Siemens SIREMOBIL User manual

SIREMOBIL
English
Print No.: SPR2-230.812.02.02.02 Doc. Gen. Date: 02.06
Replaces: SPR2-230.812.02.01.02
© Siemens AG 2004
The reproduction, transmission or
use of this document or its contents
is not permitted without express
written authority. Offenders will be
liable for damages. All rights,
including rights created by patent
grant or registration of a utility
model _or_design,_are_reserved.
SP
System Manual
Installation of TFT displays
Installation Instructions

SIREMOBIL SPR2-230.812.02 Page 2 of 4 Siemens AG
System Manual Rev. 02 02.06 CS PS SP Medical Solutions
0 - 2 Revision
Document revision level
The document corresponds to the version/revision level effective at the time of system delivery. Revi-
sions to hardcopy documentation are not automatically distributed.
Please contact your local Siemens office to order current revision levels.
Disclaimer
The installation and service of equipment described herein is to be performed by qualified personnel
who are employed by Siemens or one of its affiliates or who are otherwise authorized by Siemens or
one of its affiliates to provide such services.
Assemblers and other persons who are not employed by or otherwise directly affiliated with or autho-
rized by Siemens or one of its affiliates are directed to contact one of the local offices of Siemens or
one of its affiliates before attempting installation or service procedures.
Chapter Page Revision
all all 02

Contents 0 - 3
Siemens AG SPR2-230.812.02 Page 3 of 4 SIREMOBIL
Medical Solutions Rev. 02 02.06 CS PS SP System Manual
1 _______General _______________________________________________________ 1 - 1
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
Notes and symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
Validity of these instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 2
Parts required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 2
Auxiliary devices required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 2
2 _______Installation of TFT displays ______________________________________ 2 - 1
Dismantling the existing monitors . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1
Installation of the video and power line cables in the monitor trolley . . . . . . . . . . 2 - 3
Installation of the support arm on the monitor trolley . . . . . . . . . . . . . . . . . . 2 - 3
BARCO display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 3
Adjusting the support arm to the size of the TFT display . . . . . . . . . . . . . . 2 - 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 5
Protective ground wiring of the support arm . . . . . . . . . . . . . . . . . . . . . . 2 - 6
Wiring the radiation indicators of the support arm. . . . . . . . . . . . . . . . . . . . 2 - 6
Wiring of the displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7
BARCO displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7
Running the cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7
3 _______Settings ______________________________________________________ 3 - 1
TFT display BARCO MVG 1318, part number 80 79 530 . . . . . . . . . . . . . . . . 3 - 1
Concluding work. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 1
4 _______Changes to previous version _____________________________________ 4 - 1
Page

0 - 4 Contents
SIREMOBIL SPR2-230.812.02 Page 4 of 4 Siemens AG
System Manual Rev. 02 02.06 CS PS SP Medical Solutions
Page

1 - 1
Siemens AG SPR2-230.812.02 Page 1 of 2 SIREMOBIL
Medical Solutions Rev. 02 02.06 CS PS SP System Manual
General 1
Safety instructions 1
Notes and symbols 1
Emphasized texts in technical documentation have the following meaning:
When performing the work steps and tests described herein,
observe the product-specific safety information contained in the
documents, as well as the general safety information
TD00-000.860.01....
DANGER indicates an immediate danger that if disregarded will
cause death or serious physical injury.
WARNING indicates a possible danger that if disregarded can
cause death or serious physical injury.
CAUTION used with the safety alert icon indicates a possible dan-
ger that if disregarded will or can lead to minor or moderate phys-
ical injury and/or damage to property.
NOTICE used without the safety alert icon indicates a possible
danger that if disregarded may or will lead to an undesirable
result or state other than death, physical injury or property dam-
age.
CAUTION
DANGER
WARNING
CAUTION
NOTICE

SIREMOBIL SPR2-230.812.02 Page 2 of 2 Siemens AG
System Manual Rev. 02 02.06 CS PS SP Medical Solutions
1 - 2 General
Validity of these instructions 1
These instructions are valid for upgrading a TFT support arm and 2 TFT displays on
existing SIREMOBIL Compact, SIREMOBIL Compact L,
SIREMOBIL Iso-C, ARCOSKOP and POWERMOBIL systems with available tube moni-
tors, installed on the monitor trolley 37 77 880.
Parts required 1
Auxiliary devices required 1
To o l c a s e
Required Documents
•Replacement instructions of the delivered TFT displays.
See CS Intranet, CB-Doc of the corresponding system, "Service"
•System manual for the system
•Logbook for the system
•IQ quick test of the system
Upgrade Kit for TFT Displays 07141125
The corresponding replacement instructions are necessary for
checking and if necessary adjusting the delivered TFT displays.
NOTE

2 - 1
Siemens AG SPR2-230.812.02 Page 1 of 8 SIREMOBIL
Medical Solutions Rev. 02 02.06 CS PS SP System Manual
Installation of TFT displays 2
Dismantling the existing monitors 2
•Remove both monitors as follows.
•Remove transport monitor covers (Fig. 1).
•Remove the shielding plates (Fig. 2).
•Remove the connection housing (only for SIMOMED N monitor 11 02 628, Fig. 3).
•Unplug all cables from the monitor to be replaced.
•In each case loosen the 2 screws at the monitor mounting (Fig. 4).
•Lift down both monitors.
•Reattach all previously removed parts to the monitor.
Fig. 1 Monitor cover Fig. 2 Shielding plate
Fig. 3 Connection housing Fig. 4 Monitor attachment
Mark for the keyboard tray
Mark for the keyboard tray

SIREMOBIL SPR2-230.812.02 Page 2 of 8 Siemens AG
System Manual Rev. 02 02.06 CS PS SP Medical Solutions
2 - 2 Installation of TFT displays
•Unscrew the two bases of the monitors from the monitor trolley and remove them com-
pletely (Fig. 5).
•Remove the two video cables.
•Completely remove and disconnect the two power cables.
•4 prepunched holes are visible around the central cable bush (Ê/ Fig. 5).
4 metal bolts are inserted in these holes and they are thus closed.
Drive out the 4 metal bolts downwards with a drift (or another round object). Remove the
4 metal bolts from the monitor trolley.
•Lift off the central blind cover and close one of the cable bushes on the side with it
(Fig. 6).
•Close off the 2nd cable bush on the side and the 8 fastening holes around the cable
bushes on the sides with the enclosed blind covers.
Fig. 5 Monitor attachments Fig. 6 Monitor trolley cable bushes
Mark for the keyboard tray

Installation of TFT displays 2 - 3
Siemens AG SPR2-230.812.02 Page 3 of 8 SIREMOBIL
Medical Solutions Rev. 02 02.06 CS PS SP System Manual
Installation of the video and power line cables in the monitor trolley 2
•TFT display BARCO MVG 1318: Run the video cables (BNC plug - BNC plug) contained
in the scope of supply of the set attachment through the middle cable bush of the moni-
tor trolley, and laterally through the lateral rail to the MEMOSKOP. Plug in and lock the
cables at the OUT1 socket (left display) and OUT2 socket (right display).
Installation of the support arm on the monitor trolley 2
•Open the rear cover of the support arm base on the TFT display.
BARCO display 2
•Run the free cable ends of the new power cables (included in the attachment kit of the
TFT monitor) downwards through the holder of the support arm (2/Fig. 8), through the
center cable bush of the monitor trolley and through the lateral rail to the ON/OFF
assembly (Fig. 7) and connect them to the terminal blocks:
- Connect the brown cable ends to terminal block X2.1.
- Connect the blue cable ends to terminal block X2.2.
- Connect the protective ground (Ge/Gn) to the protective conductor bars (1/Fig. 7).
•Thread the video cables upwards, through the rectangular cable bush (1/Fig. 8) of the
support arm base and further through the holders of the support arm (2/Fig. 8).
•Place the support arm base above the center cable bush (Fig. 8).
•Starting with the logbook compartment, tighten the screws of the support arm base on
the monitor trolley. Use 4 Allen screws M6 x 20, 4 lock washers and 4 plate washers for
this (Fig. 8).
Fig. 7 ON/OFF assembly Fig. 8 Installation of the support arm
The new power line cables have a length of approx. 2.6 m and are
equipped with a straight female connector on one cable end.
NOTE

SIREMOBIL SPR2-230.812.02 Page 4 of 8 Siemens AG
System Manual Rev. 02 02.06 CS PS SP Medical Solutions
2 - 4 Installation of TFT displays
Installation of the TFT display on the support arm
•Dismount temporarily the collision protection (see Fig. 9). To do so, loosen the screws (1/
Fig. 9) on both top tubes and pull out the collision protection.
Adjusting the support arm to the size of the TFT display 2
•After loosening the 2 x 8 countersunk screws on the support arm (‰/Fig. 10), you can
adjust the distance between both tubes as well as the vertical position of the holding
plate (A/Fig. 10).
•To permit easier adjustment, it is recommended to calculate and pre-set the
distances (1/Fig. 10) before the TFT displays are attached.
Calculation of the distances (1/Fig. 10):
•Setting the distances results in a distance of approx. 1 cm between the top and bottom
edge of the TFT displays, on the one hand, and the tubes of the support arm, on the oth-
er hand.
Fig. 9 Collision protection Fig. 10 Adjustment of the support arm
You can adjust the width of the support arm and the distance
between the top and bottom tube to adapt the support arm to the
display in use. In addition, you can modify the vertical centering
of the holding plate (A/Fig. 10).
You can modify the width of the support arm using spacer rings
(2/Fig. 9).
The distance between the tubes and the vertical centering of the
holding plate can be modified after loosening the countersunk
screws on both vertical display supports (8 on each support).
Loosen the 16 countersunk screws only slightly; do not
remove them completely!
Distance (1/Fig. 10) = 17 cm __ Height TFT display (cm) (2/Fig. 10) + 4.8 cm
2
NOTE

Installation of TFT displays 2 - 5
Siemens AG SPR2-230.812.02 Page 5 of 8 SIREMOBIL
Medical Solutions Rev. 02 02.06 CS PS SP System Manual
Installation 2
•The collision protection is still removed on the left-hand and right-hand side (3/ Fig. 11).
•Place the first TFT display in front of the holder.
•Screw in both fixing screws (1/Fig. 11) only slightly, i.e. do not yet tighten them complete-
ly.
•Shift the TFT display out until it is possible to screw in the external screws. Do not yet
tighten the screws completely. It must be possible to shift the TFT display horizontally.
•Attach the second TFT display in the same way.
•Place both displays horizontally symmetrical with respect to the center axis (2/Fig. 11).
- Make sure that there is a vertical clearance of approx. 2 mm between the displays.
•If both displays are properly positioned, tighten the fixing screws firmly.
•Reattach the collision protection on the left-hand and right-hand side (Fig. 9).
•If it is required to adjust the width, insert a spacer ring on both sides, then push the colli-
sion protection in the tube and retighten its screws.
•If required, correct the distance between the displays and the top and bottom tube of the
support arm.
- It is recommended to leave a couple of millimeters for ventilation between the displays
and the top and bottom tube of the support arm to prevent collisions due to vibrations
during moving the monitor trolley.
- Both tubes of the support arm should run in parallel to each other.
Fig. 11 Installation of the TFT displays Fig. 12 Routing the cables
The displays have 4 thread holes on the rear panel for attaching
the holder.
For some displays, special adapter plates are needed for install-
ing the display on the holder (included in the scope of delivery).
These plates are to be inserted between holder and display hous-
ing.
NOTE

SIREMOBIL SPR2-230.812.02 Page 6 of 8 Siemens AG
System Manual Rev. 02 02.06 CS PS SP Medical Solutions
2 - 6 Installation of TFT displays
Protective ground wiring of the support arm 2
•On the support arm base of the TFT Display, a short protective ground wire is attached
with stripped end. Unscrew the protective ground wire and replace it by the protective
ground wire with a length of 2m (included in the attachment kit of the TFT monitor; includ-
ed in the scope of delivery). Run the free end of the protective ground wire through the
support arm base, through the logbook compartment and then through the lateral rail of
the monitor trolley to the ON/OFF assembly. Connect the wire end to a free protective
conductor bar (1/Fig. 14). Make sure that both protective ground wires make good con-
tact.
Wiring the radiation indicators of the support arm 2
•Withdraw the two radiation indicators (4/Fig. 11) after loosening the lower mounting
screws laterally from the tube.
•One end of the cable of the additional radiation indicator (included in the delivery of the
support arm of the TFT display) is equipped with 2 free cable ends. On the other end, a
connector D50.X7 is installed. Run both cable ends in the lower tube of the support arm
through the two bores (1/Fig. 13) to the radiation indicators.
•Connect both radiation indicators, then re-insert them in the bottom tube and retighten
them.
•Route the cable end with the attached connector D50.X7 through the support arm base
to the logbook compartment and then through the lateral rail of the monitor trolley to the
ON/OFF assembly located below.
•Unplug connector X4 of the ON/OFF assembly. See (2/Fig. 14).
•Wire the Y-cable (included in the attachment kit of the TFT monitors which is part of the
delivery), together with the attached plug connectors D50.X4, D50, X4A and D50.X7, as
follows:
•Attach the cables to the monitor trolley using cable ties.
Fig. 13 Cabling of SIEMENS displays Fig. 14 Routing the cables
Y-cable connector D50.X4A ----- ON/OFF assembly board D50, connector D50.X4
Y-cable, coupling D50.X4 ----- Cable of radiation indicator, connector D50.X4
Y-cables, coupling D50.X7 ----- New support arm, radiation indicator, connector
D50.X7

Installation of TFT displays 2 - 7
Siemens AG SPR2-230.812.02 Page 7 of 8 SIREMOBIL
Medical Solutions Rev. 02 02.06 CS PS SP System Manual
Wiring of the displays 2
•Open the rear panel of both TFT displays above the connections.
•Route the power line cables and the video cables to the TFT displays.
BARCO displays 2
•Connect the video cable to the BNC sockets VIDEO of the displays and lock it.
•Connect the shieldings of the video cables to the ground of the display.
•Plug in the power cables.
•Close both covers again located above the display connections.
Running the cables 2
•If required, retract the power line cables and video cables into the monitor trolley.
- Route the cables without sharp bending radius.
- It is recommended to ensure that the cables are covered by both support arm rails in
the area between support arm base and the displays (see Fig. 11).
- The cables should rest in the cable bushes of the support arm base without excessive
pulling force or stress (Fig. 15).
•Reattach the cover of the support arm (Fig. 15).
•When present, switch on the power switches of the TFT displays.
Fig. 15 Cover of the support arm
Mark for the keyboard tray

SIREMOBIL SPR2-230.812.02 Page 8 of 8 Siemens AG
System Manual Rev. 02 02.06 CS PS SP Medical Solutions
2 - 8 Installation of TFT displays
This page is intentionally left blank.

3 - 1
Siemens AG SPR2-230.812.02 Page 1 of 2 SIREMOBIL
Medical Solutions Rev. 02 02.06 CS PS SP System Manual
Settings 3
TFT display BARCO MVG 1318, part number 80 79 530 3
•Make the checks and if necessary settings according to the replacement instructions
TD00-000.841.17...
Refer to the System-dependent settings chapter of the instructions.
Concluding work 3
•Close all covers again. Make sure that the protective ground wire connections make
good contact.
•Perform the protective ground wire test according to TD00-000.860.01.
The protective ground wire resistance must not exceed 0.2 ohms.
•Perform the IQ quick test of the system.
•Perform the country-specific acceptance tests (part acceptance).

SIREMOBIL SPR2-230.812.02 Page 2 of 2 Siemens AG
System Manual Rev. 02 02.06 CS PS SP Medical Solutions
3 - 2 Settings
This page is intentionally left blank.

4 - 1
Siemens AG SPR2-230.812.02 Page 1 of 2 SIREMOBIL
Medical Solutions Rev. 02 02.06 CS PS SP System Manual
Changes to previous version 4
Editorial revised
Descriptions for SIEMENS and other TFT displays deleted.

SIREMOBIL SPR2-230.812.02 Page 2 of 2 Siemens AG
System Manual Rev. 02 02.06 CS PS SP Medical Solutions
4 - 2 Changes to previous version
This page intentionally left blank.
