Siemens FT2040 Instruction Manual

Operation (short) MP 2.1
FC20xx Fire control panel
FT2040 Fire terminal
ALARM-Procedure Page 1
Switching off detector zones / detectors Page 2
Switching on detector zones / detectors Page 4
Procedure in case of Fault Page 4
Document ID: 009906_d_en_GB Edition: 05.2009 1 of 4
ALARM Procedure
with Alarm Verification Concept (AVC), suggested possible procedure, subject to local requirements
Action / Condition Consequence / Status
1.
Press <Acknowledge> on the PMI before allowed
response time (t1) runs out (Password required)
Buzzer is turned off, alarm is acknowledged.
Countdown t2 for the investigation of the cause of alarm starts.
2.
Read top line on display:
"Fire brigade in" "mm:ss"
Remaining time is shown as countdown before building
evacuation and Fire Brigade call.
3.
Read fire location on display.
4.
Go to the fire location. Information on the cause of ALARM,
damage limitation.
5.
Decide: MAJOR INCIDENT or minor incident. If required, initiation of suitable emergency measures.
6.
MAJOR INCIDENT:
A
Press <Alarm delay off>
or actuate nearest manual call point.
Read top line on display:
●"Remote transmission activated"
●"Fire brigade called !"
●"Call fire brigade !"
Remote transmission switched off / not available or
defective.
The remote transmission for fire alarm is activated
immediately.
●Transmission to fire brigade not confirmed yet.
●ALARM transmitted to fire brigade.
●Fire brigade must be called by phone!
No automatic transmission to fire brigade.
Dial the following no.:
Minor incident:
R
Press <Reset>.
(Password required)
Fire detection system is in normal condition unless another event
occurs.
It may be necessary to vent the room before resetting is possible.
Elements that cannot be reset can be switched off temporarily.
7.
During the alarm, optionally press
<Sounders Evacuate> on the PMI.
(Password required)
Deactivates the acoustic alarm devices during the alarm.
(Reactivation is possible by pressing the button again)
1 2 3
4 5 6
7 8 9
*0 #
Cok
abc
~
ghi
j
klm
no
p
qrs
tuv
w
x
y
z
de
f
ALARM
FAUL
T
ISOLATION
DETECTOR TES
T
System
On
Fault
Scroll alarms
Remote alarm
Active
Fault / Off
Sounders
Fault / Off
Active Evacuate
Silence buzzer
Acknowledge
Reset
Alarm delay off
Premises manned
Fire brigade in
001 ALARM
Autom. FIRE ALARM Zone no.2
Execute
Commands More Options
Fx20x
x
Control function
Fault / Of
Active
7.
A
2.
1. R6.
5
.
4. Go to fire location
Decide
00:02:51
Switch to
Standard view
3.
Main Building
Ground Floor
1/01 Meeting Room 001
00:02:51

Document ID: 009906_d_en_GB Edition: 05.2009 2 of 4
Switching off detector zones / detectors
The following example represents a possible operation sequence:
DANGER System parts that have been switched off make it impossible to detect fires or
faults!
⇒Fire may spread unhindered.
⇒The area that has been switched off must be manually supervised.
⇒System parts that have been switched off must be switched back on as soon as possible.
Switching off a detector zone (password required)
Step Result
1. Press the button to open the main menu.
(Password required)
⇒Main menu
Exit with <C> Access level 2.1
Message summary
Functions
Favorites
Topology
(1)
(2)
(3)
(4)
Element search
Event memory
Log in / logout
Settings / administration
(5)
(6)
(7)
(8)
Function
On/Off
Function
All
LED
Test
2. Press <2> to open the menu item "Functions".
Note:
The numbers in brackets (1)… can be entered
with the numeric keys <1>… below the main
menu button.
⇒Functions
Exit with <C>
Access level 2.1
On / Off
Test
Activate / deactivate
Information
(1)
(2)
(3)
(4)
Configuration
Maintenance
All functions
(5)
(6)
(7)
Function
On/Off
Function
All
LED
Test
3. Press <1> "On/Off".
⇒
Select element category
Zone
Area
Section
Detector
RT control
(1)
(2)
(3)
(4)
(5)
4. Press <3> "Section".
Note:
A British Standard zone is called a Section in this
system’s.
⇒
Enter address
Zone no ---------
Confirm with <ok> / Exit with <C>
Delete with <Cursor up>
5. Enter a zone number, if known, or press <ok>
without entering a number.
Note:
The example shows the result, after confirmation
with <ok> without entering an address.
⇒
004 Sections
Second Floor
First Floor
Ground Floor
Basement
Zone no 4
Zone no 3
Zone no 2
Zone no 1
Execute
command
Show
Topology
6.
Scroll with the navigation buttons to the
zone you want to switch off.
The selected zone is marked by a frame.
Press <Softkey 1> "Execute command".
⇒
Select command
All zones OFF
MCP zones OFF
Non-MCP zones OFF
(4)
(5)
(6)
7. Press <4>, <5> or <6> according to the zone
types required to be switched off.
⇒⇒Command response confirms the execution.
⇒The zone has been switched off.
⇒The LED "ISOLATION" is on.

Document ID: 009906_d_en_GB Edition: 05.2009 3 of 4
Switching off a detector (Password required)
Step Result
1. Press the button to open the main menu.
(Password required)
⇒Main menu
Exit with <C>
Access level 2.1
Message summary
Functions
Favorites
Topology
(1)
(2)
(3)
(4)
Element search
Event memory
Logout / change level
Settings / administration
(5)
(6)
(7)
(8)
Function
On/Off
Function
All
LED
Test
2. Press <4> to open the menu item "Topology".
Note:
The numbers in brackets (1)… can be entered
with the numeric keys <1>… below the main
menu button.
⇒
Topology
Exit with <C>
Access level 2.1
Detection tree
Hardware tree
Control tree
(1)
(2)
(3)
Function
On/Off
Function
All
LED
Test
3. Press <1> "Detection tree".
Scroll with the navigation buttons to the
area within which is the detector that you want to
switch off.
The selected area is marked by a frame.
⇒
002 Items Detection tree
Main Building
Annex Building
Area
Area
Lower
level
Execute
commands
4. Press Softkey <2> "Lower level".
Scroll with the navigation buttons to the
section within which is the detector that you want
to switch off.
The selected section is marked by a frame.
Note:
As an alternative to switching off a zone (page 2)
executing commands at this point will then lead to
the menu item to switch a whole zone of detectors
off.
⇒
004 Items Area
Main Building
Second Floor
First Floor
Ground Floor
Basement
Zone no 4
Zone no 3
Zone no 2
Zone no 1
Upper
level
Lower
level
Execute
commands
5. Press Softkey <2> “Lower level".
Scroll with the navigation buttons to the
zone (=detector in this system’s terminology) you
want to switch off.
The selected detector is marked by a frame.
⇒
005 Items Zone no 2
Ground Floor
1/01 Reception hall Zone no 2
1/02 Corridor MCP Zone no 2
1/03 Storage room Zone no 2
1/04 Meeting room Zone no 2
Upper
level
Lower
level
Execute
commands
6. Select a detector and press Softkey <3> Execute
commands".
⇒
Select command
OFF (2)
7. Press <2> "OFF" (switch off). ⇒⇒Command response confirms the execution.
⇒The detector is switched off.
⇒The LED "ISOLATION" is on.

Document ID: 009906_d_en_GB Edition: 05.2009 4 of 4
Switching on detector zones / detectors (Password required)
⇒When there is no event with a higher priority, isolations (switched off) are directly indicated on the display. You
may then directly proceed with Step 3 below.
⇒When all zones within a section (a zone is a detector in this system’s terminology) are turned off, the section is
additionally indicated as switched off.
⇒
Detectors that still contain smoke or test gas cannot be switched back on.
Step Result
1. Press the button to open the main menu.
(password required)
Press <1> "Message summary".
⇒Message summary
Exit with <C>
Access level 2.1
002
003
Isolations
Information
(4)
(8)
Function
On/Off
Function
All
LED
Test
2. Press <4> "Isolations". ⇒2007-10-10 15:14:36
002 Isolations
OFF
1/01 Reception
OFF
Ground Floor
Zone no 2
Zone no 2
001
002
Execute
command
Switch to
extended view
More
options
3.
Scroll with the navigation buttons to the
isolation (detector e.g. Reception, or zone
e.g.Ground Floor) you want to switch on.
The selected isolation is marked by a frame.
Press Softkey <1> "Execute command”.
⇒
Select command
ON (1)
4. Press <1> "ON". ⇒⇒Command response confirms the execution.
⇒Detector or zone switched on.
⇒LED "ISOLATION" is off, provided that there is no other
isolation.
Procedure in case of Fault
Step Result
1. Press <Silence buzzer> on the PMI. ⇒Buzzer on the station switched off.
2. Read message/fault location on the display. ⇒Information on type and place of the fault.
3. Press <Acknowledge> on the PMI.
4. Go to the fault location and remedy the cause
of the fault.
⇒The fault will clear automatically from the station.
If you cannot eliminate a fault, please contact your service provider.

Operation (short) MP 2.1
FC20xx Fire control panel
FT2040 Fire terminal
ALARM-Procedure Page 1
Switching off detector zones / detectors Page 2
Switching on detector zones / detectors Page 4
Procedure in case of Fault Page 4
Document ID: 009906_d_en_GB Edition: 05.2009 1 of 4
ALARM Procedure
no Alarm Verification Concept (AVC), suggested possible procedure, subject to local requirements
Action / Condition Consequence / Status
1.
Press <Acknowledge> on the PMI.
(Password required) Buzzer is turned off, alarm is acknowledged.
2.
Read top line on display
●"Remote transmission activated"
●"Fire brigade called"
●"Call fire brigade!"
– Remote transmission switched off / not available
or defective
●Transmission to fire brigade not confirmed yet.
●ALARM transmitted to fire brigade.
●Fire brigade must be called by phone!
No automatic transmission to fire brigade
Dial the following no.:
3.
Read fire location on display.
4.
Go to fire location. Information on the cause of ALARM; if required, initiate required
emergency measures and damage limitation.
5.
In case of a minor incident:
R
Press
<Reset>.
(Password required)
Fire detection system is in normal condition unless another event
occurs.
It may be necessary to vent the room before resetting is possible.
Elements that cannot be reset can be switched off temporarily.
6.
During the alarm, optionally press
< Sounders Evacuate > on the PMI.
(Password required)
Deactivates the acoustic alarm devices.
(Reactivation is possible by pressing the button again.)
1 2 3
4 5 6
7 8 9
*0 #
Cok
abc
~
ghi
j
klm
no
p
qrs
tuv
w
x
y
z
de
f
ALARM
Fx20x
x
6.
2.
1. R
4. Go to fire location
5.
3.
Execute
Commands More
Options
S
witch to
Standard view
FAUL
T
ISOLATION
DETECTOR TES
T
System
On
Fault
Scroll alarms
Remote alarm
Active
Fault / Off
Sounders
Fault / Off
Active
Silence buzzer
Acknowledge
Reset
Alarm delay off
Premises manned
Control function
Fault / Of
Active
Call Fire Brigade!
001 ALARM
Autom. FIRE ALARM Zone no.2
Main Building
Ground Floor
1/01 Meeting Room 001

Document ID: 009906_d_en_GB Edition: 05.2009 2 of 4
Switching off detector zones / detectors
The following example represents a possible operation sequence:
DANGER System parts that have been switched off make it impossible to detect fires or
faults!
⇒Fire may spread unhindered.
⇒The area that has been switched off must be manually supervised.
⇒System parts that have been switched off must be switched back on as soon as possible.
Switching off a detector zone (password required)
Step Result
1. Press the button to open the main menu.
(Password required)
⇒Main menu
Exit with <C> Access level 2.1
Message summary
Functions
Favorites
Topology
(1)
(2)
(3)
(4)
Element search
Event memory
Log in / logout
Settings / administration
(5)
(6)
(7)
(8)
Function
On/Off
Function
All
LED
Test
2. Press <2> to open the menu item "Functions".
Note:
The numbers in brackets (1)… can be entered
with the numeric keys <1>… below the main
menu button.
⇒Functions
Exit with <C>
Access level 2.1
On / Off
Test
Activate / deactivate
Information
(1)
(2)
(3)
(4)
Configuration
Maintenance
All functions
(5)
(6)
(7)
Function
On/Off
Function
All
LED
Test
3. Press <1> "On/Off".
⇒
Select element category
Zone
Area
Section
Detector
RT control
(1)
(2)
(3)
(4)
(5)
4. Press <3> "Section".
Note:
A British Standard zone is called a Section in this
system’s terminology.
⇒
Enter address
Zone no ---------
Confirm with <ok> / Exit with <C>
Delete with <Cursor up>
5. Enter a zone number, if known, or press <ok>
without entering a number.
Note:
The example shows the result, after confirmation
with <ok> without entering an address.
⇒
004 Sections
Second Floor
First Floor
Ground Floor
Basement
Zone no 4
Zone no 3
Zone no 2
Zone no 1
Execute
command
Show
Topology
6.
Scroll with the navigation buttons to the
zone you want to switch off.
The selected zone is marked by a frame.
Press <Softkey 1> "Execute command".
⇒
Select command
All zones OFF
MCP zones OFF
Non-MCP zones OFF
(4)
(5)
(6)
7. Press <4>, <5> or <6> according to the zone
types required to be switched off.
⇒⇒Command response confirms the execution.
⇒The zone has been switched off.
⇒The LED "ISOLATION" is on.

Document ID: 009906_d_en_GB Edition: 05.2009 3 of 4
Switching off a detector (Password required)
Step Result
1. Press the button to open the main menu.
(Password required)
⇒Main menu
Exit with <C>
Access level 2.1
Message summary
Functions
Favorites
Topology
(1)
(2)
(3)
(4)
Element search
Event memory
Logout / change level
Settings / administration
(5)
(6)
(7)
(8)
Function
On/Off
Function
All
LED
Test
2. Press <4> to open the menu item "Topology".
Note:
The numbers in brackets (1)… can be entered
with the numeric keys <1>… below the main
menu button.
⇒
Topology
Exit with <C>
Access level 2.1
Detection tree
Hardware tree
Control tree
(1)
(2)
(3)
Function
On/Off
Function
All
LED
Test
3. Press <1> "Detection tree".
Scroll with the navigation buttons to the
area within which is the detector that you want to
switch off.
The selected area is marked by a frame.
⇒
002 Items Detection tree
Main Building
Annex Building
Area
Area
Lower
level
Execute
commands
4. Press Softkey <2> "Lower level".
Scroll with the navigation buttons to the
section within which is the detector that you want
to switch off.
The selected section is marked by a frame.
Note:
As an alternative to switching off a zone (page 2)
executing commands at this point will then lead to
the menu item to switch a whole zone of detectors
off.
⇒
004 Items Area
Main Building
Second Floor
First Floor
Ground Floor
Basement
Zone no 4
Zone no 3
Zone no 2
Zone no 1
Upper
level
Lower
level
Execute
commands
5. Press Softkey <2> “Lower level".
Scroll with the navigation buttons to the
zone (=detector in this system’s terminology) you
want to switch off.
The selected detector is marked by a frame.
⇒
005 Items Zone no 2
Ground Floor
1/01 Reception hall Zone no 2
1/02 Corridor MCP Zone no 2
1/03 Storage room Zone no 2
1/04 Meeting room Zone no 2
Upper
level
Lower
level
Execute
commands
6. Select a detector and press Softkey <3> Execute
commands".
⇒
Select command
OFF (2)
7. Press <2> "OFF" (switch off). ⇒⇒Command response confirms the execution.
⇒The detector is switched off.
⇒The LED "ISOLATION" is on.

Document ID: 009906_d_en_GB Edition: 05.2009 4 of 4
Switching on detector zones / detectors (Password required)
⇒When there is no event with a higher priority, isolations (switched off) are directly indicated on the display. You
may then directly proceed with Step 3 below.
⇒When all zones (a zone is a detector in this system’s terminology) are turned off, the section is additionally
indicated as switched off.
⇒
Detectors that still contain smoke or test gas cannot be switched back on.
Step Result
1. Press the button to open the main menu.
(password required)
Press <1> "Message summary".
⇒Message summary
Exit with <C>
Access level 2.1
002
003
Isolations
Information
(4)
(8)
Function
On/Off
Function
All
LED
Test
2. Press <4> "Isolations". ⇒2007-10-10 15:14:36
002 Isolations
OFF
1/01 Reception
OFF
Ground Floor
Zone no 2
Zone no 2
001
002
Execute
command
Switch to
extended view
More
options
3.
Scroll with the navigation buttons to the
isolation (detector e.g. Reception, or zone
e.g.Ground Floor) you want to switch on.
The selected isolation is marked by a frame.
Press Softkey <1> "Execute command”.
⇒
Select command
ON (1)
4. Press <1> "ON". ⇒⇒Command response confirms the execution.
⇒Detector or zone switched on.
⇒LED "ISOLATION" is off, provided that there is no other
isolation.
Procedure in case of Fault
Step Result
1. Press <Silence buzzer> on the PMI. ⇒Buzzer on the station switched off.
2. Read message/fault location on the display. ⇒Information on type and place of the fault.
3. Press <Acknowledge> on the PMI.
4. Go to the fault location and remedy the cause
of the fault.
⇒The fault will clear automatically from the station.
If you cannot eliminate a fault, please contact your service provider.
