Siemens E10 Operator's manual

Information and Communication
Communication Devices
E10 / S6 Power GSM /S8 GSM
Level .5
Repair Documentation
V 1.2
V1.2 Page 1 of 22 ICP CD ST
D. Schnoor
06/98

Information and Communication
Communication Devices
Table of Contents:
1INTRODUCTION................................................................................................................................................. 2
2VCXO
................................................................................................................................................................................... 3
3FUSE 1A
................................................................................................................................................................................... 8
4FUSE 0.25 A
................................................................................................................................................................................. 12
5MOLEX CONNECTOR
................................................................................................................................................................................. 16
6RINGER
................................................................................................................................................................................. 20
1Introduction
V1.2 Page of 22 ICP CD ST
D. Schnoor
06/98

Information and Communication
Communication Devices
This manual is inten e to help you carry out repairs on level 2.5, meaning limite
component repairs. Failure highlights are ocumente an shoul be repaire in the local
workshops.
The E10 an the S6 Power GSM are both han sets for GSM-900. Internally they are almost
i entical but the form factors of the boar s are ifferent.
Note: In some countries the S6 Power GSM is calle S6 Classic!
It must be note that all repairs have to be carrie out in an environment set up accor ing to
the ESD (Electrostatic Discharge Sensitive Devices) regulations efine in international
stan ar s.
If you have any questions regar ing the repair proce ures or spare parts o not hesitate to
contact our technical support team in Kamp-Lintfort, Germany:
Tel.: [phone]
Fax: [phone]
e-mail: ominik.sch[email protected]. e
VCXO
.1Affected Units
.1.1Type: E10 / S6 Power GSM
V1.2 Page 3 of 22 ICP CD ST
D. Schnoor
06/98

Information and Communication
Communication Devices
.1. Affected IMEIs / Date Codes: All / All
.1.3Affected SW-Versions: All
.1.4Fault Code for LSO reporting: 3VCX
. Fault Description
. .1Fault Symptoms for customers:
Network Search
Han set not logging into network
. . Fault Symptom on GSM-Tester:
Frequency error in synchronize mo e >90 Hz
No location up ate possible
The VCXO (Voltage Controlle Crystal Oscillator) is responsible for generating the
13 MHz reference frequency of the han set.
If it is efective, the han set cannot synchronize to the base station anymore.
.3Priority:
........ Man atory
........ Repair
........ Optional
........ Not Yet Define
.4Repair Documentation
.4.1Description of procedure:
.4.1.1Diagnosis
Check the output frequency of the VCXO using the level-2 testing
program for E10 / S6 Power GSM.
Switch off the „CMD in Use“ option in the S611.INI file an restart
V1.2 Page 4 of 22 ICP CD ST
D. Schnoor
06/98

Information and Communication
Communication Devices
the program. Start the test, when the program says „Check power an
phase of external antenna with your GSM-Tester“, switch the CMD to
„LOCAL“ mo e an enter the „MODULE TEST“.
On the CMD isplay you can see the frequency error of the han set.
(Make sure that the CMD is on channel 124, power level 5!)
If the frequency error is higher than 2kHz, the VCXO has to be
replace .
.4.1. Repair by component change
Use hot air blower to remove efective VCXO.
Avoi excessive heat!
Watch surroun ing components!
Resol er new VCXO afterwar s.
.4.1.3Repair by SW-Booting
Not possible!
.4.1.4Test
Retest han set after repair as escribe above.
The frequency error must now be < 2kHz.
.4. List of needed material
.4. .1Components
VCXO
Part-Number: L36145-G300-Y19
.4. . Jigs and Tools
Hot Air Blower
V1.2 Page 5 of 22 ICP CD ST
D. Schnoor
06/98

Information and Communication
Communication Devices
Sol ering Iron
.4. .3Special Tools
None
.4. .4Working materials
Desol er Wick / Brai
Sol er
V1.2 Page 6 of 22 ICP CD ST
D. Schnoor
06/98

Information and Communication
Communication Devices
.4.3Drawings
V1.2 Page 7 of 22 ICP CD ST
D. Schnoor
06/98
Figure 1: E10 / S6 Power GSM Board VCXO Side

Information and Communication
Communication Devices
3Fuse 1A
3.1Affected Units
3.1.1Type: E10 / S6 Power GSM
3.1. Affected IMEIs / Date Codes: All / All
3.1.3Affected SW-Versions: All
3.1.4Fault Code for LSO reporting: 3FU1
3. Fault Description
3. .1Fault Symptoms for customers:
Battery charging not possible
V1.2 Page 8 of 22 ICP CD ST
D. Schnoor
06/98
Figure : VCXO (Z601) Placement (Top View)

Information and Communication
Communication Devices
3. . Fault Symptom on GSM-Tester:
This fault cannot be etecte with a GSM-Tester
3.3Priority:
........ Man atory
........ Repair
........ Optional
........ Not Yet Define
3.4Repair Documentation
3.4.1Description of procedure:
3.4.1.1Diagnosis
Check the status of the fuse by measuring its resistance with
a multimeter. The fuse is efective if the resistance higher than 10
ohms.
3.4.1. Repair by component change
Use sol ering iron to remove efective fuse.
Avoi excessive heat!
Watch surroun ing components!
Resol er new fuse afterwar s.
3.4.1.3Repair by SW-Booting
Not possible!
V1.2 Page 9 of 22 ICP CD ST
D. Schnoor
06/98

Information and Communication
Communication Devices
3.4.1.4Test
Retest han set after repair as escribe above.
The resistance must now be close to zero.
3.4. List of needed material
3.4. .1Components
Fuse
Part-Number: L36145-A820-Y7
3.4. . Jigs and Tools
Sol ering Iron
3.4. .3Special Tools
Multimeter
3.4. .4Working materials
Desol er Wick / Brai
Sol er
V1.2 Page 10 of 22 ICP CD ST
D. Schnoor
06/98

Information and Communication
Communication Devices
3.4.3Drawings
V1.2 Page 11 of 22 ICP CD ST
D. Schnoor
06/98
Figure 1: E10 / S6 Power GSM Board 1A Fuse Side
Figure : 1A Fuse (F 01) Placement (Top View)

Information and Communication
Communication Devices
4Fuse 0. 5 A
4.1Affected Units
V1.2 Page 1 of 22 ICP CD ST
D. Schnoor
06/98

Information and Communication
Communication Devices
4.1.1Type: E10 / S6 Power GSM
4.1. Affected IMEIs / Date Codes: All / All
4.1.3Affected SW-Versions: All
4.1.4Fault Code for LSO reporting: 3FU2
4. Fault Description
4. .1Fault Symptoms for customers:
Supplying of external accessories through the han set’s
bottom connector is not possible
4. . Fault Symptom on GSM-Tester:
This fault cannot be etecte with a GSM-Tester
4.3Priority:
........ Man atory
........ Repair
........ Optional
........ Not Yet Define
4.4Repair Documentation
4.4.1Description of procedure:
4.4.1.1Diagnosis
Check the status of the fuse by measuring its resistance with
V1.2 Page 13 of 22 ICP CD ST
D. Schnoor
06/98

Information and Communication
Communication Devices
a multimeter. The fuse is efective if the resistance higher than 10
ohms
4.4.1. Repair by component change
Use sol ering iron to remove efective fuse.
Avoi excessive heat!
Watch surroun ing components!
Resol er new fuse afterwar s.
4.4.1.3Repair by SW-Booting
Not possible!
4.4.1.4Test
Retest han set after repair as escribe above.
The resistance must now be close to zero.
4.4. List of needed material
4.4. .1Components
Fuse
Part-Number: L36145-A820-Y10
4.4. . Jigs and Tools
Sol ering Iron
4.4. .3Special Tools
Multimeter
4.4. .4Working materials
Desol er Wick / Brai
Sol er
4.4.3Drawings
V1.2 Page 14 of 22 ICP CD ST
D. Schnoor
06/98

Information and Communication
Communication Devices
V1.2 Page 15 of 22 ICP CD ST
D. Schnoor
06/98
Figure 1: E10 / S6 Power GSM 0. 5A Fuse Side
Figure : E10 / S6 Power GSM 0. 5A Fuse Placement

Information and Communication
Communication Devices
5Molex Connector
5.1Affected Units
5.1.1Type: E10 / S6 Power GSM
5.1. Affected IMEIs / Date Codes: All / All
5.1.3Affected SW-Versions: All
5.1.4 Fault Code for LSO reporting: 3MOC
5. Fault Description
V1.2 Page 16 of 22 ICP CD ST
D. Schnoor
06/98

Information and Communication
Communication Devices
5. .1Fault Symptoms for customers:
Network search.
Charging or operation in a car kit not possible.
5. . Fault Symptom on GSM-Tester:
Output power problems on the external an internal
antenna.
No location up ate possible.
5.3Priority:
........ Man atory
........ Repair
........ Optional
........ Not Yet Define
5.4Repair Documentation
5.4.1Description of procedure:
5.4.1.1Diagnosis
Visually check the bottom connector. Watch for ry joints.
5.4.1. Repair by component change
Use hot air blower to remove efective connector.
Avoi excessive heat!
Watch surroun ing components!
Resol er new connector afterwar s.
Make sure that you use just very little flux, otherwise the connector
contacts can become irty.
5.4.1.3Repair by SW-Booting
Not possible!
V1.2 Page 17 of 22 ICP CD ST
D. Schnoor
06/98

Information and Communication
Communication Devices
5.4.1.4Test
Retest han set after repair.
5.4. List of needed material
5.4. .1Components
Molex Connector
Part-Number: L36851-Z1351-A70
5.4. . Jigs and Tools
Hot Air Blower
Sol ering Iron
5.4. .3Special Tools
None
5.4. .4Working materials
Desol er Wick / Brai
Sol er
Flux
V1.2 Page 18 of 22 ICP CD ST
D. Schnoor
06/98

Information and Communication
Communication Devices
5.4.3Drawings
V1.2 Page 19 of 22 ICP CD ST
D. Schnoor
06/98
Figure 1: E10 / S6 Power GSM Board Bottom Connector Side
Figure : Bottom Connector Placement (Top View)

Information and Communication
Communication Devices
6Ringer
6.1Affected Units
6.1.1Type: E10 / S6 Classic MMI
6.1. Affected IMEIs / Date Codes: All / All
6.1.3Affected SW-Versions: All
6.1.4Fault Code for LSO reporting: 3RIN
6. Fault Description
6. .1Fault Symptoms for customers:
No ringer tone au ible or ringer tone istorte .
6. . Fault Symptom on GSM-Tester:
Ringer check fails.
6.3Priority:
