Siemens ARCADIS Avantic Installation and operation manual

© Siemens AG
The reproduction, transmission or use
of this document or its contents is not
permitted without express written
authority. Offenders will be liable for
damages. All rights, including rights
created by patent grant or registration
of a utility model or design, are
reserved.
Print No.:
Würthwein
ARCADIS Avantic
Option
Installation and Startup
SP
2005
SPR2-330.814.01.01.02
Replaces: n.a.
English
Doc. Gen. Date: 02.05
Area Dose Measurement
1004765410048590

2 Revision / Disclaimer
ARCADIS Avantic SPR2-330.814.01.01.02 Siemens AG
02.05 CS SD 24
Page 2 of 10 Medical Solutions
1Revision / Disclaimer
Document revision level
The document corresponds to the version/revision level effective at the time of system
delivery. Revisions to hardcopy documentation are not automatically distributed.
Please contact your local Siemens office to order current revision levels.
Disclaimer
The installation and service of equipment described herein is to be performed by qualified
personnel who are employed by Siemens or one of its affiliates or who are otherwise
authorized by Siemens or one of its affiliates to provide such services.
Assemblers and other persons who are not employed by or otherwise directly affiliated
with or authorized by Siemens or one of its affiliates are directed to contact one of the
local offices of Siemens or one of its affiliates before attempting installation or service pro-
cedures.

Siemens AG SPR2-330.814.01.01.02 ARCADIS Avantic
02.05 CS SD 24
Table of Contents 3
Page 3 of 10
Medical Solutions
1- 0Table of Contents
1 _______ Installation and Setting Instructions ________________________________ 4
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Additional information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Required parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Required measuring and auxiliary equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Required tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
With the laser light localizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing the measuring chambers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Programming and calibrating the area dose product measuring device . . . . . . . . . . . . . 6
Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Checking the programmed value (standard resolution/pediatrics) . . . . . . . . . . . . . . . 7
Final work steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2 _______ Changes to Previous Version______________________________________ 9

4 Installation and Setting Instructions
ARCADIS Avantic SPR2-330.814.01.01.02 Siemens AG
02.05 CS SD 24
Page 4 of 10 Medical Solutions
2-
1Installation and Setting Instructions
General information 0
Safety instructions 0
NOTICE To avoid light to severe, possibly fatal, injuries and material dam-
age:
¹The product-specific safety information in the system
manual as well as the safety information in the ARTD,
part 2, must be observed.
¹After all work has been completed and all covers have
been attached, perform the protective conductor test
according to ARTD-002.731.17. The protective conductor
resistance may not exceed 0.2 Ohms.
¹Checks and settings that need to be performed under
X-ray radiation are identified by the radiation symbol
x. Radiation protective clothing must be worn while
performing procedures marked with this symbol.
Additional information 0
These instructions only apply to the retrofitting of the dose meter to an ARCADIS Avantic
system.
Required parts 0
Required measuring and auxiliary equipment 0
Required tools 0
•Tool case (see SPC catalog)
•DAP meter (including 4 threaded bolts) 10 04 76 54
•Dose meter e.g., PTW-Diados 97 17 612 Y0388
•Crosshair 96 60 051 RE999

Siemens AG SPR2-330.814.01.01.02 ARCADIS Avantic
02.05 CS SD 24
Installation and Setting Instructions 5
Page 5 of 10
Medical Solutions
With the laser light localizer 0
Fig. 1: Measuring chamber connection
Remove the laser light localizer prior to the installation procedure. After installation is
complete, remount the localizer, check it, and adjust it as needed according to the "Laser
Light Localizer" setting instructions.
Installing the measuring chambers 0
•Disconnect the ARCADIS power plug.
•Unscrew the POWERPHOS cover. Carefully separate the adhesive joints on the long
sides of the cover.
•Remove the measuring chamber connection (1/Fig.1/p.5)from the cable tie.
•Place the dose measuring chamber on the POWERPHOS according to (2/Fig.1/p.5).
•Use the included threaded bolts and screws to secure the dose measuring chamber to
the POWERPHOS.
•Connect the measuring chamber connection (1/Fig.1/p.5)to the measuring chamber.
•Use the switch on the measuring chamber to select the desired resolution (see the in-
scription on the measuring chamber and the measuring chamber operating instruc-
tions).
•Reattach the POWERPHOS cover.

6 Installation and Setting Instructions
ARCADIS Avantic SPR2-330.814.01.01.02 Siemens AG
02.05 CS SD 24
Page 6 of 10 Medical Solutions
Programming and calibrating the area dose product measuring
device 0
NOTE This calibration operation is used to adjust the area dose product
measuring device to the ARCADIS Avantic system display.
Programming 0
•Start and log on to the service program.
•<Click Main System> and <Next>.
•Click <Options> under "Configuration".
•Click <Yes> under "Diamentor Existing".
•Read off the "TW" factor from the identification tag on the diamentor chamber and enter
it in the "Constant" field.
•Select ""0.1 cGy cm*cm/pulse" for the standard resolution in the "Resolution" field
(see (1/Fig.2/p.7)).
•For pediatric applications select
“0.01 cGy cm*cm/pulse” under "Resolution".
•Enter the test value (TW) 500 under "Constant" (see (2/Fig.2/p.7)) for standard and
5000 for pediatrics.
•Press the Return key on the keyboard and click <Save>.

Siemens AG SPR2-330.814.01.01.02 ARCADIS Avantic
02.05 CS SD 24
Installation and Setting Instructions 7
Page 7 of 10
Medical Solutions
Fig. 2: main_system_
Checking the programmed value (standard resolution/pediatrics) 0
NOTE After completing all work, ensure that the value entered under
"Constant" and "Resolution" corresponds with the application de-
sired by the user.
“0.01cGy cm*cm/pulse” is only to be selected for pediatrics.
•Click <Diamentor> and ">" under "Adjustment" for the next page in the Service menu.
•Click "Click Here" in the service view and check the accuracy of the diamentor accord-
ing to the instructions on the system.

8 Installation and Setting Instructions
ARCADIS Avantic SPR2-330.814.01.01.02 Siemens AG
02.05 CS SD 24
Page 8 of 10 Medical Solutions
Final work steps 0
•Click <Backup & Restore> in the "Home menu", select "Backup" under "Command",
and select "(-R-) CD-R" under "Drives".
•Use <Go> to start the burning operation for the following packages: SW-Settings.., As-
piaSettings, Security-Settings, ExamSet, MainSystem.
•Perform partial acceptance tests in accordance with country-specific regulations.
•Check the calibration of the laser light localizer if applicable.

Siemens AG SPR2-330.814.01.01.02 ARCADIS Avantic
02.05 CS SD 24
Changes to Previous Version 9
Page 9 of 10
Medical Solutions
3-
2Changes to Previous Version
N/A; first version
