of working with STEP 7. You can find information on this topic in the STEP 7
online help.
Range of validity of this manual
The manual describes the components based on the data valid at the time of its release. We
reserve the right to include up-to-date Product Information with new components and new
versions of components.

Preface
BusAdapter
6Manual, 03/2018, A5E41449003-AA
Recycling and disposal
The BusAdapter can be recycled due to their low pollutant content. For environmentally
sustainable recycling and disposal of your old device, please contact a company certified for
the disposal of electronic waste.
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens' products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be
connected to an enterprise network or the internet if and to the extent such a connection is
necessary and only when appropriate security measures (e.g. firewalls and/or network
segmentation) are in place.
For additional information on industrial security measures that may be implemented, please
visit (https://www.siemens.com/industrialsecurity).
Siemens' products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customers' exposure
to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under (https://www.siemens.com/industrialsecurity).

Preface
BusAdapter
Manual, 03/2018, A5E41449003-AA 7
Siemens Industry Online Support
You can find current information on the following topics quickly and easily here:
●
Product support
All the information and extensive know-how on your product, technical specifications,
FAQs, certificates, downloads, and manuals.
●
Application examples
Tools and examples to solve your automation tasks – as well as function blocks,
performance information and videos.
●
Services
Information about Industry Services, Field Services, Technical Support, spare parts and
training offers.
●
Forums
For answers and solutions concerning automation technology.
●
mySupport
Your personal work area in Industry Online Support for messages, support queries, and
configurable documents.
This information is provided by the Siemens Industry Online Support on the Internet
(http://www.siemens.com/automation/service&support).
Industry Mall
The Industry Mall is the catalog and order system of Siemens AG for automation and drive
solutions on the basis of Totally Integrated Automation (TIA) and Totally Integrated Power
(TIP).
You can find catalogs for all automation and drive products on the Internet
(https://mall.industry.siemens.com).

BusAdapter
8Manual, 03/2018, A5E41449003-AA
Guide
2
2.1
BusAdapter guide
Device information
The BusAdapter manual contains information, for example, on properties, assembling,
connecting, configuring and parameter assignment, alarms and diagnostics and technical
specifications of the BusAdapter.
General information
The function manuals contain detailed descriptions on general topics such as PROFINET
and communication.
You can download the documentation free of charge from the Internet
(https://support.industry.siemens.com/cs/ww/de/view/109742709).
"mySupport"
With "mySupport", your personal work area, you make the most of your Industry Online
Support.
In "mySupport" you can store filters, favorites and tags, request CAx data and put together
your personal library in the Documentation area. Furthermore, your data is automatically
filled into support requests and you always have an overview of your current requests.
You must register once to use the full functionality of "mySupport".
You can find "mySupport" on the Internet (https://support.industry.siemens.com/My/ww/de/).

Guide
2.1 BusAdapter guide
BusAdapter
Manual, 03/2018, A5E41449003-AA 9
"mySupport" - Documentation
In the Documentation area of "mySupport", you have the possibility to combine complete
manuals or parts of them to make your own manual.
You can export the manual in PDF format or in an editable format.
Your documentation is available in My Documentation Manager
(http://support.industry.siemens.com/My/ww/de/documentation).
"mySupport" - CAx data
In the CAx data area in "mySupport", you can access the current product data for your CAx
or CAe system.
You configure your own download package with a few clicks.
In doing so you can select:
●Product images, 2D dimension drawings, 3D models, internal circuit diagrams, EPLAN
macro files
●Manuals, characteristics, operating manuals, certificates
●Product master data
You can find "mySupport" - CAx data on the Internet
(http://support.industry.siemens.com/my/ww/de/CAxOnline).
Application examples
The application examples support you with various tools and examples for solving your
automation tasks. Solutions are shown in interplay with multiple components in the system -
separated from the focus on individual products.
Additional information can be found on the Internet under Application examples
(https://support.industry.siemens.com/sc/ww/de/sc/2054).

Guide
2.1 BusAdapter guide
BusAdapter
10 Manual, 03/2018, A5E41449003-AA
SIMATIC Automation Tool
You can use the SIMATIC Automation Tool to perform commissioning and maintenance
activities simultaneously on various SIMATIC S7 stations as a bulk operation independent of
the TIA Portal.
The SIMATIC Automation Tool provides a multitude of functions:
●Scanning of a PROFINET/Ethernet system network and identification of all connected
CPUs
●Address assignment (IP, subnet, gateway) and station name (PROFINET device) to a
CPU
●Transfer of the date and the programming device/PC time converted to UTC time to the
module
●Program download to CPU
●RUN/STOP mode switchover
●CPU localization by means of LED flashing
●Reading out of CPU error information
●Reading of the CPU diagnostic buffer
●Reset to factory settings
●Firmware update of the CPU and connected modules
You can find the SIMATIC Automation Tool on the Internet
(https://support.industry.siemens.com/cs/ww/de/view/98161300).
PRONETA
With SIEMENS PRONETA (PROFINET network analysis), you analyze the plant network
during commissioning. PRONETA features two core functions:
●The topology overview independently scans PROFINET and all connected components.
●PRONETA also scans: configuration of the station name, IP subnet mask and
identification and maintenance data (I&M1..3)
For more information, refer to SIEMENS PRONETA
(https://support.industry.siemens.com/cs/ww/de/view/67460624).

BusAdapter
Manual, 03/2018, A5E41449003-AA 11
Product overview
3
Introduction
The SIMATIC BusAdapters connect PROFINET IO to their ET 200SP system. You select the
required connection technology and connection method for your process from the different
versions of SIMATIC BusAdapter.
Supported PROFINET devices
The SIMATIC BusAdapters are used for:
●ET 200SP interface module and central processing unit (CPU and Open Controller)
●PN/PN Coupler
●Switches
Overview
The SIMATIC BusAdapters can be ordered in the following versions:
BusAdapter
Article number
Property
Figure
BA 2xRJ45 6ES7193-6AR00-
0AA0
PROFINET BusAdapter with
standard Ethernet socket for
standard RJ45 connector
BA 2xFC 6ES7193-6AF00-
0AA0
PROFINET BusAdapter with
FastConnect Ethernet connection
for direct connection of the bus
cable for applications with in-
creased EMC and vibration/shock
load

Product overview
BusAdapter
12 Manual, 03/2018, A5E41449003-AA
BusAdapter
Article number
Property
Figure
BA 2xSCRJ 6ES7193-6AP00-
0AA0
PROFINET BusAdapter with fiber-
optic cable connection POF/PCF
for SCRJ connector for applica-
tions with increased EMC and
vibration/shock load as well as
electrical potential differences
between two stations
BA
SCRJ/RJ45
6ES7193-6AP20-
0AA0
Media converter, PROFINET
BusAdapter with POF/PCF fiber-
optic cable ⇔ standard RJ45 con-
nector
BA SCRJ/FC 6ES7 193-6AP40-
0AA0
Media converter, PROFINET
BusAdapter with POF/PCF fiber-
optic cable ⇔ direct connection of
bus cable
BA 2xLC 6ES7193-6AG00-
0AA0
PROFINET BusAdapter with glass
fiber-optic cable connection for LC
connector for applications with
increased EMC and vibra-
tion/shock load as well as electrical
potential differences between two
stations

Product overview
BusAdapter
Manual, 03/2018, A5E41449003-AA 13
BusAdapter
Article number
Property
Figure
BA LC/RJ45 6ES7193-6AG20-
0AA0
Media converter, PROFINET
BusAdapter with glass fiber-optic
cable ⇔ standard RJ45 connector
BA LC/FC 6ES7193-6AG40-
0AA0
Media converter, PROFINET
BusAdapter with glass fiber-optic
cable ⇔ direct connection of bus
cable
See also
Strain relief (Page 64)

BusAdapter
14 Manual, 03/2018, A5E41449003-AA
BusAdapter BA 2xRJ45
4
4.1
Product overview
Article number
6ES7193-6AR00-0AA0
View
Figure 4-1 BusAdapter BA 2×RJ45
Properties
●You connect PROFINET IO cable with RJ45 connector to the PROFINET device via the
BusAdapter BA 2×RJ45. To do this, screw the BusAdapter BA 2×RJ45 to the PROFINET
device and insert the PROFINET connecting cable.
●You loop through the PROFINET via the integrated 2-port switch.

BusAdapter BA 2xRJ45
4.2 Connecting
BusAdapter
Manual, 03/2018, A5E41449003-AA 15
4.2
Connecting
Installing the bus connector
Install the PROFINET connector according to the instructions in the PROFINET Installation
Guide (http://www.profibus.com/).
Tools required
3 to 3.5 mm screwdriver, alternatively TX10 (torx).
Accessories required
●Connector:
–IE FC RJ45 plug 180 2X2 (6GK1901-1BB10-2A)
–IE FC RJ45 plug 180 4X2 (6GK1901-1BB12-2A)
●Cables:
–IE FC TP standard cable (6XV1840-2A)
–IE FC TP trailing cable (6XV1840-3AH10)
–IE FC TP marine cable (6XV1840-4AH10)
–IE FC TP robust cable (6XV1841-2)
–IE TP torsion cable (6XV1870-2F)
●Please observe the specifications in the PROFINET Installation Guide
(http://www.profibus.com/).

BusAdapter BA 2xRJ45
4.2 Connecting
BusAdapter
16 Manual, 03/2018, A5E41449003-AA
Pin assignment
The following table shows the signal name and description of the pin assignment of
BusAdapter BA 2×RJ45.
Table 4- 1 PROFINET IO pin assignment with BusAdapter BA 2×RJ45
View
Signal name
Description
1
TD
Transmit Data +
2 TD_N Transmit Data –
3
RD
Receive Data +
4
TERM1
Termination Network 1
5
TERM1
Termination Network 1
6
RD_N
Receive Data –
7
TERM2
Termination Network 2
8 TERM2 Termination Network 1
Procedure
Watch video sequence "Connect BusAdapter BA 2xRJ45 to the ET 200SP interface module"
(https://support.industry.siemens.com/cs/ww/de/view/95886218)
To connect PROFINET IO to the PROFINET device via the BusAdapter BA 2xRJ45, follow
these steps:
1. Plug the BusAdapter BA 2×RJ45 into the PROFINET device.
2. Screw the BusAdapter BA 2×RJ45 to the PROFINET device (1 screw with 0.2 Nm
tightening torque).
3. Plug the RJ45 bus connector into the PROFINET port on the BusAdapter BA 2×RJ45.
You can also swap steps 2 and 3.

BusAdapter BA 2xRJ45
4.2 Connecting
BusAdapter
Manual, 03/2018, A5E41449003-AA 17
BusAdapter BA 2×RJ45 installed
①
CPU
②
BusAdapter BA 2×RJ45
③
PROFINET connecting cable
④
Interface module
Figure 4-2 BusAdapter BA 2×RJ45 installed (using an ET 200SP CPU/interface module as an
example)
Note
Installation guidelines for modules with PROFINET IO interfaces
En
sure that all devices are connected to the SELV/PELV power supply (or equivalent). Only
then are you permitted to operate the modules with PROFINET
IO interfaces in LAN
networks (Local Area Networks).
A data transfer point that guarantees this degree of sa
fety is prescribed for connection to the
WAN (Wide Area Network).

BusAdapter BA 2xRJ45
4.3 Diagnostics
BusAdapter
18 Manual, 03/2018, A5E41449003-AA
4.3
Diagnostics
LEDs
The figure below shows the LEDs on the BusAdapter BA 2xRJ45:
①
LK1 (green)
②
LK2 (green)
Figure 4-3 LEDs on the BusAdapter BA 2xRJ45
LK1/LK2 LEDs on the BusAdapter
Table 4- 2 Status and error displays
LED
Meaning
Remedy
LK1/LK2
off
There is no Ethernet connection between the
PROFINET IO interface of your PROFINET
device and a communication partner, e.g. IO
controller.
Check whether the bus cable to the switch or IO con-
troller is disconnected.
on
There is an Ethernet connection between the
PROFINET IO interface of your PROFINET
device and a communication partner, e.g. IO
controller.
-
flashes
The "Node flash test" is running. The
RN/ER/MT LEDs are also flashing.
-

BusAdapter BA 2xRJ45
4.4 Technical specifications
BusAdapter
Manual, 03/2018, A5E41449003-AA 19
4.4
Technical specifications
Technical specifications of the BusAdapter BA 2×RJ45
Article number
6ES7193-6AR00-0AA0
Interfaces
Number of PROFINET interfaces
1
PROFINET IO
•RJ 45 Yes; 2 x
•FC (FastConnect) No
•Number of SCRJ ports 0
•Number of LC ports 0
Cable length
–Cu conductors 100 m
Dimensions
Width
20 mm
Height
69.5 mm
Depth
59 mm
Weights
Weight, approx.
46 g
