Siemens SENTRON VL1250 User manual

805896A04
Bestell-Nr. / Order No.: 3ZX1012-0VL70-2LA1
Last update: 29 November 2022
s
3VL98008LC00
3VL98008LD00
for SENTRON
VL1250 - VL1600
Betriebsanleitung
Instruções de Serviço
Instructions de service
Инструкция по эксплуатации
Istruzioni operativeOperating Instructions
İşletme kılavuzu
Instructivo
使用说明
Deutsch English Français
Vor der Installation, dem Betrieb oder der
Wartung des Geräts muss diese
Anleitung gelesen und verstanden
werden.
Read and understand these
instructions before installing, operating,
or maintaining the equipment.
Gefährliche Spannung.
Lebensgefahr oder schwere
Verletzungsgefahr.
Vor Beginn der Arbeiten Anlage und
Gerät spannungsfrei schalten.
Hazardous voltage.
Will cause death or serious injury.
Turn off and lock out all power supplying
this device before working on this device.
Tension électrique.
Danger de mort ou risque de
blessures graves.
Mettre hors tension avant d’intervenir sur
l’appareil.
VORSICHT CAUTION PRUDENCE
Eine sichere Gerätefunktion ist nur mit
zertifizierten Komponenten gewährleistet.
Reliable functioning of the equipment is
only ensured with certified components.
GEFAHR
!DANGER !! DANGER
!
La sécurité de fonctionnement de
l'appareil n'est garantie qu'avec
des composants certifiés.
Español Italiano Português
Leer y comprender este instructivo antes
de la instalación, operación o
mantenimiento del equipo.
Leggere con attenzione queste istruzioni
prima di installare, utilizzare o eseguire
manutenzione su questa
apparecchiatura.
Tensión peligrosa.
Puede causar la muerte o lesiones graves.
Desconectar la alimentación eléctrica antes
de trabajar en el equipo.
Tensione pericolosa.
Può provocare morte o lesioni gravi.
Scollegare l’alimentazione prima di
eseguire interventi sull'apparecchiatura.
Tensão perigosa.
Perigo de morte ou ferimentos graves.
Desligue a alimentação elétrica e proteja
contra o religamento, antes de iniciar o
trabalho no equipamento.
PRECAUCIÓN CAUTELA CUIDADO
El funcionamiento seguro del aparato
sólo está garantizado con
componentes certificados.
Il funzionamento sicuro
dell'apparecchiatura è garantito
soltanto con componenti certificati.
PELIGRO
! ! PERICOLO !PERIGO
!
O funcionamento seguro do aparelho
apenas pode ser garantido se forem
utilizados os componentes certificados.
Türkçe Русский 中文
安装、使用和维修本设备前必须先
阅读并理解本说明。
Cihazın kurulumundan, çalıştırılmasından
veya bakıma tabi tutulmasından önce, bu
kılavuzun okunmuş ve anlaşılmış olması
gerekmektedir.
Перед установкой, вводом в
эксплуатацию или обслуживанием
устройства необходимо прочесть и
понять данное руководство.
Tehlikeli gerilim.
Ölüm tehlikesi veya ağır yaralanma
tehlikesi.
Çalışmalara başlamadan önce, sistemin ve
cihazın gerilim beslemesini kapatınız.
Опасное напряжение.
Опасность для жизни или
возможность тяжелых травм.
Перед началом работ отключить подачу
питания к установке и к устройству.
危险电压。
可能导致生命危险或重伤危险。
操作设备时必须确保切断电源。
ÖNEMLİ DİKKAT ОСТОРОЖНО 小心
Cihazın güvenli çalışması ancak
sertifikalı bileşenler kullanılması
halinde garanti edilebilir.
Безопасность работы устройства
гарантируется только при
использовании сертифицированных
компонентов.
TEHLİKE
! ! ОПАСНО !危险
!
只有使用经过认证的部件才能
保证设备的正常运转。
Ne pas installer, utiliser ou intervenir sur
cet équipement avant d'avoir lu et
assimilé les présentes instructions et
notamment les conseils de sécurité et
mises en garde qui y figurent.
Ler e compreender estas instruções
antes da instalação, operação ou
manutenção do equipamento.
SENTRON®VL
805896A04
Walking Beam - Verriegelung
Walking-Beam Interlock
Module d'interverouillage mécanique
Módulo de enclavamiento recíproco para interruptores
adyacentes Interblocco posteriore
Bloqueio Walking Beam
Walking-Beam Kilitleme Düzeni
Блокировка подвижной траверсы
步进梁互锁

2 3ZX1012-0VL70-2LA1
10 mm
Ø = 6.5 mm
Ø = 7.1 mm
Ø = 7.5 mm
10 mm
3VL98008LC00
3VL98008LD00
77-3232001-3M-0027
77 – ddd yyyy – 3M - aaaa
x
311
326 334
321
NOV. 2001
329
305
317
324
322 = Nov. 18, 2001 / 18.11.2001
323 = Nov. 19, 2001 / 19.11.2001
VL1600
VL1600
3P
4P 3VL8716 _ AA44 0AA0
3VL8716 _ AA34 0AA0 2001
≥323
OK ≤322
OK
2001
OK ≤322
OK ≥323
VL1250
VL1250
3P
4P 3VL7710_AA34 0AA0
3VL7712_AA34 0AA0
323 2001 ≥
OK ≤322
OK
2001
OK ≤322
OK ≥323
3VL7710_AA34 0AA0
3VL7712_AA34 0AA0
77-3512001-3M-0027
3VL7712-1AA34-0AA0

1
22a 2c
O / OFF
3VL98008LD00
clic
3VL98003M_00
3ZX10120VL112LA1
8 / 12 -10 / 12
3 / 12 - 7 / 12
3VL98008LC00
2b
TEST 11 / 12 -12 / 12
3
3ZX1012-0VL70-2LA1

3VL98008LC00
REAR CONNECT VL1250 (3 POLE)
REAR CONNECT VL1250 (4 POLE)
Supplied by Customer:
Supplied by Customer:
43ZX1012-0VL70-2LA1

3VL98008LC00
Supplied by Customer:
Supplied by Customer:
5
3ZX1012-0VL70-2LA1

3VL98008LC00
Supplied by Customer:
Supplied by Customer:
70.2
78.5 78.5
78.5
78.5
78.5
9 X Ø 7.5
70.2
63ZX1012-0VL70-2LA1

33VL98008LC00
5
4
6
Supplied by Customer:
3 Nm
32
26
10
3 Nm
2
1
3 / 12 - 5 / 10
3 -Pole
4 -Pole
0 / OFF
1.2 Nm
4.0 Nm
7
3ZX1012-0VL70-2LA1

3VL98008LC00 – 3 Pole
3VL98008LC00 – 3 Pole
3VL98008LC00 – 4 Pole
OK
83ZX1012-0VL70-2LA1

3VL98008LD00 (3+ 4 pole)
VL1250 / VL1600 Drawout
Front & Rear Connect
Supplied by Customer:
1200 N
9
3ZX1012-0VL70-2LA1

3VL98008LD00
4
3
Supplied by Customer:
5
3 Nm
25.4 X 25.4 X 775 mm Min.
25.4
25.4
3
Min.
Min. Min.
257.1
3 Nm
10 3ZX1012-0VL70-2LA1

67
89
OK
OK OK
OK
I / ON
0 / OFF
11
3ZX1012-0VL70-2LA1

O / OFF
I / ON
10
11 TEST:
AB
1X
OK
OFF
OFF ON
1XOKOFFOFF
11-c
1XOKOFF ONOFF
11-d
11-e
5XmOKOFF ON
ON
11-a
11-b 5XOKONOFF ON
BA
20.0 Nm
100 N
B
C
AB C
100 N
0 / OFF
I / ON
A
23ZX1012-0VL70-2LA1

OK Step 17
12 TEST: =
T
OK Step 14
13 TEST: =
T
17
