Siemens A71 User manual

right page (1) of A71 FCC, LAM en (19.08.2005, 11:40)

Table of Contents 1

VAR Language: en2; VAR issue date: 050331

Legal notices .......................................2

Safety precautions ..............................4

Antenna care ...................................5

Phone operation ..............................5

Electronic devices ............................6

Overview of the phone .......................9

Getting started .................................10

Using the SIM card/battery .............10

Charge battery ...............................11

Switch on/off, PIN entry ....................11

User guide .....................................11

Security .............................................11

Clear SIM card barring ....................12

Prevent accidental activation ..........12

Making a phone call .........................12

Phonebook ........................................13

New entry ......................................13

Text entry ......................................13

Call/search for an entry ..................14

Call with record no. ........................14

Edit entry .......................................14

Groups ...........................................14

Messages (SMS) ................................15

Read messages ..............................15

Inbox/Outbox .................................15

Compose a message ......................15

Setup ................................................15

Profiles ..........................................15

Display ...........................................16

Screensaver ...................................16

Call setup .......................................16

Clock .............................................16

Security .........................................16

Network .........................................17

Ring tones .........................................17

Alarm clock ...................................... 18

Fast access key ................................. 18

Customer Care ................................. 19

Product data ..................................... 20

Care and maintenance ..................... 21

Accessories ....................................... 22

SAR ................................................. 23

U.S. FDA ........................................... 24

FCC/Industry Canada Notice ............ 28

Ten Driving Safety Tips .................... 29

Intellectual property ........................ 31

End user license agreement ............ 32

Table of

Contents

left page (2) of A71 FCC, LAM en, (19.08.2005, 11:40)

Legal notices

VAR Language: en2; VAR issue date: 050331

Legal notices

The mobile phone described in this guide is approved for use on the GSM and GPRS net-

works operating on the GSM 850, 1800 (DCS/PCN) and 1900 (PCS) bands. It is approved

for use in the country where it was originally sold and may be approved for use in other

countries.

Siemens and the A71 model phone are

trademarks or registered trademarks of

Siemens AG and/or its affiliates in the

United States and/or other countries.

T9® is a registered trademark of America

Online, Inc. in the United States. Java and

all Java-based trademarks and logos are

trademarks or registered trademarks of Sun

Microsystems, Inc. in the U.S and other

countries. The names of actual companies

and products mentioned herein may be the

trademarks of their respective owners.

Disclaimer

The information contained in the User

Guide is written for the A71 phone.

Siemens reserves the right to make changes

and improvements to the products and any

of the features of the products described in

this document without prior notice. The

contents of the user guide are provided "AS

IS". Except as required by applicable law, no

warranties of any kind, either express or im-

plied, including, but not limited to, the im-

plied warranties of merchantability and fit-

ness for a particular purpose, are made in

relation to the accuracy, reliability or con-

tents of this document. Siemens reserves

the right to revise the user guide or with-

draw it at any time without prior notice. Un-

der no circumstances shall Siemens be re-

sponsible for any loss of data or income or

any special, incidental, consequential or in-

direct damages howsoever caused.

Export Information

The mobile phone may be subject to export

regulation of the United States and other

countries. Diversion contrary to law is pro-

hibited. You must comply with all applica-

ble export laws, restrictions and regulations

of the United States foreign agencies or au-

thorities, and may not export, or transfer

for the purpose of re-export, the mobile

phone or any part of the phone in violation

of any applicable restrictions, laws or regu-

lations, or without all necessary approvals.

Network Services

A number of features included in this

guide are called Network Services. They

are special services provided by wireless

service providers. In order to use any of

these Network Services, you must sub-

scribe to these service(s) from your ser-

vice provider and obtain instructions for

their use. Some of these Network Servic-

es may not be available when roaming on

a network other than your home network.

Standby and

Talk Time Information

The mobile phone incorporates features

that are new to the mobile phone world.

These may include color displays and

lighting, graphic games, music reproduc-

tion and browsing the Internet. The way

you use the display and the features will

affect the performance of the battery and

how long it lasts between charge cycles.

The quoted standby times and talk times

show the minimum and maximum per-

formance that can be expected from the

right page (3) of A71 FCC, LAM en, (19.08.2005, 11:40)

Legal notices

VAR Language: en2; VAR issue date: 050331

battery under normal network conditions

and with the default settings as set by the

factory. However, playing games (particu-

larly with the backlight continuously

switched on) and listening to music will

shorten the time available for standby

and to make and receive telephone calls.

Operation times also vary depending on

network conditions, SIM settings, charg-

ing and battery condition, how you use

your phone and other factors.

Memory

The mobile phone contains an internal

memory device that stores the software

required to operate the mobile phone,

communicate with the GSM/GPRS net-

work and provide the user interface.

Some features in the internal memory

run additional devices and some addition-

al games and utilities. The amount of

memory available in the mobile phone is

finite and may be insufficient to store

large numbers of applications and files.

Warning!

Remember to back up your data and to do so fre-

quently. Always back up all data and programs

before sending the mobile phone in for repair.

left page (4) of A71 FCC, LAM en, (23.08.2005, 08:53)

Safety precautions

VAR Language: en2; VAR issue date: 050331

Safety precautions

Information for parents

Please read the operating instructions and safety precautions carefully before use.

Explain the content and the hazards associated with using the phone to your children.

Remember to comply with legal re-

quirements and local restrictions

when using the phone. For example

in aeroplanes, petrol stations, hos-

pitals or while driving.

Mobile phones can interfere with

the functioning of medical devices

such as hearing aids or pacemak-

ers. Keep at least 20 cm/9 inches

between phone and pacemaker.

When using the mobile phone hold

it to the ear which is further away

from the pacemaker. For more

information consult your doctor.

The ringtones (p. 17), message to-

nes (p. 17) and handsfree talking

are reproduced through the loud-

speaker. Do not hold the phone to

your ear when it rings or when you

have switched on the handsfree

function (p. 12). Otherwise you risk

serious permanent damage to your

hearing.

Only use original Siemens batteries

(100 % mercury-free) and – charg-

ing devices. Otherwise you risk seri-

ous damage to health and property.

The battery could explode, for in-

stance.

Small parts such as the SIM card,

sealing stop, lens ring and lens cap

can be dismantled and swallowed

by small children. The phone must

therefore be stored out of the reach

of small children.

The mains voltage specified on the

power supply unit (V) must not be

exceeded. Otherwise the charging

device may be destroyed.

The power supply must be plugged

into an easily accessible AC mains

power socket when charging the

battery. The only way to turn off the

charging device after charging the

battery is to unplug it.

Do not use a handheld while

driving.

Do not place the phone near to elec-

tromagnetic data carriers such as

credit cards and floppy disks. Infor-

mation stored on them could be lost.

You may only open the phone to re-

place the battery (100 % mercury-

free) or SIM card. You must not

open the battery under any circum-

stances. All other changes to this

device are strictly prohibited and will

invalidate the guarantee.

right page (5) of A71 FCC, LAM en, (23.08.2005, 08:53)

Safety precautions

VAR Language: en2; VAR issue date: 050331

Antenna care

Use only the supplied or an approved re-

placement antenna. Unauthorized anten-

nas, modifications, or attachments could

damage the phone and may violate FCC

regulations.

Phone operation

Normal position

Hold the phone as you would any other

telephone with the antenna pointed up

and over your shoulder.

Tips on efficient operation

For your phone to operate most

efficiently:

• Extend your antenna fully

(if applicable).

• Do not touch the antenna unnecessari-

ly when the phone is in use. Contact

with the antenna affects call quality

and may cause the phone to operate at

a higher power level than otherwise

needed.

Important:

Please dispose of unwanted batter-

ies and phones as permitted by the

laws in your country.

The phone may cause interference

in the vicinity of TV sets, radios and

PCs.

Use only Siemens original accesso-

ries. This will avoid potential risks to

health or property and ensure com-

pliance with all relevant regulations.

Improper use will invalidate the guarantee!

These safety instructions also apply to Siemens

original accessories.

Product attributes are subject to changes in tech-

nology, design and availability. Siemens reserves

the right to modify products without prior notice.

This cellular phone offers a range of functions, it

can be used in positions other than the head, such

as on the body. In this case, separation distance

of 1.0 cm is required. When a carry case, belt clip

or holder is used for body-worn operation, it

should not contain metal and should position the

device the above-stated distance from your body.

Important

Read this information before using your

wireless handheld phone.

As this mobile phone is equipped with a

fixed (non-retractable) antenna, some

paragraphs in the text below may not be

applicable.

left page (6) of A71 FCC, LAM en, (23.08.2005, 08:53)

Safety precautions

VAR Language: en2; VAR issue date: 050331

Driving

Laws pertaining to the use of mobile

phones while driving vary significantly from

state to state and sometimes even from lo-

cality to locality within states. For example,

some areas may allow persons to use their

mobile phones only if they employ a hands-

free device, and some areas may prohibit

the use of cell phones entirely. Accordingly,

Siemens recommends that persons check

the laws for the areas in which they drive or

will be driving. For areas where the use of

mobile phones while driving is permitted,

Siemens encourages persons to use their

phones responsibly and to employ hands-

free devices. Also, if using your phone while

driving, please:

• Give full attention to driving – driving

safely is your first responsibility;

• Use hands-free operation, if available;

• Pull off the road and park before mak-

ing or answering a call, if driving condi-

tions so require.

For vehicles equipped with air bags

An air bag inflates with great force. DO NOT

place objects, including either installed or

portable wireless equipment, in the area

over the air bag or in the air bag deploy-

ment area. If in-vehicle wireless equipment

is improperly installed and the air bag in-

flates, serious injury could result.

Electronic devices

Most modern electronic equipment is

shielded from radio frequency (RF) sig-

nals. However, certain electronic equip-

ment may not be shielded against the RF

signals from your wireless phone.

Pacemakers

The Health Industry Manufacturers' Associ-

ation recommends that a minimum separa-

tion of six inches (6") be maintained be-

tween a handheld wireless phone and a

pacemaker to avoid potential interference

with the pacemaker. These recommenda-

tions are consistent with the independent

research by and recommendations of Wire-

less Technology Research.

Persons with pacemakers

• should ALWAYS keep the phone more

than six inches from their pacemaker

when the phone is turned ON;

• should not carry the phone in a breast

pocket;

• should use the ear opposite the pace-

maker to minimize the potential for in-

terference;

• should turn the phone OFF immediate-

ly if there is any reason to suspect that

interference is taking place.

Hearing aids

Some digital wireless phones may

interfere with some hearing aids. In the

event of such interference, you may want

to consult your service provider or your

hearing aid manufacturer to discuss alter-

natives.

Other medical devices

If you use any other personal medical de-

vices, consult the manufacturers of your

devices to determine if they are ade-

quately shielded from external RF energy.

Your physician may be able to assist you

in obtaining this information.

Turn your phone OFF in health care facili-

ties when any regulations posted in these

areas instruct you to do so. Hospitals or

health care facilities may be using equip-

ment that could be sensitive to external

RF energy.

right page (7) of A71 FCC, LAM en, (23.08.2005, 08:53)

Safety precautions

VAR Language: en2; VAR issue date: 050331

Vehicles

RF signals may affect improperly installed

or inadequately shielded electronic sys-

tems in motor vehicles. Check with the

manufacturer or its representative regard-

ing your vehicle. You should also consult

the manufacturer of any equipment that

has been added to your vehicle.

Posted facilities

Turn your phone OFF in any facility where

posted notices so require.

Airplanes

FCC and Airline Regulations prohibit using

your phone while in the air. Turn your

phone OFF when requested by the airline.

Check and comply with the policy of your

airline regarding the use of your phone

while the airplane is on the ground.

Blasting areas

To avoid interfering with blasting opera-

tions, turn your phone OFF when in a

“blasting area” or in areas posted: “Turn

off two-way radio.” Obey all signs and in-

structions.

Potentially explosive atmospheres

Turn your phone OFF when in any area with

a potentially explosive atmosphere and

obey all signs and instructions. Sparks in

such areas could cause an explosion or fire

resulting in bodily injury or even death.

Areas with a potentially explosive atmo-

sphere are often but not always clearly

marked. They include: fueling areas such

as gasoline stations; below deck on boats;

fuel or chemical transfer or storage facili-

ties; vehicles using liquefied petroleum

gas (such as propane or butane); areas

where the air contains chemicals or parti-

cles, such as grain, dust or metal pow-

ders; and any other area where you

would normally be advised to turn off

your vehicle engine.

Emergency calls (SOS)

Your wireless phone can be used to make

emergency calls. You can make an emer-

gency call from the main display screen.

Enter the local emergency number such

as 911 and then press the Akey.

This phone, like any wireless phone, oper-

ates using radio signals, wireless and

landline networks, and user-pro-

grammed functions. Because of this, con-

nections in all conditions cannot be guar-

anteed. Therefore, you should never rely

solely on any wireless phone for essential

communications (for example, medical

emergencies). Remember – to make or

receive any calls, the phone must be

switched on and be used in a service area

that has adequate signal strength. Emer-

gency calls might not be possible on all

wireless phone networks or when certain

network services or phone features are in

use. Check with local service providers re-

garding their network features.

Always make certain that your phone is

properly charged before attempting any

emergency calls. If you allow your battery

to discharge, you will be unable to receive

or make calls, including emergency calls.

You must then wait a few minutes after

the charging begins to place any

emergency calls.

When making an emergency call,

remember to give all of the necessary in-

formation as accurately as possible. Re-

member that your wireless phone might

be the only means of communication at

the scene of an accident, therefore you

should not terminate the call until given

permission to do so.

left page (8) of A71 FCC, LAM en, (23.08.2005, 08:53)

Safety precautions

VAR Language: en2; VAR issue date: 050331

Batteries and Chargers

Only use original Siemens batteries

(100% mercury-free) and charging

devices. Use of non-Siemens batteries

and/or charging devices may cause explo-

sion resulting in serious injury and/or

property damage. Use original Siemens

accessories in order to avoid possible

injury and property damage and to

ensure compliance with applicable laws

and regulations. Improper use invalidates

the warranty.

Battery safety precautions

To reduce the risk of fire, injury or electric

shock, and to properly dispose of batter-

ies, please read and understand the fol-

lowing instructions. CONTAINS LITHIUM-

ION OR NICKEL-METAL HYDRIDE BATTERY.

BATTERY MUST BE RECYCLED OR DIS-

POSED OF PROPERLY. DO NOT DISPOSE IN

MUNICIPAL WASTE.

1. Only use the batteries specified for use

with this mobile phone.

2. Do not use batteries of different sizes

or from different manufacturers in this

mobile phone.

3. Do not dispose of the battery in a fire; it

may explode. Dispose of used batteries

and phones in accordance with applica-

ble laws and safety regulations. Do not

expose battery to water. Check with

local codes for special disposal

instructions.

4. Do not open or mutilate the battery.

Doing so may cause damage to the

eyes or skin.

5. Exercise care in handling the battery in

order not to short the battery with con-

ducting materials such as rings, brace-

lets, and keys. The battery or conduct-

ing material may overheat and cause

burns or fire.

6. Charge the battery provided with, or

identified for use with, this product

only in accordance with the instruc-

tions and limitations specified in the

User's Guide. Do not attempt to charge

the battery by any means other than

those specified in the User's Guide.

right page (9) of A71 FCC, LAM en, A31008-H2710-A43-1-4A19 (19.08.2005, 11:40)

Overview of the phone

VAR Language: en2; VAR issue date: 050331

Overview of the phone

1Display indicators

Signal strength and battery level.

2Soft keys

Press the soft key to call up the function

that is displayed as §Text§ or icon on the

grey fields above the key.

3ACall key

Dial displayed phone number or name,

accept calls. In standby mode: Display the

last calls.

4BOn/Off/End key

• Switched off: press and hold to

switch on.

• During a conversation or in an

application: press briefly to finish.

• In menus: press briefly to go back a

level. Press and hold to return to

standby mode.

• In standby mode: press and hold to

switch off phone.

5 Control key

• In standby mode:

FOpen Phonebook.

•During conversation:

EStart adjusting the volume then set

volume withG.

6*Press and hold

• In standby mode: switch on/off all sig-

nal tones (except alarm).

• For incoming calls: only switch off ring

tones.

7Press and hold

In standby mode: switch key lock on/off.

_ g

Service provider

17.06.2005 09:15

NewSMS Menu

left page (10) of A71 FCC, LAM en, A31008-H2710-A43-1-4A19 (23.08.2005, 08:52)

Getting started

VAR Language: en2; VAR issue date: 050331

Getting started

Using the SIM card/battery

Your phone's display is delivered with a

protective film. Remove this film before get-

ting started. The service provider supplies

you with a SIM card on which all the im-

portant data for your account is stored. If

the SIM card is credit card-sized, snap out

the smaller segment and trim any rough

edges.

Remove the battery cover upwards 1.

Insert SIM card 2and push it fully into

the locating slot (make sure the angled

corner is in the correct position 3). Then

push the retaining catch over the top of

the SIM card 4.

Insert the battery sideways into the

phone 5, then press downwards 6

until it engages.

To remove, press the retaining tab 7

then lift the battery out.

Insert the battery cover by the tabs at the

bottom 8, then press downwards 9,

until it engages.

Always switch off phone before removing

the battery!

Only 3V SIM cards are supported. Please

contact your service provider if you have

an older card.

right page (11) of A71 FCC, LAM en, A31008-H2710-A43-1-4A19 (23.08.2005, 08:52)

Switch on/off, PIN entry

VAR Language: en2; VAR issue date: 050331

Charge battery

The battery is not fully charged when de-

livered. Plug in the charger cable at the

bottom of the phone, plug in the power

supply unit to the mains power socket

and charge for at least two hours.

Charging time

The charging time is 2 hours. Ambient

temperature of 5 °C to 40 °C (icon flashes

as a warning when 5 °C above/below this).

Switch on/off, PIN entry

Switch on/off

Press and hold On/Off/End keyBto

switch on or off.

Enter PIN

The SIM card can be protected with a

4 - 8 digit PIN. Enter the PIN code using

the number keys (the display shows a se-

ries of asterisks) If you make a mistake

press §Clear§. Confirm your input with §OK§.

Logging on to the network will take a few

seconds.

First time switching on phone, the time

and date must be set.

Standby mode

When the name of the service provider/

logo appears on the display, the phone is

in standby mode and ready for use.

Press and hold the On/Off/End keyBto

return to standby mode from any menu

option.

User guide

The following symbols are used to explain

operation:

JEnter numbers or letters.

BOn/Off/End key.

ACall key.

DPress the control ley on the side

indicated.

§Menu§ Displays a soft-key function.

LFunction depends on the service

provider, special registration

may be necessary.

Security

The phone and SIM card are protected

against misuse by several security codes.

Keep these confidential numbers in a safe

place where you can access them again if

required.

§Menu§ ¢Setup ¢Security ¢Codes

¢Select a function.

PIN control

The PIN is usually requested each time

the phone is switched on. You can deacti-

vate this feature but you risk unauthor-

ised use of the phone. Some service pro-

viders do not permit deactivation of the

control.

Change PIN

You can change the PIN to any 4 - 8 digit

number you may find easier to remember.

Change PIN2

(Displayed only if PIN2 is available.)

Proceed as with Change PIN.

left page (12) of A71 FCC, LAM en, A31008-H2710-A43-1-4A19 (23.08.2005, 08:52)

Making a phone call

VAR Language: en2; VAR issue date: 050331

Change phonecode

You define and enter the phone code

(4 - 8 digits) when calling a phone code

protected function (e.g. Direct call, p. 13)

for the first time. It is then valid for all

protected functions. If it is entered incor-

rectly three times the phone is locked.

Contact the Siemens Service.

Clear SIM card barring

If the PIN is entered incorrectly three

times, the SIM card is barred. Enter the

PUK (MASTER PIN) provided by your serv-

ice provider with the SIM card. If the PUK

(MASTER PIN) has been lost, please con-

tact your service provider.

Prevent accidental activation

Even if PIN use is deactivated (p. 11) con-

firmation is required to switch on the

phone.

This prevents accidental activation of the

phone, e.g. when you are carrying it in a

bag or when you are travelling in an

aircraft.

After pressing and holding the On/Off/End

keyBselect §OK§ to switch on the phone

or abort the operation with §Cancel§.

Making a phone call

Dialling with number keys

The phone must be switched on (standby

mode). Enter the number (always with

prefix, if necessary with the international

dialling code). Press §Clear§ to clear the last

digit, press and hold to clear the entire

phone number. To dial press theAkey.

End call

Press the End keyBbriefly. Press this key

even if the person on the other end of the

line has hung up first.

Set volume

Use the scroll keyEto start adjusting

the volume during conversation. Set vol-

ume withG.

Redial previous numbers

To redial the phone number last called,

press the Call keyAtwice. To redial other

numbers that were dialled previously,

pick out the required phone number from

the list withG, then pressAto dial.

When a number is busy

For automatically dialling the phone

number for up to 15 minutes at increas-

ing intervals, press §Auto dial§. For phone

ringing when the busy number is free,

press §Call back§ (L). Press §Prompt§ and a

beep will remind you to redial the dis-

payed phone number after 15 minutes.

Accept call

The phone must be switched on (standby

mode). An incoming call will interrupt

any other use of the phone.

Press §Answer§ orA.

If the phone number has been transmitted

by the network, it is displayed. If the number

and the name are stored in the Phonebook,

the corresponding name is displayed in-

stead. If set, an animation can be dis-

played instead of the bell icon.

Reject call

§Reject§ or Bpress briefly.

Held call

Make a new connection during a call with

ymenu§ ¢Hold ¢J(dial new phone

number, also from Phonebook:F). With

§Swap§ you can swap back and forth be-

tween both calls.

Additional costs will be incurred for the

2nd phone connection.

right page (13) of A71 FCC, LAM en, A31008-H2710-A43-1-4A19 (23.08.2005, 08:52)

Phonebook

VAR Language: en2; VAR issue date: 050331

Conference b

Make a new connection during a call with

ymenu§ ¢Hold ¢J(dial a new phone

number).

With ymenu§ ¢Conference you can join

the held call. Repeat this procedure until

all participants are linked together (up to

5participants).

All calls in the conference are ended si-

multaneously when the End keyBis

pressed.

Additional costs will be incurred for

every additional phone connection.

Call menu

Several functions are only available dur-

ing a call:

ymenu§ ¢Select a function.

Direct call

The phone can be locked, so it's only pos-

sible to dial a defined number.

Switch on

§Menu§ ¢Setup ¢Security ¢Direct call

Press §Select§ and enter phone code. When

first prompted you define and enter the

phone code (4 - 8 digits). Please do not for-

get this code! Confirm input with §OK§ and

press §Change§. Select phone number from

the Phonebook (p. 13) or enter a new

one. With §OK§ confirm On.

Use

Press and hold the right soft key>to

dial.

Switch off

Press and hold and enter phone code.

Confirm input with §OK§ and press §Change§.

With §OK§ confirm Off.

Phonebook

New entry

Open Phonebook (in standby mode)

F(select <New entry>) ¢§Select§

¢Activate input fields.

Number: Always enter phone number with

an area dialling code.

Name: Enter first name or surname.

Group: Organise entries in groups, select

with §Change§.

Location: Select location: SIM, Mobile or

Protected SIM.

Record no.: This is automatically assigned

to the entry. Change with §Change§.

Press §Save§ to store the new entry.

Text entry

Press number key repeatedly until the re-

quired letter appears. The cursor advanc-

es after a short delay. Example:

2Press once for a, twice for b etc.

Press and hold to write the

number.

Ä, ä, 1–9 Umlauts and numbers are dis-

played after the relevant letters.

§Clear§ Press briefly to delete the letter

before the cursor, press and hold

to delete the whole word.

GMove the cursor (forwards/back).

Press briefly: Switch between:

abc, Abc, ABC, T9abc, T9Abc,

T9ABC, 123. Status indicator in

the top line of the display.

Press and hold: All input modes

are displayed.

*Press briefly: Select special

characters. Press and hold:

Open input menu.

left page (14) of A71 FCC, LAM en, A31008-H2710-A43-1-4A19 (23.08.2005, 08:52)

Phonebook

VAR Language: en2; VAR issue date: 050331

0Press once/repeatedly:

. , ? ! ’ " 0 - ( ) @ / : _ + ~ &

Press and hold: Writes 0.

1Writes blank. Press twice =

skip line.

Call/search for an entry

Open PhonebookF, select name by typ-

ing first letter or scroll and dial withA.

Call with record no.

A record number is automatically assigned

to every new entry in the Phonebook.

JEnter record number (in standby

mode) ¢¢A

Edit entry

G¢Select entry ¢§Options§ ¢Edit

¢G(select required input field)

¢Make changes ¢§Save§

Location:

An entry can be moved to different stor-

age locations in the Phonebook.

SIM (standard) ¢

Entries that are stored in the Phonebook

on the SIM card can also be used on a dif-

ferent GSM phone.

Mobile v

Phonebook entries are stored in the

memory of the mobile phone when the

memory of the SIM card is full.

Protected SIM ¡b

Phone numbers can be stored in protect-

ed locations on a special SIM card. A PIN2

is needed for editing (p. 11).

Groups

If there are many Phonebook entries it is

best to assign them to a group, e.g.:

Family, Friends, VIP, Others

A special ring tone can sound and/or a sym-

bol can be displayed if the phone number

of a call is registered in a group.

Select a group

§Menu§ ¢Phonebook ¢<Groups>

¢G(select a group) ¢§View§

All entries of the selected group are

displayed.

Change group assignment

You can assign a Phonebook entry to a

group when you enter it (p. 13).

F¢Select entry ¢§View§ ¢§Edit§

¢G(scroll to group) ¢§Change§

¢Select a new goup ¢§Save§

SMS to group

A memo (SMS) can be sent as a "circular"

to all members of a group. Each SMS is

charged separately!

Open <Groups> in Phonebook menu and

scroll to a group.

§Options§ ¢SMS to group ¢§Select§

¢Compose message ¢A(the group

is displayed) ¢§OK§ ¢A

The SMS is sent to the first recipient.

Press Aagain to start the next send op-

eration. Each send operation must be

confirmed. Individual recipients may be

skipped.

Call to group b

You can call up to 5 group members one

by one and link them together in a con-

ference (function may need to be enabled

by the service provider).

Open <Groups> in Phonebook menu and

scroll to a group.

§Select§ ¢Select the entries ¢§Change§

(mark/unmark entry) ¢§OK§

The first entry is dialled and the call is put

on hold. ProceedAby calling the next

entry until all marked entries are called.

With §Options§ you can link the calls on

hold in a conference.

right page (15) of A71 FCC, LAM en, A31008-H2710-A43-1-4A19 (23.08.2005, 08:52)

Messages (SMS)

VAR Language: en2; VAR issue date: 050331

Group call tones

You can assign different ringtones to

groups.

§Menu§ ¢Ring tones ¢Group calls

¢Select a group ¢§Select§

¢Select ring tone ¢§Select§

Messages (SMS)

Read messages

A new message is indicated on the display

with ]. Press the control key on the left

to read the message. Scroll through the

message line by line withG.

Reply menu

§Reply§ Open the reply menu.

Inbox/Outbox

§Menu§ ¢Messages ¢Inbox or Outbox

The list of saved messages is shown.

Compose a message

§Menu§ ¢Messages ¢New SMS

¢Write text ¢A

¢J/ Q(enter phone number or

select from Phonebook) ¢§OK§

The SMS is sent to the service centre for

transmission.

Text menu

§Options§ Open the text menu.

Write text fragments

§Menu§ ¢Messages ¢Predef. texts

¢<New entry> ¢J(write text

fragment) ¢§Save§

Use text fragments

J(write message text) ¢§Options§

¢Insert text ¢G(select text

fragment from the list) ¢§Select§

The text fragment is inserted into the text

to the left of the cursor.

Text entry with T9

T9 deduces the correct word from the in-

dividual key entries by making compari-

sons with an extensive dictionary. Write a

word and finish it without looking at the

display. Simply press the keys where the

relevant letter is located once. If several

options are found in the dictionary the

most probably is displayed first. For fur-

ther options please press the right

softkey.

Setup

§Menu§ ¢Setup ¢Select a function.

Profiles

Three profiles are standard with default

settings, they can be changed however:

Normal envi., Quiet environ., Noisy environ.

You can set two personal profiles

(<No Title>).

The special profile Aircraft mode cannot be

changed.

Activate

Select default profile or personal profile

¢§Select§.

Change setting

Select profile ¢§Options§ ¢Change sett.

The list of available functions is displayed.

T9® Text Input is licensed under one or more

of the following:

U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480,

5,945,928 and 6,011,554;

Canadian Pat. No. 1,331,057;

United Kingdom Pat. No. 2238414B;

Hong Kong Standard Pat. No. HK0940329;

Republic of Singapore Pat. No. 51383;

Euro.Pat. No. 0 842 463 (96927260.8)

DE/DK, FI, FR, IT, NL, PT, ES, SE, GB;

and additional patents are pending worldwide.

left page (16) of A71 FCC, LAM en, A31008-H2710-A43-1-4A19 (23.08.2005, 08:52)

Setup

VAR Language: en2; VAR issue date: 050331

Aircraft mode

The phone will automatically switch off if

you select this profile. Even the alarm

tone is deactivated. It is not possible to

modify this profile.

Normal operation

The next time you switch on the phone

and return to normal operation the de-

fault profile will be activated.

Display

Language

Set the language of the display text.

"Automatic" will set the language of your

home service provider. Reset to this lan-

guage in standby status:

*# 0 0 0 0 # A

Screensaver

The screensaver shows a picture on the

display as soon as a period that can be set

by you has elapsed. The function is ended

by an incoming call or by pressing any key.

Call setup

Hide ID b

When switched off, the display of the call-

ing party shows your phone number (de-

pendent on service provider). To suppress

this display, you can activate the "Hide ID"

mode.

Call waiting b

If you are registered for this service, you

can check whether it is set and you can

activate/deactivate it with Call waiting.

Minute beep

During the call, you will hear a beep after

each minute as a reminder of the time

elapsed.

Divert

You can set the conditions for which calls

are diverted to your mailbox or other

numbers.

Set up call divert (example)

All calls b

All calls are diverted. nis shown in the

top line of the display in standby mode.

Unanswered calls b

Includes Unanswered, Not reachable,

No reply, Busy.

§Select§ ¢Set ¢J(Enter the phone

number to which the call should be

diverted) ¢§OK§

After a short pause, the setting is con-

firmed by the network.

Status check

After a short pause the current informa-

tion is shown.

pCondition set.

oNot set.

Display, if status is unknown

(e.g. on a new SIM card).

Clear all b

All set diversions are cleared.

Clock

§Menu§ ¢Setup ¢Clock

¢Select a function.

Security

§Menu§ ¢Setup ¢Security

¢Select a function.

Auto key lock

The keypad is locked automatically if no

key has been pressed for one minute in

standby mode. This prevents the phone

from being used accidentally. However,

you can still be called and you can still

make an emergency call.

Direct call

Only one phone number can be dialled.

Press and hold control key on the right

(p. 13).

right page (17) of A71 FCC, LAM en, A31008-H2710-A43-1-4A19 (23.08.2005, 08:52)

Ring tones

VAR Language: en2; VAR issue date: 050331

This SIM only b

Your phone is prevented from being used

with a different SIM card.

Barrings b

Network barring restricts the use of your

SIM card.

All outgoing: All outgoing calls except

emergency numbers are barred.

Outgo internat: Only national calls can be

made.

Outgo internat. x home barred: International

calls are not permitted, except for calls to

your home country.

All incoming calls: The phone is blocked

from receiving all incoming calls.

When roaming: You do not receive any calls

outside your home network.

Status check: Query the status of your

barrings.

Clear all: Clear all barrings. Password

protected!

Phone identity

The phone identity number (IMEI) is

displayed.

Factory settings

The phone is reset to the default values

(does not apply to SIM card and network

settings).

Alternative input in standby mode:

*# 9 9 9 9 # A

Network

§Menu§ ¢Setup ¢Network

¢Select a function.

Network info

The list of GSM networks currently availa-

ble is displayed.

Auto network selection

If activated, the next network is dialled in

the order of your "preferred networks".

Choose network

The network search is restarted.

Preferred network

Set the service providers you prefer when

you leave your home network.

Fast search

Speed up network reconnection.

Ring tones

§Menu§ ¢Ring tones ¢Select a function.

Set the tones to match your needs.

Ringer setting

Activate/deactivate the ring tone or re-

duce it to a short beep.

Volume

Set the same volume for all ring tones.

GSet volume.

§OK§ Confirm.

dCalls, Group tones, Other calls,

Alarm clock, Message tone

The ring tones for the stated types of

call/functions can be set separately.

More tones...

Call screening b

Only calls from numbers that are in the

Phonebook or in a predefined group are

signalled audibly or by silent alert. Other

calls are only displayed.

Key tones

Set acoustic key acknowledge:

Click or Tone or Silent

Minute beep

During the call, you will hear a beep once

a minute as a reminder.

Information tones

Set service and alarm tones.

left page (18) of A71 FCC, LAM en, A31008-H2710-A43-1-4A19 (23.08.2005, 08:52)

Alarm clock

VAR Language: en2; VAR issue date: 050331

Alarm clock

Activate/deactivate

§Menu§ ¢Alarm clock

The alarm will ring at the time set by you,

even when the phone is switched off.

§On§/§Off§ Activate/deactivate the alarm.

Setting

Set time for alarm call (hh:mm), then §OK§.

Fast access key

Left soft key

You can assign an important phone

number or function to the left soft key.

For example, Games is assigned to the

softkey. To change this (in standby

mode):

§Games§ Press briefly ¢§Change§

¢Gscroll to the application or Phone

number (select a name from the

Phonebook)¢§Select§ Confirm.

Apply (in standby mode) e.g.:

§Games§ Press and hold.

Speed dialling keys (2 to 9)

You can assign a phone number or func-

tion to each of the keys from 2 to 9

(speed dialling numbers). Number key 1

is reserved for the mailbox.

Set (in standby mode)

J(Key 2-9) ¢Gscroll to the

application or Phone number (select a

name from the Phonebook)¢§Select§

Confirm.

Apply (in standby mode) e.g.:

2Press and hold.

right page (19) of A71 FCC, LAM en, A31008-H2710-A43-1-4A19 (23.08.2005, 08:52)

Customer Care

VAR Language: en2; VAR issue date: 050331

Customer Care

Qualified Siemens employees are waiting

to offer you expert information about our

products and installation.

In some countries repair and replace serv-

ices are impossible where the products

are not sold through our authorised

dealers.

If repair work is necessary, please contact

one of our service centres:

Abu Dhabi .........................................0 26 42 38 00

Argentina .....................................0 80 08 88 98 78

Australia..........................................13 00 66 53 66

Austria.............................................05 17 07 50 04

Bahrain .................................................... 40 42 34

Bangladesh.......................................0 17 52 74 47

Belgium.............................................0 78 15 22 21

Bolivia ...............................................0 21 21 41 14

Bosnia Herzegovina..........................0 33 27 66 49

Brunei ..................................................02 43 08 01

Bulgaria................................................02 73 94 88

Cambodia ............................................12 80 05 00

Canada ........................................1 88 87 77 02 11

Chile..................................................8 00 53 06 62

China ...........................................0 21 38 98 47 77

Colombia....................................01 80 07 00 66 24

Croatia ..............................................0 16 10 53 81

Czech Republic.................................2 33 03 27 27

Denmark ............................................. 35 25 86 00

Dubai ................................................0 43 96 64 33

Ecuador ..........................................18 00 10 10 00

Egypt.................................................0 23 33 41 11

Estonia................................................ 06 30 47 97

Finland............................................09 22 94 37 00

France.............................................01 56 38 42 00

Germany ......................................0 90 01 00 77 00

Greece ............................................80 11 11 11 16

Hong Kong.......................................... 28 61 11 18

Hungary ..........................................06 14 71 24 44

Iceland .................................................. 5 11 30 00

India.............................22 24 98 70 00 Extn: 70 40

Indonesia .....................................0 21 46 82 60 81

Ireland.............................................18 50 77 72 77

Italy .................................................02 24 36 44 00

Ivory Coast.......................................... 05 02 02 59

Jordan...............................................0 64 39 86 42

Kenya.................................................... 2 72 37 17

Kuwait ................................................... 2 45 41 78

Latvia .................................................... 7 50 11 18

Lebanon.............................................. 01 44 30 43

Libya ...............................................02 13 50 28 82

Lithuania ...........................................8 52 74 20 10

Luxembourg........................................ 43 84 33 99

Macedonia .......................................... 02 13 14 84

Malaysia....................................+ 6 03 77 12 43 04

Malta.......................................+ 35 32 14 94 06 32

Mauritius ............................................... 2 11 62 13

Mexico .......................................01 80 07 11 00 03

Morocco .............................................. 22 66 92 09

Netherlands .................................0 90 03 33 31 00

New Zealand...................................08 00 57 43 63

Nigeria ..............................................0 14 50 05 00

Norway................................................ 22 70 84 00

Oman ....................................................... 79 10 12

Pakistan ..........................................02 15 66 22 00

Paraguay ..........................................8 00 10 20 04

Peru ..................................................0 80 05 24 00

Philippines ........................................0 27 57 11 18

Poland.............................................08 01 30 00 30

Portugal ............................................8 08 20 15 21

Qatar................................................... 04 32 20 10

We offer fast, individual advice! You have sever-

al options:

Our online support on the Internet:

www.siemens.com/

mobilephonescustomercare

We can be reached any time, any place. You are

given 24 hour support on all aspects of our prod-

ucts. Here you will find an interactive fault-finding

system, a compilation of the most frequently

asked questions and answers, plus user guides

and current software updates to download.

When calling customer service, please have

ready your receipt and the phone identity

number (IMEI, to display press *#06#), the soft-

ware version (to display, press *#06#, then

§Info§) and if available, your Siemens Service

customer number.

left page (20) of A71 FCC, LAM en, A31008-H2710-A43-1-4A19 (23.08.2005, 08:52)

Product data

VAR Language: en2; VAR issue date: 050331

Romania .........................................02 12 04 60 00

Russia..........................................8 80 02 00 10 10

Saudi Arabia .....................................0 22 26 00 43

Serbia .............................................01 13 07 00 80

Singapore ............................................62 27 11 18

Slovak Republic ..............................02 59 68 22 66

Slovenia............................................0 14 74 63 36

South Africa ....................................08 60 10 11 57

Spain.................................................9 02 11 50 61

Sweden.............................................0 87 50 99 11

Switzerland .....................................08 48 21 20 00

Taiwan ............................................02 23 96 10 06

Thailand............................................0 27 22 11 18

Tunisia .................................................71 86 19 02

Turkey..........................................0 21 65 79 71 00

Ukraine ........................................8 80 05 01 00 00

United Arab Emirates........................0 43 66 03 86

United Kingdom ...........................0 87 05 33 44 11

USA .............................................1 88 87 77 02 11

Venezuela....................................0 80 01 00 56 66

Vietnam...........................................84 89 20 24 64

Zimbabwe ............................................04 36 94 24

Product data

Declaration of conformity

Siemens Information and Communication

mobile hereby declares that the phone

described in this user guide is in compli-

ance with the essential requirements and

other relevant provisions of European Di-

rective 1999/5/EC (R&TTE).

The declaration of conformity (DoC) con-

cerned has been signed. Please call the

company hotline if you require a copy of

the original, or go to:

www.siemens.com/mobiledocs

Technical data

GSM class: 4 (2 watt)

Frequency range: 824–894 MHz

GSM class: 1 (1 watt)

Frequency range: 1710–1880 MHz

GSM class: 1 (1 watt)

Frequency range: 1850–1990 MHz

Weight: 78 g

Dimensions: 101×45×20mm

Li-Ion battery: 650 mAh

Operating temperature: –10 °C to 55 °C

(14°F to 131°F)

Standby time: 60 h - 230 h

Talk time: 90 min - 250 min

SIM card: 3.0 V

Table of contents

Popular Cell Phone manuals by other brands

Nokia

Nokia 3510i Service manual

Philips

Philips laserfax 855 Specifications

Samsung

Samsung TracFone SCH-R335C user manual

E-Boda

E-Boda Sunny V38 quick start guide

LG L56VL user guide

Samsung

Samsung SGH-S300 Service manual

Nokia

Nokia TA-1400 manual

Lava

Lava iris X1 Atom user guide

LG LGH870DS.ASEAPL user guide

Samsung

Samsung SCH-i730 Series user manual

LG U8120 user guide

SA GT-S7500T user manual

LG UN200 datasheet

honor

honor X7 quick start guide

Parla

Parla Sonic 3.5 user guide

LG GC900 user guide

HTC

HTC U11 life quick start guide

Amplicomms

Amplicomms PowerTel M7000i operating instructions
