Siemens LITHOSTAR Multiline Guide

LITHOSTAR Multiline
English
Print No.: RXL2-120.072.03.04.02 Doc. Gen. Date: 06.02
Replaces: RXL2-120.072.03.03.02
© Siemens AG 1996
The reproduction, transmission or
use of this document or its contents
is not permitted without express
written authority. Offenders will be
liable for damages. All rights,
including rights created by patent
grant or registration of a utility
model _or_design,_are_reserved.
SP
System
Errors by error codes
Troubleshooting Instructions

LITHOSTAR Multiline RXL2-120.072.03 Page 2 of 4 Siemens AG
System Rev. 04 06.02 CS PS 24 Medical Solutions
0 - 2 Revision level
Document revision level 0
The document corresponds to the version/revision level effective at the time of system delivery.
Revisions to hardcopy documentation are not automatically distributed.
Please contact your local Siemens office to order current revision levels.
Disclaimer 0
The installation and service of equipment described herein is to be performed by qualified personnel
who are employed by Siemens or one of its affiliates or who are otherwise authorized by Siemens or
one of its affiliates to provide such services.
Assemblers and other persons who are not employed by or otherwise directly affiliated with or autho-
rized by Siemens or one of its affiliates are directed to contact one of the local offices of Siemens or
one of its affiliates before attempting installation or service procedures.
Chapter Page Revision
all all 04

Contents 0 - 3
Siemens AG RXL2-120.072.03 Page 3 of 4 LITHOSTAR Multiline
Medical Solutions Rev. 04 06.02 CS PS 24 System
Document revision level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1 _______Motor controller D4a ____________________________________________ 1 -1
General errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 -1
ZR am1 (Lifting column right) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 -1
ZL am2 (Lifting column left) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 -1
W drive am3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 -2
O drive am4 (C-Arm) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 -2
Board errors, general . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 -2
2 _______Motor controller D4b____________________________________________ 2 -1
General errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 -1
X drive am5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 -1
Y drive am6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 -1
TVI Television iris am7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 -2
TL Cone drive, longitudinal, am8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 -2
TR Cone drive, rotation, am9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 -2
Board errors, general . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 -3
3 _______Communication controller D6 ____________________________________ 3 -1
Error displays of the collimator interface: . . . . . . . . . . . . . . . . . . . . . . . . 3 -1
Error displays of the operating master interface: . . . . . . . . . . . . . . . . . . . . 3 -1
Error displays of the image memory interface: . . . . . . . . . . . . . . . . . . . . . 3 -2
Error displays of the shock wave system interface: . . . . . . . . . . . . . . . . . . . 3 -2
Error displays of the brightness actual value interface: . . . . . . . . . . . . . . . . . 3 -2
Error displays of the ultrasound interface:. . . . . . . . . . . . . . . . . . . . . . . . 3 -3
4 _______CPU board D1 _________________________________________________ 4 -1
Overview and explanations of the unit drives . . . . . . . . . . . . . . . . . . . . . . 4 -1
Definition of the slave numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -2
General errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -3
Boot software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -5
Operating system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -6
Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -8
Shock Wave System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -14
General errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -16
Ultrasound. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -17
Collimator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -17
Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -18
Image memory errors received from MEMOSKOP . . . . . . . . . . . . . . . . . . 4 -19
Image memory errors received from Multiline. . . . . . . . . . . . . . . . . . . . . 4 -26
General errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -27
Page

0 - 4 Contents
LITHOSTAR Multiline RXL2-120.072.03 Page 4 of 4 Siemens AG
System Rev. 04 06.02 CS PS 24 Medical Solutions
Boot Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -27
Internal software errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -28
5 ______ Boot and error messages of the operating PC _______________________ 5 -1
Operating system errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 -1
Board D51 of the operating PC. . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 -2
AP - IDxx displays. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 -2
6 ______ XCS controller D2 ______________________________________________ 6 -1
7 ______ Error displays on D19 ___________________________________________ 7 -1
Overview of operating status displays . . . . . . . . . . . . . . . . . . . . . . . . . .7 -1
V7 (kVactual ¼kV nominal) / Board D1 display: 5382 . . . . . . . . . . . . . . . . .7 -2
Red LED V10 (kVactual > kVnominal) / Board D1 display: 5381 . . . . . . . . . . . .7 -3
Yellow LED V32 (discharge current too low) / Board D1 display:5282 . . . . . . . .7 -4
Yellow LED V33 (spontaneous ignition of the spark gap)
Board D1 Display: 5281 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 -4
Yellow LED V31 (discharge current too high) Board D1 display: 5383. . . . . . . .7 -5
8 ______ Error displays on D91 ___________________________________________ 8 -1
Overview of operating status displays . . . . . . . . . . . . . . . . . . . . . . . . . .8 -1
Red LED V4 (kVactual not equal to kVnominal) / Board D1 display: 5391 . . . . . . .8 -2
Yellow LED V20 (charging time exceeded Board D1 display: 5391 . . . . . . . . .8 -3
9 ______ Errors without error numbers_____________________________________ 9 -1
10 _____ Changes as compared to previous version ________________________ 10 -1
Page

1 - 1
Siemens AG RXL2-120.072.03 Page 1 of 2 LITHOSTAR Multiline
Medical Solutions Rev. 04 06.02 CS PS 24 System
Motor controller D4a 1
General errors 1
Error number
ZR am1 (Lifting column right) 1
Error number
ZL am2 (Lifting column left) 1
Error number
↓Meaning:
01 PROM_error
02 INT_RAM_error
03 EXT_RAM_error
04 TIMER_0_error
05 TIMER_1_error
06 KERN_TEST_error
07 SFR_error
09 WATCHDOG_error
↓Meaning:
10 LM_628_error
11 Control_error
12 Position accuracy not reached in stated stabilizing time
13 Motor not initialized, drive command received
14 Motor moves without actuation
15 Motor does not move when actuated
16 Speed not reached or exceeded
17 Motor moves in wrong direction
18 Motor unsuccessfully actuated three times
19 Faulty initialization of the ASIC
↓Meaning:
20 LM_628_error
21 Control_error
22 Position accuracy not reached in stated stabilizing time
23 Motor not initialized, drive command received
24 Motor moves without actuation
25 Motor does not move when actuated
26 Speed not reached or exceeded
27 Motor moves in wrong direction
28 Motor actuated unsuccessfully three times
29 Faulty initialization of the ASIC

LITHOSTAR Multiline RXL2-120.072.03 Page 2 of 2 Siemens AG
System Rev. 04 06.02 CS PS 24 Medical Solutions
1 - 2 Motor controller D4a
W drive am3 1
Error number
O drive am4 (C-Arm) 1
Error number:
Board errors, general 1
Error number:
↓Meaning:
30 LM_628_error
31 Control_error
32 Position accuracy not reached in stated stabilizing time
33 Motor not initialized, drive command received
34 Motor moves without actuation
35 Motor does not move when actuated
36 Speed not reached or exceeded
37 Motor moves in wrong direction
38 Motor unsuccessfully actuated three times
39 Faulty initialization of the ASIC
↓Meaning:
40 LM_628_error
41 Control_error
42 Position accuracy not reached in stated stabilizing time
43 Motor not initialized, drive command received
44 Motor moves without actuation
45 Motor does not move when actuated
46 Speed not reached or exceeded
47 Motor moves in wrong direction
48 Motor unsuccessfully actuated three times
49 Faulty initialization of the ASIC
↓Meaning:
60 No first contact with HOST
61 TIMEOUT, data exchange disrupted
62 CHECKSUM_error

2 - 1
Siemens AG RXL2-120.072.03 Page 1 of 4 LITHOSTAR Multiline
Medical Solutions Rev. 04 06.02 CS PS 24 System
Motor controller D4b 2
General errors 2
Error number
X drive am5 2
Error number
Y drive am6 2
Error number
↓Meaning:
01 PROM_error
02 INT_RAM_error
03 EXT_RAM_error
04 TIMER_0_error
05 TIMER_1_error
06 KERN_TEST_error
07 SFR_error
09 WATCHDOG_error
↓Meaning:
10 LM_628_error
11 Control_error
12 Position accuracy not reached in stated stabilizing time
13 Motor not initialized, drive command received
14 Motor moves without actuation
15 Motor does not move when actuated
16 Speed not reached or exceeded
17 Motor moves in wrong direction
18 Motor actuated unsuccessfully three times
19 Faulty initialization of the ASIC
↓Meaning:
20 LM_628_error
21 Control_error
22 Position accuracy not reached in stated stabilizing time
23 Motor not initialized, drive command received
24 Motor moves without actuation
25 Motor does not move when actuated
26 Speed not reached or exceeded
27 Motor moves in wrong direction
28 Motor actuated unsuccessfully three times
29 Faulty initialization of the ASIC

LITHOSTAR Multiline RXL2-120.072.03 Page 2 of 4 Siemens AG
System Rev. 04 06.02 CS PS 24 Medical Solutions
2 - 2 Motor controller D4b
TVI Television iris am7 2
Error number
TL Cone drive, longitudinal, am8 2
Error number
TR Cone drive, rotation, am9 2
Error number
↓Meaning:
30 LM_628_error
31 Control_error
32 Position accuracy not reached in stated stabilizing time
33 Motor not initialized, drive command received
34 Motor moves without actuation
35 Motor does not move when actuated
36 Speed not reached or exceeded
37 Motor moves in wrong direction
38 Motor unsuccessfully actuated three times
39 Faulty initialization of the ASIC
↓Meaning:
40 LM_628_error
41 Control_error
42 Position accuracy not reached in stated stabilizing time
43 Motor not initialized, drive command received
44 Motor moves without actuation
45 Motor does not move when actuated
46 Speed not reached or exceeded
47 Motor moves in wrong direction
48 Motor unsuccessfully actuated three times
49 Faulty initialization of the ASIC
↓Meaning:
50 LM_628_error
51 Control_error
52 Position accuracy not reached in stated stabilizing time
53 Motor not initialized, drive command received
54 Motor moves without actuation
55 Motor does not move when actuated
56 Speed not reached or exceeded
57 Motor moves in wrong direction
58 Motor unsuccessfully actuated three times
59 Faulty initialization of the ASIC

Motor controller D4b 2 - 3
Siemens AG RXL2-120.072.03 Page 3 of 4 LITHOSTAR Multiline
Medical Solutions Rev. 04 06.02 CS PS 24 System
Board errors, general 2
Error number:
↓Meaning:
60 No first contact with HOST
61 TIMEOUT, data exchange disrupted
62 CHECKSUM_error

LITHOSTAR Multiline RXL2-120.072.03 Page 4 of 4 Siemens AG
System Rev. 04 06.02 CS PS 24 Medical Solutions
2 - 4 Motor controller D4b
This page intentionally left blank.

3 - 1
Siemens AG RXL2-120.072.03 Page 1 of 4 LITHOSTAR Multiline
Medical Solutions Rev. 04 06.02 CS PS 24 System
Communication controller D6 3
Error displays of the collimator interface: 3
Error displays of the operating master interface: 3
Code "55" is displayed when the system is operating without
errors.
Code "60" also appears if the system is not equipped with the
ultrasound option.
Error No. Meaning
10 No first contact to the HOST (status message)
11 Timeout error from the HOST
12 Fatal error in the data reception block from the HOST
13 Illegal data in the reception block
14 Illegal value in the data reception flag from the HOST
15 No first contact to collimator N
16 Collimator timeout error
17 Data reception error from collimator
18 Continuous communication error to collimator
19 Reception queue full
1A DPR reception area error
1B CAN module error
1C Invalid values in reception block
Error No.Meaning
20 No first contact to the HOST (status message)
21 Timeout error from the HOST
22 Fatal error in the data reception block from the HOST
23 Wrong block type in the data reception block from the HOST
24 Illegal value in the data reception flag from the HOST
25 No first contact to slaves (status message)
26 Slave timeout error
27 Data reception error from slave
28 Serial transmitter not free
2A DPR reception area error
7x Timeout slave no. x
8x Data reception error slave no. x
NOTICE

LITHOSTAR Multiline RXL2-120.072.03 Page 2 of 4 Siemens AG
System Rev. 04 06.02 CS PS 24 Medical Solutions
3 - 2 Communication controller D6
Error displays of the image memory interface: 3
Error displays of the shock wave system interface: 3
Error displays of the brightness actual value interface: 3
Error No.Meaning
30 No first contact to the HOST (status message)
31 Timeout error from the HOST
32 Fatal error in the data reception block from the HOST
33 Illegal data in the data reception block from the HOST
34 Illegal value in the data reception flag from the HOST
35 No first contact to the image memory (status message)
36 Image memory timeout error
37 Data reception error from image memory
38 Serial transmitter not free
3A Error in the DPR reception area
Error No.Meaning
40 No first contact to the HOST (status message), System not registered
41 Timeout error from the HOST
42 Fatal error in the data reception block from the HOST
43 Illegal data in the data reception block from the HOST
44 Illegal value in the data reception flag from the HOST
45 No first contact to the shock wave system (status message)
46 Shock wave system timeout error
47 Data reception error from shock wave system
48 Serial transmitter not free
4A Error in the DPR reception area
4E Respiratory trigger signal timeout
Error No. Meaning
50 No first contact to the HOST (status message)
51 Timeout error from the HOST
52 Fatal error in the data reception block from the HOST
53 Illegal data in the data reception block from the HOST
54 Illegal value in the data reception flag from the HOST
55 No first contact to the brightness actual value (status mes-
sage)
56 Timeout error from the brightness value actual value signal
device
57 Data reception error of brightness actual value
58 Serial transmitter not free
5A Error in the DPR reception area

Communication controller D6 3 - 3
Siemens AG RXL2-120.072.03 Page 3 of 4 LITHOSTAR Multiline
Medical Solutions Rev. 04 06.02 CS PS 24 System
Error displays of the ultrasound interface: 3
Error No. Meaning
60 No first contact to the HOST (status message)
61 Timeout error from the HOST
62 Fatal error in the data reception block from the HOST
63 Illegal data in the reception block from the HOST
64 Illegal value in the data reception flag from the HOST
65 No first contact to ultrasound system
66 Timeout error from ultrasound system
67 Error in block reception from ultrasound system
68 Error in block transmission to ultrasound system
69 Transmission buffer not empty (component)
6A Error in the DPR reception area

LITHOSTAR Multiline RXL2-120.072.03 Page 4 of 4 Siemens AG
System Rev. 04 06.02 CS PS 24 Medical Solutions
3 - 4 Communication controller D6
This page intentionally left blank.

4 - 1
Siemens AG RXL2-120.072.03 Page 1 of 28 LITHOSTAR Multiline
Medical Solutions Rev. 04 06.02 CS PS 24 System
CPU board D1 4
Overview and explanations of the unit drives 4
O = am4
ZR= am1
ZL= am2
W = am3
TVI = Television iris
on the television camera
TL = Cone longitudinal
TR = Cone rotation
SWO = Shock wave head, orbital
I.I. = Image intensifier lift
OCarm
Y Unit, longitudinal
X Unit, lateral
ZR, ZL Table, up
W Shockwave head
Y = am6
X = am5

LITHOSTAR Multiline RXL2-120.072.03 Page 2 of 28 Siemens AG
System Rev. 04 06.02 CS PS 24 Medical Solutions
4 - 2 CPU board D1
Definition of the slave numbers 4
Assigment: Slave no./Slave name
Errors in the error log are identified with a letter in addition to the error number.
Slave no. Slave name Abbreviation
0 PC-Board HBF
2 Tableside control panel on PC NBF
3 Memoskop image memory BS
4 Memoskop image memory BSHD BSHD
7 Tableside control panel 1 (basic unit) NBF
8 Footswitch NBFFT
9 Tableside control panel (Ultrasound unit) NBFUS
10 Shock Wave System SWS
Error messages in ERRO.LOG starting with FD... (Error text not
available) are internal error messages without any meaning for
field service.
E = Error
These errors can be cleared by the software during the next check.
F = Fatal Error
System operation is stopped. The error may be cleared by resetting the system
(switching the system ON/OFF).
W = Warning
System operation may continue without restrictions.
I = Information
These error numbers are for information only. They are not relevant to service.
NOTICE

CPU board D1 4 - 3
Siemens AG RXL2-120.072.03 Page 3 of 28 LITHOSTAR Multiline
Medical Solutions Rev. 04 06.02 CS PS 24 System
General errors 4
Error No. Error display on the service PC Meaning of the error
0001 Switch-on routine Switch-on routine: point in time at
which the unit was switched on.
Identifies associated errors and
required switch off/on proce-
dures.
0002 Service reset
0010 Contactors K1/K2 closed, no 27V present
0011 Contactor K3 closed, no 30V present no safety contactor closed?
0012 Contactors K1/K2 open, no 0V present
0013 Contactor K3 open, no 0V present
0020 Error: reference switch check / ZR am 1 Check the reference
switch
for errors 0020 to 002B
0021 Error: reference switch check / ZL am 2
0022 Error: reference switch check /W am 3
0023 Error: reference switch check /O am 4
0025 Error: reference switch check / X am 5
0026 Error: reference switch check / Y am 6
0028 Error: reference switch check / TL am 8
0029 Error: reference switch check / TR am 9
002A Error: reference switch check / SWO am 10
002B Error: reference switch check / I.I. am 11
0050 Emergency stop is operated Emergency stop active
0070 ADC time is exceeded / converter 1 Error on board D5
0071 ADC time is exceeded / converter 2 Error on board D5
0080 ADC value out of tolerance / channel 0 ZR Drive
0081 ADC value out of tolerance / channel 1 ZL Drive
0082 ADC value out of tolerance / channel 2 W Drive
0083 ADC value out of tolerance / channel 3 O Drive
0084 ADC value out of tolerance / channel 4 X Drive
0085 ADC value out of tolerance / channel 5 Y Drive
0086 ADC value out of tolerance / channel 6
0087 ADC value out of tolerance / channel 7
0088 ADC value out of tolerance / channel 8 TVI Drive
0089 ADC value out of tolerance / channel 9
008A ADC value out of tolerance / channel 10 TL Drive
008B ADC value out of tolerance / channel 11 TR Drive
008C ADC value out of tolerance / channel 12
008D ADC value out of tolerance / channel 13
008E ADC value out of tolerance / channel 14
008F ADC value out of tolerance / channel 15

LITHOSTAR Multiline RXL2-120.072.03 Page 4 of 28 Siemens AG
System Rev. 04 06.02 CS PS 24 Medical Solutions
4 - 4 CPU board D1
Error No. Error display on the service PC Meaning of the error
0090 ADC reference voltage out of tolerance 5.12V ±60mV
0091 24V ADC supply out of tolerance 24V 3V
0092 27V ADC supply out of tolerance 27V - 9V / + 13V
0093 30V ADC supply out of tolerance 3DV - 10V / + 9V
SS relay dropped out
0094 No signal of stopping potential
0F00 System is not initialized
The system is not initialized or the ROM version is wrong. The version num-
ber of the HOST software and the parameters in the EEPROM do not match
(the first two places).
If, however, the software is present, then parameters are missing or the ver-
sion numbers of the HOST software or the parameters in the EEPROM do
not match.
The error will be displayed after the download routine. Repeat the download
routine.

CPU board D1 4 - 5
Siemens AG RXL2-120.072.03 Page 5 of 28 LITHOSTAR Multiline
Medical Solutions Rev. 04 06.02 CS PS 24 System
Boot software 4
Error No. Error display on the
service PC Meaning of the error
1000 Flash - EEPROM is empty Download HOST software again
1003 Flash EEPROM checksum
error Incorrect checksum in the Flash EEPROMs. Download HOST software again.
1004 No access to clock Set the clock again and perform Reset. If the
error still exists, replace PC board D1.
1005 Clock is not initialized Set the clock again and perform Reset. If the
error still exists, replace PC board D1.
1009 Incorrect checksum
with block receipt Incorrect checksum when a block is received from the service PC/interface driver. The
problem is in the service PC or HOST. Inter-
ference during transmission.
100A Incorrect command
from Service PC Error in the data transmission between the service PC and the HOST. The service soft-
ware version and the boot software version
do not match. Compare with the compatibility
list in the logbook.
100B Incorrect block length
from Service PC Error in the data transmission between the service PC and the HOST. The service soft-
ware version and the boot software version
do not agree. Compare with the compatibility
list in the logbook.
100C Incorrect segment address
from Service PC Incorrect segment address from the service PC for writing on EPROM. Error in IDX file;
install the backup copy.
100D Parity error Error in the communication between the ser-
vice PC and the HOST. Hardware problem or
electromagnetic compatiblity (EMC) interfer-
ence.
If necessary, perform the transfer again.
100E Overrun error Receive buffer of the serial interface at the
service PC has been exceeded.
100F Framing error Error in the communication between the ser-
vice PC and the HOST.
Hardware problem or electromagnetic com-
patibility (EMC) interference.
If necessary, perform the transfer again.
1010 Break error Service PC was switched off before the serial
connection closed. This message is also dis-
played if hardware errors are present on
board D1.
1011 Timeout error
1012 Error: Switch S2.8
(D1) = On After three unsuccessful attempts to transfer, transmission between the HOST and the ser-
vice PC is terminated.

LITHOSTAR Multiline RXL2-120.072.03 Page 6 of 28 Siemens AG
System Rev. 04 06.02 CS PS 24 Medical Solutions
4 - 6 CPU board D1
Operating system 4
Error No. Error text displayed on the service PC
Meaning of the error
3YXX 3 = Op. system Y = Slave XX = error type
0 = Operating PC (HBF) keyboard + mouse
2 = Tableside control/control desk(NBF)
7 = Tableside control/unit (NBF)
8 = Footswitch (NBFFT)
9 = Ultrasound operating panel (BFUS)
3001 HBF timeout
3002 Receive error of D6 from HBF (D6 = Communication Controller)
3003 NAK error of HBF from D6 (NAK = no acknowledge)
3004 HBF Sent invalid block length
3005 HBF didn't respond ACK/NAK
3009 Serial Interface of D6 is faulty
3030 HBF: Data error from D1
3032 HBF FIFO overrun during transmission
3033 HBF FIFO overrun during reception
3040 PC doesn't react to transmission
3041 Reception timeout, PC does not transmit
3042 Timeout of First PC contact after 60s
3043 Invalid data from PC
3044 Checksum error from PC
3045 New init request from PC
3050 Data overrun ➝HBF data update
3051 HBF: Timeout to D6
3081 HBF: Watchdog hit
3083 No contact to PC
3201 NBF Timeout
3202 Reception error of D6 from NBF
3203 NAK error of NBF from D6 (NAK = no acknowledge)
3204 NBF Sent invalid block length
3205 NBF didn´t respond ACK/NAK
3209 Serial interface of D6 is faulty
3231 NBF: Data error from D1
3250 Data overrun
3251 NBF: Timeout to D6
3252 NBF: Keyboard buffer overflow
3260 NBF: Actuated or defective key NBF:Actuated or defective key
3281 NBF: Watchdog hit
3701 NBF Timeout
3702 Reception error of D6 from NBF
