Siemens C62 User manual

Issued by
Information and Communication mobile
Haidenauplatz 1
D-81667 Munich
© Siemens AG 2003
All rights reserved. Subject to availability.
Rights of modification reserved.
Siemens Aktiengesellschaft
www.my-siemens.com
cyan magenta yellow black LIEBREICH, Medienproduktion
Be inspired
C62
BA C62.QXD 23.07.2003 17:57 Uhr Seite 1

Contents 1
See also Index at the end of this User Guide.
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:45)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_UGTOC.fm
Safety precautions ...................... 3
Phone overview .......................... 5
Display symbols (selection) ........ 7
Getting started............................ 8
Insert SIM card/battery .............. 8
Charging the battery................. 9
Switch on, off / PIN entry .......... 10
Switching on your phone
for the first time...................... 10
General information ................. 12
Security ..................................... 15
Codes ..................................... 15
Clear SIM-card barring............. 16
My phone .................................. 17
Making a phone call.................. 18
Handsfree............................... 20
Hold call ................................. 21
Conference............................. 22
Text entry.................................. 23
Text modules.......................... 26
Addressbook ............................. 27
<New entry>........................... 27
Groups ................................... 29
Businesscard........................... 30
SIM card entry ........................ 30
Records ..................................... 32
Durat / charges ......................... 33
Surf & fun .................................. 34
Internet browser (WAP)........... 34
Games.................................... 36
Organiser...................................37
Calendar .................................37
Appointments .........................38
Voice mail/mailbox ....................40
SMS............................................41
Writing and sending
SMS messages.........................41
SMS to Group..........................43
Read SMS................................43
Lists ........................................44
Archive ...................................45
MMS ..........................................46
Writing/sending
MMS messages .......................46
Receive/read MMS...................48
Lists ........................................49
Message profiles .......................51
SMS profile .............................51
MMS profile ............................52
Cell broadcast............................53
Profiles.......................................54
Extras.........................................56
SAT menu ...............................56
Alarm clock .............................56
Calculator ...............................57
Recorder .................................57
Stopwatch...............................58
Countdown .............................59
Camera (Accessories) ..............59
Contents
See also In-
dex at the end
of this User
Guide.

Contents
2
See also Index at the end of this User Guide.
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:45)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_UGTOC.fm
Fast access key.......................... 61
Speed dialling keys ................. 62
My menu ................................... 63
Filesystem ................................. 64
Setup......................................... 65
Display ................................... 65
Audio ..................................... 67
Keys ....................................... 68
Phone setup ........................... 69
Clock ...................................... 71
Connectivity ........................... 72
Security .................................. 73
Network ................................. 74
Accessories............................. 75
Notes A-Z ...................................76
Data Exchange Software ...........81
Questions & Answers ................82
Customer Care ...........................85
Care and maintenance ..............87
Product data ..............................88
Accessories ................................89
Guarantee certificate (UK) ........91
Guarantee certificate (IRL) ........92
Menu tree ..................................93
SAR- European Union (RTTE) .....97
SAR - International (ICNIRP) ......99
Index........................................100

Safety precautions 3
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:45)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_SafetyPrecautions.fm
Safety
precautions Information for parents
Please read the operating instructions and safety precautions carefully before use.
Explain the content and the hazards associated with using the phone to your children.
Remember to comply with legal
requirements and local restric-
tions when using the phone. For
example in aeroplanes, petrol
stations, hospitals or while
driving.
Mobile phones can interferewith
the functioning of medical devic-
es such as hearing aids or pace-
makers. Keep at least 20 cm/9
inches between phone and
pacemaker. When using the mo-
bile phone hold it to the ear
which is further away from the
pacemaker. For more infor-
mation consult your doctor.
The SIM card may be removed.
Caution! Small parts like this
could be swallowed by young
children.
The mains voltage specified on
the power supply unit (Volt)
must not be exceeded. Other-
wise the charging device may be
destroyed.
The ringtone (p. 67), info tones
(p. 68) and handsfree talking are
reproduced through the loud-
speaker. Do not hold the phone
to your ear when it rings or when
you have switched on the hands-
free function (p. 20). Otherwise
you risk serious permanent dam-
age to your hearing.
Only use original Siemens bat-
teries (100 % mercury-free) and
– charging devices. Otherwise
you risk serious damage to
health and property. The battery
could explode, for instance.
You may only open the phone to
replace the battery (100 % mer-
cury-free) or SIM card. You must
not open the battery under any
circumstances. All other chang-
es to this device are strictly pro-
hibited and will invalidate the
operating licence.

Safety precautions
4
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:45)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_SafetyPrecautions.fm
Please note:
Please dispose of unwanted
batteries and phones as permit-
ted by the laws in your country.
The phone may cause interfer-
ence in the vicinity of TV sets,
radios and PCs.
Use only Siemens original ac-
cessories. This will avoid poten-
tial risks to health or property
and ensure compliance with all
relevant regulations.
If you wear the phone around your neck,
please use only the Siemens original FCT-
500 Loop Case. In order to avoid any inju-
ries or death from strangulation no other
accessories are allowed for this purpose.
Childs up to 14 years shall not wear the
phone around the neck.
Improper use will invalidate the guarantee!

Phone overview 5
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:45)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_Overview.fm
Phone
overview 1Integrated antenna
Do not interfere the phone unnecces-
sarily above the battery cover, this
reduces the signal strength.
2Loudspeaker
3Display symbols
Signal strength/GPRS available/
battery level.
4Control key
See next page
5Input keys
Numbers, letters
6Microphone
7Plug socket
Connection for charger, headset etc.
Note
Your phone's display is delivered with a
protective film.
Remove this film before getting started.
In rare cases the static discharge may
cause discolouration at the edges of the
display. However this will disappear within
10 minutes.
_
Service provider
05.11.2003 12:30
New MMS Menu
1
3
2
4
5
6
7

Phone overview
6
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:45)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_Overview.fm
1Soft keys
The current functions of these keys are
shown in the bottom line of the display
as §text§/icons.
2ACall key
Dial phone number/name displayed,
take calls.
In standby mode: Show last dialled
phone numbers.
_
Service provider
05.11.2003 12:30
New MMS Menu
1
2
5
4
3
6
3B
On/Off/End key
• Switched off: hold down to
switch on.
• During a call or in an applica-
tion: press briefly to finish.
• In menus:press briefly: one
level back. Press and hold:
return to standby mode.
• In standby mode: hold
down, to switch off phone.
4Control key
In lists and menus:
GScroll up/down.
DSelect function.
CMenu level back.
During a call:
DOpen call menu.
EDisplay volume setting.
In standby mode:
FOpen Addressbook.
DOpen menu.
CGPRS info.
5*Hold down
• In standby mode: switch on/
off all signal tones (except
alarm).
For incoming calls: switch off
ringtones only.
6Hold down
• In standby mode: switch key
lock on/off.

Display symbols (selection) 7
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:45)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_DisplaySymbols.fm
Display
symbols
(selection)
Display symbols
_Signal strength.
Charging.
Battery charging status,
e.g. 50%.
èAddressbook.
ZRecords.
ÉSurf & Fun.
Organiser.
]Messages.
~Profiles.
yExtras.
ÑFile system.
mSetup.
All calls are diverted.
Ringer off.
Short ring (beep) only.
Ringer only if caller is stored in
the Addressbook.
Alarm set.
yAlarm clock activated.

Key lock activated.
Phone numbers/names:
On the SIM card.
On the SIM card
(PIN 2 protected).
vIn the phone memory.
No network access.
,Function activated/deactivated.
ABC/
Abc/abc Indicates whether upper- or lowercase letters are active.
Text input with T9.
Activated and available.
Registered.
GPRS Download.
Headset mode.
Auto answer feature on.
Organiser/Extras symbols
Memo.
vCall.
Meeting.
yAlarm clock.
Stopwatch.
Soft keys
]Message received.
MMS received.
MMS notifiation received.
Voice mail received.
Unanswered call.
Save in Addressbook.
Copy from Addressbook.
Depending on your service provider, some
of the symbols displayed here may differ
from those on the phone.

Getting started
8
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:12)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_GettingStarted.fm
Getting
started Insert SIM card/battery
The service provider supplies you
with a SIM card on which all the im-
portant data for your account is
stored. If the SIM card is in credit-
card size, snap out the smaller seg-
ment out and remove rough edges.
• Remove the battery cover by
pressing top centre of the cover
and slide downwards.
• Insert the SIM card into the slot
with the contact area facing down-
wards and push gently until it en-
gages below the holder (make
sure the angled corner is in the
correct position).
• Place the battery into the block of
the phone, with the contact area
facing down. Push the battery
carefully downwards.
• Slide the battery cover upwards
from the bottom of the phone, un-
til it latches into place.
Note
Always switch off phone before removing
the battery!
Only 3V SIM cards are supported. Please
contact your service provider, if you have
an older card.
Functions without SIM card......... page 80

Getting started 9
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:12)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_GettingStarted.fm
Charging the battery
The battery is not supplied fully
charged. Plug the charger cable into
the bottom of the phone, plug the
power supply unit into the mains
power socket and charge for at least
3,5 hours.
Display when charging is in progress
During charging.
Charging time
An empty battery is fully charged af-
ter about 3,5 hours. Charging is only
possible within the temperature
range of +0 °C to +45 °C. If the tem-
perature rises/falls above/below this,
the charge symbol flashes a warn-
ing. The voltage specified on the
power supply unit must not be ex-
ceeded.
To obtain maximum performance of
the battery it must be fully charged
and then emptied at least five times.
Charge icon not visible
If the battery was completely dis-
charged, the charging symbol will
not be immediately visible when
connected to the charger. In this
case the battery is fully charged after
4,5-5,5 hours.
Only use the charger provided!
Display while in service
Charge level display during opera-
tion (empty-full):

A beep sounds when the battery is
nearly empty. The charge level of the
battery is displayed correctly only af-
ter uninterrupted charging/discharg-
ing. You should therefore not remove
the battery unnecessarily and where
possible not interrupt charging prema-
turely.
Note
The charger will become hot after extended
use. This is normal and not dangerous.
Performance................................ page 78
Battery quality statement............. page 76

Switch on, off / PIN entry
10
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:12)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_GettingStarted.fm
Switchon,off
/
PIN entry Activate/deactivate
BHold down On/Off/End key
to switch on or off.
Enter PIN
The SIM card can be protected with a
4-8 digit PIN.
JEnter the PIN using the
number keys. The charac-
ters **** appear to en-
sure nobody can read
your PIN on the display.
Correct errors with §<C§.
§OK§ Confirm your input with
the right soft key. Logging
on to the network will
take a few seconds.
Switching on your phone
for the first time
Time and date
The clock must be set to the right
time once at start-up.
§Change§ Press.
JEnter the time, validate
with §OK§.
§Change§ Enter the date, validate
with §OK§.
Now you are also asked if you want
to copy the SIM card phonebook ent-
ries to the Addressbook on the
phone. If you choose §Yes§, please
do not interrupt this procedure. During
this time do not accept incoming calls.
Follow instructions on the display.
You are able to copy data from the
SIM card later on (page 30).
Please enter
your PIN:
* * * *
OK
<C

Switch on, off / PIN entry 11
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:12)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_GettingStarted.fm
Standby mode
When the name of the service
provider appears on the display,
the phone is in standby mode and
ready for use.
The left soft key may have different
functions pre-assigned.
BHold down the On/Off/End
key to return to standby
mode from any menu
option.
Emergency number (SOS)
Only to be used in real emergencies!
By pressing the soft key, §SOS§ you
can make an emergency call on any
network without a SIM card and
without entering a PIN (not available
in all countries).
Note
_Signal strength................ page 78
SAT menu (optional) ...........page 56
Change PIN .................................page 15
Other network .............................. page 74
SIM card problems....................... page 79
Clear SIM card barring ................. page 16
Menu
_ 
Service provider
05.11.2003 12:30
New MMS

General information
12
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:12)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_GettingStarted.fm
General
information User guide
The following symbols are used to
explain an operation:
Menu controls
In this user guide the steps needed
to reach a function are shown in
concise form, e.g. to display call list
for missed calls:
§Menu§¢Z¢Calls missed
This corresponds to:
§Menu§ Open menu.
From standby mode:
press right soft key.
JEnter numbers or
letters.
BOn/Off/End key.
ACall key.
DPress the control key on
the side indicated.
<>
Soft keys.
§Menu§ Displays a soft
key function.
LFunction dependent on
ser-vice provider, may
require special registra-
tion.
Menu
_ 
Service provider
05.11.2003 12:30
My menu
1

General information 13
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:12)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_GettingStarted.fm
ESelect ZRecords.
Press top of control key.
§Select§ Press.
Press right soft key to open the
Records submenu.
§Select§ Press.
Press right soft key to open the
Calls missed list.
FScroll to the required
entry.
Press control key at the
bottom to scroll down.
Select
My menu
èZÉ
]~
yÑm
 Messages
2
3
Select
My menu
èZÉ
]~
yÑm
 Records
Select
Records 2-1
Calls missed
Calls received
Calls dialled
Erase records
Durat / charges
4
Options
Office
[phone]
Carol
Garage
Calls missed
View
5

General information
14
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:12)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_GettingStarted.fm
§View§ Press.
Press left soft key to show
phone number with date,
time and number of calls.
Options
Office
[phone]
Carol
Garage
 Calls missed
View
6
Options
OK
 View
Carol
[phone]
05.11.2003 12:30
Calls: 5
7

Security 15
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:12)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_GettingStarted.fm
Security Codes
The phone and the SIM card are pro-
tected against misuse by several se-
curity codes.
§Menu§¢m¢Security¢Codes
¢then select function.
PIN control
The PIN is usually requested each
time the phone is switched on. You
can deactivate this feature but you
risk unauthorised use of the phone.
Some service providers do not per-
mit deactivating the control.
§Change§ Press.
JEnter PIN.
§OK§ Confirm input.
Change PIN
You can change the PIN to any
4-8 digit number you find easier to
remember.
JEnter current PIN.
§OK§ Press.
J, §OK§ Enter new PIN.
J, §OK§ Repeat new PIN.
Change PIN2
(display only if PIN 2 is available).
Proceed as with Change PIN.
Keep these confidential numbers in a
safe place where you can access them
again if required.
PIN Protects your SIM card
(personal identification
number).
PIN2 This is needed to set the charge
detail display and to access
additional functions requiring
special SIM cards.
PUK
PUK2 Key code. Used to unlock SIM
cards after the wrong PIN has
been entered repeatedly.
Phone
code Protects your phone.

Security
16
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:12)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_GettingStarted.fm
Chg.phonecode
The preset phonecode is 0000 for all
phonecode protected functions.
You are able to change it:
JEnter current phonecode.
§OK§ Press.
J, §OK§ Enter new phonecode
(4-8 digits).
J, §OK§ Repeat new phonecode.
Clear SIM-card barring
If the PIN is entered incorrectly three
times, the SIM card is barred. Enter
the PUK (MASTER PIN), provided by
your service provider with the SIM
card, according to instructions. If the
PUK (MASTER PIN) has been lost,
please contact your service provider.
Prevent accidental
activation
Even if PIN entry is deactivated (see
page 15), confirmation is required to
switch on the phone.
This prevents the phone from being
switched on accidentally, e.g. when
you are carrying it in a pocket.
BHold down.
§OK§Press. The phone switches
on.
§Cancel§ Press or take no action.
The switching-on opera-
tion is broken off.
Cancel
OK
Aircraft check
Please confirm
switch on

My phone 17
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:45)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_MyPhone.fm
My phone Change your phone to match your
personal requirements.
Ring tones
Assign individual ring tones to caller
groups (page 67).
Animations, screensavers,
logos, applications
Adjust your phone in the following
ways to give it a personal touch and
make it just how you want it:
Screensaver
Choose a digital clock or a personal
picture (page 66).
(Provider) logo
Choose an individual picture to be
displayed in standby mode
(page 65).
Wallpaper image
Choose your own background image
(page 65).
Colour scheme
Choose a colour scheme for the en-
tire service system (page 65).
Where do I get what?
You can order additional ring tones,
logos and screensavers on the Inter-
net and receive them by SMS/MMS:
www.my-siemens.com/ringtones
www.my-siemens.com/logos
www.my-siemens.com/screensaver
My menu
Create your own menu with fre-
quently used functions, phone num-
bers or WAP pages (page 63).

Making a phone call
18
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:22)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_Calling.fm
Making a
phone call Dialling with number
keys
The phone must be switched on
(standby mode).
JDial number (always with
area code, if necessary
with international dialling
code).
§<C§ A short press clears the
last digit, a long press
clears the entire number.
APress the Call key to dial
the number.
End call
BPress the End key briefly.
The call is ended. Press this key, even
if the other person hung up first.
Set volume
EUse the control key (top)
to start adjusting the vol-
ume (only possible during
conversation).
GSet volume level and con-
firm with §OK§.
If a Car Kit is used, its volume setting
will not affect the usual setting on
the phone.
Redial previous numbers
To redial the phone number last
called:
APress the Call key twice.
To redial other numbers that were
dialled previously:
APress the Call key once.
GSelect the required phone
number from the list,
then press ...
A... to dial.
Note
Save phone number in the
Addressbook ................................page 27
§Options§ Call lists........................page 32
§Hold§ ...........................................page 21
§Menu§ Call menu .........................page 22
§Divert§ Set divert .........................page 69
§Handsfr.§ Handsfree....................page 20
Microphone off .............................page 22
Phone number transmission
off/on (Hide ID).............................page 69
International dialling codes...........page 77
Phone number memo...................page 78
Control codes (DTMF)..................page 76

Making a phone call 19
C62 en, A31008-H6880-A1-1-7619 (13. February 2004, 15:22)
© Siemens AG 2003, I:\Mobil\L55\C62_Squirrel_(mc)\en\fug\_von_itl\C62long_Calling.fm
If number is busy
If the number called is busy or can-
not be reached because of network
problems, you are able to choose
(depending on the service provider):
Automatic redial of last number
§Auto dial§ Press. The phone number
is automatically dialled for
up to 15 minutes at in-
creasing time intervals.
End with: BEnd key.
Reminder
§Prompt§ Press. A beep reminds you
to redial the displayed
phone number after
15 minutes.
An incoming or outgoing call or §Off§
interrupts these functions.
Accept call
The phone must be switched on
(standby mode). An incoming call
will interrupt any other use of the
phone.
§Answer§ Press.
or
APress.
If the phone number has been trans-
mitted by the network, it is dis-
played. If the caller's name is in the
Addressbook, this will be shown in-
stead of the number. If set, a picture
can be displayed instead of the bell
icon (page 27).
Note
Please make sure you have accepted the
call before holding the phone to your ear.
This will prevent a loud ring tone from
damaging your hearing!
Answer Reject

[phone]
