Siemens simovert masterdrives User manual

SIMOVERT MASTERDRIVES
Operating Instructions
Part 1
Compact units (Types A - D)
DC-AC
Edition: AD Order No.: 6SE7087-6BD70
www . ElectricalPartManuals . com

General 09.97
The reproduction, transmission or use of this document or its
contents is not permitted without express written authority.
Offenders will be liable for damages. All rights, including rights
created by patent grant or registration of a utility model or design,
are reserved.
We have checked the contents of this document to ensure that
they coincide with the described hardware and software.
However, differences cannot be completely excluded, so that we
do not accept any guarantee for complete conformance.
However, the information in this document is regularly checked
and necessary corrections will included in subsequent editions.
We are grateful for any recommendations for improvement. SIMOVERTRegistered Trade Mark
Siemens AG 1996 All rights reserved
Overview of the MASTER DRIVES Operating Instructions:
Operating Instructions consists of
Part 1 Part 2
6SE708_-_AD10 6SE708_-_AD70 6SE708_-_XX10
6SE708_-_AD20 6SE708_-_AD70 6SE708_-_XX20
6SE708_-_AD30 6SE708_-_AD70 6SE708_-_XX30
6SE708_-_BD10 6SE708_-_BD70 6SE708_-_XX10
6SE708_-_BD20 6SE708_-_BD70 6SE708_-_XX20
6SE708_-_BD30 6SE708_-_BD70 6SE708_-_XX30
6SE708_-_AH10 6SE708_-_AH70 6SE708_-_XX10
6SE708_-_AH20 6SE708_-_AH70 6SE708_-_XX20
6SE708_-_AH30 6SE708_-_AH70 6SE708_-_XX30
6SE708_-_BH10 6SE708_-_BH70 6SE708_-_XX10
6SE708_-_BH20 6SE708_-_BH70 6SE708_-_XX20
6SE708_-_BH30 6SE708_-_BH70 6SE708_-_XX30
6SE708_-_BM20 6SE708_-_BM70 6SE708_-_XX20
You will receive Parts 1 and 2 of the Operating Instructions when you use this Order No. Parts 1
and 2 can be individually ordered by specifying the particular Order No.
_-_ stands for the language code, e.g. 0-0 for German Editions.
The following foreign language Editions of these Operating Instructions are available:
Language German French Spanish Italian
Language code 0-0 7-7 7-8 7-2
These Operating Instructions are valid for software release V1.3.
www . ElectricalPartManuals . com

09.97 General
Siemens AG 6SE7087-6BD70 0-3
SIMOVERT MASTER DRIVES Operating Instructions
Contents
0 Definitions................................................................................................................................. 0-5
0.1 Safety and operating instructions for drive converters ............................................................... 0-7
1 Description................................................................................................................................ 1-1
1.1 Applications................................................................................................................................ 1-1
1.2 Mode of operation ...................................................................................................................... 1-2
1.3 Operator control- and open-loop control possibilities................................................................. 1-4
1.4 Block diagram............................................................................................................................. 1-4
2 Transport, Unpacking, Installation......................................................................................... 2-1
2.1 Transport and unpacking............................................................................................................ 2-1
2.2 Storage....................................................................................................................................... 2-1
2.3 Mounting..................................................................................................................................... 2-2
2.4 Dimension drawings................................................................................................................... 2-3
3 Connecting-up.......................................................................................................................... 3-1
3.1 Power connections..................................................................................................................... 3-2
3.1.1 Protective conductor connection ................................................................................................ 3-4
3.2 Auxiliary power supply / main contactor or bypass contactor / „Safety off“................................ 3-4
3.2.1 Drive converters for rated DC voltages 280 V to 310 V DC ....................................................... 3-4
3.2.2 Drive converters for rated DC voltages 510 V to 780 V DC ....................................................... 3-5
3.3 Instructions for EMC-correct installation..................................................................................... 3-6
4 Operator control....................................................................................................................... 4-1
4.1 Operator control elements.......................................................................................................... 4-1
4.2 Displays .................................................................................................................... 4-2
5 Maintenance.............................................................................................................................. 5-1
5.1 Maintenance requirements......................................................................................................... 5-1
5.2 Replacing components............................................................................................................... 5-2
5.2.1 Replacing the fan........................................................................................................................ 5-2
5.2.2 Replacing the fuses (size D)....................................................................................................... 5-3
5.2.3 Replacing boards........................................................................................................................ 5-3
5.2.3.1 Replacing boards in the electronics box..................................................................................... 5-4
5.2.3.2 Replacing the PMU (Parameterization Unit)............................................................................... 5-4
5.2.4 Replacing the DC fuses.............................................................................................................. 5-5
www . ElectricalPartManuals . com

General 09.97
0-4 Siemens AG 6SE7087-6BD70
SIMOVERT MASTER DRIVES Operating Instructions
6 Options...................................................................................................................................... 6-1
6.1 Options which can be integrated into the electronics box........................................................... 6-1
6.2 Interface boards.......................................................................................................................... 6-3
6.3 Power supplies ........................................................................................................................... 6-3
6.4 Isolating amplifiers...................................................................................................................... 6-4
6.5 Power section............................................................................................................................. 6-4
6.5.1 Output reactor, dv/dt filter, sinusoidal filter .................................................................................6-5
6.5.1.1 Output reactor............................................................................................................................. 6-6
6.5.1.2 dv/dt filter.................................................................................................................................... 6-7
6.5.1.3 Sinusoidal filter ........................................................................................................................... 6-8
6.5.1.4 Selection criteria for the output reactor, dv/d filter or sinusoidal filter......................................... 6-9
6.6 Bypass- and output contactor................................................................................................... 6-10
6.6.1 Bypass contactor (electrical DC link coupling).......................................................................... 6-10
6.6.1.1 Bypass contactor without I/R unit .............................................................................................6-10
6.6.1.2 Bypass contactor with I/R unit ..................................................................................................6-11
6.6.1.3 Connecting and disconnecting individual converters to the DC bus......................................... 6-12
6.6.2 Output contactor....................................................................................................................... 6-12
6.7 Operator control........................................................................................................................ 6-13
6.8 Mechanical design.................................................................................................................... 6-13
7 Spare Parts................................................................................................................................ 7-1
8 Environmental friendliness .....................................................................................................8-1
9 Technical Data.......................................................................................................................... 9-1
9.1 De-rating for an increased cooling medium temperature ...........................................................9-8
9.2 De-rating at installation altitudes > 1000 m above sea level....................................................... 9-8
9.3 De-rating as a function of the pulse frequency........................................................................... 9-9
10 Appendix................................................................................................................................. 10-1
10.1 Index......................................................................................................................................... 10-1
10.2 List of abbreviations.................................................................................................................. 10-2
11 Addresses............................................................................................................................... 11-1
12 Certificates.............................................................................................................................. 12-1
www . ElectricalPartManuals . com

09.97 General
Siemens AG 6SE7087-6BD70 0-5
SIMOVERT MASTER DRIVES Operating Instructions
0 Definitions
•QUALIFIED PERSONAL
For the purpose of these instructions and product labels, a "Qualified person" is someone who is familiar with
the installation, mounting, start-up and operation of the equipment and the hazards involved. He or she must
have the following qualifications:
1. Trained and authorized to energize, de-energize, clear, ground and tag circuits and equipment in
accordance with established safety procedures.
2. Trained in the proper care and use of protective equipment in accordance with established safety
procedures.
3. Trained in rendering first aid.
•DANGER
For the purpose of these instructions and product labels, "Danger" indicates death, severe personal injury or
substantial property damage will result if proper precautions are not taken.
•WARNING
For the purpose of these instructions and product labels, "Warning" indicates death, severe personal injury or
property damage can result if proper precautions are not taken.
•CAUTION
For the purpose of these instructions and product labels, "Caution" indicates that minor personal injury or
material damage can result if proper precautions are not taken.
•NOTE
For the purpose of these instructions, "Note" indicates information about the product or the respective part of
the Instruction Manual which is essential to highlight.
NOTE
These instructions do not purport to cover all details or variations in equipment, nor to provide for every
possible contingency to be met in connection with installation, operation or maintenance.
Should further information be desired or should particular problems arise which are not covered sufficiently for
the purchaser’s purposes, the matter should be referred to the local Siemens sales office.
The contents of this Instruction Manual shall not become part of or modify any prior or existing agreement,
committment or relationship. The sales contract contains the entire obligation of Siemens. The warranty
contained in the contract between the parties is the sole warranty of Siemens. Any statements contained herein
do not create new warranties or modify the existing warranty.
www . ElectricalPartManuals . com

General 09.97
0-6 Siemens AG 6SE7087-6BD70
SIMOVERT MASTER DRIVES Operating Instructions
CAUTION
Components which can be destroyed by electrostatic discharge (ESD)
The converters contain components which can be destroyed by electrostatic discharge. These components can
be easily destroyed if not carefully handled. If you have to handle electronic boards please observe the
following:
♦Electronic boards should only be touched when absolutely necessary.
♦The human body must be electrically discharged before touching an electronic board
♦Boards must not come into contact with highly insulating materials - e.g. plastic foils, insulated desktops,
articles of clothing manufactured from man-made fibers
♦Boards must only be placed on conductive surfaces
♦When soldering, the soldering iron tip must be grounded
♦Boards and components should only be stored and transported in conductive packaging (e.g. metalized
plastic boxes, metal containers)
♦If the packing material is not conductive, the boards must be wrapped with a conductive packaging material,
e.g. conductive foam rubber or household aluminum foil.
The necessary ECB protective measures are clearly shown in the following diagram:
a = Conductive floor surface d = ESD overall
b = ESD table e = ESD chain
c = ESD shoes f = Cubicle ground connection
StandingSitting Standing / Siting
a
b
e
d
c
d
a
c
d
b
ca
e
f
ff f f
WARNING
Hazardous voltages are present in this electrical equipment during operation.
Non-observance of the safety instructions can result in severe personal injury or property
damage.
Only qualified personnel should work on or around the equipment after first becoming
thoroughly familiar with all warning and safety notices and maintenance procedures
contained herein.
The successful and safe operation of this equipment is dependent on proper handling,
installation, operation and maintenance.
www . ElectricalPartManuals . com

09.97 General
Siemens AG 6SE7087-6BD70 0-7
SIMOVERT MASTER DRIVES Operating Instructions
0.1 Safety and operating instructions for drive converters
Safety and operating instructions
for drive converters
(in conformity with the low-voltage directive 73/23/EEC)
1. General
In operation, drive converters, depending on their degree of protection, may have live, uninsulated, and
possibly also moving or rotating parts, as well as hot surfaces.
In case of inadmissible removal of the required covers, of improper use, wrong installation or maloperation,
there is the danger of serious personal injury and damage to property.
For further information, see documentation.
All operations serving transport, installation and commissioning as well as maintenance are to be carried out
by skilled technical personnel (Observe IEC 364 or CENELEC HD 384 or DIN VDE 0100 and IEC 664 or
DIN/VDE 0110 and national accident prevention rules!).
For the purposes of these basic safety instructions, "skilled technical personnel" means persons who are
familiar with the installation, mounting, commissioning and operation of the product and have the qualifications
needed for the performance of their functions.
2. Intended use
Drive converters are components designed for inclusion in electrical installations or machinery.
In case of installation in machinery, commissioning of the drive converter (i.e. the starting of normal operation)
is prohibited until the machinery has been proved to conform to the provisions of the directive 89/392/EEC
(Machinery Safety Directive - MSD). Account is to be taken of EN 60204.
Commissioning (i.e. the starting of normal opertion) is admissible only where conformity with the EMC directive
(89/336/EEC) has been established.
The drive converters meet the requirements of the low-voltage directive 73/23/EEC. They are subject to the
harmonized standards of the series prEN 50178/DIN VDE 0160 in conjunction with EN 60439-1/ VDE 0660,
part 500, and EN 60146/ VDE 0558.
The technical data as well as information concerning the supply conditions shall be taken from the rating plate
and from the documentation and shall be strictly observed.
3. Transport, storage
The instructions for transport, storage and proper use shall be complied with.
The climatic conditions shall be in conformity with prEN 50178.
4. Installation
The installation and cooling of the appliances shall be in accordance with the specifications in the pertinent
documentation.
The drive converters shall be protected against excessive strains. In particular, no components must be bent
or isolating distances altered in the course of transportation or handling. No contact shall be made with
electronic components and contacts.
Drive converters contain electrostatic sensitive components which are liable to damage through improper use.
Electric components must not be mechanically damaged or destroyed (potential health risks).
www . ElectricalPartManuals . com

General 09.97
0-8 Siemens AG 6SE7087-6BD70
SIMOVERT MASTER DRIVES Operating Instructions
5. Electrical connection
When working on live drive converters, the applicable national accident prevention rules (e.g. VBG 4) must be
complied with.
The electrical installation shall be carried out in accordance with the relevant requirements (e.g. cross-sectional
areas of conductors, fusing, PE connection). For further information, see documentation.
Instructions for the installation in accordance with EMC requirements, like screening, earthing, location of filters
and wiring, are contained in the drive converter documentation. They must always be complied with, also for
drive converters bearing a CE marking. Observance of the limit values required by EMC law is the
responsibility of the manufacturer of the installation or machine.
6. Operation
Installations which include drive converters shall be equipped with additional control and protective devices in
accordance with the relevant applicable safety requirements, e.g. Act respecting technical equipment, accident
prevention rules etc. Changes to the drive converters by means of the operating software are admissible.
After disconnection of the drive converter from the voltage supply, live appliance parts and power terminals
must not be touched immediately because of possibly energized capacitors. In this respect, the corresponding
signs and markings on the drive converter must be respected.
During operation, all covers and doors shall be kept closed.
7. Maintenance and servicing
The manufacturer’s documentation shall be followed.
Keep safety instructions in a safe place!
www . ElectricalPartManuals . com

09.97 Description
Siemens AG 6SE7087-6BD70 1-1
SIMOVERT MASTER DRIVES Operating Instructions
1 Description
SIMOVERT MASTER DRIVES are power electronic units. They are available as
♦Compact units with three-phase- or DC current input
Output range: 2.2 kW to 37 kW
♦Chassis units with three-phase- or DC current input
Output range: 45 kW to 200 kW
♦Cabinet units with three-phase- or DC current input
Output range: 250 kW to 1500 kW
There are three versions depending on the particular application
♦Frequency control FC simple applications (e.g. pumps and fans)
♦Vector control VC High demands on dynamic performance and accuracy
♦Servo Control SC Servodrives
1.1 Applications
Drive converter with DC current input
DC drive converters generate a variable-frequency three-phase system at the motor side from a DC supply. This
variable-frequency three-phase system is used to continuously control the speed of three-phase motors.:
SIMOVERT MASTER DRIVES can be used with a common DC link, as well as for single-motor and multi-motor
drives.
Technological functions and expansions can be realized via defined interfaces in the open-loop control section.
www . ElectricalPartManuals . com

Description 09.97
1-2 Siemens AG 6SE7087-6BD70
SIMOVERT MASTER DRIVES Operating Instructions
1.2 Mode of operation
Converters with DC current input are suitable for coupling several converters to a common DC link bus. This
permits energy transfer between drives in the motoring and generating modes which in turn means energy
savings.
The DC converter must be connected to the DC bus through an E unit (rectifier unit) due to the pre-charging of
the DC link capacitors. If an I/R unit (rectifier and regenerative feedback unit) is used instead of the E unit, power
is fed back into the supply if the regenerative output for several drives is greater than the motor power required.
The converter is ready for operation after the DC link capacitors have been pre-charged.
The inverter, configured using IGBT modules, generates a three-phase system from the DC link voltage to feed
the motor.
SIMOVERT FC
The inverter open-loop control uses a microprocessor with an adjustable V/f characteristic. The pulse frequency
is preset to 3 kHz when the unit is shipped.
SIMOVERT FC is suitable for single-motor and multi-motor drives with:
♦Induction motors
♦Synchronous motors (SM)
♦Reluctance motors
Some of the applications are, for example:
♦Pump drives
♦Fan drives
♦Textile machines
The following can be set for the V/f characteristic:
♦Max. frequency 300 Hz
♦Operation with or without slip compensation
♦Operation with or without higher-level speed controller
www . ElectricalPartManuals . com

09.97 Description
Siemens AG 6SE7087-6BD70 1-3
SIMOVERT MASTER DRIVES Operating Instructions
SIMOVERT VC
The inverter open-loop control uses a microprocessor and field-oriented vector control with an extremely fast
closed-loop current control. The drive can be precisely adapted to the demanded load torque as a result of the
field-oriented control, which in turn means that the drive has an extremely high dynamic performance.The pulse
frequency is preset to 2.5 kHz when the unit is shipped.
SIMOVERT VC is suitable for:
♦Induction motors in both single-motor or multi-motor drives.
For multi-motor drives, the motors within the group must be the same.
Some of the applications are, for example:
♦Winder drives
♦Rolling mill drives.
When the drive is shipped, closed-loop V/f control is preset. Closed-loop frequency control with field-oriented
vector control must be parameterized.
The converter can be set, as a result of the precise motor simulation up to a maximum frequency of 300 Hz, with
and without stall protection and with and without tachometer feedback.
SIMOVERT SC
The inverter open-loop control uses a microprocessor with field-oriented vector control, with a very fast
secondary closed-loop current control. High drive dynamic performance is achieved as a result of the field
oriented vector control. When the unit is shipped, the pulse frequency is preset to 5 kHz.
It can be set in the range from 5 kHz to 7.5 kHz.
SIMOVERT SC is suitable for:
♦Single-motor drives with permanent-field 1FT6 motors
Some of the applications are, for example
♦Winder drives,
♦Foil machines,
♦Packaging machines
After power-up, only the motor must be selected and the drive can then be enabled. The drive can be matched to
the load moment of inertia and optimized by changing a closed-loop control parameter.
The converter operates with motor identification (MOTID). The maximum stator frequency is 400 Hz.
The following operating modes can be selected:
♦Closed-loop speed control
♦Closed-loop torque control
The following encoders can be used:
♦ERN 1387 encoders
♦Encoders which are compatible to ERN 1387
♦Resolvers
www . ElectricalPartManuals . com

Description 09.97
1-4 Siemens AG 6SE7087-6BD70
SIMOVERT MASTER DRIVES Operating Instructions
1.3 Operator control- and open-loop control possibilities
The unit can be controlled via
♦the parameterization unit (PMU)
♦an optional operator control panel (OP1)
♦terminal strip
♦a serial interface.
When networked with automation systems, the unit open-loop control is realized via optional interfaces and
technology boards.
1.4 Block diagram
Motor
connection
U2/T1
V2/T2
W2/T3
PE2
Inverter with
CU and PMU
CU PConnector for OP1
Terminal strip
Option boards-
in the elec-
tronics box
C / L+
D / L −
PE1
Fusing and
DC link
DC bus
connection
DC fuses
Fig. 1.1 Block diagram
www . ElectricalPartManuals . com

09.97 Transport, Unpacking, Installation
Siemens AG 6SE7087-6BD70 2-1
SIMOVERT MASTER DRIVES Operating Instructions
2 Transport, Unpacking, Installation
2.1 Transport and unpacking
The units are packed in the manufacturing plant corresponding to that specified when ordered. A product packing
label is located on the outside of the packing.
Please observe the instructions on the packaging for transport, storage and professional handling.
Vibration and jolts must be avoided during transport, e.g. when setting the unit down.
The converter can be installed after it has been unpacked and checked to ensure that everything is complete
and that the converter is not damaged.
If the converter is damaged you must inform your shipping company immediately.
The packaging comprises board and corrugated paper. It can be disposed of corresponding to the appropriate
local regulations for the disposal of board products.
2.2 Storage
The converters must be stored in clean dry rooms.Temperatures between −25 °C (−13 °F) and + 70 °C (158 °F)
are permissible. Temperature fluctuations > 20 K per hour are not permissible.
WARNING
The equipment should not be stored for longer than one year. If it is stored for longer
periods of time, the converter DC link capacitors must be formed at start-up.
Capacitor forming is described in Part 2 of the Operating Instructions.
www . ElectricalPartManuals . com

Transport, Unpacking, Installation 09.97
2-2 Siemens AG 6SE7087-6BD70
SIMOVERT MASTER DRIVES Operating Instructions
2.3 Mounting
The following are required for mounting:
♦G busbar according to EN50035 with screws for mounting
♦One M6 screw for types of construction A to C; two M6 screws for type of construction D
♦Dimension drawing (Fig. 2.2 for types of construction A, B and C, Fig. 2.3 for type of construction D).
WARNING
Safe converter operation requires that the equipment is mounted and commissioned by
qualified personnel taking into account the warning information provided in this Instruction
Manual.
The general and domestic installation and safety regulations for work on electrical power
equipment (e.g. VDE) must be observed as well as the professional handling of tools and
the use of personnal protective equipment.
Death, severe bodily injury or significant material damage could result if these instructions
are not followed.
The unit must be protected against the ingress of foreign bodies as otherwise the function
as well as the operational safety cannot be guaranteed.
Requirements at the point of installation:
The local guidelines and regulations must be observed when mounting and installing the
equipment.
The unit is mounted corresponding to the dimension drawings in Section 2.4.
Equipment rooms must be dry and dust-free.Ambient and cooling air must not contain
any electrically conductive gases, vapors and dusts which could diminish the
functionality. Dust-laden air must be filtered.
WARNING
When mounting in cabinets, a clearance of above and below
must be provided so that the cooling air flow is not restricted
(refer to dimension drawings, Section 2.4).
Dimension the cabinet cooling in line with the power loss!
(+Section „Technical data“)
The converter ambient climate in operating rooms may not exceed the values of code F
according to DIN 40040. For temperatures > 40 °C (104 °F) and installation altitudes
> 1000 m, de-rating is required (+Section „Technical data“).
SIMOVERT
MASTER
DRIVES
Cooling air
≤
40 °C (50 °C)
Fig. 2.1 Mounting the
converters in
cabinets
www . ElectricalPartManuals . com

09.97 Transport, Unpacking, Installation
Siemens AG 6SE7087-6BD70 2-3
SIMOVERT MASTER DRIVES Operating Instructions
2.4 Dimension drawings
350
cd
55
55
Darstellung ohne Frontabdeckung
view without front cover
Detail Z detail Z
Z
X1
X9
X2
X1
X9
Kompaktgeräte, Bauform A bis
C
Compact units, Type A to C
300
270
250
ac
425
425 67.5 135
600 90 180
45 90
Bauform/Type A
CL+ / DL
−
Anschluß
Connection CL+ / DL
−
Motoranschlußklemme Motor terminals
a
max. 5.7
Signalanschlüsse auf der CU Connectors on CU Schirmanschlagstellen für Signal- leitungen (2 Schirmschellen) Screen connection for two cables. Durchgangsloch für Schraube M6 Mounting hole for screw M6
Anschluß ext. SV und Hilfsschütz Connector for ext. power supply and auxiliary contactor
Haken (Aufhängung) zur Befestigung an einer G-Schiene nach EN50035 Hook (suspension) for mounting on a g-rail according to EN50035
100
e
e
37
70
38.5
X1
X2
Bauform/Type B Bauform/Type C
a
bd
Funktion "Sicheres Aus" nur bei Geräten für Bemessungsgleich- spannungen DC 510 V bis 780 V "Safety off" function only for units with DC rated voltages 510 V to 780 V DC.
47
70
48.5
b
Fig. 2.2 Types A, B and C
www . ElectricalPartManuals . com

Transport, Unpacking, Installation 09.97
2-4 Siemens AG 6SE7087-6BD70
SIMOVERT MASTER DRIVES Operating Instructions
F101 F102
60
45 180
270
250
350
600
X9
600
Darstellung ohne Frontabdeckung
view without front cover
Detail Z detail Z
X1
X9
X2
X1
Z
Kompaktgeräte, Bauform Compact units, type D
310
Motoranschlußklemme Motor terminals Signalanschlüsse auf der CU Connectors on CU Schirmanschlagstellen für Signal- leitungen (2 Schirmschellen) Screen connection for two cables.
Durchgangsloch für Schraube M6 Mounting hole for screw M6
Haken (Aufhängung) zur Befestigung an einer G-Schiene nach EN50035 Hook (suspension) for mounting on a g-rail according to EN50035
90
Anpassung Ventilatorspannung Adjustment fan voltage
Ventilator-Sicherungen Fan-fuses
100
Ventilator-Sicherungen Fan-fuses
Anschluß ext. SV und Hilfsschütz Connector for ext. power supply and auxiliary contactor max. 5.7
X1
X2
CL+
/
DL
−
Ansch
l
u
ß
Connec
ti
on
CL+
/
DL
−
Funktion "Sicheres Aus" nur bei Geräten für Bemessungsgleich- spannungen DC 510 V bis 780 V "Safety off" function only for units with DC rated voltages
5
1
0
V
t
o
7
8
0
V
D
C
90
90
Fig. 2.3 Type D
www . ElectricalPartManuals . com

09.97 Connecting-up
Siemens AG 6SE7087-6BD70 3-1
SIMOVERT MASTER DRIVES Operating Instructions
3 Connecting-up
WARNING
SIMOVERT MASTER DRIVES are operated at high voltages.
The equipment must be in a no-voltage condition (disconnected from the supply) before any
work is carried-out!
Only professionally trained, qualified personnel must work on or with the unit.
Death, severe bodily injury or significant material damage could occur if these warning
instructions are not observed.
Extreme caution should be taken when working-on the unit when it is open, as external
power supplies may be connected. The power terminals and control terminals can still be at
hazardous potentials even when the motor is stationary.
Hazardous voltages are still present in the unit up to 5 minutes after it has been powered-
down due to the DC link capacitors. Thus, the appropriate delay time must be observed
before opening-up the unit.
Forming the DC link capacitors:
The storage time should not exceed one year. The converter DC link capacitors must be
formed at start-up if the unit has been stored for a longer period of time.
Forming is described in the Instruction Manual, Part 2.
When the DC link is supplied from a central unit, it must be ensured that the converter is
reliably isolated from the DC link voltage!
The user is responsible, that the motor, converter and any other associated devices or units
are installed and connected-up according to all of the recognized regulations in that
particular country as well as other regionally valid regulations. Cable dimensioning, fusing,
grounding, shutdown, isolation and overcurrent protection should be especially observed.
INFORMATION
♦Cabling/wiring: Connecting cables should be dimensioned according to the local regulations and according
to section „Power connections“. The insulation should be suitable for 75°C.
www . ElectricalPartManuals . com

Connecting-up 09.97
3-2 Siemens AG 6SE7087-6BD70
SIMOVERT MASTER DRIVES Operating Instructions
3.1 Power connections
WARNING
♦By interchanging the input terminals, the converter or the rectifier will be destroyed!
♦The drive converter or rectifier unit could be destroyed if the input terminals are
interchanged!
♦The coils of contacts and relays which are connected to the same supply as the
converter or are located in the vicinity of the converter, must be provided with
overvoltage limiters, e.g. RC elements.
The position of the connecting terminals can be seen in the dimension drawings (+Section 2.4).
DC connection: C/L+ D/L−
Motor connection: U2/T1 V2/T2 W2/T3
Protective conductor connection: PE1 PE2
The cross-sections listed in Table 3.2 are defined by the terminal size.
NOTE
For type of construction D, an external 230 V AC auxiliary voltage must be connected at F101 and F102.
This auxiliary voltage is required for the unit fan.
NOTE FC and VC
Depending on the motor insulation strength and the length of the motor feeder cable, it may be necessary to
install one of the following options between the motor and the converter:
♦Output reactor
♦dv/dt-filter only for FC and VC, not permissible for SC
♦Sinusoidal filter only for FC and VC, not permissible for SC
Information regarding selection and dimensioning is provided in Section „Options“.
www . ElectricalPartManuals . com

09.97 Connecting-up
Siemens AG 6SE7087-6BD70 3-3
SIMOVERT MASTER DRIVES Operating Instructions
Order Supply side Motor side
No. Rated
DC Cross- Recommende
d fuse Internal DC fuse Rated output Cross-section
Curr. section Voltage Curr.
VDE VDE
(A) (mm2)AWG1) (A) Type Type (V) (A) (V) (A) (mm2)AWG
6SE70 3NE FWP
Rated DC Voltage 280 V to 310 V
21-1RA_0 12,6 1,5 16 25 8 015 −0 to 230 10,6 1,5 16
21-3RA_0 15,8 2,5 14 35 8 003 −0 to 230 13,3 1,5 16
21-8RB_0 21,1 4 10 50 8 017 −0 to 230 17,7 2,5 14
22-3RB_0 27,3 6 8 80 8 020 −0 to 230 22,9 4 10
23-2RB_0 38,3 10 6 100 8 021 −0 to 230 32,2 10 6
24-4RC_0 52,6 16 4 125 8 022 −0 to 230 44,2 16 4
25-4RD_0 64,3 35 2 160 8 024 −0 to 230 54,0 25 2
27-0RD_0 82,1 35 2 160 8 024 −0 to 230 69 25 2
28-1RD_0 96,4 50 0 160 4 124 −0 to 230 81 35 0
Rated DC Voltage 510 V to 620 V
16-1TA_1 7,3 1,5 16 25 8 015 25A14F 700 25 0 to 460 6,1 1,5 16
18-0TA_1 9,5 1,5 16 25 8 015 50A14F 700 50 0 to 460 8,0 1,5 16
21-0TA_1 12,1 1,5 16 25 8 015 50A14F 700 50 0 to 460 10,2 1,5 16
21-3TB_1 15,7 4 10 50 8 017 50A22F 700 50 0 to 460 13,2 2,5 14
21-8TB_1 20,8 4 10 50 8 017 50A22F 700 50 0 to 460 17,5 2,5 14
22-6TC_1 30,4 10 6 80 8 020 100A22F 700 100 0 to 460 25,5 6 8
23-4TC_1 40,5 10 6 80 8 020 100A22F 700 100 0 to 460 34 10 6
23-8TD_1 44,6 16 4 125 8 022 100A22F 700 100 0 to 460 37,5 16 4
24-7TD_1 55,9 25 2 125 8 022 100A22F 700 100 0 to 460 47 16 4
26-0TD_1 70,2 35 0 160 8 024 80A22F 700 2x80 0 to 460 59 25 2
27-2TD_1 85,7 35 0 160 8 024 80A22F 700 2x80 0 to 460 72 25 2
Rated DC Voltage 675 V to 780 V (only for SC and VC)
14-5UB_1 5,4 1,5 16 32 4 101 50A22F 700 50 0 to 575 4,5 1,5 16
16-2UB_1 7,4 1,5 16 32 4 101 50A22F 700 50 0 to 575 6,2 1,5 16
17-8UB_1 9,3 2,5 14 32 4 101 50A22F 700 50 0 to 575 7,8 1,5 16
21-1UB_1 13,0 4 10 32 4 101 50A22F 700 50 0 to 575 11 1,5 16
21-5UB_1 18,0 4 10 32 4 101 50A22F 700 50 0 to 575 15,1 1,5 16
22-2UC_1 26,2 6 8 50 4 117 50A22F 700 50 0 to 575 22 4 10
23-0UD_1 34,5 16 4 80 4 120 100A22F 700 100 0 to 575 29 10 6
23-4UD_1 40,5 16 4 80 4 120 100A22F 700 100 0 to 575 34 10 6
24-7UD_1 55,4 25 2 100 4 121 100A22F 700 100 0 to 575 46,5 16 4
INFORMATION AND EXPLANATIONS
The cross-sections are determined for copper cables at 40 °C (104 °F) ambient temperature (in accordance
with DIN VDE 0298 Part 4 / 02.88 Group 5).
For rated DC voltages 510 V to 780 V DC, fuses on the incoming supply side are not required as the unit has
integrated DC fuses; this assumes that the connecting cables to the DC bus are routed so that they are short-
circuit proof and the cable cannot be overloaded by other loads.
1) American Wire Gauge
Table 3.1 Power connections acc. to DIN VDE
www . ElectricalPartManuals . com

Connecting-up 09.97
3-4 Siemens AG 6SE7087-6BD70
SIMOVERT MASTER DRIVES Operating Instructions
Type Order No. Possible connection cross-section for power terminals
Finely stranded Multi-stranded/solid
(mm2)AWG (mm2)AWG
A 6SE702_-_ _ A_ _ 1.5 to 10 12 to 6 2.5 to 16 12 to 4
B 6SE702_-_ _ B_ _ 1.5 to 10 12 to 6 2.5 to 16 12 to 4
C 6SE702_-_ _ C_ _ 4 to 16 10 to 4 10 to 25 6 to 2
D 6SE702_-_ _ D_ _ 10 to 35 6 to 2 10 to 50 6 to 0
Table 3.2 Possible connection cross-sections
3.1.1 Protective conductor connection
The protective conductor should be connected-up on both the supply- and motor sides. It should be dimensioned
according to the power connections. Due to discharge currents from the noise suppression capacitors, according
to VDE 0160, a minimum cross-section of 10 mm2is required, or a second protective conductor with the same
cross-section must be routed in parallel (for cross-sections < 10 mm2).
3.2 Auxiliary power supply / main contactor or bypass contactor /
„Safety off“
3.2.1 Drive converters for rated DC voltages 280 V to 310 V DC
The auxiliary power supply and the main- or bypass contactor are connected through the 5-pin connector X9.
Connector X9 is supplied together with the connectors for the control terminal strip. Cables with cross-sections
from 0.2 mm2to 2.5 mm2(AWG: 24 to 14) can be connected at X9.
The auxiliary power supply is required if the drive converter is fed through a main-
and bypass contactor.
The main- or monitoring contactor is controlled through floating contacts -X9.4
and -X9.5 (software pre-setting).
More detailed information is provided in the Section „options“.
Term. Function description
1 24 V DC external ≥2.1 A
(max. 4 A dependent on the options)
2 Reference potential to DC
3 Unassigned
4 Main contactor control
5 Main contactor control
Table 3.3 Connector assignment for -X9
NOTE
The main contactor coil must be provided with overvoltage limiters, e.g. RC element.
12345
-X9
PM
ext. 24 VDC
pwr.supp.
AC 230
1 kVA
Main contactor
control
Fig. 3.1 Connecting an
external auxiliary
24 V DC power
supply and main
contactor control
www . ElectricalPartManuals . com
