Siemens SIREMOBIL Compact User guide

SIREMOBIL Compact
Register 3 English
Print No.: SPR2-130.033.02.02.02 Doc. Gen. Date: 12.98
Replaces: SPR2-130.033.02.01.02
© Siemens AG 1997
The reproduction, transmission or
use of this document or its contents
is not permitted without express
written authority. Offenders will be
liable for damages. All rights,
including rights created by patent
grant or registration of a utility
model _or_design,_are_reserved.
SP
System Manual
Installation and Setting Instructions
Replacing the lifting column

SIREMOBIL Compact Register 3 SPR2-130.033.02 Page 2 of 4 Siemens AG
System Manual Rev. 02 12.98 TD SD 24 Medical Engineering
0 - 2 Revision
Chapter Page Revision
01to402
11to202
21to602
3 1 to 10 02
41to202

Contents 0 - 3
Siemens AG Register 3 SPR2-130.033.02 Page 3 of 4 SIREMOBIL Compact
Medical Engineering Rev. 02 12.98 TD SD 24 System Manual
1 _______General________________________________________________________1-1
Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Protective conductor resistance test . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Other information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Required documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Required tools and measurement devices . . . . . . . . . . . . . . . . . . . . . . . 1-1
Required material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
2 _______Removing the lifting column ______________________________________2-1
Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Board D3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Board D1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Board D2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Line filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Power pack M 14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
TV power supply M13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Removing the hand railing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Removing the swivel brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Removing the C-arm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Removing the upper cover with the control panel. . . . . . . . . . . . . . . . . . . . 2-5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Removing the control lever with the gears . . . . . . . . . . . . . . . . . . . . . . . 2-6
Removing the lifting column. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
3 _______Installing the lifting column _______________________________________3-1
Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Installing the new lifting column . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Installing the cover with the control panel . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Installing the C-arm and the swivel brake . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Installing the line filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Installing the power pack M 14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Installing the TV power supply M13 . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Installing boards D1 and D2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Adjusting the swivel brake. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Remaining work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
4 _______Changes to previous version______________________________________4-1
Page

0 - 4 Contents
SIREMOBIL Compact Register 3 SPR2-130.033.02 Page 4 of 4 Siemens AG
System Manual Rev. 02 12.98 TD SD 24 Medical Engineering
This page intentionally left blank.

1 - 1
Siemens AG Register 3 SPR2-130.033.02 Page 1 of 2 SIREMOBIL Compact
Medical Engineering Rev. 02 12.98 TD SD 24 System Manual
Safety information 1
Tests and adjustments performed with radiation on are identified with the radiation warn-
ing symbol . Radiation protection must be worn during these types of adjustments.
Protective conductor resistance test 1
After concluding all work and reattaching all covers, perform the protective conductor test
according to TI 236 / ARTD-002.731.17... .
The protective conductor resistance may not exceed 0.2 ohm.
Other information 1
n.a.
Required documents 1
Circuit diagram G5429
Service instructions RXR2-130.061.01....
Required tools and measurement devices 1
Required material 1
When performing service work and tests, adhere to the product-specific
safety information contained in the documents as well as the general
safety information in Register 2 of the TI folder.
Service kit (refer to ARTD / Part 3)
Digital multimeter
20N spring scale 44 29 114 NH029
200N spring scale 44 15 113 RH090
25 - 130 Nm 1/2" torque wrench 34 24 561
Service PC
Service-PC - Host connection cable 99 00 440 RE999
Protective conductor meter 44 15 899 RV090
Viscogen KL300, 40 g 73 95 353
Conductive paste for heat sink
Lifting column parts kit 37 79 407 G5429
CAUTION
General 1

SIREMOBIL Compact Register 3 SPR2-130.033.02 Page 2 of 2 Siemens AG
System Manual Rev. 02 12.98 TD SD 24 Medical Engineering
1 - 2 General
This page intentionally left blank

2 - 1
Siemens AG Register 3 SPR2-130.033.02 Page 1 of 6 SIREMOBIL Compact
Medical Engineering Rev. 02 12.98 TD SD 24 System Manual
Preliminary steps 2
•Switchthe SIREMOBIL off and disconnectthe line voltageplug.
•Securetheunit so thatitcannot be inadvertentlyswitchedon.
•Tosecurethe unitagainsttipping,supportitontheoperatingpanelside with wooden
boardsor other similarmaterial.
Board D3 2
•Removethe Plexiglascoverof board D3 by removingthe screws.
•Disconnectallplugsexcept D3/X2(Fig.1).
•Removethe protectiveconductorfromtheboard.
Board D1 2
•Disconnectallplugsfromthe board.
•Removethe protectiveconductorfromtheboard.
•Removeall 6 mounting nuts(1/Fig.2).
•Carefullyremove theboardandplace itonanESDsurface.
•Remove thespacers from the 6screws.
•Openthe strainreliefforribboncable X 4 (2/Fig.2).
Fig. 1 Fig. 2
Board D3 does not have to be removed.
1
2
NOTICE
Removing the lifting column 2

SIREMOBIL Compact Register 3 SPR2-130.033.02 Page 2 of 6 Siemens AG
System Manual Rev. 02 12.98 TD SD 24 Medical Engineering
2 - 2 Removing the lifting column
Fig. 3 Fig. 4
Fig. 5 Fig. 6
Fig. 7
1
542
3
1

Removing the lifting column 2 - 3
Siemens AG Register 3 SPR2-130.033.02 Page 3 of 6 SIREMOBIL Compact
Medical Engineering Rev. 02 12.98 TD SD 24 System Manual
Board D2 2
•Removethe protectiveconductorfromtheinterface plate.
•Removethe interfaceplate.
•Removethe groundingbracket fromtheheatsink. The heat sinkremains on the board
(1/Fig.3).
•Disconnectallplugsfromthe board.
•Removethe 6spacerscrews.
•Unscrew theboard fromthe heatsink (1/Fig.4).
•Remove theboard and place iton an ESD surface.
•Remove the grounding strap from the heatsink (5/Fig.5).
•Unscrew theprotectiveconductor.
•Removethe 6mountingscrews of the heatsink.
•Liftout theheatsink.
Line filter 2
•Disconnectthe lower connectionsof thelinefilter.
•Removethe line filterby removing thescrews.
•Removeall protectiveconductorsfrom thebaseplateof thelinefilter (2/Fig.5).
•Remove the BNCconnector(X1) and remove the screws from the BNC plug (3/Fig.5).
•Unscrew thegrounding strap fromthe base plate (4/Fig.5).
•Removethescrewsfrom thebaseplateandremovethebaseplate;removetheboltfrom
theliftingcolumn.
Power pack M 14 2
•DisconnectplugsX2andX3fromthepowerpack; theprotectiveconductorcan remain
connected.
•Removethe powerpack;
todothis,loosen onlythe two upper nutsandremovethe lowernut.
TV power supply M13 2
•Removethe Plexiglascover by removingthe screws.
•Desolderthe connectionsfrom the transformerand disconnectall otherconnections.
•Remove thescrews from underneaththe TV powersupply and liftit out, Fig.6
•Remove the stabilization bracketof the monitor cable connector from the lifting column
byremovingthe screws , 1/Fig.7.

SIREMOBIL Compact Register 3 SPR2-130.033.02 Page 4 of 6 Siemens AG
System Manual Rev. 02 12.98 TD SD 24 Medical Engineering
2 - 4 Removing the lifting column
Fig. 8 Fig. 9
Fig. 10 Fig. 11
Fig. 12 Fig. 13
1
2
1
2
1
2
3

Removing the lifting column 2 - 5
Siemens AG Register 3 SPR2-130.033.02 Page 5 of 6 SIREMOBIL Compact
Medical Engineering Rev. 02 12.98 TD SD 24 System Manual
Removing the hand railing 2
•Removethe lefthand railing fromtheC-arm.
Removing the swivel brake 2
•Removethe handle (1/Fig.9) andremove the plasticprotector(2/Fig.9).
•Removethe latchassembly by removingthescrews.
•Removethe coverplateundertheswivelbrake by removing thescrews.
•Knockthespring pin out and removethe bolt.
•Movethe C-armintothe horizontalpositionandsecure itsothatit cannot swivel.
Removing the C-arm 2
•Lift the C-armfrom itsbearing support (three peoplerequired) and place iton a table
being careful notto damage theC-arm cable (Fig.10).
•Remove the screws from the bearing shellof the C-arm bearing support.(1/Fig.11)
•Movetheliftingcolumnallthe way down by brieflyapplying 230VAC atthe3-pole
connectionplug of theliftingcolumn(NatX7 A/1,P at X7A/3).
Removing the upper cover with the control panel 2
•Remove thescrews from the strain reliefof the controlpanel cable (1/Fig.12).
•Removethe protectiveconductorbyremovingthe screws(2/Fig.12).
•Removethe cover facingby removingthe screws.
•Removethe mountingscrews (3/Fig.12).
•Placethe controlleverat 90 degreesto the controlpanel.
•Removethe cover ringaround the controllever.
•Loosenthecover (2/Fig.11)attheliftingcolumnand remove it.
•Removethe4mountingscrews (Fig.13)on the liftingcolumn.
•Removethe upper coverwiththe controlpanel; to do this,liftthecoverover thelifting
columnandcarefullypull it offoverthe controllever at thesametimepulling the
connectorof the controlpanel cable carefullythroughtherectangularopening (1/Fig.14).

SIREMOBIL Compact Register 3 SPR2-130.033.02 Page 6 of 6 Siemens AG
System Manual Rev. 02 12.98 TD SD 24 Medical Engineering
2 - 6 Removing the lifting column
2
Removing the control lever with the gears 2
•Turnthecontrolleverparallelto the unit.
•Knockthespring pin outofthesteeringlinkage(2/Fig.14).
•Marktheposition ofthecontrollever with a feltpen.
•Disconnectthe controlleverunit and remove it(3/Fig.14).
Removing the lifting column 2
•Removethefourmountingscrewsof the liftingcolumnfrom theundersideof the unit;
tiltthe unitalittle,if necessary.
•Removetheliftingcolumn(twopeople required).
Becarefulnot to damage theconnectioncable.
Fig. 14
1
2
3

3 - 1
Siemens AG Register 3 SPR2-130.033.02 Page 1 of 10 SIREMOBIL Compact
Medical Engineering Rev. 02 12.98 TD SD 24 System Manual
Preliminary steps 3
•Recutthe(1/Fig.1)threads.
•Ejectall thewiresfrom the four-poleconnectorontheconnectioncableand connect
themtothe three-poleconnectoras follows:
•Removethe blackplasticcoverfromthe liftingcolumn (1/Fig.2).
Installing the new lifting column 3
•Movethe newlifting column(twopeoplerequired)through theopeningin thechassis.
Be carefulnot todamage the connection cableand ensure that theEMC gasket is
seatedcorrectlyin the mounting.
•Placethe liftingcolumnintothe guide(1/Fig.1) on thechassisand secureitwith the
screws from underneaththe unit(screw torque =40 Nm).
Fig. 1 Fig. 2
X7A/1 X7A/2 X7A/3
1
1
Installing the lifting column 3

SIREMOBIL Compact Register 3 SPR2-130.033.02 Page 2 of 10 Siemens AG
System Manual Rev. 02 12.98 TD SD 24 Medical Engineering
3 - 2 Installing the lifting column
Fig. 3 Fig. 4
Fig. 5 Fig. 6
Fig. 7 Fig. 8
1
1

Installing the lifting column 3 - 3
Siemens AG Register 3 SPR2-130.033.02 Page 3 of 10 SIREMOBIL Compact
Medical Engineering Rev. 02 12.98 TD SD 24 System Manual
•Apply230V (N an X7 A/1 and phase at X7 A/2)andmovetheliftingcolumnas far up as
possibleuntilthedrilledholeforlubricationis accessible(1/Fig.3).
•Removethe plasticcapinthe drilledhole(1/Fig.3)and lubricatethe liftingspindle
throughthe opening. Refillenough oilsothatyou can testtheoil levelwithyour finger
UseViscogenKL 300, item number 73 95 353.
•Sealthehole with theplasticcap.
•InstalltheC-armmounting intheliftingcolumn(1/Fig.4).
•Placethe C-arm inthenewliftingcolumn(3people required)for testingpurposes (Fig.5)
andsecureit againsttwisting.
•Connectplug X7A (connectioncable of the liftingcolumn):
•Movetheliftingcolumnupanddown several timesand listen fornoise.
•Movethelifting column allthe way downagain.
•Liftthe C-arm back outof themounting(3 peoplerequired)(Fig.5)and place itona table.
•Removethe C-armmountingagain from theliftingcolumn(1/Fig.4)byremovingthe
screws.
Neutral at X7 A/1 Phase at X7 A/2 for lifting Phase at X7 A/3 for lowering

SIREMOBIL Compact Register 3 SPR2-130.033.02 Page 4 of 10 Siemens AG
System Manual Rev. 02 12.98 TD SD 24 Medical Engineering
3 - 4 Installing the lifting column
Installing the cover with the control panel 3
•Placethe cover overtheliftingcolumn.
•Routetheribbon cableandtheprotective conductorfor thecontrolpanelthroughthe
opening(1/Fig.9).
•Putthecover on.
•Securethe cover tothelifting column(10)with 4 screwsand frombelowthe controllever
sidewith 4 screws as well.
Twolongscrewsare providedon the inside.
•Reinsertthe pininthe controllever.
•Reinstallthestrainrelief(2/Fig.9)of the controlpanel cable.
•Reattach(3/Fig.9)theprotectiveconductorto thechassis(onthecontrolsidefrombelow
left).
•Reinstallthe coverplate (on thecontrolpanelsideat the chassis,underthe controllever)
Fig. 9 Fig. 10
Fig. 11 Fig. 12
2
3
1

Installing the lifting column 3 - 5
Siemens AG Register 3 SPR2-130.033.02 Page 5 of 10 SIREMOBIL Compact
Medical Engineering Rev. 02 12.98 TD SD 24 System Manual
Installing the C-arm and the swivel brake 3
•Placethe new collaroverthe liftingcolumn, centerit and attachitsecurely.
•Placethe C-arm back intothemounting(3 peoplerequired).
•Reinstall the swivel brake:
- Insert thebolt from belowthrough thelatches.
- Reinstallthespringpinwithits opening facingyou.
•Installthespringwashers:
thelowerspringwiththecone upward; the upper springwiththe conedownward.
•Securethelatchassemblywith the screws.
•Position the brake lever.
•Securethecover platewiththe screwsunderthe swivelbrake.
•Reattach the hand railing to the C-arm with the screws.

SIREMOBIL Compact Register 3 SPR2-130.033.02 Page 6 of 10 Siemens AG
System Manual Rev. 02 12.98 TD SD 24 Medical Engineering
3 - 6 Installing the lifting column
Installing the line filter 3
•Insertthe 4 standoffs(1/Fig.13)withtheshort threadsintotheholesin theliftingcolumn
andtightenthem.
•Insertthe baseplateand tightenitwith4 M4 nuts and contactwashers.
•Pullthe cable back behindtheliftingcolumntoward theright.
•Secureall protectiveconductors(2/Fig.14)againon the base plateoftheline filter;
when doing this,insert contact washers between thecable terminal and the base plate.
•Securethe line filterwithtwo screwsto the baseplate.
•Securethe BNC plug to the base platewith the screws.
•Connectthe BNC cable.
Installing the power pack M 14 3
•Install the base plate.
•Install thepower pack with the plug connections facing down.
Fig. 13
Fig. 14 Fig. 15
1
2

Installing the lifting column 3 - 7
Siemens AG Register 3 SPR2-130.033.02 Page 7 of 10 SIREMOBIL Compact
Medical Engineering Rev. 02 12.98 TD SD 24 System Manual
•Pluginthe connectors.
•Attachthe protectiveconductortothe base plateoftheline filterwith the screw;inserta
contactwasher underthecable terminal.
Installing the TV power supply M13 3
•Insertthe TV powersupplyinto the holesinthe floor oftheunit; however,don’t tightenit
yet.
•Pullthe cablesunderthe TVpowersupplyand plug in the connectionsto the board:
•Solderthe wirestothetransformer:
•Liftout theTVpower supplyonce againandinstallthePlexiglascover.
•Reinstall the TV power supplyand secure it from underneath the unitwith 4-M4 nuts and
washers.
•Securetheprotectiveconductorwith the screwtothefloor of theunitand to thechassis.
Insertcontactwashers underthecable terminals.
Installing boards D1 and D2 3
•Securetheheatsink on thecontrolside of theliftingcolumn(Fig.15).
•Attachthe 6 spacerscrewsto the heatsinkandtightenthem (Fig.15).
•Applyconductivepasteto the contactsurfaceof theheatsink.
•Positionboard D2 on the spacerscrewsand tightenit to the heatsink(Fig.15).
•Connectthe plugs on boardD2.
•SecureboardD2 with the spacersFig.15.
•Installtheinterface plate.
•Positionthe spacerson the6screws.
Black wire to 2Red wire to +
Green/yellow = protective
conductor red wire to 0 V yellow wire to 220 V

SIREMOBIL Compact Register 3 SPR2-130.033.02 Page 8 of 10 Siemens AG
System Manual Rev. 02 12.98 TD SD 24 Medical Engineering
3 - 8 Installing the lifting column
•CarefullyplaceboardD1onthe6 screwsandsecureitwithwashersand nuts (Fig.16).
•Connectthe plugs to thecorrespondingconnections on boardD1.
•Securethe grounding straptoboard D1, tothe interfaceplate,to the heatsinkand to the
baseplateof the linefilter.
When tighteningthescrewson board D1, becarefulthat thegrounding strapdoesnot
comeincontactwithadjacentcomponents.
•Secureall shieldingof the previouslyconnectedcables togroundwith cable clamps.
•Securethe C-arm cable (1/Fig.16) and pluginthe connectors.
•Pullthe Diamentor measurementcable throughtowardthe leftbehindthe liftingcolumn.
•Reattachthe bracket(2/Fig.17)to the liftingcolumn and tightenthescrews.
•Connectthe footswitchcable to boardD3andsecureit with thestrainrelief(Fig.18).
Fig. 16 Fig. 17
Fig. 18 Fig. 19
2
1
