Siemens RVL471 Operator's manual

Edition: 2.2
Controller series: C
CE1P2524E
23.10.2002
Siemens Building Technologies
HVAC Products
RVL471
Heating and Domestic Hot Water Controller
Basic Documentation

2/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products 23.10.2002

3/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products Contents 23.10.2002
Contents
1 Summary........................................................................................................11
1.1 Brief description and key features .................................................................11
1.2 Type summary...............................................................................................11
1.3 Equipment combinations................................................................................11
1.3.1 Suitable sensors ............................................................................................11
1.3.2 Suitable room units........................................................................................12
1.3.3 Suitable actuators..........................................................................................12
1.3.4 Communication..............................................................................................12
1.3.5 Passing on of heat demand signal.................................................................12
1.3.6 Documentation...............................................................................................12
2 Use.................................................................................................................13
2.1 Types of plant ................................................................................................13
2.2 Types of houses and buildings......................................................................13
2.3 Types of heating systems..............................................................................13
2.4 Functions .......................................................................................................13
3 Fundamentals................................................................................................15
3.1 Key technical features ...................................................................................15
3.1.1 Plant types with regard to heating circuit.......................................................15
3.1.2 Plant types with regard to d.h.w. heating.......................................................15
3.1.3 Function blocks..............................................................................................15
3.2 Plant types.....................................................................................................16
3.2.1 Selectable combinations................................................................................16
3.2.2 Heating circuit type 1 – space heating with mixing valve...............................17
3.2.3 Heating circuit type 2 – space heating with boiler..........................................17
3.2.4 Heating circuit type 3 – space heating with district heat................................18
3.2.5 Heating circuit type 4 – precontrol with mixing valve.....................................18
3.2.6 Heating circuit type 5 – precontrol with boiler................................................18
3.2.7 Heating circuit type 6 – precontrol with district heat ......................................19
3.2.8 D.h.w. plant type 0 – no d.h.w........................................................................19
3.2.9 D.h.w. plant type 1 – d.h.w. storage tank with charging pump.......................19
3.2.10 D.h.w. plant type 2 – d.h.w. storage tank with mixing valve...........................19
3.2.11 D.h.w. plant type 3 – storage tank with diverting valve..................................20
3.2.12 D.h.w. plant type 4 – instantaneous d.h.w. heating via heat exchanger........20
3.2.13 D.h.w. plant type 5 – only electric immersion heater .....................................20
3.2.14 Summary of plant types and plant combinations...........................................21
3.3 Setting levels, function blocks and plant types..............................................22
3.4 Heating circuit operating modes....................................................................23
3.4.1 Automatic operation.......................................................................................23

4/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products Contents 23.10.2002
3.4.2 Continuously REDUCED heating..................................................................23
3.4.3 Continuously NORMAL heating .................................................................... 23
3.4.4 STANDBY ..................................................................................................... 23
3.5 D.h.w. operating modes ................................................................................23
3.6 Manual operation...........................................................................................24
3.7 Plant type and operating mode .....................................................................24
3.8 Operating state and operational level ...........................................................25
4 Acquisition of measured values ....................................................................26
4.1 Room temperature (A6, B5)...........................................................................26
4.1.1 Measurement ................................................................................................26
4.1.2 Handling faults ..............................................................................................26
4.1.3 Room model..................................................................................................26
4.2 Flow and boiler temperature (B1)..................................................................26
4.2.1 Measurement ................................................................................................26
4.2.2 Handling faults ..............................................................................................27
4.3 Outside temperature (B9)..............................................................................27
4.3.1 Measurement ................................................................................................27
4.3.2 Handling faults ..............................................................................................27
4.4 Primary return temperature (B7) ................................................................... 27
4.4.1 Measurement ................................................................................................27
4.4.2 Handling faults ..............................................................................................27
4.5 Secondary return temperature (B71).............................................................28
4.5.1 Measurement ................................................................................................28
4.5.2 Handling faults ..............................................................................................28
4.6 D.h.w. flow temperature (B3).........................................................................28
4.6.1 Measurement ................................................................................................28
4.6.2 Handling faults ..............................................................................................28
4.7 D.h.w. storage tank temperature (B31, B32).................................................28
4.7.1 Measurement ................................................................................................28
4.7.2 Handling faults ..............................................................................................28
5 Function block "Enduser space heating".......................................................30
5.1 Operating lines..............................................................................................30
5.2 Setpoints .......................................................................................................30
5.2.1 General..........................................................................................................30
5.2.2 Frost protection for the building.....................................................................30
5.3 Heating program............................................................................................30
5.4 Holiday program............................................................................................31
6 Function block "Enduser d.h.w."....................................................................32
6.1 Operating lines..............................................................................................32
6.2 Setpoint.........................................................................................................32

5/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products Contents 23.10.2002
6.3 Actual value ...................................................................................................32
7 Function block "Enduser general"..................................................................33
7.1 Operating lines...............................................................................................33
7.2 Switching program 2......................................................................................33
7.3 Time of day and date.....................................................................................33
7.4 Indication of errors.........................................................................................34
8 Function block "Plant type"............................................................................35
8.1 Operating line.................................................................................................35
8.2 General..........................................................................................................35
9 Function block "Cascade slave".....................................................................36
9.1 Operating lines...............................................................................................36
9.2 Mode of operation..........................................................................................36
9.2.1 Boiler sequence release integral (KFI)...........................................................36
9.2.2 Boiler sequence reset integral (KRI)..............................................................36
10 Function block "Space heating".....................................................................37
10.1 Operating lines...............................................................................................37
10.2 ECO function .................................................................................................37
10.2.1 Compensating variables and auxiliary variables............................................37
10.2.2 Heating limits .................................................................................................38
10.2.3 Mode of operation..........................................................................................38
10.2.4 Operating modes and operating states..........................................................39
10.3 Room temperature source.............................................................................39
10.4 Optimization...................................................................................................39
10.4.1 Definition and purpose...................................................................................39
10.4.2 Fundamentals................................................................................................39
10.4.3 Process..........................................................................................................40
10.4.4 Room model temperature..............................................................................40
10.4.5 Optimum stop control.....................................................................................41
10.4.6 Quick setback ................................................................................................41
10.4.7 Optimum start control.....................................................................................42
10.4.8 Boost heating.................................................................................................42
10.5 Room functions..............................................................................................43
10.5.1 Maximum limitation of the room temperature.................................................43
10.5.2 Room influence..............................................................................................43
10.6 Heating curve.................................................................................................44
10.6.1 Purpose..........................................................................................................44
10.6.2 Basic setting ..................................................................................................44
10.6.3 Deflection.......................................................................................................45
10.6.4 Parallel displacement of heating curve..........................................................46

6/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products Contents 23.10.2002
10.6.5 Display of setpoints.......................................................................................46
10.7 Generation of setpoint...................................................................................47
10.7.1 Weather-compensated control......................................................................47
10.7.2 Demand-compensated control......................................................................47
11 Function block "3-position actuator heating circuit".......................................48
11.1 Operating lines..............................................................................................48
11.2 Limitations.....................................................................................................48
11.2.1 Flow temperature limitations ......................................................................... 48
11.2.2 Setpoint rise ..................................................................................................49
11.3 3-position control........................................................................................... 49
11.4 Auxiliary variables in interconnected plants..................................................49
11.4.1 Excess mixing valve or heat exchanger temperature....................................49
11.5 Pulse lock......................................................................................................50
12 Function block "Boiler" .................................................................................. 51
12.1 Operating lines..............................................................................................51
12.2 Operating mode.............................................................................................51
12.3 Limitations.....................................................................................................51
12.3.1 Maximum limitation of the boiler temperature ...............................................51
12.3.2 Minimum limitation of the boiler temperature ................................................52
12.3.3 Actions during d.h.w. heating........................................................................52
12.4 2-position control........................................................................................... 52
12.4.1 Control with a single-stage burner ................................................................52
12.4.2 Control with a 2-stage burner........................................................................53
12.4.3 Frost protection for the boiler........................................................................54
12.4.4 Protective boiler startup ................................................................................55
12.4.5 Protection against boiler overtemperatures...................................................55
12.5 Operating mode of pump M1.........................................................................56
13 Function block "Setpoint of return temperature limitation" ............................57
13.1 Operating line................................................................................................57
13.2 Description ....................................................................................................57
13.3 Minimum limitation of the return temperature................................................57
13.3.1 Acquisition of measured values ....................................................................57
13.3.2 Mode of operation ......................................................................................... 57
13.3.3 Mode of operation with a single device (with no bus) ...................................58
13.3.4 Mode of operation in interconnected plants.................................................. 58
14 Function block "District heat".........................................................................59
14.1 Operating lines..............................................................................................59
14.2 Limitations.....................................................................................................59
14.2.1 Maximum limitation of the primary return temperature..................................59

7/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products Contents 23.10.2002
14.2.2 Maximum limitation of return temperature differential (DRT limitation)..........60
14.2.3 Integral action time.........................................................................................61
14.2.4 Minimum stroke limitation (suppression of hydraulic creep)..........................61
14.2.5 Limitation of the volumetric flow.....................................................................61
15 Function block "Maximum limitation of the return temperature, d.h.w.".........62
15.1 Operating line.................................................................................................62
15.2 Purpose..........................................................................................................62
15.3 Function.........................................................................................................62
16 Function block "Basic settings d.h.w." ...........................................................64
16.1 Operating lines...............................................................................................64
16.2 Assignment of d.h.w. heating.........................................................................64
16.3 Program for the circulating pump...................................................................64
16.3.1 General mode of operation............................................................................64
16.3.2 Operation of circulating pump during the holiday period...............................65
16.4 Frost protection for d.h.w...............................................................................66
16.4.1 Frost protection in the d.h.w. storage tank.....................................................66
16.4.2 Frost protection in the d.h.w. storage tank flow .............................................66
16.4.3 Frost protection for the secondary d.h.w. flow...............................................66
17 Function block "Release of d.h.w. heating"....................................................67
17.1 Operating line.................................................................................................67
17.2 Release..........................................................................................................67
17.2.1 Function.........................................................................................................67
17.2.2 Release programs..........................................................................................67
17.2.3 D.h.w heating during the holiday period.........................................................68
18 Function block "D.h.w. priority and flow temperature setpoint"......................69
18.1 Operating line.................................................................................................69
18.2 Settings..........................................................................................................69
18.3 D.h.w. priority.................................................................................................69
18.3.1 Absolute priority.............................................................................................69
18.3.2 Shifting priority...............................................................................................70
18.3.3 No priority.......................................................................................................70
18.4 Flow temperature setpoint .............................................................................70
18.4.1 Maximum selection........................................................................................70
18.4.2 D.h.w..............................................................................................................71
19 Function block "D.h.w. storage tank".............................................................72
19.1 Operating lines...............................................................................................72
19.2 D.h.w. charging..............................................................................................72
19.2.1 D.h.w. charging with hot water.......................................................................72
19.2.2 Alternate d.h.w. charging with hot water and electricity.................................72

8/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products Contents 23.10.2002
19.3 D.h.w. temperature and d.h.w. switching differential.....................................73
19.4 Boost of the d.h.w. charging temperature .....................................................74
19.5 Maximum d.h.w. charging time......................................................................74
19.6 Setpoint of legionella function .......................................................................74
19.7 Forced charging ............................................................................................ 75
19.8 Protection against discharging...................................................................... 75
19.8.1 Purpose.........................................................................................................75
19.8.2 Mode of operation ......................................................................................... 75
19.9 Manual d.h.w. charging................................................................................. 76
20 Function block "3-position actuator for d.h.w.".............................................. 77
20.1 Operating lines..............................................................................................77
20.2 Function ........................................................................................................77
20.2.1 Flow temperature boost.................................................................................77
20.2.2 D.h.w temperature control.............................................................................77
20.3 Pulse lock......................................................................................................77
21 Function block "Derivative action time d.h.w. heating via heat exchanger" ..78
21.1 Operating line................................................................................................78
21.2 Description ....................................................................................................78
22 Function block "Multi-functional relay"...........................................................79
22.1 Operating lines..............................................................................................79
22.2 Functions.......................................................................................................79
22.2.1 No function....................................................................................................79
22.2.2 Outside temperature switch ..........................................................................79
22.2.3 ON / OFF according to the time switch .........................................................80
22.2.4 Relay energized in the event of fault.............................................................80
22.2.5 Relay energized during occupancy time ....................................................... 80
22.2.6 Relay energized during occupancy time (including optimizations)................80
22.2.7 Relay energized, if there is demand for heat ................................................80
22.2.8 Manually ON / OFF ....................................................................................... 80
23 Function block "Legionella function" .............................................................81
23.1 Operating lines..............................................................................................81
23.1.1 Periodicity of legionella function....................................................................81
23.1.2 Time of legionella function ............................................................................81
23.1.3 Dwelling time at the legionella setpoint.........................................................81
23.1.4 Circulating pump operation during the legionella function ............................81
23.2 Mode of operation ......................................................................................... 81
24 Function block "Switching program 3"...........................................................83
24.1 Operating lines..............................................................................................83
24.2 Function ........................................................................................................83

9/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products Contents 23.10.2002
25 Function block "Service functions and general settings" ...............................84
25.1 Operating lines...............................................................................................84
25.2 Display functions............................................................................................84
25.2.1 Flow temperature setpoint .............................................................................84
25.2.2 Heating curve.................................................................................................85
25.2.3 Hours run counter..........................................................................................85
25.2.4 Software version............................................................................................85
25.2.5 Identification number of room unit..................................................................86
25.2.6 Radio clock, elapsed time since last reception..............................................86
25.3 Commissioning aids.......................................................................................86
25.3.1 Simulation of the outside temperature...........................................................86
25.3.2 Relay test.......................................................................................................87
25.3.3 Sensor test.....................................................................................................87
25.3.4 Test of H-contacts..........................................................................................88
25.4 Auxiliary functions..........................................................................................88
25.4.1 Frost protection for the plant..........................................................................88
25.4.2 Flow alarm .....................................................................................................89
25.4.3 Manual overriding of operating mode (contact H1)........................................90
25.4.4 Pump overrun ................................................................................................90
25.4.5 Pump kick ......................................................................................................90
25.4.6 Winter- / summertime changeover.................................................................90
25.4.7 Gain of locking signal.....................................................................................91
25.5 Entries for LPB...............................................................................................92
25.5.1 Source of time of day.....................................................................................92
25.5.2 Outside temperature source ..........................................................................92
25.5.3 Addressing the devices..................................................................................93
25.5.4 Bus power supply...........................................................................................93
25.5.5 Bus loading number.......................................................................................94
25.6 Heat demand output DC 0...10 V...................................................................94
26 Function block "Locking functions" ................................................................95
26.1 Operating line.................................................................................................95
26.2 Locking the settings on the software side......................................................95
26.3 Locking the settings for district heat on the hardware side............................95
27 Communication..............................................................................................96
27.1 Combination with room units..........................................................................96
27.1.1 General..........................................................................................................96
27.1.2 Combination with room unit QAW50..............................................................96
27.1.3 Combination with room unit QAW70..............................................................96
27.1.4 Combination with SYNERGYR central unit OZW30......................................98
27.2 Communication with other devices................................................................98
27.2.1 Data bus.........................................................................................................98

10/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products Contents 23.10.2002
27.2.2 Heat demand signal ......................................................................................99
28 Handling......................................................................................................100
28.1 Operation.....................................................................................................100
28.1.1 General........................................................................................................100
28.1.2 Analog operating elements .........................................................................101
28.1.3 Digital operating elements...........................................................................102
28.1.4 Setting levels and access rights.................................................................. 103
28.2 Commissioning............................................................................................103
28.2.1 Installation instructions................................................................................103
28.2.2 Operating lines............................................................................................103
28.3 Installation...................................................................................................104
28.3.1 Mounting location........................................................................................104
28.3.2 Mounting choices ........................................................................................104
28.3.3 Electrical installation.................................................................................... 104
29 Engineering.................................................................................................105
29.1 Connection terminals ..................................................................................105
29.1.1 Low-voltage side ......................................................................................... 105
29.1.2 Mains voltage side ......................................................................................105
29.2 Connection diagrams .................................................................................. 106
29.2.1 Low-voltage side ......................................................................................... 106
29.2.2 Mains voltage side ......................................................................................106
30 Mechanical design ......................................................................................107
30.1 Basic design................................................................................................107
30.2 Dimensions .................................................................................................107
31 Technical data.............................................................................................108

11/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products 1 Summary 23.10.2002
1 Summary
1.1 Brief description and key features
•The RVL471 is a multifunctional heating controller for use in residential and non-resi-
dential buildings that have their own d.h.w. heating facility
•Suited for:
−Heating zone control with or without room influence via weather-compensated flow
temperature control
−Precontrol via demand-compensated control of the main / secondary flow tem-
perature
−Precontrol via demand-compensated boiler temperature control. Suited for integra-
tion into heat source cascades or heat generation systems (heat pump, solar,
wood)
•For use in plants with own heat generation or with a district heat connection
•With regard to d.h.w. heating, the RVL471 is suited for plants with d.h.w. storage tanks,
electric immersion heaters and instantaneous systems with own heat exchangers
•The RVL471 has 29 plant types preprogrammed. When a certain type of plant is se-
lected, all functions and settings required for that plant will be activated
•A scalable voltage output DC 0...10 V is used to pass the heat demand signal to other
systems
•A multifunctional relay provides additional control functions, if required
•For direct adjustment of the heating curve, the well known “bar" is used. Digital ad-
justment of the heating curve is possible also. A setting knob is used for making room
temperature readjustments
•All the other parameters are set digitally based on the operating line principle
•The RVL471 is capable of communicating with other units via LPB (Local Process Bus)
•Key design features: Operating voltage AC 230 V, CE conformity, overall dimensions
to DIN 43700 (144 x 144 mm)
1.2 Type summary
The RVL471 is a compact controller that requires no plug-in modules.
1.3 Equipment combinations
1.3.1 Suitable sensors
•For water temperatures:
Suitable are all types of temperature sensors that use a sensing element
LG-Ni 1000 7KHIROORZLQJW\SHVDUHSUHVHQWO\DYDLODEOH
−Strap-on temperature sensor QAD22
−Immersion temperature sensors QAE22...
−Immersion temperature sensor QAP21.3 complete with connecting cable
•For the room temperature:
Suitable are all types of temperature sensors that use a sensing element
LG-Ni 7KHIROORZLQJW\SHVDUHSUHVHQWO\DYDLODEOH
−Room temperature sensor QAA24
•For the outside temperature:
−2XWVLGHVHQVRU4$&VHQVLQJHOH HQW/*1L 
−Outside sensor QAC32 (sensing element NTC 575)

12/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products 1 Summary 23.10.2002
1.3.2 Suitable room units
•Room unit QAW50
•Room unit QAW70
1.3.3 Suitable actuators
All types of actuators from HVAC Products with the following features can be used:
•Electromotoric or electrohydraulic actuators with a running time of 0.5...14.5 minutes
•3-position control
•Operating voltage AC 24... 230 V
1.3.4 Communication
Communication is possible with the following units:
•All LPB-compatible controllers supplied by HVAC Products
•SYNERGYR central unit OZW30 (software version 3.0 or higher)
1.3.5 Passing on of heat demand signal
The scalable DC 0...10 V signal can be used to pass the heat demand signal to other
devices in the system.
1.3.6 Documentation
Type of documentation Ordering number (for English)
Data Sheet RVL471 CE1N2524E
Operating Instructions RVL471 4 319 2779 0
Installation Instructions RVL471 4 319 2770 0
Data Sheet QAW50 CE2N1635E
Data Sheet QAW70 CE2N1637E
Data Sheet "LPB Basic System Data" CE1N2030E
Data Sheet "LPB Basic Engineering
Data" CE1N2032E

13/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products 2 Use 23.10.2002
2 Use
2.1 Types of plant
The RVL471 is suitable for all types of heating plant that use weather-compensated
flow temperature control. In addition, it can be used for demand-compensated control of
the main flow.
With regard to d.h.w. heating, the RVL471 is suited for plants with storage tanks or
d.h.w. heating via heat exchangers (instantaneous d.h.w. heating).
Main applications:
•Heating zones and d.h.w. heating with own heat generation
•Heating zones and d.h.w. heating with a district heat connection
•Interconnected plants consisting of heat generation, several heating zones and central
or decentral d.h.w. heating
2.2 Types of houses and buildings
Basically, the RVL471 is suited for use in all types of houses and buildings It has been
designed especially for:
•Multi-family houses
•Single-family homes
•Small to medium-size nonresidential buildings
2.3 Types of heating systems
The RVL471 is suited for use with all standard heating systems, such as:
•Radiators
•Convectors
•Underfloor heating systems
•Ceiling heating systems
•Radiant panels
2.4 Functions
The RVL471 is used if one or several of the following functions is / are required:
•Weather-compensated flow temperature control
•Flow temperature control via a modulating seat or slipper valve, or boiler temperature
control through direct control of a single- or 2-stage burner
•D.h.w. storage tank charging through control of a mixing valve, charging pump or di-
verting valve, with or without circulating pump
•D.h.w. heating via heat exchanger (instantaneous d.h.w. heating), with or without cir-
culating pump
•Optimum start / stop control according to the selected 7-day program
•Quick setback and boost heating according to the selected 7-day program
•ECO function: demand-dependent switching of the heating system based on the type
of building construction and the outside temperature
•Voltage output DC 0...10 V for passing on the heat demand signal
•Multifunctional relay
•7-day program for building occupancy with a maximum of 3 setback periods per day
and daily varying occupancy schedules
•Own 7-day switching program for the release of d.h.w. heating

14/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products 2 Use 23.10.2002
•Third 7-day switching program
•Input of 8 holiday periods per year
•Automatic summer- / wintertime changeover
•Display of parameters, actual values, operating state and error messages
•Communication with other units via LPB
•Remote operation via room unit and external switches
•Service functions
•Frost protection for the plant, the boiler and the house or building
•Minimum or maximum limitation of the return temperature
•DRT limitation
•Minimum and maximum limitation of the flow temperature
•Maximum limitation of the room temperature
•Periodic pump run
•Pump overrun
•Maximum limitation of the rate of setpoint increase
•Flow alarm
•Legionella function
•Manual d.h.w. charging
For the preprogrammed heating and d.h.w. heating circuits and their possible combina-
tions, refer to section 3.2 ”Plant types”.

15/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products 3 Fundamentals 23.10.2002
3 Fundamentals
3.1 Key technical features
The RVL471 offers 2 key technical features:
•The RVL471 has 6 heating circuit plant types and 5 d.h.w. plant types preprogrammed.
When making use of all possible or practical combinations, there is a total of 29 plant
types available
•All functions and their settings are combined in the form of function blocks
3.1.1 Plant types with regard to heating circuit
In terms of heating circuit, the following plant types are available:
•Heating circuit plant type 1 –space heating with mixing valve
•Heating circuit plant type 2 –space heating with boiler
•Heating circuit plant type 3 –space heating with district heat
•Heating circuit plant type 4 –precontrol with mixing valve
•Heating circuit plant type 5 –precontrol with boiler
•Heating circuit plant type 6 –precontrol with district heat
Heating circuit plant type 5 is suited for integration into heat source cascades or heat
generation systems.
3.1.2 Plant types with regard to d.h.w. heating
In terms of d.h.w., the following plant types are available:
•D.h.w. plant type 0 –no d.h.w.
•D.h.w. plant type 1 –storage tank with charging pump
•D.h.w. plant type 2 –storage tank with mixing valve
•D.h.w. plant type 3 –storage tank with diverting valve
•D.h.w. plant type 4 –instantaneous d.h.w. heating via heat exchanger
•D.h.w. plant type 5 –only electric immersion heater
3.1.3 Function blocks
The following function blocks are available:
•Function block “Enduser space heating”
•Function block “Enduser d.h.w.”
•Function block “Enduser general”
•Function block “Plant type”
•Function block “Cascade slave”
•Function block "Space heating"
•Function block “3-position actuator heating circuit”
•Function block “Boiler”
•Function block “Setpoint return temperature limitation”
•Function block “District heat”
•Function block "Maximum limitation of the return temperature d.h.w."
•Function block "Basic settings d.h.w."
•Function block "Release of d.h.w. heating"
•Function block "Priority and flow temperature setpoint d.h.w."
•Function block "D.h.w. storage tank"
•Function block "3-position actuator d.h.w."
•Function block “Derivative action time d.h.w. heating via heat exchanger”

16/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products 3 Fundamentals 23.10.2002
•Function block “Multifunctional relay”
•Function block “Legionella function"
•Function block "Switching program 3"
•Function block “Service functions and general settings”
•Function block “Locking functions”
For each function block, the required settings are available in the form of operating
lines. On the following pages, a description of the individual functions per block and line
is given.
3.2 Plant types
The RVL471 has 29 plant types preprogrammed; the functions required for each type of
plant are ready assigned. When commissioning the installation, the relevant plant type
must be selected.
Each plant type consists of a heating circuit and a d.h.w. circuit. When making use of all
possible or practical combinations, there is a total of 29 plant types available.
3.2.1 Selectable combinations
&RPELQDWLRQV Type of heating circuit Type of d.h.w. heating
1–0 Space heating with mixing valve No d.h.w.
1–1 Space heating with mixing valve Storage tank with charging pump
1–2 Space heating with mixing valve Storage tank with mixing valve
1–4 Space heating with mixing valve Instantaneous d.h.w. heating via heat
exchanger
1–5 Space heating with mixing valve Only electric immersion heater
2–0 Space heating with boiler No d.h.w.
2–1 Space heating with boiler Storage tank with charging pump
2–2 Space heating with boiler Storage tank with mixing valve
2–3 Space heating with boiler Storage tank with diverting valve
2–5 Space heating with boiler Only electric immersion heater
3–0 Space heating with district heat No d.h.w.
3–1 Space heating with district heat storage tank with charging pump
3–2 Space heating with district heat Storage tank with mixing valve
3–3 Space heating with district heat Storage tank with diverting valve
3–4 Space heating with district heat Instantaneous d.h.w. heating via heat
exchanger
3–5 Space heating with district heat Only electric immersion heater
4–0 Precontrol with mixing valve No d.h.w.
4–1 Precontrol with mixing valve Storage tank with charging pump
4–2 Precontrol with mixing valve Storage tank with mixing valve
4–5 Precontrol with mixing valve Only electric immersion heater
5–0 Precontrol with boiler No d.h.w.
5–1 Precontrol with boiler Storage tank with charging pump
5–2 Precontrol with boiler Storage tank with mixing valve
5–4 Precontrol with boiler Instantaneous d.h.w. heating via heat
exchanger
5–5 Precontrol with boiler Only electric immersion heater
6–0 Precontrol with district heat No d.h.w.
6–1 Precontrol with district heat Storage tank with charging pump
6–2 Precontrol with district heat Storage tank with mixing valve
6–5 Precontrol with district heat Only electric immersion heater

17/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products 3 Fundamentals 23.10.2002
Notes on the plant diagrams with the different types of space heating and d.h.w. circuits
are given in the following sections:
•Symbols and indicate where and how the space heating circuit is connected to
the d.h.w. circuit. where:
representing the flow
representing the return
•The numbers beneath these symbols indicate the type of d.h.w. circuit with which the
heating circuit can be combined
3.2.2 Heating circuit type 1 –space heating with mixing
valve
A6/B5
B7
2524S01
1, 2, 4 0, 5
Space heating with weather-compensated flow temperature control. 3-position control
acting on the mixing valve of the heating zone.
Outside temperature signal from own sensor or data bus. With or without room influ-
ence. Heating up and setback according to the heating program.
3.2.3 Heating circuit type 2 –space heating with boiler
A6/B5
2524S02
1, 2 3 0, 5
Space heating with own boiler, with weather-compensated boiler temperature control.
2-position control acting on the burner.
Outside temperature signal from own sensor or data bus. With or without room influ-
ence. Heating up and setback according to the heating program.

18/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products 3 Fundamentals 23.10.2002
3.2.4 Heating circuit type 3 –space heating with district heat
B7 B71
2524S03
A6/B5
Y1
N1
2, 4 1 3 0, 5
Space heating with district heat connection, with weather-compensated flow tempera-
ture control acting on the valve in the primary return of the district heat connection.
Outside temperature signal from own sensor or data bus. With or without room influ-
ence. Heating up and setback according to the heating program.
3.2.5 Heating circuit type 4 –precontrol with mixing valve
2524S04
B7
1, 2 0, 5
Precontrol with demand-dependent control of the main flow temperature. 3-position
control acting on the mixing valve in the main flow.
Heat demand signal from data bus. No heating program.
3.2.6 Heating circuit type 5 –precontrol with boiler
2524S05
B7
1, 2, 4 0, 5
Precontrol with demand-compensated control of the boiler temperature. 2-position con-
trol acting on the burner.
Heat demand signal from data bus. No heating program.

19/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products 3 Fundamentals 23.10.2002
3.2.7 Heating circuit type 6 –precontrol with district heat
2524S06
B7 B71
Y1
N1
1, 2 0, 5
Precontrol with district heat connection, with demand-compensated control of the sec-
ondary flow temperature acting on the valve in the primary return.
Heat demand signal from data bus. No heating program.
3.2.8 D.h.w. plant type 0 –no d.h.w.
The RVL471 does not provide d.h.w. heating.
3.2.9 D.h.w. plant type 1 –d.h.w. storage tank with charging
pump
B31
B32
M3
M4
2524S07
K6
Charging of d.h.w. storage tank through control of the charging pump. Acquisition of the
d.h.w. temperature with one or 2 sensors or thermostats. Circulating pump and electric
immersion heater are optional.
3.2.10 D.h.w. plant type 2 –d.h.w. storage tank with mixing
valve
2524S08
B3
Y7
B31
B32
M3 M4
K6
Charging of d.h.w. storage tank through control of the mixing valve according to own
temperature sensor in the storage tank flow. Acquisition of the d.h.w. temperature with
one or 2 sensors or thermostats. Circulating pump and electric immersion heater are
optional.

20/118
Siemens Building Technologies Basic Documentation RVL471 CE1P2524E
HVAC Products 3 Fundamentals 23.10.2002
3.2.11 D.h.w. plant type 3 –storage tank with diverting valve
2524S09
Y3
B31
B32
M4
K6
Charging of the d.h.w. storage tank through control of the diverting valve. Acquisition of
the d.h.w. temperature with one or 2 sensors or thermostats. Circulating pump and
electric immersion heater are optional.
3.2.12 D.h.w. plant type 4 –instantaneous d.h.w. heating via
heat exchanger
M4
2524S10
B3
Y7
N1
D.h.w. heating via heat exchanger (instantaneous d.h.w. heating) through control of the
2-port valve in the heat exchanger’s primary return. Acquisition of the d.h.w. tempera-
ture in the heat exchanger’s secondary flow. Circulating pump is optional, but strongly
recommended.
3.2.13 D.h.w. plant type 5 –only electric immersion heater
M4
2524S11
K6
Charging of d.h.w. storage tank only through release of the electric immersion heater.
No control of d.h.w. heating by the controller. Circulating pump is optional.
A6 Room unit QAW50 or QAW70 E2 Consumer (space)
B1 Flow / boiler sensor LPB Data bus
B3 D.h.w. flow sensor K6 Electric immersion heater
B31 Storage tank sensor / thermostat 1 M1 Heating circuit pump / circulating pump
B32 Storage tank sensor / thermostat 2 M3 Charging pump
B5 Room sensor M4 Circulating pump
B7 Return sensor (primary circuit) N1 Controller RVL471
B71 Return sensor (secondary circuit) Y1 Heating circuit mixing valve
B9 Outside sensor Y3 Diverting valve
E1 Heat source (boiler / heat converter) Y7 D.h.w. mixing valve
