Siemens SINAMICS G130 User manual

Operating instructions · 03/2012
Motor reactors
SINAMICS G130
SINAMICS
s

Motor reactors
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
SINAMICS
SINAMICS G130
Motor reactors
Operating Instructions
Control version V4.5
03/2012
A5E00409660A
Safety information
1
General
2
Mechanical installation
3
Electrical installation
4
Technical specifications
5

Legal information
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
with a safety alert symbol, indicates that minor personal injury can result if proper precautions are not taken.
CAUTION
without a safety alert symbol, indicates that property damage can result if proper precautions are not taken.
NOTICE
indicates that an unintended result or situation can occur if the relevant information is not taken into account.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E00409660A
Ⓟ 04/2012 Technical data subject to change
Copyright © Siemens AG 2012.
All rights reserved

Motor reactors
Operating Instructions, 03/2012, A5E00409660A 3
Table of contents
1 Safety information...................................................................................................................................... 5
1.1 Warnings........................................................................................................................................5
1.2 Safety and application instructions ................................................................................................6
2 General...................................................................................................................................................... 7
3 Mechanical installation............................................................................................................................. 11
4 Electrical installation ................................................................................................................................ 15
5 Technical specifications........................................................................................................................... 17

Table of contents
Motor reactors
4 Operating Instructions, 03/2012, A5E00409660A

Motor reactors
Operating Instructions, 03/2012, A5E00409660A 5
Safety information 1
1.1 Warnings
WARNING
Hazardous voltages are present when electrical equipment is in operation.
Severe personal injury or substantial material damage may result if these warnings are not
observed.
Only qualified personnel are permitted to work on or around the equipment.
This personnel must be thoroughly familiar with all the warnings and maintenance
procedures described in these operating instructions.
The successful and safe operation of this device is dependent on correct transport, proper
storage and installation, as well as careful operation and maintenance.
National safety guidelines must be observed.
DANGER
Five safety rules
When carrying out any kind of work on electrical devices, the "five safety rules" according to
EN 50110 must always be observed:
1. Disconnect the system.
2. Protect against reconnection.
3. Make sure that the equipment is de-energized.
4. Ground and short-circuit.
5. Cover or enclose adjacent components that are still live.
NOTICE
For a UL-approved system use 60/75°C copper conductors only.

Safety information
1.2 Safety and application instructions
Motor reactors
6 Operating Instructions, 03/2012, A5E00409660A
1.2 Safety and application instructions
DANGER
This equipment is used in industrial high-voltage installations. During operation, this
equipment contains live, bare parts. For this reason, they could cause severe injury or
significant material damage if the required covers are removed, if they are used or operated
incorrectly, or have not been properly maintained.
When the machines are used in non-industrial areas, the installation location must be
protected against unauthorized access (protective fencing, appropriate signs).
Prerequisites
Those responsible for protecting the plant must ensure the following:
● The basic planning work for the plant and the transport, assembly, installation,
commissioning, maintenance, and repair work is carried out by qualified personnel and/or
checked by experts responsible.
● The operating manual and machine documentation are always available.
● The technical specifications regarding the applicable installation, connection,
environmental, and operating conditions are always observed.
● The plant-specific assembly and safety guidelines are observed and personal protection
equipment is used.
● Unqualified personnel are forbidden from using these machines and working near them.
This operating manual is intended for qualified personnel and only contain information and
notes relating to the intended purpose of the machines.
The operating manual and machine documentation are written in different languages as
specified in the delivery contracts.
Note
We recommend engaging the support and services of your local Siemens service center for
all planning, installation, commissioning and maintenance work.

Motor reactors
Operating Instructions, 03/2012, A5E00409660A 7
General 2
Description
Motor reactors reduce the voltage load on the motor windings by reducing the voltage
gradients at the motor terminals that occur during converter operation. At the same time, the
capacitive charge/discharge currents that occur at the converter output when long motor
cables are used are reduced.
The maximum output frequency when a motor reactor is used is 150 Hz.
Note
The connecting cables to the Power Module must be kept as short as possible.
CAUTION
The surface temperature of the motor reactors may exceed 80°C.
CAUTION
The 100 mm cooling clearances above and to the side of the components must be
observed.
CAUTION
Provisions for component cooling must be made at the installation site. Power loss data are
given in the technical specifications.

General
Motor reactors
8 Operating Instructions, 03/2012, A5E00409660A
Assignment of motor reactor and Power Module
Table 2- 1 Assignment of motor reactor and Power Module
Power Module Unit rating of the Power Module Suitable motor reactor
Line voltage 380 – 480 V 3 AC
6SL3310-1GE32-1AAx 110 kW 6SL3000-2BE32-1AA0
6SL3310-1GE32-6AAx 132 kW 6SL3000-2BE32-6AA0
6SL3310-1GE33-1AAx 160 kW 6SL3000-2BE33-2AA0
6SL3310-1GE33-8AAx 200 kW 6SL3000-2BE33-8AA0
6SL3310-1GE35-0AAx 250 kW 6SL3000-2BE35-0AA0
6SL3310-1GE36-1AAx 315 kW 6SL3000-2AE36-1AA0
6SL3310-1GE37-5AAx 400 kW 6SL3000-2AE38-4AA0
6SL3310-1GE38-4AAx 450 kW 6SL3000-2AE38-4AA0
6SL3310-1GE41-0AAx 560 kW 6SL3000-2AE41-0AA0
Line voltage 500 – 600 V 3 AC
6SL3310-1GF31-8AAx 110 kW 6SL3000-2AH31-8AA0
6SL3310-1GF32-2AAx 132 kW 6SL3000-2AH32-4AA0
6SL3310-1GF32-6AAx 160 kW 6SL3000-2AH32-6AA0
6SL3310-1GF33-3AAx 200 kW 6SL3000-2AH33-6AA0
6SL3310-1GF34-1AAx 250 kW 6SL3000-2AH34-5AA0
6SL3310-1GF34-7AAx 315 kW 6SL3000-2AH34-7AA0
6SL3310-1GF35-8AAx 400 kW 6SL3000-2AH35-8AA0
6SL3310-1GF37-4AAx 500 kW 6SL3000-2AH38-1AA0
6SL3310-1GF38-1AAx 560 kW 6SL3000-2AH38-1AA0
Line voltage 660 – 690 V 3 AC
6SL3310-1GH28-5AAx 75 kW 6SL3000-2AH31-0AA0
6SL3310-1GH31-0AAx 90 kW 6SL3000-2AH31-0AA0
6SL3310-1GH31-2AAx 110 kW 6SL3000-2AH31-5AA0
6SL3310-1GH31-5AAx 132 kW 6SL3000-2AH31-5AA0
6SL3310-1GH31-8AAx 160 kW 6SL3000-2AH31-8AA0
6SL3310-1GH32-2AAx 200 kW 6SL3000-2AH32-4AA0
6SL3310-1GH32-6AAx 250 kW 6SL3000-2AH32-6AA0
6SL3310-1GH33-3AAx 315 kW 6SL3000-2AH33-6AA0
6SL3310-1GH34-1AAx 400 kW 6SL3000-2AH34-5AA0
6SL3310-1GH34-7AAx 450 kW 6SL3000-2AH34-7AA0
6SL3310-1GH35-8AAx 560 kW 6SL3000-2AH35-8AA0
6SL3310-1GH37-4AAx 710 kW 6SL3000-2AH38-1AA0
6SL3310-1GH38-1AAx 800 kW 6SL3000-2AH38-1AA0
