Siemens SIMATIC NET SCALANCE XCM-100 User manual

SIMATIC NET
Network components
SCALANCE XCM-100 Media
Converter
Operating Instructions
07/2022
C79000-G8976-C659-01
Introduction 1
Safety instructions 2
Recommendations on
network security 3
Network topologies 4
Device description 5
Installation and
disassembly 6
Connecting 7
Maintenance and cleaning 8
Technical speci󹪝cations 9
Dimension drawings 10
Approvals 11

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent damage
to property. The notices referring to your personal safety are highlighted in the manual by a safety alert symbol, notices
referring only to property damage have no safety alert symbol. These notices shown below are graded according to
the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will be
used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to property
damage.
Quali󹪝ed Personnel
The product/system described in this documentation may be operated only by personnel quali󹪝ed for the speci󹪝c
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Quali󹪝ed personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended or
approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance
are required to ensure that the products operate safely and without any problems. The permissible ambient
conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identi󹪝ed by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication may
be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software described.
Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the information in this
publication is reviewed regularly and any necessary corrections are included in subsequent editions.
Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
C79000-G8976-C659-01
Ⓟ 07/2022 Subject to change
Copyright © Siemens AG 2022.
All rights reserved

Table of contents
1 Introduction ........................................................................................................................................... 5
1.1 Designations used................................................................................................................ 5
1.2 Trademarks.......................................................................................................................... 5
1.3 SIMATIC NET glossary........................................................................................................... 5
1.4 Security information ............................................................................................................ 6
1.5 Recycling and disposal ......................................................................................................... 6
1.6 Electrostatic discharge ......................................................................................................... 7
2 Safety instructions................................................................................................................................. 9
3 Recommendations on network security.............................................................................................. 11
4 Network topologies ............................................................................................................................. 13
4.1 Network topologies with SCALANCE XCM-100.................................................................... 13
4.2 Coupling of network segments........................................................................................... 16
5 Device description ............................................................................................................................... 17
5.1 Purpose ............................................................................................................................. 17
5.2 Article numbers ................................................................................................................. 17
5.3 Product properties ............................................................................................................. 17
5.4 Scope of delivery ............................................................................................................... 18
5.5 Device view ....................................................................................................................... 19
5.6 LED display ........................................................................................................................ 20
5.7 SELECT/SET button............................................................................................................. 21
5.8 Accessories........................................................................................................................ 22
6 Installation and disassembly ............................................................................................................... 25
6.1 Safety notices for installation ............................................................................................. 25
6.2 Mounting types ................................................................................................................. 27
6.3 DIN rail mounting .............................................................................................................. 28
6.4 Installing on an S7-300 mounting rail................................................................................. 30
6.5 Installing on an S7-1500 mounting rail............................................................................... 32
6.6 Wall mounting................................................................................................................... 34
6.7 Removal ............................................................................................................................ 35
7 Connecting .......................................................................................................................................... 37
7.1 Safety instructions for operation with a power supply according to NEC Class 2................... 37
SCALANCE XCM-100 Media Converter
Operating Instructions, 07/2022, C79000-G8976-C659-01 3

7.2 Safety instructions for operation with a power supply according to SELV ............................. 38
7.3 Safety instructions on use in hazardous areas ..................................................................... 39
7.4 Additional notes................................................................................................................. 41
7.5 Wiring rules ....................................................................................................................... 42
7.6 Power supply 24 V AC / 24 V DC and grounding .................................................................. 43
7.7 Signaling contact ............................................................................................................... 45
7.8 TP port (twisted pair port) .................................................................................................. 46
7.9 SFP port............................................................................................................................. 47
8 Maintenance and cleaning .................................................................................................................. 49
9 Technical speci󹪝cations ....................................................................................................................... 51
9.1 Technical speci󹪝cations of SCALANCE XCM102................................................................... 51
9.2 Mechanical stability (in operation) ..................................................................................... 53
9.3 RF radiation according to NAMUR NE21.............................................................................. 53
9.4 Cable lengths..................................................................................................................... 53
10 Dimension drawings............................................................................................................................ 55
11 Approvals............................................................................................................................................. 57
Index .................................................................................................................................................... 65
Table of contents
SCALANCE XCM-100 Media Converter
4Operating Instructions, 07/2022, C79000-G8976-C659-01

Introduction 1
Scope of validity
These operating instructions apply to the following devices:
• SCALANCE XCM102
Unless mentioned otherwise, the descriptions in these operating instructions refer to
all devices of the SCALANCE XCM-100 product group speci󹪝ed in the scope of validity.
1.1 Designations used
This section describes the conventions used in this document to clearly and e󹪟ciently portray
information.
Classi󹪝ca‐
tion
Description Terms used
Product
group
If information applies to all devices and versions of a product
group, the term SCALANCE XCM-100 is used.
SCALANCE XCM-100
Device If information relates to a speci󹪝c device, the device name is
used.
e.g. SCALANCE XCM102
1.2 Trademarks
The following and possibly other names not identi󹪝ed by the registered trademark sign ® are
registered trademarks of Siemens AG:
• SCALANCE
• SINEC
1.3 SIMATIC NET glossary
Explanations of many of the specialist terms used in this documentation can be found in the
SIMATIC NET glossary.
You will 󹪝nd the SIMATIC NET glossary here:
• SIMATIC NET Manual Collection or product DVD
The DVD ships with certain SIMATIC NET products.
• On the Internet under the following address:
50305045 (https://support.industry.siemens.com/cs/ww/en/view/50305045)
SCALANCE XCM-100 Media Converter
Operating Instructions, 07/2022, C79000-G8976-C659-01 5

1.4 Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is necessary
to implement – and continuously maintain – a holistic, state-of-the-art industrial security
concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be connected to
an enterprise network or the internet if and to the extent such a connection is necessary and only
when appropriate security measures (e.g. 󹪝rewalls and/or network segmentation) are in place.
For additional information on industrial security measures that may be implemented, please
visit
https://www.siemens.com/industrialsecurity.
Siemens’ products and solutions undergo continuous development to make them more secure.
Siemens strongly recommends that product updates are applied as soon as they are available
and that the latest product versions are used. Use of product versions that are no longer
supported, and failure to apply the latest updates may increase customer’s exposure to cyber
threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS Feed
under
https://www.siemens.com/cert.
1.5 Recycling and disposal
The products are low in pollutants, can be recycled and meet the requirements of the WEEE
directive 2012/19/EU for the disposal of electrical and electronic equipment.
Do not dispose of the products at public disposal sites.
For environmentally friendly recycling and the disposal of your old device contact a certi󹪝ed
disposal company for electronic scrap or your Siemens contact (Product return).
Note the di󹪜erent national regulations.
Introduction
1.5 Recycling and disposal
SCALANCE XCM-100 Media Converter
6Operating Instructions, 07/2022, C79000-G8976-C659-01

1.6 Electrostatic discharge
NOTICE
Electrostatic sensitive devices (ESD)
Electronic modules contain electrostatic sensitive components
These components can easily be destroyed if handled incorrectly.
Note the following instructions to avoid damage.
• Touch electronic modules only when you absolutely need to work on them.
• If electronic modules need to be touched, the body of the person involved must 󹪝rst be
electrostatically discharged and grounded.
• Do not bring electronic modules in contact with electrically isolating materials such as
plastic 󹪝lm, isolating table top pads or clothing made of synthetic 󹪝bers.
• Place the modules only on conductive surfaces.
• Pack, store and transport electronic modules and components only in conductive packaging
such as metalized plastic or metal containers, conductive foam or household aluminum foil.
Introduction
1.6 Electrostatic discharge
SCALANCE XCM-100 Media Converter
Operating Instructions, 07/2022, C79000-G8976-C659-01 7

Introduction
1.6 Electrostatic discharge
SCALANCE XCM-100 Media Converter
8Operating Instructions, 07/2022, C79000-G8976-C659-01

Safety instructions 2
Read the safety notices
Note the following safety notices. These relate to the entire working life of the device.
You should also read the safety notices relating to handling in the individual sections,
particularly in the sections "Installation" and "Connecting up".
CAUTION
To prevent injury and damage, read the manual before using the device.
Safety notices on use in hazardous areas
General safety notices relating to protection against explosion
WARNING
EXPLOSION HAZARD
Do not open the device when the supply voltage is turned on.
Safety instructions for use in hazardous locations according to UL/FM HazLoc
If you use the device under UL or FM HazLoc conditions, you must also adhere to the following
safety instructions in addition to the general safety instructions for protection against explosion:
This equipment is suitable for use in Class I, Division 2, Groups A, B, C and D or non-hazardous
locations only.
This equipment is suitable for use in Class I, Zone 2, Group IIC or non-hazardous locations only.
SCALANCE XCM-100 Media Converter
Operating Instructions, 07/2022, C79000-G8976-C659-01 9

Safety instructions
SCALANCE XCM-100 Media Converter
10 Operating Instructions, 07/2022, C79000-G8976-C659-01

Recommendations on network security 3
To prevent unauthorized access, note the following security recommendations.
General
• You should make regular checks to make sure that the device meets these recommendations
and/or other security guidelines.
• Evaluate your plant as a whole in terms of security. Use a cell protection concept with suitable
products.
• When the internal and external network are disconnected, an attacker cannot access internal
data from the outside. Therefore operate the device only within a protected network area.
• For communication via non-secure networks use additional devices with VPN functionality to
encrypt and authenticate the communication.
SCALANCE XCM-100 Media Converter
Operating Instructions, 07/2022, C79000-G8976-C659-01 11

Recommendations on network security
SCALANCE XCM-100 Media Converter
12 Operating Instructions, 07/2022, C79000-G8976-C659-01

Network topologies 4
4.1 Network topologies with SCALANCE XCM-100
You can build the following topologies with the SCALANCE XCM-100 series media converters:
• Line
• Star
• Redundant ring when two media converters are used
The connection status (Link up or Link down) of the twisted pair ports always corresponds to
the connection status of the SFP ports. If the connection status for one of the two ports changes,
this change also takes e󹪜ect for the other port without signi󹪝cant time delay. There may be a
delay of a few seconds with two coupled media converters. In this case, the full connection is
󹪝rst monitored before the connection is activated.
In addition, you can use the devices of the SCALANCE XCM-100 product group for two special
applications:
• "Cascading" two media converters (series connection) You can only connect two media
converters in series via the FO port. A maximum of two SCALANCE XCM-100 can be
connected in series. Media converters of the SCALANCE X-100 product group cannot be
connected in series.
• Standby coupling of two redundant rings This requires redundancy-capable stations, e.g.
devices of the SCALANCE XM-400 series. You can 󹪝nd information about this application in
the next section.
Note
Adhere to the maximum permissible cable lengths for the respective devices. You can 󹪝nd
information about the maximum cable length in the section "Cable lengths (Page 53)".
SCALANCE XCM-100 Media Converter
Operating Instructions, 07/2022, C79000-G8976-C659-01 13

Bus topology
130'*/&5*OEVTUSJBM&UIFSOFUUXJTUFEQBJS
130'*/&5*OEVTUSJBM&UIFSOFU꫼CFSPQUJD
4*."5*$
4
4$"-"/$&
9$.
4$"-"/$&
9$.
4$"-"/$&
9$4'1
4$"-"/$&
9$
Figure 4-1 Line topology with electrical und optical cables and two SCALANCE XCM102
Star topology
The following example shows an optical star topology. SCALANCE XCM102 media converters
allow the connection of the devices with twisted pair cables.
130'*/&5*OEVTUSJBM&UIFSOFUUXJTUFEQBJS
130'*/&5*OEVTUSJBM&UIFSOFU꫼CFSPQUJD
4*."5*$
4
4*."5*$
*05
4*."5*$
4
4$"-"/$&
9$.
4$"-"/$&
9$.
4$"-"/$&
9$.
4$"-"/$&
9.$
Figure 4-2 Optical star topology with SCALANCE XCM102
Network topologies
4.1 Network topologies with SCALANCE XCM-100
SCALANCE XCM-100 Media Converter
14 Operating Instructions, 07/2022, C79000-G8976-C659-01

Ring Topology
The following example shows an electrical ring with a SCALANCE XM408-4C as the redundancy
manager. With two SCALANCE XCM102 media converters, part of the ring can be implemented
with a 󹪝ber-optic cable.
Note
Replacement of SCALANCE X101-1 devices with SCALANCE XCM102
If you want to replace SCALANCE X101-1 or SCALANCE X101-1LD devices with SCALANCE
XCM-100 type devices in a ring topology, you can only exchange the devices in pairs. Mixed
operation of SCALANCE X101-1 or SCALANCE X101-1LD with SCALANCE XCM-100 type devices
is not possible. SCALANCE X101-1 and SCALANCE X101-1LD devices use a proprietary protocol
to exchange link status information, which is not supported by SCALANCE XCM-100.
130'*/&5*OEVTUSJBM&UIFSOFUUXJTUFEQBJS
130'*/&5*OEVTUSJBM&UIFSOFU꫼CFSPQUJD
4*."5*$
4
4*."5*$
4
4$"-"/$&
9.$
4$"-"/$&
9$4'1
4$"-"/$&
9$
4$"-"/$&
9$.
4$"-"/$&
9$.
Figure 4-3 Ring topology with a 󹪝ber-optic cable in one segment
Network topologies
4.1 Network topologies with SCALANCE XCM-100
SCALANCE XCM-100 Media Converter
Operating Instructions, 07/2022, C79000-G8976-C659-01 15

4.2 Coupling of network segments
The following example shows the redundant coupling ("stand-by coupling") of rings with two
SCALANCE XCM102 media converters. This setup is only possible with redundancy-capable
stations, in the example, SCALANCE XM408-4C.
0QFSBUPS
TUBUJPO
130'*/&5*OEVTUSJBM&UIFSOFUUXJTUFEQBJS
130'*/&5*OEVTUSJBM&UIFSOFU꫼CFSPQUJD
4UBOECZNBTUFS 4UBOECZTMBWF
4$"-"/$&9.$
BTSFEVOEBODZNBOBHFS
4*."5*$
4
4*."5*$
*05
4$"-"/$&
-1&
4$"-"/$&
9.$
4$"-"/$&
9$4'1
4$"-"/$&
9$4'1
4$"-"/$&
9$4'1
4$"-"/$&
9$4'1
4$"-"/$&
9$
4$"-"/$&
9$.
4$"-"/$&
9$.
Figure 4-4 Coupling network segments with SCALANCE XCM102 media converters
Network topologies
4.2 Coupling of network segments
SCALANCE XCM-100 Media Converter
16 Operating Instructions, 07/2022, C79000-G8976-C659-01

Device description 5
5.1 Purpose
The devices of the SCALANCE XCM-100 product group enable cost-e󹪜ective setup of Industrial
Ethernet networks with media transitions. The use of a SCALANCE XCM-100 Media Converter is
especially recommended for the following tasks:
• In a network with twisted pair cables, a connection is to be made with 󹪝ber-optic cables, but
the device in question does not have an FO port.
• In a redundant ring with twisted pair lines, a section is to be implemented with 󹪝ber-optic
cables. This requires the two media converters to be connected in series, which is possible
with devices of the SCALANCE XCM-100 product group.
• A device without FO port should be integrated into a network segment with 󹪝ber-optic cables.
5.2 Article numbers
Device version Description Article number
SCALANCE XCM102 1x 100/1000 Mbps RJ45 port
with retaining collar for a Fast
Connect plug, 1x 100/1000 Mbps
SFP port
6GK5102-1GS00-2AC2
5.3 Product properties
Properties SCALANCE XCM102
SIMATIC environment +
Diagnostics LED +
Redundant power supply 2 x 24 V DC/AC +
Compact enclosure 35 mm +
Signaling contact + on-site operation +
Diagnostics: Web, SNMP, PROFINET -
C-PLUG / CLP -
Ring redundancy with RM -
Passive ring redundancy +
Standby redundancy -
IRT capability -
Fast learning -
Passive listening -
Log table -
SCALANCE XCM-100 Media Converter
Operating Instructions, 07/2022, C79000-G8976-C659-01 17

Properties SCALANCE XCM102
SNTP + SICLOCK -
Cut Through -
5.4 Scope of delivery
The following parts are included in the scope of delivery of the SCALANCE XCM-100 Media
Converter:
• One SCALANCE XCM-100 Media Converter
• One 2-pin plug-in terminal block (signaling contact)
• Two 3-pin plug-in terminal blocks (power supply and ground connection)
WARNING
Do not use any parts that show evidence of damage
If you use damaged parts, there is no guarantee that the device will function according to the
speci󹪝cation.
If you use damaged parts, this can lead to the following problems:
• Injury to persons
• Loss of the approvals
• Violation of the EMC regulations
• Damage to the device and other components
Check all the parts for transport damage and use only undamaged parts.
Device description
5.4 Scope of delivery
SCALANCE XCM-100 Media Converter
18 Operating Instructions, 07/2022, C79000-G8976-C659-01

5.5 Device view
The following 󹪝gure shows an overview of the components of the SCALANCE XCM102:
SIEMENS
A
P1
P2
L1
P1
P2
A1
AL ARM
L1
M1
L2
M2
A2
SELEC T/
SET
L2
SCALANCE
XCM102

①LED display
②RJ45 port for twisted pair cable
③SFP port for 󹪝ber-optic cable
④"SELECT/SET" button
⑤Signaling contact
⑥Redundant power supply and grounding
⑦Spring-loaded securing bar for mounting on a DIN rail, S7-300 mounting rail or S7-1500 mount‐
ing rail
Device description
5.5 Device view
SCALANCE XCM-100 Media Converter
Operating Instructions, 07/2022, C79000-G8976-C659-01 19

5.6 LED display
The following 󹪝gure shows the arrangement of the LEDs on the SCALANCE XCM-100.
SELECT/
SET
SIEMENS
A
P1
P2
L1
P1
P2
A1
AL ARM
L1
M1
L2
M2
A2
L2
SCALANCE
XCM102
SIEM
A
P1
P2
L1
L2
LED "A" (red alarm LED)
The "A" LED indicates an alarm status of the device.
LED color LED status Meaning
Red Lit SCALANCE XCM-100 detects and error. At the same time, the signaling contact opens.
The following faults/errors are detected:
1. Link down event on a monitored port.
2. Loss or shortfall of the power supply below 14 V on one of the two power supplies.
-O󹪜 No error detected by the SCALANCE XCM-100.
LEDs "P" (green/yellow port LEDs)
The port LEDs indicate the status of the ports or the fault mask.
Port LED LED color LED status Meaning
P1 Green Lit Link exists, no data reception at port
P1 Yellow Flash Link exists, data reception at port
P2 Green Lit Link exists, no data reception at port
P2 Yellow Flash Link exists, data reception at port
P1 + P2 Green Flash Setting or display of the fault mask
Device description
5.6 LED display
SCALANCE XCM-100 Media Converter
20 Operating Instructions, 07/2022, C79000-G8976-C659-01
