Siemens MOBILETT Plus User manual

MOBILETT Plus/ -E/ -M/ -HP
English
Print No.: SPR8-220.092.02.01.02 Doc. Gen. Date: 08.01
Replaces: n.a. 66 08 116
© Siemens AG 2001
The reproduction, transmission or
use of this document or its contents
is not permitted without express
written authority. Offenders will be
liable for damages. All rights,
including rights created by patent
grant or registration of a utility
model _or_design,_are_reserved.
Service
Collimator mounting modification
Modification Instructions

MOBILETT Plus/ -E/ -M/ -HP SPR8-220.092.02 Page 2 of 4 Siemens-Elema AB
Service Rev. 01 08.01 SPS-UD Solna, Sweden
0 - 2 Revision
Document revision level
The document corresponds to the version/revision level effective at the time of system delivery. Revi-
sions to hardcopy documentation are not automatically distributed.
Please contact your local Siemens office to order current revision levels.
Disclaimer
The installation and service of equipment described herein is to be performed by qualified personnel
who are employed by Siemens or one of its affiliates or who are otherwise authorized by Siemens or
one of its affiliates to provide such services.
Assemblers and other persons who are not employed by or otherwise directly affiliated with or autho-
rized by Siemens or one of its affiliates are directed to contact one of the local offices of Siemens or
one of its affiliates before attempting installation or service procedures.
Chapter Page Revision
All All 01

Contents 0 - 3
Siemens-Elema AB SPR8-220.092.02 Page 3 of 4 Mobilett Plus/ -E/ -M/ -HP
Solna, Sweden Rev. 01 08.01 SPS-UD Service
1 _______Prerequisites __________________________________________________ 1 - 1
Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
Components / documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
Tools / documents required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
Time required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
2 _______Remounting collimator __________________________________________ 2 - 1
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1
Remounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1
Page

0 - 4 Contents
Mobilett Plus/ -E/ -M/ -HP SPR8-220.092.02 Page 4 of 4 Siemens-Elema AB
Service Rev. 01 08.01 SPS-UD Solna, Sweden
This page intentionally left blank.

1 - 1
Siemens-Elema AB SPR8-220.092.02 Page 1 of 2 MOBILETT Plus/ -E/ -M/ -HP
Solna, Sweden Rev. 01 08.01 SPS-UD Service
Prerequisites 1
Purpose 1
This document contains additional information on how to remount the collimator on a
MOBILETT Plus/ Plus E/ Plus M/ Plus HP.
Components / documents 1
The remounting changes comprise the following parts:
Tools / documents required 1
•Standard installation tools
•"Service Instructions", SPR8-220.061.01... or SPR8-215.898/061.01...
Time required 1
•Approximately 5 minutes for one customer support engineer
Safety information 1
Part no. Quantity Part no. Name
1 4 60 89 593 Cable ties
2 1 66 08 116 This instruction
Be sure to unplug the unit from the mains or turn off
the main circuit breaker before performing any service.
Remove or install boards only when the generator is
switched OFF. Adhere to the ESD guidelines.
Checks and adjustments performed with radiation ON
are identified by the radiation warning symbol .
During these types of adjustments, radiation protective
clothing must be worn.
Observe all MOBILETT safety guidelines.
CAUTION

MOBILETT Plus/ -E/ -M/ -HP SPR8-220.092.02 Page 2 of 2 Siemens-Elema AB
Service Rev. 01 08.01 SPS-UD Solna, Sweden
1 - 2 Prerequisites
This page intentionally left blank.

2 - 1
Siemens-Elema AB SPR8-220.092.02 Page 1 of 2 MOBILETT Plus/ -E/ -M/ -HP
Solna, Sweden Rev. 01 08.01 SPS-UD Service
Remounting collimator 2
General 2
Consult the document “Service Instructions”, Chapter 9 for details about settings and
adjustments.
Remounting 2
•Install the collimator. Center the rotary-flange so that the screws marked "E" are
centered in the grooves before tightening.
•Connect the wires to connection terminal board "D".
Fig. 1
D
E
E
E
cable tie
cable tie left side
E
right side

MOBILETT Plus/ -E/ -M/ -HP SPR8-220.092.02 Page 2 of 2 Siemens-Elema AB
Service Rev. 01 08.01 SPS-UD Solna, Sweden
2 - 2 Remounting collimator
•Attach the cable ties (Fig. 1). The cable ties have to be mounted exactly as shown in Fig.
2 and Fig. 3. The cable ties should not be tightened hard. Fig. 2 and Fig. 3 shows how the
cable tie on the right side is mounted. Repeat for the left side, but with the cable tie
mirror-inverted.
•Rotate the collimator through the whole interval, and make sure the cable ties does not
come in contact with the collimator / moving parts.
•Reattach collimator covers.
Make sure not to forget to attach the cable ties!
When replacing the collimator, the new collimator should be
positioned and adjusted so that the light and radiation fields
correspond.
The adjustment should be performed by moving the whole
collimator, not just changing the position of the collimator bulb.
More information can be found in the document Service
Instructions, Chapter 9.
MOB00578
Fig. 2
MOB00579
Fig. 3
NOTE
NOTICE
