Siemens SENTRON 7KN POWERCENTER 3000 User manual

SENTRON
IoT data platforms
7KN POWERCENTER 3000
Equipment Manual
V1.2
07/2020
L1V30579222003
-03
Introduction
1
Safety information
2
Description
3
Installing, connecting,
commissioning
4
Functions
5
Application examples
6
Service and maintenance
7
FAQs
8
Technical data
9
Dimensional drawings
10
Appendix
A
Technical support
B

Siemens AG
Smart Infrastructure
Electrical Products
Postfach 10 09 53
93009 Regensburg
GERMANY
Ⓟ
08/2020 Subject to change
Copyright © Siemens AG 2019.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

7KN POWERCENTER 3000
Equipment Manual, 07/2020, L1V30579222003-03 3
Table of contents
1 Introduction........................................................................................................................................... 7
1.1 Reference documents .......................................................................................................... 7
1.2 Advanced training courses ................................................................................................... 8
1.3 Technical Support ................................................................................................................ 8
2 Safety information................................................................................................................................. 9
2.1 General safety information .................................................................................................. 9
2.2 Security information .......................................................................................................... 11
2.3 Information on use ............................................................................................................ 11
2.4 Open Source Software ....................................................................................................... 12
3 Description........................................................................................................................................... 13
3.1 Product description............................................................................................................ 13
3.2 Design of the devices......................................................................................................... 14
3.2.1 Operating displays of the devices ....................................................................................... 15
3.3 Accessories........................................................................................................................ 16
3.4 Hardware description......................................................................................................... 16
3.4.1 Data interfaces .................................................................................................................. 16
4 Installing, connecting, commissioning................................................................................................ 19
4.1 Preparing installation......................................................................................................... 19
4.1.1 Checking delivery .............................................................................................................. 19
4.1.2 Identification data of the device......................................................................................... 21
4.1.3 Permissible mounting positions.......................................................................................... 22
4.1.3.1 Upright mounting.............................................................................................................. 23
4.1.3.2 Upright mounting on DIN rails............................................................................................ 24
4.1.3.3 Wall mounting................................................................................................................... 25
4.1.3.4 Mounting on DIN rails........................................................................................................ 26
4.2 Mounting the device.......................................................................................................... 27
4.2.1 Mounting instructions........................................................................................................ 27
4.3 Connecting the device ....................................................................................................... 28
4.3.1 Instructions for connection ................................................................................................ 28
4.3.2 Connecting the ground conductor...................................................................................... 30
4.3.3 Connecting the power supply............................................................................................. 31
4.4 Connecting the device to networks .................................................................................... 33
4.5 Commissioning a device .................................................................................................... 33
4.5.1 Instructions for commissioning .......................................................................................... 33
4.5.2 Switching the device on/off................................................................................................ 34

Table of contents
7KN POWERCENTER 3000
4Equipment Manual, 07/2020, L1V30579222003-03
4.6 Interfaces of the 7KN POWERCENTER 3000......................................................................... 35
4.6.1 Internal Ethernet interface for the smart assembly network ................................................ 35
4.6.1.1 Performance features of the smart assembly interface........................................................ 35
4.6.2 External Ethernet interface with the intranet...................................................................... 37
4.6.2.1 Performance features of the external Ethernet interface..................................................... 37
4.7 Security features................................................................................................................ 38
4.7.1 Security features of the 7KN POWERCENTER 3000. ............................................................. 39
4.7.2 Further recommended security measures........................................................................... 40
5 Functions ............................................................................................................................................. 43
5.1 Commissioning with powerconfig...................................................................................... 45
5.1.1 First commissioning........................................................................................................... 45
5.2 Web user interface............................................................................................................. 46
5.2.1 Contents of the Web user interface .................................................................................... 47
5.2.1.1 Toolbar.............................................................................................................................. 48
5.2.1.2 Widgets ............................................................................................................................. 49
5.2.1.3 Messages .......................................................................................................................... 49
5.2.2 Settings via the web user interface..................................................................................... 51
5.2.3 Write protection in the web user interface.......................................................................... 52
5.3 Exporting recorded data..................................................................................................... 53
5.3.1 Backing up data records..................................................................................................... 53
5.3.2 Explicit export of energy data for ISO 50001 ...................................................................... 54
5.3.3 Periodic export of energy data for ISO 50001 ..................................................................... 55
5.3.4 Display and export with the archive chart........................................................................... 57
5.3.5 Designation and content of the exported energy data ........................................................ 58
5.4 Display and export of daily trends ...................................................................................... 59
5.5 Communication with MindSphere...................................................................................... 60
5.5.1 Communication with SENTRON powermind ....................................................................... 61
5.5.1.1 Setting the SENTRON MindSphere application with 7KN POWERCENTER 3000..................... 62
5.5.2 MindSphere application support ........................................................................................ 63
5.5.2.1 Grouping the information .................................................................................................. 64
5.5.2.2 Onboarding with 7KN POWERCENTER 3000........................................................................ 65
5.5.2.3 Transferring the manual settings in MindSphere................................................................. 67
5.5.3 Starting MindSphere data transfer...................................................................................... 67
5.6 Cloud service with MQTT ................................................................................................... 68
5.6.1 Value selection for the cloud.............................................................................................. 69
5.6.2 Connecting 7KN POWERCENTER 3000 to the cloud............................................................. 70
5.6.3 Analysis of the database .................................................................................................... 71
5.6.4 Structure of the 7KN POWERCENTER 3000 data points........................................................ 74
5.7 Notification of exceptional situations ................................................................................. 75
5.7.1 Setting the notifications..................................................................................................... 75
5.7.2 Connecting to an email server............................................................................................ 76
5.7.3 Selection of events to be reported...................................................................................... 77
5.8 7KN POWERCENTER 3000 as a Modbus gateway................................................................. 78
5.8.1 Addressing via the 7KN POWERCENTER 3000 gateway........................................................ 79
5.8.2 Method of operation of the 7KN POWERCENTER 3000 Modbus TCP Gateway ...................... 80

Table of contents
7KN POWERCENTER 3000
Equipment Manual, 07/2020, L1V30579222003-03 5
5.9 Modbus devices................................................................................................................. 81
5.9.1 Creating and configuring a Modbus device......................................................................... 82
5.9.1.1 Example for addressing a data point................................................................................... 84
5.9.1.2 Supported data formats ..................................................................................................... 85
5.9.2 Integrating the Modbus device into the communication ..................................................... 86
5.9.3 Displaying a Modbus device with powerconfig ................................................................... 87
5.9.4 Preparing a Modbus device for the cloud............................................................................ 87
5.10 Time synchronization......................................................................................................... 88
5.10.1 Time synchronization of the connected devices.................................................................. 88
5.11 Saving and further processing setup................................................................................... 88
6 Application examples .......................................................................................................................... 89
6.1 Network environments ...................................................................................................... 90
6.1.1 Internet communication .................................................................................................... 91
6.1.2 External communication .................................................................................................... 93
6.2 Web-based applications ..................................................................................................... 96
6.2.1 Local visualization of a switchboard ................................................................................... 96
6.3 Entry into energy management in accordance with ISO 50001 ........................................... 97
6.4 MindSphere for smart assembly network............................................................................ 98
6.4.1 SENTRON powermind ........................................................................................................ 98
6.4.2 Other MindSphere applications .......................................................................................... 99
6.4.3 Security aspects of MindSphere communication................................................................. 99
6.5 Integrating existing power distribution systems into the digitalization .............................. 100
6.5.1 Cloud applications with the 7KN Powercenter 3000.......................................................... 100
6.5.2 Integrating other Modbus devices into the digitalization................................................... 101
6.6 Synchronized time of day, as the basis for digitalization ................................................... 102
6.7 Identifying and eliminating exceptional situations............................................................ 103
6.8 Modbus TCP communication with higher-level applications .............................................. 104
6.8.1 Security aspects of the 7KN POWERCENTER 3000 as a gateway......................................... 104
6.9 Interface with a wireless LAN interface............................................................................. 105
6.9.1 Security aspects of the wireless LAN interface .................................................................. 105
6.10 Interface with a cellular network...................................................................................... 106
7 Service and maintenance .................................................................................................................. 109
7.1 Repair instructions ........................................................................................................... 109
7.2 Fault rectification............................................................................................................. 110
7.2.1 Diagnostic data................................................................................................................ 112
7.3 Firmware update ............................................................................................................. 113
7.3.1 Finding the update in SIOS............................................................................................... 113
7.3.2 Firmware update via Web user interface........................................................................... 113
7.4 Replacing the backup battery ........................................................................................... 114
7.5 Recycling and disposal ..................................................................................................... 117

Table of contents
7KN POWERCENTER 3000
6Equipment Manual, 07/2020, L1V30579222003-03
8 FAQs................................................................................................................................................... 119
8.1 No firmware update via powerconfig ............................................................................... 119
8.2 Version management between powerconfig and 7KN POWERCENTER 3000...................... 119
8.3 Special aspects of powerconfig V3.15 .............................................................................. 120
8.4 Modifications in smart assembly networks ....................................................................... 121
9 Technical data ................................................................................................................................... 123
9.1 General technical data ..................................................................................................... 123
9.2 Funktionsumfang des 7KN POWERCENTER 3000 .............................................................. 124
9.3 Environmental conditions ................................................................................................ 125
9.4 Current requirement of the components .......................................................................... 126
9.5 DC power supply.............................................................................................................. 126
10 Dimensional drawings....................................................................................................................... 127
10.1 Dimensional drawing of basic device................................................................................ 127
A Appendix ........................................................................................................................................... 129
A.1 List of abbreviations......................................................................................................... 129
A.2 ESD guidelines................................................................................................................. 129
A.2.1 Electrostatic sensitive devices (ESD) ................................................................................. 129
A.3 Labels and symbols.......................................................................................................... 132
A.3.1 Overview......................................................................................................................... 132
A.3.2 Safety.............................................................................................................................. 132
A.3.3 Operator controls ............................................................................................................ 132
A.3.4 Certificates, approvals and labels ..................................................................................... 132
B Technical support .............................................................................................................................. 133
B.1 Service and support ......................................................................................................... 133
Glossary ............................................................................................................................................. 135
Index.................................................................................................................................................. 141

7KN POWERCENTER 3000
Equipment Manual, 07/2020, L1V30579222003-03 7
Introduction
1
This manual contains all information required to commission and use the 7KN Powercenter
3000. It is aimed both at programmers and testers who commission the device themselves
and connect them to other units, e.g. energy monitoring, automation systems or SCADA
systems, and at service and maintenance technicians who install expansions or perform error
analyses.
Required basic knowledge
In addition to knowledge about the design of a low-voltage power distribution system, basic
knowledge of Ethernet technology and industrial communication is required.
Scope of validity of this document
This manual applies to all V1.x versions of the 7KN Powercenter 3000.
Conventions
In this documentation, the term "Device" is used instead of the product label
7KN Powercenter 3000.
History
The following editions of the manual have been published so far:
Edition
Comment
08/2019
First edition
03/2020
Version 02
1.1 Reference documents
You can find further details in the following documents:
Title
Article number
Quick Installation Guide 7KN POWERCENTER 3000
(https://support.industry.siemens.com/cs/ww/en/view/109766001)
L1V30579222002

Introduction
1.2 Advanced training courses
7KN POWERCENTER 3000
8Equipment Manual, 07/2020, L1V30579222003-03
1.2 Advanced training courses
Find out about training courses on offer on the following link.
Training for Industry (https://www.siemens.de/sitrain-lowvoltage)
Here you can choose from:
•Web-based training courses (online, informative, free)
•Classroom training courses (course attendance, comprehensive, subject to fee)
You also have the possibility of compiling your own training portfolio via Learning paths.
1.3 Technical Support
You can find further support on the Internet at:
Technical Support (https://www.siemens.com/lowvoltage/technical-support)

7KN POWERCENTER 3000
Equipment Manual, 07/2020, L1V30579222003-03 9
Safety information
2
2.1 General safety information
WARNING
The safety of a system in which the device is integrated is the responsibility of those
who install the system.
There is danger of a malfunction resulting in death of serious injury.
•
Ensure only qualified personnel perform work.
WARNING
Lethal voltage when the control cabinet is open.
If you install the device in a control cabinet, individual areas or components in the control
cabinet might be carrying a lethal voltage. If you touch these areas or components, this can
result in death due to electric shock.
•
Disconnect the control cabinet completely so that it is dead before opening it.
System expansions
NOTICE
Damage due to system expansions
Device and system expansions can be faulty and affect the entire machine or plant.
Installation of expansions can damage the device, machine or plant. Device or system
expansions can violate safety rules and regulations relating to interference suppression.
The warranty is voided if you cause faults in the device due to installation or replacement of
system expansions.

Safety information
2.1 General safety information
7KN POWERCENTER 3000
10 Equipment Manual, 07/2020, L1V30579222003-03
Battery
WARNING
Danger of explosion and danger of release of harmful substances
Improper handling of lithium batteries can result in explosion of the batteries.
Explosion of the batteries and the resulting release of harmful substances can result in
serious injury. Worn batteries endanger the function of the device.
When handling lithium batteries, please note:
•Replace depleted batteries in a timely manner, see Replacing backup battery (Page 114).
•Replace the lithium battery only with identical types or types recommended by the
manufacturer (Order No.: A5E34345932).
•Do not throw batteries into a fire, do not solder on the body of the cell, do not recharge,
open, or short-circuit batteries, do not connect batteries with incorrect polarity, do not
heat batteries above 100 °C (212 °F), and protect batteries from direct sunlight, humidity
and condensation.
Radio-frequency radiation
NOTICE
Consider immunity to interference due to radio-frequency radiation
The device has enhanced immunity to interference caused by radio-frequency radiation in
accordance with the electromagnetic compatibility specifications in the technical data.
Irradiation above the specified immunity levels can impair the function of the device, result
in malfunctions and injury or damage to property.
Note the specifications for immunity to interference caused by radio-frequency radiation in
the technical data.

Safety information
2.2 Security information
7KN POWERCENTER 3000
Equipment Manual, 07/2020, L1V30579222003-03 11
2.2 Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be connected
to an enterprise network or the Internet if and to the extent such a connection is necessary
and only when appropriate security measures (e.g. firewalls and/or network segmentation)
are in place.
For additional information on industrial security measures that may be implemented, please
visit (https://www.siemens.com/industrialsecurity).
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customer's exposure to
cyber threats.
To keep up to date with all the latest product updates, subscribe to the Siemens Industrial
Security RSS Feed at (https://www.siemens.com/industrialsecurity).
2.3 Information on use
NOTICE
Possible functional restrictions when the function of the plant has not been validated
The device is tested and certified based on the technical standards. In rare cases, functional
restrictions can occur during operation of your plant.
To avoid functional restrictions, validate the correct function of the plant.
Note
Use in
industry without additional protective measures
The device was designed for use in a normal industrial environment in accordance with
IEC 60721-3-3.
NOTICE
Cleaning
Clean the surface of the housing with a damp cloth and make sure that no water enters the
interior of the device.

Safety information
2.4 Open Source Software
7KN POWERCENTER 3000
12 Equipment Manual, 07/2020, L1V30579222003-03
2.4 Open Source Software
This product, solution or service ("Product") contains third-party software components. These
components are Open Source Software licensed under a license approved by the Open
Source Initiative (https://www.opensource.org) or similar licenses as determined by SIEMENS
("OSS") and/or commercial or freeware software components. With respect to the OSS
components, the applicable OSS license conditions prevail over any other terms and
conditions covering the Product. The OSS portions of this Product are provided royalty-free
and can be used at no charge.
If SIEMENS has combined or linked certain components of the Product with/to OSS
components licensed under the GNU LGPL version 2 or later as per the definition of the
applicable license, and if use of the corresponding object file is not unrestricted ("LGPL
Licensed Module", whereas the LGPL Licensed Module and the components that the LGPL
Licensed Module is combined with or linked to is the "Combined Product"), the following
additional rights apply, if the relevant LGPL license criteria are met: (i) you are entitled to
modify the Combined Product for your own use, including but not limited to the right to
modify the Combined Product to relink modified versions of the LGPL Licensed Module, and
(ii) you may reverse-engineer the Combined Product, but only to debug your modifications.
The modification right does not include the right to distribute such modifications and you
shall maintain in confidence any information resulting from such reverse-engineering of a
Combined Product.
Certain OSS licenses require SIEMENS to make source code available, for example, the GNU
General Public License, the GNU Lesser General Public License and the Mozilla Public License.
If such licenses are applicable and this Product is not shipped with the required source code, a
copy of this source code can be obtained by anyone in receipt of this information during the
period required by the applicable OSS licenses by contacting the following address:
Siemens AG
Smart Infrastructure
Electrical Products
Technical Support
Postfach 10 09 53
93009 Regensburg
Germany
You will find Technical Support under (https://www.siemens.com/lowvoltage/technical-
support).
Keyword: Open Source Request (please specify Product name and version, if applicable)
SIEMENS may charge a handling fee of up to 5 EUR to fulfil the request.
Warranty regarding further use of the Open Source Software
SIEMENS' warranty obligations are set forth in your agreement with SIEMENS. SIEMENS does
not provide any warranty or technical support for this Product or any OSS components
contained in it if they are modified or used in any manner not specified by SIEMENS. The
license conditions may contain disclaimers that apply between you and the respective
licensor. For the avoidance of doubt, SIEMENS does not make any warranty commitment on
behalf of or binding upon any third-party licensor. The Open Source Software used in the
product and the license agreements concerning this software can be found in the
Readme_OSS.

7KN POWERCENTER 3000
Equipment Manual, 07/2020, L1V30579222003-03 13
Description
3
3.1 Product description
Overview
The 7KN Powercenter 3000 has high industrial functionality.
•Compact dimensions
•Highly robust

Description
3.2 Design of the devices
7KN POWERCENTER 3000
14 Equipment Manual, 07/2020, L1V30579222003-03
3.2 Design of the devices
Interfaces and connections
①
Ground connection
②
Connection for the 24 V DC power supply
③
2 x USB 3.0 port, high current
④
Not used
⑤
2 x RJ45 Ethernet port X1P1 and X2P1 for 10/100/1000 Mbps
⑥
X2P1 Ethernet connection for first commissioning
⑦
On-off switch; for function, see Switching the device on/off (Page 34)
⑧
LED displays
Note
The device starts as soon as it is energized,
Because of this, there is no need to press the ON/OFF switch to switch on the device.

Description
3.2 Design of the devices
7KN POWERCENTER 3000
Equipment Manual, 07/2020, L1V30579222003-03 15
3.2.1 Operating displays of the devices
LED name
Status
Description
PC ON/WD
Off
No voltage
Green
BIOS active
Flashing green / yellow (4 Hz)
Power ON self-test
Yellow
Idle state / shutdown
Flashing red (4 Hz)
Fault monitoring has triggered
L1 RUN/STOP
Off
Not used
Flashing green (2 Hz)
7KN Powercenter 3000 starting
Green
7KN Powercenter 3000 active
Yellow
Not used
L2 ERROR
Off
Not used
Red
Serious error
Yellow
Alert
L3 MAINT
Off
Not used
Flashing yellow (2 Hz)
Firmware updating (do not switch off)
Yellow
Not used
Red
Not used
L1 RUN/STOP
and
L2 ERROR
and
L3 MAINT
Flashing yellow (2 Hz)
The device "identifies" itself.
•An "Activate blinking mode" has been started
via powerconfig in the search function:
Ethernet.
•Via the web user interface, the command
"Identify device" *) has been executed
*) See: Settings → Actions → Device

Description
3.3 Accessories
7KN POWERCENTER 3000
16 Equipment Manual, 07/2020, L1V30579222003-03
3.3 Accessories
This section contains the range of accessories available at the time of production of the
manual.
Wall mounting
6AG4021-0AA20-0AA2
Upright mounting for the
7KN Powercenter 3000
6AG4021-0AA20-0AA3
Upright mounting on DIN rails
6AG4021-0AA20-0AA5
Lithium battery
A5E44491494
You will find further information on the Internet at:
•Service & Support (https://support.industry.siemens.com/cs/ww/en/)
3.4 Hardware description
3.4.1 Data interfaces
Interface overview
Interface
Use
Description
X1P1
Ethernet
Intranet
RJ45
10/100/1000 Mbps
X2P1
Ethernet
Smart assembly
network
RJ45
10/100/1000 Mbps
X60
USB
Not used
USB channel
USB 3.0
X61
USB
Not used
USB channel
USB 3.0
X70
Not used
X80
24 V DC
Power supply

Description
3.4 Hardware description
7KN POWERCENTER 3000
Equipment Manual, 07/2020, L1V30579222003-03 17
Ethernet interface
LED
Short code
Meaning
1
LED 1
Off: 10 Mbps
Lights up green: 100 Mbps
Lights up yellow: 1000 Mbps
2
LED 2
Lights up yellow: Connection established
Flashing: Activity

Description
3.4 Hardware description
7KN POWERCENTER 3000
18 Equipment Manual, 07/2020, L1V30579222003-03
