Siemens SINAMICS G110M User manual

___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
SINAMICS
SINAMICS G110M
Distributed converter for
SIMOGEAR geared motors
Operating Instructions
Edition 09/2017, Firmware V4.7 SP9
Original instructions
09/2017, FW V4.7.9
A5E31298649B AH
Changes in this manual
Fundamental safety
instructions
1
Introduction
2
Description
3
Installation
4
Commissioning
5
Advanced commissioning
6
Data backup and series
commissioning
7
Alarms, faults and system
messages
8
Service and maintenance
9
Technical data
10
Appendix
A

Siemens AG
Division Digital Factory
Postfach 48 48
90026 NÜRNBERG
GERMANY
Document order number: (null)
Ⓟ
09/2017 Subject to change
Copyright © Siemens AG 2013 - 2017.
All rights
reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

Distributed converter for SIMOGEAR geared motors
Operating Instructions, 09/2017, FW V4.7.9, A5E31298649B AH 5
Changes in this manual
Essential changes with respect to Edition 07/2016
New functions
●Improved efficiency optimization of induction motors
Efficiency optimization (Page 275)
●The converter reports a warning if no memory card is plugged.
Activate message for a memory card that is not inserted (Page 291)
Overview of all the new and changed functions in the V4.7 SP9 firmware:
Firmware version 4.7 SP9 (Page 347)
Corrections
●Function "motor holding brake" is corrected:
–The converter sets the signal "operation enabled" to "high" after the time p1216 (not
with the ON command)
–The converter sets the signal "operation enabled" to "low" with the OFF command (not
with the signal "magnetizing completed")
Motor holding brake (Page 185)
●LED state when updating the firmware has been corrected
Firmware upgrade and downgrade (Page 332)
●We recommend that you also activate the friction characteristic when you use the
"moment of inertia estimator" function.
An appropriate note has been added to the description of the "moment of inertia
estimator" function.
Moment of inertia estimator (Page 246)
Revised chapter
●Description for drive control via PROFIBUS and PROFINET revised
Drive control via PROFIBUS or PROFINET (Page 149)
●Summary of the directives and standards relevant for the inverter added
Directives and standards (Page 38)
●Description of the differences for star and delta connection of an induction motor added
Connecting the motor to the inverter in a star or delta connection (Page 78)

Changes in this manual
Distributed converter for SIMOGEAR geared motors
6Operating Instructions, 09/2017, FW V4.7.9, A5E31298649B AH
●Sorting of the inverter functions changed, new "Energy saving" and "Availability"
categories
Overview of converter functions (Page 139)
●LED symbols added, tables revised
Status LED overview (Page 303)
●Descriptions shortened and graphics simplified
Alarms, alarm buffer, and alarm history (Page 308)
Faults, alarm buffer and alarm history (Page 311)
●Fault and alarm lists combined to form a common list
List of alarms and faults (Page 314)
●The description for the firmware upgrade or downgrade extended, graphics revised
Firmware upgrade and downgrade (Page 332)
●The description for the know-how protection revised
Know-how protection (Page 295)

Distributed converter for SIMOGEAR geared motors
Operating Instructions, 09/2017, FW V4.7.9, A5E31298649B AH 7
Table of contents
Changes in this manual........................................................................................................................... 5
1 Fundamental safety instructions............................................................................................................ 13
1.1 General safety instructions .....................................................................................................13
1.2 Equipment damage due to electric fields or electrostatic discharge ......................................18
1.3 Warranty and liability for application examples ......................................................................18
1.4 Industrial security ....................................................................................................................19
1.5 Residual risks of power drive systems....................................................................................20
2 Introduction........................................................................................................................................... 23
2.1 About the Manual....................................................................................................................23
3 Description............................................................................................................................................ 27
3.1 Identifying the components of the system ..............................................................................27
3.2 SINAMICS G110M converter..................................................................................................29
3.3 General layout SINAMICS G110M system.............................................................................33
3.4 Directives and standards ........................................................................................................38
4 Installation ............................................................................................................................................ 41
4.1 Mechanical Installation............................................................................................................42
4.2 System Installation..................................................................................................................46
4.2.1 Installing the 24V power supply ..............................................................................................59
4.3 Electrical Installation ...............................................................................................................63
4.3.1 SINAMICS G110M Electrical data ..........................................................................................63
4.3.2 EMC installation guidelines.....................................................................................................66
4.3.2.1 Connections and interference suppression ............................................................................66
4.3.2.2 Basic EMC rules .....................................................................................................................66
4.3.2.3 Equipotential bonding .............................................................................................................67
4.3.3 Protective conductor ...............................................................................................................69
4.3.4 Connection and cables ...........................................................................................................70
4.3.5 Connecting the motor to the inverter in a star or delta connection.........................................78
4.3.6 Cable protection......................................................................................................................79
4.3.7 Connecting the PROFINET interface......................................................................................81
4.3.8 Terminal assignment dependent on interface configuration...................................................82
4.3.9 Wiring example for the factory settings...................................................................................82
4.4 Connecting the inverter to the fieldbus ...................................................................................90
4.4.1 Fieldbus version of the Control Module ..................................................................................90
4.4.2 PROFINET..............................................................................................................................90
4.4.2.1 What do you need for communication via PROFINET? .........................................................92
4.4.2.2 Connect the converter to PROFINET .....................................................................................92
4.4.2.3 Configuring communication to the control ..............................................................................93

Table of contents
Distributed converter for SIMOGEAR geared motors
8Operating Instructions, 09/2017, FW V4.7.9, A5E31298649B AH
4.4.2.4 Installing GSDML ................................................................................................................... 93
4.4.3 PROFIBUS............................................................................................................................. 94
4.4.3.1 What do you need for communication via PROFIBUS? ........................................................ 94
4.4.3.2 Integrating the inverter in PROFIBUS.................................................................................... 94
4.4.3.3 Configuring the communication using SIMATIC S7 control................................................... 95
4.4.3.4 Installing the GSD .................................................................................................................. 95
4.4.3.5 Setting the address ................................................................................................................ 95
4.4.4 Communications via AS-i....................................................................................................... 96
4.4.4.1 Setting the address ................................................................................................................ 97
4.4.4.2 Using the AS-i Programmer ................................................................................................... 99
5 Commissioning ....................................................................................................................................103
5.1 Commissioning guidelines ................................................................................................... 103
5.2 Commissioning tools............................................................................................................ 104
5.3 Prepare commissioning ....................................................................................................... 105
5.3.1 Collecting motor data ........................................................................................................... 106
5.3.2 Inverter factory setting ......................................................................................................... 108
5.3.3 V/f control or speed control .................................................................................................. 109
5.3.4 Defining additional requirements for the application............................................................ 111
5.4 Quick commissioning ........................................................................................................... 111
5.4.1 Motor data using p300 and p301 ......................................................................................... 111
5.4.2 Quick Commissioning with DIP switches............................................................................. 113
5.4.3 Basic commissioning with the IOP-2 ................................................................................... 119
5.4.4 p0015 Macros ...................................................................................................................... 122
5.4.5 Quick commissioning with STARTER.................................................................................. 127
5.4.5.1 Adapting the USB interface.................................................................................................. 128
5.4.5.2 Generating a STARTER project........................................................................................... 129
5.4.5.3 Go online and start the configuration wizards - STARTER ................................................. 130
5.4.5.4 Identify motor data - STARTER ........................................................................................... 133
5.5 Restoring the factory settings .............................................................................................. 134
5.5.1 Resetting the safety functions to the factory setting ............................................................ 135
5.5.2 Restore the factory settings (without safety functions) ........................................................ 137
6 Advanced commissioning.....................................................................................................................139
6.1 Overview of converter functions........................................................................................... 139
6.2 Sequence control when switching the motor on and off ...................................................... 142
6.3 Adapt the default setting of the inputs and outputs.............................................................. 143
6.3.1 Digital Inputs ........................................................................................................................ 144
6.3.2 Digital outputs ...................................................................................................................... 145
6.3.3 Analog inputs ....................................................................................................................... 146
6.4 Drive control via PROFIBUS or PROFINET ........................................................................ 149
6.4.1 Receive data and send data ................................................................................................ 149
6.4.2 Telegrams ............................................................................................................................ 150
6.4.3 Control and status word 1 .................................................................................................... 153
6.4.4 Control and status word 3 .................................................................................................... 155
6.4.5 NAMUR message word ....................................................................................................... 157
6.4.6 Parameter channel............................................................................................................... 158
6.4.7 Examples for using the parameter channel ......................................................................... 161
6.4.8 Extend telegrams and change signal interconnection ......................................................... 163

Table of contents
Distributed converter for SIMOGEAR geared motors
Operating Instructions, 09/2017, FW V4.7.9, A5E31298649B AH 9
6.4.9 Slave-to-slave communication..............................................................................................165
6.5 Control via AS-i .....................................................................................................................165
6.5.1 Single slave mode.................................................................................................................165
6.5.2 Dual slave mode ...................................................................................................................167
6.5.3 Assignment tables.................................................................................................................170
6.5.4 Cyclic and acyclic communication via CTT2 ........................................................................172
6.5.5 Cyclic communication ...........................................................................................................173
6.5.6 Acyclic communication - standard ........................................................................................174
6.5.7 Acyclic communication - manufacturer-specific....................................................................174
6.6 Jogging .................................................................................................................................176
6.7 Limit position control .............................................................................................................177
6.8 Quick Stop function...............................................................................................................180
6.9 Switching over the drive control (command data set)...........................................................183
6.10 Motor holding brake ..............................................................................................................185
6.11 Free function blocks..............................................................................................................189
6.11.1 Overview ...............................................................................................................................189
6.11.2 Further information................................................................................................................189
6.12 Selecting physical units.........................................................................................................189
6.12.1 Select the motor standard.....................................................................................................189
6.12.2 Selecting the system of units ................................................................................................190
6.12.3 Selecting the technological unit of the technology controller................................................191
6.12.4 Setting the motor standard, system of units and technology unit using STARTER .............192
6.13 Safe Torque Off (STO) safety function .................................................................................
193
6.13.1 Function description..............................................................................................................193
6.13.2 ((Precondition for using STO))..............................................................................................196
6.13.3 Commissioning STO .............................................................................................................196
6.13.3.1 ((Commissioning tools))........................................................................................................196
6.13.3.2 Safety functions password....................................................................................................196
6.13.3.3 Configuring safety function ...................................................................................................198
6.13.3.4 Interconnecting the "STO active" signal ...............................................................................200
6.13.3.5 Setting the filter for fail-safe digital inputs.............................................................................201
6.13.3.6 (Basic filter parameters)).......................................................................................................204
6.13.3.7 Setting the forced checking procedure (test stop) ................................................................204
6.13.3.8 Activating the settings and checking the digital inputs .........................................................206
6.13.3.9 Acceptance - completion of commissioning..........................................................................210
6.14 Setpoints ...............................................................................................................................213
6.14.1 Overview ...............................................................................................................................213
6.14.2 Analog input as setpoint source............................................................................................214
6.14.3 Specifying the setpoint via the fieldbus.................................................................................214
6.14.4 Electromechanical potentiometer .........................................................................................215
6.14.5 Motorized potentiometer as setpoint source.........................................................................216
6.14.6 Fixed speed setpoint as setpoint source ..............................................................................218
6.15 Setpoint calculation...............................................................................................................220
6.15.1 Overview of setpoint processing...........................................................................................220
6.15.2 Invert setpoint .......................................................................................................................220
6.15.3 Inhibit direction of rotation.....................................................................................................221
6.15.4 Skip frequency bands and minimum speed..........................................................................222

Table of contents
Distributed converter for SIMOGEAR geared motors
10 Operating Instructions, 09/2017, FW V4.7.9, A5E31298649B AH
6.15.5 Speed limitation.................................................................................................................... 223
6.15.6 Ramp-function generator ..................................................................................................... 223
6.16 PID technology controller..................................................................................................... 228
6.16.1 Overview .............................................................................................................................. 228
6.16.2 Setting the controller ............................................................................................................ 229
6.16.3 Optimizing the controller ...................................................................................................... 232
6.17 Motor control ........................................................................................................................ 233
6.17.1 V/f control ............................................................................................................................. 233
6.17.1.1 Characteristics of U/f control................................................................................................ 234
6.17.1.2 Selecting the U/f characteristic ............................................................................................ 235
6.17.1.3 Optimizing motor starting ..................................................................................................... 236
6.17.2 Sensorless vector control with speed controller .................................................................. 238
6.17.2.1 Structure of vector control without encoder (sensorless)..................................................... 238
6.17.2.2 Optimizing the closed-loop speed controller........................................................................ 240
6.17.2.3 Advanced settings................................................................................................................ 242
6.17.2.4 Friction characteristic ........................................................................................................... 244
6.17.2.5 Moment of inertia estimator ................................................................................................. 246
6.17.2.6 Pole position identification ................................................................................................... 252
6.17.3 Torque control ...................................................................................................................... 253
6.18 Elektrically braking the motor............................................................................................... 254
6.18.1 DC braking ........................................................................................................................... 254
6.18.2 Dynamic braking .................................................................................................................. 257
6.19 Overcurrent protection ......................................................................................................... 260
6.20 Inverter protection using temperature monitoring ................................................................ 261
6.21 Motor temperature monitoring using a temperature sensor ................................................ 264
6.22 Motor protection by calculating the temperature.................................................................. 267
6.23 Motor and inverter protection by limiting the voltage ........................................................... 269
6.24 Monitoring the driven load.................................................................................................... 270
6.24.1 No-load monitoring............................................................................................................... 270
6.24.2 Rotation monitoring.............................................................................................................. 271
6.24.3 Torque monitoring ................................................................................................................ 272
6.25 Efficiency optimization ......................................................................................................... 275
6.26 Calculating the energy saving for fluid flow machines......................................................... 278
6.27 Switchover between different settings ................................................................................. 280
7 Data backup and series commissioning ...............................................................................................283
7.1 Backing up and transferring settings using memory card.................................................... 284
7.1.1 Saving settings to the memory card..................................................................................... 284
7.1.2 Transferring the settings from the memory card.................................................................. 286
7.1.3 Manually transferring the settings from the memory card ................................................... 287
7.1.4 Safely remove the memory card.......................................................................................... 289
7.1.5 Activate message for a memory card that is not inserted.................................................... 291
7.2 Backing up and transferring settings via STARTER ............................................................ 292
7.3 Other ways to back up settings............................................................................................ 293
7.4 Write protection.................................................................................................................... 293

Table of contents
Distributed converter for SIMOGEAR geared motors
Operating Instructions, 09/2017, FW V4.7.9, A5E31298649B AH 11
7.5 Know-how protection ............................................................................................................295
7.5.1 Extending the exception list for know-how protection...........................................................297
7.5.2 Activating and deactivating know-how protection.................................................................298
8 Alarms, faults and system messages .................................................................................................. 303
8.1 Status LED overview.............................................................................................................303
8.2 Operating states indicated on LEDs .....................................................................................304
8.3 System runtime .....................................................................................................................306
8.4 Identification & maintenance data (I&M)...............................................................................307
8.5 Alarms, alarm buffer, and alarm history................................................................................308
8.6 Faults, alarm buffer and alarm history ..................................................................................311
8.7 List of alarms and faults ........................................................................................................314
9 Service and maintenance.................................................................................................................... 323
9.1 Spare parts compatibility ......................................................................................................323
9.2 Replacing converter components .........................................................................................323
9.2.1 Overview of replacing converter components ......................................................................324
9.2.2 Replacing the Control Module ..............................................................................................326
9.2.3 Replacing a Control Module with active know-how protection .............................................327
9.2.4 Replacing the Power Module................................................................................................330
9.3 Correcting a failed firmware upgrade or downgrade ............................................................331
9.4 Firmware upgrade and downgrade.......................................................................................332
9.4.1 Upgrading firmware...............................................................................................................334
9.4.2 Firmware downgrade ............................................................................................................336
10 Technical data .................................................................................................................................... 339
10.1 Performance ratings of the Control Module - CU240M ........................................................339
10.2 Performance ratings Power Module - PM240M....................................................................340
10.3 SINAMICS G110M specifications .........................................................................................341
10.4 Ambient operating temperature ............................................................................................343
10.5 Current derating - depending on the installation altitude ......................................................344
10.6 Pulse frequency and current reduction .................................................................................345
A Appendix............................................................................................................................................. 347
A.1 New and extended functions ................................................................................................347
A.1.1 Firmware version 4.7 SP9 ....................................................................................................347
A.1.2 Firmware version 4.7 SP3 ....................................................................................................350
A.1.3 Firmware version 4.7 ............................................................................................................353
A.1.4 Firmware version 4.6 SP6 ....................................................................................................354
A.1.5 Firmware version 4.6 ............................................................................................................355
A.2 The device trace in STARTER..............................................................................................356
A.3 Interconnecting signals in the inverter ..................................................................................359
A.3.1 Fundamentals .......................................................................................................................359
A.3.2 Application example..............................................................................................................361

Table of contents
Distributed converter for SIMOGEAR geared motors
12 Operating Instructions, 09/2017, FW V4.7.9, A5E31298649B AH
A.4 Acceptance tests for the safety functions ............................................................................ 363
A.4.1 Recommended acceptance test .......................................................................................... 363
A.4.2 Acceptance test STO (basic functions)................................................................................ 364
A.4.3 Machine documentation....................................................................................................... 366
A.4.4 Documenting the settings for the basic functions, firmware V4.4 ... V4.7 SP6 ................... 368
A.5 Electromagnetic Compatibility.............................................................................................. 369
A.6 Manuals and technical support ............................................................................................ 372
A.6.1 Manuals for your converter .................................................................................................. 372
A.6.2 Configuring support.............................................................................................................. 373
A.6.3 Product Support ................................................................................................................... 374
A.7 Mistakes and improvements ................................................................................................ 374
Index ...................................................................................................................................................375

Distributed converter for SIMOGEAR geared motors
Operating Instructions, 09/2017, FW V4.7.9, A5E31298649B AH 13
Fundamental safety instructions
1
1.1
General safety instructions
WARNING
Electric shock and danger to life due to other energy sources
Touching live components can result in death or severe injury.
•Only work on electrical devices when you are qualified for this job.
•Always observe the country-specific safety rules.
Generally, the following six steps apply when establishing safety:
1. Prepare for disconnection. Notify all those who will be affected by the procedure.
2. Isolate the drive system from the power supply and take measures to prevent it being
switched back on again.
3. Wait until the discharge time specified on the warning labels has elapsed.
4. Check that there is no voltage between any of the power connections, and between any
of the power connections and the protective conductor connection.
5. Check whether the existing auxiliary supply circuits are de-energized.
6. Ensure that the motors cannot move.
7. Identify all other dangerous energy sources, e.g. compressed air, hydraulic systems, or
water. Switch the energy sources to a safe state.
8. Check that the correct drive system is completely locked.
After you have completed the work, restore the operational readiness in the inverse
sequence.
WARNING
Electric shock due to connection to an unsuitable power supply
When equipment is connected to an unsuitable power supply, exposed components may
carry a hazardous voltage that might result in serious injury or death.
•Only use power supplies that provide SELV (Safety Extra Low Voltage) or PELV-
(Protective Extra Low Voltage) output voltages for all connections and terminals of the
electronics modules.

Fundamental safety instructions
1.1 General safety instructions
Distributed converter for SIMOGEAR geared motors
14 Operating Instructions, 09/2017, FW V4.7.9, A5E31298649B AH
WARNING
Electric shock due to equipment damage
Improper handling may cause damage to equipment. For damaged devices, hazardous
voltages can be present at the enclosure or at exposed components; if touched, this can
result in death or severe injury.
•Ensure compliance with the limit values specified in the technical data during transport,
storage and operation.
•Do not use any damaged devices.
WARNING
Electric shock due to unconnected cable shield
Hazardous touch voltages can occur through capacitive cross-coupling due to unconnected
cable shields.
•As a minimum, connect cable shields and the conductors of power cables that are not
used (e.g. brake cores) at one end at the grounded housing potential.
WARNING
Electric shock if there is no ground connection
For missing or incorrectly implemented protective conductor connection for devices with
protection class I, high voltages can be present at open, exposed parts, which when
touched, can result in death or severe injury.
•Ground the device in compliance with the applicable regulations.
WARNING
Arcing when a plug connection is opened during operation
Opening a plug connection when a system is operation can result in arcing that may cause
serious injury or death.
•Only open plug connections when the equipment is in a voltage-free state, unless it has
been explicitly stated that they can be opened in operation.
WARNING
Electric shock due to residual charges in power components
Because of the capacitors, a hazardous voltage is present for up to 5 minutes after the
power supply has been switched off. Contact with live parts can result in death or serious
injury.
•Wait for 5 minutes before you check that the unit really is in a no-voltage condition and
start work.

Fundamental safety instructions
1.1 General safety instructions
Distributed converter for SIMOGEAR geared motors
Operating Instructions, 09/2017, FW V4.7.9, A5E31298649B AH 15
NOTICE
Property damage due to loose power connections
Insufficient tightening torques or vibration can result in loose power connections. This can
result in damage due to fire, device defects or malfunctions.
•Tighten all power connections to the prescribed torque.
•Check all power connections at regular intervals, particularly after equipment has been
transported.
WARNING
Spread of fire from built-in devices
In the event of fire outbreak, the enclosures of built-in devices cannot prevent the escape of
fire and smoke. This can result in serious personal injury or property damage.
•Install built-in units in a suitable metal cabinet in such a way that personnel are
protected against fire and smoke, or take other appropriate measures to protect
personnel.
•Ensure that smoke can only escape via controlled and monitored paths.
WARNING
Failure of pacemakers or implant malfunctions due to electromagnetic fields
Electromagnetic fields (EMF) are generated by the operation of electrical power equipment,
such as transformers, converters, or motors. People with pacemakers or implants in the
immediate vicinity of this equipment are at particular risk.
•If you have a heart pacemaker or implant, maintain a minimum distance of 2 m from
electrical power equipment.
WARNING
Unexpected movement of machines caused by radio devices or mobile phones
When radio devices or mobile phones with a transmission power > 1 W are used in the
immediate vicinity of components, they may cause the equipment to malfunction.
Malfunctions may impair the functional safety of machines and can therefore put people in
danger or lead to property damage.
•If you come closer than around 2 m to such components, switch off any radios or mobile
phones.
•Use the "SIEMENS Industry Online Support App" only on equipment that has already
been switched off.

Fundamental safety instructions
1.1 General safety instructions
Distributed converter for SIMOGEAR geared motors
16 Operating Instructions, 09/2017, FW V4.7.9, A5E31298649B AH
WARNING
Motor fire in the event of insulation overload
There is higher stress on the motor insulation through a ground fault in an IT system. If the
insulation fails, it is possible that death or severe injury can occur as a result of smoke and
fire.
•Use a monitoring device that signals an insulation fault.
•Correct the fault as quickly as possible so the motor insulation is not overloaded.
WARNING
Fire due to inadequate ventilation clearances
Inadequate ventilation clearances can cause overheating of components with subsequent
fire and smoke. This can cause severe injury or even death. This can also result in
increased downtime and reduced service lives for devices/systems.
•Ensure compliance with the specified minimum clearance as ventilation clearance for
the respective component.
WARNING
Unrecognized dangers due to missing or illegible warning labels
Dangers might not be recognized if warning labels are missing or illegible. Unrecognized
dangers may cause accidents resulting in serious injury or death.
•Check that the warning labels are complete based on the documentation.
•Attach any missing warning labels to the components, where necessary in the national
language.
•Replace illegible warning labels.
NOTICE
Device damage caused by incorrect voltage/insulation tests
Incorrect voltage/insulation tests can damage the device.
•Before carrying out a voltage/insulation check of the system/machine, disconnect the
devices as all converters and motors have been subject to a high voltage test by the
manufacturer, and therefore it is not necessary to perform an additional test within the
system/machine.

Fundamental safety instructions
1.1 General safety instructions
Distributed converter for SIMOGEAR geared motors
Operating Instructions, 09/2017, FW V4.7.9, A5E31298649B AH 17
WARNING
Unexpected movement of machines caused by inactive safety functions
Inactive or non-adapted safety functions can trigger unexpected machine movements that
may result in serious injury or death.
•Observe the information in the appropriate product documentation before
commissioning.
•Carry out a safety inspection for functions relevant to safety on the entire system,
including all safety-related components.
•Ensure that the safety functions used in your drives and automation tasks are adjusted
and activated through appropriate parameterizing.
•Perform a function test.
•Only put your plant into live operation once you have guaranteed that the functions
relevant to safety are running correctly.
Note
Important safety notices for Safety Integrated functions
If you want to use Safety Integrated functions, you must observe the safety notices in the
Safety Integrated manuals.
WARNING
Malfunctions of the machine as a result of incorrect or changed parameter settings
As a result of incorrect or changed parameterization, machines can malfunction, which in
turn can lead to injuries or death.
•Protect the parameterization (parameter assignments) against unauthorized access.
•Handle possible malfunctions by taking suitable measures, e.g. emergency stop or
emergency off.

Fundamental safety instructions
1.2 Equipment damage due to electric fields or electrostatic discharge
Distributed converter for SIMOGEAR geared motors
18 Operating Instructions, 09/2017, FW V4.7.9, A5E31298649B AH
1.2
Equipment damage due to electric fields or electrostatic discharge
Electrostatic sensitive devices (ESD) are individual components, integrated circuits, modules
or devices that may be damaged by either electric fields or electrostatic discharge.
NOTICE
Equipment damage due to electric fields or electrostatic discharge
Electric fields or electrostatic discharge can cause malfunctions through damaged
individual components, integrated circuits, modules or devices.
•Only pack, store, transport and send electronic components, modules or devices in their
original packaging or in other suitable materials, e.g conductive foam rubber of
aluminum foil.
•Only touch components, modules and devices when you are grounded by one of the
following methods:
–Wearing an ESD wrist strap
–Wearing ESD shoes or ESD grounding straps in ESD areas with conductive flooring
•Only place electronic components, modules or devices on conductive surfaces (table
with ESD surface, conductive ESD foam, ESD packaging, ESD transport container).
1.3
Warranty and liability for application examples
The application examples are not binding and do not claim to be complete regarding
configuration, equipment or any eventuality which may arise. The application examples do
not represent specific customer solutions, but are only intended to provide support for typical
tasks. You are responsible for the proper operation of the described products. These
application examples do not relieve you of your responsibility for safe handling when using,
installing, operating and maintaining the equipment.

Fundamental safety instructions
1.4 Industrial security
Distributed converter for SIMOGEAR geared motors
Operating Instructions, 09/2017, FW V4.7.9, A5E31298649B AH 19
1.4
Industrial security
Note
Industrial security
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against
cyber threats, it is
necessary to implement
– and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens products and solutions only represent one component of such a
concept.
The customer is responsible for preventing un
authorized access to its plants, systems,
machines and networks. Systems, machines and components should only be connected to
the enterprise network or the internet if and to the extent necessary and with appropriate
security measures (e.g. use of firewall
s and network segmentation) in place.
Additionally, Siemens’ guidance on appropriate security measures should be taken into
account. For more information about industrial security, please visit:
Industrial security (
http://www.siemens.com/industrialsecurity).
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends to apply product updates as soon as available and to
always use the latest product versions. Use of product versions that are no longer supported,
and failure to apply latest updates may increase customer’s exposure to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed
at:
Industrial security (
http://www.siemens.com/industrialsecurity).
WARNING
Unsafe operating states resulting from software manipulation
Software manipulations (e.g. viruses, trojans, malware or worms) can cause unsafe
operating states in your system that may lead to death, serious injury, and property
damage.
•Keep the software up to date.
•Incorporate the automation and drive components into a holistic, state-of-the-art
industrial security concept for the installation or machine.
•Make sure that you include all installed products into the holistic industrial security
concept.
•Protect files stored on exchangeable storage media from malicious software by with
suitable protection measures, e.g. virus scanners.

Fundamental safety instructions
1.5 Residual risks of power drive systems
Distributed converter for SIMOGEAR geared motors
20 Operating Instructions, 09/2017, FW V4.7.9, A5E31298649B AH
1.5
Residual risks of power drive systems
When assessing the machine- or system-related risk in accordance with the respective local
regulations (e.g., EC Machinery Directive), the machine manufacturer or system installer
must take into account the following residual risks emanating from the control and drive
components of a drive system:
1. Unintentional movements of driven machine or system components during
commissioning, operation, maintenance, and repairs caused by, for example,
–Hardware and/or software errors in the sensors, control system, actuators, and cables
and connections
–Response times of the control system and of the drive
–Operation and/or environmental conditions outside the specification
–Condensation/conductive contamination
–Parameterization, programming, cabling, and installation errors
–Use of wireless devices/mobile phones in the immediate vicinity of electronic
components
–External influences/damage
–X-ray, ionizing radiation and cosmic radiation
2. Unusually high temperatures, including open flames, as well as emissions of light, noise,
particles, gases, etc., can occur inside and outside the components under fault conditions
caused by, for example:
–Component failure
–Software errors
–Operation and/or environmental conditions outside the specification
–External influences/damage
3. Hazardous shock voltages caused by, for example:
–Component failure
–Influence during electrostatic charging
–Induction of voltages in moving motors
–Operation and/or environmental conditions outside the specification
–Condensation/conductive contamination
–External influences/damage
4. Electrical, magnetic and electromagnetic fields generated in operation that can pose a
risk to people with a pacemaker, implants or metal replacement joints, etc., if they are too
close
5. Release of environmental pollutants or emissions as a result of improper operation of the
system and/or failure to dispose of components safely and correctly
6. Influence of network-connected communication systems, e.g. ripple-control transmitters
or data communication via the network
