Siemens SIMATIC NET S7-CPs Instruction Manual

Preface, Contents
Communication in S7 Stations 1
Characteristics of the Ethernet
CPs 2
Commissioning an Ethernet CP 3
SEND/RECEIVE
interface 4
Configuring Connections 5
CP as PROFINET IO Controller 6
S7−300 CP as PROFINET IO
Device 7
Sending Process Messages by
E-Mail 8
File Management and File
Access with FTP 9
CP as Web Server: HTML
Process Control 10
Web Diagnostics 11
NCM S7 Diagnostics 12
Firmware Loader 13
Appendix A −E / Index
SIMATIC NET
S7-CPs for Industrial Ethernet
Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
Manual
Part A −General Application

A−2S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
Classification of Safety−Related Notices
This manual contains notices which you should observe to ensure your own
personal safety, as well as to protect the product and connected equipment. These
notices are highlighted in the manual by a warning triangle and are marked as
follows accordin
g
to the level of dan
g
er:
!Danger
indicates that death or severe personal injury will result if proper precautions are
not taken.
!Warning
indicates that death or severe personal injury can result if proper precautions are
not taken.
!Caution
with warning triangle indicates that minor personal injury can result if proper
precautions are not taken.
Caution
without warning triangle indicates that damage to property can result if proper
precautions are not taken.
Notice
indicates that an undesirable result or status can occur if the relevant notice is
ignored.
Note
highlights important information on the product, using the product, or part of the
documentation that is of particular importance and that will be of benefit to the
user.

A−3
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
Trademarks
SIMATICR, SIMATIC HMIRand SIMATIC NETRare registered trademarks of
SIEMENS AG.
Third parties using for their own purposes any other names in this document which
refer to trademarks might infringe upon the rights of the trademark owners.
Safety Instructions Regarding your Product:
Before you use the product described here, read the safety instructions below
thoroughly.
Qualified Personnel
Only qualified personnel should be allowed to install and work on this equipment.
Qualified persons are defined as persons who are authorized to commission, to
ground, and to tag circuits, equipment, and systems in accordance with
established safety practices and standards.
Correct Usage of Hardware Products
Note the following
!Warning
This device and its components may only be used for the applications described in
the catalog or the technical description, and only in connection with devices or
components from other manufacturers which have been approved or
recommended by Siemens.
This product can only function correctly and safely if it is transported, stored, set
up, and installed correctly, and operated and maintained as recommended.
Before you use the supplied sample programs or programs you have written
yourself, make certain that no injury to persons nor damage to equipment can
result in your plant or process.
EU Directive: Do not start up until you have established that the machine on which
you intend to run this component complies with the directive 89/392/EEC.
Correct Usage of Software Products
Note the following
!Warning
This software may only be used for the applications described in the catalog or the
technical description, and only in connection with software products, devices, or
components from other manufacturers which have been approved or
recommended by Siemens.
Before you use the supplied sample programs or programs you have written
yourself, make certain that no injury to persons nor damage to equipment can
result in your plant or process.

A−4S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
Prior to Startup
Before putting the product into operation, note the following warning:
Caution
Prior to startup you must observe the instructions in the relevant documentation.
For ordering data of the documentation please refer to the catalogs or contact your
local SIEMENS representative.
We have checked the contents of this manual for agreement with the
hardware and software described. Since deviations cannot be precluded
entirely, we cannot guarantee full agreement. However, the data in this
manual are reviewed regularly and any necessary corrections included in
subsequent editions. Suggestions for improvement are welcomed.
Disclaimer of LiabilityCopyright ESiemens AG 2001−2008 All rights reserved
The reproduction, transmission or use of this document or its contents is not
permitted without express written authority. Offenders will be liable for
damages. All rights, including rights created by patent grant or registration of
a utility model or design, are reserved.
Siemens AG
Industry Automation
Industrial Communication
Postfach 4848, 90327 Nürnberg Germany Subject to technical change.
Siemens Aktiengesellschaft G79000−G8976−C182−09

A−5
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
This manual...
... supports you when commissioning your SIMATIC NET CP modules in an S7
station.
... supports you so that your applications can communicate successfully and
efficiently over the SIMATIC NET CPs.
... in tandem with the “Primer” description, provides you with all the information you
require to implement your communications tasks:
Operating S7 CPs with
STEP 7
Learning from the
example
Installation /
commissioning
ManualDescription
“Primer”
Part A
SCP overviews
SCommunication services
SNetwork attachment
SConfiguration
SProgram interface
SDiagnostics
Sfamiliarization
Stesting interfaces
Scommissioning
Part B
(device manuals)
SCharacteristics
SOperator controls/
displays
SOperating instructions
STechnical specifications
The description “Primer −NCM S7 for Industrial Ethernet” is in the online
documentation of STEP 7 under “NCM S7 Manuals”. The manual (Part A and
Part B) for your S7-CP is in the SIMATIC NET Manual Collection. For details, refer
to the References in the Appendix.
After installing STEP 7, the examples described in the “Primer” are located in the
project folder for sample programs
(<drive>:\Programs\Siemens\Step7\EXAMPLES)!

This manual...
A−6S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
Audience
This manual is intended for personnel responsible for installing and programming
STEP 7 programs and for service personnel.
Scope of this manual
This manual is valid as of version V5.4 SP4 of the STEP 7 software.
Notice
If functions are described that require higher versions, this is indicated by an
additional icon.
Example:
The description of the IT functions is valid for the following modules:
S6GK7 343-1GX30-0XE0: as of hardware version 1,
as of firmware version V1.0
S6GK7 443-1GX20-0XE0: as of hardware version 3,
as of firmware version V2.0
The term “Advanced CP”
The term “Advanced CP” stands for CP modules with E-mail, FTP or Web
functions and PROFINET CBA (for example CP x43-1 Advanced).
Structural innovations in the documentation
SThe chapter “Programmed Communications Connections“ finden is now in the
manual “Functions (FCs) and Function Blocks (FBs) for SIMATIC NET S7 CPs”
/10/.

This manual...
A−7
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
New Technical Information / Content
Apart from various adaptations to the currently available devices and the current
versioln of STEP 7 / NCM S7 V5.5, the following changes were made:
SIn the Chapter “Configuring Communications Connections”, the information on
unspecified connections as it relates to S7 connections was expanded
SThe previous name “S5−compatible communication” has been replaced by the
name “Open communications services“.
SIn the chapter “CP as Web Server: HTML Process Control” it is taken into
account that S7 applets can only be generated by individual usw of the supplied
S7 beans; the CP does not provide any preprogrammed specifíc S7 applets.
Note
You should also check the History for this manual in Appendix F.
Notice
Please note that the availability of new functions depends on the device type you
are using. You can check which functions your module supports in the description
in the Properties dialog in STEP 7 and in the catalog in HW Config.

This manual...
A−8S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
The documentation on the Internet
The following table provides you with an overview of the content and the
addresses for downloading from the Web.
Title Content / Web Addresses
Configuring and
CommissioningS7-CPs
for Industrial Ethernet
Configuration Manual
Part A
General section:
http://support.automation.siemens.com/WW/view/en/8777865
S7-CPs for Industrial
Ethernet
Manual Part B
Device descriptions:
SCP 343-1 Lean (CX00):
http://support.automation.siemens.com/WW/view/en/19308657
SCP 343-1 Lean (CX10):
http://support.automation.siemens.com/WW/view/en/23643456
SCP 343-1 (EX20/EX11):
http://support.automation.siemens.com/WW/view/en/8777308
SCP 343-1 (EX21):
http://support.automation.siemens.com/WW/view/en/22259495
SCP 343-1 (EX30):
http://support.automation.siemens.com/WW/view/en/24485272
SCP 343-1 PN:
http://support.automation.siemens.com/WW/view/en/8776538
SCP 343-1 IT:
http://support.automation.siemens.com/WW/view/en/8776544
SCP 343-1 Advanced (GX21):
http://support.automation.siemens.com/WW/view/en/22261695
SCP 343-1 Advanced (GX30):
http://support.automation.siemens.com/WW/view/en/28017299
SCP 443-1 (EX11):
http://support.automation.siemens.com/WW/view/en/8776219
SCP 443-1 (EX20):
http://support.automation.siemens.com/WW/view/en/26417141
SCP 443-1 IT:
http://support.automation.siemens.com/WW/view/en/8776322
SCP 443-1 Advanced (EX40):
http://support.automation.siemens.com/WW/view/en/19308871
SCP 443-1 Advanced (EX41):
http://support.automation.siemens.com/WW/view/en/23643789
SCP 443-1 Advanced (GX20):
http://support.automation.siemens.com/WW/view/en/28011203
Gateways SIE/PB Link:
http://support.automation.siemens.com/WW/view/en/7851748
SIE/PB Link PN IO:
http://support.automation.siemens.com/WW/view/en/19299692
SIWLAN/PB Link PN IO:
http://support.automation.siemens.com/WW/view/en/21379908

This manual...
A−9
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
Title Content / Web Addresses
NCM S7 for SIMATIC
NET S7-CPs
Primer
This is available on the Web at:
http://support.automation.siemens.com/WW/view/en/1172503
Commissioning PC
Stations
Manual and Quick Start
The manual supports you and helps you to make efficient use of
communications with your PC applications in conjunction with the SIMATIC
NET modules. It shows you how to configure PC modules and the steps
required in project engineering with NCM S7.
This is available on the Web at:
http://support.automation.siemens.com/WW/view/en/13542666
Configuring and
Commissioning S7-CPs
for PROFIBUS
Manual
You will find the Web addresses of the current documents of this manual at the
address shown below for the Version History.
NCM S7 for
PROFIBUS/FMS
This is available on the Web at:
http://support.automation.siemens.com/WW/view/en/1158418
CP documentation in the Manual Collection (order no. A5E00069051)
The SIMATIC NET Manual Collection ships with each S7-CP. This DVD is
updated at regular intervals and contains the latest device manuals and
descriptions available at the time the DVD was written.
Version history/current downloads for the SIMATIC NET S7 CPs
In the “Version History/Current Downloads for the SIMATIC NET S7-CPs”, you will
find information on all previously available CPs for SIMATIC S7 (Ind. Ethernet,
PROFIBUS and IE/PB Link).
You will find the latest release of these documents at:
http://support.automation.siemens.com/WW/view/en/9836605
Information on the current block versions (FCs/FBs)
For new user programs, please make sure that you use the latest block versions.
You will find information on the current block versions and the current blocks to
download from the Internet at:
http://support.automation.siemens.com/WW/view/en/8797900
If you require replacements, please follow the instructions in the device-specific
Part B of this manual.

This manual...
A−10 S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
SIMATIC NET Quick Start CD: Samples covering all aspects of communication
The Quick Start CD that can be ordered separately is a treasure-trove of
sample programs and configurations.
You can order this directly over the Internet at:
http://support.automation.siemens.com/WW/view/en/21827955
Additional information on SIMATIC S7 and STEP 7
The additional documentation on the basic software STEP 7 of the SIMATIC
programmable controllers is included in electronic format in your STEP 7
installation.
You will also find information on SIMATIC programmable controllers on the Quick
Start CD and from the Customer Support Online services at:
http://www.automation.siemens.com/net/index_76.htm
(general information on SIMATIC NET)
or
http://support.automation.siemens.com/WW/view/de
(product information and downloads)

This manual...
A−11
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
Symbols used in this manual
Unless indicated otherwise, the functions described in this manual assume the use
of STEP 7. This symbol is used to indicate functions that require a specific version
of STEP 7 or higher, for example Version V5.2.
This symbol appears in the margin to draw your attention to useful tips.
This symbol indicates recommended documentation.
Where you see this symbol, you should also refer to additional information in the
basic help system of STEP 7.
This symbol indicates where detailed context-sensitive help is available. You can
display these help texts with the F1 key or by clicking on the “Help” button in the
relevant dialog.
Conventions
References to other manuals and documentation are indicated by numbers in
slashes /.../. These numbers refer to the titles of manuals listed in the References
section of the Appendix.
-
F1

Contents
A−12 S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
Contents
Contents −Part A
This manual... A−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1 Communication via Ethernet CPs in S7 Stations A−19. . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Industrial Ethernet A−20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 SIMATIC S7 communication with S7 Ethernet CPs A−21. . . . . . . . . . . . . . . .
1.2.1 Possible types of communication A−21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2.2 The communication services of the Ethernet CPs A−24. . . . . . . . . . . . . . . . .
1.2.3 Operation using a configured or programmed database A−26. . . . . . . . . . . .
1.3 PG/OP communication via Industrial Ethernet A−27. . . . . . . . . . . . . . . . . . . .
1.3.1 PG communication with STEP 7 over Industrial Ethernet A−29. . . . . . . . . .
1.3.2 OP operation: Connecting operator interface devices via
Industrial Ethernet A−30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 S7 communication on Industrial Ethernet A−31. . . . . . . . . . . . . . . . . . . . . . . .
1.5 Open communications services (SEND/RECEIVE interface) ) A−36. . . . . .
1.6 FETCH/WRITE services (Server) A−39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.7 Networking stations with STEP 7 A−40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.7.1 Network/project variant : One subnet, one project A−42. . . . . . . . . . . . . . . . .
1.7.2 Network/project variant: SIMATIC S5 and non-SIMATIC devices
on the subnet A−43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.7.3 Network/project variant: Two or more subnets, one project A−44. . . . . . . . .
1.7.4 Network/project variant: One subnet, multiple (sub) projects A−45. . . . . . . .
1.7.5 Network/project variant: Multiple subnets in multiple (sub) projects A−48. .
1.7.6 Network/project variant: Connections across subnets (TCP/IP) A−50. . . . .
1.7.7 Network/project variant: IP connection across subnets (TCP/IP) A−51. . . .
2 Characteristics of the Ethernet CPs A−53. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 Communications processors for S7-300 A−53. . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Communications processors for S7-400 A−54. . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Slot rules for SIMATIC S7-300 A−56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3.1 Permitted slots A−56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3.2 Number of SIMATIC NET CPs operated at the same time A−56. . . . . . . . .
2.3.3 Multicomputing A−56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3.4 Removing/inserting (module replacement) A−57. . . . . . . . . . . . . . . . . . . . . . .
2.3.5 Note on S7-300 CPU: Connection resources A−57. . . . . . . . . . . . . . . . . . . . .
2.4 Slot rules for SIMATIC S7-400 A−58. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4.1 Permitted slots A−58. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4.2 Number of SIMATIC NET CPs operated at the same time A−58. . . . . . . . .
2.4.3 Multicomputing A−58. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4.4 Removing/inserting (module replacement) A−59. . . . . . . . . . . . . . . . . . . . . . .

Contents
A−13
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
2.4.5 Note on S7-400 CPU: Connection resources A−59. . . . . . . . . . . . . . . . . . . . .
3 Operating the Ethernet CP with STEP 7/NCM S7 A−60. . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 How to commission an Ethernet CP A−61. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 General information on STEP 7 / NCM S7 A−62. . . . . . . . . . . . . . . . . . . . . . .
3.3 Configuring −how it is done? A−63. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.1 Creating an Industrial Ethernet subnet A−64. . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.2 Entering an Ethernet CP in the hardware configuration A−66. . . . . . . . . . . .
3.3.3 Displaying the network attachments of a station A−69. . . . . . . . . . . . . . . . . .
3.4 Setting further CP properties A−71. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.1 Addresses tab A−72. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.2 Options tab A−73. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.3 Time-of-day Synchronization tab A−76. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.4 Diagnostics tab A−77. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.5 IP Access Protection tab A−77. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.6 IP Configuration tab A−80. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.7 “Port Parameters” tab A−82. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.8 “PROFINET” tab A−82. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.9 Configuring IT functions A−83. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.5 Sending entries for the IP access control list to the CP
(Advanced CP) by HTTP A−86. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.6 Media Redundancy tab A−88. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.6.1 Media redundancy options A−88. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.6.2 Media redundancy in ring topologies A−88. . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.6.3 MRP A−90. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.6.4 MRP configuration with PROFINET IO A−92. . . . . . . . . . . . . . . . . . . . . . . . . .
3.7 “Substitute objects” in the STEP 7 project A−95. . . . . . . . . . . . . . . . . . . . . . . .
3.8 Configuring communication services A−98. . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.9 Assigning addresses for the first time A−99. . . . . . . . . . . . . . . . . . . . . . . . . . .
3.9.1 Addressing by selecting the target system in the SIMATIC Manager A−100.
3.9.2 Addressing using the properties dialog in HW Config or NetPro A−101. . . . .
3.10 Downloading the configuration data to the target system A−103. . . . . . . . . . .
4 SEND/RECEIVE Interface in the User Program A−106. . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1 How the SEND/RECEIVE interface on the CPU works A−107. . . . . . . . . . . .
4.2 Programming the SEND/RECEIVE interface A−109. . . . . . . . . . . . . . . . . . . . .
4.3 Data exchange S7 CPU <−> Ethernet CP A−112. . . . . . . . . . . . . . . . . . . . . . .
4.4 Additional information A−114. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.4.1 Programming data transfer on TCP connections A−114. . . . . . . . . . . . . . . . . .
4.4.2 Recommendations for use with a high communications load A−115. . . . . . . .
5 Configuring Communication Connections A−116. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.1 Procedure A−117. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2 Possible connection configurations A−118. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.3 Connections A−120. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.3.1 New connection A−122. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents
A−14 S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
5.3.2 Connections to partners in other projects A−124. . . . . . . . . . . . . . . . . . . . . . . .
5.3.3 Further functions A−126. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.3.4 Connections without assignment A−127. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.4 Configuring ISO transport connections A−130. . . . . . . . . . . . . . . . . . . . . . . . . .
5.4.1 Specifying the local connection endpoint A−131. . . . . . . . . . . . . . . . . . . . . . . . .
5.4.2 Specifying ISO transport addresses A−133. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.4.3 Specifying ISO transport dynamic properties A−136. . . . . . . . . . . . . . . . . . . . .
5.4.4 Checking ISO transport connection properties A−138. . . . . . . . . . . . . . . . . . . .
5.5 Configuring ISO−on−TCP connection properties A−139. . . . . . . . . . . . . . . . . .
5.5.1 Specifying the local connection endpoint A−140. . . . . . . . . . . . . . . . . . . . . . . . .
5.5.2 Specifying ISO−on−TCP addresses A−142. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.5.3 Checking ISO−on−TCP connection properties A−145. . . . . . . . . . . . . . . . . . . .
5.6 Configuring TCP connection properties A−146. . . . . . . . . . . . . . . . . . . . . . . . . .
5.6.1 Specifying the local connection endpoint A−147. . . . . . . . . . . . . . . . . . . . . . . . .
5.6.2 Specifying TCP addresses A−149. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.6.3 Checking TCP connection properties A−153. . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.7 Configuring UDP connection properties A−154. . . . . . . . . . . . . . . . . . . . . . . . . .
5.7.1 Specifying the local connection endpoint A−155. . . . . . . . . . . . . . . . . . . . . . . . .
5.7.2 Specifying UDP addresses A−156. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.7.3 UDP with broadcast and multicast A−160. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.7.4 Checking the properties of a UDP connection A−166. . . . . . . . . . . . . . . . . . . .
5.7.5 Free UDP connection A−167. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.8 FETCH/WRITE mode A−168. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.9 Routing to distribute load A−171. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 CP as PROFINET IO Controller A−172. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.1 Configuration A−173. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.1.1 PROFINET IO system in STEP 7 A−173. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.1.2 PROFINET IO with IRT communication A−174. . . . . . . . . . . . . . . . . . . . . . . . .
6.2 IO controller mode with S7−300 A−175. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.2.1 Programming A−175. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.2.2 Reading and writing data records with FB52 A−176. . . . . . . . . . . . . . . . . . . . .
6.2.3 Interrupt evaluation using FB54 A−176. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.3 IO controller mode with S7−400 A−177. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.3.1 Multicomputing mode −Assigning the CP to the CPU A−177. . . . . . . . . . . . .
6.3.2 Programming A−177. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.4 Further information on operation with PROFINET IO A−178. . . . . . . . . . . . . .
6.4.1 Effects of multicast communication on RT communication A−178. . . . . . . . .
7S7−300 CP as PROFINET IO Device A−179. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.1 Principle of the data exchange in IO device mode A−180. . . . . . . . . . . . . . . . .
7.2 Configuration A−181. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.2.1 Principle of the IO device coupling A−181. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.2.2 Activating the CP as a PROFINET IO device in the S7 station A−182. . . . . .
7.2.3 Configuring the CP as IO device with IRT communication A−182. . . . . . . . . .
7.2.4 Assigning the PROFINET IO device to a PROFINET IO system A−184. . . .
7.3 Programming A−187. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.3.1 Interface for programming on the PROFINET IO device A−187. . . . . . . . . . .

Contents
A−15
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
7.3.2 Initialization and configuration A−188. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.4 Example of configuration and programming A−190. . . . . . . . . . . . . . . . . . . . . .
8 Sending Process Messages by E-Mail A−193. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.1 Overview of the functions A−193. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.1.1 Authentication and other features of the Advanced CP A−194. . . . . . . . . . . .
8.2 Configuration A−195. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.2.1 Procedure A−195. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.2.2 Options of mail server mode A−196. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.2.3 Configuring a mail server and addressing recipients A−196. . . . . . . . . . . . . . .
8.3 Setting up an E−mail connection A−197. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.4 Sending an E−mail A−199. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.4.1 E−mail data block A−199. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.4.2 Sending E−mail with AG_SEND/AG_LSEND A−201. . . . . . . . . . . . . . . . . . . . .
8.5 Testing the E-mail function A−202. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9 File Management and File Access with FTP A−204. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9.1 FTP functions in an S7 station with the Advanced CP A−205. . . . . . . . . . . . .
9.2 Advanced CP as FTP server for the file system on the CP A−206. . . . . . . . .
9.2.1 Method A−206. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9.2.2 File system −structure and features A−207. . . . . . . . . . . . . . . . . . . . . . . . . . . .
9.3 Advanced CP as FTP server for S7 CPU data A−210. . . . . . . . . . . . . . . . . . . .
9.3.1 Method A−210. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9.3.2 FTP commands on the FTP client A−211. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9.3.3 File allocation table A−213. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9.3.4 Structure of the data blocks (File DB) for FTP services A−218. . . . . . . . . . . .
9.4 The Advanced CP as FTP client for S7 CPU data A−222. . . . . . . . . . . . . . . .
9.4.1 Method A−222. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9.4.2 Setting up FTP connections A−223. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9.4.3 Structure of the data blocks (File DB) for FTP services A−225. . . . . . . . . . . .
9.4.4 FCs and FBs for FTP services A−228. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10 CP as Web Server: HTML Process Control A−229. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10.1 Overview of HTML process control A−229. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10.2 Security when Accessing Process Data A−231. . . . . . . . . . . . . . . . . . . . . . . . .
10.2.1 Opening ports on the Advanced CP during configuration A−231. . . . . . . . . . .
10.2.2 Operation with firewall and proxy server A−231. . . . . . . . . . . . . . . . . . . . . . . . .
10.2.3 Level of password protection A−232. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10.3 Accessing the Advanced CP via a Web browser A−233. . . . . . . . . . . . . . . . . .
10.4 Accessing HTML system pages −Examples A−235. . . . . . . . . . . . . . . . . . . . .
10.4.1 Querying the diagnostic buffer A−235. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10.5 Creating and storing your own ”home page” A−237. . . . . . . . . . . . . . . . . . . . . .
11 Web Diagnostics A−239. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11.1 Initial situation A−239. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11.2 Setup and operation A−240. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents
A−16 S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
11.3 Diagnostics pages of the CP A−242. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11.3.1 Start page A−242. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11.3.2 Identification A−244. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11.3.3 Rack configuration A−245. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11.3.4 Diagnostic buffer A−246. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11.3.5 Industrial Ethernet A−247. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11.3.6 PROFINET IO A−250. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11.3.7 Configured connections A−252. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11.3.8 IP access protection A−254. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11.3.9 Media redundancy A−255. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12 NCM S7 Diagnostics A−256. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12.1 Overview A−257. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12.2 Functions of NCM S7 Diagnostics A−258. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12.2.1 Installing and starting NCM S7 Diagnostics A−259. . . . . . . . . . . . . . . . . . . . . .
12.2.2 General menu commands A−261. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12.3 Starting diagnostics A−263. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12.3.1 Establishing a connection to the Ethernet CP A−263. . . . . . . . . . . . . . . . . . . .
12.3.2 Starting diagnostics from the properties dialog of the CP A−263. . . . . . . . . . .
12.3.3 Starting diagnostics from the Windows Start menu A−264. . . . . . . . . . . . . . . .
12.3.4 Using a gateway A−266. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12.3.5 Using a PC station −setting a gateway with ”PC internal” A−269. . . . . . . . . .
12.3.6 Other ways of starting diagnostics A−270. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12.4 How to use diagnostics A−271. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12.5 Starting diagnostic functions explicitly A−272. . . . . . . . . . . . . . . . . . . . . . . . . . .
12.6 Checklist for ‘typical problems‘ in a system A−274. . . . . . . . . . . . . . . . . . . . . . .
12.6.1 Checklist for general CP functions A−274. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12.6.2 Communication connection checklist A−275. . . . . . . . . . . . . . . . . . . . . . . . . . . .
12.7 Diagnostic messages from E−mail connections with authentication A−276. .
13 Firmware Loader A−278. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13.1 Area of application A−278. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13.2 Loading firmware A−279. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A Connector Pinning A−281. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.1 24 V DC connector A−281. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.2 RJ-45 jack for twisted−pair Ethernet A−281. . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.3 Connector for Industrial Ethernet A−282. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.4 Connector for PROFIBUS A−283. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B Standards and approvals of SIMATIC NET S7 CPs A−284. . . . . . . . . . . . . . . . . . . . . . . .
C References and Literature A−290. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D Glossary A−296. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D.1 General section A−296. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D.2 Industrial Ethernet and IT functions of the CPs A−300. . . . . . . . . . . . . . . . . . .
D.3 PROFINET A−305. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents
A−17
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
E Linking to Other Systems with FETCH/WRITE A−307. . . . . . . . . . . . . . . . . . . . . . . . . . .
F Document History A−312. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A−18 S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10

A−19
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
1 Communication via Ethernet CPs in S7
Stations
The Ethernet CP for SIMATIC S7 provides a series of communications services for
different tasks.
This chapter explains the following:
SThe types of communication possible with the Ethernet CP on Industrial
Ethernet
SThe tasks handled by the Ethernet CP for the various services
SHow to create the conditions for your communications requirements
You will find further information in the following sources:
SWhen installing the Ethernet CP, follow the instructions in the manual in the
Manual Collection that ships with the Ethernet CP /1/. This also contains further
information about the performance of the Ethernet CP .
SFor the functions and use of the STEP 7 configuration software, some of which
is used to configure the CP (such as hardware configuration), please refer to
/6/.

1 Communication via Ethernet CPs in S7 Stations
A−20 S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 07/2010
C79000−G8976−C182−10
1.1 Industrial Ethernet
Definition
Within the open, heterogeneous SIMATIC NET communication system, Industrial
Ethernet is the network for the management and cell level. Physically, Industrial
Ethernet is an electrical network that uses a shielded coaxial cable or twisted pair
or an optical network with fiber-optic cables.
Industrial Ethernet is defined by the international standard IEEE 802.3.
All-round communication in the industrial sector
Industrial Ethernet is integrated in the SIMATIC NET concept that allows
comprehensive networking of the management, cell and field levels along with
PROFINET / PROFIBUS and the AS-Interface (AS-i).
PROFIBUS
(EN 50170 Vol. 2 PROFIBUS)
AS-Interface
(AS-i, Actuator-Sensor
Interface)
Industrial
Ethernet
(IEEE 802.3)
PROFINET
Figure 1-1 Industrial Ethernet in the SIMATIC NET concept
Network access
Industrial Ethernet is accessed using the CSMA/CD (Carrier Sense Multiple
Access with Collision Detection) network access technique specified in
IEEE 802.3.
