SIMATIC HMI
HMI device
IRD400
Operating Instructions
05/2018
A5E36790512
-AC
Preface
Overview
1
Safety instructions
2
Installing and connecting the
display unit
3
Operating the display unit
4
Configuring the display unit
5
Maintenance and repairs
6
Technical specifications
7
Appendix
A

Siemens AG
Division Digital Factory
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E36790512-AC
Ⓟ
05/2018 Subject to change
Copyright © Siemens AG 2018.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

IRD400
Operating Instructions, 05/2018, A5E36790512-AC 3
Preface
Purpose of the operating instructions
These operating instructions provides information relating to the place of use, transport,
storage, mounting, use and maintenance of the device.
These operating instructions are intended for:
●Commissioning engineers
●Operators
●Maintenance personnel
Scope
This document applies to the display unit "SIMATIC HMI IRD400" with the article number
6ES7292-0AA50-1AA0.
Note
Note:
•
You are also going to need this document whenever the system is recommissioned. Keep
this and supplementary documentation in a safe place for the entire life cycle of the
device.
•
Submit all of these documents to a future owner of the device.
Knowledge required
General knowledge in the fields of electrical engineering, automation technology and
process communication is prerequisite for comprehension of this documentation.
Style conventions
Notation
Scope
"Add screen" •Terminology for the user interface, e.g. dialog name, tab, but-
ton, menu command
•Necessary entries, e.g. limit value, tag value
•Path information
"File > Edit" Operational sequences, e.g, menu command, shortcut menu
command

Preface
IRD400
4Operating Instructions, 05/2018, A5E36790512-AC
Please observe notes labeled as follows:
Note
A note contains important information about the product described in the document and its
handling, or a specific section of the document to which you should pay particular attention.
Naming conventions
Term
Applies to
Display unit
SIMATIC HMI IRD400
Device
Display unit
Control cabinet •Installation cabinet
•Enclosure
•Terminal box
•Console
•Switchboard
Figures
This document contains illustrations of the described devices. The illustrations may deviate
from the particularities of the delivered device.

IRD400
Operating Instructions, 05/2018, A5E36790512-AC 5
Table of contents
Preface ........................................................................................................................................3
1 Overview......................................................................................................................................7
1.1 Product overview................................................................................................................. 7
1.2 Scope of delivery................................................................................................................. 7
1.3 Design of the display unit..................................................................................................... 8
1.4 Accessories......................................................................................................................... 9
2 Safety instructions ....................................................................................................................... 10
2.1 Industrial Security.............................................................................................................. 12
3 Installing and connecting the display unit........................................................................................ 13
3.1 Preparing for mounting ...................................................................................................... 13
3.1.1 Checking the package contents......................................................................................... 13
3.1.2 Permitted mounting positions............................................................................................. 14
3.1.3 Installation location and clearance ..................................................................................... 16
3.2 Installing the display unit.................................................................................................... 18
3.3 Connecting the display unit................................................................................................ 19
3.3.1 Connection information...................................................................................................... 19
3.3.2 Connecting functional ground ............................................................................................ 20
3.3.3 Connecting the Power Supply............................................................................................ 22
3.3.4 Connecting the PLC .......................................................................................................... 24
3.3.5 Connecting digital inputs/outputs ....................................................................................... 25
3.3.6 Securing the cables........................................................................................................... 25
4 Operating the display unit............................................................................................................. 26
5 Configuring the display unit........................................................................................................... 29
5.1 PROFINET modules.......................................................................................................... 29
5.2 Configuring in the TIA Portal.............................................................................................. 30
5.3 Slot 1 - IR-RC module (IR remote control).......................................................................... 33
5.4 Slot 2 - DISPLAY module (7-segment display and LEDs)................................................... 34
5.5 Slot 3 - Digital port module (8 x DI/DO).............................................................................. 36
5.6 Slot 4 - IR-P2P module ("IR-P2P" operating mode)............................................................ 37
5.7 Slot 5 - Control module (operating mode) .......................................................................... 38
6 Maintenance and repairs .............................................................................................................. 40
6.1 Recycling and disposal ...................................................................................................... 40

Table of contents
IRD400
6Operating Instructions, 05/2018, A5E36790512-AC
7 Technical specifications............................................................................................................... 41
7.1 Certificates and approvals ..................................................................................................41
7.2 Notes about usage .............................................................................................................42
7.3 Electromagnetic compatibility .............................................................................................42
7.4 Ambient conditions .............................................................................................................44
7.4.1 Transportation and storage requirements ...........................................................................44
7.4.2 Operational requirements ...................................................................................................45
7.4.3 Tests for ambient conditions...............................................................................................46
7.5 Dimensional diagram..........................................................................................................47
7.6 Technical specifications......................................................................................................47
7.7 Interface description...........................................................................................................49
7.7.1 Power supply .....................................................................................................................49
7.7.2 RS 232 interface (X30).......................................................................................................49
7.7.3 PROFINET.........................................................................................................................50
7.7.4 Digital inputs/outputs ..........................................................................................................50
A Appendix ................................................................................................................................... 51
A.1 Technical support...............................................................................................................51
A.2 Abbreviations .....................................................................................................................52
Index ......................................................................................................................................... 53

IRD400
Operating Instructions, 05/2018, A5E36790512-AC 7
Overview
1
1.1
Product overview
The display unit is used to display data which is sent by a controller. Digits or symbols can
be shown in the display. The status of the controller, for example, can be signaled via the
LEDs. In addition, two controllers which are each connected to a IRD400 display unit can
communicate via the display units.
The display ensures legibility up to a distance of 10 m. You can use the integrated dimming
function to adjust the display to the ambient light conditions.
The display unit has an infrared transmitter/receiver module which is tuned to the IR remote
control with the article number 6ES7292-0CA50-0AA0 and can communicate with a display
unit of the same design. The display unit can be used with and without remote control. You
can use the IR remote control to adjust the brightness of the display on the display unit and
transmit signals to the controller via the display unit.
The display unit is configured with STEP 7 (TIA Portal).
1.2
Scope of delivery
The scope of delivery of the display unit includes:
●1 × display unit
●1 x accessory pack with the following contents:
–4 mounting clips
–4 threaded pins for the mounting clips
–1 mains terminal for the power supply
–1 plug connector, 12-pin

Overview
1.3 Design of the display unit
IRD400
8Operating Instructions, 05/2018, A5E36790512-AC
1.3
Design of the display unit
①
PROFINET ports X1 P1 and X1 P2
⑥
Recesses for a mounting clip
②
Power supply connector X80
⑦
"Green" and "red" LEDs, for example for
displaying the operating state
③
Mounting seal
⑧
IR transmitter/receiver module with "blue"
LED
④
I/O interface X10, digital inputs/outputs
⑨
Rating plate
⑤
Display with three 7-segment displays
⑩
Connection for functional earthing
The RS 232 interface X30 is deactivated.

Overview
1.4 Accessories
IRD400
Operating Instructions, 05/2018, A5E36790512-AC 9
Display and LEDs
The LED contains three 7-segment displays, each with a decimal point.
The response of the three 7-segment displays and LEDs is defined via the configuration.
PROFINET ports and digital inputs/outputs
The display unit communicates with the controller via PROFINET. The response of the digital
inputs/outputs (pins 1...8) of the I/O interface X10 is defined via the configuration of the slots
in HW Config (TIA Portal) and is freely-programmable.
1.4
Accessories
Accessories for the display unit:
●IR remote control
The IR remote control represents the input device for the display unit. The article number
is 6ES7292-0CA50-0AA0.
Accessories can be found on the Internet (https://mall.industry.siemens.com).

IRD400
10 Operating Instructions, 05/2018, A5E36790512-AC
Safety instructions
2
WARNING
Injury or material damage
You risk the development of danger sources and deactivation of safety functions if you
neglect the safety and handling instructions provided in this document. This can result in
personal injuries or material damage.
Strictly adhere to the safety and handling instructions.
Always adhere to the safety instructions and accident prevention regulations for the
respective application, independent of the safety instructions provided in this document.
Safety during commissioning and operation
WARNING
Installation/use as intended
It is strictly forbidden to commission the device before compliance with Machinery Directive
2006/42/E has been verified for the machine to be operated with this device.
Verify before commissioning that the provisions of Directive 2006/42/EC are fulfilled.
Safety when working in and on electrical systems
Only authorized persons are allowed to work in or on electrical equipment. The following
safety regulations for prevention of electrical shock are valid in Germany:
1. Isolation of the system from power
2. Securing the system against restart
3. Verification of isolation from power at all poles
4. Grounding and shorting the system
5. Covering or fencing off adjacent live parts

Safety instructions
IRD400
Operating Instructions, 05/2018, A5E36790512-AC 11
These safety regulations are based on DIN VDE 0105.
Note
The safety regulations must be
applied in the aforementioned order before any work is
carried out on electrical systems. The safety regulations must be applied in reverse order on
completion of all tasks on the electrical system.
Identify the electrical system in accordance with valid safety regulations when working on
this system.
Observe the valid safety regulations of the respective country.
Infrared interference signal
WARNING
Malfunctions with IR interference signal possible
The display unit receives all infrared signals of their spectrum within their sensing range.
Interference signals can cause unwanted commands to be sent to the controller.
Unintentional reaction of the plant as well as personal injury or property damage can result.
Note:
•Do not operate any infrared signal sources except the permitted remote control in the
entire receiving range of the display unit Only the remote control "IR-RC" with article
number 6ES7292-0CA50-0AA0 is permitted.
•Take appropriate measures to prevent interference by other sources within the spectrum
and reception range of the display unit. Read the information in the technical
specifications.
Strong high-frequency radiation
NOTICE
Observe immunity to RF radiation
The device has an increased immunity to RF radiation according to the specifications on
electromagnetic compatibility in the technical specifications.
Radiation exposure in excess of the specified immunity limits can impair device functions,
result in malfunctions and therefore injuries or damages.
Read the information on immunity to RF radiation in the technical specifications.

Safety instructions
2.1 Industrial Security
IRD400
12 Operating Instructions, 05/2018, A5E36790512-AC
Warranty
Prerequisites for trouble-free and safe operation of the device:
●Proper transportation and storage
●Proper mounting and wiring
●Proper operation and repairs
Non-compliance with these regulations shall render the device warranty void.
ESD
An ESD (Electrostatically Sensitive Device) is equipped with electronic components. Due to
their design, electronic components are highly sensitive to overvoltage and electrostatic
discharge. Observer the regulations governing the handling of ESD components.
2.1
Industrial Security
Industrial Security
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions only form one element of such a concept.
Siemens’ products and solutions only form one element of such a concept.
Customer is responsible to prevent unauthorized access to its plants, systems, machines
and networks. Systems, machines and components should only be connected to the
enterprise network or the internet if and to the extent necessary and with appropriate security
measures (e.g. use of firewalls and network segmentation) in place.
Additionally, Siemens’ guidance on appropriate security measures should be taken into
account. For more information about industrial security, please visit
(http://www.siemens.com/industrialsecurity).
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends to apply product updates as soon as available and to
always use the latest product versions. Use of product versions that are no longer supported,
and failure to apply latest updates may increase customer’s exposure to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under (http://www.siemens.com/industrialsecurity).

IRD400
Operating Instructions, 05/2018, A5E36790512-AC 13
Installing and connecting the display unit
3
3.1
Preparing for mounting
3.1.1
Checking the package contents
Check the package content for visible signs of transport damage and for completeness.
Note
Damaged parts
Do not install parts damaged during shipment. In the case of damaged parts, contact your
Siemens representative.
The package content is described in section Scope of delivery (Page 7).
Keep the provided documentation in a safe place. The documentation is part of the HMI
device and is required for subsequent commissioning.

Installing and connecting the display unit
3.1 Preparing for mounting
IRD400
14 Operating Instructions, 05/2018, A5E36790512-AC
3.1.2
Permitted mounting positions
Mounting position
The display unit is approved for operation in horizontal and inclined mounting position in
stationary and mobile control cubicles.
The following lateral installation angles are permitted:
Mounting position
Deviation from the perpendicular axis
Temperature
①
Horizontal
-90°
0 ... 50 °C
②
Inclined
≥–35°
0 ... 60 °C
③
Vertical
0°
0 ... 60 °C
④
Inclined
≤35°
0 ... 60 °C
The display unit is quipped with venting slots for heat convection into the control cabinet
where thermal energy is dissipated on the panels of the control cabinet.
Note
You risk damage to the display unit if operating it outside the approved ambient temperature
limits. The approvals and warranty for the display unit are rendered void in this case.

Installing and connecting the display unit
3.1 Preparing for mounting
IRD400
Operating Instructions, 05/2018, A5E36790512-AC 15
Mobile operation
If you operate the device in a mobile system, for example in an electrical monorail system,
then in addition to the lateral installation angle, the permitted tilt of the front of the device
must be taken into consideration.
The following angles of inclination are permitted for a short time for the display unit during
movement:
Position
Deviation from the perpendicular axis
①
Tilted
≥–35°
②
Vertical
0°
③
Tilted
≤35°
Inclinations may occur, for example, if the display unit is mounted to a conveying device that
services several levels of the plant.
Note
Please note that the vertical position
②for mobile use may only be exceeded for a short
period of time.

Installing and connecting the display unit
3.1 Preparing for mounting
IRD400
16 Operating Instructions, 05/2018, A5E36790512-AC
3.1.3
Installation location and clearance
Selecting installation location
The display unit is designed for installation in a control cabinets. The display unit is installed
in landscape format.
NOTICE
Installation location
Non-compliance with permissible ambient conditions at the installation location may lead to
malfunctions.
Observe the permissible ambient conditions when selecting the installation location.
When selecting the mounting location for the display unit, ensure that sufficient heat
convection is possible. Avoid installation of heat generating equipment directly underneath
the display unit.
Clearance
The following clearance is required for ventilation of the display unit:
10 mm clearance at the rear side of the device.
Note
Additional clearance for connectors and cables
Take into consideration additional clearance due to the type of connector used and the
permissible bending radii of the connecting cables.

Installing and connecting the display unit
3.1 Preparing for mounting
IRD400
Operating Instructions, 05/2018, A5E36790512-AC 17
Dimensions of the mounting cut-out
The following figure shows the dimensions of the mounting cut-out and the clearances to be
observed when mounting several devices in a horizontal or vertical arrangement.
Configuration of the mounting cut-out
The following conditions must be met to ensure the degree of protection:
●The material at the mounting cut-out must be resistant to distortion.
●Material thickness at the mounting cut-out for IP65 degree of protection, or for
enclosure type 4X/type 12 (indoor use only): 2 mm bis 6 mm
●Permitted deviation from plane at the mounting cutout: ≤0.5 mm
This condition must be fulfilled for the mounted HMI device.
●Permitted surface roughness in the area of the mounting seal: ≤120 µm (Rz120)
NOTICE
Operation in the scope of UL508
For use on a flat surface of a Type 1 (indoor use only) Enclosure.

Installing and connecting the display unit
3.2 Installing the display unit
IRD400
18 Operating Instructions, 05/2018, A5E36790512-AC
3.2
Installing the display unit
The display unit is installed in a control cabinet with mounting clips. These prevent the main
dimensions of the display unit from being exceeded. Always adhere to the specifications in
these operating instructions when installing the display unit.
Requirement
To install the display unit, you need the following from the accessories kit:
●4 mounting clips
●4 threaded pins for the mounting clips
Procedure
Note
Secure mounting clips
You will risk damage to the enclosure of device if you continue to turn the mounting screw
while the gap between the device and the panel of the control cabinet is already closed.
Once the gap is closed, do not turn the mounting screw any further. You have
the option to
tighten the mounting clamp with a torque of 0.2
Nm.
Risk of the loss of the guaranteed degree of protection
The degree of protection is not insured if the mounting seal is not installed, or if it is
damaged or improperly inserted.
Check the
presence, condition and seating of the mounting seal.
1.
Turn the threaded pin in the mounting
clip.

Installing and connecting the display unit
3.3 Connecting the display unit
IRD400
Operating Instructions, 05/2018, A5E36790512-AC 19
2.
Hook the mounting clip in the cutout
as shown.
The red markers indicate additional
cutouts into which a mounting clamp is
to be installed.
3.
Screw in the threaded pin until the gap
between the enclosure front and the
display unit is closed.
Degree of protection IP65 achieved
when the gap is closed.
3.3
Connecting the display unit
3.3.1
Connection information
Wiring sequence
Note
You will risk damage to the device if you ignore the specif
ied wiring sequence.
Wire the device in the following sequence:
1. Functional ground
2. Power supply
3. Digital inputs/outputs
4. Controller

Installing and connecting the display unit
3.3 Connecting the display unit
IRD400
20 Operating Instructions, 05/2018, A5E36790512-AC
You can disconnect the device in reverse order.
Note
Device failure
Moisture and condensation lead to malfunction. Moisture in the form of condensation on or in
the device is formed:
•
When transporting a device at low temperatures
•
Under extreme temperature variations
Bring the device to room temperature before operating.
Condensation
Do not expose the device to direct heat radiation from a heater.
If condensation has developed, wait approximately 4
hours until the device has dried
completely before switching it on.
Wiring cables
Make sure that you do not bend the pins when connecting the cables.
Note
You will risk malfunctions if using cables that are not approved.
Always use shielded standard cables for data transmission. Orders for accessories can be
placed at the following Internet URL:
Industry Mall (
https://mall.industry.siemens.com)
3.3.2
Connecting functional ground
Potential differences
Potential differences may develop between distributed plant parts. Potential differences may
cause high equipotential currents on the data cables and destroy their interfaces. Equalizing
currents can develop if the cable shielding is terminated at both ends and grounded to
different parts of the system.
Differences in potential can develop when a system is connected to different mains.
