Siemens SIMOTICS GP series User manual

SIMOTICS GP, SD, DP
Low-Voltage Motors
Standard motors SH 63 ... 355
Operating Instructions
12/2018
A5E38483075A
Introduction
1
Safety information
2
Description
3
Preparing for use
4
Assembly
5
Electrical connection
6
Commissioning
7
Operation
8
Maintenance
9
Spare parts
10
Disposal
11
Service & support
A
Technical data
B
Quality documents
C

Siemens AG
Division Process Industries and Drives
Postfach 48 48
90026 NÜRNBERG
GERMANY
Document order number: A5E38483075A
Ⓟ
12/2018 Subject to change
Copyright © Siemens AG 2008 - 2018.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury
may
result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

Standard motors SH 63 ... 355
Operating Instructions, 12/2018, A5E38483075A 3
Table of contents
1 Introduction............................................................................................................................................. 9
1.1 About these instructions............................................................................................................9
1.2 Compiling personal documents ................................................................................................9
2 Safety information ................................................................................................................................. 11
2.1 Information for those responsible for the plant or system.......................................................11
2.2 The 5 safety rules ...................................................................................................................11
2.3 Qualified personnel .................................................................................................................12
2.4 Safe handling..........................................................................................................................12
2.5 Electrostatic sensitive devices ................................................................................................14
2.6 Interference immunity .............................................................................................................15
2.7 Influence on the line power supply through a strongly irregular torque..................................15
2.8 Interference voltages when operating the converter ..............................................................15
2.9 Special designs and construction versions.............................................................................15
3 Description............................................................................................................................................ 17
3.1 Area of application ..................................................................................................................17
3.2 Rating plates ...........................................................................................................................19
3.3 Installation...............................................................................................................................20
3.3.1 Cooling and ventilation............................................................................................................21
3.3.1.1 General ...................................................................................................................................21
3.3.1.2 Machines with a fan ................................................................................................................21
3.3.1.3 Machines without a fan (optional) ...........................................................................................23
3.3.2 Bearings..................................................................................................................................23
3.3.3 Balancing ................................................................................................................................24
3.3.4 Types of construction/method of installation ..........................................................................24
3.3.5 Degree of protection ...............................................................................................................25
3.3.6 Environmental conditions........................................................................................................25
3.3.7 Optional built-on and built-in accessories ...............................................................................26
3.3.8 Terminal box ...........................................................................................................................26
3.3.9 Paint finish ..............................................................................................................................26
4 Preparing for use .................................................................................................................................. 27
4.1 Safety-related aspects to consider when configuring the plant ..............................................27
4.2 Observing the operating mode ...............................................................................................27
4.3 Machines without final paint coating.......................................................................................27
4.4 Delivery ...................................................................................................................................28
4.5 Transport and storage.............................................................................................................28

Table of contents
Standard motors SH 63 ... 355
4Operating Instructions, 12/2018, A5E38483075A
4.5.1 Storage................................................................................................................................... 30
4.5.2 Securing the rotor................................................................................................................... 32
4.5.3 Commissioning after storage ................................................................................................. 34
4.5.3.1 Insulation resistance and polarization index .......................................................................... 34
4.5.3.2 Lubricating the rolling bearings.............................................................................................. 34
4.5.3.3 Regreasing rolling bearings after storage periods of up to two years ................................... 34
4.5.3.4 Releasing the rotor shipping brace before commissioning.................................................... 34
4.6 Ensure adequate cooling ....................................................................................................... 35
4.7 Interlock circuit for anti-condensation heating ....................................................................... 37
4.8 Noise emission....................................................................................................................... 37
4.9 Voltage and frequency fluctuations during line operation...................................................... 37
4.10 Rotational speed limit values ................................................................................................. 38
4.11 System-inherent frequencies ................................................................................................. 38
4.12 Electromagnetic compatibility ................................................................................................ 39
4.13 Converter operation ............................................................................................................... 40
4.13.1 Parameterizing the converter................................................................................................. 40
4.13.2 Converter input voltage.......................................................................................................... 40
4.13.3 Reducing bearing currents during operation with converter (low voltage) ............................ 41
4.13.4 Insulated bearings when operated with a converter .............................................................. 42
4.13.5 Tandem operation .................................................................................................................. 43
4.13.6 Speed limits for converter operation ...................................................................................... 44
5 Assembly.............................................................................................................................................. 45
5.1 Preparing for installation ........................................................................................................ 45
5.1.1 Requirements for installation ................................................................................................. 45
5.1.2 Insulation resistance .............................................................................................................. 46
5.1.2.1 Insulation resistance and polarization index .......................................................................... 46
5.1.2.2 Testing the insulation resistance and polarization index ....................................................... 47
5.2 Installing the machine ............................................................................................................ 49
5.2.1 Preparing the assembly area ................................................................................................. 49
5.2.2 Safety instructions for installation .......................................................................................... 50
5.2.3 Lift the machine to where it will be mounted and position it .................................................. 50
5.2.4 Balancing ............................................................................................................................... 51
5.2.4.1 Mounting and withdrawing output transmission elements ..................................................... 52
5.2.5 Machines with type of construction IM B15, IM B9, IM V8 and IM V9 ................................... 52
5.2.6 Foot mounting ........................................................................................................................ 53
5.3 Aligning and fixing the machine ............................................................................................. 53
5.3.1 Measures for alignment and mounting .................................................................................. 54
5.3.2 Flatness of the supporting surfaces for conventional motors ................................................ 55
5.3.3 Machine frame mounting feet (special design)...................................................................... 55
5.4 Installing the machine ............................................................................................................ 55
5.4.1 Preconditions for smooth, vibration-free operation................................................................ 55
5.4.2 Aligning the machine to the driven machine and mounting ................................................... 55
5.4.2.1 Selecting bolts........................................................................................................................ 55
5.4.2.2 Horizontal types of construction with mounting feet .............................................................. 56
5.4.2.3 Horizontal types of construction with flange .......................................................................... 56
5.4.2.4 Vertical types of construction with flange............................................................................... 57

Table of contents
Standard motors SH 63 ... 355
Operating Instructions, 12/2018, A5E38483075A 5
5.4.3 Removing the rotor shipping brace.........................................................................................57
5.4.4 Mounting the output elements ................................................................................................58
5.4.5 Axial and radial forces.............................................................................................................59
6 Electrical connection ............................................................................................................................. 61
6.1 Connected parts can become loose .......................................................................................62
6.2 Connecting the machine .........................................................................................................62
6.2.1 Selecting cables......................................................................................................................62
6.2.2 Terminal box ...........................................................................................................................63
6.2.2.1 Terminal marking ....................................................................................................................63
6.2.2.2 Circuit diagram inside the terminal box cover.........................................................................64
6.2.2.3 Direction of rotation.................................................................................................................64
6.2.2.4 Cable entry..............................................................................................................................64
6.2.2.5 Versions ..................................................................................................................................65
6.2.2.6 Protruding connection cables .................................................................................................65
6.2.2.7 Connecting protruding cables .................................................................................................66
6.2.2.8 Connection with/without cable lugs.........................................................................................66
6.2.2.9 Minimum air clearances ..........................................................................................................66
6.2.3 Cable glands ...........................................................................................................................67
6.2.3.1 Mounting position of sheet metal nuts in screw-type connections .........................................67
6.3 Tightening torques ..................................................................................................................68
6.3.1 Cable entries, sealing plugs and thread adapters ..................................................................68
6.4 Connecting the grounding conductor......................................................................................
68
6.4.1 Minimum surface area of grounding conductor ......................................................................69
6.4.2 Grounding connection type.....................................................................................................69
6.5 Connecting the temperature sensor/anti-condensation heater ..............................................70
6.5.1 Connecting optional integrated devices and equipment.........................................................70
6.6 Conductor connection .............................................................................................................71
6.6.1 Type of conductor connection.................................................................................................71
6.6.2 Connecting aluminum conductors ..........................................................................................72
6.7 Connecting converters ............................................................................................................72
6.8 Final checks ............................................................................................................................73
7 Commissioning ..................................................................................................................................... 75
7.1 Measures before commissioning ............................................................................................75
7.1.1 Checks to be carried out prior to commissioning....................................................................75
7.1.2 Mechanical checks..................................................................................................................76
7.1.3 Insulation resistance and polarization index...........................................................................77
7.1.4 Testing the insulation resistance and polarization index ........................................................78
7.1.5 Testing the cooling of the machine .........................................................................................80
7.1.6 Commissioning an external fan ..............................................................................................80
7.1.7 Further documents..................................................................................................................81
7.1.8 Setpoint values for monitoring the bearing temperature.........................................................82
7.2 Switching on............................................................................................................................82
7.2.1 Measures required for commissioning and test operation......................................................82
8 Operation.............................................................................................................................................. 85
8.1 Safety instructions for operation .............................................................................................85

Table of contents
Standard motors SH 63 ... 355
6Operating Instructions, 12/2018, A5E38483075A
8.1.1 Safety instructions relating to ventilation and cooling ............................................................ 88
8.1.1.1 Safety instruction for forced ventilation (option)..................................................................... 88
8.1.1.2 Safety instructions when operating machines with fan.......................................................... 89
8.1.1.3 Machines with fan for the textile industry............................................................................... 89
8.1.2 Switching on with the anti-condensation heating active ........................................................ 89
8.2 Switching on the machine...................................................................................................... 90
8.3 Switch off the external fan...................................................................................................... 90
8.4 Switching on again after an emergency switching-off............................................................ 90
8.5 Stoppages .............................................................................................................................. 90
8.5.1 Avoidance of damage to rolling bearings during stoppages.................................................. 92
8.5.2 Decommissioning the machine .............................................................................................. 92
8.5.3 Re-commissioning the machine............................................................................................. 92
8.6 faults....................................................................................................................................... 92
8.6.1 Inspections in the event of faults............................................................................................ 92
8.6.2 Electrical faults ....................................................................................................................... 93
8.6.3 Mechanical faults ................................................................................................................... 94
8.6.4 Rolling bearing faults ............................................................................................................. 94
8.6.5 Faults at the external fan ....................................................................................................... 95
8.7 Deactivating ........................................................................................................................... 95
9 Maintenance ......................................................................................................................................... 97
9.1 Preparation and notes............................................................................................................ 97
9.1.1 North American market (optional) .......................................................................................... 97
9.1.2 Touch up any damaged paintwork......................................................................................... 98
9.2 Inspection and maintenance .................................................................................................. 98
9.2.1 Safety instructions for inspection and maintenance .............................................................. 98
9.2.2 Inspections in the event of faults............................................................................................ 99
9.2.3 First inspection after installation or repair ............................................................................ 100
9.2.4 General inspection ............................................................................................................... 100
9.2.5 Assessing the rolling bearings ............................................................................................. 101
9.2.6 Maintenance intervals .......................................................................................................... 101
9.2.7 Re-greasing.......................................................................................................................... 102
9.2.8 Cleaning ............................................................................................................................... 103
9.2.9 Cleaning the fan cover of machines for the textile industry ................................................. 103
9.2.10 Drain condensate ................................................................................................................. 104
9.2.11 Insulation resistance and polarization index ........................................................................ 104
9.2.12 Servicing the external fan .................................................................................................... 105
9.3 Corrective maintenance ....................................................................................................... 105
9.3.1 Rolling bearings ................................................................................................................... 106
9.3.1.1 Bearing bushes .................................................................................................................... 108
9.3.1.2 Installing rolling bearings ..................................................................................................... 108
9.3.2 Mounting dimension "x" ....................................................................................................... 110
9.3.3 Fan ....................................................................................................................................... 110
9.3.3.1 Metal fan disassembly ......................................................................................................... 111
9.3.3.2 Mounting fans....................................................................................................................... 112
9.3.3.3 Mounting the fan cover ........................................................................................................ 113
9.3.4 Canopy; mounting a rotary pulse encoder under the canopy.............................................. 113
9.3.5 Screw lock washers ............................................................................................................. 113

Table of contents
Standard motors SH 63 ... 355
Operating Instructions, 12/2018, A5E38483075A 7
9.3.6 Links......................................................................................................................................114
9.3.7 Reassembly: Miscellaneous information ..............................................................................114
9.3.8 Optional add-on units............................................................................................................114
9.3.8.1 Mounting a brake ..................................................................................................................115
9.3.9 O-ring seal ............................................................................................................................115
10 Spare parts ......................................................................................................................................... 117
10.1 Parts order ............................................................................................................................117
10.2 Data matrix code on the machine .........................................................................................117
10.3 Ordering data ........................................................................................................................117
10.4 Ordering spare parts via the Internet ....................................................................................118
10.5 Replacing rolling bearings ....................................................................................................118
10.6 Insulated rolling bearings......................................................................................................118
10.7 Parts groups definition ..........................................................................................................118
10.8 Ordering example .................................................................................................................119
10.9 Machine parts .......................................................................................................................120
10.10 Standardized parts................................................................................................................122
10.11 Exploded drawings................................................................................................................123
10.11.1 1LA,1LP,1PP6 SH63 ... 90 ...................................................................................................123
10.11.2 1LA,1LP,1PP6 SH100 ... 160 ...............................................................................................124
10.11.3 1LA5180 ... 225.....................................................................................................................125
10.11.4 1LE1,1FP1 SH80 ... 160 aluminum ......................................................................................126
10.11.5 1LE1 SH180 ... 200 aluminum..............................................................................................127
10.11.6 1LE1 SH71 ... 90 cast iron....................................................................................................128
10.11.7 1LE1, 1FP1 SH100 ... 200 cast iron .....................................................................................
129
10.11.8 1LE1 SH225 ... 315 cast iron................................................................................................130
10.11.9 1LG4/6 SH180 ... 315 ...........................................................................................................131
10.11.10 Terminal box gk330, gt320, gk430, gt420 ............................................................................132
10.11.11 Terminal box gk431, gt421, gt520, gt540 .............................................................................133
10.11.12 Terminal box 1LG4/6 gt620, gt640, gt791 ............................................................................134
11 Disposal.............................................................................................................................................. 135
11.1 Country-specific legislation - LV machines...........................................................................135
11.2 RoHS - restricting the use of certain hazardous substances................................................135
11.3 Information according to Article 33 of the REACH regulation ..............................................135
11.4 Preparing for disassembly ....................................................................................................136
11.5 Dismantling the machine ......................................................................................................136
11.6 Disposal of components........................................................................................................136
A Service & support................................................................................................................................ 139
A.1 Siemens Industry Online Support .........................................................................................139
A.2 Further documents................................................................................................................140
B Technical data .................................................................................................................................... 141

Table of contents
Standard motors SH 63 ... 355
8Operating Instructions, 12/2018, A5E38483075A
B.1 Tightening torques ............................................................................................................... 141
B.1.1 Tightening torques for screw and bolt connections ............................................................. 141
B.1.2 Terminal board and grounding............................................................................................. 142
B.1.3 Terminal boxes, end shields, grounding conductors, sheet metal fan covers..................... 142
B.1.4 Additional connecting terminals for monitoring equipment and anti-condensation
heating ................................................................................................................................. 142
C Quality documents ...............................................................................................................................143
C.1 Quality documents SIMOTICS in SIOS ............................................................................... 143
Index ...................................................................................................................................................145

Standard motors SH 63 ... 355
Operating Instructions, 12/2018, A5E38483075A 9
Introduction
1
1.1 About these instructions
These instructions describe the machine and explain how to handle it, from initial delivery to
final disposal of the equipment. Keep these instructions for later use.
Read these operating instructions before you handle the machine and follow the instructions
to become familiar with its design and operating principles and thus ensure safe, problem-
free machine operation and long service life.
Safety instructions and handling-related warning notes are provided in these instructions.
When carrying out any activity at or with the machine, carefully comply with all of these notes
for your own safety, to protect other people and to avoid material damage.
Please contact the Service Center if you have any suggestions on how to improve this
document.
Text format features
You can find the following text format features in these instructions:
1. Handling instructions are always formatted as a numbered list. Always perform the steps
in the order given.
●Lists are formatted as bulleted lists.
–Lists on the second level are hyphenated.
Note
The note provides you with additional information about the product itself, handling the
product
- and the relevant documentation.
1.2 Compiling personal documents
On the Internet pages in Industry Online Support you have the possibility of compiling
personal documents using the function Documentation
(https://support.industry.siemens.com/My/ww/en/documentation)
Using the "Documentation" function, from Product Support manuals, you can compile your
own "Documentation". However, you can also include other Product Support content such as
FAQs or characteristics in the documentation that you compile.
In the "Documentation" function, you have the option of creating your own compiled
documents in your own structure and managing them. You can delete or shift individual
chapters or topics. Further, using the note function you can import your own content. The
compiled "documentation" can be exported as PDF, for example.

Introduction
1.2 Compiling personal documents
Standard motors SH 63 ... 355
10 Operating Instructions, 12/2018, A5E38483075A
Using the "Documentation" function, you can efficiently compile your own plant or system
documentation. The "Documentation" compiled in a specific language can also be
automatically exported in one of the other available languages.
The full functionality is only available for registered users.

Standard motors SH 63 ... 355
Operating Instructions, 12/2018, A5E38483075A 11
Safety information
2
2.1 Information for those responsible for the plant or system
This electric machine has been designed and built in accordance with the specifications
contained in Directive 2014/35/EU ("Low-Voltage Directive") and is intended for use in
industrial plants. Please observe the country-specific regulations when using the electric
machine outside the European Community. Follow the local and industry-specific safety and
setup regulations.
The persons responsible for the plant must ensure the following:
●Planning and configuration work and all work carried out on and with the machine is only
to be done by qualified personnel.
●The operating instructions must always be available for all work.
●The technical data as well as the specifications relating to the permissible installation,
connection, ambient and operating conditions are taken into account at all times.
●The specific setup and safety regulations as well as regulations on the use of personal
protective equipment are observed.
Note
Use the services and support provided by the local service center for planning,
installation, commissioning and service work.
2.2 The 5 safety rules
For your own personal safety and to prevent material damage when carrying out any work,
always observe the safety-relevant instructions and the following five safety rules according
to EN 50110-1 "Working in a voltage-free state". Apply the five safety rules in the sequence
stated before starting work.
5 safety rules
1. Disconnect the system.
Also disconnect the auxiliary circuits, for example, anti-condensation heating.
2. Secure against reconnection.
3. Verify absence of operating voltage.
4. Ground and short-circuit.
5. Provide protection against adjacent live parts.
To energize the system, apply the measures in reverse order.

Safety information
2.3 Qualified personnel
Standard motors SH 63 ... 355
12 Operating Instructions, 12/2018, A5E38483075A
2.3 Qualified personnel
All work at the machine must be carried out by qualified personnel only. For the purpose of
this documentation, qualified personnel is taken to mean people who fulfill the following
requirements:
●Through appropriate training and experience, they are able to recognize and avoid risks
and potential dangers in their particular field of activity.
●They have been instructed to carry out work on the machine by the appropriate person
responsible.
2.4 Safe handling
Workplace safety depends on the attentiveness, care, and common sense of the personnel
who install, operate, and maintain the machine. In addition to the safety measures cited, as a
matter of principle, the use of caution is necessary when you are near the machine. Always
pay attention to your safety.
Also observe the following to prevent accidents:
●General safety regulations applicable in the country where the machine is deployed.
●Manufacturer-specific and application-specific regulations
●Special agreements made with the operator
●Separate safety instructions supplied with the machine
●Safety symbols and instructions on the machine and its packaging
Danger as a result of stationary parts under voltage (live parts)
Live parts represent a hazard. Touch protection against active (live) parts is no longer
guaranteed if covers are removed. The minimum clearance and creepage distances may be
violated when coming close to live parts. Touching or coming close to them can result in
death, serious injury or material damage.
●Ensure that all live parts are suitably covered.
●Switch off and disconnect the machine first if you want to remove covers. Observe the "5
safety rules" (Page 11).
Risk of injury due to rotating parts
Rotating parts are dangerous. Touch protection against rotating parts is no longer
guaranteed if covers are removed. Touching rotating parts can result in death, serious injury
or material damage.
●Ensure that all rotating parts are reliably covered.
●Switch off and disconnect the machine first if you want to remove covers. Observe the "5
safety rules" (Page 11).
●Only remove covers when the rotating parts have come to a complete standstill.

Safety information
2.4 Safe handling
Standard motors SH 63 ... 355
Operating Instructions, 12/2018, A5E38483075A 13
Risk of burns due to hot surfaces
Individual machine parts can become hot in operation. Burns can result when coming into
contact with these parts.
●Never touch machine parts during operation.
●Allow the machine to cool before starting work on the machine.
●Check the temperature of parts before touching them. If required, wear suitable protective
equipment.
Health hazard due to chemical substances
Chemical substances required for the setup, operation and maintenance of machines can
present a health risk.
●Observe the product information provided by the manufacturer.
Flammable substances hazard
Chemical substances required for the setup, operation and maintenance of machines may
be flammable. These substances can ignite if handled incorrectly. They can cause burns and
property damage.
●Observe the product information provided by the manufacturer.
Noise emissions
During operation, the machine's noise emission levels can exceed those permitted at the
workplace, which can cause hearing damage.
●Ensure that nobody is in the area of increased noise emissions during machine operation.
●Take steps to reduce noise so that the machine can be operated safely within your
system. The following measures may help to reduce noise.
–Covers
–Noise insulation
–Hearing protection measures
Prevention of hearing damage
If the permissible sound pressure level is exceeded, hearing damage can occur when
operating three-phase motors at their rated power.
Observe the permissible sound pressure level in accordance with ISO 1680. The maximum
permissible sound pressure level is 70 dB (A).
Electrical power equipment generate electromagnetic fields during operation. Potentially
lethal malfunctions can occur in medical implants, e.g. pacemakers, in the vicinity of
electrical power equipment. Data may be lost on magnetic or electronic data carriers.
●Protect the personnel working in the plant by taking appropriate measures, such as
erecting identifying markings, safety barriers and warning signs and giving safety talks.
●Observe the nationally applicable health and safety regulations.

Safety information
2.5 Electrostatic sensitive devices
Standard motors SH 63 ... 355
14 Operating Instructions, 12/2018, A5E38483075A
●It is forbidden for people with pacemakers to be close to the machine.
●Do not carry any magnetic or electronic data media.
2.5 Electrostatic sensitive devices
Material damage due to electrostatic discharge
Electronic modules contain components that can be destroyed by electrostatic discharge.
These components can be damaged or destroyed if they are not handled correctly. To
protect equipment against damage, follow the instructions given below.
●Only touch electronic modules if you absolutely have to work on them.
●The body of the person concerned must have been electrostatically discharged and
grounded immediately before any electronic modules are touched.
●Electronic modules should not be brought into contact with electrically insulating
materials, such as:
–Plastic film
–Plastic parts
–Insulating table supports
–Clothing made of synthetic fibers
●Always place electrostatic sensitive devices on conductive bases.
●Always pack, store and transport electronic modules or components in conductive
packaging, such as:
–Metallized plastic or metal containers
–Conductive foam material
–Domestic aluminum foil
The necessary ESD protective measures for electrostatic sensitive devices are illustrated
once again in the following drawings:
a = conductive floor sur-
face
b = ESD table
c = ESD shoes
d = ESD overall
e = ESD wristband
f = cabinet ground connection

Safety information
2.6 Interference immunity
Standard motors SH 63 ... 355
Operating Instructions, 12/2018, A5E38483075A 15
Electromagnetic compatibility
This machine is designed in accordance with IEC/EN 60034, and when used as prescribed it
satisfies the requirements of European Directive 2014/30/EU on Electromagnetic
Compatibility.
2.6 Interference immunity
By selecting suitable signal cables and evaluation units, ensure that the interference
immunity of the machine is not diminished.
2.7 Influence on the line power supply through a strongly irregular
torque
A strongly irregular torque, for example with the drive of a reciprocating motor, forces a non-
sinusoidal motor current. The emerging harmonics can have an impermissible influence on
the line power supply via the connection lines.
2.8 Interference voltages when operating the converter
Interference voltages when operating the converter
When a converter is in operation, the emitted interference varies in strength depending on
the converter (manufacturer, type, interference suppression measures undertaken). On
machines with integrated sensors (e.g. PTC thermistors), interference voltages caused by
the converter may occur on the sensor lead. This can cause faults which can result in
eventual or immediate death, serious injury or material damage.
●Comply with the EMC information provided by the manufacturer of the converter. This is
how you prevent the limit values stipulated by IEC/EN 61000-6-3 for the drive system
(consisting of the machine and converter) from being exceeded.
●You must put appropriate EMC measures in place.
2.9 Special designs and construction versions
Note
Before carry out any work on the machine, determine the machine version.
If there are any deviations or uncertainty, contact the manufacturer, specifying the type
designation and serial number (see th
e rating plate), or contact the Service Center.

Safety information
2.9 Special designs and construction versions
Standard motors SH 63 ... 355
16 Operating Instructions, 12/2018, A5E38483075A

Standard motors SH 63 ... 355
Operating Instructions, 12/2018, A5E38483075A 17
Description
3
3.1 Area of application
The rotating electrical motors of this series are used as industrial drives. They are designed
for a wide range of drive applications both for line operation as well as in conjunction with
frequency converters.
They are characterized by their high power density, extreme robustness, long service life
and outstanding reliability.
Intended use of the machines
These machines are intended for industrial installations. They comply with the harmonized
standards of the series EN / IEC 60034 (VDE 0530). It is prohibited to use these motors in
hazardous zones if the marking on the motor rating plate does not explicitly permit line or
converter operation. If other/more wide-ranging demands (e.g. protection so that they cannot
be touched by children) are made in special cases – i.e. use in non-industrial installations –
these conditions must be ensured by the customer.
Note
Machine directive
Low
-voltage motors are components designed for installation in machines in accordance
with the current Machinery Directive. Commissioning is prohibited until it has been absolutely
identified that the end product is in conformance with this Directive. Please observe the
EN
/ IEC 60204-1 standard.
Use of machines without CE marking
Machines without CE marking are intended for operation outside the European Economic
Area (EEA). Do not use any machines without a CE marking in the EEA!
Note
IE2 marking
Since January 1, 2017, according to REGULATION (EC) No. 640/2009, low
-voltage motors
with power ratings above 0.75
kW up to 375 kW – and with efficiency IE2 – have this label.
This is mandatory within the European Economic Area (EEA). Customers ar
e solely
responsible in ensuring the correct use.
When connecting the machine to a converter, carefully observe the rules and notes in
Chapter "Connecting a converter."

Description
3.1 Area of application
Standard motors SH 63 ... 355
18 Operating Instructions, 12/2018, A5E38483075A
Use of machines without EAC marking
EAC machines are appropriately marked on the rating plate, and are intended for operation
within the Eurasian customs union.
Within the Eurasian customs union, do not use machines without the appropriate EAC
marking.
WARNING
Risk of explosion
This machine is not designed for use in hazardous areas. An explosion can occur if the
machine is operated in these areas. This can result in death, serious injury or material
damage.
•
Never
operate this machine in hazardous areas.
Operating a machine with a converter
Implement all machines of the overall machine-converter system according to UL-File
E227215 assuming that the machines are only to be operated with a converter and are
supplied with UL certificate.
The company operating the equipment is responsible for implementing this in the actual
application.
