Siemens SIMATIC NET SCALANCE LPE9413 User manual

SIMATIC NET
Network components
SCALANCE LPE9413 Industrial
Edge Device
Operating Instructions
07/2023
C79000-G8976-C703-01
Introduction 1
Security information 2
Security recommendations 3
Device description 4
Installation and removal 5
Connecting up 6
Maintenance and cleaning 7
Troubleshooting 8
Technical speci󹪝cations 9
Dimension drawings 10
Approvals 11

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Quali󹪝ed Personnel
The product/system described in this documentation may be operated only by personnel quali󹪝ed for the speci󹪝c
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Quali󹪝ed personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended or
approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance
are required to ensure that the products operate safely and without any problems. The permissible ambient
conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identi󹪝ed by ® are registered trademarks of SiemensAG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
C79000-G8976-C703-01
Ⓟ 08/2023 Subject to change
Copyright © SiemensAG 2023.
All rights reserved

Table of contents
1 Introduction ........................................................................................................................................... 5
1.1 Scope of validity .................................................................................................................. 5
1.2 Designations used................................................................................................................ 5
1.3 Supplementary documentation............................................................................................ 5
1.4 Trademarks.......................................................................................................................... 7
1.5 SIMATIC NET glossary........................................................................................................... 7
1.6 Security information ............................................................................................................ 7
1.7 Error/fault ............................................................................................................................ 8
1.8 Decommissioning ................................................................................................................ 8
1.9 Recycling and disposal ......................................................................................................... 8
1.10 Electrostatic discharge ......................................................................................................... 9
2 Security information............................................................................................................................ 11
3 Security recommendations.................................................................................................................. 13
4 Device description ............................................................................................................................... 17
4.1 Function ............................................................................................................................ 17
4.2 Article numbers ................................................................................................................. 17
4.3 Type designation................................................................................................................ 18
4.4 Device view ....................................................................................................................... 19
4.5 Components of the product ............................................................................................... 19
4.6 Spare parts ........................................................................................................................ 20
4.7 Accessories........................................................................................................................ 20
4.7.1 Serial USB cable ................................................................................................................. 20
4.7.2 Pluggable transceivers ....................................................................................................... 21
4.8 LED display ........................................................................................................................ 22
4.8.1 "A" LED .............................................................................................................................. 22
4.8.2 Port LEDs ........................................................................................................................... 23
4.8.3 "L" LED............................................................................................................................... 24
4.9 SET button......................................................................................................................... 24
4.10 Combo port ....................................................................................................................... 25
4.11 Function extender interface ............................................................................................... 25
5 Installation and removal...................................................................................................................... 27
5.1 Safety during installation and removal................................................................................ 27
5.2 Mounting types ................................................................................................................. 30
SCALANCE LPE9413 Industrial Edge Device
Operating Instructions, 07/2023, C79000-G8976-C703-01 3

5.3 Mounting on DIN rails........................................................................................................ 31
5.4 Installation on a standard S7-300 rail ................................................................................. 32
5.5 Installation on a standard S7-1500 rail ............................................................................... 33
5.6 Wall mounting ................................................................................................................... 34
5.7 Changing the position of the securing bar .......................................................................... 35
5.8 Connecting a SCALANCE XCM-300 with a SCALANCE LPE9413 Industrial Edge Device......... 37
5.9 General notes for SFP transceivers...................................................................................... 39
6 Connecting up ..................................................................................................................................... 41
6.1 Safety when connecting up................................................................................................ 41
6.2 Wiring rules ....................................................................................................................... 46
6.3 24VDC power supply........................................................................................................ 47
6.4 Functional ground ............................................................................................................. 49
6.5 Industrial Ethernet ............................................................................................................. 51
6.5.1 Electrical............................................................................................................................ 51
6.5.2 Optical............................................................................................................................... 52
6.6 USB console interface ........................................................................................................ 53
6.7 USB interface..................................................................................................................... 54
7 Maintenance and cleaning .................................................................................................................. 55
8 Troubleshooting................................................................................................................................... 57
8.1 Firmware and Rescue system.............................................................................................. 57
8.2 Starting the Rescue system when using the Function Extender Interface............................. 59
8.3 Resetting the con󹪝guration ................................................................................................ 59
9 Technical speci󹪝cations ....................................................................................................................... 61
9.1 Technical speci󹪝cations of the SCALANCE LPE9413 Industrial Edge Device .......................... 61
9.2 Mechanical stability (in operation) ..................................................................................... 63
9.3 RF radiation according to NAMUR NE21.............................................................................. 63
9.4 Cable lengths..................................................................................................................... 64
10 Dimension drawings............................................................................................................................ 65
10.1 SCALANCE LPE9413 Industrial Edge Device dimension drawings......................................... 65
10.2 Dimension drawings SCALANCE XCM-300 .......................................................................... 67
11 Approvals............................................................................................................................................. 71
Index .................................................................................................................................................... 79
Table of contents
SCALANCE LPE9413 Industrial Edge Device
4Operating Instructions, 07/2023, C79000-G8976-C703-01

Introduction 1
These operating instructions support you when installing and connecting the SCALANCE
LPE9413 Industrial Edge Device.
The con󹪝guration and the integration of the devices in a network are not described in these
operating instructions.
1.1 Scope of validity
These operating instructions apply to the following devices:
• SCALANCE LPE9413 Industrial Edge Device
1.2 Designations used
This section describes the conventions used in this document to clearly and e󹪟ciently portray
information.
Classi󹪝ca‐
tion
Description Terms used
Product
group
If information applies to all devices and variants of a product
group, the term SCALANCE LPE is used.
SCALANCE LPE
Device If information relates to a speci󹪝c device, the device name is
used.
e.g. SCALANCE
LPE9413
1.3 Supplementary documentation
The following additional documents may be of interest. Unless speci󹪝ed otherwise, the
documents are available in the Siemens Industry Online Support (SIOS) (https://
support.industry.siemens.com/cs/en/en/view/109799510).
Open source software license terms
The SCALANCE LPE9413 Industrial Edge Device uses Debian GNU/Linux as the operating system
and includes other open source software. The license terms are stored on the device. To display
them, enter the following in the address bar of your web browser:
https://<IP address of the device>/OSS
SCALANCE LPE9413 Industrial Edge Device
Operating Instructions, 07/2023, C79000-G8976-C703-01 5

Getting Started
You can 󹪝nd information on the integration of the device in Industrial Edge Management in
"SCALANCE LPE Industrial Edge Device Getting Started (https://
support.industry.siemens.com/cs/ww/en/ps/26683/man)"
Industrial Edge Device – Operation
You can 󹪝nd operating instructions for Industrial Edge Devices in the manual "Industrial Edge
Device – Operation (https://support.industry.siemens.com/cs/en/en/view/109799507)".
Pluggable transceivers
You can 󹪝nd information on pluggable transceivers in the operating instructions "Pluggable
transceivers SFP/SFP+/SCP/STP (https://support.industry.siemens.com/cs/ww/en/ps/25547/
man)"
Industrial Edge – Update procedure
You can 󹪝nd instructions on updating Industrial Edge and the associated components in the
manual "Industrial Edge – Update procedure (https://support.industry.siemens.com/cs/en/en/
view/109813153)".
Industrial Edge – Security overview
You can 󹪝nd a general security overview of Industrial Edge in the manual "Industrial Edge –
Security overview (https://support.industry.siemens.com/cs/en/en/view/109799476)".
Industrial Edge Management – Download
You can 󹪝nd the download 󹪝le for Industrial Edge Management in the Industrial Edge Hub.
Industrial Edge Management – Installation
You can 󹪝nd installation instructions for Industrial Edge Management in the manual "Installation
Edge Management - Getting Started (https://support.industry.siemens.com/cs/en/en/view/
109799510)."
Industrial Edge Management – Operation
You can 󹪝nd operating instructions for Industrial Edge Management in the manual "Industrial
Edge Management – Operation (https://support.industry.siemens.com/cs/en/en/view/
109799510)."
Industrial Edge App Publisher – Operation
You can 󹪝nd operating instructions for the Industrial Edge App Publisher in the manual
"Industrial Edge App Publisher – Operation (https://support.industry.siemens.com/cs/en/en/
view/109795386)".
Introduction
1.3Supplementary documentation
SCALANCE LPE9413 Industrial Edge Device
6Operating Instructions, 07/2023, C79000-G8976-C703-01

Industrial Edge – Publishing apps in the IE Hub
You can 󹪝nd information on the requirements and procedures when publishing apps in the IE
Hub in the manual "Industrial Edge – Publishing apps in the IE Hub (https://
support.industry.siemens.com/cs/en/en/view/109803581)".
Note
Support of Edge apps and components for Industrial Edge Management
Industrial Edge only supports apps developed by Siemens or customers.
1.4 Trademarks
The following and possibly other names not identi󹪝ed by the registered trademark sign ® are
registered trademarks of Siemens AG:
• SCALANCE
• SINEC
Linux® is the registered trademark of Linus Torvalds in the United States and other countries.
The registered trademark Linux® is used according to a sublicense of LMI, the exclusive
licensee of Linus Torvalds, owner of the trademark on a global basis.
1.5 SIMATIC NET glossary
Explanations of many of the specialist terms used in this documentation can be found in the
SIMATIC NET glossary.
You will 󹪝nd the SIMATIC NET glossary here:
• SIMATIC NET Manual Collection or product DVD
The DVD ships with certain SIMATIC NET products.
• On the Internet under the following address:
50305045 (https://support.industry.siemens.com/cs/ww/en/view/50305045)
1.6 Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be connected
to an enterprise network or the internet if and to the extent such a connection is necessary
Introduction
1.6Security information
SCALANCE LPE9413 Industrial Edge Device
Operating Instructions, 07/2023, C79000-G8976-C703-01 7

and only when appropriate security measures (e.g. 󹪝rewalls and/or network segmentation)
are in place.
For additional information on industrial security measures that may be implemented, please
visit
https://www.siemens.com/industrialsecurity (https://www.siemens.com/industrialsecurity).
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customer’s exposure
to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under
https://www.siemens.com/cert (https://www.siemens.com/cert).
1.7 Error/fault
If a fault develops, send the device to your SIEMENS representative for repair. Repairs on-site are
not permitted.
1.8 Decommissioning
Shut down the device properly to prevent unauthorized persons from accessing con󹪝dential
data in the device memory.
To do this, restore the factory settings on the device.
1.9 Recycling and disposal
The products are low in pollutants, can be recycled and meet the requirements of the WEEE
directive 2012/19/EU for the disposal of electrical and electronic equipment.
Do not dispose of the products at public disposal sites.
For environmentally friendly recycling and the disposal of your old device contact a certi󹪝ed
disposal company for electronic scrap or your Siemens contact (Product return).
Note the di󹪜erent national regulations.
Introduction
1.9Recycling and disposal
SCALANCE LPE9413 Industrial Edge Device
8Operating Instructions, 07/2023, C79000-G8976-C703-01

1.10 Electrostatic discharge
NOTICE
Electrostatic sensitive devices (ESD)
Electronic modules contain electrostatic sensitive components
These components can easily be destroyed if handled incorrectly.
Note the following instructions to avoid damage.
• Touch electronic modules only when you absolutely need to work on them.
• If electronic modules need to be touched, the body of the person involved must 󹪝rst be
electrostatically discharged and grounded.
• Do not bring electronic modules in contact with electrically isolating materials such as
plastic 󹪝lm, isolating table top pads or clothing made of synthetic 󹪝bers.
• Place the modules only on conductive surfaces.
• Pack, store and transport electronic modules and components only in conductive packaging
such as metalized plastic or metal containers, conductive foam or household aluminum foil.
Introduction
1.10Electrostatic discharge
SCALANCE LPE9413 Industrial Edge Device
Operating Instructions, 07/2023, C79000-G8976-C703-01 9

Introduction
1.10Electrostatic discharge
SCALANCE LPE9413 Industrial Edge Device
10 Operating Instructions, 07/2023, C79000-G8976-C703-01

Security information 2
Read the safety notices
Note the following safety notices. These relate to the entire working life of the device.
You should also read the safety notices relating to handling in the individual sections,
particularly in the sections "Installation" and "Connecting up".
CAUTION
To prevent injury and damage, read the manual before using the device.
Safety notices on use in hazardous areas
General safety notices relating to protection against explosion
WARNING
EXPLOSION HAZARD
Do not open the device when the supply voltage is turned on.
Safety instructions for use in hazardous locations according to UL/FM HazLoc
If you use the device under UL or FM HazLoc conditions, you must also adhere to the
following safety instructions in addition to the general safety instructions for protection
against explosion:
This equipment is suitable for use in Class I, Division 2, Groups A, B, C and D or non-hazardous
locations only.
This equipment is suitable for use in Class I, Zone 2, Group IIC or non-hazardous locations only.
SCALANCE LPE9413 Industrial Edge Device
Operating Instructions, 07/2023, C79000-G8976-C703-01 11

Security information
SCALANCE LPE9413 Industrial Edge Device
12 Operating Instructions, 07/2023, C79000-G8976-C703-01

Security recommendations 3
To prevent unauthorized access, note the following security recommendations.
General
• You should make regular checks to make sure that the device meets these recommendations
and/or other security guidelines.
• Evaluate your plant as a whole in terms of security. Use a cell protection concept with suitable
products.
• When the internal and external network are disconnected, an attacker cannot access internal
data from the outside. Therefore operate the device only within a protected network area.
• For communication via non-secure networks use additional devices with VPN functionality to
encrypt and authenticate the communication.
Physical access
• Restrict physical access to the device to quali󹪝ed personnel.
• Lock unused physical ports on the device. Unused ports can be used to access the system
without authorization.
Software (security functions)
• Keep the 󹪝rmware up to date. Check regularly for security updates for the device. You can
󹪝nd information on this at the Industrial Security (https://www.siemens.com/
industrialsecurity) website.
• Inform yourself regularly about security recommendations published by Siemens
ProductCERT (https://new.siemens.com/global/en/products/services/cert.html).
• Only activate protocols that you require to use the device.
• Disable encryption methods with a low security level.
• The option of VLAN structuring provides protection against DoS attacks and unauthorized
access. Check whether this is practical or useful in your environment.
• Use a central logging server to log changes and accesses. Operate your logging server within
the protected network area and check the logging information regularly.
Authentication
•De󹪝ne rules for the assignment of passwords.
• Use passwords with a high password strength. Avoid weak passwords, (e.g. password1,
123456789, abcdefgh) or recurring characters (e.g. abcabc).
This recommendation also applies to symmetrical passwords/keys con󹪝gured on the device.
SCALANCE LPE9413 Industrial Edge Device
Operating Instructions, 07/2023, C79000-G8976-C703-01 13

• Make sure that passwords are protected and only disclosed to authorized personnel.
• Do not use the same passwords for multiple user names and systems.
• Store the passwords in a safe location (not online) to have them available if they are lost.
• Regularly change your passwords to increase security.
• A password must be changed if it is known or suspected to be known by unauthorized
persons.
• When user authentication is performed via RADIUS, make sure that all communication takes
place within the security environment or is protected by a secure channel.
• Watch out for link layer protocols that do not o󹪜er their own authentication between
endpoints, such as ARP or IPv4. An attacker could use vulnerabilities in these protocols to
attack hosts, switches and routers connected to your layer 2 network, for example, through
manipulation (poisoning) of the ARP caches of systems in the subnet and subsequent
interception of the data tra󹪟c. Appropriate security measures must be taken for non-secure
layer 2 protocols to prevent unauthorized access to the network. Physical access to the local
network can be secured or secure, higher layer protocols can be used, among other things.
Certi󹪝cates and keys
• Make sure that user-de󹪝ned private keys are protected and inaccessible to unauthorized
persons.
• It is recommended that you use password-protected certi󹪝cates in the PKCS #12 format.
• Verify certi󹪝cates and 󹪝ngerprints on the server and client to prevent "man in the middle"
attacks.
• It is recommended to use certi󹪝cates with su󹪟cient cryptographic security.
• Change certi󹪝cates and keys immediately if there is a suspicion of compromise.
Secure/non-secure protocols and services
• Check whether use of the following protocols and services is necessary:
– Non-authenticated and unencrypted ports
– Syslog
– DHCP options 66/67
– TFTP
• The following protocols provide secure alternatives:
– HTTP → HTTPS
• Use secure protocols when access to the device is not secured by physical protection
measures.
• If you require non-secure protocols and services, operate them only within a protected
network area.
• Restrict the services and protocols available to the outside to a minimum.
Security recommendations
SCALANCE LPE9413 Industrial Edge Device
14 Operating Instructions, 07/2023, C79000-G8976-C703-01

Interface security
• Disable unused interfaces.
List of available protocols
The following is a list of all available protocols and services as well as their ports through which
the device can be accessed, including the following information:
•Protocol/service
The protocols/services supported by the device.
•Protocol
The protocol used by the service.
•Port number
The port number assigned to the service.
Note
The table contains the preset ports. Additional ports can be opened for protocols with a
con󹪝gurable port number.
•Default port status/protocol status
The default state (i.e. open, closed, active).
•Protocol/service con󹪝gurable
Speci󹪝es whether or not the protocol or service can be con󹪝gured.
•Port number con󹪝gurable
Speci󹪝es whether the port number can be con󹪝gured.
•Authentication
Speci󹪝es whether an authentication of the communication partner takes place or whether
an authentication can be con󹪝gured.
•Encryption
Speci󹪝es whether the transfer is encrypted or whether the encryption can be con󹪝gured.
Service Proto‐
col
Port number Default port sta‐
tus
Protocol/
service con‐
󹪝gurable
Port num‐
ber con󹪝gu‐
rable
Authentica‐
tion
Encryption
DHCP UDP - 1) Closed - - - -
HTTPS TCP 443 Open - - ✓ 2) ✓
NTP UDP - 3) Closed ✓ - - -
TFTP UDP 69 Open 4) - - - -
1) DHCP only outbound, port number is not con󹪝gured.
2) Authentication is only possible after successful onboarding.
3) Only client.
4) The TFTP service is only active in the Rescue system.
Security recommendations
SCALANCE LPE9413 Industrial Edge Device
Operating Instructions, 07/2023, C79000-G8976-C703-01 15

Service Protocol Default protocol sta‐
tus
Protocol/service con‐
󹪝gurable
Authentication Encryption
Ping ICMP Active - - -
Secure Boot
Secure Boot is a security standard that allows a device to start only with trusted software
components (bootloader, operating system etc.). Secure Boot is part of the UEFI (Uni󹪝ed
Extensible Firmware Interface), an interface between the hardware and the operating system.
During booting with Secure Boot, each involved component is checked for authenticity and
integrity. Use of software not signed by the manufacturer is not possible. Furthermore,
Secure Boot allows additional security functions for which a secure boot process is essential,
such as fTPM, to be activated.
With Secure Boot, it is no longer possible to use self-generated components for the system
test (bootloader, kernel etc.). There are no restrictions during operation; any IE applications
can be installed, updated, modi󹪝ed or deleted as before.
The SCALANCE LPE9413 Industrial Edge Device supports the Secure Boot function.
Security recommendations
SCALANCE LPE9413 Industrial Edge Device
16 Operating Instructions, 07/2023, C79000-G8976-C703-01

Device description 4
4.1 Function
The SCALANCE LPE Industrial Edge Device is an industrial IoT (Internet of Things) device with a
Linux operating system that was developed for use in the Siemens Industrial Edge ecosystem.
The device provides computing power for a wide range of Industrial Edge applications (Edge
Computing). The rugged housing in SIMATIC S7-1500 format and the fanless design enable use
in direct manufacturing environments.
As Industrial Edge Device with connection to the Industrial Edge Management (IEM), it o󹪜ers
special advantages during con󹪝guration and operation:
• Central management of Edge Devices.
•E󹪟cient software update for Edge Devices and Edge apps through the IEM.
• Monitoring of the device and device groups by the IEM.
4.2 Article numbers
Device Description Article number
SCALANCELPE9413 Indus‐
trial Edge Device
The SCALANCE LPE9413 Industrial Edge Device can be operated
either standalone or connected with a SCALANCE XCM-300.
In standalone operation, the SCALANCE LPE9413 Industrial
Edge Device has the following ports:
• 2 x 10/100/1000Mbps RJ45 ports
• 1 x combo port (1 x 10/100/1000Mbps RJ45 port / 1x plug‐
gable transceiver slot with 100/1000Mbps)
When the SCALANCE LPE9413 Industrial Edge Device is connec‐
ted to a SCALANCE XCM-300, the ports of the SCALANCE
LPE9413 Industrial Edge Device work as Function Extender Inter‐
face (FEI) ports of the SCALANCE XCM-300 with the following
speeds:
• 2 x 1 Gbps
• 1 x 10 Gbps
The three RDI ports are available as bridge ports within SCA‐
LANCE XCM-300.
6GK5998-3GS01-2AC2
SCALANCE LPE9413 Industrial Edge Device
Operating Instructions, 07/2023, C79000-G8976-C703-01 17

4.3 Type designation
LPE is the acronym for "Local Processing Engine". The type designation of a SCALANCE LPE has
the following structure:
Number of connectors
Design
0Standard version
1For Industrial Edge use
LPE94
Device description
4.3Type designation
SCALANCE LPE9413 Industrial Edge Device
18 Operating Instructions, 07/2023, C79000-G8976-C703-01

4.4 Device view
The following 󹪝gure shows an overview of the components of the device.
2
4
\3
11
12
13
9 106 87
1
①CLP slot ⑧Levering aid for moving the securing bar
with a screwdriver
②LED display ⑨Securing bar
③USB3.0 port (Type A) ⑩Knurled screw
④Electrical ports ⑪"SET" button
⑤Combo port ⑫USB 2.0 interface (Type B, serial via USB)
⑥Grounding screw ⑬Function extender interface
⑦Power supply  
4.5 Components of the product
The following components are supplied with the device:
• A SCALANCE LPE
• Two 2-pin terminal blocks for the power supply
• One cover for the pluggable transceiver slot
Device description
4.5Components of the product
SCALANCE LPE9413 Industrial Edge Device
Operating Instructions, 07/2023, C79000-G8976-C703-01 19

Unpacking and checking
WARNING
Do not use any parts that show evidence of damage
If you use damaged parts, there is no guarantee that the device will function according to the
speci󹪝cation.
If you use damaged parts, this can lead to the following problems:
• Injury to persons
• Loss of the approvals
• Violation of the EMC regulations
• Damage to the device and other components
Use only undamaged parts.
1. Make sure that the package is complete.
2. Check all the parts for transport damage.
4.6 Spare parts
The following spare parts are available for the device:
Component Description Article number
Spring-loaded terminal
block, 4-pin
4-pin spring-loaded terminal block to connect
the power supply (24VDC)
Pack of 5
6GK5 980-1DB10-0AA5
Spring-loaded terminal
block, 2-pin
2-pin spring-loaded terminal block to connect
the power supply (24 V DC)
Pack of 5
6GK5 980-0BB10-0AA5
4.7 Accessories
The following accessories are available for the device:
4.7.1 Serial USB cable
Component Description Article number
Connecting cable
(USBTypeA /
USBTypeB)
Preassembled USB cable with USB Type A and USB
Type B connector, length: 2 m
Pack of 1
7ML1930-1FN
Device description
4.7Accessories
SCALANCE LPE9413 Industrial Edge Device
20 Operating Instructions, 07/2023, C79000-G8976-C703-01
